UTILITY BENCH
Assembly Manual
2 UTILITY BENCH - Assembly Manual
M10x170mm Bolt
x3
10
M10x90mm Bolt
x2
11
Allen Wrench
x1
26
Inner Washer
x2
18
M10 Washer
x12
15
1
HARDWARE PACK
Spanner x1
NOT INCLUDED
M10 Nylon Locknut
x2
14
M10x90mm Bolt x2
11
M10x20mm Bolt x2
12
Spanner x1
1
Screwdriver x1
15
11
11
15
2
12
12
15
15
14
14
15
M10x20mm Bolt
x2
12
M6x40mm Bolt
x8
13
Allen Wrench x1
26
M10 Washer x6
15
M10 Nylon Locknut
x5
14
www.reebokfitness.com 3
2
3
Allen Wrench x1
26
Spanner x1
M10x170mm Bolt x3
10
M10 Nylon Locknut
x3
14
M10 Washer x6
15
Spanner x1
8
7
13
13
13
13
13 13
13
13
10
10
10
15
15
15
4
4
15
14
14
15
15
14
5
6
18
18
3
Allen Wrench x1
26
M6x40mm x8
13
Inner Washer x2
18
4 UTILITY BENCH - Assembly Manual
4
www.reebokfitness.com 5
www.reebokfitness.info/product-support
This product is suitable for user’s
weight of 100kg.
100
kg
150
kg
This product is suitable for a max
load of 150kg.
USER INFORMATION
6 UTILITY BENCH - Assembly Manual
8
7
10
10
10
20
9
21
22
1
11
15
23
5
18
18
21
11
15
25
13
17
17
16
13
17
25
17
14
15
21
6
2
12
15
24
15
12
23
21
13
13
13
14
15
13
14
15
19
21
15
19
19
19
13
15
14
15
13
13
3
Part No. Code Description QTY
1 PFM0002-01 Frame 1
2 PFM0002-02 Rear Horizontal Beam 1
3 PFM0002-03 Backrest Tube 1
4 PFM0002-04 Seat Tube 2
5 PFM0002-05 Seat Support Bar 1
6 PFM0002-06 Backrest Support Bar 1
7 PFM0002-07 Seat 1
8 PFM0002-08 Backrest 11
9 PFM0002-09 Ø32xØ23x240 Foam Pad 1
10 PFM0002-10 M10 x 170mm Bolt 3
11 PRKG19A-04 M10 x 90mm Bolt 2
12 PFM404-18 M10 x 20mm Bolt 2
13 PFMCS704MF-18 M6 x 40mm Bolt (A - 8) (B - 2) 10
14 PFMS80-27 M10 Nylon Locknut 5
15 PRK1-06 M10 Washer 12
16 PHHBXROK002-26 M6 Nylon Locknut 2
17 PFMS80-22 M6 Washer 4
18 PFMH1001-46 Inner Washer #12.5 2
19 PFM2240-32 25mm Square Inner Cap 6
20 PFM0002-11 25mm Round Angled Cap 1
21 PFM0002-12 Ø19*45mm Handle 4
22 PFM0002-13 200*60 Rubber Strip 1
23 PFM0002-14 85*60 Rubber Strip 2
24 PFM0002-15 50*50 Rubber Strip 1
25 PFMCB804DX-10 Wheel 1
26 PFMALLEN10 Allen Wrench 1
