User Manual LG LW8021HRSM 7,500 BTU Smart Wi-Fi Enabled Window Air Conditioner

The LG 7,500 BTU Smart Wi-Fi Enabled Window Air Conditioner, Cooling & Heating, Model # LW8021HRSM is not designed for installation in horizontal-sliding windows. It is designed for installation in standard single-hung o double-hung windows that have actual opening widths from 22" to 36". The top and bottom windows sashes must open sufficiently to allow a clear vertical opening of 14" from the bottom of the upper sash to the inside sill.

The specifications on our product detail page for the LG 7,500 BTU Smart Wi-Fi Enabled Window Air Conditioner, Cooling & Heating, Model # LW8021HRSM list BTU Performance (Heating) as 3,850 so it will have a power consumption of 343.75W/hr.

When the LG 7,500 BTU Smart Wi-Fi Enabled Window Air
Conditioner, Cooling & Heating, Model # LW8021HRSM is in AC Mode, the condensate that drips off the evaporator coils collects in the base pan at the bottom of the unit which is why it is recommended that you install the cabinet with a slight tilt (about 1/2") downward on the outside. The unit is equipped with a slinger fan that has an outer ring that picks up the condensed water from the base pan if the water level gets high enough. The water is then picked up by the fan and expelled through the condenser, making their conditioner more efficient. In humid weather, excess water may cause the base pan to overflow. To drain the water, remove the drain cap and secure the supplied drain pipe to the rear hole of the base pan. Press the drain pipe into the hole by pushing down and away from the fins to avoid injury.
