PLASMA
TV
OWNER'S
MANUAL
Please
read
this
manual
carefully
and
completely
before
operating
your
TV.
Retain
this
manual
for
future
reference.
Record
model
number
and
serial
number
of
the
TV
in
the
spaces
provided
below.
See
the
label
attached
on
the
back
cover
and
relate
this
information
to
your
dealer
if
you
require
service.
Model
Number
:
Serial
Number
:
MODEL:
42PX7DC
42PX7DCV
LG
Electronics
U.S.A.,
Inc.
2
Plasma
TV
WARNING/CAUTION:
TO
REDUCE
THE
RISK
OF
ELECTRIC
SHOCK
DO
NOT
REMOVE
COVER
(OR
BACK).
NO
USER
SERVICEABLE
PARTS
INSIDE.
REFER
TO
QUALIFIED
SERVICE
PERSONNEL.
The
lightning
flash
with
arrowhead
symbol,
within
an
equilateral
triangle,
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
"dangerous
voltage"
within
the
product's
enclosure
that
may
be
of
suffi-
cient
magnitude
to
constitute
a
risk
of electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
important
operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
the
appli-
ance.
WARNING/CAUTION:
TO PREVENT
FIRE
OR
SHOCK
HAZARDS,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
FCC
NOTICE
?
A
Class
B
digital
device
This
equipment
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B
digital
device,
pursuant
to
Part
15
of
the
FCC
Rules.
These
limits
are
designed
to
provide
reasonable
protection
against
harmful
interference
in
a
residential
installation.
This
equipment
generates,
uses
and
can
radiate
radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instructions,
may
cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular
installation.
If
this
equipment
does
cause
harmful
interference
to
radio
or
television
reception,
which
can
be
determined
by
turning
the
equipment
off
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
the
following
measures:
-
Reorient
or
relocate
the
receiving
antenna.
-
Increase
the
separation
between
the
equipment
and
receiver.
-
Connect
the
equipment
into
an
outlet
on
a
circuit
different
from
that
to
which
the
receiver
is
connected.
-
Consult
the
dealer
or
an
experienced
radio/TV
technician
for
help.
?
Any
changes
or
modifications
not
expressly
approved
by
the
party
responsible
for
compli-
ance
could
void
the
user's
authority
to
operate
the
equipment.
CAUTION:
Do
not
attempt
to
modify
this
product
in
any
way
without
written
authorization
from
LG
Electronics.
Unauthorized
mod-
ification
could
void
the
user's
authority
to
operate
this
product.
COMPLIANCE:
The
responsible
party
for
this
product's
compliance
is:
LG
Electronics
U.S.A.,
Inc
1000
Sylvan
Avenue,
Englewood
Cliffs,
NJ
07632
1-800-243-0000
http://www.lgcommercial.com
WARNING/CAUTION
WARNING/CAUTION
TO
REDUCE
THE
RISK
OF
FIRE
AND
ELECTRIC
SHOCK,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
W
W
arning/Caution
arning/Caution
Owner's
Manual
3
IMPORTANT
SAFETY
INSTRUCTIONS
Important
safety
instructions
shall
be
provided
with
each
apparatus.
This
information
shall
be
given
in
a
separate
booklet
or
sheet,
or
be
located
before
any
operating
instructions
in
an
instruction
for
installation
for
use
and
supplied
with
the
appara-
tus.
This
information
shall
be
given
in
a
language
acceptable
to
the
country
where
the
apparatus
is
intended
to
be
used.
The
important
safety
instructions
shall
be
entitled
"Important
Safety
Instructions".
The
following
safety
instructions
shall
be
includ-
ed
where
applicable,
and,
when
used,
shall
be
verbatim
as
follows.
Additional
safety
information
may
be
included
by
adding
statements
after
the
end
of
the
following
safety
instruction
list.
At
the
manufacturer
's
option,
a
or
drawing
that
illus-
trates
the
intent
of
a
specific
safety
instruction
may
be
placed
immediately
adjacent
to
that
safety
instruction
:
1.
Read
these
instructions.
2.
Keep
these
instructions.
3.
Heed
all
warnings.
4.
Follow
all
instructions.
5.
Do
not
use
this
apparatus
near
water.
6.
Clean
only
with
dry
cloth.
7.
Do
not
block
any
ventilation
openings.
Install
in
accordance
with
the
manufacturer
's
instructions.
8.
Do
not
install
near
any
heat
sources
such
as
radiators,
heat
registers,
stoves,
or
other
apparatus
(including
ampli-
fiers)that
produce
heat.
9.
Do
not
defeat the
safety
purpose
of
the
polarized
or
grounding-type
plug.
A
polarized
plug
has
two
blades
with
one
wider
than
the
other.
A
grounding
type
plug
has
two
blades
and
a
third
grounding
prong,
The
wide
blade
or
the
third
prong
are
provided
for
your
safety.
If
the
provided
plug
does
not
fit
into
your
outlet,
consult
an
electrician
for
replacement
of
the
obsolete
outlet.
10.
Protect
the
power
cord
from
being
walked
on
or
pinched
particularly
at
plugs,
convenience
receptacles,
and
the
point
where
they
exit
from
the
apparatus.
11.
Only
use
attachments/accessories
specified
by
the
manufacturer.
12.
Use
only
with
the
cart,
stand,
tripod,
bracket,
or
table
specified
by
the
manufacturer,
or
sold
with the
apparatus.
When
a
cart
is
used,
use
caution
when
moving
the
cart/apparatus
combination
to
avoid
injury
from
tip-over.
Safety
Instructions
Safety
Instructions
PORTABLE
CART
WARNING
4
Plasma
TV
13.
Unplug
this
apparatus
during
lightning
storms
or
when
unused
for
long
periods
of
time.
14.
Refer
all
servicing
to
qualified
service
personnel.
Servicing
is
required
when
the
apparatus
has
been
damaged
in
any
way,
such
as
power-supply
cord
or
plug
is
damaged,
liquid
has
been
spilled
or
objects
have
fallen
into
the
apparatus,
the
apparatus
has
exposed
to
rain
or
moisture,
does
not
operate
normally,
or
has
been
dropped.
15.
CAUTION
concerning
the
Power
Cord
:
Most
appliances
recommend
they
be
placed
upon
a
dedicated
circuit;
that
is,
a
single
outlet
circuit
which
powers
only
that
appliance
and
has
no
additional
outlets
or
branch
circuits.
Check
the
specification
page
of
this
owner's
manual
to
be
certain.
Do
not
overload
wall
outlets.
Overloaded
wall
outlets,
loose
or
damaged
wall
outlets,
extension
cords,
frayed
power
cords,
or
damaged
or
cracked
wire
insulation
are
dangerous.
Any
of
these
conditions
could
result
in
electric
shock
or
fire.
Periodically
examine
the
cord
of
your
appliance,
and
if
its
appearance
indicates
damage
or
deterioration,
unplug
it,
discontinue
use
of
the
appliance,
and
have
the
cord
replaced
with
an
exact
replacement
part
by
an
authorized
servicer.
Protect
the
power
cord
from
physical
or
mechanical
abuse,
such
as
being
twisted,
kinked,
pinched,
closed
in
a
door,
or
walked
upon.
Pay
particular
attention
to
plugs,
wall
outlets,
and
the
point
where
the
cord
exits
the
appliance.
16.
Outdoor
Use
Marking
:
WARNING
-
To
Reduce
The
Risk
Of
Fire
Or
Electric
Shock,
Do
Not
Expose
This
Appliance
To
Rain
Or
Moisture.
17.
Wet
Location
Marking
:
Apparatus
shall
not
be
exposed
to
dripping
or
splashing
and
no
objects
filled
with
liquids,
such
as
vases,
shall
be
placed
on
the
apparatus.
Safety
Instructions
Safety
Instructions
Owner's
Manual
5
After
reading
this
manual,
keep
it
handy
for
future
reference.
Warning/Caution................................2
SafetyInstructions.............................3~4
Introduction
Controls...............................7
ConnectionOptions......................8
RemoteControlKeyFunctions.
. . . . . . . . .
.9~10
Installation
Accessories.............................11
Installation
Instructions
Joining
the
TV
assembly
to
the
wall
to
protect
the
set
tumbling................................11
DesktopPedestalInstallation................12
External
Equipment
Connections
AntennaConnection.....................13
VCRSetup...........................14
ExternalA/VSourceSetup................14
DVDSetup............................15
HDSTBSetup.........................16
PCSetup..........................17~18
DigitalAudioOutput.....................19
Operation
TurningtheTVOn........................20
On-screen
Menus
Language
Selection
. . . . . . . .
.20
Setup
Menu
Options
EZScan(ChannelSearch)................21
ManualScan..........................21
ChannelEdit...........................22
DTVSignalStrength.....................22
ChannelLabelSetup....................23
MainInput............................23
SubInput.............................24
SetID................................24
Video
Menu
Options
EZPicture............................25
Manual
Control
(Custom
Option)
. . . . .
.25
ColorTemperatureControl................25
VideoReset...........................25
Audio
Menu
Options
AudioLanguage........................26
EZSoundRite/EZSound.................26
Manual
Sound
Control
(Custom
Option)
. . . . .
.26
FrontSurround.........................27
TVSpeakersOn/OffSetup................27
BBE.................................28
Stereo/SAPBroadcastsSetup.
. . . . . . . . . . . .
.28
Time
Menu
Options
AutoClockSetup.......................29
ManualClockSetup.....................29
On/OffTimerSetup.....................29
SleepTimer/AutoOff....................30
Option
Menu
Features
AspectRatioControl.....................31
Cinema3:2ModeSetup..................31
Caption...............................32
Caption/Text..........................32
CaptionOption........................33
ISMMethod...........................33
LowPower............................34
Lock
Menu
Options
ParentalLockSetup.....................36
Brief
Info.
.............................37
Mute..................................38
Freeze.................................38
ScreenSetupforPCmode..................39
KeyCode...................................40
ProgrammingtheRemote......................41
ProgrammingCodes.......................42~43
TroubleshootingChecklist......................44
Maintenance.................................45
ProductSpecifications.........................46
Warranty.................................47~48
Contents
Contents
6
Plasma
TV
Introduction
Introduction
What
is
a
Plasma
Display
Panel
(PDP)?
A
plasma
display
panel
is
the
latest
display
technology
and
the
best
way
to
achieve
flat
panel
displays
with
excellent
quality
and
large
screen
sizes
that
are
easily
viewable.
The
PDP
can
be
thought
of
as
a
descendant
of
the
neon
lamp
and
it
can
be
also
be
viewed
as
a
series
of
fluorescent
lamps.
How
does
it
work?
PDP
is
an
array
of
cells,
known
as
pixels,
which
are
comprised
of
3
sub
pixels,
corresponding
to
the
colors
red,
green,
and
blue.
Gas
in
a
plasma
state
is
used
to
react
with
phosphors
in
each
sub-pixel
to
produce
colored
light
(red,
green,
or
blue).
These
phos-
phors
are
the
same
types
used
in
Cathode
Ray
Tube
(CRT)
devices
such
as
televisions
and
common
computer
monitors.
You
get
the
rich,
dynamic
colors
that
you
expect.
Each
sub-pixel
is
individually
controlled
by
advanced
electronics
to
produce
over
16
million
different
colors.
All
of
these
mean
that
you
get
perfect
images
that
are
easily
viewable
in
a
display
that
is
less
than
5
inches
thick.
160°
-
Wide
angle
range
of
vision
Your
flat
panel
plasma
screen
offers
an
exceptionally
broad
viewing
angle
--
over
160
degrees.
This
means
that
the
display
is
clear
and
visible
to
viewers
anywhere
in
the
room
who
can
see
the
screen.
Wide
Screen
The
screen
of
the
Plasma
Display
is
so
wide
that
your
viewing
experience
is
as
if
you
are
in
a
theater.
Multimedia
Connect
your
plasma
display
to
a
PC
and
you
can use
it
for
conferencing,
games,
and
Internet
browsing.
Versatile
The
light
weight
and
thin
size
makes
it
easy
to
install
your
plasma
display
in
a
variety
of
locations
where
conventional
TVs
will
not
fit.
The
PDP
Manufacturing
Process:
a
few
minute
colored
dots
may
be
present
on
the
PDP
screen
The
PDP
(Plasma
Display
Panel),
which
is
the
display
device
of
this
product,
is
composed
of
0.9
to
2.2
million
cells.
A
few
cell
defects
will
normally
occur
in
the
PDP
manufacturing
process.
Several
tiny,
minute
colored
dots
visible
on
the
screen
should
be
acceptable.
This
also
occurs
in
other
PDP
manufacturers'
products.
The
tiny
dots
appearing
does
not
mean
that
this
PDP
is
defec-
tive.
Thus
a
few
cell
defects
are
not
sufficient
cause
for
the
PDP
to
be
exchanged
or
returned.
Our
production
technology
mini-
mizes
these
cell
defects
during
the
manufacture
and
operation
of
this
product.
Operating
Guide
7
-
This
is
a
simplified
representation
of
front
panel.
Here
shown
may
be
somewhat
different
from
your
TV.
Controls
Controls
Front
Panel
Controls
Front
Panel
Controls
CH
VOL
MENU
INPUT
ENTER
POWER
Button
Remote
Control
Sensor
VOLUME
(F,G)
Buttons
CHANNEL
(E,
D)
Buttons
MENU
Button
INPUT
Button
ENTER
Button
8
Plasma
TV
AUDIO
IN
RGB
DVI
SPEAKER
OUT
8
SERV
CE
ONLY
AC
IN
ANTENNA
N
MP
MONO
AUDIO
VIDEO
NTERFACE
RESET
UPDATE
OP
CAL
1
S-VIDEO
IN
VIDEO
IN
AUDIO
IN
Connection
Options
Connection
Options
Back
Connection
Panel
Back
Connection
Panel
AC
IN
AUDIO
IN
(RGB/DVI)
RGB
IN
(PC/DTV)
REMOTE
CONTROL
OUT
SPEAKER
OUT
RJP
INTERFACE
HDMI1/DVI
IN
DIGITAL
AUDIO
OUT
OPTICAL
SERVICE
ONLY
AVIN1
COMPONENT
IN
HDMI
IN
2
ANTENNA
IN
M.P.I.
RESET
UPDATE
Connect
an
IR
cable
for
a
DVD
play-
er
or
other
IR controlled
device.
Owner's
Manual
9
-
When
using
the
remote
control,
aim
it
at
the
remote
control
sensor
on
the
TV.
123
456
789
0
TV
MODE
INFO
POWER
INPUT
EZ
PIC
EZ
SOUND
VCR
CABLE
DVD
HDSTB
MUTE
SWAP
PIPCH-
PIPCH+
PIP
RATIO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
CC
FREEZE
PIP
INPUT
VOL
CH
FAV
SAP
TIMER
SIGNAL
ADJUST
MULTIMEDIA
SKIP
FLASHBK
+
Remote
Control
Key
Functions
Remote
Control
Key
Functions
INDICATOR
LIGHTS
Show
active
remote
mode
every
time
any
button
is
pressed.
MODE
Select the
remote
oper
ting
mode:
TV,
VCR,
Cable,
DVD
and
Satellite.
INFO
Display
information
t
the
top
of
the
screen.
(Refer
to
p.37)
INPUT
External
input
modes
rotate
in
regular
sequence:
Tuner,
AV1, AV2,
Component,
RGB1, RGB2,
HDMI1/DVIand
HDMI2
input
sources.
(AV1,
AV2,
Component
input
sources
are
linked
automatically,
only
if
these
are
connected
)
FAV
Scrolls
the
Favorite
channels.
EZ
PIC
Selects
a
factory
preset
mode
depending
on
the
viewing
environment.
MUTE
Switches
the
sound
on
or
off.(Refer
to
p.38)
TIMER
Lets
you
select
the
amount
of
time
before
your
TV
turns
itself
off
automati-
cally.
VOLUME
UP/DOWN
Increases/decreases
the
sound
level.
NUMBER
KEYPAD
For
direct
channel
selection
and
programming
functions.
RATIO
Changes
the
screen
format
or
aspect
ratio.
PIP
INPUT
Selects the
input
source
for
the
sub
picture.
ENTER
When
in
the
menu
system
and
other
on-screen
displays,
selects
highlighted
options.
MENU
Brings
up
the
main
menu
to
the
screen.
EXIT
Clears
all
on-screen
displays
and
returns
to
TV
viewing
from
any
menu.
SKIP
Playing
CDs:
Selects
songs.
Playing
DVDs:
Selects
movie
chapters.
10
Plasma
TV
123
456
789
0
TV
MODE
INFO
POWER
INPUT
EZ
PIC
EZ
SOUND
VCR
CABLE
DVD
HDSTB
MUTE
SWAP
PIPCH-
PIPCH+
PIP
RATIO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
CC
FREEZE
PIP
INPUT
VOL
CH
FAV
SAP
TIMER
SIGNAL
ADJUST
MULTIMEDIA
SKIP
FLASHBK
+
Remote
Control
Key
Functions
Remote
Control
Key
Functions
?
Open
the
battery
compartment
cover
on
the
back
side
and
install
the
batteries
matching
correct
polarity
(+
with
+,
-
with
-).
?
Install
two
1.5V
AA
batteries.
Don't
mix
old
or
used
batteries
with
new
ones.
Close
cover.
Installing
Batteries
Installing
Batteries
back
of
remote
MULTIMEDIA
Selects:
RGB1-2,HDMI1/DVI,
HDMI2
and
Component
input
sources.
CC
Selects
a
closed
caption
mode
for dis-
playing
captioning
information
if
avail-
able
on
program.
POWER
Turns
your
TV
or
any
other
programmed
equipment
on
or
off,
depending
on
mode.
SIGNAL
Displays
the
digital
signal
strength.
ADJUST
Adjusts
screen
position,
size,
and
phase
in
PC
mode.
EZ
SOUND
Selects
the
sound
appropriate
for
the
pro-
gram's
character.
SAP
Selects
MTS
sound:
Mono,
Stereo,
and
SAP
in
Analog
mode.
Change
the
audio
language
in
DTV
mode.
CHANNEL
UP/DOWN
Scrolls
through
available
channels
in
EZ
Scan
memory.
FLASHBK
Tunes
to
the
last
channel
viewed.
PIPCH+
Changes
to
next
higher
PIP
channel.
SWAP
Exchanges
the
main/sub
images
in
PIP/Twin
mode.
PIPCH-
Changes
to
next
lower
PIP
channel
PIP
Toggles
between
PIP
and
Twin
mode.
FREEZE
Freezes
the
currently-viewed
picture.
Main
is
frozen
in
PIP/Twin
mode.
THUMBSTICK
Allows
you
to
navigate
the
on-screen
menus
and
to
adjust
the
system
settings
and
preferences,
by
moving
to
an
option
withF
G
and
selecting
the
highlighted
option
with
.
D
E
RECORD,
PAUSE,
REW,
FFWD,
PLAY,
STOP
Control
the
functions
on
your
VCR.
Owner's
Manual
11
Owner's
Manual
1.5V
1
.
5
V
Batteries
Power
Cord
123
456
789
0
TV
MODE
INFO
POWER
INPUT
EZ
PIC
EZ
SOUND
VCR
CABLE
DVD
HDSTB
MUTE
SWAP
PIPCH-
PIPCH+PIP
RATIO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
CC
FREEZE
PIP
INPUT
VOL
CH
FAV
SAP
TIMER
SIGNAL
ADJUST
MULTIMEDIA
SKIP
FLASHBK
+
75Ω
Round
Cable
Ensure
that
the
following
accessories
are
included
with
your
plasma
display.
If
an
accessory
is
missing,
please
contact
the
dealer
where
you
purchased
the
product.
Remote
Control
-
Secure
the
TV
assembly
by
joining
it
to
a
wall
by
using
the
TV/Wall
brackets.
-
This
TV's
stand
is
sold,
separately
.
-
Here
shown
may
be
somewhat
different
from
your
TV.
Joining
the
TV
assembly
to
the
wall
to
protect
the
set
tumbling
?
If
the
set
will
be
mounted
on
a
desk
top,
insert
the
2
eye-bolts*,
(not
supplied
with
the
product)
and
tight
en
them
securely
in
the
upper
holes
as
shown.
Install
the
wall
brackets
on
the
wall
with
2
bolts*,
(not
supplied
with
the
product),
as
shown.
Match
the
height
of
the
eye-bolts*,
(not
supplied
with
the
product)
and
the
wall
brackets.
Check
to
be
sure
the
eye-bolts*,
(not
supplied
with
the
product)
and
the
brackets
are
tightened
securely.
?
Secure
the
TV
assembly
to
the
wall
with
strong
strings
or
wire
cables,
(not
supplied
with
the
product),
as
shown.
Installation
Installation
Installation
Instructions
Installation
Instructions
Accessories
Accessories
D-sub
15
pin
Cable
(RGB)
12
Plasma
TV
GROUNDING
Ensure
that
you
connect
the
earth
ground
wire
to
prevent
possible
electric
shock.
If
grounding
methods
are
not
possible,
have
a
qualified
electrician
install
a
separate
circuit
breaker.
Do
not
try
to
ground
the
unit
by
connecting
it
to
telephone
wires,
lightening
rods,
or
gas
pipes.
Power
Supply
Short-circuit
Breaker
4
inches
4
inches
2.36
inches
4
inches
2
inches
Desktop
Pedestal
Installation
Desktop
Pedestal
Installation
?
The
TV
can
be
installed
in
various
ways
such
as on
a
wall,
or
on a
desktop
etc.
?
The
TV
is
designed
to
be
mounted
horizontally.
Installation
Instructions
Installation
Instructions
For
proper
ventilation,
allow
a
clearance
of
4"
on
each
side
and
the
top,
2.36"
on
the
bottom,
and
2"
from
the
wall.
Detailed
installation
instructions
are
included
in
the
optional
Desktop
Stand
Installation.
To
Install
on
a
Desktop
Pedestal
mount
minimum
allowableclearances
for
adequate
ventilation.
Owner's
Manual
13
External
Equipment
Connections
External
Equipment
Connections
-
Antenna
or
Cable
Service
without
a
Cable
Box
Connections
-
For
optimum
quality,
adjust
antenna
direction
if
needed.
Antenna
Connection
Antenna
Connection
Analog
and
Digital
TV
signals
provided
on
one
antenna
NOTE:
If
you
are
not
sure
of
the
type
of
signal(s)
you
are
receiving,
let
EZ
Scan
complete
all
the
channel
signal-type
searches.
The
TV
will
let
you
know when
the
analog,
cable,
and
digital
channel
scans
are
complete.
Analog
and
DTV
signals
provided
on
two
separate
antennas
?
In
a
poor
signal
area
to
improve
quality,
purchase
and
install
a
signal
amplifier.
?
If
the
antenna
needs
to
be
split
for
two
TV's,
install
a
"2-
Way
Signal
Splitter"
in
the
connections.
?
If
the
antenna
is
not
installed
properly,
contact
your
deal-
er
for
assistance.
ANTENNA
IN
Multi-family
Dwellings/Apartments
(Connect
to
wall
antenna
socket)
Single-family
Dwellings
/Houses
(Connect
to
wall
jack
for
outdoor
antenna)
Outdoor
Antenna
Wall
Antenna
Socket
VHF
Antenna
UHF
Antenna
RF
Coaxial
Wire
(75
ohm)
Copper
Wire
Turn
clockwise
to
tighten.
Copper
Wire
Be
careful
not
to
bend
the
Copper
wire
when
connecting
the
antenna.
ANTENNA
IN
M.P.I.
Wall
Antenna
Socket
RF
Coaxial
Wire
(75
ohm)
Analog
Antenna
Digital
Antenna
Copper
Wire
Copper
Wire
Turn
clockwise
to
tighten.
Wall
Antenna
Socket
RF
Coaxial
Wire
(75
ohm)
ANTENNA
IN
Signal
Amplifier
14
Plasma
TV
How
to
connect
Connect
the
audio
and
video
cables
from
the
external
equip-
ment's
output
jacks
to
the
TV
input
jacks,
as
shown
in
the
figure.
When
connecting
the
TV
to
external
equipment,
match
the
jack
colors
(Video
=
yellow,
Audio
Left
=
white,
and
Audio
Right
=
red).
How
to
use
1.
Select
the
input
source
with
using
the
INPUT
button
on
the
remote
control.
2.
Operate
the
corresponding
external
equipment.
External
External
A/V
Source
Setup
A/V
Source
Setup
RL
AUDIO VIDEO
MONO
AUDIO
VIDEO
Camcorder
Video
Game
Device
-
To
avoid
noise
(interference),
leave
an
adequate
distance
between
the
VCR
and
TV
-
Use
the
ISM
Method
(on
the
Option
menu)
feature
to
avoid
having
a
fixed
remain
on
the
screen
for
a
long
period
of
time.
If
the
4:3
format
is
used;
the
fixed
images
on
the sides
of
the
screen
may
remain
visible
on
the
screen.
Connection
Option
1
Set
VCR
output
switch
to
channel
3
or
4
and
then
tune
the
TV
to
the
same
channel
number.
Connection
Option
2
1.
Connect
the
audio
and
video
cables
from
the
VCR's
output
jacks
to
the
TV
input
jacks,
as
shown
in
the
figure.
When
connecting
the
TV
to
VCR,
match
the
jack
colors
(Video
=
yellow,
Audio
Left
=
white,
and
Audio
Right
=
red).
If
you
connect
an
S-VIDEO
output
from
VCR
to
the
S-VIDEO
input,
the
quality
is
improved;
compared
to
connecting
a
regular
VCR
to
the
Video
input.
2.
Insert
a
video
tape
into
the
VCR
and
press
PLAY
on
the
VCR.
(Refer
to
the
VCR
owner
's
manual.)
3.
Select
the
input
source
with
using
the
INPUT
button
on
the
remote
control.
Note
that
this
TV
finds
the
connected
input
sources
automatically
for
AV1,
AV2
and
Component
.
It
is
presumed
that
RGB1-2
,
HDMI1/DVI
and
HDMI2
sources
are
connected.
Do
not
connect
to
both
Video
and
S-Video
at
the
same
time.
VCR
Setup
VCR
Setup
S-VIDEO
OUT
IN
(R)
AUDIO
(L)
VIDEO
34
OUTPUT
SWITCH
ANT OUT
ANT
IN
ANTENNA
N
MP
VCR
Rear
1
2
or
Owner's
Manual
15
?
Component
Input
ports
To
get
better
quality,
connect
a
DVD
player
to
the
compo-
nent
input
ports
as
shown
below.
Component
ports
on
the
TV
YPBPR
Video
output
ports
on
DVD
player
Y
Y
Y
Y
Pb
B-Y
Cb
PB
Pr
R-Y
Cr
PR
How
to
connect
1.
Connect
the
DVD
video
outputs
(Y,
PB,
PR)
to
the
COMPO-
NENT
(Y,
PB,
PR)
INPUT
jacks
on
the
TV
and
connect
the
DVD
audio
outputs
to
the
AUDIO
INPUT
jacks
on
the
TV,
as
shown
in
the
figure.
2.
If
your
DVD
only
has
an
S-Video
output
jack,
connect
this
to
the
S-VIDEO
input
on
the
TV
and
connect
the
DVD
audio
out-
puts
to
the
AUDIO
INPUT
jacks
on
the
TV,
as
shown
in
the
figure.
Note:
If
your
DVD
player
does
not
have
component
AV
out,
use
S-Video.
How
to
use
1.
Turn
on
the
DVD
player,
insert
a
DVD.
2.
Use
the
INPUT
button
on
the
remote
control
to
select
Component
.
(If
connected
to
S-VIDEO,
select
the
AV1
or
AV
2
external
input
source.)
3.
Refer
to
the
DVD
player's
manual
for
operating
instructions.
DVD
Setup
DVD
Setup
(R)
AUDIO
(L)
S-VIDEO
B
R
(R)
AUDIO
(L)
DVD
or
HDMI-DVD
OUTPUT
NTERFACE
OP
CAL
1
When
supporting
HDMI
1.
Connect
the
HDMI
output
of
the
DVD
to
the
HDMI1/DVI
IN
jack
on
the
set.
2.
Select
HDMI1/DVI
or
HDMI2
input
source
with
using
the
INPUT
button
on
the
remote
control.
3.
Refer
to
the
DVD
player's
manual
for
operating
instruc-
tions.
?
TV
can
receive
the
video
and
audio
signal
simulta-
neously
with
using
a
HDMI
cable.
?
If
the
DVD
supports
Auto
HDMI
function,
the
DVD
output
resolution
will
be
automatically
set
to
1280x720p.
?
If
the
DVD
does
not
support
Auto
HDMI,
you
need
to
set
the
output
resolution
appropriately.
To
get
the
best
quality,
adjust
the
output
resolution
of
the
DVD
to
1280x720p.
DVD
16
Plasma
TV
-
This
TV
can
receive
Digital
Over-the-air/Cable
signals
without
an
external
digital
set-top
box.
However,
if
you
do
receive
Digital
signals
from
a
digital
set-top
box
or
other
digital
external
device,
refer
to
the
figure
as
shown
below.
-
This
TV
supports
HDCP
(High-bandwidth
Digital
Contents
Protection)
protocol
for
Digital
Contents
(480p,720p,1080i).
How
to
connect
Use
the
TV's
COMPONENT
(Y,
PB,
PR)
INPUT,
RGB
or
HDMI1/DVI
jack
for
video
connections,
depending
on
your
set-top
box
connector.
Then,
make
the
corresponding
audio
connections.
How
to
use
1.
Turn
on
the
digital
set-top
box.
(Refer
to
the
owner's
manual
for
the
digital
set-top
box.)
2.
Use
INPUT
on
the
remote
control
to
select
Component
,
RGB-DTV,
or
HDMI1/DVI
source.
HDSTB
Setup
HDSTB
Setup
Digital
Set-top
Box
Signal
480i
480p
720p
1080i
Component
Yes
Yes
Yes
Yes
RGB1/2-DTV
,
HDMI1/DVI
No
Yes
Yes
Yes
or
UDO
GB
DV
S K
)
AC
INPUT
(R)
AUDIO
(L)
RGB-DTV
OUTPUT
B
R
(R)
AUDIO
(L)
When
supporting
HDMI
DV
(R)
AUDIO
(L)
DVI-DTV
OUTPUTHDMI-DTV
OUTPUT
S
VC
O
OL
1
1.
Connect
the
DVI
output
of
the
digital
set-top
box
to
the
HDMI1/DVI
IN
or
HDMI
IN
2
jack
on
the
set.
2.
Connect
the
audio
output
of
the
digital
set-top
box
to
the
AUDIO
IN(RGB/DVI)
jack
on
the
set.
3.
Turn
on
the
digital
set-top
box.
(Refer
to
the
owner's
manual
for
the
digital
set-top
box.)
4.
Select
HDMI1/DVI
or
HDMI2
input
source
with
using
the
INPUT
button
on
the
remote
control.
?
If
the
digital
set-top
box
has
a
DVI
output
and
no
HDMI
output,
a
separated
audio
connection
is
nec-
essary.
?
If
the
digital
set-top
box
supports
Auto
DVI
function,
the
output
resolution
of
the
digital
set-top
box
will
be
automatically
set
to
1280x720p.
?
If
the
digital
set-top
box
does
not
support
Auto
DVI,
you
need
to
set
the
output
resolution
appropriately.
To
get
the best
quality,
adjust
the
output
res-
olution
of
the
digital
set-top
box
to
1280x720p.
Owner's
Manual
17
PC
Setup
PC
Setup
-
This
TV
provides
Plug
and
Play
capability,
meaning
that
the
PC
adjusts
automatically
to
the
TV's
settings.
-
The
TV
perceives
640x480,
60Hz
as
DTV
480p
based
on
the
PC
graphic
card,
change
the
screen
scanning
rate
for
the
graphic
card
accordingly.
AUDO
RGBDV
SPEAKE
O
T
8
AC
INPUT
(R)
AUDIO
(L)
RGB-PC
OUTPUT
AU
B
V
KR
U
)
(R)
AUDIO
(L)
DVI-PC
OUTPUT
SERVCEO
LY
OPT
CAL
1
When
supporting
HDMI
1.
Connect
the
DVI
output
of
the
PC
to
the
HDMI1/DVI
IN
jack
on
the
set.
2.
Connect
the
PC
audio
output
to
the
AUDIO
IN(RGB/DVI)
jack
on
the
set.
3.
Turn
on
the
PC
and
the
set.
4.
Select
HDMI1/DVI
input
source
with
using
the
INPUT
button
on
the
remote
control.
?
HDMI2
source
does
not
support
DVI
source.
?
If
the
PC
has
a
DVI
output
and
no
HDMI
output,
a
separat-
ed
audio
connection
is
necessary.
?
If
the
PC
does
not
support
Auto
DVI,
you
need
to
set
the
output
resolution
appropriately.
To
get
the
best
qual-
ity,
adjust
the
output
resolution
of
PC
graphics
card's
output
resolution
to
1024x768,
60Hz.
How
to
connect
1.
To
get
the
best
quality,
adjust
the
PC
graphics
card
to
1024x768,
60Hz.
2.
Use
the
TV's
RGB
INPUT
or
DVI
(Digital
Visual
Interface)
INPUT
port
for
video
connections,
depending
on
your
PC
connector.
?
If
the
graphic
card
on
the
PC
does
not
output
analog
and
digital
RGB
simultaneously,
connect
only
one
of
either
RGB
INPUT
or
DVI
INPUT
to
display
the
PC
on
the
TV.
?
If
the
graphic
card
on
the
PC
does
output
analog
and
digi-
tal
RGB
simultaneously,
set
the
TV
to
either
RGB
or
DVI;
(the
other
mode
is
set
to
Plug
and
Play
automatically
by
the
TV.)
3.
Then,
make
the
corresponding
audio
connections.
If
using
a
sound
card,
adjust
the
PC
sound
as
required.
How
to
use
1.
Turn
on
the
PC
and
the
TV.
2.
Turn
on
the
display
by
pressing
the
POWER
button
on
the
TV's
remote
control.
3.
Select
RGB1-2
input
source
in
main
input
option
of
SETUP
menu.
(Refer
to
P.23)
4.
Check
the
on
your
TV.
There
may
be
noise
associat-
ed
with
the
resolution,
vertical
pattern,
contrast
or
brightness
in
PC
mode.
If
noise
is
present,
change
the
PC
mode
to
another
resolution,
change
the
refresh
rate
to
another
rate
or
adjust
the
brightness
and
contrast
on
the
menu
until
the
is
clear.
If
the
refresh
rate
of
the
PC
graphic
card
can
not
be
changed,
change
the
PC
graphic
card
or
consult
the
manufacturer
of
the
PC
graphic
card.
18
Plasma
TV
Resolution
640x480
800x600
Horizontal
Frequency(KHz)
31.469
37.861
37.500
35.156
37.879
48.077
46.875
59.94
72.80
75.00
56.25
60.31
72.18
75.00
48.363
56.476
60.023
60.00
70.06
75.02
Vertical
Frequency(Hz)
Resolution
Horizontal
Frequency(KHz)
Vertical
Frequency(Hz)
1024x768
Monitor
Display
Specifications
(HDMI1/DVI-PC
Mode)
800x600
70.08
59.94
72.80
75.00
35.156
37.879
48.077
46.875
48.363
56.476
60.023
56.25
60.31
72.18
75.00
60.00
70.06
75.02
Vertical
Frequency(Hz)
Resolution
Horizontal
Frequency(KHz)
Vertical
Frequency(Hz)
1024x768
Resolution
640x480
Horizontal
Frequency(KHz)
31.469
31.469
37.861
37.500
Monitor
Display
Specifications
(RGB1/2-PC
)
640x350
1.
Depending
on
the
graphics
card,
DOS
mode
may
not
work
if
a
HDMI
to
DVI
Cable
is in
use.
2.
When
Source
Devices
connected
with
HDMI1/DVI
Input,
output
PC
Resolution
(VGA,
SVGA,
XGA),
Position
and
Size
may
not
fit
to
Screen.Press
the
ADJUST
button
to
adjust
the
screen
Position
of
TV
SET
and
contact
an
PC
graphics
card
service
cen-
ter.
3
When
Source
Devices
connected
with
HDMI1/DVI
Input,
output
TV
SET
Resolution
(480p,
720p,
1080i)
and
TV
SET
Display
fit
EIA/CEA-861-B
Specification
to
Screen.
If
not,
refer
to
the
Manual
of
HDMI1/DVI
Source
Devices
or
contact
your
ser-
vice
center.
4.
In
case
HDMI1/DVI
Source
Devices
is
not
con-
nected
Cable
or
poor
cable
connection,
"NO
SIG-
NAL"
OSD
display
in
HDMI1/DVI
Input.
In
case
that
Video
Resolution
is
not
supported
TV
SET
output
in
HDMI1/DVI
Source
Devices,
"INVALID
FORMAT"
OSD
display.
Refer
to
the
Manual
of
HDMI1/DVI
Source
Devices
or
contact
your
ser-
vice
center.
5.
Check
the
on
your
TV.
There
may
be
noise
associated
with
the
resolution,
vertical
pattern,
contrast
or
brightness
in
PC,
HDMI1/DVI
mode.
If
noise
is
present,
change
the
PC
or
HDMI1/DVI
mode
to
another
resolution,
change
the
refresh
rate
to
another
rate
or
adjust
the
brightness
and
contrast
on
the
menu
until
the
is
clear.
If
the
refresh
rate
of
the
PC
graphic
card
can
not
be
changed,
change
the
PC
graphic
card
or
consult
the
manufacturer
of
the
PC
graphic
card.
6.
Avoid
keeping
a
fixed
on
the
TV's
screen
for
a
long
period
of
time.
The
fixed
may
become
permanently
imprinted
on
the
screen.
7.
The
synchronization
input
form
for
Horizontal
and
Vertical
frequencies
is
separate.
Owner's
Manual
19
Send
the
TV's
audio
to
external
audio
equipment
(stereo
system)
via
the
Digital
Audio
Out(Optical)
port.
How
to
connect
1.
Connect
one
end
of
an
optical
cable
to
the
TV
Digital
Audio
(Optical)
Output
port.
2.
Connect
the other
end
of
the
optical
cable
to
the
digital
audio
(opti-
cal)
input
on
the
audio
equipment.
See
the
external
audio
equipment
instruction
manual
for
operation.
Note:
When
connecting
with
external
audio
equipments,
such
as
amplifers
or
speakers,
please
turn
the
TV
speakers
off.(Refer
to
p.28)
Caution:
Do
not
look
into
the
optical
output
port.
Looking
at
the
laser
beam
may
damage
your
vision.
Digital
Digital
Audio
Output
Setup
Audio
Output
Setup
N
ERFACE
SERVCEO
LY
OPT
CAL
1
External
Audio
Equipment
20
Plasma
TV
1.
First,
connect
power
cord
correctly.
At
this
moment,
the
TV
switches
to
standby
mode.
In
standby
mode
to
turn
TV
on,
press
the
button
on
the
TV
or
press
the
POWER
button
on
the
remote
control.
-
The
menus
can
be
shown
on
the
screen
in
the
selected
language.
First
select
your
language.
1.
Press
the
MENU
button
and
then
use
D
/
E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D
/
E
button
to
select
Language.
3.
Press
the
G
button
and
then
use
D
/
E
button
to
select
your
desired
language.
From
this
point
on,
the
on-screen
menus
will
be
shown
in
the
selected
lan-
guage.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
2.
Select
the
viewing
source
by
using
INPUT
button
on
the
remote
control.
3.
When
finished
using
the
TV,
press
the
POWER
button
on
the
remote
control.
The
TV
reverts
to
standby
mode.
TV
Setup
TV
Setup
On-screen
Menus
Language
Selection
On-screen
Menus
Language
Selection
Operation
Operation
T
T
urning
the
TV
On
urning
the
TV
On
*
In
this
manual,
the
OSD
(On
Screen
Display)
may
be
different
from
your
TV's
because
it
is
just
an
example
to
help
you
with
the
TV
operation.
Owner's
Manual
21
-
Automatically
finds
all
available
channels
through
antenna
or
cable
inputs,
and
stores
them
in
memory
on
the
channel
list.
-
Run
EZ
Scan
again
after
any
Antenna/Cable
connection
changes.
-
A
password
is
required
to
gain
access
to
EZ
Scan
menu
if
the
Lock
System
is
turned
on.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
EZ
Scan.
3.
Press
the
ENTER
button
to
begin
the
channel
search.
Allow
EZ
Scan
to
complete
the
channel
search
cycle
for
ANTENNA,
and
CABLE.
EZ
Scan
(Channel
Search)
EZ
Scan
(Channel
Search)
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Manual
Scan.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
DIGITAL
and
ANALOG.
4.
Press
the
G
button
and
then
use
D/E
button
to
select
channel
number
you
want
to
add
or
delete.
5.
Press
the
ENTER
button
to
add
or
delete
for
the
channel
number.
6.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Manual
Scan
Manual
Scan
Notes:
?
This
channel
number
is
a
physical
channel
number,
which
is
different
from
the
normal
channel
number
shown
in
Channel
Edit.
?
Antenna
jack
Analog
TV
signal
Digital
DTV
signal
?
Cable
jack
Analog
CATV
signal
Digital
CADTV
signal
Setup
Menu
Options
Setup
Menu
Options
-
A
password
is
required
to
gain
access
to
Manual
Scan
menu
if
the
Lock
System
is
turned
on.
22
Plasma
TV
-
There
are
two
different
ways
in
order
to
add
or
delete
scanned
channels.
One
is
"Custom
List"
and
the
other
is
"Favorite
List"
in
the
channel
list.
Both
of
them
are
available
after
EZ
Scan
on
the
SETUP
menu.
-
A
Custom
List
can
be
created
by
toggling
each
channel
on
or
off
with
ENTER
button.
The
channels
in
the
Custom
List
are
displayed
in
black
color,
and
the
channels
deleted
from
the
Custom
List
are
displayed
in
gray
color.
Once
a
channel
is
highlighted
you
can
add
or
delete
the
channel
by
referring
to
the
small
window
at
the
top-left
corner
of
the
screen.You
can
create
your
own
Favorite
List.
Use
the
FAV
button
on
the
remote
control
when
a
channel
is
highlighted
and
then
you
can
add
or
delete
the
channel
to/from
the
Favorite
List.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Channel
Edit.
3.
Press
the
G
button.
You
will
now
see
a
screen
filled
with
channel
numbers
and
a
preview
picture.
4.
Use
D/E
/
F
/
G
button
to
select
a
channel
and
then
use
the
ENTER
button
to
add
or
delete
it.
Press
FAV
button
to
add
the
channel
to
the
Favorite
List.
5.
Press
EXIT
button
to
return to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Channel
Edit
Channel
Edit
-
It
indicates
strength
of
the
DTV
signal
whether
you
need
to
adjust
your
antenna
or
digital
cable
input.
The
higher
the
signal
strength,
the
less
likely
you
are
to
experience
degradation.
-
DTV
Signal:
Only
when
the
input signal
is
DTV
or
CADTV,
this
function
is
available.
DTV
Signal
Strength
DTV
Signal
Strength
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
DTV
Signal.
3.
View
the
on-screen
signal
strength
monitor
to
see
the
quality
of
the
signal
being
received.
4.
Press
EXIT
button
to
return to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Setup
Menu
Options
Setup
Menu
Options
Owner's
Manual
23
-
Change
the
source
so
you
can
watch
your
TV,
cable
TV,
VCR,
DVD,
or
any
other
devices
that
are
connected
to
your
TV.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Main
Input.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
the
source:
Tuner,
AV1,
AV2,
Component,
RGB1,
RGB2,
HDMI1/DVI,
HDMI2
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Main
Input
Main
Input
-
Choose
preset
labels
for
your
channels.
-
If
a
channel
label
is
provided
on
the
signal
from
the
broadcasting
station,
the
TV
displays
a
short
name
for
a
channel
-
even
if
you
didn't
preset
a
label for
the
channel.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Channel
Label.
3.
Press
the
G
button.
You
will
now
see a
screen
filled
with
Labels
and
a
preview
screen.
4.
Use
the
CH
D
/
E
button
to
select
a
channel
to
Label.
5.
Use
D/E
/
F
/
G
button
to
select
the
appropriate
label
for
the
channel,
then
press
ENTER
button
to
set
the
Label
to
the
selected
channel.
Channel
Label
Setup
Channel
Label
Setup
24
Plasma
TV
Set
ID
Set
ID
Use
this
function
to
specify
a
monitor
ID
number.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
SET
ID.
3.
Press
the
G
button
and
then
use
D/E
button
to
adjust
SET
ID
to
choose
the
desired
monitor
ID
number.
The
adjustment
range
of
SET
ID
is
1
~
99.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
-
When
Main
Input
is
selected
to
Tuner,
this
function
cannot
be
selected
to
Tuner.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
SETUP
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Sub
Input.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
the
source:
Tuner,
AV1,
AV2.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return to
the
previous
menu.
*
You
can
also
select
sources
as
using
the
PIP
INPUT
button.
Sub
Input
Sub
Input
Owner's
Manual
25
-
Use
to
quickly
reset
all
the
Video
menu
options
to
their
original
factory
preset
values.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
VIDEO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Video
Reset
.
3.
Press
the
G
button
to
reset
the
Video
menu
options
to
original
values.
V
V
ideo
Reset
ideo
Reset
-
Adjust
the
appearance
to
suit
your
preference
and
viewing
situations.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
VIDEO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
the
desired
option
(Contrast,
Brightness,
Color,
Sharpness,
or
Tint
).
3.
Press
the
G
button
and
then
use
F
/
G
button
to
make
appropriate
adjustments.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1.
Press
the
EZ
PIC
button
repeatedly
to
select
the
appearance
setup
option
as
shown
below:
Custom
(your
own
settings),
Daylight,
Normal,
Night
Time, Movie,
Video
Game,
and
Sports.
?
You
can
also
use
the
VIDEO
menu
to
adjust
EZ
Picture.
2.
Press
the
EXIT
button
to
save
and
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
EZ
EZ
Manual
Control
(
Manual
Control
(Custom
option)
option)
-
Choose
one
of
three
automatic
color
adjustments.
Set
to
warm
to
enhance
hotter
colors
such
as
red,
or
set
to
cool
to
see
less
intense
colors
with
more
blue.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
VIDEO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Color
Temperature
.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
either
Cool,
Medium
or
Warm.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Color
Color
T
T
emperature
Control
emperature
Control
-
EZ
adjusts
the
TV
for
the
best
appearance.
Select the
preset
value
in
the
EZ
menu
based
on
the
program
category.
-
When
adjusting
Video
menu
options
(contrast,
brightness,
color,
sharpness,
tint,
and
color
temperature)
manually,
EZ
automatically
changes
to
Custom.
-
Daylight,
Normal,
Night
Time, Movie,
Video
Game,
and
Sports
settings
are
preset
for
optimum
quality
at
the
factory
and
are
not
adjustable.
V
V
ideo
Menu
Options
ideo
Menu
Options
26
Plasma
TV
-
Other
languages
may
be
available
if
a
digital
signal
is
provided
by
the
broad-
casting
station.
1.
Press
the
EZ
SOUND
button
repeatedly
to
select
the
appropriate
sound
setup
as
shown
below:
Custom
(your
own
settings),
Normal,
Stadium,
News,
Music,
and
Theater.
?
You
can
also
adjust
EZ
Sound
in
the
AUDIO
menu.
2.
Press
EXIT
button
to
save
and
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
EZ
Sound
EZ
Sound
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
AUDIO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
the
desired
sound
option
(Balance,
Treble,
or
Bass).
3.
Press
the
G
button
and
then
use
F
/
G
button
to
make
appropriate
adjustments.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to return
to
the
previous
menu.
Manual
Sound
Control
(
Manual
Sound
Control
(Custom
option)
option)
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
AUDIO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Audio
Language.
3.
Press
the
G
button
and
then
use
D/E
button
to
select:
English,
Spanish,
or
French.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to return
to
the
previous
menu.
Audio
Language
Audio
Language
-
EZ
Sound
lets
you
enjoy
the
best
sound
without
any
special
adjustment
because
the
TV
sets
the
appropriate
sound
options
based
on
the
program
content.
-
When
adjusting
sound
options
(treble,
bass,
and
front
surround)
manually,
EZ
Sound
automatically
switches
to
Custom.
-
Normal,
Stadium,
News,
Music,
and
Theater
are
preset
for
good
sound
quality
at
the
factory
and
are
not
adjustable.
-
Scans
for
changes
in
sound
level
during
commercials,
then
adjusts
the
sound
to
match
the
specified
audio
level.
EZ
SoundRite
makes
sure
that
the
volume
level
remains
consistent
whether
you
are
watching
a
commercial
or
a
regular
TV
program.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
AUDIO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
EZ
SoundRite.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to return
to
the
previous
menu.
EZ
SoundRite
EZ
SoundRite
-
Adjust
the
sound
to
suit
your
taste
and
room
situations.
Audio
Menu
Options
Audio
Menu
Options
Owner's
Manual
27
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
AUDIO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
TV
Speaker.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
TV
Speakers
On/Of
TV
Speakers
On/Of
f
Setup
f
Setup
-
Turn
TV
speakers
off
if
using
external
audio
equipment.
Feature
turns
the
TV
Speakers
option
On
or
Off.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
AUDIO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Front
Surround.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
Off,
3D
EchoSound
System
or
SRS
(Sound
Retrieval
System)
TruSurround
XT..
?
3D
EchoSound
System
Creates
a
stunning
simulated
stereo
effects
from
any
mono
sound
and
a
realistic
three-dimensional
sound
with
a
very
wide
and
deep
sound
stage
into
stereo
sound.
?
SRS
TruSurround
XT
Takes
advantage
of
any
multi-channel
format
without
needing
to
add
extra
speakers
or
equipment.
Dialog
clarity,
bass
enrichment,
and
the
addition
of
stereo
audio
enhancement
that
produces
an
immersive
sound
experience
from
standard
stereo
material.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Front
Surround
Front
Surround
-
is
a
trademark
of
SRS
Labs,
Inc.
-
TruSurround
XT
technology
is
incorporated
under
license
from
SRS
Labs,
Inc.
-
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby"
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
Audio
Menu
Options
Audio
Menu
Options
28
Plasma
TV
1.
Use
the
SAP
button
to
select
your
desired
MTS
mode
in
a
analog
signal.
Each
time
you
press
the
SAP
button,
Mono,
Stereo,
or
SAP
appear
in
turn.
?
If
other
languages
are
available
on
the
digital
signal,
select
them
with
the
SAP
button.
2.
Press
EXIT
button
to
save
and
return
to
TV
viewing.
Stereo/SAP
Stereo/SAP
Broadcasts
Setup
Broadcasts
Setup
-
This
TV
can
receive
MTS
stereo
programs
and
any
SAP
(Secondary
Audio
Program)
that
accompanies
the
stereo
program;
if
the
station
transmits
an
additional
sound
signal
as
well
as
the
original
one.
-
When
having
selected
Stereo
or
SAP
button
on
the
remote
control,
this
TV
can
only
receive
the
signal
when
the
TV
station
transmits
the
proper
signals.
-
Mono
sound
is
automatically
received
if
the
broadcast
is
only
in
Mono;
even
though
Stereo
or
SAP
has
been
selected.
-
Select
Mono
if
you
want
to
listen
to
mono
sound
during
stereo/SAP
broadcasting.
-
Stereo
or
SAP
can
be
received
in
a
Analog
channel.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
AUDIO
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
BBE.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
BBE
BBE
-
BBE
High
Definition
Sound
restores
clarity
and
presence
for
better
speech
intelligibility
and
music
realism.
?
Manufactured
under
license
from
BBE
Sound,
Inc.
?
Treble,
Bass
or
BBE
aren't
suitable
for
SRS
TSXT
mode.
Owner's
Manual
29
-
Timer
function
operates
only
if
the
current
time
has
been
set.
-
Off-Timer
function
overrides
On-Timer
function
if
they
are
both
set
to
the
same
time.
-
The
TV
must
be
in
standby
mode
for
the
On-Timer
to
work.
-
If
you
do
not
press
any
button
within
2
hours
after
the
TV
turns
on
with
the
On
Timer
function,
the
TV
will
automatically
revert
to
standby
mode.
On/Of
On/Of
f
f
T
T
imer
Setup
imer
Setup
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
TIME
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Off
Timer
or
On
Timer.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On.
?
To
cancel
On/Off
timer
function,
select
Off.
4.
Press
the
G
button
and
then
use
D/E
button
to
set
the
hour.
5.
Press
the
G
button
and
then
use
D/E
button
to
set
the minutes.
6.
For
only
On
timer
function
Press
the
G
button
and
then
use
D/E
button
to
select
the
channel
at
turn-on.
Press
the
G
button
and
then
use
D/E
button
to
set
the
sound
level
at
turn-on.
7.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Auto
Clock
Setup
Auto
Clock
Setup
-
The
time
is
set
automatically
from
a
digital
channel
signal.
-
The
digital
channel
signal
includes
information
for
the
current
time
provided
by
the
broadcasting
station.
-
Set
the
clock
manually,
if
the
current
time
is
set
incorrectly
by
the
auto
clock
function.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
TIME
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Auto
Clock.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
the
G
button
and
then
use
D/E
button
to
select
your
viewing
area
time
zone:
Eastern,
Central,
Mountain,
Pacific,
Alaska,
or
Hawaii.
5.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Manual
Clock
Setup
Manual
Clock
Setup
-
If
current
time
setting
is
wrong,
reset
the clock
manually.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
TIME
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Manual
Clock.
3.
Press
the
G
button
and
then
use
F
/
G
button
to
select
either
the
year,
date,
or
time
option.
Once
selected,
use
the
D/E
button
to
set
the
year,
date,
and
time
options.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
T
T
ime
Menu
Options
ime
Menu
Options
30
Plasma
TV
Auto
Of
Auto
Of
f
f
-
If
set
to
on
and
there
is
no
input
signal,
the
TV
turns
off
automatically
after
10
minutes.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
TIME
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Auto
Off.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Sleep
Sleep
T
T
imer
imer
-
The
Sleep
Timer
turns
the
TV
off
at
the
preset
time.
Note
that
this
setting
is
cleared
when
the
TV
is
turned
off.
-
You
can
also
set
up
the
Sleep
Timer
in
the
TIME
menu.
1.
Press
the
TIMER
button
repeatedly
to
select
the
number
of
minutes.
When
the
Off
option
appears
on
the
screen,
highlight
one
of
the
following
sleep
timer
options
by
using
the
navigation
:
10,
20, 30, 60, 90,
120, 180,
and
240
minutes.
2.
When
the
number
of
minutes
you
want
is
displayed
on
the
screen,
press
the
ENTER
button.
The
timer
begins
to
count
down
from
the
number
of
minutes
selected.
3.
To
check
the
remaining
minutes
before
the
TV
turns
off,
press
the
TIMER
button
once.
4.
To
cancel
the
Sleep
Timer,
press
the
TIMER
button
repeatedly
to
select
Off.
Owner's
Manual
31
Aspect
Ratio
Control
Aspect
Ratio
Control
0-
Lets
you
choose
the
way
an
analog
with
a
4:3
aspect
ratio
is
displayed
on
your
TV
with
a
16:9
ratio
format.
When
you
receive
an
analog
with
a
4:3
aspect
ratio
on
your
16:9
TV,
you
need
to
specify
how
the
is
to
be
dis-
played.
-
If
you
are
viewing
a
with
a
16:9
aspect
ratio,
you
can't
use
the
Horizon
aspect
ratio
option.
-
Horizon
aspect
ratio
is
not
available
for
Component
(480p/720p/1080i)/RGB-DTV
(480p/720p/1080i)/HDMI1/DVI-DTV
(720p/1080i)
/DTV(720p/1080i)
input
source.
-
In
RGB-PC/DVI-PC
input
source,
only
either
4:3
or
16:9
aspect
ratio
is
available.
-
Note:
If
a
fixed
is
displayed
on
the
screen
for
a
long
time,
the
may
become
imprinted
on
the
screen
and
remain
visible.
?
Set
By
Program
Choose
the
proper
proportion
to
match
the
source's
image.
(4:3
→
4:3,
16:9
→
16:9)
?
4:3
Choose
4:3
when
you
want
to
view
a
with
an
original
4:3
aspect
ratio,
with
gray
bars
appearing
at
both
the
left
and
right
sides.
?
16:9
Choose
16:9
when
you
want
to
adjust
the
horizontally,
in
a
linear
proportion
to
fill
the
entire
screen.
?
Horizon
Choose
Horizon
when
you
want
to
adjust
the
in
a
non-linear
proportion,
that
is,
more
enlarged
at
both
sides,
to
create
a
spectacular
view.
?Zoom1
Choose
Zoom
1
when
you
want
to
view
the
without
any
alteration.
However,
the
top
and
bottom
portions
of
the
will
be
cropped.
?Zoom2
Choose
Zoom
2
when
you
want
the
to
be
altered,
both
vertically
extended
and
cropped.
The
tak-
ing
a
halfway
trade
off
between
alteration
and
screen
coverage.
?
Cinema
Zoom
Choose
Cinema
Zoom
when
you
want
to
enlarge
the
in
correct
proportion.
Note:
When
enlarging
or
reducing
the
size,
the
may
become
distorted.
You
can
adjust
the
enlarge
proportion
of
Cinema
Zoom
using
D/E
button.
The
adjustment
range
is
1~16.
1.
Press
the
RATIO
button
repeatedly
to
select
the
desired
format.
You
can
also
adjust
Aspect
Ratio
in
the
OPTION
menu.
Cinema
3:2
Mode
Setup
-
Most
movies
are
24
frames/sec,
but
TV
signal
is
30
frames/sec.
This
option
lets
the
TV
do
3:2
pull-down
operation
for
you
to
watch
movies
at
the best
motion
appearance.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Cinema
3:2
Mode.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Option
Menu
Features
Option
Menu
Features
Note:
This
feature
operates
only
in
Component
480i,
S-Video,
AV
mode.
32
Plasma
TV
Caption/T
Caption/T
ext
ext
Analog
Broadcasting
System
Captions
-
Select
a
caption
mode
for
displaying
captioning
information
if
being
provided
on a
program.
-
Analog
caption
displays
information
at
any
position
on
the
screen.
-
Text
displays
information,
usually
at
the
bottom
position
and
is
used
for
a
data
service.
-
Caption/Text,
if
being
provided
by
the
broadcaster,
would
be
available
for
both
digital
and
analog
channels
on
the
Antenna/Cable.
-
This
TV
is
programmed
to
memorize
the
caption/text
mode
which
was
last
set
to,
when
you
turn the
power
off.
Digital
Broadcasting
System
Captions
-
Choose
the
language
you
want
the
DTV/CADTV
Captions
to
appear
in.
-
Languages
can
be
chosen
for
digital
sources
only
if
they
are
included
on
the
program.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Caption/Text.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
caption:
CC1,
CC2,
CC3,
CC4,
Text1,
Text2,
Text3,
or
Text4.
?
CAPTION
The
term
for
the
words
that
scroll
across
the
bottom
of
the
TV
screen;
usual-
ly
the
audio
portion
of
the
program
is
provided
for
the
hearing
impaired.
?
TEXT
The
term
for
the
words
that
appear
in
a
large
black
frame
and
almost
cover
the
entire
screen;
usually
messages
are
provided
by
the
broadcaster.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Caption/Text.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
available
caption
lan-
guages:
English,
Spanish,
or
French.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return to
the
previous
menu.
Caption
Caption
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Caption.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to return
to
the
previous
menu.
1.
Use
the
CC
button
repeatedly
to
select
Caption
CC1,
CC2,
CC3,
CC4,
Text1,
Text2,
Text3,
or
Text4.
2.
Press
EXIT
button
to
save
and
return
to
TV
viewing.
?
You
can
also
use
the
OPTION
menu
to
select
Caption/Text.
SETUP
VIDEO
AUDIO
TIME
OPTION
LOCK
Previous
Aspect
Ratio
Cinema
3:2
Mode
Caption
Caption
/
Text
G
Caption
Option
Language
ISM
Method
Low
Power
MENU
English
Spanish
French
Owner's
Manual
33
Caption
Option
Caption
Option
-
Customize
the
DTV/CADTV
captions
that
appear
on
your
screen.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Caption
Option.
3.
Press
the
G
button
and
then
use
F
/
G
button
to
select
Custom.
4.
Use
D/E
button
to
customize
the
Style,
Font,
etc.,
to
your
preference.
A
pre-
view
icon
is
provided
at
the
bottom
of
the
screen,
use
it
to
see
the
caption
language.
?
Size:
Set
the
size
of
the
words.
?
Font:
Select
a
typeface
for
the
words.
?
Text
Color:
Choose
a
color
for
the
text.
?
Text
Opacity:
Specify
the
opacity
for
the
text
color.
?
Bg
(Background)
Color:
Select
a
background
color.
?
Bg
(Background)
Opacity:
Select
the
opacity
for
the
background
color.
?
Edge
Type:
Select
an
edge
type.
?
Edge
Color:
Select
a
color
for
the
edges.
5.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
-
A
frozen
still
from
a
PC/video
game
displayed
on
the
screen
for
prolonged
periods
will
result
in
a
ghost
remaining;
even
though
the
is
changed.
Use
our
unique
method
to
minimize
any
fixed
on
the
screen.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
ISM
Method.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
either
Normal,
White
Wash,
Orbiter
or
Inversion.
?
Normal
If
sticking
is
never
a
problem,
ISM
is
not
necessary
-
set
to
Normal.
?
White
wash
White
Wash
removes
permanent
images
from
the
screen.
Note:
An
excessive
permanent
may
be
impossible
to
clear
entirely
with
White
Wash.
To
return
to
normal
viewing,
press
the
any
button.
?
Orbiter
Orbiter
may
help
prevent
ghost images.
However,
it
is
best
not
to
allow
any
fixed
to
remain
on
the
screen.
To
avoid
a
permanent
on
the
screen,
the
will
move
once
per
2
minutes:
Left
→
Right
→
Upside
→
Downside
→
Right
→
Left
→
Downside
→
Upside.
?
Inversion
Inversion
will
automatically
invert
the
plasma
display
panel
color
every
30
minutes.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
ISM
(Image
Sticking
Minimization)
Method
ISM
(Image
Sticking
Minimization)
Method
Option
Menu
Features
Option
Menu
Features
34
Plasma
TV
Low
Power
Low
Power
-
Low
power
reduces
the
plasma
display
power
consumption.
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
OPTION
menu.
2.
Press
the
G
button
and
then
use
D/E
button
to
select
Low
Power.
3.
Press
the
G
button
and
then
use
D/E
button
to
select
On
or
Off.
?
When
you
select
On,
the
screen
darkens.
4.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Owner's
Manual
35
Parental
Control
can
be
used
to
block
specific
channels,
ratings
and
other
viewing
sources.
The
Parental
Control
Function
(V-Chip)
is
used
to
block
program
viewing
based
on
the
ratings
sent
by
the
broadcasting
station.
The
default
setting
is
to
allow
all
programs
to
be
viewed.
Viewing
can
be
blocked
by
choosing
the
type
of
the
program
and
the
cat-
egories.
It
is
also
possible
to
block
all
program
viewing
for
a
time
period.
To
use
this
function,
the
following
must
be
done
:
1.
Set
ratings
and
categories
to
be
blocked.
2.
Specify
a
password
3.
Enable
the
lock
V-Chip
rating
and
categories
Rating
guidelines
are
provided
by
broadcasting
stations.
Most
television
programs
and
television
movies
can
be
blocked
by
TV
Rating
and/or
Individual
Categories.
Movies
that
have
been
shown
at
the
theaters
or
direct-to-video
movies
use
the
Movie
Rating
System
(MPAA)
only.
Ratings
for
Movies
previously
shown
in
theaters:
Movie
Ratings
:
?
Blocking
Off
(Permits
all
programs)
?G
(General
audience)
?PG
(Parental
guidance
suggested)
?
PG-13
(Parents
strongly
cautioned)
?R
(Restricted)
?
NC-17
(No
one
17
and
under
admitted)
?X
(Adult
only)
If
you
set
PG-13
:
G
and
PG
movies
will
be
available
,
PG-13,
R,
NC-17
and
X
will
be
blocked.
Ratings
for
Television
programs
including
made-for-TV
movies
:
?
TV-G
(General
audience)
?
TV-PG
(Parental
guidance
suggested)
?
TV-14
(Parents
strongly
cautioned)
?
TV-MA
(Mature
audience
only)
?
TV-Y
(All
children)
?
TV-Y7
(Children
7
years
older)
TV
Rating
Children:
?
Age
(applies
to
TV-Y,
TV-Y7)
?
Fantasy
Violence
(applies
to
TV-Y7)
TV
Rating
General:
?
Age
(applies
to
TV-G,
TV-PG,
TV-14,
TV-MA)
?
Dialogue
-
sexual
dialogue
(applies
to
TV-PG,
TV-14)
?
Language
-
adult
language
(applies
to
TV-PG,
TV-14,
TV-MA)
?
Sex
-
sexual
situations
(applies
to
TV-PG,
TV-14,
TV-MA)
?
Violence
(applies
to
TV-PG,
TV-14,
TV-MA)
Input
Block
?
AV1,
AV2
(On,
Off)
?
Component
(On,
Off)
?
RGB1, RGB2,
HDMI1/DVI,
HDMI2
(On,
Off)
Lock
Menu
Options
Lock
Menu
Options
36
Plasma
TV
Parental
Lock
Setup
Parental
Lock
Setup
1.
Press
the
MENU
button
and
then
use
D/E
button
to
select
the
LOCK
menu.
Then,
press
the
G
button
?
The
TV
is
set
up
with
the
initial
password
"0-0-0-0".
2.
Use
the
D/E
button
to
choose
from
the
following
Lock
Menu
options.
Once
the
option
is
selected,
change
the
settings
to
your
preference.
?
Lock
System:
Enables
or
disables
the
blocking
scheme
you
set
up
previ-
ously.
?
Set
Password:
Change
the
password
by
inputting
a
new
password
twice.
?
Block
Channel:
Blocks
any
channels
that
you
do
not
want
to
watch
or
that
you
do
not
want
your
children
to
watch.
?
Movie
Rating
(MPAA):
Blocks
movies
according
to
the
movie
ratings
lim-
its
specified,
so
children
cannot
view
certain
movies.
You
can
set
the
rat-
ings
limit
by
blocking
out
all
the
movies
with
the
ratings
above
a
specified
level.
Keep
in
mind
that
the
movie
ratings
limit
only
applies
to
movies
shown
on
TV,
not
TV
programs,
such
as
soap
operas.
?
TV
Rating-Children:
Prevents
children
from
watching
certain
children's
TV
programs,
according
to
the
ratings
limit
set.
The
children
rating
does
not
apply
to
other
TV
programs.
Unless
you
block
certain
TV
programs
intend-
ed
for
mature
audiences
in
the
TV
Rating
-
sub
menu,
your
children
can
view
those
programs.
?
TV
Rating-General:
Based
on
the
ratings,
blocks
certain
TV
programs
that
you
and
your
family
do
not
want
to
view.
?
Input
Block:
Enables
you
to
select
a
source
to
block
from
the
external
source
devices
you
have
hooked
up.
3.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
Note:
?
If
you
ever
forget
your
password,
key
in
'7',
'7', '7',
'7'
on
the
remote
control.
-
Set
up
blocking
schemes
to
block
specific
channels,
ratings,
and
external
viewing
sources.
-
A
password
is
required
to
gain
access
to
this
menu.
Owner's
Manual
37
4:3
16:9
The
original
aspect
ratio
of
the
video
is
4:3
The
original
aspect
ratio
of
the
video
is
16:9(wide)
The
video
resolution
is
720x480i
The
video
resolution
is
720x480p
The
video
resolution
is
1280x720p
The
video
resolution
is
1920x1080i
Multilingual
:
The
program
contains
two
or
more
audio
services.
Press
the
SAP
button
to
select
wanted
Audio.
Caption:
=>
The
program
contains
one
or
more
cap-
tion
services.
Press
the
CC
button
to
select
wanted
Closed
caption.
The
program
contains
V-Chip
information.
Refer
to
the
<LOCK
Menu>.
D
(Dialogue),
L
(Language),
S
(Sex),
V
(Violence),
FV
(Fantasy
Violence)
480i
480p
720p
1080i
CC
Operation:
?
Watching
TV/DTV/CATV/CADTV
?
Watching
AV1,
AV2
?
In
Component,
RGB1-2,
HDMI1/DVI,
HDMI2
modes,
INFO
button
is
not
work
ing.
Function:
?
Show
the
present
screen
information.
?
On
Watching
with
the
upper
Input
signal,
press
the
INFO
button.
?
Press
the
INFO
button
or
EXIT
button
to
exit.
A:
Banner
information
B:
Program
title
C:
Day
of
week,
Month,
Year
D:
Program
start
time
E:
Program
progress
bar
F:
Program
finish
time
G:
Present
time
H:
Additional
information.
Refer
to
the
icon
explanation
on
the
right.
-
Brief
Info
shows
the
present
screen
information.
-
Press
the
INFO
button
to
show
the
Brief
Info
on
the
screen.
-
INFO
button
does
not
work
in
Component,
RGB1-2,
and
HDMI1/DVI
modes.
-
Press
the
INFO
button
or
EXIT
button
to
exit.
Brief
Info.
B
C
D
E
A
F
H
G
38
Plasma
TV
-
When
you
repeatedly
press
the
MUTE
button,
the
sound
mode
is
changed
in
turn.
(Refer
to
the
below)
Mute
Mute
24
Mute
:
Sound
is
muted.
Mute
Off
:
Sound
is
enabled.
1.
Press
the
FREEZE
button
to
freeze
the
screen
section.
2.
To
return
to
normal
viewing,
press
the
FREEZE
button
again.
-
Freezes
the
currently-viewed
picture.
Freeze
Owner's
Manual
39
?
When
RGB
connect
to
PC
input
and
select
the
RGB-PC,
this
function
is
used.
?
When
HDMI1/DVI
connect
to
PC
input
and
select
HDMI1/DVI
input,
this
function
is
used.
?
In
RGB1/2-DTV
mode,
SIZE
and
PHASE
is
not
available.
?
After
connecting
RGB1,
2(When
setting
the
PC),
HDMI1/DVI
or
HDMI2
to
PC
input
and
checking
the
screen
quali-
ty.
-
Display
PC
Adjust
Menu
using
ADJUST
button.
-
Position
:
Adjust
the
screen
position.
After
displaying
the
Adjust,
select
the
screen
position.
-
Size
:
Adjust
the
screen
size.
-
Phase
:
Adjust
the
phase
of
Pixel
clock.
In
HDMI1/DVI-PC
mode,
PHASE
is
not
available.
-
Reset
:
Initializating
Position,
Size,
Phase
adjustment
.
Operation
Operation
Adjustment
for
screen
Position,
Size,
Phase,
Reset
Adjustment
for
screen
Position,
Size,
Phase,
Reset
Screen
Setup
for
PC
mode
40
Plasma
TV
0B
0F
08
C4
C5
79
0E
10~19
4C
1A
09
02
03
00
01
1E
AA
39
40
41
07
06
44
43
A9
52
4D
5B
65
0A
CB
D6
5A
D0
BF
D5
D7
C6
76
77
AF
98
R/C
Button
R/C
Button
R/C
Button
(Power
On/Off)
Discrete
IR
Code
(Only
Power
On)
Discrete
IR
Code
(Only
Power
Off)
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
R/C
Button
Discrete
IR
Code
(TV
Input
Selection)
Discrete
IR
Code
(AV1
Input
Selection)
Discrete
IR
Code
(AV2
Input
Selection)
Discrete
IR
Code
(Component
Input
Selection)
Discrete
IR
Code
(RGB-PC
Input
Selection)
Discrete
IR
Code
(RGB-DTV
Input
Selection)
Discrete
IR
Code
(HDMI1/DVI
Input
Selection)
Discrete
IR
Code
(Only
4:3
Mode)
Discrete
IR
Code
(Only
16:9
Mode)
Discrete
IR
Code
(Only
Zoom1
Mode)
Discrete
IR
Code
(Multmedia
Selection)
Code
(Hexa)
Function
Note
INPUT
TV
INPUT
POWER
POWER
ON
POWER
OFF
RATIO
TIMER
Number
Key
0~
9
-
(Dash)
FLASHBK
MUTE
VOL
D
VOL
E
CH
D
CH
E
FAV
INFO
CC
D
E
F
G
ENTER
MENU
GUIDE
EZ
SOUND
EZ
PIC
EXIT
FREEZE
SAP
ADJUST
TV
AV1
AV2
Component
RGB-PC
RGB-DTV
HDMI1/DVI
Ratio
4:3
Ratio
16:9
Ratio
Zoom
MULTIMEDIA
Key
Code
Owner's
Manual
41
G
The
remote
is
a
multi-brand
or
a
universal
remote.
It
can
be
programmed
to
operate
most
remote-controllable
devices
of
other
manufacturers.
Note
that
the
remote
may
not
control
all
models
of
other
brands.
Programming
a
code
into
a
remote
mode
Programming
a
code
into
a
remote
mode
Programming
the
Remote
Programming
the
Remote
1.
To
find
out
whether
your
remote
can
operate
the
device
without
programming,
turn
on
the
device
such
as
a
VCR
and
press
the
corresponding
mode
button
on
the
remote.
After
that,
press
the
POWER
button.
If
the
device
is
turned
off
then
it
responds
properly
and
the
remote
need
not
to
be
pro-
grammed.
If
not,
the
remote
should
be
programmed
to
operate
the
device.
The
programming
procedures
are
explained
below.
2.
Press
the
MENU
and
MUTE
button
continuously
at
the
same
time
for
2
seconds,
the
current
selected
device
button
will
be
illu-
minated.
If
you
don't
press
any
button
for
20
seconds,
the
light
on
the
mode
button
will
be
turned
off.
In
that
case,
you
have
to
repeat
from
step
2.
3.
Enter
code
numbers
using
the
number
button
on
the
remote
by
refering
the
code
table
on
the
following
pages.
When
pressing
the
button,
the
light
blinks
at
a
time.
If
the
device
turned
off,
the
programming
is
successful.
4.
Press
the
MENU
button
to
store
the
code.
After
blinking
twice,
this
code
is
stored.
5.
Test
the
remote
functions
to
see
if
the
device
responds
properly.
If
not,
repeat
from
step
2.
42
Plasma
TV
Programming
Codes
Programming
Codes
VCRs
VCRs
CA
CA
TV
TV
AIWA
034
AKAI
016 043 046
124
125 146
AMPRO
072
ANAM
031
033
103
AUDIO
DYNAMICS
012
023
039 043
BROKSONIC
035 037
129
CANON
028
031
033
CAPEHART
108
CRAIG
003 040
135
CURTIS
MATHES
031
033
041
DAEWOO
005 007
010 064
065
108
110
111
112
116 117 119
DAYTRON
108
DBX
012
023 039
043
DYNATECH
034 053
ELECTROHOME
059
EMERSON
006 017
025 027
029
031
034 035
036 037
046
101
129
131
138 153
FISHER
003 008 009
010
FUNAI
034
GE
031
033
063
072
107 109
144 147
GO
VIDEO
132
136
HARMAN
KARDON
012
045
HITACHI
004 018
026 034
043 063
137 150
INSTANTREPLAY
031
033
JCL
031
033
JCPENNY
012
013 015
033
040 066
101
JENSEN
043
JVC
012
031
033 043
048 050
055 060
130 150 152
KENWOOD
014 034
039 043
047 048
LG
(GOLDSTAR)
001
012
013
020
101
106
114
123
LLOYD
034
LXI
003 009
013 014
017 034
101
106
MAGIN
040
MAGNAVOX
031
033 034
041
067 068
MARANTZ
012
031
033 067
069
MARTA
101
MATSUI
027 030
MEI
031
033
MEMOREX
003 010 014
031
033 034
053
072
101
102
134 139
MGA
045 046 059
MINOLTA
013 020
MITSUBISHI
013 020
045 046
049
051
059
061
151
MTC
034 040
MULTITECH
024 034
NEC
012
023 039
043
048
NORDMENDE
043
OPTONICA
053 054
PANASONIC
066 070
074 083
133 140
145
PENTAX
013 020
031
033
063
PHILCO
031
034 067
PHILIPS
031
033
034 054
067
071
101
PILOT
101
PIONEER
013
021
048
PORTLAND
108
PULSAR
072
QUARTZ
011
014
QUASAR
033 066 075
145
RCA
013 020 033
034
040
041
062
063
107 109 140
144
145 147
REALISTIC
003 008 010
014
031
033 034
040
053 054
101
RICO
058
RUNCO
148
SALORA
014
SAMSUNG
032
040
102
104
105 107 109
112
113 115
120 122
125
SANSUI
022
043 048
135
SANYO
003 007 010
014
102
134
SCOTT
017 037
112
129
131
SEARS
003 008 009
010
013 014 017
020
031
042
073
081
101
SHARP
031
054
149
SHINTOM
024
SONY
003 009
031
052
056 057 058
076
077 078
149
SOUNDESIGN
034
STS
013
SYLVANIA
031
033 034
059
067
SYMPHONIC
034
TANDY
010 034
TATUNG
039 043
TEAC
034 039 043
TECHNICS
031
033 070
TEKNIKA
019
031
033 034
101
THOMAS
034
TMK
006
TOSHIBA
008 013
042
047
059
082
112
131
TOTEVISION
040
101
UNITECH
040
VECTOR
RESEARCH
012
VICTOR
048
VIDEO
CONCEPTS
012
034 046
VIDEOSONIC
040
WARDS
003 013 017 024
031
033 034 040
053 054
131
YAMAHA
012
034 039 043
ZENITH
034 048 056
058
072
080
101
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
ABC
003 004 039 042
046
052
053
AJIN
112
ANTRONIK
014
ARCHER
005 007 014
024
CABLE
STAR
026
CENTURION
092
CENTURY
007
CITIZEN
007
COLOUR
VOICE
065 090
COMBANO
080
081
COMTRONICS
019 030
DIAMOND
023
EAGLE
020 030
040
EASTERN
057
062
066
ELECTRICORD
032
GE
072
GEMINI
008
022
025 054
GI
052
074
GOLDEN
CHANNEL
030
HAMLIN
049 050 055
HITACHI
052
055
HOSPITALITY
070 077
JERROLD
002
003 004
008
009 010 052
069
074
LG
(GOLDSTAR)
001
106
101
005
M-NET
037
MACOM
033
MAGNAVOX
010
012
064
079
MEMOREX
100
MOVIE
TIME
028
032
NSC
015 028 038
071
073
OAK
016
031
037 053
PANASONIC
044 047
PARAGON
100
PHILIPS
006
012
013 020
065 085 090
PIONEER
034
051
052
063
076
POST
NEWS
WEEK
016
PRUCER
059
PTS
011
048
071
072
073 074
PULSAR
100
RCA
047
REGAL
049 050
REGENCY
057
REMBRANT
025
SAMSUNG
102
107
030
068
SCIENTIFIC
ATLANTA
003
011
041
042
043 045 046
SHERITECH
022
SIGNAL
030
SIGNATURE
052
SL
MARX
030
SPRUCER
047 078
STARCOM
002
004 008
009
STARGATE
008 030
TADIRAN
030
TAEKWANG
110
TAIHAN
105
TANDY
017
TEXSCAN
029
TOCOM
039 040 056
TOSHIBA
100
UNIKA
007 014 024
UNITED
CABLE
004 053
UNIVERSAL
005 007 014 024
026 027
032
035
VIEWSTAR
012
015 018 086
087 088 089
ZENITH
100
114
060 093
Owner's
Manual
43
Audio
Audio
APEX
DIGITAL
022
DENON
020 014
GE
005 006
HARMAN
KARDON
027
JVC
012
LG
001
010 016 025
MAGNAVOX
013
MARANTZ
024
MITSUBISHI
002
NAD
023
ONKYO
008 017
PANASONIC
003 009
PHILIPS
013
PIONEER
004 026
PROCEED
021
PROSCAN
005 006
RCA
005 006
SAMSUNG
011
015
SONY
007
THOMPSON
005 006
TOSHIBA
019 008
YAMAHA
009 018
ZENITH
010 016 025
DVD
DVD
ALPHASTAR
DSR
123
AMPLICA
050
BIRDVIEW
051
126 129
CHANNEL
MASTER
013 014 015 018
036 055
CHAPARRAL
008 009
012
077
CITOH
054
CURTIS
MATHES
050
145
DRAKE
005 006 007 010
011
052
112
116
141
DX
ANTENNA
024 046 056 076
ECHOSTAR
038 040 057 058
093 094 095 096
097 098 099
100
122
ELECTRO
HOME
089
EUROPLUS
114
FUJITSU
017
021
022
027
133 134
GENERAL
INSTRUMENT
003 004 016 029
031
059
101
HITACHI
139 140
HOUSTON
TRACKER
033 037 039
051
057
104
HUGHES
068
JANIEL
060
147
JERROLD
061
KATHREIN
108
LEGEND
057
LG
001
LUTRON
132
LUXOR
062
144
MACOM
010 059 063 064
065
MEMOREX
057
NEXTWAVE
028
124 125
NORSAT
069 070
PACE
SKY
SATELLITE
143
PANASONIC
060
142
PANSAT
121
PERSONAL
CABLE
117
PHILIPS
071
PICO
105
PRESIDENT
019
102
PRIMESTAR
030
110
111
PROSAT
072
RCA
066
106
REALISTIC
043 074
SAMSUNG
123
SATELLITE
SERVICE
CO
028 035 047 057
085
SCIENTIFIC
ATLANTA
032
138
SONY
103
STARCAST
041
SUPER
GUIDE
020
124 125
TEECOM
023 026 075 087
088 090
107 130
137
TOSHIBA
002
127
UNIDEN
016 025
042
043
044 045 048 049
078 079 080 086
101
135 136
VIEWSTAR
115
WINEGARD
128 146
ZENITH
081
082
083 084
091
120
HDSTB
HDSTB
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
AIWA
014 028 070 096
125 129 139
229
230
AKAI
163
ANAM
003 014 017 023
059
106 189
216
217 235 236
BURMECTER
252
CARVER
086
CLARION
199
DAEWOO
027 053 060 084
102
148 198
221
DENON
015 075
130 143
FANTASIA
071
FINEARTS
022
FISHER
089 099
LG(GOLDSTAR)
001 021
024 029
087
107 108
110
190
191
192
210
211
212
239
HAITAI
034 035
188
222
HARMAN/KARDON
068
INKEL
037 058
062
069
078 079 095
121
122
149 150
151
152
153 154 155
157 158 159 160
189
207
222
224
225 226 227 243
247
JVC
004 013
141
KEC
185 186 187
KENWOOD
038 050 067 089
170
171
197
206
215
222
KOHEL
030
NAD
045 046
LOTTE
014 016 036 098
100
172
173 174
175 176 177 178
179 180
181
183
201
202
208 213
214 219 223
232
238 240
LXI
103
MAGNAVOX
111
MARANTZ
002
018 020 025
034
041 081
090
097
112
MCINTOSH
049
MCS
104
MEMOREX
107
NAD
046
ONKYO
013 040
041
047
048 056 057
132
133 140
OPTIMUS
158
PANASONIC
007 033 064
113
142
220
241 251
PENNEY
104
PHILIPS
026
112
143
PIONEER
039
042
043 063
065
091
093 094
115
123 127
250
QUASAR
113
RCA
080
RCX
092
REALISTIC
103 106
SAMSUNG
124 145 146
182
193 194 195
203
204 244 245 246
SANSUI
011
135 138 144
SANYO
019 083 234
SCOTT
106 186
SHARP
031
032
051
052
072 082
117 119
156 184 199
200
206 209
SHERWOOD
005 006
158
SONY
044 045
109
114
118
126
248 249
TAEKWANG
012
020 073 074
076 077
105
161
162
163 164 165
166 167 168 169
205
231
233
242
TEAC
010 085
106 136
185 187
237
TECHNICS
101
113
128 134
147
218
TOSHIBA
137
THE
061
VICTOR
088
131
WARDS
089
YAMAHA
054 055 066
092
199
Brand
Codes
Brand
Codes
Brand
Codes
Brand
Codes
44
Plasma
TV
No
output
from
one
of
the
speakers
?
Adjust
Balance
in
the
AUDIO
menu.
(Refer
to
p.26)
Unusual
sound
from
inside
the
TV
?
A
change
in
ambient
humidity
or
temperature
may
result
in
an
unusual
noise
when
the
plasma
display
is
turned
on
or
off
and
does
not
indicate
a
fault
with
the
TV.
No
&
No
sound
?
Check
whether
the
TV
is
turned
on.
?
Is
the
power
cord
inserted
into
wall
power
outlet?
?
Test
the
wall
power
outlet,
plug
another
product's
power
cord
into
the
outlet
where
the
TV's
power
cord
was
plugged
in.
No
or
poor
color
or
poor
?
Select
Color
in
the
Video
menu
and
press
the
G
button.
(Refer
to
p.25)
?
Keep
a
sufficient
distance
between
the
TV
and
the
VCR.
?
Activate
any
function
to
restore
the
brightness
of
the
picture.
(If
still
is
on
the
screen
for
more
than
5
minutes,
the
screen
gets
dark.)
The
remote
control
doesn't
work
?
Check
to
see
if
there
is
any
object
between
the
TV
and
the
remote
control
causing
obstruction.
?
Are
batteries
installed
with
correct
polarity
(+
to
+,
-
to
-)?
(Refer
to
p.10)
?
Correct
remote
operating
mode
set:
TV,
VCR
etc.?
?
Install
new
batteries.
(Refer
to
p.10)
OK
&
No
sound
?
Press
the
VOLUME
(
D
/
E
)
button.
?
Sound
muted?
Press
MUTE
button.
appears
slowly
after
switching
on
?
This
is
normal,
the
is
muted
during
the
TV
startup
process.
Please
contact
your
service
center,
if
the
has
not
appeared
after
five
minutes.
Horizontal/vertical
bars
or
shaking
?
Check
for
local
interference
such
as an
electrical
appliance
or
power
tool.
T
T
roubleshooting
Checklist
roubleshooting
Checklist
Owner's
Manual
45
1.
Here's
a
great
way
to
keep
the
dust
off
your
screen
for
a
while.
Wet
a
soft
cloth
in
a
mixture
of
lukewarm
water
and
a
little
fabric
softener
or
dish
washing
detergent.
Wring
the
cloth
until
it's
almost
dry,
and
then
use
it
to
wipe
the
screen.
2.
Make
sure
the
excess
water
is
off
the
screen,
and
then
let
it
air-dry
before
you
turn
on
your
TV.
To
remove
dirt
or
dust,
wipe
the
cabinet
with
a
soft,
dry,
lint-free
cloth.
Please
be
sure
not
to
use
a
wet
cloth.
If
you
expect
to
leave
your
TV
dormant
for
a
long
time
(such
as
a
vacation),
it's
a
good
idea
to
unplug
the
power
cord
to
protect
against
possible
damage
from
lightning
or
power
surges.
-
Early
malfunctions
can
be
prevented.
Careful
and
regular
cleaning
can
extend
the
amount
of
time
you
will
have
your
new
TV.
Be
sure
to
turn the
power
off
and
unplug
the
power
cord
before
you
begin
any
cleaning.
Cleaning
the
Screen
Cleaning
the
Screen
Cleaning
the
Cabinet
Cleaning
the
Cabinet
Extended
Extended
Absence
Absence
Maintenance
Maintenance
46
Plasma
TV
Product
Specifications
Product
Specifications
?
The
specifications
shown
above
may
be
changed
without
prior
notice
for
quality
improvement.
MODELS
AC100-240V~
50/60Hz
NTSC-M,
ATSC,
64
&
256
QAM
VHF2~13,UHF14~69,CATV1~135,DTV2~69,CADTV1~135
75Ω
32
~
104°F
(0
~
40°C)
Less
than
80%
Width
(inches
/
mm)
Height
(inches
/
mm)
Depth
(inches
/
mm)
Weight
(pounds
/
kg)
Resolution
Power
requirement
Television
System
Program
Coverage
External
Antenna
Impedance
Operating
Temperature
Range
Operating
Humidity
Range
46.7
/
1186
27.6
/
654.7
25.8
/
119.5
58.9
/
26.7
42PX7DC
(
42PX7DC-UA
)
1024x768
(Dot)
852x480(Dot)
42PX7DCV
(
42PX7DCV-UA
)
Your
LG
Plasma
TV
will
be
repaired
or
replaced
in
accordance
with
the
terms
of
this
warranty,
at
LGE's
option,
if
it
proves
to
be
defective
in
material
or
workmanship
under
normal
use,
during
the
warranty
period
("Warranty
Period")
listed
below,
effective
from
the
date
("Date
of
Purchase")
of
original
consumer
purchase
of
the
product.
This
war-
ranty
is
good
only
to
the
original
purchaser
of
the
product
and
effective
only
when
used
in
the
United
States,
includ-
ing
Alaska,
Hawaii,
and
U.S.
Territories.
CONCERNING
PIXEL
FUNCTIONALITY:
Your
Plasma
TV
contains
about
one
million
individual
pixels.
Plasma
TV
typically
contain
a
small
number
of
pixels
that
do
not
function
normally.
Your
display
has
been
inspected
and
is
in
compliance
with
manufacturer's
specifications,
indicating
that
any
pixel
defects
do
not
effect
the
operation
or
use
of
your
display.
THIS
WARRANTY
IS
IN
LIEU
OF
ANY
OTHER
WARRANTY,
EXPRESS
OR
IMPLIED,
INCLUDING
WITHOUT
LIMITATION,
ANY
WARRANTY
OF
MERCHANTABILITY
OR
FITNESS
FOR
A
PARTICULAR
PURPOSE.
TO
THE
EXTENT
ANY
IMPLIED
WARRANTY
IS
REQUIRED
BY
LAW,
IT
IS
LIMITED
IN
DURATION TO
THE
EXPRESS
WARRANTY
PERIOD
ABOVE.
NEITHER
THE
MANUFACTURER
NOR
ITS
U.S.
DISTRIBUTOR
SHALL
BE
LIABLE
FOR
ANY
INCIDENTAL,
CONSEQUENTIAL,
INDIRECT,
SPECIAL,
OR
PUNITIVE
DAMAGES
OF
ANY
NATURE,
INCLUDING
WITHOUT
LIMITATION,
LOST
PROFITS,
LOST
OR
CORRUPTED
PROGRAMMING
OR
DATA,
OR
ANY
OTHER
DAMAGE
WHETHER
BASED
IN
CONTRACT,
TORT,
OR
OTHERWISE.
Some
states
do
not
allow
the
exclusion
or
limitation
of
incidental
or
consequential
damages
or
limitations
on
how
long
an
implied
warranty
lasts,
so
the
above
exclusion
or
limitation
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
rights
and
you
may
also
have
other
rights
that
vary
from
state
to
state.
WARRANTY
PERIOD:
LABOR
and
PARTS:
2
YEARS
from
the
Date
of
Purchase.
Your
unit
will
be
repaired
or
replaced
with
a
new,
substitute
model
or
factory
reconditioned
unit,
at
LGE's
option.
If
repaired,
parts
used
in
the
repair
may
be
new
or
remanufac-
tured.
Replacement
Units
and
Repair
Parts
are
warranted
for
the
remaining
portion
of
the
original
unit's
warranty
period.
EFFECTIVE
DATE
OF
WARRANTY:
Your
warranty
period
begins
on
the
date
of
sale
to
the
original
consumer/end
user.
KEEP
THE
DEALER'S
DATED
BILL
OF
SALE
OR
PROOF
OF
DELIVERY
as
evidence
of
the
purchase
date.
You
will
be
required
to
submit
a
legible
copy
of
your
bill
of
sale
or
proof
of
delivery
when
requesting
warranty
service.
HOW
SERVICE
IS
HANDLED:
Please
retain
dealer's
dated
bill
of
sale
or
deliv-
ery
ticket
as
evidence
of
the
Date
of
Purchase
for
proof
of
warranty,
and
submit
a
copy
of
the
bill
of
sale
to
the
service
person
at
the
time
warranty
service
is
provided.
Please
call
1-800-243-0000
to
locate
your
nearest
LGE
Authorized
Service
Center.
Visit
our
website
at:
http://www.lgservice.com
IMPORTANT:
Please
fill
out
and
mail
in
your
Product
Registration
Card
or
go
to
www.lgservice.com
to
register
your
product
online.
This
information
will
allow
us
to
reach
you
promptly
should
we
discover
a
safety
or
reliability
prob-
lem
that
could
affect
you.
P/N
:
38289U0558A
TO
CONTACT
THE
LGE
CUSTOMER
SERVICE
CENTER
BY
MAIL:
LGE Customer
Interactive
Center
P.O.
Box
240007
201
James
Record
Road
Huntsville,
Alabama
35824
http://www.lgservice.com
FOR
SERVICE:
Before
you
call
for
warranty
service,
check
your
operating
guide
--
you
may
avoid
a
service
call.
For
warranty
service
information,
please
contact
the
LGE
Customer
Interactive
Center
telephone
number.
When
calling
for
service,
please
have
your
product
model
number,
serial
number
and
the
date
of
pur-
chase
or
the
date
of
original
installation
available.
If
a
replacement
unit
is
required,
under
some
circumstances
you
may
be
asked
to
provide
a
reserve
deposit
to
the
LGE
Service
Center
against
a
credit
card
number
as
surety
for
advanced
shipment.
Your
credit
card
will
not
be
charged
if
you
return
the
defective
unit
within
10
working
days.
If
a
replacement
unit
is
received,
please
use
the
carton
and
packaging
from
that
unit
in
returning
the
defective
unit
to
the
LG
Brand
Service
Center.
Parts
and
service
in
accordance
with
the
LGE
warranty
are
LGE's
responsibility
and
will
be
provided
without
charge.
Other
service
requirements
will
be
at
the
owner's
expense.
If
you
have
problems
in
obtaining
satisfactory
warranty
service,
write
or
call
the
LGE
Customer
Interactive
Center.
Service
may
be
provided
by
independently
owned
and
operated
service
organizations.
To
assure
proper
credit
and
avoid
unnecessary
charges,
you
must
obtain
an
LGE
Return
Authorization
before
returning
any
product
to
the
LGE
Service
Center.
Contact
the
Customer
Interactive
Center
for
details.
CUSTOMER
INTERACTIVE
CENTER
NUMBERS:
To
obtain
customer
assistance,
product
information
or
Dealer
or
Service
locations
Call
1-800-243-0000
24
hours
a
day,
365
days
per
year
THIS
LIMITED
WARRANTY
DOES
NOT
APPLY
TO:
The
cost
of
repair
or
replacement
under
these
excluded
circumstances
shall
be
borne
by
the
consumer.
damage
caused
in
shipping
or
transit
service
required
as
a
result
of
improper
installation,
including
incorrect
or
insufficient
AC
supply
(please
consult
the
owner's
manual
for
power
supply
requirements)
installation
or
repair
of
antenna
systems,
cable
con-
verters,
cable
company
supplied
equipment,
or
other
components
in
a
video
system
set-up
or
adjustment
on
consumer
controls,
or
damage
caused
by
improper
adjustments
damage
caused
by
other
system
components
any
panel
that
has
been
modified
or
incorporated
into
any
other
product
replacement
of
batteries
on
the
remote
control.
damage
(including
cosmetic
damage),
failure,
loss
or
personal
injury
due
to
misuse,
abuse,
negli-
gence,
improper
maintenance
or
storage,
or
to
acts
of
nature
or
other
causes
beyond
our
control.
(Causes
beyond
our
control
include
but
are
not
lim-
ited
to
lightning
strike,
power
surges,
power
out-
ages
and
water
damage.)
burn-in
repair
or
replacement
of
warranted
parts
by
other
than
LGE
authorized
service
centers.
units
purchased
or
serviced
outside
of
the
coverage
area.
product
where
the
original
factory
serial
numbers
have
been
removed,
defaced
or
changed
in
any
way.
product
sold
and
labeled
as
"as
is,
where
is"
or
sim-
ilar
disclaimer.
c
