MODEL:
HR6SBS690GW
HR6SBS690GB
3
8
15
2
5
7
10
14
11
12
Brief introduction
-Catering and similar non-retail
applications.
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to
ensure that they do not play with the
appliance.
Do not store explosive substances
such as aerosol cans with a flammable
propellant in this appliance.
WARNING—Keep ventilation openings,
in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING—Do not use mechanical
devices or other means to accelerate
the defrosting process, other than those
recommended by the manufacturer.
WARNING—Do not damage the
refrigerant circuit.
WARNING—Do not use electrical
appliances inside the food storage
compartments of the appliance, unless
they are of the type recommended by
the manufacturer.
WARNING—When disposing of the
appliance do so only at an authorized
waste disposal centre. Do not expose to
flame.
WARNING—If the supply cord is
damaged, it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order to
avoid a hazard.
●
Thank you for your choosing our
products. We are sure you will find
your new appliance a pleasure to use.
Before you use the appliance, we
recommend that you read through
these instructions carefully, which
provides details about its usage and
functions.
Please ensure that all people using
this appliance are familiar with its
operations and safety features. It is
important that you install the appliance
correctly and pay attention to the safety
instructions carefully.
We recommend that you keep this
user's manual with the appliance for
future reference and retain it to any
future users.
This appliance is intended to be used
in household and similar applications
such as:
-Staff kitchen- areas in shops, offices
and other working environments;
-Farmhouses by clients in hotels,
motels and other residential types of
environment;
- B e d a n d b r e a k f a s t t y p e o f
environments;
-Catering and similar non-retail
applications.
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
●
●
●
●
3
Safety for children and infirm persons
Safety about electricity
●
●
●
●
●
●
●
●
Unpack the appliance and check
through the appliance. Should any
damage be evident, don't plug in the
appliance but contact the shop
immediately from which you purchased
it. Keep all packing materials in this
case.
We recommend that you wait for 4
hours before connecting the appliance
to allow the refrigerant to flow back into
the compressor.
The appliance must be applied with
single phase alternating current of
220~240V/50Hz. If the voltage
fluctuates exceeding the upper limit,
A.C. automatic voltage regulator of
more than 350W should be applied to
the refrigerator for safety use.
The mains plug must be accessible
when the appliance is installed.
recommend that you follow the
guidelines below.
Store any food in accordance with the
s t or a g e i n st r uc t i on s fr o m t h e
manufacturer.
Don't try to repair the appliance
yourself. It is dangerous to alter the
specifications or modify this product in
any way. Any damage to the cord may
cause short circuit, fire or electric
shock.
Don't place too much food directly
against the air outlet on the rear wall of
both the refrigerator and freezer
compartment, as it affects sufficient air
circulation.
Don't place hot items near the plastic
components of this appliance.
Frozen food must not be refrozen
once it has been thawed out.
Don't store bottled or canned drinks
(especially carbonated drinks) in the
freezer compartment. Bottles and cans
may explode.
Do not consume ice popsicles or ice
cubes straight from the freezer as this
can cause freezer burn to the mouth
and lips.
●
●
Keep all packaging away from
children to avoid risk of suffocation.
Protect children from being scalded
by touching the very hot compressor at
the rear bottom of appliance.
Don't place items on top of the
appliance as this could cause injury
should they fall off.
Never allow children to play with the
appliance by hanging or standing over
or on the doors, racks, shelves and
drawers etc.
●
●
●
To avoid the risks that are
always present when using an
electric appliance, we recommend that
you pay more attention to the
instructions about electricity below.
Important safety instructions
●
It is important to use your
appliance safely. We
General safety and daily use
4
●
This appliance must be earthed.
-This appliance is fitted with a plug in
accordance with local standard. The
plug should be suitable for use in all
houses fitted with sockets in
a c c o r d a n c e w i t h c u r r e n t
specifications.
-If the fitted plug is not suitable for
your socket outlets, it should be cut
off and carefully disposed of. To avoid
a possible shock hazard, do not insert
the discarded plug into a socket. If in
doubt contact a qualified, registered
electrician.
Do not use extension cords or
multiple sockets which could cause
overloading of wiring circuits and could
cause a fire.
Always plug your appliance into its
own individual electrical socket which
has a voltage rating that matched the
rating plate.
●
●
●
Make sure that the plug is not
squashed or damaged. Otherwise, it
may cause short circuit, electric shock
or overheat and even cause a fire.
Do not insert the mains plug if the
socket is loose, there is a risk of
electric shock or fire.
Switch off the appliance and
disconnect it from the mains power
before you clean or move it.
Never unplug the appliance by pulling
on the electrical cord. Always grip the
plug firmly and pull straight out from
the socket to prevent damaging the
power cord.
●
●
●
●
●
Do not operate the appliance without
the light cover of interior lighting.
Any electrical component must be
replaced or repaired by a qualified
electrician or authorized service
engineer. Only genuine spares should
be used.
Do not use electrical appliances such
as ice cream makers inside the food
s t o ra ge c o m pa rt m e n ts of t h e
appliance, unless they are approved
by the manufacturer.
Do not look direct into the LED light
located in the refrigerator compartment
with optical instruments to avoid eye
injuries. If it is not functioning correctly,
consult a qualified, registered
electrician or replace it in accordance
with the “cleaning and care” chapter.
●
Refrigerant
The refrigerant isobutene (R600a) is
contained within the refrigerant circuit
of the appliance, a natural gas with a
h i g h l e v e l o f e n v i r o n m e n t a l
compatibility, which is nevertheless
flammable. During transportation and
installation of the appliance, ensure
that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
5
●
●
●
Don't store products which contain
flammable propellants(e.g. spray cans )
or explosive substances in the
appliance.
Should the refrigerant circuit be
damaged:
Avoid opening flames(candles,
lamps etc.) and sources of ignition.
Thoroughly ventilate the room in
which the appliance is situated.
Service Note
This appliance employs
Hydrocarbon Refrigerant type
R600a.
It is hazardous for anyone other
than an Authorized Service Person
to service this applian. In
Queensland the authorized Service
Person MUST hold a Gas Work
Authorization for hydrocarbon
refrigerants to carry out servicing or
repairs which involve removal of
covers.
Caution: risk of fire
●
●
en 150 .See in follow
diagrams
150
?
150
?
w
°
0.5
adjusta e bottom f etbl e
adjusta e bottom f etbl e
908
411.5
650
1196.5
6
1. Freezer zone LED light
4
. Wind channel cover in freezer
6
. Ice box part
3
. Fre zer door s alee
2.
Freezer door Rack
7. Freezer drawerupper
9.
Freezer door Rack
1 . bl e
9
Right adjusta e bottom f et
1 e one LED light1. Fr sh z
1 . nne r in fresh
3
Wind cha l cove
1.Fres e
5
h sh lf
1. Fres e
6
h door s al
1 . Fresh door Rac
2
k
1.Eggtray
4
5
. Freezer shelf
8lower. Freezer drawer
10. bl eLeft adjusta e bottom f et
9
10
11
12
13
14
15
16
17
18
19
17. Fresh upper drawer
18 Fresh lower. drawer
7
Display controls
Use appliance according to theyour
following regulations, yourcontrol
appliance has the corresponding
functions and modes as the control
panelsshowed in the pictures below.
When the isappliance
powered for firson the
time, thebacklighting of
the icons on display
panel starts working. If
no have beenbuttons
pressed the doorsand
are theclosed,
backlighting offwill turn
after 60 seconds.
The control panel
consists areasof two
about temperature,one
area about different
modes.
Controlling the
temperature
We recommend that
when start youryou
refrigerator for the firs
time, temperaturethe
for the refrigerator is set
to and5 the freezer℃
to want to-18 . If you℃
change the
temperature, follow the
instructions below.
Caution!When a temperature,you set
you temperature for theset an average
whole refrigerator cabinet.
Temperatures eachinside
compartment may vary from the
temperatures thedisplayed on panel,
depending on how much food you
store and where you orplace it. High
low may alsoroom affecttemperature
the actual temperature inside the
appliance.
Unlock
You can select different modes by
pressing the button " " .M
ode
when
When certain mode is selected, wait
for corresponding icon flashin forthe
10 seconds.
All the buttons are iconlocked if the
" " illuminated, theis press
""for 3button seconds to
unlockthem.
And it will be locked itself after
Unlock
20 seconds no pressing any button
.
Mode
""
8
Display controls
Freezer
●
You can press the Freezer" button
to
activate the mode to contol the freezer
temperature. When you press the
butto n con tinuo usly, t he
temperature will be set as the
followingsequence.
DoorAlarm
If door of or freezer isthe fridge
open for over minutes, the door
alarm The buzzer willwill sound.
automatically stop alarming 10
minuteslater.
To energy,save please avoid
keeping the door open timefor a long
when using the The doorappliance.
alarm can be cleared by closing the
door.
2
●
●
Fridge
You can the "Fridge" buttonpress to
activate modethe fridgeto control the
temperature.When you press the
button continuously, the temperature
will sequence.be set the followingas
●
Artificia Intelligence
When the function is seleced, the
temperature isof the appliance
automatically adjusted.
When the Artifcial Intelligence
function is activated, the temperature
of the fridge is automatically switched
to 5 and the freezer to -18.
●
●
Super Freeze
Super Freeze will lower thequickly
temperature within sothe freezer food
will faster. thefreeze This can lock in
vitamins freshand nutrients of food
and keep food fresh longer.
Press button to select the"Unlock"
Super Freeze function. The light will
be illuminated.
For maximum tothe amount of food
be frozen, please wait 24 h.about
Super switchesfreezeautomatically
off after 26 hours the freezerand
temperature to -25 .℃
℃setted
●
●
●
Holiday
If you are going to be away for a long
period of time, holiday function will be
your best choice.
Holiday function. The light will be
illuminated.
When the holiday function is
activated, the temperature of the
fridge is automatically switched to
15 and the freezer to -18 to
℃℃℃ ℃
minimize the energy consumption.
Do not store any food in
the fridge during this time.
Important!
●
9
②
nut
①
bolt
③
screwdriver
y causethe
bottle tobreak.
When you foud the doors are not at the
same level, you can use the screwdriver
to adjust the door.
When the freezer door is upper than the
refrigerator door. First, you can use the
screwdriver to turn the bolt anticlockwise
on the lower hinge that can make the door
go up. Then use the screwdriver to locking
the nut.
1.Adjust the door
ck into the
position.
4.Using your ice box
The ice box is as a independent part
that can be take out of the freezing
chamber.
Using the ice box
Take out the ice box placed on a
platform, then pour water into the ice
trays and the ater level shall not
w
exceed the maximum line.
Place the flled ice box back to the
freezing room.
When ice cubes form, twist the
knobs clockwise and the ice will drop
into the ice box below.
Ice cubes can be stored in t he ice
box, if you need t hem, you can pull out
the ice box and take them out.
mes
10
Place foo
Note: If the ice is used for the firstb
ox
time or has not been used for a long
time, please clean it before using.
water injection
take off ice
s suggested by
11
12
13
14
Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental
safe recycling.
15
