Built-in oven
[en] Instruction manual
HB875GDB1A
en
3
Table of contents
enI nst r uct i on manual
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
( Important safety information . . . . . . . . . . . . . . . 5
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Meat thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7 Environmental protection . . . . . . . . . . . . . . . . . . 7
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 7
* Getting to know your appliance . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating modes menu . . . . . . . . . . . . . . . . . . . . . . . . 9
Types of heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking compartment functions . . . . . . . . . . . . . . . . 10
_ Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 10
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
K Before using for the first time. . . . . . . . . . . . . . 12
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning the cooking compartment and accessories 12
1 Operating the appliance . . . . . . . . . . . . . . . . . . 13
Switching the appliance on and off . . . . . . . . . . . . . . 13
Starting or interrupting operation . . . . . . . . . . . . . . . . 13
Selecting an operating mode . . . . . . . . . . . . . . . . . . . 13
Setting the type of heating and temperature . . . . . . . 13
Rapid heat up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
O Time-setting options . . . . . . . . . . . . . . . . . . . . . 14
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cooking time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
End time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
A Childproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 15
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 15
The appliance door is locked. . . . . . . . . . . . . . . . . . . 15
Q Basic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
List of settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing the time . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
F Sabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Starting Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . .16
@ Meat thermometer . . . . . . . . . . . . . . . . . . . . . . . 17
Heating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Inserting the meat probe into the food . . . . . . . . . . . .17
Setting the core temperature . . . . . . . . . . . . . . . . . . .17
Core temperatures of different foods . . . . . . . . . . . . .18
. Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 18
Before running the cleaning function . . . . . . . . . . . . .18
Setting the self-cleaning function . . . . . . . . . . . . . . . .19
Once the cleaning function has ended . . . . . . . . . . . .19
D Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .19
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .21
p Rails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Detaching and refitting the rails . . . . . . . . . . . . . . . . .21
q Appliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing and fitting the appliance door . . . . . . . . . .22
Removing the door cover . . . . . . . . . . . . . . . . . . . . . .23
Removing and installing the door panels . . . . . . . . . .23
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 25
Fault table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Maximum operating time exceeded . . . . . . . . . . . . . .25
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Glass cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . 26
E number and FD number . . . . . . . . . . . . . . . . . . . . .26
P Dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Information on the setting . . . . . . . . . . . . . . . . . . . . . .27
Selecting a dish . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Applying settings for dishes . . . . . . . . . . . . . . . . . . . .27
J Tested for you in our cooking studio. . . . . . . . 28
Silicone moulds . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Roasting and braising. . . . . . . . . . . . . . . . . . . . . . . . .30
Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Convenience products . . . . . . . . . . . . . . . . . . . . . . . .36
Yogurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Eco heating functions . . . . . . . . . . . . . . . . . . . . . . . . .38
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .39
en Intended use
4
Slow cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Drying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Prove dough. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Test dishes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.siemens-home.bsh-group.com and in the online
shop www.siemens-home.bsh-group.com/eshops
8Intended use
Intended us e
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~ "Accessories" on page 10
Important safety information en
5
(Important safety
information
Impor t ant safety informat i on
General information
:Warning – Risk of fire!
■ Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■ Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■ A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■ The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■ Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■ Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
:Warning – Risk of scalding!
■ The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■ When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■ Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■ Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■ The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
:Warning – Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■ The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■ Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■ A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.
en Causes of damage
6
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
Meat thermometer
:Warning – Risk of electric shock!
The insulation of an incompatible meat
thermometer may be damaged. Only use the
meat thermometer which is recommended for
this appliance.
Cleaning function
:Warning – Risk of fire!
■ Loose food residues, grease and meat
juices may catch fire during the cleaning
function. Before starting the cleaning
function, remove coarse dirt from the
cooking compartment and from the
accessories.
Risk of fire!
■ The appliance will become very hot on the
outside during the cleaning function. Never
hang combustible objects, e.g. tea towels,
on the door handle. Do not place anything
against the front of the appliance. Keep
children away from the appliance.
Risk of fire!
■ If the door seal is damaged, a large amount
of heat will be generated around the door.
Do not scrub or remove the seal. Never
operate the appliance if the seal is
damaged or missing.
:Warning – Risk of serious damage to
health!
The appliance will become very hot during the
cleaning function. The non-stick coating on
baking trays and tins is destroyed and noxious
gases are released. Never clean non-stick
baking trays and baking tins using the
cleaning function. Only clean enamelled
accessories using the cleaning function.
:Warning – Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so
that food remnants left over from roasting,
grilling and baking will burn off.This process
releases vapours, which can irritate the
mucous membranes. While the cleaning
function is running, keep the kitchen well
ventilated. Do not remain in the room for long
periods. Keep children and pets away. Follow
the instructions even when using the Delayed
start function with a delayed end time.
:Warning – Risk of burns!
■ The cooking compartment becomes
extremely hot during the cleaning function.
Never open the appliance door. Allow the
appliance to cool down. Keep children
away from the appliance.
Risk of burns!
■ ; The appliance becomes very hot on the
outside during the cleaning function. Never
touch the appliance door. Allow the
appliance to cool down. Keep children at a
safe distance.
]Causes of damage
Ca u s e s of damage
General information
Caution!
■ Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■ Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■ Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■ Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■ Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■ Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
Environmental protection en
7
■ Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing. ~ "Cleaning" on page 19
■ Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■ Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■ Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
7Environmental protection
En v i r o n ment al pr ot ec t i on
Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■ Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■ Leave frozen food to defrost before placing it in the
cooking compartment.
■ Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■ Remove any unnecessary accessories from the
cooking compartment.
■ Open the appliance door as infrequently as possible
when the appliance is in use.
■ It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■ For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
en Getting to know your appliance
8
*Getting to know your
appliance
Get t i ng to know your appl i ance
In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
In the control panel, you can use the various buttons,
touch fields and the rotary selector to set the required
function of the appliance. The current settings are
shown in the display.
Controls
The individual controls are adapted for the various
functions of your appliance. You can set your appliance
simply and directly.
Buttons and touch fields
Here you can find a short explanation of the various
buttons and touch fields.
--------
Rotary selector
Use the rotary selector to change the operating modes
and adjustment values shown in the display.
In most selection lists, e.g. types of heating, the first
selection follows the last. For temperature for example,
you must turn the rotary selector back when the
minimum or maximum temperature is reached.
Display
The display is structured so that the information can be
read at a glance.
The value that you can currently set is in focus. It is
displayed in white lettering with a dark background.
Status bar
The status bar is at the top of the display. The time and
set time functions are displayed here.
Progress line
The progress line is under the status bar. The progress
line shows you how much time has elapsed, for
&
##
PO
PGG
NFOV TUBSUTUPQ
'KRWDLU
(
Buttons
The buttons to the left and right of the rotary
selector have a pressure point. Press these
buttons to activate them.
0
Rotary selector
You can turn the rotary selector clockwise and
anti-clockwise.
8
Display
You can see the current adjustment values,
options or notes in the display.
@
Touch fields
There are sensors under the touch fields to the left
¾ and right ¿ of the display. Touch the respective
arrow to select the function.
Buttons Meaning
on/off Switches the appliance on and off
menu Menu Opens the operating modes menu
l/
Information
Childproof lock
Displays notes
Activates/deactivates the child-
proof lock
0
Time-setting
options
Opens the time-setting options
menu
c
Rapid heat up Switches rapid heat up on and off
Start/Stop Starts, pauses or cancels opera-
tion
Touch fields
¾
Field to the left of
the display
Navigates left
¿
Field to the right of
the display
Navigates right
Getting to know your appliance en
9
example. The line over the in-focus value progresses
from left to right, the longer the operation continues to
run.
Lapse of time
If you have started your appliance without a cooking
time, you can see how long the operation has already
been running for at the top on the right in the status bar.
Temperature check
The temperature indicator bars show the heating
phases in the cooking compartment.
Note: Due to thermal inertia, the temperature displayed
may be slightly different to the actual temperature inside
the oven. You can use the
² button to check the
current heating temperature when heating up.
Operating modes menu
The menu is divided into different operating modes. In
this way, you can quickly access the required function.
--------
Types of heating
To make sure that you always use the right type of
heating to cook your food, we have explained the
differences and applications below.
For temperature settings above 275 °C and grill
setting 3, the appliance reduces the temperature to
approx. 275 °C or grill setting 1 after approx.
40 minutes.
Heating indicator The heating indicator displays the rising tempera-
ture in the cooking compartment. When all bars
are complete, the optimum time for placing the
dish in the oven has been reached.
The bars do not appear when settings are applied
for grilling and cleaning.
Residual heat
indicator
When the appliance is switched off, a line appears
under the status bar which shows how much
residual heat is in the cooking compartment.
Once the temperature has dropped to approxi-
mately 60 °C, the display goes out.
Operating mode Use
Types of heating There are several finely tuned
types of heating for you to pre-
pare your dishes.
Dishes ~ "Dishes" on page 27 Here you can find prepro-
grammed setting values which
are suitable for many dishes.
Self-cleaning ~ "Cleaning
function" on page 18
The self-cleaning function cleans
your oven automatically.
Settings ~ "Basic settings"
on page 16
You can adapt your appliance's
basic settings to suit your needs.
Types of heating Temperature Use
:
4D hot air 30-275 °C For baking and roasting on one or more levels.
The fan distributes the heat from the ring heating element in the back panel evenly
around the cooking compartment.
%
Top/bottom heating 30-300 °C For traditional baking and roasting on one level. Especially suitable for cakes with
moist toppings.
Heat is emitted evenly from above and below.
‘
Hot air eco 30-275 °C For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back panel
around the cooking compartment.
This heating function is most effective between 125 and 275 °C.
This heating function is used to measure both the energy consumption in air recircula-
tion mode and the energy efficiency class.
+
Top/bottom heating eco 30-300 °C For gently cooking selected types of food on one level.
Heat is emitted from above and below.
This heating function is most effective between 150 and 250 °C.
This heating function is used to measure the energy consumption in the conventional
mode.
4
Hot air grilling 30-300 °C For roasting poultry, whole fish and larger pieces of meat.
The grill heating element and the fan switch on and off alternately. The fan circulates
the hot air around the food.
(
Grill, large area Grill settings:
1 = low
2 = medium
3 = high
For grilling flat items such as steaks, sausages or bread, and for browning food.
The whole area of the grill heating element becomes hot.
*
Grill, small area Grill settings:
1 = low
2 = medium
3 = high
For grilling small quantities of food such as steaks, sausages or bread, and for brown-
ing food.
The centre part under the grill heating element becomes hot.
en Accessories
10
--------
Default values
For each type of heating, the appliance specifies a
default temperature or level. You can accept this value
or change it in the appropriate area.
Further information
In most cases, the appliance provides notes and further
information on the action just carried out. To do this,
press the l button. The note is shown for a few
seconds.
Some notes are displayed automatically, for example as
confirmation, or to provide an instruction or warning.
Cooking compartment functions
Some functions make your appliance easier to use.
This, for example, enables the cooking compartment to
be well lit and a cooling fan to prevent the appliance
from overheating.
Opening the appliance door
If you open the appliance door during an operation, the
operation is paused. Operation continues to run when
you close the door.
Interior lighting
When you open the appliance door, the interior lighting
switches on. If the door remains open for longer than
15 minutes, the lighting switches off again.
For most operating modes, the interior lighting switches
on as soon as the operation is started. When the
operation has finished, the lighting switches off.
Note: You can set the interior lighting not to come on
during the operation in the basic settings.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise the oven
will overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
Note: You can change how long the cooling fan
continues to run for in the basic settings. ~ "Basic
settings" on page 16
_Accessories
Ac c e s s o r i e s
Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
;
Pizza setting 30-275 °C For preparing pizza and dishes which require a lot of heat from underneath.
The bottom heating element and the ring heating element in the back panel heat up.
.
Slow cooking 70-120 °C For gentle and slow cooking of seared, tender pieces of meat in ovenware without a
lid.
The heat is emitted evenly from the top and bottom at low temperatures.
$
Bottom heating 30-250 °C For cooking in a bain marie and for the final baking stage.
The heat is emitted from below.
R
Keeping warm 60-100 °C For keeping cooked food warm.
ˆ
Preheating ovenware 30-70 °C For preheating ovenware.
,
CoolStart function 30-275 °C For the quick preparation of frozen products on level 3. The temperature depends on
the manufacturer's instructions. Use the highest temperature specified on the packag-
ing. The cooking time is as specified or shorter. Preheating is not required.
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.
Grill tray
Use for grilling in place of the wire rack
or as a splatter guard.
Only use in the universal pan.
Meat thermometer
Enables precision roasting to your exact
requirements.
Its use is described in the relevant sec-
tion. ~ "Meat thermometer"
on page 17
Accessories en
11
Only use original accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may deform when they become
hot. This does not affect their function. Once they have
cooled down again, they regain their original shape.
Inserting accessories
The cooking compartment has five shelf positions. The
shelf positions are counted from the bottom up.
In some appliances, the highest shelf position is
marked on the cooking compartment with the grill
symbol.
Always insert the accessory between the two guide bars
for a shelf position.
Accessories can be pulled out approximately halfway
without tipping.
Notes
■ Make sure that you always insert the accessories
into the cooking compartment the right way round.
■ Always insert accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■ Take any accessories that you will not be using out
of the cooking compartment.
Locking function
The accessories can be pulled out approximately
halfway until they lock in place. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to
work properly.
When inserting the wire rack, ensure that lug ‚ is at the
rear and is facing downwards. The open side must be
facing the appliance door and the outer rail must be
facing downwards ¾.
When inserting baking trays, make sure that the recess
‚ is at the rear and is facing downwards. The sloping
edge of the accessory ƒ must be facing towards the
appliance door.
Example in the picture: Universal pan
Combining accessories
You can insert the wire rack and the universal pan at
the same time to catch drops of liquid.
When inserting the wire rack, ensure that both spacers
‚ are at the rear edge. When inserting the universal
pan, the wire rack is on top of the upper guide rod of
the shelf position.
Example in the picture: Universal pan
Optional accessories
You can buy optional accessories from the after-sales
service, from specialist retailers or online. *You will find
a comprehensive range of products for your appliance
in our brochures and online.
Both availability and whether it is possible to order
online differ between countries. Please see your sales
brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, please always quote the
exact identification number (E-no.) of your appliance.
~ "Customer service" on page 26
D
D
Optional accessories
Wire rack
For ovenware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Universal pan, Self-cleaning
For moist cakes, pastries, frozen meals and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
Baking tray, Self-cleaning
For tray bakes and small baked products.
D
D
E
D
D
D
en Before using for the first time
12
--------
KBefore using for the first
time
Be f o r e us i ng for the fi rst ti me
Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
After connecting the appliance to the power or following
a power cut, the settings for initial use are shown in the
display.
Note: You can change these settings at any time in the
basic settings. ~ "Basic settings" on page 16
Setting the language
"German" is the preset language.
1. Use the rotary selector to select the required
language.
2. Touch the ¿ arrow.
The next setting appears.
Setting the time
The time starts at "12:00".
1. Turn the rotary selector to set the current time.
2. Touch the ¿ arrow
Setting the date
The default date is "01.01.2014".
1. Use the rotary selector to set the current day, month
and year.
2. Touch the ¿ arrow to confirm.
A note appears in the display confirming that the
initial use has been completed.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To remove the new-appliance smell, heat up the
cooking compartment when empty and with the oven
door closed.
Make sure that there is no leftover packaging, such as
polystyrene pellets, in the cooking compartment and
remove the adhesive tape that is in or on the appliance.
Before heating the appliance, wipe the smooth surfaces
in the cooking compartment with a soft, wet cloth. Keep
the kitchen ventilated while the appliance is heating.
Apply the settings indicated.
You can find out how to set the type of heating and the
temperature in the next section.
Switch off the appliance after the cooking time indicated
using the On/Off button.
After the cooking compartment has cooled down, clean
the smooth surfaces with soapy water and a dish cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
Profi pan
For preparing large quantities.
Lid for the Profi pan
The lid turns the Profi pan into a Profi roasting dish.
Pizza tray
For pizzas and large round cakes.
Grill tray, Self-cleaning
Use for grilling in place of the wire rack or as a splatter guard.Only use
in the universal pan.
Bread-baking stone, Self-cleaning
For home-made bread, bread rolls and pizzas that require a crispy
base.
The baking stone must be preheated to the recommended tempera-
ture.
Glass roasting dish
For stews and bakes.
Particularly suitable for the "Meals" operating mode.
Glass tray
For large roasts, moist cakes and bakes.
Glass tray
For bakes, vegetable dishes and baked goods.
Pull-out system, 1 level, ,Self-cleaning
The pull-out rails at level 2 allow you to pull the accessories out further
without them tipping.
Pull-out system, 2 levels, Self-cleaning
The pull-out rails at levels 2 and 3 allow you to pull the accessories out
further without them tipping.
Pull-out system, 3 levels, Self-cleaning
The pull-out rails at levels 1, 2 and 3 allow you to pull the accessories
out further without them tipping.
Decorative trims
For concealing the lower shelf of the unit and the base of the appli-
ance. Settings
Type of heating
4D Hotair :
Temperature maximum
Cooking time 1 hour
Operating the appliance en
13
1Operating the appliance
Oper at i ng the appl i anc e
You have already learnt about the controls and how
they work. Now we will explain how to set your
appliance. You will learn about what happens when you
switch the appliance on and off, and how to select the
operating mode.
Switching the appliance on and off
Before you are able to set the appliance, you must
switch it on.
Exception: The childproof lock and the timer can be set
when the appliance is switched off.
Displays or information, e.g the residual heat indicator
in the cooking compartment, remain visible in the
display after the appliance has been switched off.
Switch off your appliance when you do not need to use
it. If no settings are applied for a long time, the
appliance switches itself off automatically.
Switching on the appliance
Use the on/off button to switch the appliance on.
The on/off symbol above the button lights up in blue.
The studioLine logo appears in the display, followed by
a type of heating and a temperature.
Note: In the basic settings, you can specify which
operating mode should appear after the appliance is
switched on.
Switching off the appliance
Use the On/Off button to switch off the appliance.
The lighting above the button goes out.
A set function is cancelled.
The time appears in the display.
Note: You can set whether or not the time should be
displayed when the appliance is switched off in the
basic settings.
Starting or interrupting operation
To start operation or to interrupt an operation which has
started running, press the Start/Stop button. The
cooling fan may continue to run after an operation is
interrupted.
Press the On/Off button to delete all settings.
If you open the cooking compartment door during
operation, operation is interrupted. Close the cooking
compartment door to continue operation.
Selecting an operating mode
If you want to set an operating mode, the appliance
must be switched on.
1. Press the menu button.
The operating modes menu opens.
2. Use the rotary selector to select the required
operating mode.
Depending on the operating mode, different options
are available.
3. Use the ¿ arrow to reach the required operating
mode.
4. Use the rotary selector to change the selection.
Depending on the option, change different settings.
5. Press the Start/Stop button to start.
Setting the type of heating and temperature
After the appliance is switched on, the suggested type
of heating appears with the temperature. You can start
this setting immediately with the Start/Stop button.
For other settings, you can change the values as shown
in the pictures.
Example: Top/bottom heating, 180 °C
1. Use the rotary selector to change the type of
heating.
2. Press the arrow ¿ to switch to the temperature.
3. Use the rotary selector to change the temperature.
4. Press the Start/Stop button.
The set type of heating and the temperature are
displayed in the display.
Rapid heat up
You can use the c button to heat up the cooking
compartment particularly quickly.
The rapid heat up function is not possible for all types of
heating.
Suitable types of heating:
To ensure an even cooking result, do not place your
food and the accessory in the cooking compartment
until rapid heating is complete.
:
4D hot air
%
Top/bottom heating
$
7RSERWWRP
KHDWLQJ
$
7RSERWWRP
KHDWLQJ
&
PLQV
7RSERWWRP
KHDWLQJ
en Time-setting options
14
Making settings
Ensure you have selected a suitable type of heating.
The temperature must be set to above 100 °C,
otherwise the rapid heat up function cannot be started.
1. Set the type of heating and temperature.
2. Press the c button.
The c symbol appears on the left next to the
temperature. The progress line begins to move across.
When rapid heat up is complete, a signal sounds. The
c symbol goes out. Place your dish in the cooking
compartment.
Notes
■ If a cooking time has been set, this runs
independently of the rapid heat up process and
counts down immediately when operation is started.
■ You can use the l button to check the current
cooking compartment temperature during rapid heat
up.
Cancelling
Press the c button. The c symbol disappears from
the display.
OTime-setting options
Ti me- s et t i ng opt i ons
Your appliance has different time-setting options.
Notes
■ A cooking time of up to one hour can be set exactly
to the minute.
A cooking time of over one hour can be set in 5-
minute increments.
■ Depending on which direction you turn the rotary
selector, the cooking time starts at a default value:
Anti-clockwise, 10 minutes,
Clockwise, 30 minutes.
■ After a time-setting option has elapsed, a signal
sounds.
■ Using the l button, you can request information
during operation, which then appears briefly in the
display.
Timer
You can set the timer at any time, even if the appliance
is switched off. It runs parallel to the other time settings
and has a separate audible signal. In this way, you can
tell whether it is the timer or a cooking time which has
elapsed.
The maximum setting you can apply is 24 hours.
1. Press the 0 button.
The field for the timer opens.
2. Use the rotary selector to set the timer duration.
The timer starts after a few seconds.
The U symbol for the timer and the time counting down
are displayed on the left in the status bar.
When the time has elapsed
An audible signal sounds. "Timer elapsed" appears in
the display. Use the 0 button to cancel the audible
signal early.
Cancelling the timer duration
Press the 0 button to open the time-setting options
menu and turn the time back. Press the 0 button to
close the menu.
Changing the timer duration
Use the 0 button to open the time-setting options
menu and change the timer time in the next few
seconds using the rotary selector. Start the timer with
the 0 button.
Cooking time
If you set the cooking time for your food, operation
stops automatically once this time has elapsed. The
oven stops heating.
Prerequisite: A type of heating and a temperature have
been set.
For example: Setting for 4D hot air, 180 °C, cooking
time 45 minutes.
1. Press the 0 button.
The time-setting options menu opens.
2. Set the cooking time using the rotary selector.
3. Press the Start/Stop button to start.
Time-setting option Use
Q
Timer The timer functions like an egg timer. An
audible signal sounds once the set time
has elapsed.
+
Cooking time A signal sounds once a set cooking time
has elapsed. The appliance switches off
automatically.
*
End Set a cooking time and an end time. The
appliance switches on automatically so
that the operation ends at the desired
time.
ꑛ
&
PLQV
7RSERWWRP
KHDWLQJ
PLQV
ꑘ
PLQV
ꑖ
'XUDWLRQ
7LPHU
PLQV
ꑘ
PLQV
ꑖ
'XUDWLRQ
7LPHU
Childproof lock en
15
You can see the cooking time
x counting down in
the status bar.
The cooking time has elapsed
A signal sounds. The oven stops heating. You can
cancel the audible signal early using the 0 button.
Cancelling the cooking time
Press the 0 button to open the time-setting options
menu. Turn the time back. The type of heating and
temperature set are shown in the display.
Changing the cooking time
Press the 0 button to open the time-setting options
menu. Change the cooking time using the rotary
selector.
End time
If you change the end time, please remember that
easily spoiled foods must not be allowed to remain in
the cooking compartment for too long.
Prerequisite: The selected operation has not already
begun. A cooking time has been set. The time-setting
options menu 0 is open.
Example in the picture: You put the dish in the cooking
compartment at 9:30. It takes 45 minutes to cook and
will be ready at 10:15, but you would like it to be ready
at 12:45 instead.
1. Touch the ¿ arrow to continue to "y end".
2. Set the end time using the rotary selector.
3. Confirm with the Start/Stop button.
The oven is in standby. The y symbol and the time at
which the operation will be finished appear in the status
bar. The operation starts at the appropriate time. You
can see the cooking time counting down in the status
bar.
The cooking time has elapsed
A signal sounds. The oven stops heating. You can
cancel the audible signal early using the 0 button.
Correcting the end time
This is possible if the oven is in standby.
1. Press the Start/Stop button.
2. Press the 0 button.
The Time-setting Options menu opens.
3. Use the ¿ arrow to switch to "y End" and correct
the end time using the rotary selector.
4. Press the 0 button.
5. Press the Start/Stop button.
The oven is on standby.
Cancelling the end time
This is possible if the oven is in standby.
1. Press the Start/Stop button.
2. Press the 0 button.
The Time-setting Options menu opens.
3. Use the ¿ arrow to switch to "y End" and turn the
end time back using the rotary selector.
4. Press the 0 button.
5. Press the Start/Stop button to start.
The cooking time starts to count down immediately.
AChildproof lock
Ch i l d p r o o f lock
Your appliance is equipped with a childproof lock so
that children cannot switch it on accidentally or change
any settings.
Activating and deactivating
You can activate and deactivate the childproof lock
when the appliance is switched on or off.
In each case, press the / button for approx. 4
seconds. A confirmation note appears in the display
and the / symbol appears in the status bar.
The appliance door is locked
In the basic settings, you can change the settings so
that the appliance door is also locked in addition to the
control panel.
The appliance door locks if the temperature in the
cooking compartment reaches approx. 50 °C. The H
symbol is displayed in the status bar. When the oven is
switched off, the appliance door locks immediately if the
childproof lock has been activated.
ꑗ
(QG
&
ꑗ
'KRWDLU
en Basic settings
16
QBasic settings
Ba s i c set t i ngs
There are various settings available to you in order to
help use your appliance effectively and simply. You can
change these settings as required.
Changing settings
1. Press the "On/off" button.
2. Press the menu button.
The operating modes menu opens.
3. Use the rotary selector to select "Settings".
4. Touch the arrow ¿.
5. Use the rotary selector to change the values.
6. Use the arrow ¿ to change to the next settings, and
change them if necessary.
7. Press the menu button to save.
"Save" or "Discard" appears on the display.
List of settings
This list tells you all the basic settings and how to
change them. Depending on the model of the appliance
you own, the display will show only those settings that
apply to your appliance.
You can change the following settings:
Caution!
For shelves and single rails: "Not retrofitted" setting.
For sets of two or three rails: "Retrofitted" setting.
Note: Changes to the language, button tone and
display brightness settings take effect immediately. All
other changes take effect after the settings have been
saved.
--------
Changing the time
You can change the time in the basic settings.
For example: Changing from summer to winter time.
1. Press the On/Off button.
2. Press the Menu button.
3. Use the rotary selector to select "Settings".
4. Touch the arrow ¿ to move to "Time of day".
5. Use the rotary selector to change the time.
6. Press the Menu button.
Save or Discard appears in the display.
Power cut
Following a long power cut, the settings for initial use
are shown in the display.
Reset the language, time and date.
FSabbath mode
Sa b b a t h mode
With the Sabbath mode, a cooking time of up to 74
hours can be set. You can keep the food in the cooking
compartment warm without having to switch the oven
on or off.
Starting Sabbath mode
Prerequisite: "Sabbath mode activated" is activated in
the basic settings. ~ "Basic settings" on page 16
The cooking compartment heats with top/bottom
heating and a temperature between 85 °C and 140 °C.
1. Press the on/off button.
A type of heating and a temperature are suggested
in the display.
2. Turn the rotary selector anti-clockwise and select the
"Sabbath mode" type of heating.
3. Tap the ¿ arrow and set the temperature using the
rotary selector.
Setting Options
Select language Additional languages possible
Time of day Sets the current time
Date Sets the current date
Audible signal duration Short (30 s)
Medium (1 m)
Long (5 m)
Button tone Switched off (button tone still sounds
when switching on/off using the "On/off"
button)
Switched on
Display brightness Can be adjusted to one of five different
levels
Clock display Digital
Off
Lighting On during operation
Off during operation
Childproof lock Door lock + button lock
Button lock only
Operation after switching
on
Main menu
Heating modes
Dishes*
Night-time dimming Switched off
Switched on (display dimmed between 10
p.m. and 5.59 a.m.)
Brand name logo Display
Do not display
Fan run-on time Recommended
Minimum
Pull-out system Not retrofitted
Retrofitted
Sabbath mode Switched on
Switched off
Factory settings Restore
Do not restore
*) Included, depending on appliance model
Meat thermometer en
17
4. Press the 0 button to open the time-setting options
menu.
25:00 hours are suggested.
5. Use the rotary selector to set the required cooking
time.
6. Press the start/stop button to start.
You can see the cooking time counting down in the
status bar.
The cooking time has elapsed
A signal sounds. The oven stops heating.
Setting a later end time
It is not possible to set a later end time.
Cancelling Sabbath mode
Press the On/Off button. All settings are deleted. You
can apply new settings.
@Meat thermometer
Meat t her momet er
The meat thermometer Plus makes precise cooking
possible. It measures the temperature inside the food.
Once the set temperature has been reached, the
appliance automatically switches itself off.
Heating modes
Once you have placed the meat thermometer in the
cooking compartment, the following heating modes are
available for you to select.
Notes
■ The meat thermometer measures the temperature
on the inside of the food between 30 °C and 99 °C.
■ Use only the meat thermometer supplied. You can
purchase it as a spare part from the after-sales
service.
■ After use, always remove the meat thermometer
from the cooking compartment. Never store it inside
the cooking compartment.
Cooking compartment temperature
To prevent damage to the meat thermometer, do not
set temperatures higher than 250 °C.
The interior temperature set in the cooking
compartment must be at least 10 °C higher than the
core temperature that has been set.
Inserting the meat probe into the food
Before placing your food into the cooking compartment,
insert the meat probe into the food.
The meat probe has three measuring points. Ensure
that the middle measuring point is inserted in the food.
Meat: For large pieces of meat, insert the meat probe at
an angle from above as far as it will go into the meat.
For relatively thin pieces of meat, insert the meat probe
from the side at the thickest point.
Poultry: Insert the meat probe as far as it will go into
the thickest point in the breast. Insert the meat probe
into the poultry crossways or lengthways depending on
its structure. Then turn the poultry and place it on the
wire rack breast-side down.
Turning the food: If you wish to turn the food, do not
remove the meat probe. Once you have turned the
food, check that the meat probe is correctly positioned
in the food.
If you remove the meat probe while the food is cooking,
all settings will be reset and you will have to apply them
again.
Caution!
Ensure that the meat probe's cable does not become
trapped.
To prevent the meat probe from being damaged by
excessive heat, there must be a gap of a few
centimetres between the grill element and the meat
probe. The meat may expand during the cooking
process.
Setting the core temperature
1. Insert the meat thermometer in the socket on the left-
hand side of the cooking compartment.
2. Use the rotary selector to select the heating mode or
the "Dishes" operating mode.
3. Use the arrow ¿ to switch to the temperature and set
the temperature using the rotary selector.
:
4D hot air
‘
Hot air eco
%
Top/bottom heating
+
Top/bottom heating eco
;
Pizza setting
4
Hot air grilling
en Cleaning function
18
4. Use the arrow ¿ to switch to the core temperature
and set the core temperature using the rotary
selector.
5. Press the start/stop button.
Operation begins.
Once the set core temperature in the food has been
reached
An audible signal sounds. The oven stops heating. You
can unplug the meat thermometer from the socket. The
. symbol goes out.
Changing the core temperature
You can change the core temperature at any time.
Cancelling
Unplug the meat thermometer from the socket.
:Warning – Risk of burns!
The cooking interior and the core temperature probe
become very hot. Use oven mitts to plug and unplug the
core temperature probe.
:Warning – Risk of electric shock!
The insulation of an incompatible meat probe may be
damaged. Only use the meat probe which is
recommended for this appliance.
Core temperatures of different foods
Do not use frozen food. The figures in the table are
given as a guide. They depend on the quality and
composition of the food.
You can find comprehensive information on the heating
mode and temperature at the end of the instruction
manual. ~ "Tested for you in our cooking studio"
on page 28
.Cleaning function
Cl e a n i n g functi on
Use "Self-cleaning" mode to clean the cooking
compartment.
You can choose from three cleaning settings.
The dirtier the cooking compartment and the longer the
dirt has been there, the higher the cleaning setting
should be. A cleaning cycle requires only approx. 2.5 –
4.7 kilowatt hours.
Note: For your safety, the cooking compartment door
locks automatically. It cannot be opened again until the
H symbol for the locking mechanism goes out in the
status bar. The interior lighting remains off during
cleaning.
:Warning
Risk of burns!
■ The cooking compartment becomes extremely hot
during the cleaning function. Never open the
appliance door. Allow the appliance to cool down.
Keep children away from the appliance.
Risk of burns!
■ ; The appliance becomes very hot on the outside
during the cleaning function. Never touch the
appliance door. Allow the appliance to cool down.
Keep children at a safe distance.
:Warning
Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so that food
remnants left over from roasting, grilling and baking will
burn off.This process releases vapours, which can
irritate the mucous membranes. While the cleaning
function is running, keep the kitchen well ventilated. Do
not remain in the room for long periods. Keep children
and pets away. Follow the instructions even when using
the Delayed start function with a delayed end time.
Before running the cleaning function
While cleaning is in progress, you can clean an
accessory at the same time, e.g. the universal pan or
the baking tray. Before starting the cleaning function,
remove the worst of the food remnants manually. Slide
the accessory in at level 2.
Clean the appliance door and along the edges of the
cooking compartment in the area around the seal. Do
not scrub or remove the seal.
Clean the inner door panel using hot soapy water and a
dish cloth. Dry with a soft cloth. If the cooking
compartment is heavily soiled, use oven cleaner.
Note: You can clean the enamelled accessory supplied
in the cooking compartment when the cleaning function
is cleaning the cooking compartment. You cannot clean
any of the wire racks when using the cleaning function.
Food Core temperature in
°C
Poultry 75
Pork 75
Beef, rare 50
Beef, medium 60
Beef, well done 70
Lamb 70
Setting Cleaning level Duration
1 Light Approx. 1 hour, 15 minutes
2 Medium Approx. 1 hour, 30 minutes
3 Intensive Approx. 2 hours
Cleaning en
19
The wire racks are not suitable for the cleaning function
and will become discoloured. Further accessories that
can be cleaned using the cleaning function are listed in
the table for special accessories. ~ "Accessories"
on page 10
:Warning
Risk of fire!
■ Loose food residues, grease and meat juices may
catch fire during the cleaning function. Before
starting the cleaning function, remove coarse dirt
from the cooking compartment and from the
accessories.
Risk of fire!
■ The appliance will become very hot on the outside
during the cleaning function. Never hang
combustible objects, e.g. tea towels, on the door
handle. Do not place anything against the front of
the appliance. Keep children away from the
appliance.
Risk of fire!
■ If the door seal is damaged, a large amount of heat
will be generated around the door. Do not scrub or
remove the seal. Never operate the appliance if the
seal is damaged or missing.
:Warning – Risk of serious damage to health!
The appliance will become very hot during the cleaning
function. The non-stick coating on baking trays and tins
is destroyed and noxious gases are released. Never
clean non-stick baking trays and baking tins using the
cleaning function. Only clean enamelled accessories
using the cleaning function.
Setting the self-cleaning function
1. Press the menu button.
The operating modes menu opens.
2. Use the rotary selector to select "Self cleaning".
3. Touch the arrow ¿.
Cleaning setting 3 is suggested. You can start the
cleaning process immediately using the "Start/stop"
button or
4. select a different cleaning setting using the rotary
selector.
5. Press the "Start/stop" button.
Instructions for the cleaning operation appear on the
display.
6. Press the "Start/stop" button to start the cleaning
operation.
Ventilate the kitchen when the cleaning function is
running.
The cooking compartment door locks shortly after
operation starts. The H symbol for the locking
mechanism appears on the right-hand side of the status
bar next to the elapsing duration.
The cooking compartment door cannot be opened until
the H symbol goes out in the status bar.
Once the cleaning has finished
An audible signal sounds. The oven stops heating. Use
the 0 button to switch off the audible signal. "Appliance
cooling down" appears on the display.
Cancelling the cleaning operation
Use the "On/off" button to switch off the oven. The
cooking compartment door cannot be opened until the
H symbol goes out in the status bar.
Adjusting the cleaning setting
Once cleaning starts, the cleaning setting can no longer
be changed.
You can set the cleaning to run overnight
In the section "Time settings", you can find out how to
delay the end time. This allows you to use the oven at
any time throughout the day. ~ "Time-setting options"
on page 14
Once the cleaning function has ended
Once the cooking compartment has cooled down, use
a damp cloth to wipe off the ash that has been left
behind in the cooking compartment, in the accessories
on the racks and around the appliance door.
Wipe the pull-out rails with a damp cloth. Then slide the
pull-out rails in and out several times. After cleaning,
some discolouration may remain on the pull-out rails.
This has no effect on performance.
Note: Very bad soiling may cause white deposits to
remain on the enamel surfaces. This is residue from the
food and is harmless. It does not affect performance.
You can remove these residues using lemon juice if
required.
DCleaning
Cl eani ng
With good care and cleaning, your appliance will retain
its appearance and remain fully functioning for a long
time to come. We will explain here how you should
correctly care for and clean your appliance.
Suitable cleaning agents
To ensure that the different surfaces are not damaged
by using the wrong cleaning agent, observe the
information in the table. Depending on the appliance
model, not all of the areas listed may be on/in your
appliance.
Caution!
Risk of surface damage
Do not use:
■ Harsh or abrasive cleaning agents,
■ Cleaning agents with a high alcohol content,
■ Hard scouring pads or cleaning sponges,
■ High-pressure cleaners or steam cleaners,
■ Special cleaners for cleaning the appliance while it is
hot.
Wash new sponge cloths thoroughly before use.
Tip: Highly recommended cleaning and care products
can be purchased through the after-sales service.
Observe the respective manufacturer's instructions.
en Cleaning
20
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
--------
Notes
■ Slight differences in colour on the front of the
appliance are caused by the use of different
materials, such as glass, plastic and metal.
■ Shadows on the door panels, which look like
streaks, are caused by reflections made by the
interior lighting.
Area Cleaning
Appliance exterior
Stainless steel
front
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Remove flecks of limescale, grease, starch and
albumin (e.g. egg white) immediately. Corrosion
can form under such flecks.
Special stainless steel cleaning products suitable
for hot surfaces are available from our after-sales
service or from specialist retailers. Apply a very
thin layer of the cleaning product with a soft cloth.
Plastic Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Painted surfaces Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Control panel Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Door panels Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use a glass scraper or a stainless steel
scouring pad.
Door handle Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If descaler comes into contact with the door han-
dle, wipe it off immediately. Otherwise, any stains
will not be able to be removed.
Appliance interior
Enamelled sur-
faces
Hot soapy water or a vinegar solution:
Clean with a dish cloth and then dry with a soft
cloth.
Soften baked-on food remnants with a damp cloth
and soapy water. Use stainless steel wire wool or
oven cleaner to remove stubborn dirt.
Caution!
Never use oven cleaner in the cooking compart-
ment when it is still warm. This may damage the
enamel. Remove all food remnants from the cook-
ing compartment and the appliance door before
you next heat up the appliance.
Leave the cooking compartment open to dry after
cleaning it.
It is best to use the cleaning function.
~ "Cleaning function" on page 18
Note: Food residues can cause white deposits to
form. These are harmless and do not affect how
the appliance works.
Remove using lemon juice if required.
Glass cover for
the interior light-
ing
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If the cooking compartment is heavily soiled, use
oven cleaner.
Door cover made from stainless steel:
Use stainless steel cleaner. Follow the manufac-
turers' instructions. Do not use stainless steel
care products.
made from plastic:
Clean using hot soapy water and a dish cloth. Dry
with a soft cloth. Do not use glass cleaner or a
glass scraper.
Remove the door cover for cleaning.
Rails Hot soapy water:
Soak and clean with a dish cloth or brush.
Pull-out system Hot soapy water:
Clean with a dish cloth or a brush.
Do not remove the lubricant while the pull-out rails
are pulled out – it is best to clean them when they
are pushed in. Do not clean in the dishwasher.
Accessories Hot soapy water:
Soak and clean with a dish cloth or brush.
If there are heavy deposits of dirt, use a stainless
steel scouring pad.
Meat thermome-
ter
Hot soapy water:
Clean with a dish cloth or a brush.
Do not clean in the dishwasher.
Rails en
21
■ Enamel is baked on at very high temperatures.This
can cause some slight colour variation. This is
normal and does not affect operation.
The edges of thin trays cannot be completely
enamelled. As a result, these edges can be rough.
This does not impair the anti-corrosion protection.
Keeping the appliance clean
Always keep the appliance clean and remove dirt
immediately so that stubborn deposits of dirt do not
build up.
:Warning – Risk of fire!
Loose food remnants, fat and meat juices may catch
fire. Before using the appliance, remove the worst of the
food remnants from the cooking compartment, heating
elements and accessories.
Tips
■ Clean the cooking compartment after each use. This
will ensure that dirt cannot be baked on.
■ Always remove flecks of limescale, grease, starch
and albumin (e.g. egg white) immediately.
■ Use the universal pan for baking very moist cakes.
■ Use suitable ovenware for roasting, e.g. a roasting
dish.
pRails
Ra i l s
With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
shelves and clean them.
Detaching and refitting the rails
:Warning – Risk of burns!
The rails become very hot. Never touch the hot rails.
Always allow the appliance to cool down. Keep children
away from the appliance.
Detaching the rails
1. Lift the rail slightly at the front ‚ and detach it ƒ
(figure !).
2. Then pull the whole rail towards you and take it out
(figure ").
Clean the rails with cleaning agent and a sponge. For
stubborn deposits of dirt, use a brush.
21
D
E
en Appliance door
22
Attaching the rails
The rails only fit on the right or the left side. For both
rails, ensure that the curved rods are at the front.
1. First, insert the rail in the middle of the rear socket ‚,
until the rail rests against the cooking compartment
wall, and push it back ƒ (figure !).
2. Then insert the rail into the front socket „, until the
rail also rests against the cooking compartment wall
here, and press it downwards … (figure ").
qAppliance door
Ap p l i a n c e door
With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
appliance door and clean it.
Removing and fitting the appliance door
For cleaning purposes and to remove the door panels,
you can detach the appliance door.
The appliance door hinges each have a locking lever.
When the locking levers are closed (figure !), the
appliance door is secured in place. It cannot be
detached.
When the locking levers are open in order to detach the
appliance door (figure "), the hinges are locked. They
cannot snap shut.
:Warning
Risk of injury!
■ If the hinges are not locked, they can snap shut with
great force. Ensure that the locking levers are always
fully closed or, when detaching the appliance door,
fully open.
Risk of injury!
■ The hinges on the appliance door move when
opening and closing the door, and you may be
trapped. Keep your hands away from the hinges.
Removing the appliance door
1. Open the appliance door fully and push it in the
direction of the appliance.
2. Fold up the two locking levers on the left and right
(figure !).
3. Close the appliance door as far as it goes ‚. With
both hands, grip the door on the left- and right-hand
side and pull it up and out (figure ").
2
F
G
1
D
E
21
2
E
E
D
1I
Appliance door en
23
Fitting the appliance door
Reattach the appliance door in the opposite sequence
to removal.
1. When attaching the appliance door, ensure that both
hinges are inserted straight into the opening (figure
!).
Place both hinges at the bottom on the outer panel
and use this as a guide.
Ensure that the hinges are inserted into the correct
opening. You must be able to insert them easily and
without resistance. If you can feel any resistance,
check that the hinges are inserted into the correct
opening.
2. Open the appliance door fully. Fold both locking
levers closed again (figure ").
3. Close the cooking compartment door.
Removing the door cover
The stainless steel inlay in the door cover may become
discoloured. To carry out thorough cleaning, you can
remove the cover. ~ "Cleaning" on page 19
1. Open the appliance door slightly.
2. Press on the right and left side of the cover (figure
!).
3. Remove the cover (figure ").
Close the appliance door carefully.
Note: Clean the stainless steel inlay in the cover with
stainless steel cleaner. Clean the rest of the door
cover with soapy water and a soft cloth.
4. Open the appliance door again slightly. Put the
cover back in place and press on it until it clicks
audibly into place (figure #).
5. Close the appliance door.
Removing and installing the door panels
To facilitate cleaning, you can remove the glass panels
from the appliance door.
Removing the door from the appliance
1. Open the appliance door slightly.
2. Press on the right and left side of the cover (figure
!).
3. Remove the cover (figure ").
4. Loosen and remove the screws on the left and right
of the appliance door (figure #).
5. Before closing the door again, trap a tea towel which
has been folded several times in the door (figure $).
Pull out the front panel upwards and lay it on a flat
surface with the door handle facing downwards.
1
2I
2
1
21
en Appliance door
24
6. Push both retainers on the intermediate panel
upwards, but do not remove it (figure %). Hold the
panel with one hand. Remove the panel.
Clean the panels with glass cleaner and a soft cloth.
:Warning
Risk of injury!
■ Scratched glass in the appliance door may develop
into a crack. Do not use a glass scraper, sharp or
abrasive cleaning aids or detergents.
Risk of injury!
■ The hinges on the appliance door move when
opening and closing the door, and you may be
trapped. Keep your hands away from the hinges.
Fitting the door on the appliance
When fitting the intermediate panel, make sure that the
arrow is in the top right of the panel and that it aligns
with the arrow on the metal panel.
1. Insert the intermediate panel at the bottom into the
retainer and push it in firmly at the top (figure !).
2. Push both retainers downwards (figure ").
3. Insert the front panel at the bottom into the retainers
(figure #).
4. Close the front panel until both upper hooks are
opposite the opening (figure $).
5. Press the front panel at the bottom until it clicks
audibly into place (figure %).
6. Open the appliance door again slightly and remove
the tea towel.
7. Screw both screws back in on the left and right.
8. Put the cover back in place and press on it until it
clicks audibly into place (figure &).
9. Close the appliance door.
Caution!
Do not use the cooking compartment again until the
panels have been correctly fitted.
2
1
Trouble shooting en
25
3Trouble shooting
Tr oubl e s hoot i ng
If a fault occurs, there is often a simple explanation.
Before calling the after-sales service, please refer to the
fault table and attempt to correct the fault yourself.
Note: If a dish does not turn out as well as you had
hoped, refer to the table section at the end of the
instruction manual, where you will find plenty of tips and
information. ~ "Tested for you in our cooking studio"
on page 28
:Warning – Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be
carried out and damaged power cables replaced by
one of our trained after-sales technicians. If the
appliance is defective, unplug the appliance from the
mains or switch off the circuit breaker in the fuse box.
Contact the after-sales service.
:Warning – Risk of injury!
Incorrect repairs are dangerous. Do not attempt to
repair the appliance yourself. Repairs must only be
carried out by one of our trained after-sales engineers. If
the appliance is defective, call the after-sales service.
Fault table
If an error message beginning with 'E' is shown, e.g.
E0111, switch the appliance off and then on again. If
this message appears again, contact the after-sales
service.
--------
Maximum operating time exceeded
Your appliance automatically ends the operation if no
duration has been set and the setting has not been
changed for a long time.
The point at which this occurs depends on the
temperature or grill setting that has been set.
A message appears on the display on the appliance to
say that the operation is being ended automatically. The
operation is then cancelled.
To use the appliance again, first switch it off. To switch
the appliance back on again set the required operation.
Tip: Set a cooking time so that the appliance does not
switch off when you do not want it to, e.g. with an
extremely long preparation time. The appliance heats
up until the set cooking time has elapsed.
Fault Possible cause Information/remedial action
The appliance does not work The fuse is faulty Check in the fuse box to make sure that the fuse for
the appliance is in working order
Power cut Check whether other kitchen appliances are working
The appliance door will not open; the
5 symbol is shown in the display
The appliance door is locked until the cooking com-
partment has cooled down.
Wait until the 5 symbol goes out
Although the appliance is switched
on, it cannot be operated; the 1
symbol is shown in the display
The child lock is activated
Press and hold the 1 button until the 1 symbol
goes out
The cooking compartment does not
heat and "Demo mode on" is shown in
the display
The appliance is in demo mode Switch off the fuse in the fuse box and switch it back
on again after approx. 10 seconds. Switch on the
appliance and select "Demo mode off" in the settings.
The appliance will not start and
"Cooking compartment too hot"
appears on the display
The cooking compartment is too hot for the selected
dish or type of heating
Allow the cooking compartment to cool down and
start again
en Customer service
26
Replacing the bulb in the top of the cooking
compartment
If the cooking compartment light bulb fails, it must be
replaced. Heat-resistant, 40 watt, 230 V halogen bulbs
are available from the after-sales service or specialist
retailers.
When handling the halogen bulb, use a dry cloth. This
will increase the service life of the bulb. Only use these
bulbs.
:Warning – Risk of electric shock!
When replacing the cooking compartment bulb, the
bulb socket contacts are live. Before replacing the bulb,
unplug the appliance from the mains or switch off the
circuit breaker in the fuse box.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
1. Place a tea towel in the cold cooking compartment
to prevent damage.
2. Turn the glass cover anti-clockwise to remove it
(figure !).
3. Pull out the bulb – do not turn it (figure ").
Insert the new bulb, making sure that the pins are in
the correct position. Push the bulb in firmly.
4. Screw the glass cover back on.
Depending on the appliance model, the glass cover
may have a sealing ring. If the glass cover has a
sealing ring, put it back in place before screwing the
cover back on.
5. Remove the tea towel and switch on the circuit
breaker.
Glass cover
If the glass cover of the halogen bulb is damaged, it
must be replaced. You can obtain a new glass cover
from the after-sales service. Please specify the E
number and FD number of your appliance.
4Customer service
Cu s t o mer ser vi ce
Our after-sales service is there for you if your appliance
needs to be repaired. We will always find an
appropriate solution, also in order to avoid after-sales
personnel having to make unnecessary visits.
E number and FD number
When calling us, please quote the full product number
(E no.) and the production number (FD no.) so that we
can provide you with the correct advice. The rating plate
bearing these numbers can be found when you open
the appliance door.
On some appliances with a steam-assisted cooking
function, you will find the rating plate behind the control
panel.
To save time, you can make a note of the numbers for
your appliance and the telephone number of the after-
sales service in the space below in case you need
them.
Please note that a visit from an after-sales service
engineer is not free of charge in the event that the
appliance has been misused, even during the warranty
period.
Please find the contact data of all countries in the
enclosed customer service list.
To book an engineer visit and product advice
Rely on the professionalism of the manufacturer. You
can therefore be sure that the repair is carried out by
trained service technicians who carry original spare
parts for your appliances.
2
1
E no.
FD no.
After-sales service O
GB 0344 892 8999
Calls charged at local or mobile rate.
IE 01450 2655
0.03 € per minute at peak. Off peak 0.0088 €
per minute.
=1U)'(1U
7\SH
Dishes en
27
PDishes
Di shes
You can use the "Dishes" operating mode to prepare a
wide variety of food. The appliance selects most
settings for you.
To achieve good results, the cooking compartment
must not be too hot for the type of food you have
selected. If it is, a message will appear on the display.
Allow the cooking compartment to cool down and start
again.
Information on the setting
■ The cooking result depends on the quality of the
food and the type of cookware. For an optimal
cooking result, use food that is in good condition
and chilled meat only.
■ The appliance chooses the optimal heating mode
and the time and temperature setting for you. You
will only be asked to enter the weight. It is not
possible to set weights outside of the intended
weight range.
■ When roasting dishes for which the appliance will
apply the temperature selection for you,
temperatures of up to 300 °C can be saved.
Therefore, make sure that you use cookware that is
sufficiently heat resistant.
■ Information is provided, e.g. on cookware, shelf
position or the addition of liquid when cooking meat.
Some food requires turning or stirring, etc., during
cooking. This is shown on the display shortly after
operation starts. An audible signal will remind you at
the right time.
■ Information on the right kind of cookware to use and
tips and tricks for the preparation can be found at
the end of the instruction manual.
Selecting a dish
The dishes are arranged in a uniform structure:
■ Category
■ Food
■ Dish
The following table lists the categories with the
corresponding food. One or more dishes are listed
beside each food.
Applying settings for dishes
You will be guided through the entire setting process for
your chosen food. Always touch the ¿ arrow.
1. Press the menu button.
2. Use the rotary selector to select "Dishes".
3. Touch the ¿ arrow.
The first dish will appear, along with a default value
for the weight.
4. Use the rotary selector to select the food you
require.
5. Touch the ¿ arrow.
6. Turn the rotary selector to set the weight.
7. Touch the ¿ arrow.
Note: Information will be displayed on the best shelf
position, cookware, etc. to use.
8. Press the Start/Stop button to start.
You will be guided through the entire setting process for
your chosen food. Always touch the ¿ arrow.
The setting has ended
A signal sounds. The oven stops heating. You can
cancel the audible signal early using the 0 button.
If you are not satisfied with the cooking result, you can
increase the cooking time again. Touch the "Extend
cooking time" field. A cooking time is suggested. You
can change this if you wish.
If you are satisfied with the cooking result, touch
"Finish". "Enjoy your meal" appears in the display.
Cancelling the setting
Press the On/Off button. All settings are deleted. You
can implement new settings.
Setting a later end time
For some dishes, it is possible to set a later end time.
You can find out how to set a later end time by looking
in the time-setting options. ~ "Time-setting options"
on page 14
Once you have set an end time, the display shows the
waiting time. The status bar shows the time at which
operation is to end. None of the settings can be
changed. Please remember that easily spoiled foods
must not be allowed to remain in the cooking
compartment for too long.
Dishes
Chicken, unstuffed
Turkey breast
Roasting joint
Belly
Slow roasting joint
Top side, top rump
Leg of lamb, boned, medium
Meat loaf made from fresh minced meat
Goulash
Vegetable stew
en Tested for you in our cooking studio
28
JTested for you in our
cooking studio
Tes t ed for you in our c ooki ng st udi o
Here, you can find a selection of dishes and the ideal
settings for them. We will show you which type of
heating and temperature are best suited to your dish.
You will get information on suitable cooking
accessories and the height at which they should be
placed in the oven. You will also get tips about
cookware and preparation methods.
Note: A lot of steam can build up in the cooking
compartment when cooking food.
Your appliance is very energy-efficient and radiates very
little heat to its surroundings during operation. Due to
the high difference in temperature between the
appliance interior and the external parts of the
appliance, condensation may build up on the door,
control panel or adjacent kitchen cabinet panels. This is
a normal physical phenomenon. Condensation can be
reduced by preheating the oven or opening the door
carefully.
Silicone moulds
For the best cooking results, we recommend dark-
coloured metal baking tins/dishes.
Nevertheless, if you wish to use silicone moulds, follow
the manufacturer's instructions and recipes. Silicone
moulds are often smaller than normal baking tins.
Quantity and recipe specifications may vary.
Baking
Here, you can find recommended settings for many
dishes.
Also refer to the notes in the section on allowing dough
to rise.
Only use original accessories supplied with your
appliance. These have been tailored to the cooking
compartment and the operating modes of your
appliance.
Shelf positions
Use the indicated shelf positions.
Baking on one level
When baking on one level, use the following shelf
positions:
■ Tall baked items: Level 2
■ Flat baked items: Level 3
If you are using 4D Hot air as the type of heating, you
can choose between levels 1, 2, 3 and 4.
You can also prepare soufflés in a water bath in the
universal pan. To do so, slide the universal pan in at
level 2.
Baking on two levels
Use 4D hot air. Baked items that are placed into the
oven on trays or in baking tins/dishes at the same time
will not necessarily be ready at the same time.
■ Universal pan: Level 3
Baking tray: Level 1
■ Baking tins/dishes on the wire rack
First wire rack: Level 3
Second wire rack: Level 1
By preparing several dishes at the same time, you can
make energy savings of up to 45 per cent. Position
baking tins/dishes next to one another or offset and
vertically stacked in the cooking compartment.
Accessories
Ensure that you always use suitable accessories and
that they are placed in the oven the right way around.
Wire rack
Insert the wire rack with the open side facing the
appliance door and the curved lip pointing downwards.
Always place ovenware, tins and dishes on the wire
rack.
Universal pan or baking tray
Slide the universal pan or the baking tray in carefully as
far as the limit stop with the bevelled edge facing the
appliance door.
When baking moist cakes or pastries with many
toppings, use the universal pan so that any excess
liquid does not overflow and make the cooking
compartment dirty.
Baking tins
Dark- coloured metal baking tins are most suitable.
Tinplate baking tins, ceramic dishes and glass dishes
extend baking time and mean that the baked item will
not brown evenly. If you wish to bake using these
baking tins/dishes and using top/bottom heating, slide
in the tin/dish at level 1.
Greaseproof paper
Only use greaseproof paper that is suitable for the
selected temperature. Always cut greaseproof paper to
size.
Recommended setting values
The table lists the optimal heating type for various
baked items. The temperature and baking time depend
on the amount and consistency of the dough/mixture.
For this reason, the table specifies setting ranges. Try
using the lower values to start with. A lower temperature
will result in more even browning. You can use a higher
setting next time if necessary.
Note: Baking times cannot be reduced by using higher
temperatures. Cakes or small baked items would only
be cooked on the outside, and would not be fully baked
in the middle.
The setting values apply to food that is placed into a
cold cooking compartment; by doing this, you can
make energy savings of up to 20 per cent.If you preheat
the oven, you can reduce the indicated baking times by
several minutes.
Preheating is necessary for selected food, and this is
indicated in the table. Do not place your food or
accessories into the cooking compartment until it has
finished preheating.
Tested for you in our cooking studio en
29
If you wish to follow one of your own recipes when
baking, you should use the setting values listed for
similar baked items in the table as reference.Additional
information can be found in the baking tips listed after
the settings table.
Remove unused accessories from the cooking
compartment. This will ensure that you achieve the best
possible cooking results and energy savings of up to
20 per cent.
Types of heating used:
■ : 4D hot air
■ % Top/bottom heating
■ ; Pizza setting
Dish Accessories/cookware Shelf po-
sition
Type of
heating
Tempera-
ture in °C
Cooking
time in mins.
One level baking
Victoria sponge cake 2x Ø20 cm tins 2
:
160-170* 25-30
Light fruit cake high Ø20 cm tin 2
:
140-160 70-90
Rich fruit cake high Ø23 cm tin 2
:
130-150 150-180
Fruit crumble flat glass dish 3
:
150-170* 35-45
Sponge Cake (fatless), 3 eggs springform cake tin Ø26 cm 2
:
160-170* 25-35
Sponge flan, 6 eggs springform cake tin Ø28 cm 2
:
150-170* 30-50
Swiss roll swiss roll tin 3
:
180-190* 10-15
Fruit Pie plate Ø20 cm or pie tin 2
;
160-170 55-65
Quiche quiche tin (dark coated) 3
;
190-210 30-40
(White) Bread loaf tin (1x 900 g or 2x 450 g) 2
:
180-200* 20-30
Scones baking tray 3
:
180-200* 10-14
Biscuits baking tray 3
:
140-160* 10-25
Small Cakes 12-cup-tin 3
:
140-160* 20-30
Puff pastry slices baking tray 3
:
170-190* 20-35
Jam tarts 12-cup-tin 3
:
170-190* 15-30
Meringue baking tray 3
:
80-90* 120-150
Pavlova baking tray 3
:
90-100* 120-180
Soufflé 1,2L-soufflé dish 2
:
160-170* 35-45
Soufflé individual moulds 2
%
170-190 65-75
Choux pastry baking tray 3
:
190-210* 30-40
Meat Pie rectangular pie tin 2
:
180-190 40-50
Yorkshire pudding 12-cup-tin 3
:
200-220* 15-25
Jacket potatoes baking tray 3
:
150-170 75-90
Pizza, homemade baking tray 3
;
200-220 25-35
Pizza, homemade, thin base pizza tray 2
%
250-270 20-25
Pizza, homemade, thin base pizza tray 2
;
210-220 25-30
Multishelf baking
Victoria Sponge Cake, 2 levels 4x Ø20 cm tins 3+1
:
160-170* 25-35
Scones, 2 levels 2 baking trays 3+1
:
170-190* 12-16
Biscuits, 2 levels 2 baking trays 3+1
:
140-160* 10-25
Biscuits, 3 levels 3 baking trays 5+3+1
:
140-160* 15-30
Small cakes, 2 levels 2x 12-cup-tins 3+1
:
140-160* 22-32
Puff pastry slices, 2 levels 2 baking trays 3+1
:
170-190* 25-45
Puff pastry slices, 3 levels 3 baking trays 5+3+1
:
170-190* 25-45
Jam tarts, 2 levels 2x 12-cup-tins 3+1
:
170-190* 20-35
Meringues, 2 levels 2 baking trays 3+1
:
80-90* 120-150
* Preheat
en Tested for you in our cooking studio
30
Tips on baking
Roasting and braising
Here, you can find information on roasting and braising
poultry and meat. You can find the ideal settings for
many dishes in the settings tables.
Poultry
For duck or goose, pierce the skin on the underside of
the wings. This allows the fat to run out.
If using duck breast, score the skin. Do not turn duck
breasts.
When you turn poultry, ensure that the breast side or
the skin side is underneath at first.
Poultry will turn out particularly crispy and brown if you
baste it towards the end of the roasting time with butter,
salted water or orange juice.
Meat
Baste lean meat with fat as required or cover it with
strips of bacon.
Score the rind crosswise. If you turn the joint when
cooking, ensure that the rind is underneath at first.
When the joint is ready, turn off the oven and allow it to
rest for another 10 minutes in the cooking
compartment. This allows the meat juices to be better
distributed. Wrap the joint in aluminium foil if necessary.
The recommended resting time is not included in the
cooking time indicated.
Jacket potatoes, 2 levels universal pan + baking tray 3+1
:
150-170* 75-90
(White) Bread, 2 levels 4x loaf tins 3+1
:
170-190* 30-40
Pizza, homemade, 2 levels universal pan + baking tray 3+1
:
180-200 35-45
Dish Accessories/cookware Shelf po-
sition
Type of
heating
Tempera-
ture in °C
Cooking
time in mins.
* Preheat
You want to find out whether the cake
is completely cooked in the middle.
Push a cocktail stick into the highest point on the cake. If the cocktail stick comes out clean with no dough res-
idue, the cake is ready.
The cake collapses. Next time, use less liquid. Alternatively, set the temperature to be 10 °C lower and extend the baking time.
Adhere to the specified ingredients and preparation instructions in the recipe.
The cake has risen in the middle but
is lower around the edge.
Only grease the base of the springform cake tin. After baking, loosen the cake carefully with a knife.
The fruit juice overflows. Next time, use the universal pan.
Small baked items stick to one
another during baking.
There should be a gap of approx. 2 cm around each item. This gives enough space for the baked items to
expand well and brown on all sides.
The cake is too dry. Set the temperature 10 °C higher and shorten the baking time.
The cake is generally too light in col-
our.
If the shelf position and the cookware are correct, then you should increase the temperature if necessary or
extend the baking time.
The cake is too light on top, and too
dark underneath.
Bake the cake one level higher in the oven the next time.
The cake is too dark on top, and too
light underneath.
Bake the cake one level lower in the oven the next time. Select a lower temperature and extend the baking
time.
Cakes baked in a tray or tin are too
brown at the back.
Place the baking tray in the middle of the accessories, not directly against the back wall.
The whole cake is too dark. Select a lower temperature next time and extend the baking time if necessary.
The cake is unevenly browned. Select a slightly lower temperature.
Protruding greaseproof paper can affect the air circulation. Always cut greaseproof paper to size.
Ensure that the baking tin does not stand directly in front of the openings in the cooking compartment back
wall.
When baking small items, you should use similar sizes and thicknesses wherever possible.
You were baking on several levels.
The items on the top baking tray are
darker than those on the lower baking
tray.
Always select 4D hot air when baking on several levels. Baked items that are placed into the oven on trays or
in baking tins/dishes at the same time will not necessarily be ready at the same time.
The cake looks good, but is not
cooked properly in the middle.
Use a lower temperature and bake slightly longer; if necessary, add slightly less liquid. For cakes with a moist
topping, bake the base first. Sprinkle it with almonds or breadcrumbs and then place the topping on top.
The cake cannot be turned out of the
dish when it is turned upside down.
Allow the cake to cool down for 5 to 10 minutes after baking. If it still sticks, carefully loosen the cake around
the edges again using a knife. Turn the cake tin upside down again and cover it several times with a cold, wet
cloth. Next time, grease the baking tin/dish and sprinkle with breadcrumbs.
Tested for you in our cooking studio en
31
Roasting on the wire rack
On the wire rack, poultry and meat will become very
crispy on all sides. Roasting on the wire rack is well
suited for larger poultry or for multiple pieces at the
same time.
Depending on the size and type of the meat, add up to
^ litres of water to the universal pan. Any dripping fat
and meat juices will be caught. You can prepare a
sauce using these meat juices. In addition, less smoke
is generated, and the cooking compartment stays
cleaner.
Slide the universal pan into the oven at the indicated
shelf position with the wire rack attached. Ensure that
the wire rack is correctly positioned on the universal
pan. ~ "Accessories" on page 10
Roasting and braising in cookware
It is more convenient to roast and braise meat in
cookware. You can take the joint out of the cooking
compartment more easily in the cookware, and prepare
the sauce in the cookware itself.
Only use cookware which is suitable for use in an oven.
Check whether the cookware fits in the cooking
compartment.
Glass cookware is most suitable. Place hot glass
cookware onto a dry mat after cooking. If the surface is
damp or cold, the glass may crack.
Add in a little liquid for roasting if the meat is lean. A
covering of approx. ^ cm depth should be applied to
the base of any glass cookware.
The amount of liquid is dependent on the type of meat,
the cookware material and also on whether or not a lid
is used. If preparing meat in an enamelled or dark metal
roasting dish, it will need a little more liquid than if
cooked in glass cookware.
The steam evaporates in the cookware when roasting.
Carefully pour in more liquid if required.
Shiny roasting dishes made from stainless steel or
aluminium reflect heat like a mirror and are therefore
not particularly suitable. The meat cooks more slowly
and will not brown so much. Use a higher temperature
and/or a longer cooking time.
Observe the manufacturer's instructions for your
roasting cookware.
Roasting in uncovered cookware
It is best to use a deep roasting tin/dish for roasting
poultry and meat. Place the tin/dish onto the wire rack.
If you do not have any suitable cookware, use the
universal pan.
Braising in covered cookware
When preparing food with covered cookware, the
cooking compartment remains considerably cleaner.
Ensure that the lid fits well and closes properly. Place
the cookware onto the wire rack.
The distance between the meat and the lid must be at
least 3 cm. The meat may rise.
Very hot steam may escape when opening the lid after
cooking. Lift the lid at the rear, so that the hot steam
can escape away from you.
If necessary, braise the meat first by searing it. Add
water, wine, vinegar or a similar liquid to the braising
liquid. A covering at least 2 cm deep should be applied
to the base of the cookware.
The steam evaporates in the cookware when roasting.
Carefully pour in more liquid if required.
Meat thermometer
You can cook accurately using a meat thermometer.
Read important notes on using the meat thermometer in
the corresponding chapter. There, you can find notes
on inserting the meat thermometer, the possible heating
types and additional information. ~ "Meat
thermometer" on page 17
Recommended setting values
In the table, you can find the ideal heating type for
poultry and meat. Temperature and cooking time
depend on the quantity, composition and temperature
of the food. Different settings ranges are indicated for
this reason. Try using the lower values at first. You can
increase the temperature next time if necessary.
The setting values are based on the assumption that
unstuffed, chilled, ready-to-roast poultry and meat are
placed into a cold cooking compartment. By doing so,
you can make energy savings of up to 20 per cent. If
you preheat the oven, the indicated cooking times will
be reduced by several minutes.
In the table, you can find specifications for poultry and
meat with default values for the weight. If you wish to
prepare heavier poultry or meat, use the lower
temperature in every case. If roasting several joints, use
the weight of the heaviest piece as a basis for
determining the cooking time. The individual pieces
should be approximately equal in size.
A general rule: the larger the poultry or piece of meat is,
the lower the cooking temperature and the longer the
cooking time.
Turn the poultry and meat after approx. ^ to Z of the
indicated time.
Remove unused accessories from the cooking
compartment. This will achieve the best possible
cooking results and energy savings of up to 20 per
cent.
Cooking time calculation (e. g. 20+35):
Please calculate the cooking time with 20 minutes per
500 g meat + 35 minutes additional time. For 1,5 kg
the calculated cooking time would be 95 minutes.
Cooking time range (e. g. 10-15):
The food is done within the stated minutes.
en Tested for you in our cooking studio
32
Type of heating used:
■ : 4D hot air
Dish Accessories/cookware Shelf po-
sition
Type of
heating
Temperature in
°C
Time in min.
Beef
Slow roasting joint wire rack 2
:
140-150 35+40
Top side / Top rump wire rack 2
:
160-170 30+25
Lamb
Leg (bone-in) wire rack 2
:
160-170 25+25
Shoulder (bone-in) wire rack 2
:
160-170 25+20
Shoulder (boned and rolled) wire rack 2
:
170-180 25+25
Rack of lamb** wire rack 2
:
180-190* 15+25
Pork
Roasting joint wire rack 2
:
180-190 30+35
Loin joint wire rack 2
:
180-190 35+35
Belly wire rack 2
:
170-180 30+25
Gammon joint wire rack 2
:
160-170 30+30
Poultry
Chicken, whole wire rack 2
:
170-180 25+15
Chicken, portion (each 200-250 g)*** wire rack 2
:
190-200 35-45
Duck wire rack 2
:
180-190 25+20
Turkey, crown**** wire rack 2
:
150-160 20+15
Turkey, thighs wire rack 2
:
170-180 25+30
Turkey, whole, 4-8 kg***** wire rack 2
:
150-160 12+12
Meat dishes
Meat loaf cookware, uncovered 2
:
170-180 20+35
Casserole
Diced meat (beef, pork, lamb), 500 g
meat
cookware, covered 2
:
140* 100-120
Diced chicken (boned), 500 g meat cookware, covered 2
:
140* 90-100
Braising steak cookware, covered 2
:
140 65+60
Complete meal
With beef wire rack + wire rack 4+1
:
160, then 200
(Yorkshire Pud-
ding)
calculation for meat
(see table above) + 15-
25 for Yorkshire Pud-
ding
With chicken wire rack + wire rack 4+1
:
180 calculation for chicken
(see table above)
* Preheat
** Without fat layer (best and neck), do not turn
*** Skin side down
**** Bone side down, do not turn
***** Turn after app. 1 hour
Tested for you in our cooking studio en
33
Tips on roasting and braising
Grilling
Here, you can find information on grilling poultry, meat
and fish, as well as toast. You can find the ideal settings
for certain dishes in the settings tables.
Grilling with circulated air
Circulated air grilling is very well suited to the
preparation of whole poultry, fish, and also meat, e.g.
roast pork with crackling.
Poultry
For duck or goose, pierce the skin on the underside of
the wings. This allows the fat to run out.
If using duck breast, score the skin. Do not turn duck
breasts.
When you turn poultry, ensure that the breast side or
the skin side is underneath at first.
Poultry will turn out particularly crispy and brown if you
baste it towards the end of the roasting time with butter,
salted water or orange juice.
Meat
Baste lean meat with fat as required or cover it with
strips of bacon.
Score the rind crosswise. If you turn the joint when
cooking, ensure that the rind is underneath at first.
When the joint is ready, turn off the oven and allow it to
rest for another 10 minutes in the cooking
compartment. This allows the meat juices to be better
distributed. Wrap the joint in aluminium foil if necessary.
The recommended resting time is not included in the
cooking time indicated.
Fish
Fish cooked whole does not have to be turned. Place
the whole fish into the cooking compartment in
swimming position with the dorsal fin facing upwards.
Placing half a potato or a small oven-proof container in
the stomach cavity of the fish will provide stability.
You can tell when the fish is cooked because the dorsal
fin can be removed easily.
Roasting on the wire rack
On the wire rack, poultry and meat will become very
crispy on all sides. Roasting on the wire rack is well
suited for larger poultry or for multiple pieces at the
same time.
Depending on the size and type of the meat, add up to
^ litres of water to the universal pan. Any dripping fat
and meat juices will be caught. You can prepare a
sauce using these meat juices. In addition, less smoke
is generated, and the cooking compartment stays
cleaner.
Slide the universal pan into the oven at the indicated
shelf position with the wire rack attached. Ensure that
the wire rack is correctly positioned on the universal
pan. ~ "Accessories" on page 10
Roasting in cookware
It is more convenient to roast and braise meat in
cookware. You can take the joint out of the cooking
compartment more easily in the cookware, and prepare
the sauce in the cookware itself.
Only use cookware which is suitable for use in an oven.
Check whether the cookware fits in the cooking
compartment.
Glass cookware is most suitable. Place hot glass
cookware onto a dry mat after cooking. If the surface is
damp or cold, the glass may crack.
Add in a little liquid if the meat is lean. A covering of
approx. ^ cm depth should be applied to the base of
any glass cookware.
The quantity of liquid is dependent on the type of meat,
the cookware material and also on whether or not a lid
is used. If preparing poultry, meat or fish in an
enamelled or dark metal roasting dish, it will need a
little more liquid than if cooked in glass cookware.
The steam evaporates in the cookware when roasting.
Carefully pour in more liquid if required.
Shiny roasting dishes made from stainless steel or
aluminium reflect heat like a mirror and are therefore
not particularly suitable. The meat cooks more slowly
and will not brown so much. Use a higher temperature
and/or a longer cooking time.
Observe the manufacturer's instructions for your
roasting cookware.
Uncovered cookware
Use a deep roasting tin/dish for roasting meat. Place
the tin/dish onto the wire rack. If you do not have any
suitable cookware, use the universal pan.
The cooking compartment becomes
very dirty.
Prepare your food in an enclosed roasting dish with higher temperature or use the grill tray. You will achieve
the best roasting results if you use the grill tray. The grill tray can be bought later as a special accessory.
The roast is too dark and the crack-
ling is burned in places, and/or the
roast is too dry.
Check the shelf position and temperature. Select a lower temperature the next time and reduce the roasting
time if necessary.
The crackling is too thin. Increase the temperature or switch on the grill briefly at the end of the roasting time.
The roast looks good but the juices
are burnt.
Next time, use a smaller roasting dish and add more liquid if necessary.
The roast looks good but the juices
are too clear and watery.
Next time, use a larger roasting dish and add less liquid if necessary.
The meat gets burned during brais-
ing.
The roasting dish and lid must fit together well and close properly.
Reduce the temperature and add more liquid when braising if necessary.
en Tested for you in our cooking studio
34
Covered cookware
When cooking with covered cookware, the cooking
compartment remains considerably cleaner. Ensure that
the lid fits well and closes properly. Place the cookware
onto the wire rack.
The distance between the meat and the lid must be at
least 3 cm. The meat may rise.
Very hot steam may escape when opening the lid after
cooking. Lift the lid at the rear, so that the hot steam
can escape away from you.
If necessary, braise the meat first by searing it. Add
water, wine, vinegar or a similar liquid to the braising
liquid. A covering approx. 1-2 cm deep should be
applied to the base of the cookware.
The steam evaporates in the cookware when roasting.
Carefully pour in more liquid if required.
Meat can also become crispy in a covered roasting
dish. To do so, use a roasting dish with a glass lid and
set a higher temperature.
Grilling flat pieces
Flat pieces of poultry, meat and fish, such as steaks,
drumsticks and burgers, can be prepared well using the
"Grill" heating type. Excellent results are also achieved
when grilling toast.
Grilling
Keep the appliance door closed when using the grill.
Never grill with the appliance door open.
Place the food to be grilled on the wire rack. In addition,
slide the universal pan in at least one shelf position
lower, with the slanted edge facing the appliance door.
Any dripping fat will be caught.
When grilling, try wherever possible to use pieces of
food which are of a similar thickness and weight. This
will allow them to brown evenly and remain succulent
and juicy. Place the food to be grilled directly onto the
wire rack.
Use tongs to turn the pieces of food you are grilling. If
you pierce the meat with a fork, the juices will run out
and it will become dry.
Do not add salt until after the meat has been grilled.
Salt draws water from the meat.
Notes
■ The grill element switches itself continuously on and
off; this is normal. The grill setting determines how
frequently this occurs.
■ Smoke may be produced when grilling.
Meat thermometer
You can cook accurately using a meat thermometer.
Read important notes on using the meat thermometer in
the corresponding chapter. There, you can find notes
on inserting the meat thermometer, the possible heating
types and additional information. ~ "Meat
thermometer" on page 17
Recommended setting values
In the table, you can find the ideal heating type for your
poultry, meat and fish, in addition to toast. Temperature
and cooking time depend on the quantity, composition
and temperature of the food. Settings ranges are
indicated for this reason. Try using the lower values at
first. You can use a higher setting next time if
necessary.
The setting values are based on the assumption that
unstuffed, chilled, ready-to-roast poultry, meat and fish
are placed into a cold cooking compartment.
In the table, you can find specifications for poultry, meat
and fish with default values for the weight. If you wish to
prepare heavier poultry, meat or fish, use the lower
temperature in every case. If roasting several joints, use
the weight of the heaviest piece as a basis for
determining the cooking time. The individual pieces
should be approximately equal in size.
A general rule: the larger the poultry, meat or fish is, the
lower the cooking temperature and the longer the
cooking time.
Turn the poultry, meat and fish after approx.^ to Z of
the indicated time.
Remove unused accessories from the cooking
compartment. This will achieve the best possible
cooking results and energy savings of up to 20 per
cent.
Cooking time calculation (e. g. 20+35):
Please calculate the cooking time with 20 minutes per
500 g meat + 35 minutes additional time. For 1,5 kg
the calculated cooking time would be 95 minutes.
Cooking time range (e. g. 10-15):
The food is done within the stated minutes.
Tested for you in our cooking studio en
35
Types of heating used:
■ 4 Circulated air grilling
■ ( Grill, large area
Dish Accessories Shelf po-
sition
Type of
heating
Temperature in C /
Grill setting
Time in min.
Beef
Steaks, height 2-3 cm** wire rack 3
(
3 1st side 10-12
2nd side 3-5
Burger, height 1-2 cm wire rack 3
(
3* 1st side 6-8
2nd side 4-6
Top side / Top rump wire rack 2
4
150-160 30+30
Lamb
Steaks, height 2-3 cm wire rack 3
(
3* 1st side 8-10
2nd side 4-6
Chops, height 2-3 cm wire rack 3
(
3 1st side 6-8
2nd side 6-8
Leg (bone-in) wire rack 2
4
170-180 25+30
Shoulder (bone-in) wire rack 2
4
170-190 25+15
Shoulder (boned and rolled) wire rack 2
4
170-180 20+15
Rack of lamb wire rack 2
4
190-200 15+25
Pork
Steaks, height 2 cm wire rack 5
(
2 1st side 10-12
2nd side 5-7
Chops, height 2-3 cm wire rack 3
(
3* 1st side 10-12
2nd side 9-10
Burger, height 1-2 cm wire rack 3
(
3*** 1st side 6-8
2nd side 4-6
Bacon rashers wire rack 3
(
3***** 1st side 4-5
2nd side 3-4
Sausages, thickness 2 4 cm wire rack 3
(
3**** 10-15
Roasting joint wire rack 2
4
180-200 30+40
Loin joint wire rack 2
4
180-200 35+35
Belly wire rack 2
4
200-220 30+25
Gammon joint wire rack 2
4
180-200 30+25
Poultry
Chicken drumstick, 150 g each wire rack 3
4
210-230 20-30
Chicken breast, boned, 150 g each wire rack 3
(
3*** 1st side 10-15
2nd side 10-15
Chicken, whole wire rack 2
4
200-220 20+15
Chicken, portion, bone-in 200 -250 g
each******
wire rack 3
4
200-220 30-45
Duck, 2-3 kg wire rack 2
4
190-200 20+20
* Preheat
** Do not preheat
*** Preheat 3 minutes
**** Preheat 3 minutes, turn over several times
***** Preheat 5 minutes
****** Skin side down
en Tested for you in our cooking studio
36
Convenience products
Here, you can find the ideal settings for preparing
chilled and frozen food.
Only use original accessories supplied with your
appliance. These have been tailored to the cooking
compartment and the operating modes of your
appliance.
Tips
■ The cooking result greatly depends on the quality of
the food. Pre-browning and unevenness may already
be present on the packaged product.
■ Do not use frozen products that are heavily frosted.
Remove any ice on the food.
■ Distribute foods which are in pieces, such as bread
rolls and potato products, so that they are spread
flat and evenly on the accessories. Leave a little
space between the individual pieces.
■ Observe the instructions on the packaging.
Shelf positions
Use the indicated shelf positions.
Baking on one level
When baking on one level, use the following shelf
positions:
■ Tall baked items: Level 2
■ Flat baked items: Level 3
If you are using 4D Hot air as the type of heating, you
can choose between levels 1, 2, 3 and 4.
Baking on two levels
Use 4D hot air. Baked items that are placed into the
oven on trays or in baking tins/dishes at the same time
will not necessarily be ready at the same time.
■ Universal pan: Level 3
Baking tray: Level 1
Accessories
Ensure that you always use suitable accessories and
that they are placed in the oven the right way around.
Wire rack
Insert the wire rack with the open side facing the
appliance door and the curved lip pointing downwards.
Always place ovenware, tins and dishes on the wire
rack.
Universal pan or baking tray
Slide the universal pan or the baking tray in carefully as
far as the limit stop with the bevelled edge facing the
appliance door.
Greaseproof paper
Only use greaseproof paper that is suitable for the
selected temperature. Always cut greaseproof paper to
size.
Recommended setting values
In the table, you can find the ideal heating type for
various dishes. Temperature and cooking time depend
on the quantity and composition of the product. Setting
ranges are indicated for this reason. Try using the lower
values at first. A lower temperature results in more even
browning. You can use a higher setting next time if
necessary.
Note: Cooking times cannot be reduced by using
higher temperatures. The dish would only be cooked on
the outside, but would not be fully cooked in the middle.
The setting values apply to dishes placed into a cold
cooking compartment. By doing so, you can make
energy savings of up to 20 per cent. If you preheat the
oven, the indicated cooking times will be reduced by
several minutes.
Preheating is necessary for selected dishes, and this is
indicated in the table.
Remove unused accessories from the cooking
compartment. This will achieve the best possible
cooking results and energy savings of up to 20 per
cent.
Turkey, thighs wire rack 2
4
180-190 25+30
Turkey, whole, 4-8 kg wire rack 2
4
140-160 12+12
Fish
Trout, whole, 300 g each wire rack 2
4
170-190 20-30
Fillets, each 150 g wire rack 4
(
1*** 1st side 5-10
2nd side 5-10
Toast
Grilling white bread** wire rack 5
(
3 4-6
Dish Accessories Shelf po-
sition
Type of
heating
Temperature in C /
Grill setting
Time in min.
* Preheat
** Do not preheat
*** Preheat 3 minutes
**** Preheat 3 minutes, turn over several times
***** Preheat 5 minutes
****** Skin side down
Tested for you in our cooking studio en
37
Types of heating used:
■ : 4D hot air
■ % Top/bottom heating
■ ; Pizza setting
■ , coolStart function
Yogurt
You can make your own yogurt using your appliance.
Making yoghurt
Remove accessories and shelf supports from the
cooking compartment. The cooking compartment must
be empty. Do not open the appliance door while the
appliance is in operation.
1. Heat 1 litre of milk (3.5% fat) to 90 °C on the hob
and then leave it to cool down to 40 °C.
It is sufficient to heat UHT milk to 40 °C.
2. Stir in 150 g (chilled) yoghurt.
3. Pour into cups or small jars and cover with cling film.
4. Place the cups or jars onto the cooking
compartment floor and use the settings indicated in
the table.
5. After making the yoghurt, leave it to cool in the
refrigerator.
Type of heating used:
■ : 4D hot air
Dish Accessories/cookware Shelf po-
sition
Type of
heating
Tempera-
ture in °C
Cooking
time in mins.
Pizza, chilled
Pizza, chilled wire rack 3
;
190-210 10-15
Pizza, frozen
Pizza, thin base* wire rack 3
,
- -
Pizza, thin base, 2 levels universal pan + wire rack 3+1
:
190-210 20-25
Pizza, thick base wire rack 3
,
- -
Pizza, thick base, 2 levels universal pan + wire rack 3+1
:
190-210 20-30
Pizza baguette* wire rack 3
,
- -
Potatoe products, frozen
Oven chips* universal pan 3
,
- -
Oven chips, 2 levels universal pan + baking tray 3+1
:
190-210 30-40
Croquettes* universal pan 3
,
- -
Hash browns* universal pan 3
,
- -
Potatoe wedges* universal pan 3
,
- -
Baked goods, frozen, prebaked
Rolls, baguettes* universal pan 3
,
- -
Fried food, frozen
Fish fingers** universal pan 3
%
200-220 20-30
Chicken nuggets universal pan 3
,
- -
Food, chilled
Lasagna, 500 g ovenproof dish on wire rack 2
,
- -
Lasagna, 1,5 kg ovenproof dish on wire rack 2
;
180-200 30-40
Food, frozen
Lasagna, 500 g ovenproof dish on wire rack 2
,
- -
Lasagna, 1,5 kg ovenproof dish on wire rack 2
;
180-200 50-70
* Observe information on the packaging
** Turn during cooking
Dish Cookware Shelf position Type of
heating
Tempera-
ture in °C
Cooking
time in hours
Yoghurt individual moulds cooking compartment floor
:
40-45 8-9h
en Tested for you in our cooking studio
38
Eco heating functions
Hot air eco and Top/bottom heating eco are intelligent
heating functions that allow you to gently cook meat,
fish and baked items. The appliance optimally controls
the supply of energy to the cooking compartment.The
food is cooked in phases using residual heat. This
means that it remains more succulent and browns less.
Depending on the method of preparation and the type
of food, it is possible to save energy. If you open the
appliance door before the food has finished cooking or
if you preheat the appliance, you may not be able to
achieve this result.
Only use genuine accessories for your appliance.
These have been tailored to the cooking compartment
and the operating modes of your appliance.Remove
any accessories that are not being used from the
cooking compartment.
Place the food into the empty cooking compartment
before the oven is heated up. For Hot air eco, select a
temperature of between 125 and 275 °C, and for Top/
bottom heating eco, select a temperature of between
150 and 250 °C. Always keep the appliance door
closed when cooking. Only cook on one level when
using this function.
The Hot air eco heating function is used to measure
both the energy consumption in air recirculation mode
and the energy efficiency class. The Top/bottom
heating eco heating function is used to measure the
energy consumption in the conventional mode.
Accessories
Ensure that you always use suitable accessories and
that they are placed in the oven the right way around.
Wire rack
Insert the wire rack with the open side facing the
appliance door and the curved lip pointing downwards.
Always place ovenware, tins and dishes on the wire
rack.
Universal pan or baking tray
Slide the universal pan or the baking tray in carefully as
far as the limit stop with the bevelled edge facing the
appliance door.
Baking tins and cookware
Dark- coloured metal baking tins are most suitable.
These allow you to make energy savings of up to 35
per cent.
Cookware made from stainless steel or aluminium
reflects heat like a mirror. Non-reflective cookware
made from enamel, heat-resistant glass or coated, die-
cast aluminium is more suitable.
Tinplate baking tins, ceramic dishes or glass dishes
prolong baking time, and the cake will not brown so
evenly.
Greaseproof paper
Only use greaseproof paper that is suitable for the
selected temperature. Always cut greaseproof paper to
size.
Recommended setting values
Here, you can find specifications for various dishes. The
temperature and baking time are dependent on the
quantity and composition of the dough. Different
settings ranges are indicated for this reason. Try using
the lower values at first. A lower temperature results in
more even browning. If necessary, use a higher setting
the next time.
Note: Baking times can not be reduced by using higher
temperatures. Cakes or baked items would only be
cooked on the outside, but would not be cooked
completely in the middle.
Types of heating used:
■ ‘ Hotair Eco
■ + Top/bottom heating Eco
Dish Accessories/cookware Shelf po-
sition
Type of
heating
Tempera-
ture in °C
Cooking
time in mins.
Baking
Victoria Sponge Cake 2x Ø20 cm tins 2
‘
170-180 25-35
Light Fruit Cake high Ø20 cm tin 2
‘
150-170 70-90
Rich Fruit Cake high Ø23 cm tin 2
‘
140-160 120-180
Fruit crumble flat glass dish 3
‘
160-180 40-70
Sponge Cake (fatless), 3 eggs springform cake tin Ø26 cm 2
‘
160-170 25-40
Swiss Roll swiss roll tin 3
‘
180-190 15-25
Fruit Pie plate Ø20 cm or pie tin 2
‘
170-190 60-75
Quiche quiche tin (dark coated) 3
‘
190-210 35-45
(White) Bread loaf tin (1x 900 g or 2x 450 g) 2
‘
190-200 40-50
Scones baking tray 3
‘
190-210 15-20
Jam tarts 12-cup-tin 3
‘
180-200 20-30
Soufflé 1,2L-soufflé dish 2
‘
160-170 40-50
Meat Pie rectangular pie tin 2
‘
190-200 40-55
Jacket Potatoes baking tray 3
‘
150-170 60-90
Tested for you in our cooking studio en
39
Acrylamide in foodstuffs
Acrylamide is mainly produced in grain and potato
products prepared at high temperatures, such as potato
crisps, chips, sliced bread, bread rolls, bread or fine
baked goods (biscuits, gingerbread, spiced biscuit).
Slow cook
Slow cooking is a technique for cooking food over a
long period at low temperatures. For this reason, it is
also called "low-temperature cooking".
Slow cooking is ideal for all prime cuts (e.g. tender
portions of beef, veal, pork, lamb or poultry) which are
to be cooked "à point". The meat will remain succulent
and tender.
The benefit of this cooking method is that it allows lots
of scope for menu planning because slow-cooked meat
is easy to keep warm. You do not have to turn the meat
when cooking. Keep the appliance door closed in order
to maintain an even cooking climate.
Only use fresh, clean and hygienic meat without bones.
Carefully remove sinews and fat from around the edge.
Fat develops a strong, distinct flavour during slow
cooking. You can also use seasoned or marinated
meat. Do not use defrosted meat.
Meat can be carved immediately following slow
cooking. No standing time is required. Due to the
special cooking method, the meat looks pink, but is not
raw or undercooked.
Note: Delayed-start operation with an end time is not
possible for the slow cooking heating type.
Cookware
Use shallow cookware, e.g. a glass/porcelain serving
dish. Place the cookware into the cooking compartment
to preheat it.
Always place the uncovered cookware onto the wire
rack at level 2.
You can find additional information in the tips on slow
cooking attached to the settings table.
Your appliance features the heating type "Slow cook".
Only start operation when the cooking compartment
has fully cooled down. Allow the cooking compartment
to warm up for approx. 15 minutes with the cookware
inside.
Sear the meat on the hotplate at a very high heat and
for a sufficiently long time on all sides, even on the
ends. Place into the preheated cookware right away.
Place the cookware containing the meat into the
cooking compartment once again and cook slowly.
Recommended setting values
The slow cooking temperature and cooking time are
dependent on the size, thickness and quality of the
meat. Different settings ranges are indicated for this
reason.
Meat
Beef, slow roast joint wire rack 2
‘
140-150 35+40
Casserole
Diced meat (beef, pork, lamb), 500 g meat cookware, covered 2
‘
140 100-120
Braising steak cookware, covered 2
‘
140 65+60
Fish
Fish, braised, whole 300 g, e. g. trout cookware, covered 2
+
190-210 25-35
Fish, braised, whole 1,5kg, e. g. salmon cookware, covered 2
+
190-210 45-55
Fish fillet, plain, braised, 100 g cookware, covered 2
+
190-210 15-25
Dish Accessories/cookware Shelf po-
sition
Type of
heating
Tempera-
ture in °C
Cooking
time in mins.
Tips for keeping acrylamide to a minimum
General ■ Keep cooking times as short as possible.
■ Cook food until it is golden brown, but not too dark.
■ Large, thick pieces of food contain less acrylamide.
Baking With top/bottom heating at max. 200 °C.
With hot air at max. 180 °C.
Biscuits With top/bottom heating at max. 190 °C.
With hot air at max. 170 °C.
Egg or egg yolk reduces the production of acrylamide.
Oven chips Spread out a single layer evenly on the baking tray. Cook at least 400 g at once on a baking tray so that
the chips do not dry out.
en Tested for you in our cooking studio
40
Type of heating used:
■ . Slow cooking
Tips for slow cooking
Drying
With 4D hot air, you can dry foods with outstanding
results. With this type of preserving, flavourings are
concentrated by the dehydration.
Only use unblemished fruit, vegetables and herbs and
wash them thoroughly. Line the wire rack with
greaseproof paper or parchment paper. Drain the
excess water from the fruit and dry it.
If necessary, cut it into equal chunks or thin slices.
Place unpeeled fruit onto the dish with the sliced
surfaces facing upwards. Ensure that neither fruit nor
mushrooms overlap on the wire rack.
Grate vegetables and then blanch them. Allow the
blanched vegetables to drain off and distribute them
evenly on the wire rack.
Dry herbs on the stem. Position the herbs evenly and
slightly heaped on the wire rack.
Use the following shelf positions for drying:
■ 1 wire rack: Level 3
■ 2 wire racks: Level 3+1
Turn very juicy fruit and vegetables several times. After
drying, remove the dried products from the paper
immediately.
Dish Cookware Shelf posi-
tion
Heating
function
Searing time
in mins
Tempera-
ture in °C
Cooking
time in
mins
Poultry
Duck breast, medium rare, 300 g each Cookware, uncovered 2
.
6-8 90* 45-60
Chicken breast fillet, 200 g each, well
done
Cookware, uncovered 2
.
4 120* 45-60
Turkey breast, boned, 1 kg, well done Cookware, uncovered 2
.
6-8 120* 110-130
Pork
Pork tenderloin steak, 5-6 cm thick,
1.5 kg
Cookware, uncovered 2
.
6-8 80* 130-180
Fillet of pork, whole Cookware, uncovered 2
.
4-6 80* 45-70
Beef
Joint of beef (rump), 6-7 cm thick,
1.5 kg
Cookware, uncovered 2
.
6-8 100* 150-180
Fillet of beef, 1 kg Cookware, uncovered 2
.
4-6 80* 90-120
Sirloin, 5-6 cm thick Cookware, uncovered 2
.
6-8 80* 120-180
Beef medallions/rump steak, 4 cm
thick
Cookware, uncovered 2
.
4 80* 30-60
Veal
Joint of veal, 4-5 cm thick, 1.5 kg Cookware, uncovered 2
.
6-8 80* 80-140
Joint of veal, 7-10 cm thick, 1.5 kg Cookware, uncovered 2
.
6-8 80* 140-200
Fillet of veal, whole, 800 g Cookware, uncovered 2
.
4-6 80* 70-120
Veal medallions, 4 cm thick Cookware, uncovered 2
.
4 80* 30-50
Lamb
Saddle of lamb, boneless, 200 g each Cookware, uncovered 2
.
4 80* 30-45
Leg of lamb, boned, medium, 1 kg, tied Cookware, uncovered 2
.
6-8 95* 120-180
* Preheat
Slow-cooking duck breast. Place the cold duck breast into a pan and fry the skin side first. After slow cooking, grill for 3 to 5 minutes until
crispy.
The slow-cooked meat is not as hot as
conventionally roasted meat.
So that the roasted meat does not cool so quickly, warm the plates and serve the sauces very hot.
Tested for you in our cooking studio en
41
Recommended setting values
In the table, you can find settings for drying various
foodstuffs. The temperature and cooking time are
dependent on the type, moisture, ripeness and
thickness of the food to be dried. The longer you leave
the food to be dried, the better it will be preserved. The
thinner the slices are, the quicker the drying process
will be and the more aromatic the dried food will
remain. Setting ranges are indicated for this reason.
If you wish to dry additional foodstuffs, you should use
similar foodstuffs in the table as a reference.
Type of heating used:
■ : 4D hot air
Preserving
You can preserve fruit and vegetables using your
appliance.
:Warning – Risk of injury!
If the food is preserved incorrectly, the preserving jars
may burst. Follow the instructions for preserving.
Jars
Use only clean and undamaged preserving jars. Only
use heat-resistant, clean and undamaged rubber rings.
Check clips and clamps in advance.
For each preserving process, only use preserving jars
that are the same size and contain the same food. In
the cooking compartment, you can preserve the
contents of a maximum of six ^, 1 or 1^-litre
preserving jars at the same time. Do not use jars that
are larger or taller than this. The lids could rupture.
Preserving jars must not touch one another in the
cooking compartment during the preserving process.
Preparing fruit and vegetables
Only use fruit and vegetables that are in good condition.
Wash them thoroughly.
Peel, core and chop fruit and vegetables appropriate to
their type and fill the preserving jars with them up to
approx. 2 cm below the rim.
Fruit
Fill the preserving jars with the fruit along with a hot,
skimmed sugar solution (approx. 400 ml for a 1-litre
jar). For one litre of water:
■ Approx. 250 g sugar for sweet fruit
■ Approx. 500 g sugar for sour fruit
Vegetables
Fill the jars with the vegetables along with hot, boiled
water.
Wipe the rims of the jars, as they must be clean. Place
a damp rubber ring and a lid on each jar. Seal the jars
with clamps. Place the jars into the universal pan so
that they do not touch each other. Pour 500 ml hot
water (approx. 80 °C) into the universal pan. Use the
settings indicated in the table.
Ending the preserving process
Fruit
After a short while, small bubbles will form at short
intervals. Switch off the appliance once all preserving
jars are bubbling. Remove the jars from the cooking
compartment after the indicated cooling time.
Vegetables
After a short while, small bubbles will form at short
intervals. As soon as all preserving jars are bubbling,
reduce the temperature to 120 °C and allow the jars to
continue to bubble in the closed cooking compartment
as indicated in the table. After this time has elapsed,
switch off the appliance and make use of the residual
heat for several minutes as indicated in the table.
After preserving, remove the jars from the cooking
compartment and place them onto a clean cloth. Do not
place these hot jars onto a cold or damp surface, as
they may crack. Cover the preserving jars to protect
them from draughts. Only remove the clamps once the
jars are cold.
Recommended setting values
The indicated times in the settings table are average
values for preserving fruit and vegetables. They may be
influenced by room temperature, the number of jars,
quantity, heat and quality of the jar contents. The
specifications are based on 1-litre round jars. Before
you switch off the appliance or change the cooking
mode, check whether the contents of the jars are
bubbling as they should. The bubbling process starts
after approx. 30-60 minutes.
Fruit, vegetables and herbs Accessories Type of
heating
Tempera-
ture in °C
Cooking
time in
hours
Pomes (apple rings, 3 mm thick, 200 g per wire rack) 1-2 wire racks
:
80 5-9
Stone fruit (plums) 1-2 wire racks
:
80 8-10
Root vegetables (carrots), grated, blanched 1-2 wire racks
:
80 5-8
Sliced mushrooms 1-2 wire racks
:
60 6-9
Herbs, washed 1-2 wire racks
:
60 2-6
en Tested for you in our cooking studio
42
Type of heating used:
■ : 4D hot air
Prove dough
You can prove yeast dough in your appliance more
quickly than at room temperature. Use the top/bottom
heating type. Only start operation when the cooking
compartment has fully cooled down.
Always allow yeast dough to prove twice. Observe the
specifications in the settings tables for the 1st and 2nd
proving processes (dough fermentation and final
fermentation).
Dough fermentation
Use the settings indicated in the table and heat up the
appliance. Position the dough bowl on the wire rack.
Do not open the appliance door during the proving
process, as moisture will escape. Cover the dough with
a damp cloth.
Final fermentation
Place your baked item into the oven at the shelf position
indicated in the table.
If you want to preheat the oven, the final fermentation
takes place outside the appliance in a warm place.
Recommended setting values
The temperature and proving time are dependent on
the type and quantity of the ingredients. The values in
the table are therefore only meant to be average values.
Type of heating used:
■ % Top/bottom heating
Defrosting
Use heating type 4D hot air to defrost fruit, vegetables
and baked items. Poultry, meat and fish should ideally
be defrosted in the refrigerator.
Use the following shelf positions when defrosting:
■ 1 wire rack: Level 2
■ 2 wire racks: Level 3+1
Recommended setting values
The times in the table are average values. They are
dependent on the quality, freezing temperature (-18 °C)
and composition of the food. Time ranges are indicated.
Set the shortest time first and then extend the time if
necessary.
Tip: Items which were frozen flat or portioned defrost
faster than those frozen in a block.
Remove frozen food from the packaging and place it in
suitable cookware onto the wire rack.
Stir the food or turn it once or twice in between. Large
pieces of food should be turned several times.
Occasionally split the food or remove items which have
already defrosted from the cooking compartment.
Leave the defrosted food to rest for another 10 to 30
minutes in the appliance whilst it is switched off, so that
the temperature balances out.
Preserving Cookware Shelf posi-
tion
Type of
heating
Tempera-
ture in °C
Cooking time in mins.
Vegetables, e.g. carrots 1-litre preserving jars 1
:
160-170 Before it starts bubbling:30-40
120 When it starts to bubble: 30-40
- Residual heat: 30
Vegetables, e.g. cucumbers 1-litre preserving jars 1
:
160-170 Before it starts bubbling: 30-40
- Residual heat: 30
Stone fruit, e.g. cherries, damsons 1-litre preserving jars 1
:
160-170 Before it starts bubbling:30-40
- Residual heat:35
Pomes, e.g. apples, strawberries 1-litre preserving jars 1
:
160-170 Before it starts bubbling:30-40
- Residual heat: 25
Dish Accessories/cookware Shelf posi-
tion
Type of
heating
Step Tempera-
ture in °C
Cooking
time in
mins.
Yeast dough, light Bowl 2
%
Dough fer-
mentation
35-40 25-30
Baking tray 2
%
Final fermen-
tation
35-40 10-20
Yeast dough, heavy and rich Bowl 2
%
Dough fer-
mentation
35-40 20-40
Baking tray 2
%
Final fermen-
tation
35-40 15-25
Tested for you in our cooking studio en
43
Type of heating used:
■ : 4D hot air
Keeping warm
You can keep cooked dishes warm using the "Keeping
warm" heating type. This will avoid condensation
developing, and means you will not have to wipe out the
cooking compartment.
Do not keep cooked dishes warm for longer than two
hours. Be aware that some dishes may continue
cooking whilst being kept warm. Cover the dishes if
necessary.
Test dishes
These tables have been produced for test institutes to
facilitate appliance testing.
As per EN 60350-1.
Baking
Baked items that are placed into the oven on trays or in
baking tins/dishes at the same time will not necessarily
be ready at the same time.
Shelf positions for baking on two levels:
■ Universal pan: Level 3
Baking tray: Level 1
■ Baking tins/dishes on the wire rack
First wire rack: Level 3
Second wire rack: Level 1
Shelf positions for baking on three levels:
■ Baking tray: Level 5
■ Universal pan: Level 3
■ Baking tray: Level 1
Apple pie
Apple pie on one level: place dark-coloured springform
cake tins diagonally next to each other.
Apple pie on two levels: position dark-coloured
springform cake tins above each other so that they are
offset.
Cakes in tinplate springform cake tins: bake on one
level with top/bottom heating. Place the springform
cake tin onto the universal pan instead of onto the wire
rack.
Fatless sponge cake
Fatless sponge cake on two levels: vertically stack
springform cake tins in an offset manner on the wire
racks.
Notes
■ The setting values apply to dishes placed into a cold
cooking compartment.
■ Please note the information in the tables about
preheating. The setting values are valid without rapid
heating-up.
■ For baking, use the lower of the indicated
temperatures first.
Types of heating used:
■ : 4D hot air
■ % Top/bottom heating
■ ; Pizza setting
Dish Accessories Shelf posi-
tion
Type of
heating
Tempera-
ture in °C
Cooking
time in
mins.
Bread, bread rolls
Bread & bread rolls general Baking tray 2
:
50 40-70
Cake
Cake, moist Baking tray 2
:
50 70-90
Cake, dry Baking tray 2
:
60 60-75
Dish Accessory Shelf posi-
tion
Type of
heating
Tempera-
ture in °C
Cooking
time in
mins.
Baking
Shortbread Baking tray 3
%
140-150* 25-40
Shortbread Baking tray 3
:
140-150* 25-40
Shortbread, 2 levels Universal pan + baking tray 3+1
:
140-150* 30-40
Shortbread, 3 levels Baking trays + universal pan 5+3+1
:
130-140* 35-55
Small cakes Baking tray 3
%
160* 20-30
Small cakes Baking tray 3
:
150* 25-35
Small cakes, 2 levels Universal pan + baking tray 3+1
:
150* 25-35
* Preheat for 5 mins, do not use quick heat function
** Preheat, do not use quick heat function
en Tested for you in our cooking studio
44
Grilling
Also slide in the universal pan. The liquid will be caught
and the cooking compartment stays cleaner.
Type of heating used:
■ ( Grill, large area
Small cakes, 3 levels Baking trays + universal pan 5+3+1
:
140* 35-45
Fatless sponge cake Springform cake tin, diameter 26 cm 2
%
160-170** 25-35
Fatless sponge cake Springform cake tin, diameter 26 cm 2
:
160-170** 30-40
Fatless sponge cake, 2 levels Springform cake tin, diameter 26 cm 3+1
:
150-170** 30-50
Apple pie 2 x black plate tins, diameter 20 cm 2
;
170-180 60-80
Apple pie 2 x black plate tins, diameter 20 cm 2
%
180-200 60-80
Apple pie, 2 levels 2 x black plate tins, diameter 20 cm 3+1
:
170-190 70-90
Dish Accessory Shelf posi-
tion
Type of
heating
Tempera-
ture in °C
Cooking
time in
mins.
* Preheat for 5 mins, do not use quick heat function
** Preheat, do not use quick heat function
Dish Accessories Shelf posi-
tion
Type of
heating
Grill
setting
Cooking
time in
mins.
Grilling
Toasting bread* Wire rack 5
(
3 4-6
Beefburger, 12 pieces** Wire rack 4
(
3 25-30
* Do not preheat
** Turn after 2/3 of the total time
6
6
Carl-Wery-Str. 34
81739 München
GERMANY
BSH Hausgeräte GmbH
siemens-home.bsh-group.com
*9001382151*
9001382151 (990731)
Manufactured by BSH Hausgeräte GmbH under Trademark License of Siemens AG
