www.lg.com
OWNER’S MANUAL
MONITOR SIGNAGE
47WX50MF
Please read this manual carefully before operating your set and retain it
for future reference.
MONITOR SIGNAGE MODELS
ENG
ENGLISH
background
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
background
2
ENG
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
4 LICENSES
5 ASSEMBLING AND
PREPARING
5 Accessories
6 OptionalAccessories
7 PartsandButtons
8 ConnectingtheStand
8 PortraitLayout
9 ConnectingMediaPlayer
10 STORAGEMETHODFORPANEL
PROTECTION
10 - CorrectMethod
10 - IncorrectMethod
11 MovingHandles
11 - MovingtheDeviceinaVerticalPosition
12 REMOTE CONTROL
14 USING THE MONITOR SET
14 ConnectingtoaPC
14 - RGBConnection
15 - DVIConnection
15 - HDMIConnection
16 - DisplayPortconnection
17 AdjustingtheScreen
17 - SelectinganImageMode
17 - CustomizingImageOptions
18 - CustomizingPCDisplayOptions
18 AdjustingtheSound
18 - SelectinganSoundMode
19 - CustomizingSoundOptions
19 UsingAdditionalOptions
19 - AdjustingAspectRatio
21 - UsingtheInputList
22 ENTERTAINMENT
22 - ConnectingtoaWiredNetwork
23 - NetworkStatus
24 - ConnectingUSBStorageDevices
25 - BrowsingFiles
27 - ViewingMovies
30 - ViewingPhotos
33 - ListeningtoMusic
35 - ViewingtheContentsList
36 - DivX®VODGuide
37 - UsingPIP/PBP
38 CUSTOMIZING SETTINGS
38 AccessingtheMainMenus
39 - PICTURESettings
42 - AUDIOSettings
43 - TIMESettings
44 - OPTIONSettings
49 - PictureID
50 - NETWORKSettings
51 MAKING CONNECTIONS
52 ConnectingtoaHDreceiver,DVD,
Camcorder,Camera,GamingDeviceor
VCRplayer
52 - DVIConnection
52 - HDMIConnection
53 - ComponentConnection
53 - AV(CVBS)Connection
54 ConnectingtotheLAN
54 - LANConnection
54 ConnectingtoaUSB
55 DaisyChainMonitors
55 - DVICable
55 - RGBCable
background
3
ENG
ENGLISH
TABLE OF CONTENTS
56 TROUBLESHOOTING
59 SPECIFICATIONS
62 CONTROLLING THE MULTIPLE
PRODUCT
62 ConnectingtheCable
62 RS-232CConfigurations
62 CommunicationParameter
63 Commandreferencelist
65 Transmission/Receivingprotocol
77 IR CODES
background
ENGLISH
4
LICENSES
LICENSES
Supportedlicensesmaydifferbymodel.Formoreinformationofthelicenses,visitwww.lg.com.
HDMI,theHDMIlogoandHigh-DefinitionMultimediaInterfacearetrademarks
orregisteredtrademarksofHDMILicensingLLC.
ABOUTDIVXVIDEO:DivX isadigitalvideoformatcreatedbyDivX,LLC,a
subsidiaryofRoviCorporation.ThisisanofficialDivXCertified devicethat
playsDivXvideo.Visitdivx.comformoreinformationandsoftwaretoolsto
convertyourfilesintoDivXvideos.
ABOUTDIVXVIDEO-ON-DEMAND:ThisDivX
Certified devicemustberegisteredinordertoplaypurchasedDivXVideo-
on-Demand(VOD)movies.Toobtainyourregistrationcode,locatethe
DivXVODsectioninyourdevicesetupmenu.Gotovod.divx.comformore
informationonhowtocompleteyourregistration.
DivXCertified toplayDivX videouptoHD1080p,includingpremium
content.
DivX ,DivXCertified andassociatedlogosaretrademarksofRovi
Corporationoritssubsidiariesandareusedunderlicense.
CoveredbyoneormoreofthefollowingU.S.patents:7,295,673;7,460,668;
7,515,710;7,519,274
ManufacturedunderlicensefromDolbyLaboratories.“Dolby”andthe
double-DsymbolaretrademarksofDolbyLaboratories.
background
5
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Accessories
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
Remote control and Batteries Power Cord
D-sub 15 pin signal cable
Donotuseanypirateditemstoensurethesafetyandproductlifespan.
Anydamagesorinjuriesbyusingpirateditemsarenotcoveredbythewarranty.
CAUTION
Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
NOTE
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
POWER
OK
S.MENU
ID
BACK
TILE
ON
OFF
EXIT
CD (Owner's Manual,
Software Program, Software
Manual)/Card
background
6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Optional Accessories
Withoutpriornotice,optionalaccessoriesaresubjecttochangetoimprovetheperformanceoftheproduct,
andnewaccessoriesmaybeadded.Theillustrationsinthismanualmaydifferfromtheactualproductand
accessories.
Pleasepurchaseoptionalaccessoriesseparatelyifnecessary.
FormoreinformationontheMediaPlayer,pleaserefertotheowner'smanualprovidedwiththe
product.
NOTE
Stand Screws
Stand kit
Media Player kit
Media Player Screws
CD (Owner's Manual) /
Card
background
7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and Buttons
Screen Marks Description
INPUT Changestheinputsource.
MENU Accessesthemainmenus,orsavesyourinputandexitsthemenus.
Adjusttheupanddown.
Adjuststhevolumelevel.
AUTO/SET Displaysthecurrentsignalandmode.
Pressthisbuttontoadjustthescreenautomatically(availableonlyinRGBmode)
/I
Turnsthepoweronoroff.
YoucansetthePowerindicatortoonoroffbyselectingOPTIONinthemainmenu.
NOTE
USB DP LANAUDIO
IN
DVI IN DVI OUT
IN
SPEAKER
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
Illuminance sensor/
IR Receiver
Power Indicator
Screen Buttons
Screen Marks
Connection panel
Illuminance sensor Adjuststhescreenbrightnessbymeasuringtheamountoflight.
IR Receiver Thisiswheretheunitreceivessignalsfromtheremotecontrol.
Power Indicator ThisIndicatorlightsupredwhenthedisplayoperatesnormally(onmode).Ifthedisplay
Insleepmode(InPowerSavingmode),thisindicatorcolorchangestoamber.
background
8
ENG
ENGLISH
ASSEMBLING AND PREPARING
2
Usethescrewstosecurethestandontherear
sideoftheproductasshowninthediagram.
Connecting the Stand
-Onlyonsomemodels.
1
Place a soft cloth on the table and put the
productwiththescreenfacingdownward.
Portrait Layout
WheninstallinginaPortraitLayout,rotatethe
monitorclockwise90degrees(whenfacingthe
screen).
Usethespecifiedscrew.(M4.0mmxPitch
0.6mmxLength9mm(includingspring
washer:1.8mm))
NOTE
background
9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Connecting Media Player
-Onlyonsomemodels.
1
Placeasoftclothonthetableandputthe
productwiththescreenfacingdownward.
Removetheopeningcoverbyunfasteningtwo
screwsasshowninthepicture.
Usethescrewsprovidedwiththeproduct.
(M3.0mmxPitch0.5mmxLength6.0mm)
NOTE
2
PushtheMediaPlayerintothecompartmentto
mountit.
3
FixtheMediaPlayerontheproductusingthe
twoscrewsprovided.
background
10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Correct Method Incorrect Method
STORAGE METHOD FOR PANEL PROTECTION
Iftheproductneedstobesetupright,holdboth
sidesoftheproduct,andtiltbackwardcarefully
for.Donotletthepanelnottotouchthefloor.
Iftheproductistiltedontothebezel,thebottomof
thepanelmaybedamaged.
Panel
Panel
Cushion
Panel
Panel
Whenlayingdowntheproductonthefloor,place
itfacedownonacushionedflatsurface.
Layingdownthebackoftheproductmaycause
damagetothenumberkeysiftheyarepressed.
background
11
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving the Device in a Vertical Position
Holdtheleftandrighthandlesonthebackofthedisplay.
Moving Handles
Becarefulnottodirectlytouchthepanelorexposeittoshockwhenmovingthemonitor.
Holdthemonitorwiththehandlesasthecornersofthefrontpanelaresharp,whichmaycausean
injury.
CAUTION
Leftandrighthandlesat
theback
background
12
ENG
ENGLISH
REMOTE CONTROL
REMOTE CONTROL
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
/I(POWER)
TurnstheMonitorsetonoroff.
MONITOR
On / Off
Turnoffthemonitorandthen
turnitbackon.
1/a/A Button
Togglesbetweennumerical
andalphabetical.
ENERGY SAVING ( )
Adjuststhebrightnessof
thescreentoreduceenergy
consumption.
INPUT
Selectstheinputmode.
Number and Alphabet buttons
Entersnumericaloralphabetical
charactersdependingonthe
setting.
CLEAR
Deletestheenterednumerical
oralphabeticalcharacter.
PSM
SelectsthePictureStatus
Mode.
MUTE
Mutesallsounds.
ARC
SelectstheAspectRatio
Mode.
Volume Up / Down
Adjuststhevolumelevel.
BRIGHTNESS Key
Adjustthebrightnessby
pressingtheUpandDown
buttonsontheremotecontrol.
InUSBmode,theOSDmenu
hasthePagefunctionto
movetothenextfilelist.
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
1
. , !
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
1/a/A
0
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
P
A
G
E
INPUT
ENER
GY
S
AVIN
G
MARK
ARC
.
,
!
2
ABC
3
D
E
F
4
G
HI
5
J
K
L
6
M
N
O
7
PQ
R
S
7
7
8
T
U
V
9
1/a/A
0
- * #
WXYZ
C
LEA
R
ON
OF
F
MONITOR
MONITOR
PSM
MU
T
E
BRI
G
H
T
NESS
PO
WE
R
Thedescriptionsinthismanualarebasedonthebuttonsoftheremotecontrol.Pleasereadthismanual
carefullyandusetheMonitorsetcorrectly.
Toreplacebatteries,openthebatterycover,replacebatteries(1.5VAAA)matching and endstothe
labelinsidethecompartment,andclosethebatterycover.
Toremovethebatteries,performtheinstallationactionsinreverse.
Donotmixoldandnewbatteries,asthis
maydamagetheremotecontrol.
Makesuretopointtheremotecontroltothe
remotecontrolsensorontheMonitorset.
CAUTION
background
13
ENG
ENGLISH
REMOTE CONTROL
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
S.MENU
(SuperSignMenuKey)
Allowstoselectthe
SuperSignOSDmenu(for
SuperSigninputonly).
EXIT
Clearsallon-screendisplays
andreturnstoMonitorset
viewingfromanymenu.
TILE
SelectstheTILEMode.
MENU (Seep.38)
Accessesthemainmenus
orsavesyourinputandexit
menus.
Navigation buttons
Scrollsthroughmenusor
options.
OK
Selectsmenusoroptionsand
confirmsyourinput.
BACK
Allowstheusertomoveback
onestepinuserinteraction
function.
USB Menu control buttons
Controlsmediaplayback.
ID ON/OFF
WhenthenumberofPicture
IDisequaltoSetIDyoucan
controlthemonitorwhich
youwantinthemultidisplay
condition.
AUTO
Automaticallyadjustspicture
positionandminimizesimage
instability.(RGBinputonly)
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
1
. , !
2
ABC
3
DEF
4
GHI
5
JKL
6
MNO
7
PQRS
8
TUV
9
1/a/A
0
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
OK
S
.MEN
U
A
U
T
O
MEN
U
ID
BA
C
K
T
IL
E
ON
O
FF
E
XIT
background
14
ENG
ENGLISH
USING THE MONITOR SET
USING THE MONITOR SET
Connecting to a PC
YourMonitorsetsupportsthePlug&Play*feature.
*Plug&Play:APCwillhaveabuilt-indriverfor
themonitor,noextrasoftwareisneeded.
Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.
Donotpressthescreenwithyourfingerfor
alongtimeasthismayresultintemporary
distortiononthescreen.
Avoiddisplayingafixedimageonthe
screenforalongperiodoftimetoprevent
imageburn.Useascreensaverifpossible.
RGB Connection
TransmitstheanalogvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwiththe15pinsignalcableasshownthe
followingillustrations.
SelectRGBinput.
NOTE
ItisrecommendedtousetheMonitorset
withtheHDMIconnectionforthebestimage
quality.
Useashieldedsignalinterfacecable,such
asD-sub15pinsignalcableandDVI/
HDMIcable,withaferritecoretomaintain
standardcompliancefortheproduct.
IfyouturntheMonitorsetonwhentheset
becomescold,thescreenmayflicker.This
isnormal.
Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
CAUTION
Use the standardMacintosh
adaptersinceanincompatible
adapte r is ava ilab le in the
market. (Different signaling
system)
Applecomputers mayrequireanadapterto
connecttothismonitor.Callorvisittheirweb
siteformoreinformation.
NOTE
AUDIO
IN
AUDIO
IN
DVI IN
IN
DP
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
PC
Backoftheproduct.
MacintoshAdapter
(notincluded)
(notincluded)
PC/MAC
background
15
ENG
ENGLISH
USING THE MONITOR SET
DVI Connection
TransmitsdigitalvideosignalfromyourPCto
theMonitorset.ConnectthePCandtheMonitor
setwiththeDVIcableasshownthefollowing
illustrations.
SelectDVIinput.
HDMI Connection
Transmitsdigitalvideoandaudiosignalsfromyour
PCtotheMonitorset.ConnectthePCandthe
MonitorsetwiththeHDMIcableasshowninthe
followingillustrations.
SelectHDMIinput.
UseaHighSpeedHDMI™Cable.
PleasecheckthePCenvironmentifyou
cannothearthesoundinHDMImode.
SomePCsrequireyoutomanuallychange
thedefaultaudiooutputtoHDMI.
IfyouwanttouseHDMI-PCmode,you
mustsettheinputlabeltoPCmode.
WhenHDMIPCisused,acompatiblity
problemcouldoccur.
NOTE
AUDIO
IN
AUDIO
IN
DVI IN
IN
DP
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
AUDIO
IN
AUDIO
IN
DVI IN
IN
DP
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
PC PC
PC
Backoftheproduct.
Backoftheproduct.
(notincluded)
(notincluded)
(notincluded)
background
16
ENG
ENGLISH
USING THE MONITOR SET
Display Port connection
Transmitsdigitalvideoandaudiosignalsfrom
yourPCtotheMonitor.ConnectthePCandthe
MonitorwiththeDisplayPortcableasshownin
thefollowingillustrations.
SelectDisplayPortinputsource.
Soundmaynotbeavailabledependingon
theDPversionofyourPC.
NOTE
AUDIO
IN
AUDIO
IN
DVI IN
IN
DP
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
PC
Backoftheproduct.
(notincluded)
background
17
ENG
ENGLISH
USING THE MONITOR SET
Adjusting the Screen
Selecting an Image Mode
Displayimagesinitsoptimizedsettingsby
selectingoneofthepresetimagemodes.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
Customizing Image Options
Customizebasicandadvancedoptionsofeach
imagemodeforthebestscreenperformance.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
5
Selectandadjustfollowingoptions,andthen
pressOK.
Mode Description
Vivid Adjuststhevideoimagefortheretail
environmentbyenhancingthecontrast,
brightness,color,andsharpness.
Standard Adjuststheimageforthenormal
environment.
Cinema Optimizesthevideoimageforacinematic
looktoenjoymoviesasifyouareina
movietheater.
Sport Optimizesthevideoimageforhighand
dynamicactionsbyemphasizingprimary
colorsuchaswhite,grass,orskyblue.
Game Optimizesthevideoimageforafast
gamingscreensuchasPCsorgames.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Option Description
Backlight Adjuststhebrightnessofthescreen
bycontrollingtheLCDbacklight.If
youdecreasethebrightnesslevel,
thescreenbecomesdarkerandthe
powerconsumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthegradient
ofthevideosignal.Youmayuse
Contrastwhenthebrightpartofthe
pictureissaturated.
Brightness Adjuststhebaselevelofthesignalin
thepicture.YoumayuseBrightness
whenthedarkpartofthepictureis
saturated.
Sharpness Adjuststhelevelofcrispnessinthe
edgesbetweenthelightanddark
areasofthepicture.Thelowerthe
level,thesoftertheimage.
Color Adjustsintensityofallcolors.
Tint Adjuststhebalancebetweenredand
greenlevels.
Color Temp. SettowarmtoenhancehotterColors
suchasred,orsettocooltomake
picturebluish.
background
18
ENG
ENGLISH
USING THE MONITOR SET
Customizing PC Display Options
Customizeoptionsofeachimagemodeforthe
bestimagequality.
Thisfunctionworksinthefollowingmode:
RGB[PC]mode.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
ScreenandpressOK.
4
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Resolution Selectsaproperresolution.See
“CustomizingPCdisplayoptions”.
Auto
Config.
Setstoadjustthescreenposition,clock,
andphaseautomatically.
Thedisplayedimagemaybeunstablefor
afewsecondswhiletheconfigurationis
inprogress.
Position/
Size/Phase
Adjuststheoptionswhenthepictureis
notclear,especiallywhencharactersare
shaky,aftertheautoconfiguration.
Reset Restorestheoptionstothedefault
setting.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Adjusting the Sound
Selecting an Sound Mode
Playthesoundinitsoptimizedsettingsby
selectingoneofthepresetsoundmodes.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3
PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
Mode Description
Standard Selectwhenyouwantstandard-quality
sound.
Music Selectwhenyoulistentomusic.
Cinema Selectwhenyouwatchmovies.
Sports Selectwhenyouwatchsportsevents.
Game Selectwhenyouplaygames.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Advanced
Control
Customizestheadvancedoptions.
RefertotheAdvancedimageoptions.
Picture Reset Restorestheoptionstothedefault
setting.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
19
ENG
ENGLISH
USING THE MONITOR SET
Customizing Sound Options
Customizeoptionsofeachsoundmodeforthe
bestsoundquality.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3
PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
5
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Infinite
Sound
LG'sInfinitySoundoptionprovides5.1
channelstereosoundqualityfromtwo
speakers.
Treble Increasestheintensityofthehigh
frequencypartofaudio.
Bass Increasestheintensityofthelow
frequencypartofaudio.
Reset Resetsthesoundmodetothedefault
setting.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Using Additional Options
Adjusting Aspect Ratio
Resizetheimagetoviewtheimageatitsoptimal
sizebypressingARC whileyouarewatching
Monitorset.
Ifafixedimagedisplaysonthescreenfor
alongperiodoftime,itcouldbeimprinted
andbecomeapermanentdisfigurementon
thescreen.Thisis“imageburn”or“burn-in”
andnotcoveredbythewarranty.
Iftheaspectratioissetto4:3foralong
periodoftime,imageburnmayoccuron
theletterboxedareaofthescreen.
CAUTION
Youcanalsochangetheimagesizeby
accessingthemainmenus.
NOTE
MODE
ARC
AV Component RGB Display
Port
DVI-D HDMI
PC DTV PC PC DTV PC
16:9
o o o o o o o o
Just Scan
x o x o x x o x
1:1
x x o x o o x o
4:3
o o o o o o o o
Zoom
o o x o x x o x
Cinema
Zoom
o o x o x x o x
background
20
ENG
ENGLISH
USING THE MONITOR SET
-4:3 :Thisselectionwillallowyoutoviewa
picturewithanoriginal4:3aspectratio,black
barswillappearonboththeleftandrightofthe
screen.
-Zoom :Thisselectionwillallowyoutoviewthe
picturewithoutanyalteration,whilefillingthe
entirescreen.However,thetopandbottomof
thepicturewillbecropped.
-Cinema Zoom :ChooseCinemaZoomwhen
youwanttoenlargethepictureincorrect
proportion.Note:Whenenlargingorreducing
thepicture,theimagemaybecomedistorted.
-16:9 :Thisselectionwillallowyoutoadjustthe
picturehorizontally,inlinearproportion,tofillthe
entirescreen(usefulforviewing4:3formatted
DVDs).
-Just Scan :ThisSelectionwillallowyouview
thepictureofbestqualitywithoutlossoforiginal
pictureinhighresolutionimage.Note:Ifthereis
noiseinoriginalPicture,Youcanseethenoise
attheedge.
-1:1 :Theaspectratioisnotadjustedfromthe
original.(OnlyDisplayPortPC,HDMIPC,
DVI-DPC,RGBPC)
Just Scan
background
21
ENG
ENGLISH
USING THE MONITOR SET
Using the Input List
Selecting an input source
1
PressINPUTtoaccesstheinputsourcelist.
2
PresstheNavigationbuttonstoscrolltooneof
theinputsourcesandpressOK.
Input source Description
AV(CVBS) WatchvideofromaVCRorother
externaldevices.
Component WatchthecontentfromaDVDor
otherextemaldevices,orthrougha
digitalset-topbox
RGB ViewaPCdisplayonthescreen
Display Port ViewaPCdisplayonthescreen
DVI-D ViewaPCdisplayonthescreen
HDMI WatchcontentsfromaPC,DVD
ofDigitalset-topboxotherhigh
definitiondevices
If the PC screen is not displayed on the
monitor that is connected through Display
PortorHDMI,presstheBluebuttontosetthe
inputlabeltoPCmode.
NOTE
background
22
ENG
ENGLISH
ENTERTAINMENT
ENTERTAINMENT
Connecting to a Wired Network
Connectthedisplaytoalocalareanetwork(LAN)
viatheLANportasshownonthefollowingillustra-
tionandsetupthenetworksettings.
Onlysupportswirednetworkconnection.
Aftermakingaphysicalconnection,asmall
numberofhomenetworksmayrequirethedisplay
networksettingstobeadjusted.Formosthome
networks,thedisplaywillconnecttoautomatically
withoutanyadjustments.
Fordetailinformation,contactyourinternetpro-
viderorroutermanual.
Tosetupthenetworksettings:(Evenifyourdis-
playhasalreadyconnectedautomatically,running
setupagainwillnotharmanything),
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrolltoNET-
WORKandpressOK.
3 PresstheNavigationbuttonstoselectNet-
work SettingandpressOK.
4 IfyoualreadysetNetworkSetting,select
Resetting.Thenewconnectionsettingsresets
thecurrentnetworksettings.
5 SelectIP Auto SettingorIP Manual Setting.
-IfselectingIP Manual Setting,pressthe
NavigationandNumberbuttons.IPaddress-
eswillneedtobeinputmanually.
-IP Auto Setting:Selectthisifthereisa
DHCPserver(Router)onthelocalareanet-
work(LAN)viawiredconnection,thedisplay
willautomaticallybeallocatedanIPaddress.
Ifyou’reusingabroadbandrouterorbroad-
bandmodemthathasaDHCP(Dynamic
HostConfigurationProtocol)serverfunction.
TheIPaddresswillautomaticallybedeter-
mined.
6 Whenyouarefinished,pressEXIT.
Networksettingmenuwillnotbeavaila-
bleuntilthedisplayconnectedtophysical
network.
Sincetherearevariousconnectionmeth-
ods,pleasefollowthespecificationsof
yourtelecommunicationcarrierorinternet
serviceprovider.
CAUTION
Donotconnectamodularphonecableto
theLANport.
Sincetherearevariousconnectionmeth-
ods,pleasefollowthespecificationsof
yourtelecommunicationcarrierorinternet
serviceprovider.
CAUTION
LAN
LAN WAN
ETHERNET
@
Internet
Backoftheproduct.
Cablemodem
Router
background
23
ENG
ENGLISH
ENTERTAINMENT
Tips for Network setting
UseastandardLANcablewiththisdisplay.
Cat5orbetterwithaRJ45connector.
Manynetworkconnectionproblemsduringset
upcanoftenbefixedbyre-settingtherouter
ormodem.Afterconnectingthedisplaytothe
homenetwork,quicklypoweroffand/ordiscon-
nectthepowercableofthehomenetwork
routerorcablemodem.Thenpoweronand/or
connectthepowercableagain.
Dependingontheinternetserviceprovider
(ISP),thenumberofdevicesthatcanreceive
internetservicemaybelimitedbytheapplica-
bletermsofservice.Fordetails,contactyour
ISP.
LGisnotresponsibleforanymalfunctionofthe
displayand/ortheinternetconnectionfeature
duetocommunicationerrors/malfunctionsas-
sociatedwithyourinternetconnection,orother
connectedequipment.
LGisnotresponsibleforproblemswithinyour
internetconnection.
Youmayexperienceundesiredresultsifthe
networkconnectionspeeddoesnotmeetthe
requirementsofthecontentbeingaccessed.
Someinternetconnectionoperationsmaynot
bepossibleduetocertainrestrictionssetby
theInternetserviceprovider(ISP)supplying
yourInternetconnection.
AnyfeeschargedbyanISPincluding,without
limitation,connectionchargesareyourrespon-
sibility.
A10Base-Tor100Base-TXLANportis
requiredwhenusingawiredconnectiontothis
display.Ifyourinternetservicedoesnotallow
forsuchaconnection,youwillnotbeableto
connectthedisplay.
ADSLmodemisrequiredtouseDSLservice
andacablemodemisrequiredtousecable
modemservice.Dependingontheaccess
methodofandsubscriberagreementwithyour
ISP,youmaynotbeabletousetheinternet
connectionfeaturecontainedinthisdisplayor
youmaybelimitedtothenumberofdevices
youcanconnectatthesametime.(IfyourISP
limitssub-scriptiontoonedevice,thisdisplay
maynotbeallowedtoconnectwhenaPCis
alreadyconnected.)
Theuseofa“Router”maynotbeallowedorits
usagemaybelimiteddependingonthepoli-
ciesandrestrictionsofyourISP.Fordetails,
contactyourISPdirectly.
Network Status
1 PressMENUtoaccessthemainmenus.
2 PresstheNavigationbuttonstoscrolltoNET-
WORKandpressOK.
3 PresstheNavigationbuttonstoselectNet-
work Status.
4 PressOKtocheckthenetworkstatus.
5 Whenyouarefinished,pressEXIT.
Option Description
Setting Returntothenetworksettingmenu.
Test
Testthecurrentnetworkstatusafterset-
tingthenetwork.
Close Returntothepreviousmenu.
IfyouwanttoaccesstheInternetdirectly
onyourdisplay,theinternetconnection
shouldalwaysbeon.
IfyoucannotaccesstheInternet,check
thenetworkconditionsfromaPConyour
network.
WhenyouuseNetwork Setting,check
theLANcableorcheckifDHCPinthe
routeristurnedon.
Ifyoudonotcompletethenetworkset-
tings,thenetworkmaynotworkproperly.
NOTE
background
24
ENG
ENGLISH
ENTERTAINMENT
Tips for using USB storage devices
OnlyaUSBstoragedeviceisrecognizable.
IftheUSBstoragedeviceisconnected
throughaUSBhub,thedeviceisnotrecog-
nizable.
AUSBstoragedeviceusinganautomatic
recognitionprogrammemaynotberecog-
nized.
AUSBstoragedevicewhichusesitsown
drivermaynotberecognized.
TherecognitionspeedofaUSBstorage
devicemaydependoneachdevice.
Pleasedonotturnoffthedisplayorunplug
theUSBdevicewhentheconnectedUSB
storagedeviceisworking.Whensuchdevice
issuddenlyseparatedorunplugged,the
storedfilesortheUSBstoragedevicemay
bedamaged.
PleasedonotconnecttheUSBstorage
devicewhichwasartificiallymaneuveredon
thePC.Thedevicemaycausetheproductto
malfunctionorfailtobeplayed.Neverforget
touseonlyaUSBstoragedevicewhichhas
normalmusicfiles,imagefilesormoviefiles.
PleaseuseonlyaUSBstoragedevicewhich
wasformattedasaFAT32filesystem,NTFS
filesystemprovidedwiththeWindowsop-
eratingsystem.Incaseofastoragedevice
formattedasadifferentutilityprogramwhich
isnotsupportedbyWindows,itmaynotbe
recognized.
PleaseconnectpowertoaUSBstorage
device(over0.5A)whichrequiresanexternal
powersupply.Ifnot,thedevicemaynotbe
recognized.
PleaseconnectaUSBstoragedevicewith
thecableofferedbythedevicemaker.
SomeUSBstoragedevicesmaynotbesup-
portedoroperatedsmoothly.
FilealignmentmethodofUSBstorage
deviceissimilartoWindowXPandfilename
canrecognizeupto100Englishcharacters.
Besuretobackupimportantfilessincedata
storedinaUSBmemorydevicemaybe
damaged.Wewillnotberesponsibleforany
dataloss.
Connecting USB Storage Devices
ConnectUSBstoragedevicessuchasaUSB
flashmemory,externalharddrivetothedisplay
andusemultimediafeatures(See"BrowsingFiles"
onpage25).
ConnectaUSBflashmemoryorUSBmemory
cardreadertotheDisplayasshownonthefollow-
ingillustration.TheMymediascreenappears.
or
DonotturnthedisplayofforremoveaUSB
storagedevicewhileEMF(mymedia)Menu
isactivated,asthiscouldresultinlossof
filesordamagetotheUSBstoragedevice.
BackupyourfilessavedonaUSBstorage
devicefrequently,asyoumayloseordam-
agethefilesandthismaybenotcoveredby
thewarranty.
CAUTION
background
25
ENG
ENGLISH
ENTERTAINMENT
IftheUSBHDDdoesnothaveanexternal
powersource,theUSBdevicemaynotbe
detected.Sobesuretoconnecttheexternal
powersource.
-Pleaseuseapoweradaptorforanexternal
powersource.WedonotguaranteeanUSB
cableforanexternalpowersource.
IfyourUSBmemorydevicehasmultiple
partitions,orifyouuseaUSBmulti-card
reader,youcanuseupto4partitionsorUSB
memorydevices.
IfaUSBmemorydeviceisconnectedtoa
USBmulti-cardreader,itsvolumedatamay
notbedetected.
IftheUSBmemorydevicedoesnotwork
properly,disconnectandreconnectit.
HowfastaUSBmemorydeviceisdetected
differsfromdevicetodevice.
IftheUSBisconnectedinStandbyMode,
specificharddiskwillautomaticallybe
loadedwhenthedisplayisturnedon.
Therecommendedcapacityis1TBorless
foraUSBexternalharddiskand32GBor
lessforUSBmemory.
Anydevicewithmorethantherecommend-
edcapacitymaynotworkproperly.
IfaUSBexternalharddiskwitha“Energy
Saving”functiondoesnotwork,turnthe
harddiskoffandonagaintomakeitwork
properly.
USBstoragedevicesbelowUSB2.0are
supportedaswell.Buttheymaynotwork
properlyinthemovielist.
Maximumof999foldersorfilescanberec-
ognizedunderonefolder.
ItisrecommendedtouseacertifiedUSB
storagedeviceandcable.Otherwise,aUSB
storagedevicemaynotbedetectedora
playbackerrormayoccur.
OnlyaUSBmemorystickcanbeusedto
playbackthefilesdistributedandstored
bySuperSignManager.AUSBharddiskor
multi-cardreaderwillnotwork.
OnlyanFAT32fileformattedstoragedevice
canplaybackthefilesdistributedandstored
bySuperSignmanager.
AUSB3.0storagedevicemaynotwork.
Browsing Files
Accessthephoto,music,ormovielistsandbrowse
files.
1
ConnectaUSBstoragedevice.
2
PressMENUtoaccessthemainmenus.
3
PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
4
PresstheNavigationbuttonstochoose
fromMovie List, Photo List,Music Listor
Contents ListandpressOK.
No. Description
1
Movestoupperlevelfolder
2
Currentpage/Totalpages
3
Correspondingbuttonsonthe
remotecontrol
4
Current page/ total pages of contents
underthefolderfocusedon
1
5
Contentsunderthefolderfocusedon
1
Buttom Description
Green
Button
Pressthegreenbuttontotogglebetween
Photo List -> Music List,Music List ->
Contents List,Contents List -> Movie
List or Movie List -> Photo List.
Yellow
Button
Amethodtoviewin5largethumbnailor
simplelist.
Blue
Button
ConverttoMarkMode.
MovieList MusicListPhotoList ContentsList
Page1/1
PhotoList
Drive1
Page1/1
USBExternal
001
010 011 012 013 014 015
002 003 004 005 006 007
008
009
ToMusicList
ChangeNumbers
MarkMode
Exit
View
Move
11
2
3
4
5
P PageChange
background
26
ENG
ENGLISH
ENTERTAINMENT
Supported file format
Type Supported file format
Movie DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV,TS,T
RP,TP,ASF,WMV,FLV)
Movie(*.mpg/*.mpeg/*dat/*.ts/*.trp/*.tp/*.vob/*.
mp4/*.mov/*.mkv/*.divx/*.avi/*.asf/*.wmv/*.flv/*.
avi(motion-jpeg)/*.
mp4(motion-jpeg)/*.mkv(motion-jpeg))supporting
file
Video format:DivX3.11,DivX4.12,DivX5.x,
DivX6,Xvid1.00,Xvid1.01,Xvid1.02,Xvid1.03,
Xvid1.10beta-1/beta-2,
Mpeg-1,Mpeg-2,Mpeg-4,H.264/AVC,VC1,
JPEG,SorensonH.263
Audio format:DolbyDigital,AAC,Mpeg,MP3,
LPCM,HE-AAC,ADPCM,WMA
Bit rate:within32kbpsto320kbps(MP3)
External Subtitle format:*.smi/*.srt/*.sub
(MicroDVD,Subviewer1.0/2.0)/*.ass/*.ssa/*.
txt(TMPlayer)/*.psb(PowerDivX)
Internal Subtitle format :only,XSUB(Itisthe
subtitleformatusedinDivX6files)
Photo JPEG
Baseline:64x64to15360x8640
Progressive:64x64to1920x1440
YoucanplayJPEGfilesonly.
Non-supportedfilesaredisplayedintheform
ofpredefinedicon.
Only 3D Models
File
Extensions
Item Profile
2D jpeg
jpg
jpe
supported
fileformat
SOF0:
baseline
SOF1:
Extend
Sequential
SOF2:
Progressive
photosize
Min:64x64
Max-Normal
Type:
15360(W)x
8640(H)
Progressive
Type:
1920(W)x
1440(H)
3D mpo supported
fileformat
mpo
photosize
4:3size:
3,648x2,736
2,592x1,944
2,048x
1,536
3:2size:
3,648x
2,432
Music MP3
Bitrate32to320
SamplingrateMPEG1Layer3:32kHz,44.1
kHz,48kHz
SamplingrateMPEG2Layer3:16kHz,22.05
kHz,24kHz
SamplingrateMPEG2.5Layer3:8kHz,
11.025kHz,12kHz
Content
(when
using
SuperSign
Manager)
FileExtensions:*.cts/*.cse
Movie
File Extensions:*.mpg/*.mpeg/*.dat/*.ts/*.
trp/*.tp/*.vob/*.mp4/*.mov/*.mkv/*.avi/*.asf/*.
wmv/*.avi(motionJPEG)/*.mp4(motionJPEG)/*.
mkv(motionJPEG)
Video format:MPEG1,MPEG2,MPEG4,H.264/
AVC,DivX3.11,DivX4.12,DivX5.x,DivX6,
Xvid1.00,Xvid1.01,Xvid1.02,Xvid1.03,Xvid
1.10-beta1/2,JPEG,VC1(WVC1/WMV3)
Audio format:MP2,MP3,DolbyDigital,LPCM,
AAC,HE-AAC,LPCM,ADPCM,WMA,MP3
File
Extensions
Item Profile
Photo JPEG
JPG
PNG
BMP
supported
fileformat
SOF0:
baseline
SOF1:
Extend
Sequential
SOF2:
Progressive
Photosize
Min:64x64
MaxType:
1366x768
Music MP3 Bitrate 32kbpsto320
kbps
Sampling
rate
32kHz,44.1
kHz,48kHz
(MPEG1L3)
16kHz,22.05
kHz,24kHz
(MPEG2L3)
8kHz,11.025
kHz,12kHz
(MPEG2.5L3)
background
27
ENG
ENGLISH
ENTERTAINMENT
Viewing Movies
Playvideofilesondisplay.Yourdisplayshowsall
ofthevideofilessavedinaUSBstoragedeviceor
sharedfolderonaPC.
1 PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
2 PresstheNavigationbuttonstoscrolltoMovie
ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
4 PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Menu Description
Play Marked Playtheselectedmoviefile.
Onceamoviefilefinishesplaying,
thenextselectedonewillbeplayed
automatically.
Mark All Markallmoviefilesonthescreen.
Unmark All Deselectallmarkedmoviefiles.
Exit Mark
Mode
ExittheMarkMode.
5 Playamovie.
6 Controlplaybackbyusingthefollowingbuttons.
Button Description
r
Stopstheplayback
s
Playsavideo
t
Pausesorresumestheplayback
v
Scansbackwardinafile
w
Scansforwardinafile
MENU ShowtheOptionmenu.
HIDE Hidethemenuonthefull-sizedscreen.
EXIT ReturntoMovie List.
< or >
Skipstospecificpointsinafiledur-
ingplayback.Thetimeofaspecific
pointwillappearonthestatusbar.In
somefiles,thisfunctionmaynotwork
properly.
ENERGY
SAVING( )
PresstheENERGY SAVINGbutton
repeatedlytoincreasethebrightness
ofyourscreen.
Page1/1
MovieList
USB1USBDrive
Drive1
Page1/1
ToPhotolist
ChangeNumbers
MarkMode
Exit
003
001 002
004
005 006
Play
Move
Page ChangeP
01:02:30/02:30:25
Option
MENU
Hide
Exit
Non-supportedfilesaredisplayedthepreview
imagebyicononly .
Abnormal files are displayed in the form of
bitmap .
NOTE
Page1/1
MovieList
USB1USBDrive
Drive1
Page1/1
PlayMarked
MarkAll
UnmarkAll
Exit
003
001 002
004
005 006
MarkMode
ExitMarkMode
051.Apple_......
02:30:25
Mark
Move
Page ChangeP
background
28
ENG
ENGLISH
ENTERTAINMENT
Video options
1 PressMENUtoaccessthePop-Upmenus.
2 PresstheNavigationbuttonstoscrolltoSet
Video Play., Set Video. or Set Audio. and
pressOK.
Tips for using playing video files
Someuser-createdsubtitlesmaynotwork
properly.
Somespecialcharactersarenotsupported
insubtitles.
HTMLtagsarenotsupportedinsubtitles.
Subtitlesinlanguagesotherthanthesup-
portedlanguagesarenotavailable.
Thescreenmaysuffertemporaryinterrup-
tions(imagestoppage,fasterplayback,etc.)
whentheaudiolanguageischanged.
Adamagedmoviefilemaynotbeplayed
correctly,orsomeplayerfunctionsmaynot
beusable.
Moviefilesproducedwithsomeencoders
maynotbeplayedcorrectly.
Ifthevideoandaudiostructureofrecorded
fileisnotinterleaved,eithervideooraudiois
outputted.
HDvideoswithamaximumof
1920x1080@25/30Por1280x720@50/60P
aresupported,dependingontheframe.
Videoswithresolutionshigherthan
1920X1080@25/30Por1280x720@50/60P
maynotworkproperlydependingonthe
frame.
Moviefilesotherthanthespecifiedtypesand
formatsmaynotworkproperly.
Maxbitrateofplayablemoviefileis20Mbps.
(only,MotionJPEG:10Mbps)
Wedonotguaranteesmoothplaybackof
profilesencodedlevel4.1orhigherinH.264/
AVC.
DTSAudiocodecisnotsupported.
Amoviefilemorethan30GBinfilesizeis
notsupportedforplayback.
ADivXmoviefileanditssubtitlefilemustbe
locatedinthesamefolder.
Avideofilenameanditssubtitlefilename
mustbeidenticalforittobedisplayed.
PlayingavideoviaaUSBconnectionthat
doesn’tsupporthighspeedmaynotwork
properly.
FilesencodedwithGMC(GlobalMotion
Compensation)maynotbeplayed.
WhenyouarewatchingthemoviebyMovie
Listfunction,youcanadjustanimageby
EnergySavingkeyontheremotecontrol.
Usersetupforeachimagemodedoesnot
operate.
OptionvalueschangedinMovie Listdoes
notaffectPhoto ListandMusic List.
OptionvaluechangedinPhoto ListandMu-
sic ListarechangedlikewiseinPhoto List
andMusic ListexcludingMovie List.
Whenreplayingthevideofileafterstopping,
youcanplayfromwhereitstoppedprevi-
ously.
NOTE
background
29
ENG
ENGLISH
ENTERTAINMENT
Repeat Turnon/offrepeatfunctionof
movieplayback.Whenturnedon,the
filewithinthefolderwillbeplayed
backrepeatedly.Evenwhenthe
repeatedplayback
isturnedoff,itcanruntheplaybackif
thefilenameissimilartotheprevious
file.
Code Page Support Language
Latin1 English,Spanish,French,
German,Italian,Swedish,Finnish,
Dutch,Portuguese,Danish,Roma-
nian,Norwegian,Albanian,Gaelic,
Welsh,Irish,Catalan,Valencian
Latin2 Bosnian,Polish,Croatian,Czech,
Slovak,Slovenian,Serbian,
Hungarian
Latin4 Estonian,Latvian,Lithuanian
Cyrillic Bulgarian,Macedonian,Russian,
Ukrainian,Kazakh
Greek Greek
Turkish Turkish
Korean Korean
WhenyouselecttheSet Video Play,,
1 PresstheNavigationbuttonstoscrolltoshow
thePicture Size, Audio Language, Subtitle
LanguageorRepeat.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
Menu Description
Picture Size Selectsyourdesiredpicture
formatduringmovieplay.
Audio
Language
ChangestheLanguageGroupofthe
audioduringmovieplay.Files
withasingleaudiotrackcannotbe
selected.
Subtitle Lan-
guage
Turnon/offthesubtitle.
Language ActivatedforSMIsubtitleand
canselectthelanguagewithinthe
subtitle.
Code Page Canselectthefontforsubtitle.
Whensettodefault,samefontas
generalmenuwillbeused.
Sync Adjuststhetimesynchronisationof
thesubtitlefrom-10secsto+10secs
bystepsof0.5secsduringmovie
play.
Position Changesthepositionofthe
subtitleeitherupordownduring
movieplay.
Size SelectsyourdesiredSubtitlesize
duringmovieplay.
Only10,000ofsyncblockscanbesupported
withinthesubtitlefile.
Whenplayingavideo,youcanadjustthe
PictureSizebypressingtheRATIObutton.
Subtitlesinyourlanguageareonlysup-
portedwhentheOSDmenuisalsointhis
language.
Thecodepageoptionsmaybedisabledde-
pendingonthelanguageofthesubtitlefiles.
Selecttheappropriatecodepageforthe
subtitlefiles.
NOTE
background
30
ENG
ENGLISH
ENTERTAINMENT
WhenyouselecttheSet Video,,
1 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
WhenyouselecttheSet Audio,,
1 PresstheNavigationbuttonstoscrolltoshow
theSound Mode, Clear Voice II orBalance.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
Viewing Photos
ViewimagefilessavedinaUSBstoragedevice.
Thedisplaysonthescreenmaydifferfromthe
model.
1 PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
2 PresstheNavigationbuttonstoscrolltoPhoto
ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
4 PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
5 Viewphotos.
Menu Description
View Marked Displaytheselectedphotofile.
Mark All Markallphotofilesonthescreen.
Unmark All Deselectallmarkedphotofiles.
Exit Mark Mode ExittheMarkMode.
Non-supportedfilesaredisplayedthepre-
viewimagebyicononly .
Abnormalfilesaredisplayedintheformof
bitmap .
NOTE
Page1/1
PhotoList
Drive1
Page1/1
USB1USBDrive
001
010 011 012 013 014 015
002 003 004 005 006 007
008
009
ToMusicList
ChangeNumbers
MarkMode
Exit
Page1/1
PhotoList
Drive1
Page1/1
USB1USBDrive
001
010 011 012 013 014 015
002 003 004 005 006 007
008
009
MarkMode
ViewMarked
MarkAll
UnmarkAll
Exit
ExitMarkMode
View
Move
Page ChangeP
Mark
Move
Page ChangeP
background
31
ENG
ENGLISH
ENTERTAINMENT
Photo options
1 PressMENUtoshowtheOptionmenus.
2 Press the Navigation buttons to scroll to Set
Photo View., Set Video. or Set Audio. and
pressOK.
Option Description
Slideshow Startsorstopsaslideshowwithselected
photos.
Iftherearenoselectedphotos,allpho-
tossavedinthecurrentfolderdisplay
duringaslideshow.
SelectOptiontosetthespeedandview
modeoftheslideshow.
BGM Turnsthebackgroundmusiconoroff.
Tosetthebackgroundmusicfolder,
selectOption.
YoucanadjustOptionbyMENUbutton
ontheremotecontrol.
Rotate
Rotatesphotosclockwise(90°,180°,
270°,360°).
Zoom
Enlargestheimageto200%or400%.
NumberofselectedphotosOptions
Using photo options
Usethefollowingoptionswhileviewingphotos.
The supported photo size is
limited. You cannot rotate a
photo if the resolution of the
rotatedwidthislargerthanthe
supportedresolutionsize.
NOTE
Option values changed in Movie List does
notaffectPhoto ListandMusic List.
OptionvaluechangedinPhoto ListandMu-
sic ListarechangedlikewiseinPhoto List
andMusic ListexcludingMovie List.
NOTE
ENER-
GY SAVING
PresstheENERGY SAVINGbutton
repeatedlytochangethebrightnessof
yourscreen.
Option
Slide Speed: Selects a slideshow
speed(Fast,Medium,Slow).
TransitionEffect: Settheviewmode
oftheslideshow.
BGM:Selectsamusicfolderforthe
backgroundmusic.
Hide
Hidestheoptionwindow.
Todisplaytheoptions,pressOK.
EXIT
ReturntoPhoto List.
2/13
Slideshow BGM
Hide
Option
MENU
Exit
Youcannotchangethemusic
folder while the background
musicisplaying.
You can only select the MP3
foldersavedonthedevicethat
currentlydisplaysthephoto.
NOTE
NOTE
Zoom to 200% or 400% only
work for image of 1372×772
pixelsizeorlarger.
For image of 960×540 pixel
size or larger, only zoom to
400%worksproperly.
background
32
ENG
ENGLISH
ENTERTAINMENT
WhenyouselecttheSet Photo View,
1 PresstheNavigationbuttonstoscrolltoselectSlide Speed,Transition Effect or BGM.
2 PresstheNavigationbuttonstoscrolltomakeappropriateadjustments.
Transition Effect Option
Option Description
Sliding Pushesthecurrentslideoutofviewasitplaystothenextslide.
Stairs Pushesthecurrentslideinastaircaseshapeasitplaystothenextslide.
Door Open
/Close
Pushesthecurrentslidelikeopeningorclosingthedoorasitplaystothenextslide.
Shutter Pushesthecurrentslidelikedrawingorpullingdowntheblindasitplaystothenextslide
Fade In Fadestheslideoutslowlybeforeplayingtothenextslide.
background
33
ENG
ENGLISH
ENTERTAINMENT
WhenyouselecttheSet Video,
1 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
WhenyouselecttheSet Audio,
1 PresstheNavigationbuttonstoscroll to show
theSound Mode, Clear Voice II orBalance.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
5 Playmusic.
Listening to Music
1 PresstheNavigationbuttonstoscrolltoMy Me-
diaandpressOK.
2 PresstheNavigationbuttonstoscrolltoMusic
ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoafolder
youwantandpressOK.
4 Pressthe Navigation buttons to scrollto a file
youwantandpressOK.
Menu Description
Play Marked Displaytheselectedmusicfile.
Mark All Markallmusicfilesonthescreen.
Unmark All Deselectallmarkedmusicfiles.
Exit Mark Mode ExittheMarkMode.
Page1/1
MusicList
Drive1
Page1/1
001.-B01.mp3
00:00
002.-B02.mp3
00:00
003.B03.mp3
00:00
004.-B04.mp3
00:00
005.-B05.mp3
00:00
USB1USBDrive
ToMovieList
ChangeNumbers
MarkMode
Exit
Page1/1
MusicList
Drive1
Page1/1
001.-B01.mp3
00:00
002.-B02.mp3
00:00
003.B03.mp3
00:00
004.-B04.mp3
00:00
005.-B05.mp3
00:00
USB1USBDrive
PlayMarked
MarkAll
UnmarkAll
Exit
MarkMode
ExitMarkMode
Play
Move
Page ChangeP
Mark
Move
Page ChangeP
background
34
ENG
ENGLISH
ENTERTAINMENT
Timeelapsed/Duration
002.B02.mp3
00:31/04:04
filename
6 Controlplaybackbyusingthefollowingbuttons.
Page1/1
MusicList
Drive1 Page1/1
3file(s)Marked
004.-B04.mp3
00:00
005.-B05.mp3
00:00
006.-B06.mp3
00:00
007.-B07.mp3
00:00
008.-B08.mp3
00:00
005.-B05.mp3
02:30/03:25
Hide Exit
Option
MENU
PlaywithPhoto
Button Description
Stopsplayingbackthefileandmoves
backtothemusiclist.
Playsamusicfile
Pausesorresumesplayback
Skipstothenextfile
Skipstothepreviousfile
or
Whenplaying,
Whenyoupressthevbutton,theprevi-
ousmusicfilewillbeplayed.
Whenyoupressthewbutton,thenext
musicfilewillbeplayed.
Green
Button
Startplayingtheselectedmusicfilesand
thenmovetothePhoto List.
ENERGY
SAVING( )
Press the ENERGY SAVING button re-
peatedly to change the brightness of
yourscreen.
MENU ShowtheOptionmenu.
Hide
Hidestheoptionwindow.
Todisplaytheoptions,pressOK.
EXIT
When you press the EXIT button while
the Music player is displayed, only the
musicwillbestoppedandtheplayerwill
notreturntonormalviewing.
When you press the EXIT button while
themusicisstoppedorwhilethemusic
playerishidden,theplayerwillreturnto
normalviewing.
< or >
When using the < or > button during
playbackacursorindicatingtheposition
canbeplayed.
Tips for playing music files
ThisunitcannotsupporttheID3Tag
embeddedMP3files.
Non-supportedfilesaredisplayedthepre-
viewimagebyicononly .
Abnormalfilesaredisplayedintheformof
bitmap .
Adamagedorcorruptedmusicdoesnotplay
butdisplays00:00inplaytime.
Amusicdownloadedfromapaidservicewith
copyrightprotectiondoesnotstartbutdis-
playsinappropriateinformationinplaytime.
IfyoupressOK, buttons,screensaveris
stopped.
ThePLAY( ),Pause( ), , , buttons
ontheremotecontrolarealsoavailablein
thismode.
Youcanusethe buttontoselectthenext
musicandthe buttontoselecttheprevi-
ousmusic.
NOTE
background
35
ENG
ENGLISH
ENTERTAINMENT
1 PressMENUtoaccessthePop-Upmenus.
2 PresstheNavigationbuttonstoscrolltoSet Au-
dio Play. or Set Audio. andpressOK.
Music options
WhenyouselecttheSet Audio Play.,
1 PresstheNavigationbuttonstoscrolltoselect
theRepeatorRandom.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
WhenyouselecttheSet Audio,,
1 PresstheNavigationbuttonstoscrolltoselect
theSound Mode, Clear Voice II orBalance.
2 PresstheNavigationbuttonstoscrolltomake
appropriateadjustments.
Option values changed in Movie List does
notaffectPhoto ListandMusic List.
OptionvaluechangedinPhoto ListandMu-
sic ListarechangedlikewiseinPhoto List
andMusic ListexcludingMovie List.
NOTE
WhileplayingmediafilesfromContentsList,
onlytheBACK,EXITorVolumebuttonare
available.SelectingtheBACKorEXITbutton
stopsplayingmediafilesandreturnstothe
screenviewmode.
IfthereistheAutoPlayfolderintheUSB
deviceanditsfilesareinsupportedformats,
theycanbeplayedbackautomaticallywhen
theUSBdeviceisconnectedtothemonitor.
NOTE
Viewing the Contents List
PlaysbackthestoredfilesusingtheExportoption
inSuperSignManager.
1 PresstheNavigationbuttonstoscrolltoMy
MediaandpressOK.
2 PresstheNavigationbuttonstoscrolltoCon-
tents ListandpressOK.
3 PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
4 PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Page1/1
ContentsList
Drive1
Page1/1
test1.cts
07/01/2011
test2.cts
07/01/2011
test3.cts
07/01/2011
test4.cts
07/01/2011
test5.cts
07/01/2011
USB1USBDrive
ToMovieList
ChangeNumbers
Exit
Play
Move
Page ChangeP
background
36
ENG
ENGLISH
ENTERTAINMENT
DivX® VOD Guide
DivX® VOD Registration
In order to play purchased or rented DivX® VOD
contents, you should register your device with 10
digit DivX registration code from your device at
www.divx.com/vod.
1 PressMENUtoaccessthemainmenus.
2 Press the Navigation buttons to scroll to MY
MEDIAandpressOK.
3 PresstheBluebutton.
4 Press the Navigationbuttons to scrollto DivX
Reg. CodeandpressOK.
5 Viewtheregistrationcodeofyourdisplay.
6 Whenyouarefinished,press EXIT.
When you return to the previous menu, press
BACK.
Youmustregisteryourdeviceto
playDivX protectedvideos.
Registrationcode:**********
Registerathttp://vod.divx.com
Close
Whileyouarecheckingtheregistration
code,somebuttonsmaynotwork.
IfyouusetheDivXregistrationcodeofan-
otherdevice,youcannotplaytherentedor
purchasedDivXfile.Makesuretousethe
DivXregistrationcodeassignedtoyourTV.
Thevideooraudiofilesthatarenotcon-
vertedbythestandardDivXcodecmaybe
corruptedornotbeplayed.
TheDivXVODcodeallowsyoutoactivate
upto6devicesunderoneaccount.
NOTE
DivX® VOD Deregistration
Youshouldderegisteryourdevicewith8digitDivX
deregistrationcodefromyourdeviceatwww.divx.
com/vod.
1 PressMENUtoaccessthemainmenus.
2 Press the Navigation buttons to scroll to MY
MEDIAandpressOK.
3 PresstheBluebutton.
4 PresstheNavigationbuttonstoscrolltoDeacti-
vationandpressOK.
5 Press the Navigation buttons to select Yes to
confirm.
Deregistrationcode:
********
Deregisterathttp://vod.divx.com
Continuewithregistration?
Yes No
6 Whenyouarefinished,press EXIT.
When you return to the previous menu, press
BACK.
Oncethederegistrationisexecuted,you
mustregisteryourdeviceagaintosee
DivX®VODcontents.
NOTE
background
37
ENG
ENGLISH
ENTERTAINMENT
Using PIP/PBP
DisplaysvideosorphotosstoredonaUSBdevice
onasinglemonitorbydividingitintothemainand
subscreens.(Seep.48)
1 PresstheMENUbuttontomovetoOPTION
andpressOK.
2 PressPIP/PBPtoselectPIPorPBPandthen
pressOK.
3 SelectMovieListorPhoto ListfromMy
Media.(WithPIP/PBPselected,theMusic
ListandContents Listaredeactivated.)
Move
PIP/PBP
Off
PIP
PBP
Pre.
Mode
Position
Size
4 SelectafileyouwantandthenpressOK.
5 SelectthePIPorPBPiconfromtheplaylist.
01:02:30/02:30:25
Option
MENU
Hide
Exit
< Movie List >
< Photo List >
6 SelecteitherMainorSubforsound.Youmust
toselecttheoutputsoundbeforerunningthe
PIPorPBPfunction.
7 Thesubscreenisdisplayedonthemain
screen.
Selectthesoundpath.
Main Sub
MovieList MusicListPhotoList ContentsList
Page1/1
MovieList
USB1USBDrive
Drive1
Page1/1
ToPhotolist
ChangeNumbers
MarkMode
Exit
003
001 002
004
005 006
Play
Move
Page ChangeP
2/13
Slideshow BGM
Hide
Option
MENU
Exit
background
38
ENG
ENGLISH
CUSTOMIZING SETTINGS
CUSTOMIZING SETTINGS
Accessing the Main Menus
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltooneofthefollowingmenusand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyouwant
andpressOK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
P
A
G
E
MARK
ARC
OK
S.MENU
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
OPTION
NETWORK
AUDIO TIME
MY MEDIA
PICTURE (Seep.39)
Adjuststheimagesize,
quality,oreffect.
AUDIO(Seep.42)
Adjuststhesoundquality,
effect,orvolumelevel.
NETWORK(Seep.50)
Setsupthenetwork
setting.
OPTION (Seep.44)
Customizesthegeneral
settings.
TIME(Seep.43)
Setsthetime,date,or
Timerfeature.
MY MEDIA(Seep.24)
Displayandplaymovie,
photoandmusiccontent
storedonyourUSB
background
39
ENG
ENGLISH
CUSTOMIZING SETTINGS
PICTURE Settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoPICTUREand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK. 
Theavailablepicturesettingsaredescribedinthefollowing:
Setting Description
Aspect Ratio Changestheimagesizetoviewimagesatitsoptimalsize(Seep.19).
Energy
Saving
Setstoautomaticallyadjustthescreenbrightnesscorrespondingtothesurroundings.
Level
Auto Adjustautomatically
Off DisablesEnergySavingfunction.
Minimum/
Medium/
Maximum
Selectsthebrightnesslevelofthebacklight.
ScreenOff Thescreenturnsoffin3seconds.
Smart Energy
Saving
Adjuststhebacklightandcontrastdependingonthescreenbrightness.
Level
Off DisablestheSmartEnergySavingfunction.
On EnablestheSmartEnergySavingfunctiontosavepowerconsumptionasmuch
asthevaluesetinthesmartenergysavingrate.
Picture Mode SelectsoneofthepresetimageorcustomizesoptionsineachmodeforthebestMonitorsetscreen
performance.Youarealsoabletocustomizeadvancedoptionsofeachmode.
TheavailablepresetpicturemodesvarydependingontheMonitorset.
Mode
Vivid Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,
brightness,Color,andsharpness.
Standard Adjuststheimageforthenormalenvironment.
Cinema Optimizesthevideoimageforacinematiclooktoenjoymoviesasifyouareina
movietheater.
Sport Optimizesthevideoimageforhighanddynamicactionsbyemphasizingprimary
Colourssuchaswhite,grass,orskyblue.
Game OptimizesthevideoimageforafastgamingscreensuchasPCsorgames.
Move
OK
ꔋ
•AspectRatio :16:9
•
EnergySaving :Off
•SmartEnergySaving :Off
•PictureMode :Standard
•Backlight 70
•Contrast 100
•Brightness 50
•Sharpness 50
•Color 60
•Tint 0
•ColorTemp. 0
•AdvancedControl
•PictureReset
•Screen
R G
W C
background
40
ENG
ENGLISH
CUSTOMIZING SETTINGS
Ifthe'Picture Mode'settinginthePicturemenuissettoVivid, Standard, Cinema, SportorGame
thesubsequentmenuswillbeautomaticallyset.
YoucannotadjustcolorandtintintheRGB-PC/HDMI-PCmode.
WhenusingtheSmartEnergySavingfunction,thescreenmaylooksaturatedinthewhiteareaofa
stillimage.
IfEnergySavingissettoMinimum,Medium,orMaximum,theSmartEnergySavingfunctionis
disabled.
Picture Mode options
Setting Description
Backlight AdjuststhebrightnessofthescreenbycontrollingtheLCDbacklight.Ifyoudecreasethe
brightnesslevel,thescreenbecomesdarkerandthepowerconsumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthegradientofthevideosignal.YoumayuseContrastwhenthe
brightpartofthepictureissaturated.
Brightness Adjuststhebaselevelofthesignalinthepicture.YoumayuseBrightnesswhenthedarkpart
ofthepictureissaturated.
Sharpness Adjuststhelevelofcrispnessintheedgesbetweenthelightanddarkareasofthepicture.
Thelowerthelevel,thesoftertheimage.
Color Adjustsintensityofallcolors.
Tint Adjuststhebalancebetweenredandgreenlevels.
Color Temp . SettowarmtoenhancehotterColorssuchasred,orsettocooltomakepicturebluish.
Advanced Control Customizestheadvancedoptions.RefertotheAdvancedimageoptions.(Seep.41).
Picture Reset Restorestheoptionstothedefaultsetting.
Setting Description
SCREEN
(In RGB
Mode Only)
CustomizesthePCdisplayoptionsinRGBmode.
Option
Resolution Selectsaproperresolution.See“CustomizingPCdisplayoptions”.
AutoConfigure Setstoadjustthescreenposition,clock,andphaseautomatically.
Thedisplayedimagemaybeunstableforafewsecondswhiletheconfigurationis
inprogress.
Position/Size/
Phase
Adjuststheoptionswhenthepictureisnotclear,especiallywhencharactersare
shaky,aftertheautoconfiguration.
Reset Restorestheoptionstothedefaultsetting.
NOTE
background
41
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Dynamic
Contrast
(Off/High/
Medium/Low)
Adjuststhecontrasttokeepitatthebestlevelaccordingtothebrightnessofthescreen.The
pictureisimprovedbymakingbrightpartsbrighteranddarkpartsdarker.(Thisfunctioncanbeused
onlyunderAV(CVBS)andComponent.)
Dynamic Color
(Off/High/Low)
AdjustsscreenColorssothattheylooklivelier,richerandclearer.Thisfeatureenhances
hue,saturationandluminancesothatred,blue,greenandwhitelookmorevivid.(Thisfunctioncan
beusedonlyunderAV(CVBS)andComponent.)
Clear White
(Off/High/Low)
Makethewhiteareaofscreenbrighterandmorewhite.
Skin Color
(-5 to 5)
Itdetectstheskinareaofvideoandadjustsittoexpressanaturalskincolor.
Noise
Reduction
(Off/High/
Medium/Low)
Reducesscreennoisewithoutcompromisingvideoquality.(Thisfunctioncanbeusedonlyunder
AV(CVBS)andComponent.)
Digital Noise
Reduction
(Off/High/
Medium/Low)
Thisoptionreducesthenoiseproducedwhilecreatingdigitalvideosignals.
Gamma
(High/Medium/
Low)
Setyourowngammavalue.Onthemonitor,highgammavaluesdisplaywhitishimagesandlow
gammavaluesdisplayhighcontrastimages.
Black Level
(High/Low)
Low:Thepictureofthescreengetsdarker.
High:Thepictureofthescreengetsbrighter.
Setblacklevelofthescreentoproperlevel.
(Functionworksinthefollowingmode-Component,HDMI-DTV)
Advanced Control
background
42
ENG
ENGLISH
CUSTOMIZING SETTINGS
AUDIO Settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoAUDIOandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableaudiooptionsaredescribedinthefollowing:
Move
OK
AUDIO
ꔋ
• Clear Voice II : Off
• Balance 0
• Sound Mode : Standard
• Infinite Sound: Off
• Treble 50
• Bass 50
• Reset
• Digital Audio Input
• Speaker : On
L R
Setting Description
Clear Voice ll Bydifferentiatingthehumansoundrangefromothers,ithelpsusersmakedialogmoreclear.
Balance Adjustsbalancebetweentheleftandrightspeakersaccordingtoyourroomenvironment.
Sound Mode Thebestsoundtonequalitywillbeselectedautomaticallydependingonthevideotypethatyou're
currentlywatching.
Mode
Standard Themostcommandingandnaturalaudio.
Music Selectthisoptiontoenjoytheoriginalsoundwhenlisteningto
themusic.
Cinema Selectthisoptiontoenjoysublimesound.
Sport Selectthisoptiontowatchsportsbroadcasting.
Game Toenjoydynamicsoundwhenplayingagame.
Option
InfiniteSound LG'sInfinitySoundoptionprovides5.1channelstereosound
fromtwospeakers.
Treble Controlsthedominantsoundsintheoutput.Whenyouturnup
thetreble,itwillincreasetheoutputtothehigherfrequency
range.
Bass Makestheoutputsoundsofter.Whenyouturnupthebass,itwill
increasetheoutputtothelowerFrequency.
Reset Resetsthesoundmodetothedefaultsetting.
Digital Audio
Input
HDMI/Display Port:OutputsthesoundofdigitalsignalfromHDMIanddisplayportsthroughthe
monitorspeaker.
Audio In:OutputsthesoundthroughthemonitorspeakerbyconnectingHDMIanddisplayports
totheAudioInport.
Speaker ON:Enablessoundtothemonitorspeaker.(*Themonitorspeakerissoldseparately.)
OFF:Disablessoundtothemonitorspeaker.Usethisoptionwhenusinganexternalsounddevice.
NOTE
Ifsoundqualityorvolumeisnotatthelevelyouwant,itisrecommendedto
useaseparatehometheatersystemoramplifiertocopewithdifferentuser
environments.
background
43
ENG
ENGLISH
CUSTOMIZING SETTINGS
TIME Settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoTIMEandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailabletimesettingsaredescribedinthefollowing:
Setting Description
Clock Setsthetimefeature.
On/Off Time SetsthetimetoturnonorofftheMonitorset.
Sleep Timer SetsthelengthoftimeuntiltheMonitorsettoturnsoff.WhenyouturntheMonitorsetoffandturn
itonagain,theSleepTimerwillbesettooff.
Power on delay Whenconnectingmultiplemonitorsandturningthepoweron,themonitorsareturnedonindividually
topreventoverload.
Auto off IfAutooffisactiveandthereisnoinputsignal,thesetswitchestooffmodeautomaticallyafter15
minutes.
Automatic
Standby
Ifyoudonotusethemonitorformorethan4hours,itwillbeinstandbymodeautomatically.
Oncetheonorofftimeisset,thesefunctionsoperatedailyatthepresettime.
Thescheduledpower-offfunctionworksproperlyonlywhenthedevicetimeissetcorrectly.
Whenthescheduledpower-onandpower-offtimesarethesame,thepower-offtimehaspriorityoverthe
power-ontimeifthesetisturnedon,andviceversaifthesetisturnedoff.
The"AutoOff,AutomaticStandby"functionmaynotbeavailabledependingonthecountry.
Iftimehasnotbeenresetforalongperiodoftime,tolerancemayoccurduetoenvironmental
conditions,forexampletemperature.
NOTE
Move OK
TIME
ꔋ
• Clock
• Off Time : Off
• On Time : Off
• Sleep Timer : Off
• Power On Delay : Off
• Auto Off : On
• Automatic Standby : On
background
44
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Language Tochoosethelanguageinwhichthecontrolnamesaredisplayed.
Power Indicator UsethisfunctiontosetthepowerindicatoronthefrontsideoftheproducttoOnorOff.
ISM Method AfrozenorstillpicturefromaPC/Videogamedisplayedonthescreenforprolongedperiods
couldresultinaghostimageremainingevenwhenyouchangetheimage.Avoidallowingafixed
imagetoremainonthescreenforalongperiodoftime.
Setting
Normal Leaveonnormalifyoudon'tforeseeimageburninbeingaproblem.
Orbiter Mayhelppreventghostimages.However,itisbestnottoallowanyfixed
imagetoremainonthescreen.Toavoidapermanentimageonthescreen,
thescreenwillmoveevery2minutes.
Inversion Thisfunctioninvertsthepanelcolorofthescreen.Thepanelcoloris
automaticallyinvertedevery30minutes.
WhiteWash Whitewashfillsthescreenwithsolidwhite.Thishelpsremovespermanent
imagesburnedintothescreen.Apermanentimagemaybeimpossibletoclear
entirelywithwhitewash.
DPM Select Ausercanchoosetoturnthepowersavingmodeon/off.
Fail Over Ifthereisnoinputsignal,itautomaticallyswitchestoanotherinputwithsignal.
Setting
Off Stopsautoswitchoftheinputsource.
Auto Switchestoanotherinputsourcewithvideosignalifnovideosignalcomes
fromthecurrentinputsource.
Manual Selectsthepriorityofinputsourceforautoswitch.
Whenseveralinputsourcesarefound,theinputsourcewithahigherpriority
willbeselected.
Factory Reset Selectthisoptiontoreturntothedefaultfactorysettings.
Set ID YoucanassignauniqueSetIDNO(nameassignment)toeachproductwhenseveralproducts
areconnectedfordisplay.Specifythenumber(1to255)usingthebuttonandexit.Usethe
assignedSetIDtoindividuallycontroleachproductusingtheProductControlProgram.
OPTION Settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoOPTIONandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableoptionsettingsaredescribedinthefollowing:
Move OK
OPTION
ꔋ
• Language
• Power Indicator
• ISM Method : Normal
• DPM Select : On
• Fail Over : Off
• Factory Reset
• Set ID : 1
• Tile Mode
• PIP/PBP
• Key Lock : Off
• Product/Service Info.
• Portrait Mode
• Fan
background
45
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Tile Mode TileMode Tousethisfunction
-Mustbedisplayedwithvariousotherproducts.
-MustbeinafunctionthatcanbeconnectedtoRGBCablebydistributorand
RS-232C.
TilemodeandchooseTilealignmentandsettheIDofthecurrentproductto
setlocation.
*OnlyafterpressingtheSETbuttontheadjustmentsmadetothesettingswill
besaved.
-Tilemode:columnxrow(c=1to15r=1to15)
-15x15available.
-Configurationofanintegrationscreenisalsoavailableaswellas
configurationofOnebyoneDisplay.
AutoConfig. Setstoadjustthescreenposition,clock,andphaseautomatically.
Thedisplayedimagemaybeunstableforafewsecondswhilethe
configurationisinprogress.
Position Movingthescreenpositionhorizontallyandvertically.
Size Adjustthehorizontalandverticalsizeofthescreentakingintoaccountthesize
ofthebezel.
Natural Theimageisomittedbythedistancebetweenthescreenstobenaturally
shown.
Reset ResetstheTileModeoption.
Ifselected,itresetstheautoconfiguration.
PIP/PBP DisplaysvideosorphotosstoredintheUSBdeviceonasinglemonitorbydividingitintothemain
andsubscreens.
Option
Mode Setsthetypeofsecondaryscreen.
*OFF:Disablesthesecondaryscreen.
*PIP (Picture In Picture):Displaysthesecondaryscreeninthemainscreen.
*PBP (Picture By Picture):Displaysthesecondaryscreennexttothemain
screen.
Position Adjuststhepositionofthesubscreen(topleft,bottomleft,topright,bottom
right)
Thedefaultvalueisthebottomright.
Size Adjuststhesizeofthesubscreen(Size0to10).
ThedefaultsizeofPIP(Size:0)is480x240;themaximumsize10is960x540.
Key Lock Turnsthelocalkeyfunctiononoroff.IfKeyLockisenabled,thelocalkeydoesnotwork.
Product/Service
Info.
Displaysthemodelname,softwareversion,serialnumber,IPaddress,MACaddressandhome
page.
Portrait mode RotateOSDclockwise(90°,270°)
Option
90° RotateOSDclockwise90°.
270° RotateOSDclockwise270°.
ꔋ
이동 확인
일반
언어설정(Language)
전면표시설정
화면잔상방지 : 표준
절전모드설정 : 켜짐
자동입력전환 : 켜짐
초기설정
세트 ID : 1
타일모드
ꔋ
이동 확인
일반
언어설정(Language)
전면표시설정
화면잔상방지 : 표준
절전모드설정 : 켜짐
자동입력전환 : 켜짐
초기설정
세트 ID : 1
타일모드
270°90°
NOTE
ThePositionandSizeoptionsareenabledonlyinPIPmode.
background
46
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Fan Setting
Mode Thisoptionindicatesthemonitor'sinternaltemperatureandcontrolsthefan.
•Auto:Switchesthefanonandoffaccordingtothesettemperature.
•On:Thefanisalwaysswitchedon.
•Manual:Switchesthefanonandoffaccordingtousersettings.
Hysteresis Thedifferenceintemperaturebetweenwhenthefanisswitchedonandwhen
itisoff.
SetTemperature Setthetemperatureatwhichthefanisswitchedon.
Current
Temperature
Currenttemperatureinsidetheset.
NOTE
WerecommendthatyouusetheAutomodetopreventanymalfunctions
resultingfromincorrectfansettings.
Iftheinteriortemperatureofthesetexceeds80°C,thesetwillbeturnedoff
automaticallyforsafetyreasons.
background
47
ENG
ENGLISH
CUSTOMIZING SETTINGS
Tile Mode
Thismonitorcanbetiledwithadditionalmonitorstocreatealargetileddisplay.
Tile Mode - Natural mode
Whenactive,thepartoftheimagethatwouldnormallybedisplayedinthegapbetweenthemonitorsis
omitted.
ID1
ID2
ID3
ID4
ID1
ID2
ID4
ID5
ID3
ID6
ID7
ID8
ID9
3X3
Whenusing9monitors
ID1
ID2
ID5
ID6
ID3
ID7
ID9
ID10
ID11
ID4
ID8
ID12
ID13
ID14
ID15
ID16
ID1
ID2
ID6
ID7
ID3
ID8
ID11
ID12
ID13
ID4 ID5
ID9 ID10
ID14 ID15
ID16
ID21
ID17
ID22
ID18
ID23
ID19
ID24
ID20
ID25
Off
WhentheTileMode
optionisdisabled
1X2
Whenusing2monitors
2X2
Whenusing4monitors
5X5
Whenusing25monitors
4X4
Whenusing16monitors
ID1
ID2
TileID
Before After
background
48
ENG
ENGLISH
CUSTOMIZING SETTINGS
PIP/PBP
DisplaysvideosorphotosstoredonaUSBdeviceonasingle
monitorbydividingitintothemainandsubscreens.(Seep.37)
Position
Mode
Size
top left top right
bottom left bottom right
*PIP(Picture In Picture):DisplaystheSubscreen
inthemainscreen.
*PBP(Picture By Picture):DisplaystheSub
screennexttothemainscreen.
Adjuststhepositionofthesubscreen(topleft,
bottomleft,topright,bottomright)
Adjuststhesizeofthesubscreen(Size0-10).
< 1920x1080 >
PBP
960x1080
0 :
480x270
PIP
10 : 960x540
Thesubscreenisonlysupportedwhenusingthe
USBdevice.
Sub
USB
Main
Component O
RGB O
HDMI/DVI-D/Display Port O
AV X
YoucanonlychangethesizeandpositioninPIP
mode.
WithPBPselected,theAspectRatiooptioninthe
PICTUREmenuisdisabled(Fixedas16:9).
WhilerunningthePBPfunction,theTileModefunction
doesnotwork.
Youmustselecttheoutputsoundbeforerunning
thePIPorPBPfunctions.(SelecteitherMainor
Sub.)
IfyoufailtoselectMainorSubfromthesound
selectionbox,andiftheOSDdisappearsafter
eitheraperiodoftimeorwhentheExitorBack
keyispressed,thePIP/PBPsubscreenisnot
activated.
Youcannotchangethesoundwhilerunningthe
PIPorPBPfunctions.Ifyouwanttochangethe
sound,pleaserestartPIP/PBP.
Thepicturequalityofthesubscreenisset
accordingtothevaluesselectedinthemainmenu,
nottheUSBdevice.
Whenthepoweristurnedoff/on,thePIP/PBP
modeisdisabled.
IfyouplayvideosyouselectedinPIP/PBPmode,
thevideoswillplaybackrepeatelyinsuccession.
ThebuttonsbelowworkinPIPmode.
Button Photo Movie
NOTE
Main
screen
Sub
screen
PIP PBP
background
49
ENG
ENGLISH
CUSTOMIZING SETTINGS
Picture ID
PictureIDisusedtochangethesettingsofa
specicdisplayusingasingleIRreceiverfor
multi-vision.ThesetreceivingtheIRsignal
communicateswithanothersetviaanRS232
connection.EachsetisidentiedbyaSetID.If
youassignthePictureIDusingtheremotecontrol,
onlydisplayswiththesamePictureIDandSetID
canbecontrolledremotely.
1 PresstheredONbuttonontheremotecontrol
toassignthePictureID.
2 Ifyoupresstheleft/rightbuttonsorpressthe
ONbuttonrepeatedly,thePictureIDcycles
throughOFFand0to4.AssigntheIDyou
want.
IfyouassigntheSetIDtoeachsetwith
multi-vision,andthenassignthePictureID
usingtheredbuttonontheremotecontrol,
thekeycommandisdisplayedfortheset
withthesameSetIDandPictureID.Aset
withdifferentSetIDsandPictureIDscannot
becontrolledbyIRsignals.
Formoreinformationonhowtoassignthe
SetID,see"SetID"onpage44.
PleaserefertotheInstallationManualfor
moreinformationonTotalSetIDassignment.
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
P
A
G
E
INPUT
ENERGY
SAVING
MARK
ARC
ON
OFF
. , !
ABC
DEF
GHI
JKL
MNO
PQRS
TUV
1/a/A
- * #
WXYZ
CLEAR
OK
S.MENU
MONITOR
PSM
AUTO
MUTE
BRIGHT
NESS
MENU
ID
BACK
TILE
ON
OFF
EXIT
POWER
Forexample,ifthePictureIDisassigned
to2,theupperrightdisplay(SetID:2)can
becontrolledbyIRsignals.
Foreachset,youcanchangethe
settingsforthePICTURE,AUDIO,TIME,
NETWORKandMYMEDIAmenusorthe
hotkeysontheremotecontrol.
IfyoupressthegreenOFFbuttonfor
PictureIDs,thePictureIDsforallsetsare
turnedoff.Ifyouthenpressanybutton
ontheremotecontrol,allsetswillstart
workingagain.
PictureIDwillbedisabledwhileusingthe
MYMEDIAmenu.
NOTE
Picture ID
Close
◀
Off
▶
1
2
3
4
Picture ID
Off
Close
IR Receiver
RS232C
1
2
3
4
1
2
3
4
Picture ID
Off
Close
Picture ID
Off
Close
IR Receiver
RS232C
2X2Multi-Vision(TotalSetID:4)
SetIDsareassignedasshowninthepicture.
IRReceiver
background
50
ENG
ENGLISH
CUSTOMIZING SETTINGS
Setting Description
Player Name SetstheplayernameusedinSuperSignManager.(Upto20characters)
Network Setting Configurethenetworksettings.
Network Status Displaythenetworkstatus.
-Internetisconnected:Extermallyconnected
-Homenetworkisconnected:Onlyinternallyconnected
-Notconnected:Whenthereisnonetworkconnection
Server IP Setting SetstheIPaddressofthecomputer(server)onwhichSuperSignManagerisinstalled.
Server IP Status Displaystheconnectionstatuswiththeserver.
-Notconnected:WhenthereisnonetworkconnectionwithSuperSignserver
-Waitingforapproval:WhennetworkconnectionwithSuperSignserverhasbeenmade,but
accesstoserverhasnotbeenapprovedbytheserver
-Rejected:WhennetworkconnectionwithSuperSignserverhasbeenmade,butaccessto
serverhasbeenrejectedbytheserver
-Internetisconnected:WhennetworkconnectionwithSuperSignserverhasbeenmadeand
accesstoserverhasalsobeenapprovedbytheserver
NETWORK Settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoNETWORKand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableoptionsettingsaredescribedinthefollowing:
Move OK
NETWORK
ꔋ
• Player Name
• Network Setting : Wired
• Network Status : Not connected
• Server IP Setting
• Server IP Status : Not connected
WhensettingthePlayerName,inputdelaymayoccurifyoupressthebuttonsontheremotecontrol
continuously.
CAUTION
background
51
ENG
ENGLISH
MAKING CONNECTIONS
HDMI-Seep.52
DVI-Seep.52
AV(CVBS)-Seep.53
Component-Seep.53
HDMI-Seep.15
DVI-Seep.15
RGB-Seep.14
LAN-Seep.54
Display Port-Seep.16
HDMI-Seep.52
DVI-Seep.52
AV(CVBS)-Seep.53
Component-Seep.53
HDMI-Seep.52
DVI-Seep.52
AV(CVBS)-Seep.53
Component-Seep.53
AV(CVBS)
-Seep.53
Component
-Seep.53
HDMI-Seep.52
AV(CVBS)
-Seep.53
Component
-Seep.53
MAKING CONNECTIONS
ConnectvariousexternaldevicestotheportsontheMonitorset’sbackpanel.
1
FindanexternaldeviceyouwanttoconnecttoyourMonitorsetshownonthefollowingillustration.
2
Checktheconnectiontypeoftheexternaldevice.
3
Gototheappropriateillustrationandchecktheconnectiondetails.
IfyouconnectagamingdevicetotheMonitorset,usethecablesuppliedwiththegamingdevice.
HD Receiver DVD VCR
USB
PC
Camcorder/Camera
Gaming device
Speaker
Memory storage
–Seep.24
NOTE
background
52
ENG
ENGLISH
MAKING CONNECTIONS
AUDIO
IN
AUDIO
IN
DVI IN
IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
AUDIO
IN
DVI IN
IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
Connecting to a HD receiver,
DVD, Camcorder, Camera,
Gaming Device or VCR player
ConnectaHDreceiver,DVD,orVCRplayertothe
Monitorsetandselectanappropriateinputmode.
HDMI Connection
Transmitsdigitalvideoandaudiosignalsfroman
externaldevicetotheMonitorset.Connectthe
externaldeviceandtheMonitorsetwiththeHDMI
cableasshownonthefollowingillustration.
UseaHighSpeedHDMI™Cable.
HighSpeedHDMI™Cablesaretestedto
carryanHDsignalupto1080pandhigher.
NOTE
DVI Connection
Transmitsdigitalvideosignalfromanexternal
devicetotheMonitorset.Connecttheexternal
deviceandtheMonitorsetwiththeDVIcableas
showninthefollowingillustration.Totransmitan
audiosignal,connectanoptionalaudiocable.
Backoftheproduct.
Backoftheproduct.
(notincluded)
(notincluded)
(notincluded)
background
53
ENG
ENGLISH
MAKING CONNECTIONS
AUDIO
IN
AUDIO
IN
AV (CVBS)
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
AUDIO
IN
AUDIO
IN
AV (CVBS)
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
AV(CVBS) Connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connectthe
externaldeviceandtheMonitorsetwiththe15
pinsignaltoRCAcableasshownonthefollowing
illustration.
Component Connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheMonitorset.Connectthe
externaldeviceandtheMonitorsetwiththe15
pinsignaltoRCAcableasshownonthefollowing
illustration.Todisplayimagesbyusingprogressive
scan,makesuretousethecomponentcable.
PC
PC
WhenconnectingtotheAVorComponent
portusingthesharedinterface,theportmust
matchuptotheinputsource.Otherwise,
noisemayoccur.
NOTE NOTE
Backoftheproduct. Backoftheproduct.
(notincluded)
(notincluded)
(notincluded)
(notincluded)
ForAV(CVBS)connection,theredandblue
cablesinasharedinterfacearenotinuse.
background
54
ENG
ENGLISH
MAKING CONNECTIONS
Connecting to the LAN
LAN Connection
A
Usingarouter(Switch)
MonitorSet
Network
PC
LAN
Switch
MonitorSet
Network
PC
LAN
B
UsingtheInternet.
Connecting to a USB
ConnectaUSBstoragedevicesuchassUSB
flashmemory,externalharddrive,MP3playeror
aUSBmemorycardreadertotheMonitorsetand
accesstheUSBmenutousevariousmultimedia
files.
or
background
55
ENG
ENGLISH
MAKING CONNECTIONS
Thenumberofmonitorsthatcanbeconnectedtooneoutputmayvarydependingonsignalstatus
andcableloss.Ifthesignalstatusisgood,andthereisnocableloss,itispossibletoconnectupto
9monitors.Ifyouwanttoconnectmorethanthisnumberofmonitors,itisrecommendedtousea
distributor.
Whenmulti-connectingin/outcascadeformat,nolosscablesarerecommended.
DVIOUTdoesnotworkwhenconnectingtoathird-partyproduct.
NOTE
Daisy Chain Monitors
UsethisfunctiontosharetheRGBvideosignalwithothermonitorswithouthavingtouseaseparatesignal
splitterbox.
•TousedifferentproductsconnectedtoeachotherConnectoneendofthesignalinputcable(15-pin
D-SubSignalCable)totheRGBOUTconnectorofproduct1andconnecttheotherendtotheRGBIN
connectorofotherproducts
RGB Cable
DVI IN DVI OUT DVI IN DVI OUT DVI IN DVI OUT DVI IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
MonitorSET1 MonitorSET2 MonitorSET3 MonitorSET4
15-pinD-SubSignalCable
(Max3m)
DVI Cable
DVI IN DVI OUT DVI IN DVI OUT DVI IN DVI OUT DVI IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
DVICable
MonitorSET1 MonitorSET2 MonitorSET3 MonitorSET4
background
56
ENG
ENGLISH
TROUBLESHOOTING
TROUBLESHOOTING
No image is displayed
Problem Resolution
Istheproductpowercord
connected?
Seeifthepowercordisproperlyconnectedtotheoutlet.
Isthepowerindicatorlighton?
Seeifthepowerswitchisturnedon.
Mayneedservice.
Powerisonbutthescreen
appearsextremelydark.
Adjustbrightnessandcontrastagain.
Backlightmayneedrepair.
Thepowerindicatoramber?
Iftheproductisinpowersavingmode,movethemouseorpressany
key.
Turnbothdevicesoffandthenbackon.
Doesthe'Outofrange'
messageappear?
ThesignalfromthePC(videocard)isoutoftheverticalorhorizontal
frequencyrangeoftheproduct.Adjustthefrequencyrangeby
referringtotheSpecificationsinthismanual.
*Maximumresolution
RGB:1920x1080@60Hz
HDMI/DVI:1920x1080@60Hz
Doesthe'Checksignalcable'
messageappear?
ThesignalcablebetweenPCandproductisnotconnected.Check
thesignalcable.
Pressthe'INPUT'menuintheremoteControltochecktheinput
signal.
'Unknown Product' message appears when the product is connected.
Problem Resolution
Didyouinstallthedriver?
Seeiftheplug&playfunctionissupportedbyreferringtothevideo
cardusermanual.
background
57
ENG
ENGLISH
TROUBLESHOOTING
'Key Lock On' message appears.
Problem Resolution
The'KeyLockOn'message
appearswhenpressingthe
Menubutton.
TheLockfunctionpreventstheOSDsettingsfrombeingchanged
inadvertently.Toreleasethelock,gotoMenuandOptionanddisable
theKeyLockoption.
The screen image looks abnormal.
Problem Resolution
Isthescreenpositionwrong?
D-Subanalogsignal-Pressthe"AUTO"buttonintheremotecontrol
toautomaticallyselecttheoptimalscreenstatusthatfitsintothe
currentmode.Ifadjustmentisnotsatisfactory,usethePositionOSD
menu.
Seeifthevideocardresolutionandfrequencyaresupportedbythe
product.Ifthefrequencyisoutofrange,settotherecommended
resolutionintheControlPanel"Display"Settingmenu.
Dothinlinesappearonthe
backgroundscreen?
D-Subanalogsignal-Pressthe"AUTO"buttonintheremotecontrol
toautomaticallyselectanoptimalscreenstatusthatfitsintothe
currentmode.Ifadjustmentisnotsatisfactory,usetheClockOSD
menu.
Horizontalnoiseappearsorthe
characterslookblurred.
D-Subanalogsignal-Pressthe"AUTO"buttonintheremotecontrol
toautomaticallyselectanoptimalscreenstatusthatfitsintothe
currentmode.Ifadjustmentisnotsatisfactory,usethePhaseOSD
menu.
Thescreenisdisplayed
abnormally.
Theproperinputsignalisnotconnectedtothesignalport.Connect
thesignalcablethatmatcheswiththesourceinputsignal.
After-image appears on the product.
Problem Resolution
After-imageappearswhenthe
productisturnedoff.
Ifyouuseafixedimageforalongtime,thepixelsmaybedamaged
quickly.Usethescreen-saverfunction.
background
58
ENG
ENGLISH
TROUBLESHOOTING
Screen color is abnormal.
Problem Resolution
Screenhaspoorcolorresolution
(16colors).
Setthenumberofcolorstomorethan24bits(truecolor)Select
ControlPanel-Display-Settings-ColorTablemenuinWindows.
Screencolorisunstableor
mono-colored.
Checktheconnectionstatusofthesignalcable.Or,re-insertthePC
videocard.
Doblackspotsappearonthe
screen?
Severalpixels(red,green,whiteorblackcolor)mayappearonthe
screen,whichcanbeattributabletotheuniquecharacteristicsofthe
LCDpanel.ItisnotamalfunctionoftheLCD.
The operation does not work normally.
Problem Resolution
Thepowersuddenlyturnedoff.
Isthesleeptimerset?
Checkthepowercontrolsettings.Powerinterrupted.
The audio function does not work.
Problem Resolution
Nosound?
Seeiftheaudiocableisconnectedproperly.
Adjustthevolume.
Seeifthesoundissetproperly.
Soundistoodull.
Selecttheappropriateequalizesound.
Soundistoolow.
Adjustthevolume.
background
59
ENG
ENGLISH
SPECIFICATIONS
SPECIFICATIONS
LCDPanel ScreenType 47"class(46.9"diagonal)TFT(ThinFilmTransistor)
LCD(LiquidCrystalDisplay)Panel.
Visiblediagonalsize:1192.87mm
PixelPitch 0.5414mm(H)x0.5414mm(V)
VideoSignal Max.Resolution RGB:1920x1080@60Hz
HDMI/DVI/DP:1920x1080@60Hz
-ItmaynotbesupporteddependingontheOSorvideocardtype.
RecommendedResolution RGB:1920x1080@60Hz
HDMI/DVI/DP:1920x1080@60Hz
-ItmaynotbesupporteddependingontheOSorvideocardtype.
HorizontalFrequency
RGB:30kHzto83kHz
HDMI/DVI/DP:30kHzto83kHz
VerticalFrequency RGB:56Hzto75Hz
HDMI/DVI/DP:56Hzto60Hz
SynchronizationType SeparateSync,CompositeSync,Digital
InputConnector 15-pinD-Subtype,HDMI(digital),RS-232C,LAN,DVI-D,
Displayport,USB
Power RatedVoltage AC100-240V~50/60Hz3.0A
PowerConsumption OnMode:240WTyp.
SleepMode:≤1W
OffMode:≤0.7W
Environmental
conditions
OperatingTemperature
OperatingHumidity
0°Cto40°C
10%to80%
StorageTemperature
StorageHumidity
-20°Cto60°C
5%to95%
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
background
60
ENG
ENGLISH
SPECIFICATIONS
Dimensions
(WidthxHeightx
Depth)/Weight
1070.8mmX665.5mmX157mm/23.9Kg
1070.8mmX720mmX293.7mm/25.7Kg
* Speaker Specifications
Audio RMSAudioOutput 10W+10W(R+L)
InputSensitivity 0.7Vrms
SpeakerImpedance 8Ω
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
background
61
ENG
ENGLISH
SPECIFICATIONS
RGB (PC) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
640x350
31.469 70.8
720x400
31.468 70.8
640x480
31.469 59.94
640x480
37.5 75
800x600
37.879 60.317
800x600
46.875 75
832x624
49.725 74.55
1024x768
48.363 60
1024x768
60.123 75.029
1280x720
44.772 59.855
1280x768
47.7 60
1360x768
47.72 59.799
1366x768
47.7 60
1280x1024
63.981 60.02
1280x1024
79.98 75.02
1680x1050
65.290 59.954
1920x1080
67.5 60
HDMI/DVI/Display Port(PC) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
640x480
31.469 59.94
800x600
37.879 60.317
1024x768
48.363 60
1280x720
44.772 59.855
1280x768
47.7 60
1360x768
47.72 59.799
1366x768
47.7 60
1280x1024
63.981 60.02
1680x1050
65.290 59.954
1920x1080
67.5 60
PCresolutionsavailableastheinputlabel
optioninRGBandHDMI/DVIinputmode:
640x480/60Hz,1280x720/60Hz,1920
x1080/60HzandDTVresolutions:480p,
720p,1080p.
DTV Mode
Resolution Component
HDMI/DVI
(DTV)
480i o x
576i o x
480p o o
576p o o
720p o o
1080i o o
1080p o o
Power Indicator
Mode Product
OnMode Red
SleepMode Amber
OffMode -
NOTE
Verticalfrequency:Toenabletheuserto
watchtheproductdisplay,screenimage
shouldbechangedtensoftimesevery
secondlikeafluorescentlamp.Thevertical
frequencyorrefreshrateisthetimesof
imagedisplaypersecond.TheunitisHz.
Horizontalfrequency:Thehorizontalinterval
isthetimetodisplayoneverticalline.When
1isdividedbythehorizontalinterval,the
numberofhorizontallinesdisplayedevery
secondcanbetabulatedasthehorizontal
frequency.TheunitiskHz.
NOTE
background
62
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
CONTROLLING THE MULTIPLE PRODUCT
UsethismethodtoconnectseveralproductstoasinglePC.Youcancontrolseveralproductsatone
timebyconnectingthemtoasinglePC.
IntheOptionmenu,SetIDmustbebetween1and99withoutbeingduplicated.
Connecting the Cable
ConnecttheRS-232Ccableasshowninthepicture.
TheRS-232CprotocolisusedforcommunicationbetweenthePCandproduct.Youcanturnthe
producton/off,selectaninputsourceoradjusttheOSDmenufromyourPC.
Communication Parameter
MonitorSet1 MonitorSet2 MonitorSet3 MonitorSet4
PC
RS-232CCable
(notincluded)
BaudRate:9600buadRate(UART)
DataLength:8bit
ParityBit:None
StopBit:1bit
FlowControl:None
CommunicationCode:ASCIIcode
Useacrossed(reverse)cable
RS-232C Configurations
RXD
TXD
GND
DTR
DSR
RTS
CTS
RXD
TXD
GND
DTR
DSR
RTS
CTS
TXD
RXD
GND
DSR
DTR
CTS
RTS
TXD
RXD
GND
DSR
DTR
CTS
RTS
PC Set PC Set
2
3
5
4
6
7
8
3
2
5
6
4
8
7
D-Sub 9 D-Sub 9
(Female) (Female)
D-Sub 9 D-Sub 9
(Female) (Female)
2
3
5
4
6
7
8
3
2
5
6
4
7
8
7-WireConfigurations(StandardRS-232Ccable)
3-WireConfigurations(NotStandard)
Whenusing3-wireconnections(non-standard),anIRdaisychaincannotbeused.
NOTE
background
63
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
Command reference list
COMMAND
DATA
(Hexadecimal)
1 2
01.Power k a 00Hto01H
02.InputSelect x b Referto‘02.InputSelect’
03.AspectRatio k c Referto‘03.AspectRatio’
04.EnergySaving j q Referto‘04.EnergySaving’
05.Picturemode d x 00Hto04H
06.Contrast k g 00Hto64H
07.Brightness k h 00Hto64H
08.Sharpness k k 00Hto64H
09.Color k i 00Hto64H
10.Tint k j 00Hto64H
11.ColorTemperature x u 00Hto64H
12.HPosition f q 00Hto64H
13.VPosition f r 00Hto64H
14.HSize f s 00Hto64H
15.Autoconfiguration j u 01H
16.Balance k t 00Hto64H
17.Soundmode d y 01Hto05H
18.Treble k r 00Hto64H
19.Bass k s 00Hto64H
20.Speaker d v 00Hto01H
21.VolumeMute k e 00Hto01H
22.VolumeControl k f 00Hto64H
23.Time1(Years/Months/Days) f a Referto‘23.Time1’
24.Time2(Hours/Minutes/Seconds) f x Referto‘24.Time2’
25.OffTimer(Repeatmode/Time) f e Referto‘25.OffTimer’
26.OnTimer(RepeatMode/Time) f d Referto‘26.OnTimer’
27.OnTimerInput f u Referto‘27.OnTimerInput’
28.SleepTime f f 00Hto08H
29.PowerOnDelay f h 00Hto64H
30.AutomaticStandby m n 00Hto01H
31.AutoOff f g 00Hto01H
32.Language f i Referto‘32.Language’
33.PowerIndicator(StandbyLight) f o 00Hto01H
34.PowerIndicator(PowerLight) f p 00Hto01H
35.ISMmode j p Referto‘35.ISMMethod’
36.FailOverSelect m i 00Hto02H
37.FailOverInputSelect m j Referto‘37.FailOverInputSelect’
38.Reset f k 00Hto03H
background
64
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
COMMAND
DATA
(Hexadecimal)
1 2
39.TileMode d d 00HtoFFH
40.TileModeCheck d z FFH
41.TileID d i Referto‘41.TileID’
42.TileHPosition d e 00Hto32H
43.TileVPosition d f 00Hto32H
44.TileHSize d g 00Hto32H
45.TileVSize d h 00Hto32H
46.NaturalMode(InTilemode) d j 00Hto01H
47.DPMSelect f j 00Hto01H
48.FANControl d o 00Hto03H
49.FANFaultCheck d w FFH
50.TemperatureValue d n FFH
51.RemoteLock/keyLock k m 00Hto01H
52.Key m c Referto‘52.Key’
53.OSDSelect k l 00Hto01H
54.Elapsedtimereturn d l FFH
55.SerialNo.Check f y FFH
56.S/WVersion f z FFH
57.WhiteBalanceRedGain j m 00HtoFEH
58.WhiteBalanceGreenGain j n 00HtoFEH
59.WhiteBalanceBlueGain j o 00HtoFEH
60.Backlight
m
g 00Hto64H
Note:DuringUSBoperationssuchasDvixorEMF,allcommandsexceptPower(ka)andKey(mc)are
notexecutedandtreatedasNG.
background
65
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
Transmission
[Command1][Command2][][SetID][][Data][Cr]or
[Command1][Command2][][SetID][][Data1][][Data2][][Data3][Cr]
*[Command1]:Firstcommandtocontroltheset.
*[Command2]:Secondcommandtocontroltheset.
*[SetID]:SetIDwithwhichyouwanttocommunicate.Etner[SetID]=‘00(0x00’tocommunicatewithallsets
regardlessoftheirSetIDnumbers.
*[Data]:Informationpassedtotheset.
*[Data1]:Informationpassedtotheset.
*[Data2]:Informationpassedtotheset.
*[Data3]:Informationpassedtotheset.
*[Cr]:CarriageReturn.ASCIIcode‘0x0D’.
*[]:ASCIIcodespace‘0x20’
Acknowledgement
[Command2][][SetID][][OK/NG][Data][x]or
[Command2][][SetID][][OK/NG][Data1][Data2][Data3][x]
*Inalikemanner,ifotherfunctionstransmit‘FF’databasedonthisformat,Acknowledgementdatafeedback
presentsstatusabouteachfunction.
*Note:Inthismode,displaywillsendtheacknowledgementafterpoweronprocessingcompletion.
Theremightbeatimedelaybetweencommandandacknowledgement.
*Noacknowledgementsignalwillbesentfromdisplay,ifSetIDintransmissionsignalissetto‘00’(=0x00).
Transmission / Receiving protocol
background
66
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
04. Energy Saving (Command: j q)
Tocontroltheenergysavingfunction.
Transmission
[j][q][][SetID][][Data][Cr]
Data 00:Off
01:Minimum
02:Medium
03.Maximum
04:Auto
05.ScreenOff
Acknowledgement
[q][][SetID][][OK/NG][Data][x]
05. Picture Mode (Command: d x)
Toselectthepicturemode.
Transmission
[d][x][][SetID][][Data][x]
Data 00:Vivid
01:Standard
02.Cinema
03.Sport
04:Game
Acknowledgement
[x][][SetID][][OK/NG][Data][x]
06. Contrast (Command: k g)
Toadjustscreencontrast.
Transmission
[k][g][][SetID][][Data][Cr]
Data 00to64:Contrast0to100
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
01. Power (Command: k a)
TocontrolpowerOn/Offthedisplay.
Transmission
[k][a][][SetID][][Data][Cr]
Data00:PowerOff
01:PowerOn
FF:Checkstatus
Acknowledgement
[a][][SetID][][OK/NG][Data][x]
*Inalikemanner,ifotherfunctionstransmit‘FF’
databasedonthisformat,Acknowledgementdata
feedbackpresentsstatusabouteachfunction.
*Note:Inthismodes,displaywillsendthe
acknowledgementafterpoweronprocessing
completion.Theremightbeatimedelaybetween
commandandacknowledgement.
*Theremightbesometimedelaysbetween
commandandacknowledgement.
02. Input Select (Command: x b)
Toselectinputsourcefordisplay.
Transmission
[x][b][][SetID][][Data][Cr]
Data 20:AV
40:Component
60:RGBPC
70:DVI-D
90:HDMI(DTV)
A0:HDMI(PC)
C0:DisplayPort(DTV)
D0:DisplayPort(PC)
Acknowledgement
[b][][SetID][][OK/NG][Data][x]
03. Aspect Ratio (Command: k c)
Toadjustthescreenformat.
Transmission
[k][c][][SetID][][Data][Cr]
Data 01:4:3
02:16:9
04:Zoom
09:Justscan(720pormore)
10to1F:CinemaZoom1to16
Acknowledgement
[c][][SetID][][OK/NG][Data][x]
background
67
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
07. Brightness (Command: k h)
Toadjustscreenbrightness.
Transmission
[k][h][][SetID][][Data][Cr]
Data 00to64:Brightness0to100
Acknowledgement
[h][][SetID][][OK/NG][Data][x]
08. Sharpness (Command: k k) (Video input only)
Toadjustscreensharpness.
Transmission
[k][k][][SetID][][Data][Cr]
Data 00to64:Sharpness0to100
Acknowledgement
[k][][SetID][][OK/NG][Data][x]
09. Color (Command: k i) (Video input only)
Toadjustscreencolor.
Transmission
[k][i][][SetID][][Data][Cr]
Data 00to64:Color0to100
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
10. Tint (Command: k j) (Video input only)
Toadjustscreentint.
Transmission
[k][j][][SetID][][Data][Cr]
Data 00to64:Tint0to100(R50toG50)
Acknowledgement
[j][][SetID][][OK/NG][Data][x]
11. Color Temperature (Command: x u)
Toadjustcolortemperature.
Transmission
[x][u][][SetID][][Data][Cr]
Data 00to64:Warm50toCool50
Acknowledgement
[u][][SetID][][OK/NG][Data][x]
12. H Position (Command: f q)
TosettheHorizontalposition.
*OnlyavailableforTileOffmode.
Transmission
[f][q][][SetID][][Data][Cr]
Data 00to64:Left-50toRight50
Acknowledgement
[q][][SetID][][OK/NG][Data][x]
background
68
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
13. V Position (Command: f r)
TosettheVerticalposition.
*OnlyavailableforTileOffmode.
Transmission
[f][r][][SetID][][Data][Cr]
"0-64:min.-50(bottom)tomax.50(top)
*Theoperationalrangevariesdependingonthe
RGBinputresolution.
Acknowledgement
[r][][SetID][][OK/NG][Data][x]
14. H Size (Command: f s)
TosettheHorizontalsize.
*OnlyavailableforTileOffmode.
Transmission
[f][s][][SetID][][Data][Cr]
Data 00to64:Size-50to50
Acknowledgement
[s][][SetID][][OK/NG][Data][x]
15. Auto Configuration (Command: j u)
Toadjustpicturepositionandminimizeimage
shakingautomatically.
*OnlyavailableforRGBinput.
Transmission
[j][u][][SetID][][Data][Cr]
Data01:Set
Acknowledgement
[u][][SetID][][OK/NG][Data][x]
16. Balance (Command: k t)
Toadjustbalance.
Transmission
[k][t][][SetID][][Data][Cr]
Data 00to64:Left50toRight50
Acknowledgement
[t][][SetID][][OK/NG][Data][x]
17. Sound Mode (Command: d y)
Toselectthesoundmode.
Transmission
[d][y][][SetID][][Data][x]
Data 01:Standard
02:Music
03:Cinema
04:Sport
05.Game
Acknowledgement
[y][][SetID][][OK/NG][Data][x]
18. Treble (Command: k r)
Toadjusttreble.
Transmission
[k][r][][SetID][][Data][Cr]
Data 00to64:Treble0to100
Acknowledgement
[r][][SetID][][OK/NG][Data][x]
background
69
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
22. Volume Control (Command: k f)
Toadjustvolume.
Transmission
[k][f][][SetID][][Data][Cr]
Data 00to64:Volume0to100
Acknowledgement
[f][][SetID][][OK/NG][Data][x]
23. Time 1(Year/ Month/ Day) (Command: f a)
TosettheTime1(Year/Month/Day)values.
Transmission
[f][a][][SetID][][Data1][][Data2][][Data3][Cr]
Data100to14:2010to2030
Data201to0C:JanuarytoDecember
Data301to1F:1to31
*Enter“fa[SetID]ff”forcheckingTime1values.
Acknowledgement
[a][][SetID][][OK/NG][Data1][Data2][Data3][x]
24. Time 2(Hour/ Minute/ Second) (Command: f x)
TosettheTime2(Hour/Minute/Second)values.
Transmission
[f][x][][SetID][][Data1][][Data2][][Data3][Cr]
Data1 00to17:00to23hours
Data2 00to3B:00to59minutes
Data3 00to3B:00to59seconds
*Enter“fx[SetID]ff”forcheckingTime2values.
**Thiscommandwon’tworkifTime1hasnotbeen
setinadvance.
Acknowledgement
[x][][SetID][][OK/NG][Data1][Data2][Data3][x]
19. Bass (Command: k s)
Toadjustbass.
Transmission
[k][s][][SetID][][Data][Cr]
Data 00to64:Bass0to100
Acknowledgement
[s][][SetID][][OK/NG][Data][x]
20. Speaker (Command: d v)
Toselectspeakeron/off.
Transmission
[d][v][][SetID][][Data][x]
Data00:SpeakerOff
01:SpeakerOn
Acknowledgement
[v][][SetID][][OK/NG][Data][x]
21. Volume Mute (Command: k e)
Toselectscreenmuteon/off.
Transmission
[k][e][][SetID][][Data][Cr]
Data00:VolumeMuteOn(VolumeOff)
01:VolumeMuteOff(VolumeOn)
Acknowledgement
[e][][SetID][][OK/NG][Data][x]
background
70
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
25. Off Timer(Repeat Mode/ Time) (Command: f e)
TosettheOffTimer(Repeatmode/Time)function.
Transmission
[f][e][][SetID][][Data1][][Data2][][Data3][Cr]
Data100:RepeatOff
01:RepeatOnce
02.RepeatDaily
03:RepeatfromMondaytoFriday
04:RepeatfromMondaytoSaturday
05:RepeatfromSaturdaytoSunday
06.RepeatonSunday
Data200to17:00to23Hours
Data300to3B:00to59Minutes
*Enter“fe[SetID]ff”forcheckingOffTimer(Repeat
mode/Time)values.
*CheckifTime1andTime2havebeensetbefore
settingthisfunction.
Acknowledgement
[e][][SetID][][OK/NG][Data1][Data2][Data3][x]
26. On Timer(Repeat Mode/ Time) (Command: f d)
TosettheOnTimer(Repeatmode/Time)function.
Transmission
[f][d][][SetID][][Data1][][Data2][][Data3][Cr]
Data100:RepeatOff
01:RepeatOnce
02.RepeatDaily
03:RepeatfromMondaytoFriday
04:RepeatfromMondaytoSaturday
05:RepeatfromSaturdaytoSunday
06.RepeatonSunday
Data200to17:00to23Hours
Data300to3B:00to59Minutes
*Enter“fd[SetID]ff”forcheckingOnTimer(Repeat
mode/Time)values.
*CheckifTime1andTime2havebeensetbefore
settingthisfunction.
Acknowledgement
[d][][SetID][][OK/NG][Data1][Data2][Data3][x]
27. On Timer Input (Command: f u)
TosettheOnTimerInputfunction.
Transmission
[f][u][][SetID][][Data][Cr]
Data20:AV
40:Component
60.RGB
90:HDMI
70:DVI
C0:DISPLAYPORT
*CheckifTime1andTime2andOnTimer(Repeat
Mode/Time)functionshavebeensetbeforesetting
thisfunction.
Acknowledgement
[u][][SetID][][OK/NG][Data][x]
28. Sleep Time (Command: f f)
Tosetsleeptime.
Transmission
[f][f][][SetID][][Data][Cr]
Data 00:Off
01:10min.
02:20min.
03:30min.
04:60min.
05:90min.
06:120min.
07:180min.
08:240min.
Acknowledgement
[f][][SetID][][OK/NG][Data][x]
29. Power On Delay (Command: f h)
Tosetthescheduledelaywhenthepoweristurned
on(unit:second).
Transmission
[f][h][][SetID][][Data][Cr]
Data 00to64:0to100sec.
Acknowledgement
[h][][SetID][][OK/NG][Data][x]
background
71
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
30. Automatic Standby (Command: m n)
TosettheAutomaticStandbyfunction.
Transmission
[m][n][][SetID][][Data][Cr]
Data 00:AutomaticStandbyOff
01:AutomaticStandbyOn
Acknowledgement
[n][][SetID][][OK/NG][Data][x]
31. Auto Off (Command: f g)
TosettheAutoOfffunction.
Transmission
[f][g][][SetID][][Data][Cr]
Data 00:AutoOffOff
01:AutoOffOn
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
32. Language (Command: f i)
TosetlanguageforOSD.
Transmission
[f][i][][SetID][][Data][Cr]
Data 00:Czech
01:Danish
02:German
03:English
04:Spanish(EU)
05:Greek
06:French
07:Italian
08:Dutch
09:Norwegian
0A:Portuguese
0B:Protuguese(BR)
0C:Russian
0D:Finnish
0E:Swedish
0F:Korean
10:Chinese(Mandarin)
11:Japanese
12:YueChinese(Cantonese)
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
33. Power Indicator(Standby Light) (Command: f o)
TosetthePowerIndicator(StandbyLight)function.
Transmission
[f][o][][SetID][][Data][Cr]
Data 00:StandbyLightOff
01:StandbyLightOn
Acknowledgement
[o][][SetID][][OK/NG][Data][x]
34. Power Indicator(Power Light) (Command: f p)
TosetthePowerIndicator(PowerLight)function.
Transmission
[f][p][][SetID][][Data][Cr]
Data 00:PowerLightOff
01:PowerLightOn
Acknowledgement
[p][][SetID][][OK/NG][Data][x]
35. ISM mode (Command: j p)
ToselectISMmethodforavoidinghavingafixed
imageremainonscreen.
Transmission
[j][p][][SetID][][Data][Cr]
Data 01:Inversion
02:Orbiter
04:WhiteWash
08.Normal
Acknowledgement
[p][][SetID][][OK/NG][Data][x]
background
72
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
36. Fail Over Select (Command: m i)
TosettheFailOverfunction.
Transmission
[m][i][][SetID][][Data][Cr]
Data 00:Off
01:Auto
02:Manual
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
37. Fail Over Input Select (Command: m j)
Toselectfailovermode.
*OnlyavailableinFailOvermanualmode.
Transmission
[m][j][][SetID][][Data1][][Data2][][Data3][Cr]
[][Data4][Cr]
Data1to4(Priority1to4)
60:RGB
70:DVI-D*
90:HDMI**
C0:DisplayPort***
*Use0x70asdataforDVI-Dinput,regardlessDVI-
D(PC)orDVI-D(DTV).
**Use0x90asdataforHDMIinput,regardless
HDMI-DTVorHDMI-PC
***Use0xC0asdataforDisplayPortinput,
RegardlessDisplayPort(DTV)orDisplayPort(PC)
Acknowledgement
[j][][SetID][][OK/NG][Data1][Data2][Data3][Data4]
[x]
Data 1to4(Priority1to4)
60:RGB
70:DVI-D****
90:HDMI*****
C0:DisplayPort******
****Returns0x70asDataforDVI-Dport,regardless
DVI-D(PC)orDVI-D(DTV).
*****Returns0x90asDataforHDMIport,regardless
HDMI-DTVorHDMI-PC.
******Returns0xC0asDataforDisplayPort,
regardlessDisplayPort(DTV)orDisplayPort(PC).
38. Reset (Command: f k)
ToexecutethePicture,Screen,AudioandFactory
resetfunction.
Transmission
[f][k][][SetID][][Data][Cr]
Data 00:PictureReset
01:ScreenReset
02:FactoryReset
03:AudioReset
Acknowledgement
[k][][SetID][][OK/NG][Data][x]
39. Tile Mode (Command: d d)
ToselectaTileModeOff/OnandTileRow/Column
size.
Transmission
[d][d][][SetID][][Data][Cr]
Data 00toFF:1stbyte-TileColumnvalue
2ndbyte-TileRowvalue
*00,01,10,11meansTileModeOff.
Acknowledgement
[d][][SetID][][OK/NG][Data][x]
40. Tile Mode Check (Command: d z)
TocheckTileModestatus.
Transmission
[d][z][][SetID][][Data][Cr]
Data FF:CheckTileModestatus
Acknowledgement
[z][][SetID][][OK/NG][Data1][Data2][Data3][x]
Data1 00:TileModeOff
01:TileModeOn
Data2 00to0F:TileColumeValue
Data3 00to0F:TileRowValue
background
73
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
41. Tile ID (Command: d i)
TosetTileID.
Transmission
[d][i][][SetID][][Data][x]
Data 01toE1: TileID01to225**
FF:ReadTileID
**Datacouldnotbesetover(TileRow)x(Tile
Column)
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
*NGwillbereturnifdataisover(TileRow)x(Tile
Column),except0xFF.
42. Tile H Position (Command: d e)
TosettheTileHorizontalposition.
*OnlyavailablewhenTileNaturalModeisoff.
Transmission
[d][e][][SetID][][Data][Cr]
Data 00to32:Left(-50)toRight(0)
(*Left/RightvaluesdependonTileHsize.)
Acknowledgement
[e][][SetID][][OK/NG][Data][x]
43. Tile V Position (Command: d f)
TosettheTileVerticalposition.
*OnlyavailablewhenTileNaturalModeisoff.
Transmission
[d][f][][SetID][][Data][Cr]
Data 0to32:Bottom(0)toTop(50)
(*Bottom/TopvaluesdependonTileVsize.)
Acknowledgement
[f][][SetID][][OK/NG][Data][x]
44. Tile H Size (Command: d g)
TosettheTileHorizontalSize.
*SetTileHPositionto0x32(50)beforesettingTileH
Size.
*OnlyavailablewhenTileNaturalModeisoff.
Transmission
[d][g][][SetID][][Data][x]
Data 00to32:0to50
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
45. Tile V Size (Command: d h)
TosettheTileVerticalsize.
*SetTileVPositionto0x00beforesettingTileV
Size.
*OnlyavailablewhenTileNaturalModeisoff.
Transmission
[d][h][][SetID][][Data][x]
Data 00to32:0to50
Acknowledgement
[h][][SetID][][OK/NG][Data][x]
46. Natural Mode (In Tile Mode) (Comman : d j)
TosettheTileNaturalmode.
Transmission
[d][j][][SetID][][Data][x]
Data 00:Off
01:On
Acknowledgement
[j][][SetID][][OK/NG][Data][x]
background
74
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
47. DPM Select (Command: f j)
TosettheDPM(DisplayPowerManagement)
function.
Transmission
[f][j][][SetID][][Data][x]
Data 00:DPMSelectOff
01:DPMSelectOn
Acknowledgement
[j][][SetID][][OK/NG][Data][x]
48. FAN Control (Command : d o)
TosetFancontrolon/off.
Transmission
[d][o][][SetID][][Data][Cr]
Data 00:Auto
01:On
02:Manual
03:Off
Acknowledgement
[o][][SetID][][OK/NG][Data][x]
49. FAN Fault Check (Command: d w)
TosetFancontrolon/off.
Transmission
[d][w][][SetID][][Data][Cr]
Data FF:Datashouldbealwaysffinhexadecimal.
Acknowledgement
[w][][SetID][][OK/NG][Data][x]
Data 00:Fanfault
01:FanOK
50. Temperature Value (Command: d n)
Toreadtheinsidetemperatureofthedisplay.
Transmission
[d][n][][SetID][][Data][Cr]
DataFF:Datashouldbe alwaysffinhexadecimal.
Acknowledgement
[n][][SetID][][OK/NG][Data][x]
51. Remote Controller Lock/ Key Lock
(Command: k m)
Tolocktheremotecontrolandthefrontpanelcontrol
keysonthedisplay.
Transmission
[k][m][][SetID][][Data][Cr]
Data 00:Lockoff
01:Lockon
*Ifyouareintendednottousetheremotecontroller
andfrontpanelcontrolkeysonthedisplayforkindof
reasons,usethismode.RemotecontrollerLock/Key
Lockwillbereleasedautomaticallyafterdisplayis
rebooted.
*Displaywillnotbeturnedonbypoweronkeyof
remotecontrollerandfrontpanelcontrolkeys,ifkey
islockedoninstandbymode.
Acknowledgement
[m][][SetID][][OK/NG][Data][x]
52. Key (Command: m c)
TosendIRremotecontrolcode.
Transmission
[m][c][][SetID][][Data][Cr]
Data IR_KEY_CODE
Acknowledgement
[c][][SetID][][OK][Data][x]
Whendisplayisinthestandbymode,displaywillturn
onbyPowerbuttonofremotecontrolonly.
background
75
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
53. OSD Select (Command: k l)
ToselectOSD(OnScreenDisplay)on/off
Transmission
[k][l][][SetID][][Data][Cr]
Data 00:OSDOff
01:OSDOn
Acknowledgement
[l][][SetID][][OK/NG][Data][x]
54. Elapsed time return (Command: d l)
Toreadthepanelusedtime.
Transmission
[d][l][][SetID][][Data][x]
Data FF:Datashouldbealwaysffinhexadecimal.
Acknowledgement
[l][][SetID][][OK/NG][Data][x]
*Returneddatameansusedhoursinhexadecimal.
55. Serial No.Check (Command: f y)
Toreadtheserialnumbers.
Transmission
[f][y][][SetID][][Data][Cr]
Data FF:Datashouldbealwaysffinhexadecimal.
Acknowledgement
[y][][SetID][][OK/NG][Data][x]
56. S/W Version (Command: f z)
Toreadthesoftwareversion.
Transmission
[f][z][][SetID][][Data][Cr]
Data FF:Datashouldbealwaysffinhexadecimal.
Acknowledgement
[z][][SetID][][OK/NG][Data][x]
57. White Balance Red Gain (Command: j m)
Toadjustwhitebalanceredgain.
Transmission
[j][m][][SetID][][Data][Cr]
Data 00toFE:Redgain0to254
Acknowledgement
[m][][SetID][][OK/NG][Data][x]
58. White Balance Green Gain (Command: j n)
Toadjustwhitebalancegreengain.
Transmission
[j][n][][SetID][][Data][Cr]
Data 00toFE:Greengain0to254
Acknowledgement
[n][][SetID][][OK/NG][Data][x]
background
76
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
59. White Balance Blue Gain (Command: j o)
Toadjustwhitebalancebluegain.
Transmission
[j][o][][SetID][][Data][Cr]
Data00toFE:Bluegain0to254
Acknowledgement
[o][][SetID][][OK/NG][Data][x]
60. Backlight (Command: m g)
Toadjustscreenbacklight.
Transmission
[m][g][][SetID][][Data][Cr]
Data 00to64:Backlight0to100
Acknowledgement
[g][][setID][][OK/NG][Data][x]
background
77
ENG
ENGLISH
IR CODES
Code (Hexa) Function Note
95 EnergySaving( ) R/CBUTTON
08
POWER
R/CBUTTON(ON/OFF)
0B INPUT R/CBUTTON
C4 MonitorOn R/CBUTTON
C5 MonitorOff R/CBUTTON
43 MENU R/CBUTTON
40 Up( ) R/CBUTTON
41 Down( ) R/CBUTTON
07 Left( ) R/CBUTTON
06 Right( ) R/CBUTTON
44 OK( ) R/CBUTTON
28
BACK( )
R/CBUTTON
5B EXIT R/CBUTTON
4D PSM R/CBUTTON
02
Volume
R/CBUTTON
03
Volume
R/CBUTTON
09 MUTE R/CBUTTON
E0 Bright (PageUP) R/CBUTTON
E1 Bright (PageDown) R/CBUTTON
10to19 NumberKey0to9 R/CBUTTON
72 RedKey(IDON) R/CBUTTON
71 GreenKey(IDOFF) R/CBUTTON
63 YellowKey R/CBUTTON
61 BlueKey R/CBUTTON
7B TILE R/CBUTTON
76 ARC(4:3) R/CBUTTON
77 ARC(16:9) R/CBUTTON
AF ARC(ZOOM) R/CBUTTON
79 ARC(MARK) R/CBUTTON
99 AutoConfig. R/CBUTTON
B1 R/CBUTTON
B0 R/CBUTTON
BA R/CBUTTON
8F R/CBUTTON
8E R/CBUTTON
IR CODES
AllmodelsdonotsupporttheHDMI/USBfunction.
background
Make sure to read the Safety Precautions
before using the product.
Keep the Owner's Manual(CD) in an accessible
place for future reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
MODEL
SERIAL
Temporarynoise isnormalwhen poweringONor
OFFthisdevice.
WARNING-ThisisaclassA product. Ina domestic
e n v i r on m en t t h i s p r o d u c t m a y c a u s e r a d i o
interferenceinwhich casetheusermayberequired
totakeadequatemeasures.
Warrantyvoidifremoved.
Important
WARRANTYVOID
IFREMOVED
3850TAZ209Y
background
P/NO : 3840TRL098E (0801-REV00)
www.lge.com

Specifications

LG Electronics 47WX50MF-B Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

Product LG Electronics RS501 image
LG Electronics RS501 Lg K20 Lra
2020-10-25 1 docs
Product LG Electronics LGP925G image
LG Electronics LGP925G Lg Optimus 3d
2020-10-17 1 docs
Product LG Electronics PQDSBC1 image
LG Electronics PQDSBC1 LG Dry Contact with Economizer Interface
2026-05-15 1 docs
Product LG Electronics PESC0RV0 image
LG Electronics PESC0RV0 LG CO2 Sensor
2026-05-15 3 docs
Product LG Electronics PDRYCB400 image
LG Electronics PDRYCB400 LG Dry Contact Module 2 Contact Points 5V & 12V from Indoor PCB
2026-05-15 2 docs
Product LG Electronics PACS5A000 image
LG Electronics PACS5A000 LG AC Smart 5 with Mobile Web Access and BACnet Gateway
2026-05-15 2 docs
