BUILT- IN COOKING APPLIANCES
User Manual
MODELS
EOC617
EOC627/63K906
EXC617
EGC627/EXC627
EOC647/63K914
The symbols you will see in this booklet have these meanings:
WARNING
warning
Indicates information concerning your personal safety
WARNING
caution
Indicates information on how to avoid damaging the appliance
TIPS & INFORMATION
tips & information
Indicates tips and information about use of the appliance
ENVIRONMENTAL TIPS
environmental tips
Indicates tips and information about economical and
ecological use of the appliance
TIPS & INFORMATION
tips & information
Important – check for any damage or marks
If you find the appliance is damaged or marked, you must
report it within 7 days if you wish to claim for damage/
marks under the manufacturer’s warranty. This does not
affect your statutory rights.
ENVIRONMENTAL TIPS
environmental tips
Information on disposal for users
• Mostofthepackingmaterialsarerecyclable.Pleasedispose
of those materials by contacting your local authorities and
ask for the correct method of disposal.
CONGRATULATIONS
Congratulations and thank you for choosing our Built-in
Cooking Appliance. We are sure you will find your new
appliance a pleasure to use and a great asset to your
cooking. Before you use the appliance, we recommend that
you read through the whole user manual which provides
a description of the product and its functions.
To avoid the risks that are always present when you use a
cooking appliance, it is important that the appliance is installed
correctly and that you read the safety instructions carefully to
avoid misuse and hazards. For future reference, please store
this booklet in a safe place. This appliance complies to the
requirements of Australian Standard AS 60335.2.6
CONTENTS
Description of your appliance ..............................4
EOC617 ................................................................... 4
EOC627 ................................................................... 4
63K906 .................................................................... 4
EXC617 ....................................................................4
EGC627 ...................................................................4
EXC627 ....................................................................4
EOC647 ................................................................... 4
63K914 .................................................................... 4
Before operating your appliance for the first time ..5
Setting the time ...........................................................5
Preparing your appliance for the first time ......................... 5
Installing your oven accessories ......................................5
Operating the programmable clock ....................6
3 button programmable clock ........................................6
Using your oven ....................................................7
Understanding your oven functions .................................. 7
Cooling/venting fan ....................................................8
Condensation .............................................................9
Operating your oven temperature selector ........................9
Pre-heating your appliance ............................................9
Cooking guide .................................................... 10
Oven shelf location .................................................... 10
Choosing the best oven settings ...................................11
Roasting meat ......................................................12
Roasting poultry and fish ........................................12
Grilling guide ...................................................... 13
Grilling hints .............................................................13
Guide to better grilling ...............................................13
Turbo Grill (Multifunction models only) ............................13
Dealing with cooking problems ........................ 14
Get to know your oven ..................................... 15
Cleaning your appliance ................................... 16
Enamel ....................................................................16
Stainless Steel ...........................................................16
Glass ......................................................................16
Painted Control Panel & Door Trim ................................16
Oven ......................................................................16
Grill ......................................................................16
Cleaning your oven accessories ...................................16
Cleaning your oven door................................... 18
Solving problems ............................................... 21
Installation .......................................................... 22
Cabinet construction for your appliance .........................23
Oven Dimensions ......................................................23
Underbench Ovens .................................................... 23
Separate Grill Underbench Ovens ................................24
Separate Grill Wall Ovens ..........................................25
Hard wiring detail .....................................................25
Notes......................................................................26
Warranty .................................................................27
Record model and serial number here:
Model: ..................................................................
Serial number: ........................................................
2 CONTENTS Built-in Cooking
CONDITIONS OF USE
This appliance is intended to be used in household and
similar applications such as:
•Staffkitchenareasinshops,ofcesandother
working environments
•Farmhouses
•Byclientsinhotels,motelsandotherresidential
type environments
•Bedandbreakfasttypeenvironments
general safety
Built-in Cooking GENERAL SAFETY 3
An important read to avoid an electric shock or fire
Meanings of symbols used in this manual are shown below:
This symbol indicates never to do this
This symbol indicates always do this
The appliance is NOT suitable for use by children,
without supervision.
Young children should be supervised to ensure they
do not play with this appliance.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by
a person responsible for their safety.
During use this appliance becomes hot. Care should
be taken to avoid touching hot external and internal
surfaces when in use. Use oven gloves. Children
should be kept away to avoid burns and scalds.
This appliance must NOT be used as a space heater.
DO NOT spray aerosols in the vicinity of this
appliance while it is in operation.
DO NOT store flammable materials in the appliance
storage drawer or near this appliance, e.g. Aerosols.
Ensure all specified vents, openings and airspaces are
not blocked in order to avoid a fire.
DO NOT line the bottom of the oven or grill with foil
or cookware.
DO NOT MODIFY THIS APPLIANCE.
Oven warnings
During use the appliance becomes hot. Care should be
taken to avoid touching hot surfaces inside the oven.
Switch the appliance off before removing the oven light
glass for globe replacement.
To avoid an accident, ensure that oven shelves and
fittings are always inserted into the appliance in
accordance with the instructions.
Do not use the door as a shelf.
Do not push down on the open oven door.
Grill warnings
DO NOT leave grill on unattended.
The grill door must be left fully open whilst grilling
in a separate grill wall oven.
The grill drawer must be left approx. two finger widths
ajar whilst grilling in a separate grill underbench oven.
Always turn the grill off immediately after use as fat left
there may catch fire.
Do not cover the insert with foil, as fat left there may
catch fire.
Always keep the grill dish clean as any fat left may
catch fire.
To avoid a fire, ensure that grill trays and fittings are
always inserted into the appliance in accordance with
the instructions.
Do not place thick portions of food under the grill.
Foods may curl, catch and ignite.
Accessible parts may become hot when grill is in use.
Children should be kept away.
Installation, cleaning and servicing
Only authorised personnel must install and carry out
servicing this appliance. (Certificate of Compliance
to be retained)
Before using the appliance, ensure that all packing
materials are removed from the appliance.
In order to avoid any potential hazard, the enclosed
installation instructions must be followed.
Ensure that all specified vents, openings and airspaces
are not blocked.
Where the appliance is built into a cabinet, the cabinet
material must be capable of withstanding 70°C.
Always ensure the appliance is switched off before
cleaning or replacing parts.
Do not use steam cleaners, as this may cause moisture
build up.
Always clean the appliance immediately after any
food spillage.
To maintain safe operation, it is recommended that
the product be inspected every five years by an
authorised service person.
This appliance must be earthed.
description of
your appliance
Model: EOC617 Underbench Oven Conventional
Oven/Grill Temperature Selector One Hour Timer
Oven/Grill Temperature Selector One Hour Timer
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Oven Indicator Light Grill Indicator Light
Oven Indicator Light Grill Indicator Light
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Function Selector 3 Button Programmable Timer Oven/Grill Temperature Selector
Model: EOC627/63K906 Underbench Oven Fan Forced
Oven/Grill Temperature Selector One Hour Timer
Oven/Grill Temperature Selector One Hour Timer
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Oven Indicator Light Grill Indicator Light
Oven Indicator Light Grill Indicator Light
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Function Selector 3 Button Programmable Timer Oven/Grill Temperature Selector
Model: EXC617 Separate Grill Wall Oven Conventional
Oven/Grill Temperature Selector One Hour Timer
Oven/Grill Temperature Selector One Hour Timer
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Oven Indicator Light Grill Indicator Light
Oven Indicator Light Grill Indicator Light
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Function Selector 3 Button Programmable Timer Oven/Grill Temperature Selector
Model: EGC627/EXC627 Separate Grill Underbench Fan Forced/Separate Grill Wall Oven Fan Forced
Oven/Grill Temperature Selector One Hour Timer
Oven/Grill Temperature Selector One Hour Timer
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Oven Indicator Light Grill Indicator Light
Oven Indicator Light Grill Indicator Light
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Function Selector 3 Button Programmable Timer Oven/Grill Temperature Selector
Model: EOC647/63K914 Underbench Oven Multifunction 5
Oven/Grill Temperature Selector One Hour Timer
Oven/Grill Temperature Selector One Hour Timer
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Oven Indicator Light Grill Indicator Light
Oven Indicator Light Grill Indicator Light
Oven Temperature Selector Grill Temperature Selector One Hour Timer
Function Selector 3 Button Programmable Clock Oven/Grill Temperature Selector
4 DESCRIPTION OF YOUR APPLIANCE Built-in Cooking
Built-in Cooking BEFORE OPERATING YOUR APPLIANCE 5
before operating your
appliance for the first time
TIPS & INFORMATION
tips & information
Setting the time
After electrically connecting the appliance, you must set the
time of the day before you can operate your oven.
• Aftertheappliancehasbeenelectricallyconnected
‘12:00’ will be displayed and the clock ‘indicator’
will flash.
• Tosetthetimeofdayinhoursandminutespressthe
or buttons.
5 seconds after the last change, clock
‘indicator’
will disappear, confirming the time has been set.
Once the time has been entered, the clock advances minute
by minute.
NOTE: The clock has a 24-hour display.
Preparing your appliance for the first time
• Pleaseremoveallinternalboxesandbagsfromtheoven
before operation.
• Pleasewipeouttheoveninteriorpriortooperationwith
warm soapy water and polish dry with a soft clean cloth.
Do not close the oven door until the oven is completely dry.
• Newappliancescanhaveanodourduringrstoperation.
It is recommended to ‘run in’ your oven before you cook
for the first time. Run the oven at 180°C for 30 minutes
and ensure that the room is well ventilated.
• Forapplianceswithaseparategrillcompartment,rungrill
on maximum for 15 minutes with grill door open.
Installing your oven accessories
The type of oven furniture you receive is dependant on the
model you have purchased.
1. Side racks
Separate grill wall ovens come with side racks that are to be
fitted to the smaller “grill cavity”.
These can be attached to either side in the following manner:
• Insertthelargestpegintorearaccessholeprovided.
See diagram above.
• Thenlocatethefrontpegintothefrontaccessholeand
push in firmly.
2. Shelves and trays
Your oven comes with formed “easy clean” runners.
The shelves are designed to travel freely on runners without
being pulled out accidentally. Make sure you have the shelf
in the correct orientation before you slide it in. Otherwise it
could become jammed.
• Locatetherearedgeoftheshelfintherecessbetween
2 formed runners. See diagram below.
NOTE: The top ‘Ledge’ is not a shelf position.
Note the orientation of the side and rear features
• Withthefrontedgeraised,begintoslidetheshelfinto
the oven. Lower the front edge as you push the shelf
completely in.
• Thegrill/bakingtrayforunderbenchovenmodelssitsinto
a wire carrier that fits into the oven exactly like the shelves.
• Thegrill/bakingtrayforseparategrillwallovenmodels
slides into the wire runners in a similar manner.
• Whenfullyinserted,theshelf/trayshouldnotinterfere
with the closed oven door.
3 button programmable clock
6 BEFORE OPERATING YOUR APPLIANCE Built-in Cooking
Your oven is equipped with a 3 button timer that has the
following features:
• Timer
- you can set a countdown time that will beep
when the set time has elapsed.
• Cooktime
- you can set cooking duration. A timer will
count down the preset cooking time, beep when the time
has elapsed and turn the appliance off.
• Endtime
- instead of setting a cooking duration
you can set a cooking finish time. When the finish
time has been reached the timer will beep and turn the
appliance off.
• Delayedstartcookingtime-youcancombinethecooking
time and end cooking time to switch oven on and off at a
specific time during the day.
Selecting the timer
• PresstheMODEbuttonuntilthetimer‘indicator’begins
flashing.
• Setthecountdowntimeyouwantbyusingthe
and
buttons. 5 seconds after the last change the timer
‘indicator’ will stop flashing and the countdown will start
in minutes.
• Tostopthebeeper,pressanybutton.
• MaximumCountdownTimeis2hrs30mins
Setting the cooking duration
• Selectthedesiredovenfunctionandtemperature.
• Theovenindicatorlightwillglowandtheheatingsource
will come on.
• PresstheMODEbuttonuntilthecooktime
‘indicator’
begins flashing.
• Setthecookingdurationyouwantbyusingthe
and
buttons. Five seconds after the last change the cook time
‘indicator’ will stop flashing, and the time of day will be
displayed.
• Tostopbeeper,pressanybutton.
Note:
• Remembertoaddpre-heatingtimeifnecessary.
Setting the cooking end time
• Checkthattheclockdisplaysthecorrecttimeofday.
• Selectthedesiredovenfunctionandtemperature.The
oven indicator light will glow and the heating source will
come on.
• PressMODEbuttonuntiltheendtime
‘indicator’
begins flashing.
• Enterthetimeofdayyouwanttonishcookingby
pressing
or buttons. Five seconds after the last
change, the end time ‘indicator’ will stop flashing and the
current time of day will be displayed.
• Tostopbeeper,pressanybutton.
Setting the delayed start cooking time
• Setthecooktime
and end time as described in
the previous sections.
• Onceboththecooktimeandendtimehavebeenset,the
cook time and the end time ‘indicators’ will stop flashing
and the current time of day will be displayed.
• Tostopbeeper,pressanybutton.
using your oven
• Toinsertthegrilltrayinaseparategrillunderbench,fully
open the grill drawer and position the tray so that the slots
on the outer edges fit on the tabs on the slides.
Separate grill underbench
• Alwaysremoveunnecessarytraysanddishesfromoven
when roasting or baking.
Understanding your oven functions
Your oven will have a selection of the following functions.
Refer to “Description of your appliance” (page 4) to confirm
what functions are available to you.
Fan Forced
Heat comes from the element surrounding the fan. This fan
circulates the hot air around the oven cavity so that you can
put your food in different places in the oven and still cook
them at the same time.
You can use the “fan forced” function for multi-shelf cooking,
reheating cooked foods, pastries and complete oven meals.
It will cook at a lower temperature and be faster than baking.
Please note that some variation in browning is normal.
Bake
Heat comes from the elements, one above and one below
the food. The bottom element is a clean heat element and
is below the floor of the oven. Both elements are controlled
by the thermostat and will turn on and off to maintain the
set temperature.
Built-in Cooking BEFORE OPERATING YOUR APPLIANCE 7
To check or cancel settings
• Tocheckyoursettings,presstheMODE button until the
indicator you want is flashing.
• Tocancel“delayedstart”pressthemodebuttonuntil
“end time”
symbol starts flashing. Press and hold the
button until the clock no longer reverses (you will hear a
beep). If you have left the temperature and function knobs
at a setting the oven will start once the “end time”
indicator stops flashing.
• Tocancel“autoshutoff”pressthemodebuttonuntil“cook
time”
indicator starts flashing. Press and hold the
button until the clock no longer reverses (at 0:00 you will
hear a beep). This automatically cancels “delayed start”.
If you have left the temperature and function knobs at a
setting, the oven will start once the “cook time” indicator
stops flashing. Because you have cancelled “auto off” the
oven will continue to heat until you manually turn it off.
On completion of cooking
• Theheatsourcewillturnoff,thetimerwillbeepandthe
end time and/or cook time ‘indicators’ will flash.
• Eventhoughtheheatingelementturnsofftheovenwillstill
retain substantial heat. This will continue to cook the food
until it is removed or the oven cools down. If you do not
plan on being present when the oven turns off, you should
take this extra heating time into account.
• Turnthefunctionandtemperaturecontrolstotheoffposition.
• Pressanybuttontostopthetimerbeeping.
Adjusting the clock
• PresstheMODEbuttonuntiltheclock ‘indicator’
begins flashing.
• Pressthe
or buttons to change the time of day.
5 seconds after the last change, the clock ‘indicator’ will
disappear, confirming the time has been adjusted.
8 USING YOUR OVEN Built-in Cooking
using your oven
You can use the “Bake” function for single trays of biscuits,
scones, muffins, cakes, slices, casseroles, baked puddings,
roasts and delicate egg dishes.
Defrost
The “Defrost” function uses low temperature air that is
circulated by the fan. You can defrost (thaw) your food before
you cook it. You can also use “Defrost” to raise your yeast
dough and to dry fruit, vegetables and herbs.
Turbo Grill
“Turbo grill” offers you the benefits of both “bake” and
traditional “grill” functions. The grill element turns on and
off to maintain the set temperature while the fan circulates
the heated air. The oven door remains closed. You can use
“Turbo grill” for large cuts of meat. This gives you a result
that is similar to “rotisserie” cooked meat. Put your food on
a shelf in the second lowest shelf position. Put the grill dish
on the lowest shelf position to catch any spills. When using
“Turbo grill” it is not necessary to turn the food over during
the cooking cycle. Set temperature to 180°C.
Grill
The “Grill” directs radiant heat from the powerful upper
element onto the food. You can use the “Grill” function for
tender cuts of meat, steak, chops, sausages, fish, cheese
toasties and other quick cooking foods. Grill with the oven
door closed. Preheat your grill for 3 minutes to get the best
results. This will help seal in the natural juices of steak, chops
etc. for a better flavour. You can slide your grill dish into
either of the 2 spaces within the upper pairs of support rails.
Maxi Grill
“Maxi grill” directs radiant heat from 2 powerful upper
elements onto the food. You can use the “maxi grill” function
for tender cuts of meat, steak, chops, sausages, fish, cheese
toasties and other quick cooking foods. Grill with the oven
door closed.
“Maxi grill” allows you to take full advantage of the large grill
dish area and will cook faster than normal “grill”. For best
results it is recommended to preheat your grill for 3 minutes.
This will help seal in the natural juices of steak, chops etc. for
a better flavour. You can slide your grill dish into either of the
2 spaces within the upper pairs of support rails.
Separate Grill
The “grill” directs radiant heat from the powerful upper
elements onto the food. You can use the “grill” function for
tender cuts of meat, steak, chops, sausages, fish, cheese
toasties and other quick cooking foods. Grill with the oven
door open. Preheat your grill for 3 minutes to get the best
results. This will help seal in the natural juices of steak, chops
etc. for a better flavour. The grill dish is to be positioned
between the upper pair of support rails.
Cooling/Venting fan
Your built-in appliance is fitted with a cooling fan. It will
operate whenever you are using your oven or grill and will
blow warm air across the top of the oven door. In some
appliances the cooling fan may continue to operate after
the appliance is turned off. This is to cool the product.
Built-in Cooking USING YOUR OVEN 9
Condensation
Excess condensation may fog the oven door. This may
happen when you are cooking large quantities of food
from a cold start. You can minimise condensation by:
• Keepingtheamountofwaterusedwhilstcooking
to a minimum.
• Makingsurethattheovendoorisrmlyclosed.
• Bakingcustardinabakingdishthatisslightlysmaller
than the water container.
• Cookingcasseroleswiththelidon.
NOTE: If you are using water in cooking, this will turn
tosteamandmaycondenseoutsideyourappliance.
Thisisnotaproblemorfaultwithyouroven.
Operating your oven temperature selector
A thermostat controls the temperature in your appliance.
The temperature can be selected within the specified range.
To set the temperature, turn the temperature selector in a
clockwise direction to the desired setting. An indicator light
above the temperature selector will come on. When the
temperature is reached, the heating source switches itself off
and the indicator light goes out. When the oven temperature
falls below the desired setting, the heating source switches
on and the indicator light comes on again. Once the food
is cooked, turn the temperature selector back in an anti-
clockwise direction. Do not force it right round in a clockwise
direction as this will result in damage to the thermostat.
NOTE:Formultifunctionovensthedesiredcookingfunction
mustbeselectedbeforetheovenwilloperate.Oncethe
desiredfunctionhasbeenselected,usethetemperature
selectortosettherequiredtemperature.
Pre-heating your appliance
Pre-heating your oven is recommended in cooking and
grilling functions. For best results when baking you must
preheat your oven for 30 minutes.
With “Fan Forced”
1. It is recommended to preheat your appliance when
cooking or baking.
2. Set the desired temperature, by rotating your oven
temperature selector.
When the indicator light above the temperature selector goes
out, the oven has reached the desired temperature, place your
food into the oven, close the door and set the timer if you desire.
With “Grill”
Preheat the grill for at least 3 minutes to obtain best results.
This will help to seal the natural juices of steak, chops and
other meats for a better flavour.
Setting temperatures
The following table displays the temperature settings
for recipes which do not show actual temperatures.
Oven Temperature
º
C
Temperature
º
F
Cool 80 175
Low Heat
Very slow 100 – 110 210 – 230
Slow 130 – 140 265 – 285
Moderate
Heat
Moderately slow 150 – 160 300 – 320
Moderate 170 – 180 340 – 355
High Heat
Moderately hot 190 – 200 375 – 390
Hot 200 – 210 390 – 410
Very hot 220 – 230 430 – 450
Extremely hot 240 – 250 465 – 480
cooking guide
10 COOKING GUIDE Built-in Cooking
On completion of cooking
The oven will turn off, the timer will beep and the “end time“
and/or “cook time“ indicators will flash.
1. Turn the function and temperature controls to the off position.
2. Press any button to stop the timer from beeping.
• Selectthecorrectshelflocationforfoodbeingcooked.
• Makesuredisheswilltintotheovenbeforeyouswitchiton.
• Keepedgesofbakingdishesatleast40mmfromthe
side of the oven. This allows free circulation of heat and
ensures even cooking.
• Donotopentheovendoormorethannecessary.
• Donotplacefoodswithalotofliquidintotheovenwith
other foods. This will cause food to steam and not brown.
• Aftertheovenisturnedoffitretainstheheatforsome
time. Use this heat to finish custards or to dry bread.
• Donotusealotofcookingoilwhenroasting.Thiswill
prevent splattering oil on the sides of the oven and the
oven door. Polyunsaturated fats can leave varnish like
residue which is very difficult to remove.
• Forspongesandcakesusealuminium,brightnishedor
non-stick utensils.
Oven shelf location
Your oven comes with formed “easy clean” runners that allow
five positions for shelves. These are numbered from 1 (the lowest
shelf position) to 5 (the highest shelf position). See diagram.
In general:
• Whencookingwith1shelf,useposition3.
• Whencookingwith2shelves,usepositions2and4.
For more specific suggestions refer to the table on the
following page.
Use the oven efficiently, by cooking many trays of food at the
same time. For example:
• Cook2traysofscones,smallcakesorsausagerolls.
• Cookaroastdinneratthesametimeasyoucookchips
or vegetables.
Not a shelf
position
5
4
3
2
1
5 position rack
5
4
3
2
1
Not a shelf position
5 Position Rack
cooking guide
Built-in Cooking COOKING GUIDE 11
Choosing the best oven settings
The following table is intended as a guide and experience
may show some variation in cooking times necessary to meet
individual requirements. For best baking results preheat oven
for 30 minutes.
Food Non Fan forced mode Fan forced oven Time in minutes
Temperature
0
C Oven shelf position* Temperature
0
C Oven shelf position*
Plain or fruit scones 220 2 210 Any 10 –15
Rolled biscuits
Spooned biscuits
Shortbread biscuits
170 2 150 Any 10 –15
190 2 180 Any 12 –15
160 1 or 2 150 Any 30 – 35
Hard individual meringues
Soft individual meringues
Pavlova – 6 eggs
110 2 100 Any 90
180 2 165 Any 15 – 20
110 1 100 Any 75
Patty cakes
Sponge – 4 eggs
Shallow butter cake
Rich fruit cake
190 3 180 Any 15 – 20
180 2 170 Any 20 – 30
180 2 170 Any 25 – 40
140 2 130 Any 180
Shortcrust cornish pasty
#
Shortcrust custard tart
200
200/180
2
1
180
(180/160)
Any 40 – 45
(10/35
Cream puffs 210 2 200 Any 25 – 30
Yeast bread 210 1 200 Any 25 – 30
*Shelf position is counted from the bottom up. Bottom shelf is 1.
#
Turn down temperatures and times shown.
cooking guide
12 COOKING GUIDE Built-in Cooking
Roasting Meat
1. Place the meat in the oven and set the temperature
between 180°C and 200°C. (It is recommended to wrap
your meats in an oven roasting bag or foil to prevent fats
and oils from splattering, making it easier to clean your oven.)
2. Use the grill/oven dish and smokeless grill insert.
Place the meat on the insert.
3. Do not pierce the meat, as this will allow juices to escape.
4. When the meat is cooked, take the roast out of the oven,
wrap in aluminum foil and leave to stand for about 10 minutes.
This will help retain the juices when the meat is carved.
The table shows temperatures and cooking times for
different kinds of meat. These may vary depending
on the thickness or bone content of the meat.
Roasting poultry and fish
1. Place the poultry or fish in an oven set at a moderate
temperature of 180°C.
2. Place a layer of foil over the fish for about three quarters
of the cooking time.
The table shows temperatures and cooking times for different
kinds of fish and poultry. These may vary depending on the
thickness or bone content of the meat.
Meat/Poultry/Fish Recommended temperature
0
C Minutes per kilogram
Beef – Rare
– Medium
– Well done
200 35 – 40
200 45 – 50
200 55 – 60
Lamb – Medium
– Well done
200 40
60
Veal – Well done 180 60
Pork – Well done 200 60
Chicken 180 45 – 50
Duck 180 – 200 60 – 70
Turkey 180 40 – 45 (
10kg)
35 – 40 (
10kg)
Fish 180 20
grilling guide
Grilling hints
WARNING
warning
NOTE:Alwayscleanthegrill/ovendishaftereveryuse.
Excessivefatbuildupmaycauseare.
Depending on your model of appliance you will grill:
• Withthedooropen,ifyouaregrillingintheseparategrill
wall-oven compartment.
• Withthedrawerapproximatelytwongerwidthsajar,
if you are grilling in the separate grill underbench
compartment.
• Withthedooropenorclosed,ifyouaregrillinginthe
oven compartment.
As a method of cooking, grilling can be used to:
• Enhancetheavoursofvegetables,sh,poultryandmeat.
• Sealthesurfaceofthefoodandretainthenaturaljuices.
• Youcangrillwiththedooropenorclosed.
This table shows how to grill different types of meat:
Beef You can use tenderloin, rump, sirloin.
Brush with oil or melted butter, especially if the
meat is very lean.
Lamb You can use loin chops, shortloin chops, chump
chops, and forequarter chops.
Remove skin or cut at intervals to stop curling.
Brush with oil or melted butter.
Sausages Prick sausages to stop skin from bursting.
Poultry Divide into serving pieces.
Brush with oil.
Fish Brush with oil or melted butter and lemon juice.
Bacon Remove rind.
Grill flat and make into rolls.
Guide to better grilling
No definite times can be given for grilling because this
depends on your own tastes and the size of the food. These
times should only be used as a guide and remember to turn
the food over halfway through the cooking process.
Steak 15 – 20 minutes
Chops 20 – 30 minutes
Fish 8 – 10 minutes
Bacon 4 – 5 minutes
For better grilling results, follow these easy instructions:
1. Remove oven/grill dish and smokeless grill insert and
preheat grill for about 5 minutes.
2. Choose only prime cuts of meat or fish. If the cut is less
than 5mm thick it will dry out. If the cut is more than
40mm thick, the outside may burn whilst the inside
remains raw.
3. Do not place aluminium foil under the food as this
prevents fats and oils from draining away, which could
result in a fire.
4. Baste the food during cooking with butter, olive oil or
marinade. Grilled food is better if marinated before cooking.
5. Use tongs to turn food as a fork pierces the surface and
will let juices escape.
Turbo Grill (Multifunction models only)
If your appliance has Turbo grill as a function, this will assist
the grilling process by circulating the heat evenly around the
food. The recommended temperature setting is 180°C for all
fan grilling functions.
1. Use the smokeless grill insert and oven dish for all
Turbo grilling.
2. Position the dish in the lower half of the oven, for best
results.
3. Wipe off any oil or fat which spatters while the oven is
still warm.
There is no need to turn the meat as both sides are cooked
at the same time which means that the food is succulent.
Built-in Cooking GRILLING GUIDE 13
dealing with cooking
problems
Problem Causes Remedy
Uneven cooking Incorrect shelf position Select shelf that puts food in centre of oven
Oven tray too large Try other trays or dishes
Trays not in centre Put trays in centre
Air flow in oven uneven Rotate food during cooking
Grill tray affecting thermostat Remove grill tray from oven on bake modes
Baked products too brown on top Oven not preheated Preheat the oven
Baking tins too large for recipe Use correct size tins
Baking tins not evenly spaced Stagger baking tins at least 3cm between tins and
the oven walls
Products not evenly sized or spaced on tray
s
Make into same size and shape and spread
evenly over trays
Baked products too brown
on bottom
Baking tins too large Use correct size tins
Baking tins are dark metal or glass Change to shiny, light tins or lower the
temperature by 10°C
Food too low in oven Cook one shelf higher
Oven door opened too frequently during
baking
Don’t open the oven door until at least half the
cooking time has passed
Baking temperature too high Lower the temperature
Grill tray affecting thermostat Remove grill tray from oven on bake modes
Cakes have a cracked thick crust Baking temperature too high Lower the temperature
Food too high in oven Cook one shelf lower
Cake batter over mixed Mix just long enough to combine the ingredients
Baking tin too deep Check size of tin and use recommended size
Baking tins dark Change to shiny light tins
Baked products are pale,
flat and undercooked
Baking temperature too low Raise the temperature
Food too low in oven Cook one shelf higher
Baking time too short Increase cooking time
Incorrect baking tin size Use correct size tin
Cakes fallen in centre Baking temperature too low Raise the temperature
Baking time too short Increase cooking time
Proportions of ingredients incorrect for recipe Check recipe
Opening door too early during baking Do not open door until the last quarter of
cooking time
Roast meat and potatoes not brown
in fan oven
Poor hot air circulation Elevate food onto a rack to allow air circulation
Grill tray affecting thermostat Remove grill tray from oven on bake modes
Juices running out of meat Do not pierce meat with fork, turn with tongs
Grilled meats overcooked on
outside & raw in the centre
Grill at lower insert position
Grilled chops & steaks curling Cut into fat every 2cm (½")
14 COOKING PROBLEMS Built-in Cooking
get to know
your oven
Built-in Cooking GET TO KNOW YOUR OVEN 15
Get to know your new oven with this
‘Simple Test Cake’
Although we strive for a perfect performing oven, it’s
possible that there will be some variation in colour when
baking. Therefore, we suggest this simple, easy and delicious
to make Simple Test Cake, it can help you understand your
new oven. All ovens do sometimes have hot or cold spots,
therefore it is important to judge with your eye as you may
require to rotate during baking.
‘Simple Test Cake’
125g butter, softened to room temperature
1 cup caster sugar
1 teaspoon pure vanilla essence
4 large eggs
2 cups self-raising flour
Pinch of salt
4 tablespoons (80mL) full-cream milk
Method:
1. Butter base and sides of two, 20cm straight-sided round
or square cake pans. Then line the base with grease
proof or baking paper.
2. Preheat oven to moderate ‘180ºC’ (170ºC fan forced)
and ensure oven shelf is in the centre position of oven.
3. Cream softened butter and sugar until light in colour.
4. Add vanilla essence.
5. Then eggs one at a time, beating well after each
addition.
6. Sift flour and salt into the mixture and beat until
well combined.
7. Add milk and beat or stir to combine.
8. Spoon mixture equally between prepared cake pans.
9. Bake in preheated oven, middle shelf for about 25 to
35 minutes or until when tested with a fine cake skewer
it comes out clean or the edges of the cakes have come
away slightly from the sides of the cake pans.
10. Remove from oven to wire cake rack and rest for 5
minutes before removing from cake pans.
Cool completely.
To serve: Sandwich together with your favourite jam or
conserve, and dust top with pure icing sugar.
NOTE:Ifdesired,substitutebutterforeithermargarineor
oliveoilspread.
RecipeisbasedontheAustralianstandardmetric250mLcup
and20mLtablespoonsets.
16 CLEANING YOUR APPLIANCE Built-in Cooking
cleaning your
appliance
TIPS & INFORMATION
tips & information
Important:
• Alwaysmakesurethattheoveniselectricallyisolated
before cleaning. This can be done via the functional
switch located nearby. Do not use steam cleaners.
• Donotlinethebottomoftheovenorgrillwithfoil
or cookware as trapped heat will crack and graze the
floor of the oven.
Enamel
• Rubpersistentstainsvigorouslywithanylonscoureror
creamed powder cleansers.
NOTE:Youcanalsousehouseholdovenenamelcleaners
–followthemanufacturer’sinstructionscarefully.
• Donotuseharshabrasivecleaners,powdercleaners,
steel wool or wax polishes.
Stainless steel
All grades of stainless steel can stain, discolour or became
greasy. You must clean these areas regularly by following
the procedures below, if you want your appliance to look its
best, perform well and have a long life.
Care must be taken when wiping exposed stainless steel
edges...they can be sharp!
• Washwithwarmsoapywaterandrinsewithcleanwater.
• Ifyouwantabetterlook,wipeyourappliancewitha
suitable stainless steel cleaner then wipe with a soft lint
free cloth.
• Useastainlesssteelcleaneronlywherethestainlesssteel
is extremely dirty and/or discoloured. A suitable cleaner
can be purchased from Electrolux Service or Spares. See
back cover.
NOTE:Makesureyoufollowthepolishorbrushinglines
in the steel.
Glass
• Glasssurfacesondoorsarebestcleanedimmediately
after soiling.
• Adampclothmayhelpremovebakedonfooddeposits.
• Ovencleanerscanbeusedtoremovestubbornmarks
and stains.
Painted Control Panel & Door Trim
• Washwithsoapywaterandrinsewithcleanwater.
Wipe dry with a soft, lint free cloth.
• Donotuseharshabrasivecleaners,powdercleaners,
steel wool or wax polishes.
Oven
• Alwayskeepyourapplianceclean.Ensurethatfatsand
oils do not accumulate around elements, burners or fans.
• Alwayskeeptheovendish,baketraysandsmokelessgrill
insert clean, as any fat deposits may catch fire.
• Alwayswrapyourmeatsinfoiloranovenroastingbag
to minimise cleaning. Any polyunsaturated fats can leave
a varnish-like residue which is very difficult to remove.
Grill
• Alwayskeepthegrilldishandsmokelessgrillinsertclean,
as any fat deposits may catch fire.
Cleaning your oven accessories
Removing the shelves from your appliance
• Slidetheshelvestowardsyouuntiltheyreachthefrontstop.
• Tiltthemupatthefront,takingcarenottospillanycontents.
• Liftthemclear.
• Washthedishandinserttheshelvesinhotsoapywater.
• Reversetheabovestepstoputthegrilldishandshelves
back again.
• Seepage5formoredetails.
Removing the side racks (in separate grill wall ovens)
• Grasptheshelfsupportsatthefront.
• Pullthemrmlyinwards.
• Toinstallthesideracks,seepage5.
Built-in Cooking CLEANING YOUR APPLIANCE 17
cleaning your
appliance
Rotating latch models
• Rotatelatch180º.
The element will drop down freely.
Removing and replacing the oven light
• Turnovenlightglassanticlockwisetoremoveitforglobe
replacement.
• Aspecialhightemperatureresistantglobeshouldbe
used. This can be purchased from the Electrolux Customer
Care Centre.
WARNING
warning
Important:
Make sure the appliance is turned off before you remove
or replace parts, to avoid the possibility of electric shock.
Releasing the grill element
Retaining wire models
We have designed the upper element with a hanger clip to
help you reach your oven roof for cleaning.
Retaining wire models
• Liftelementupcarefully.
• Pushthesidesofthecliptogether.
The element will drop down freely.
cleaning your
oven door
18 CLEANING YOUR OVEN DOOR Built-in Cooking
WARNING
warning
Do not lift the door by the handle. Rough handling will cause
glass to break.
Removing the oven door
Your oven is equipped with a door that can be disassembled
in order to clean all the panes of glass. Remove the door
before cleaning.
• Openthedoorfullytoaccessthehingesthenrotatethe
‘stirrups’ (highlighted in the image) on both hinges fully
towards the oven.
• Slowlyclosetheovendooruntilitisstopsagainstthe
‘stirrups’ (about 45
O
).
• Grasptheovendoorwithahandeachsideofthedoor
and remove it from the oven by pulling it towards you.
• Laytheovendoorwiththeoutersidefacingdownwards
on something soft and flat (for example a blanket on a
kitchen table) to prevent scratches.
Removing oven door top trim
• Takeholdofthegridembossedsectionsofthedoor
trim at each end and press inwards to release the clips.
Remove the door trim by pulling it towards you.
Removing door glass panels
WARNING
warning
Rough handling, especially around the edges can cause the
glass to break.
• Lifttheblackborderedglasspaneloutoftheguide.
• Repeatthisforthesmallerclearglasspanel(whentted).
cleaning your
oven door
Built-in Cooking CLEANING YOUR OVEN DOOR 19
Cleaning door glass panels
WARNING
warning
Do not to use harsh abrasives on the glass panes as
the reflective surface plays a role in the function of the oven.
Do not place glass in dishwasher. Hand wash only with a
soft cloth and warm soapy water. When dry, polish with a
soft cloth and ensure the glass is dry before reassembly.
Bottom trim (on selected models)
• Thebottomtrimmayberemovedforcleaningby
snapping out and lifting away from the glass.
Re-assembling bottom trim
• Pushdownto“snap”eachsideofbottomtrimbackinto
door columns.
Re-assembling door glass panels
• Insertthesmallerclearglasspanel(whentted)rstfrom
above and at an angle to the profile of the door.
• Repeatfortheblackborderedglasspanelensuringthe
painted surface is facing to the downside.
cleaning your
oven door
Re-assembling top door trim
• Takeholdofthetopdoortrimateachsideandpositionit
to the inside edge of the glass.
• Pushthetrimdownwithitstopedgeoverglasspaneluntil
the clip snaps in on each side of the trim.
• Pushthemiddleofthetrimdowntoensureitisstraight
and firm against the glass panel.
Fitting the oven door
• Takeholdoftheovendoorwithahandoneachsideand
with the door at an angle of 45º, position the recesses at
the bottom of the door onto the hinge arms of the oven.
Let the door slide down the hinge arms as far as it will go.
• Openthedoorfullytoaccessthehingesthenrotatethe
‘stirrups’ (highlighted in the image) on both hinges back to
their original positions.
The oven door may now be closed.
20 CLEANING YOUR OVEN DOOR Built-in Cooking
solving problems
Built-in Cooking SOLVING PROBLEMS 21
Faults
If there is a problem with the oven and/or grill, please:
• Checkthepointslistedbelowbeforecallingforservice.
It may be possible to avoid a call by fixing the problem
yourself – and so continue cooking.
• Forcookingproblemsrefertopagedealingwithcooking
problems section.
NOTE:Wemaychargeforserviceevenintheguarantee
periodifyourproblemisduetothecauseslistedbelow.
Data Plate
When you need information, service or replacement parts please:
• Tellusthe1.Model2.ModelNumber&
3. Serial Number shown on the data plate.
The data plate is visible when the oven or grill door is open.
Problem Possible Cause
Oven or grill not working • Timeofdaynotset.
• Powernotturnedon.
• Controlsareincorrectlyset.
• Householdfusehasblownorpowersupplyisoff.
• Child-proofovenlockactivated.(Refertooperatinginstructions)
NOTE:Ifthehouseholdfusecontinuestoblow,calltheElectroluxCustomerCareCentre.
Oven light not working • Lampblownorlooseinsocket.
• Householdfusehasblown.
NOTE:Ifthehouseholdfusecontinuestoblow,calltheElectroluxCustomerCareCentre.
Oven not heating enough • Foilortraysonbottomofoven.
Oven not working • Timerisin“AUTO”mode.(Refertotimeroperatinginstructions)
• Householdfusehasblown.
NOTE:Ifthehouseholdfusecontinuestoblow,calltheElectroluxCustomerCareCentre.
Timer flashing on display • Powerfailureorinterruption.
NOTE:Resettimeofdayandanycookingfunctionsyouwereusing.(RefertoTIMERoperatinginstructions)
Unit smoking when first used • Protectiveoilsbeingremoved.
Condensation building up • Reduceamountofwaterusedincooking.(Somecondensationisnormal)
Door cannot be replaced
after removal
• Stirrupnotengagedproperly.
Shelves tight in oven • Shelfnotincorrectorientation.
When you need information, service or replacements please quote:
1. Model Number
2. Serial Number: You can find these on the data plate, which can be seen when the oven door is open. If you need more information, please contact the
Customer Care Centre on 1300 363 640 (Australia – Centre is open 8.00am to 5.00pm Monday to Friday EST) or 0800 234 234 (New Zealand –
Centre is open 8.00am to 5.00pm Monday to Friday). Only authorised service centres should carry out servicing. Otherwise warranty may be void.
If you have a warranty or spare parts enquiry, you should call the numbers listed on the back page.
WARNING
warning
USE AN AUTHORISED PERSON
As stated in the local municipal building codes and other relevant
statutory regulations.
• WiringconnectionsmustbeinaccordancewithAS/NZS
3000 Wiring Rules and any particular conditions of the
local authority.
• Refertodataplateforratinginformationandcircuitdiagram.
The data plate is positioned behind the bottom of the oven
door. The circuit diagram is positioned on the top panel of
the appliance.
• Anallpoledisconnectfunctionalswitchshouldbeprovided
near the appliance in an accessible position. Refer to AS/
NZS 3000 clause 4.3.11
• Wiringshouldbeprotectedagainstmechanicalfailure.
Refer to AS/NZS 3000 clause 3.9
• Ameansofdisconnectionwithacontactseparationofatleast
3mm must be supplied in the fixed wiring.
• Togainaccesstothemainsconnectionterminals,remove
the rear panel by unscrewing the 2 assembly screws.
NOTE:Whereconnectionismadetoamulti-phase240V
supply,thebridgepieceshouldberemovedfrombetween
theactiveconnections.
WARNING
warning
IMPORTANT: This appliance must be properly earthed.
• Donotlifttheappliancebythedoorhandles.
• Preparethecupboardopeningtomatchyourappliance
measurements. (See diagrams)
• Slideapplianceintothecupboard,ensuringthatthesupply
cable (where fitted) does not kink.
• Topreventtipping,usethescrewssuppliedtosecureyour
oven into the cupboard. Use just 2 screws for single cavity
ovens and 4 screws for dual cavity. Remove the bottom
door in dual cavity ovens to provide access to the bottom
2 screwing points. (See illustration page 23)
• Forappliancesttedwithasupplyexiblecord,ifthecord
is damaged, it must be replaced by the manufacturer or its
service agent or similarly qualified person in order to avoid
a hazard. The plug must be accessible after installation.
• Wheretheapplianceisbuiltintoacabinet,thecabinet
material must be capable of withstanding 70°C. Installation
into low temperature tolerant cabinetry (e.g. vinyl coated)
may result in deterioration of the low temperature coating by
discolouring or bubbling.
• Iftheapplianceisinstalledadjacenttovinyl-wrappedsurfaces,
use an installation kit available from the vinyl-wrap supplier.
• ElectroluxHomeProductscannotacceptresponsibility
for damage caused by installation into low temperature
tolerant cabinets.
• Afterinstallation,testandensurethattheapplianceoperates
correctly before handing it over to the customer.
WARNING
warning
CAUTION:Toavoidanypotentialhazard,youmustfollowour
instructionsbelowwhenyouinstallyourappliance.Failureto
installtheappliancecorrectlycouldinvalidateanywarranty
orliabilityclaimsandleadtoprosecution.
installation
22 INSTALLATION Built-in Cooking
installation
Built-in Cooking INSTALLATION 23
Cabinet construction for your appliance
For the best integration within a kitchen, install this appliance in
a standard 600mm wide cupboard that gives a flush fit with the
surrounding cupboard fronts (figure A).
A recess of 20mm is ideal. It can also be installed using a proud
fit with the surrounding cupboard (figure B).
NOTE:Yourappliancemustbemountedonaatsurfacefor
the full width and depth of the product.
Underbench Ovens
Your underbench oven looks best when the control panel is directly
under the benchtop. An upper infill panel may have to be added
if the cooktop placed above the benchtop is too deep.
Refer to cooktop installation instructions for required clearance
between cooktop and oven.
Oven Dimensions
Figure A – Flush fit (top view) Figure B – Proud fit (top view)
Underbench Oven
595 x 595 x 567mm (HxWxD)
Separate Grill Underbench Oven
725 x 595 x 567mm (HxWxD)
Separate Grill Wall Oven
888 x 595 x 567mm (HxWxD)
Cleat
Figure A – Flush fit (top view)
Figure B – Proud fit (top view)
Cupboard
door
Cupboard
door
Infill panel
Cupboard front
20mm
100mm max
100mm max 100mm max
Cleat
Figure A – Flush fit (top view)
Figure B – Proud fit (top view)
Cupboard
door
Cupboard
door
Infill panel
Cupboard front
20mm
100mm max
100mm max 100mm max
NOTE: If a powerpoint is fitted it must be
accessible with the appliance installed.
installation
24 INSTALLATION Built-in Cooking
Separate Grill Underbench Ovens
Recommended Cabinet Design
NOTETOINSTALLER:ForSeparateGrillUnderbench
InstallationswhereaCooktopisinstalleddirectlyabovethe
appliance,aminimumclearancedistanceof10mmmustbe
allowedforbetweenthebottomofthecooktopandthetop
oftheSeparateGrillUnderbenchOven.
720mm Module(s)
Bench top
720mm Module(s)
Kick Panel
Infill panel (2)
Cleat (2)
Cooker
platform
8mm
Supporting shelf 8mm below door line
to give perfect alignment of cooker
& cupboard (kickboard notched to suit).
Built-in Cooking INSTALLATION 25
installation
Separate Grill Wall Ovens
Hard Wiring Detail
1. Remove terminal cover plate from rear panel of appliance.
2. Fit wires through hole in cover plate and make connections
to terminals.
3. Engage wires into plastic clip. Secure plastic clip with two
long silver screws (supplied in separate bag).
4. Replace cover plate onto rear panel.
Plastic clip
securing points.
Plastic clips
Second active wire only
required (optional) for
multi-phase products.
26 NOTES Built-in Cooking
notes
This document sets out the terms and conditions of the product
warranties for Electrolux Appliances. It is an important document.
Please keep it with your proof of purchase documents in a safe place
for future reference should you require service for your Appliance.
1. In this warranty:
(a) ‘acceptable quality’ as referred to in clause 10 of this warranty has
the same meaning referred to in the ACL;
(b) ‘ACL’ means Schedule 2 to the Competition and Consumer Act 2010;
(c) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(d) ‘ASC’ means Electrolux authorised service centres;
(e) ‘Electrolux’ means Electrolux Home Products Pty Ltd of 163
O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in
respect of Appliances purchased in Australia and Electrolux (NZ)
Limited (collectively ‘Electrolux’) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
(f) ‘major failure’ as referred to in clause 10 of this warranty has the
same meaning referred to in the ACL and includes a situation when
an Appliance cannot be repaired or it is uneconomic for Electrolux, at
its discretion, to repair an Appliance during the Warranty Period;
(g) ‘Warranty Period’ means the Appliance is warranted against
manufacturing defects in Australia for 24 months and in New Zealand
for 24 months, following the date of original purchase of the Appliance;
(h) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. This warranty only applies to Appliances purchased and used in Australia
or New Zealand and used in normal domestic applications and is in
addition to (and does not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia or New Zealand.
3. During the Warranty Period Electrolux or its ASC will, at no extra charge
if your Appliance is readily accessible for service, without special
equipment and subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Electrolux or its ASC may
use remanufactured parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
This warranty does not apply to light globes, batteries, lters or similar
perishable parts.
4. Parts and Appliances not supplied by Electrolux are not covered by
this warranty.
5. To the extent permitted by law, you will bear the cost of transportation,
travel and delivery of the Appliance to and from Electrolux or its ASC. If
you reside outside of the service area, you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance to and from Electrolux or
its ASC.
In all instances, unless the Appliance is transported by Electrolux or an
Electrolux authorised representative, the Appliance is transported at the
owner’s cost and risk while in transit to and from Electrolux or its ASC.
6. Proof of purchase is required before you can make a claim under
this warranty.
7. You may not make a claim under this warranty unless the defect claimed
is due to faulty or defective parts or workmanship. Electrolux is not liable
in the following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions supplied with
the Appliance;
(b) the Appliance is modied without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced;
(d) the Appliance was serviced or repaired by anyone other than
Electrolux, an authorised repairer or ASC.
8. This warranty, the contract to which it relates and the relationship
between you and Electrolux are governed by the law applicable where
the Appliance was purchased. Where the Appliance was purchased in
New Zealand for commercial purposes the Consumer Guarantee Act
does not apply.
9. To the extent permitted by law and subject to your non-excludable
statutory rights and warranties, Electrolux excludes all warranties and
liabilities (other than as contained in this document) including liability for
any loss or damage whether direct or indirect arising from your purchase,
use or non use of the Appliance.
10. For Appliances and services provided by Electrolux in Australia,
the Appliances come with a guarantee by Electrolux that cannot be
excluded under the ACL. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the Appliance
repaired or replaced if the Appliance fails to be of acceptable quality and
the failure does not amount to a major failure.
The benets to you given by this warranty are in addition to your other
rights and remedies under a law in relation to the Appliances or services
to which the warranty relates.
11. At all times during the Warranty Period, Electrolux shall, at its discretion,
determine whether repair, replacement or refund will apply if an
Appliance has a valid warranty claim applicable to it.
12. For Appliances and services provided by Electrolux in New Zealand,
the Appliances come with a guarantee by Electrolux pursuant to the
provisions of the Consumer Guarantees Act, the Sale of Goods Act and
the Fair Trading Act.
13. To enquire about claiming under this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the terms
of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
14. You accept that if you make a warranty claim, Electrolux and its ASC
may exchange information in relation to you to enable Electrolux to meet
its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: BUILT-IN OVEN, COOKTOP
AND FREESTANDING COOKERS
Important Notice
Before calling for service, please ensure that the steps listed in clause 13 above have been followed.
FOR SERVICE
or to nd the address of your nearest
state service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
FOR SPARE PARTS
or to nd the address of your nearest
state spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to nd the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX (NZ) Limited
www.electrolux.co.nz
FOR SPARE PARTS
or to nd the address of your nearest
state spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
GOV_Warr_Aug13
This document sets out the terms and conditions of the product
warranties for Electrolux Appliances. It is an important document.
Please keep it with your proof of purchase documents in a safe place
for future reference should you require service for your Appliance.
1. In this warranty:
(a) ‘acceptable quality’ as referred to in clause 10 of this warranty has
the same meaning referred to in the ACL;
(b) ‘ACL’ means Schedule 2 to the Competition and Consumer Act 2010;
(c) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(d) ‘ASC’ means Electrolux authorised service centres;
(e) ‘Electrolux’ means Electrolux Home Products Pty Ltd of 163
O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in
respect of Appliances purchased in Australia and Electrolux (NZ)
Limited (collectively ‘Electrolux’) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
(f) ‘major failure’ as referred to in clause 10 of this warranty has the
same meaning referred to in the ACL and includes a situation when
an Appliance cannot be repaired or it is uneconomic for Electrolux, at
its discretion, to repair an Appliance during the Warranty Period;
(g) ‘Warranty Period’ means the Appliance is warranted against
manufacturing defects in Australia for 24 months and in New Zealand
for 24 months, following the date of original purchase of the Appliance;
(h) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. This warranty only applies to Appliances purchased and used in Australia
or New Zealand and used in normal domestic applications and is in
addition to (and does not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia or New Zealand.
3. During the Warranty Period Electrolux or its ASC will, at no extra charge
if your Appliance is readily accessible for service, without special
equipment and subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Electrolux or its ASC may
use remanufactured parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
This warranty does not apply to light globes, batteries, lters or similar
perishable parts.
4. Parts and Appliances not supplied by Electrolux are not covered by
this warranty.
5. To the extent permitted by law, you will bear the cost of transportation,
travel and delivery of the Appliance to and from Electrolux or its ASC. If
you reside outside of the service area, you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance to and from Electrolux or
its ASC.
In all instances, unless the Appliance is transported by Electrolux or an
Electrolux authorised representative, the Appliance is transported at the
owner’s cost and risk while in transit to and from Electrolux or its ASC.
6. Proof of purchase is required before you can make a claim under
this warranty.
7. You may not make a claim under this warranty unless the defect claimed
is due to faulty or defective parts or workmanship. Electrolux is not liable
in the following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions supplied with
the Appliance;
(b) the Appliance is modied without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced;
(d) the Appliance was serviced or repaired by anyone other than
Electrolux, an authorised repairer or ASC.
8. This warranty, the contract to which it relates and the relationship
between you and Electrolux are governed by the law applicable where
the Appliance was purchased. Where the Appliance was purchased in
New Zealand for commercial purposes the Consumer Guarantee Act
does not apply.
9. To the extent permitted by law and subject to your non-excludable
statutory rights and warranties, Electrolux excludes all warranties and
liabilities (other than as contained in this document) including liability for
any loss or damage whether direct or indirect arising from your purchase,
use or non use of the Appliance.
10. For Appliances and services provided by Electrolux in Australia,
the Appliances come with a guarantee by Electrolux that cannot be
excluded under the ACL. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the Appliance
repaired or replaced if the Appliance fails to be of acceptable quality and
the failure does not amount to a major failure.
The benets to you given by this warranty are in addition to your other
rights and remedies under a law in relation to the Appliances or services
to which the warranty relates.
11. At all times during the Warranty Period, Electrolux shall, at its discretion,
determine whether repair, replacement or refund will apply if an
Appliance has a valid warranty claim applicable to it.
12. For Appliances and services provided by Electrolux in New Zealand,
the Appliances come with a guarantee by Electrolux pursuant to the
provisions of the Consumer Guarantees Act, the Sale of Goods Act and
the Fair Trading Act.
13. To enquire about claiming under this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the terms
of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
14. You accept that if you make a warranty claim, Electrolux and its ASC
may exchange information in relation to you to enable Electrolux to meet
its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: BUILT-IN OVEN, COOKTOP
AND FREESTANDING COOKERS
Important Notice
Before calling for service, please ensure that the steps listed in clause 13 above have been followed.
FOR SERVICE
or to nd the address of your nearest
state service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PRODUCTS
www.electrolux.com.au
FOR SPARE PARTS
or to nd the address of your nearest
state spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
or to nd the address of your nearest
authorised service centre in New Zealand
FREE CALL 0800 10 66 10
(New Zealand only)
SERVICE NEW ZEALAND
ELECTROLUX (NZ) Limited
www.electrolux.co.nz
FOR SPARE PARTS
or to nd the address of your nearest
state spare parts centre in New Zealand
FREE CALL 0800 10 66 20
(New Zealand only)
GOV_Warr_Aug13
We are part of the Electrolux family.
Share more of our thinking at www.electrolux.com
© 2014 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
Part No. 0342 001 603 Issue B ECN 13A164C
Print code: CMAN_BICOOK_UM_Feb14
For further information on all appliances, or to obtain detailed
dimension and installation information, call into your Retailer,
phone or email our Customer Care team or visit our website:
Australia
phone: ..................................................1300 363 640
fax:.......................................................1800 350 067
email: ............................. [email protected]
website .............................................. www.chef.com.au
New Zealand
phone: ..................................................0800 234 234
fax:.......................................................0800 363 600
email: ................................[email protected]
website ............................................www.simpson.co.nz
Top service
Top Service encompasses the after sales service provided by
The Electrolux Group to consumers including delivery, home
service and spare parts.
like to know more?
