HTS9540
Register your product and get support at
www.philips.com/welcome
EN User manual
DA Brugervejledning
DE Benutzerhandbuch
EL Εγχειρίδιο χρήσης
ES Manual del usuario
FI Käyttöopas
FR Mode d’emploi
IT Manuale utente
NL Gebruiksaanwijzing
NO Brukerhåndbok
PT Manual do utilizador
SV Användarhandbok
TR Kullanım kılavuzu
1
5 Change settings 20
Access the setup menu 20
Change video settings 20
Change audio settings 21
Set up surround sound automatically 21
Set up surround sound manually 22
Set up network 22
Set up EasyLink 22
Multiview 23
Change preference settings 23
Change advanced settings 23
6 Update software 24
Check software version 24
Update software from the network 24
Update software from a USB 24
Update electronic user manual 25
7 Product specications 25
8 Troubleshooting 27
Main unit 27
Picture 27
Sound 27
Play 27
Network 28
9 Index 29
Contents
1 Important 2
Safety 2
Product care 2
Disposal of your old product and batteries 3
3D health warning 3
2 Your home theater 4
Main unit 4
Remote control 4
3 Connect your home theater 7
Connectors 7
Connect to the TV 8
Connect audio from TV or other devices 9
Connect to a computer network
and the Internet
10
Connect a wireless module 11
4 Use your home theater 11
Before you start 11
Access the home menu 11
Choose your sound 12
Play a disc 13
Use Bonus View on Blu-ray 13
Access BD-Live on Blu-ray 14
Play 3D video 14
Play from a USB storage device 14
More play features for disc or USB 15
Play from PC (DLNA) 16
Browse Net TV 17
Access online video stores 17
Play from radio 18
Play audio from TV or other devices 19
Play from an MP3 player 19
Play from an iPod or iPhone 19
Use Philips EasyLink 19
English
EN
2
• For speakers with stands, use only the
supplied stands. Secure the stands
to the speakers tightly. Place the
assembledstandsonat,levelsurfaces
that can support the combined weight
of the speaker and stand.
• Never place the product or any objects
on power cords or on other electrical
equipment.
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
• Visible and invisible laser radiation
when open. Avoid exposure to beam.
• Do not touch the disc optical lens
inside the disc compartment.
Risk of overheating!
• Neverinstallthisproductinaconned
space. Always leave a space of at least
four inches around the product for
ventilation. Ensure curtains or other
objects never cover the ventilation
slots on the product.
Risk of contamination!
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries if they are exhausted
or if the remote control is not to be
used for a long time.
• Batteries contain chemical substances,
they should be disposed of properly.
Product care
• Do not insert any objects other than
discs into the disc compartment.
• Do not insert warped or cracked discs
into the disc compartment.
• Remove discs from the disc
compartment if you are not using the
product for an extended period of time.
• Onlyusemicroberclothtocleanthe
product.
1 Important
Read and understand all instructions before you
use your home theater. If damage is caused by
failure to follow instructions, the warranty does
not apply.
Safety
Risk of electric shock or re!
• Never expose the product and
accessories to rain or water. Never
place liquid containers, such as vases,
near the product. If liquids are spilt on
or into the product, disconnect it from
the power outlet immediately. Contact
Philips Consumer Care to have the
product checked before use.
• Never place the product and
accessoriesnearnakedamesorother
heat sources, including direct sunlight.
• Never insert objects into the
ventilation slots or other openings on
the product.
• Where the mains plug or an appliance
coupler is used as the disconnect
device, the disconnect device shall
remain readily operable.
• Disconnect the product from the
power outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Risk of short circuit or re!
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on
the back or bottom of the product.
Never connect the product to the
power outlet if the voltage is different.
Risk of injury or damage to the home theater!
• For wall-mountable products, use
only the supplied wall mount bracket.
Secure the wall mount to a wall that
can support the combined weight
of the product and the wall mount.
Koninklijke Philips Electronics N.V.
bears no responsibility for improper
wall mounting that results in accident,
injury or damage.
EN
3
3D health warning
If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical
professionalbeforeexposingyourselftoashing
light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache
or disorientation, we recommend not watching
3D for extended periods of time. If you
experience any discomfort, stop watching 3D
and do not immediately engage in any potentially
hazardous activity (for example driving a car)
until your symptoms have disappeared. If
symptoms persist, do not resume watching 3D
withoutconsultingamedicalprofessionalrst.
Parents should monitor their children during 3D
viewing and ensure they do not experience any
discomfort as mentioned above. Watching 3D is
not recommended for children under six years of
age as their visual system is not fully developed yet.
Disposal of your old product
and batteries
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot be
disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.
English
EN
4
Remote control
Note
•
Your home theater is supplied with one of the
following remote controls.
Remote control - A
2
5
6
7
10
11
12
1
3
4
8
14
13
9
17
18
19
15
16
2 Your home theater
Congratulations on your purchase, and welcome
toPhilips!Tofullybenetfromthesupportthat
Philips offers, register your home theater at
www.philips.com/welcome.
Main unit
a +/- (Volume)
Increases or decreases volume.
b SOURCE
Selects an audio/video source for the home
theater.
c (Standby-On)
Switches on the home theater or switches
to standby mode.
d (Play/Pause)
Starts, pauses or resumes play.
e (Stop)
Stops play.
f (Open/Close)
Opens or closes the disc compartment.
g Display panel
h Disc compartment
EN
5
o (Stop) / (Eject / Open/Close)
• Stops play.
• Press and hold to eject the disc or
open the disc compartment.
• In radio mode, erases the current
preset radio station.
p (Mute)
Mutes or restores volume.
q BACK
Returns to a previous menu screen.
r POP-UP MENU/DISC MENU
Accesses or exits the disc menu.
s Source buttons
• Color buttons (for Blu-ray discs):
Selects tasks or OPTIONS.
• DISC: Switches to disc source.
• RADIO: Switches to FM radio.
• DOCK for iPod: Switches to Philips
Dock for iPod/iPhone.
• SOURCE: Selects an audio input
source.
a (Standby-On)
• Switches the home theater on or to
standby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
b (Home)
Accesses the home menu.
c SOUND SETTINGS
Accesses or exits various sound OPTIONS.
d Navigation buttons
• Navigates menus.
• In radio mode, press left or right to
start auto search.
e OK
• Conrmsanentryorselection.
f OPTIONS
• Accesses more play OPTIONS during
playback.
• In radio mode, programs radio stations.
g +/- (Volume)
Increases or decreases volume.
h (Play)
Starts or resumes play.
i (Pause)
Pauses play.
j / (Fast Backward/Fast Forward)
Fast backwards or fast forwards. Press
repeatedly to change the search speed.
k Alphanumeric buttons
Enters values or letters (using SMS style
entry).
l SUBTITLE
Selects subtitle language for video.
m TOP MENU
Accesses the main menu of a video disc.
n / (Previous/Next)
• Skips to the previous or next track,
chapterorle.
• In radio mode, selects a preset radio
station.
English
EN
6
b (Home)
Accesses the home menu.
c (Disc menu)
Accesses or exits the disc menu.
d Navigation buttons
• Navigates menus.
• In radio mode, press left or right to
start auto search.
e / (Previous/Next)
• Skips to the previous or next track,
chapterorle.
• In radio mode, selects a preset radio
station.
f OK
Conrmsanentryorselection.
g (Sound OPTIONS)
Accesses or exits various sound OPTIONS.
h (OPTIONS)
• Accesses more play OPTIONS during
playback.
• In radio mode, programs radio stations.
i (Play)
Starts or resumes play.
j +/- (Volume)
Increases or decreases volume.
k (Pause)
Pauses play.
l Source buttons / Color buttons
• Blu-ray discs: Selects tasks or
OPTIONS.
• AUDIO SOURCE: Selects an audio
input source.
• DOCK for iPod: Switches to Philips
Dock for iPod/iPhone.
• RADIO: Switches to FM radio.
• DISC: Switches to disc source.
m Alphanumeric buttons
Enters values or letters (using SMS style
entry).
n TOP MENU
Accesses the main menu of a video disc.
o SUBTITLE
Selects subtitle language for video.
Remote control - B
a (Standby-On)
• Switches the home theater on or to
standby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
3
4
6
7
8
9
11
12
13
14
1
2
5
15
5
16
10
18
17
EN
7
3 Connect your home
theater
This section helps you connect your home theater
to a TV and other devices. The basic connections of
the home theater with its accessories are provided
in the Quick Start. For a comprehensive interactive
guide, see www.connectivityguide.philips.com.
Note
•
Refer to the type plate at the back or bottom
oftheproductforidenticationandsupply
ratings.
• Before you make or change any connections,
ensure that all devices are disconnected from
the power outlet.
Connectors
Connect other devices to your home theater.
Front connectors
a (USB)
Audio, video or picture input from a USB
storage device.
b MP3 LINK
• Audio input from an MP3 player.
• Connects to the auto calibration
microphone.
p (Stop)
• Stops play.
• Press and hold to eject the disc or
open the disc compartment.
• In radio mode, erases the current
preset radio station.
q / (Fast Backward/Fast Forward)
Fast backwards or fast forwards. Press
repeatedly to change the search speed.
r (Back)
Returns to a previous menu screen.
English
EN
8
Connect to the TV
Connect your home theater directly to a TV
through one of the following connectors (from
highest to basic quality video):
a HDMI
b Component video
c Composite video
Option 1: Connect to the TV through
HDMI
Note
•
The HDMI connector on the TV might be
labeled HDMI IN or HDMI ARC.
• If the TV supports HDMI Audio Return
Channel (ARC), you can use it to output digital
audio to the home theater.
• If the HDTV has a DVI connector, connect
using an HDMI/DVI adapter.
• If the TV supports EasyLink HDMI CEC,
control the home theater and TV with one
remote control (see ‘Use Philips EasyLink’ on
page 19).
Option 2: Connect to the TV through
YPbPr (component video)
Note
•
The component video cable or connector
might be labeled Y Cb Cr or YUV.
TV
Back connectors
a AC MAINS~
Connects to the power supply.
b AUDIO IN-AUX 1/AUX 2
Connects to the analog audio output on the
TV or an analog device.
c SUBWOOFER
Connects to the supplied subwoofer.
d LAN
Connects to the LAN input on a broadband
modem or router.
e HDMI OUT (ARC)
Connects to the HDMI input on the TV.
f VIDEO OUT
Connects to the video input on the TV.
g SD CARD
Slot for SD card. Downloads video from
online video stores (see ‘Access online video
stores’ on page 17).
h ANTENNA FM 75
Signal input from an antenna, cable or satellite.
i VIDEO OUT (Y Pb Pr)
Connects to the component video input on
the TV.
j DIGITAL IN-OPTICAL
Connects to the optical audio output on
the TV or a digital device.
k DIGITAL IN-COAXIAL
Connects to the coaxial audio output on
the TV or a digital device.
l DOCK for iPod
Connects to a Philips Dock for iPod/iPhone.
(See Quick Start guide.)
m Wireless Rear Audio
Connects to a Philips wireless module.
(Model: Philips RWSS9500, sold separately.)
n SPEAKERS
Connects to the supplied speakers.
EN
9
Option 1: Connect audio through analog
audio cables
(Cable not supplied)
Option 2: Connect audio through coaxial
cable
Note
•
The digital coaxial cable or connector might be
labeled COAXIAL/DIGITAL OUT or SPDIF
OUT.
(Cable not supplied)
TV
TV
(Cable not supplied)
Option 3: Connect to the TV through
composite video (CVBS)
Note
•
The composite video cable or connector might
be labeled AV IN, VIDEO IN, COMPOSITE or
BASEBAND.
Connect audio from TV or
other devices
Use your home theater to play audio from the
TV or other devices such as a cable box.
Tip
•
Press SOURCE / AUDIO SOURCE
repeatedly to select the audio output of your
connection.
Component Video Out
Component Video In
TV
TV
English
EN
10
(Cable not supplied)
Set up network
1 Connect the home theater to a network
router through wired or wireless network
connection. This home theater has a built-in
Wi-Fi for easy access to the wireless network.
2 Turn on your TV and switch to the correct
source for the home theater.
3 Press (Home).
4 Select [Setup], then press OK.
5 Select [Network] > [Network Installation],
then press OK.
• For wired network, select [Wired
(Ethernet)] and press OK.
• For wireless network, select [Wireless
(Wi-Fi)] and press OK.
6 Follow the instructions on the TV to
complete the setup.
» The home theater connects to the
Internet. If connection fails, select [Retry],
then press OK.
7 Select [Finish], then press OK to exit.
Caution
•
Familiarize yourself with the network router,
media server software and networking
principles before attempting to connect the
home theater to a computer network. If
necessary, read documentation accompanying
network components. Philips is not responsible
for lost, damaged or corrupt data.
LAN
www
Option 3: Connect audio through a digital
optical cable
Note
•
The digital optical cable or connector might be
labeled as SPDIF OUT or OPTICAL OUT.
(Cable not supplied)
Connect to a computer
network and the Internet
Connect the home theater to a computer
network and enjoy:
• Multimedia content streamed from
your computer : view photos, play
musicandwatchvideolesstreamed
from your computer (see ‘Play from PC
(DLNA)’ on page 16).
• Net TV : browse Net TV services (see
‘Browse Net TV’ on page 17).
• Software update : update the software
of the home theater through the
network (see ‘Update software from
the network’ on page 24).
What you need:
• A network router (with DHCP
enabled).
• A network cable (RJ45 straight cable).
• A computer with media server
software installed (see ‘Set up media
server software’ on page 16).
• For Net TV and software update,
make sure that the network router
has access to the Internet and is not
restrictedbyrewallsorothersecurity
systems.
TV
EN
11
4 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Before you start
Check that you:
• Make the necessary connections described
in the Quick Start and User Manual.
• Completethersttimesetup.First
time setup appears when you turn on
thehometheaterforthersttime.If
you do not complete the setup, you
are prompted to complete it each time
you turn on the home theater.
• Switch the TV to the correct source
for the home theater.
Access the home menu
The home menu gives you easy access to
connected devices, audio and video settings, and
other features.
1 Press (Home).
» The home menu appears.
2 Press the Navigation buttons and OK to
select the following:
• [play Disc] : Starts disc play.
• [browse USB] : Accesses the content
browser of the connected USB storage
device.
• [browse iPod] : Accesses the content
browser of the connected iPod or
iPhone.
• [browse PC] : Accesses the content
browser of the connected PC network.
• [browse Net TV] : Accesses Net TV.
• [Setup] : Accesses menus to change
picture, sound and other settings.
• [User Manual] : Launches the
electronic user manual.
Connect a wireless module
Note
•
When you connect and switch on the wireless
module, the rear speaker connectors on the
home theater are muted, the rear surround
sound is output through the connectors on the
wireless receiver.
(Wireless module not supplied - Philips RWSS9500)
Wireless Rear Audio
English
EN
12
Change sound mode
Selectpredenedsoundmodestosuityour
video or music.
1 Press SOUND SETTINGS /
(Sound OPTIONS).
2 Select SOUND, then press OK.
3 Press the Navigation buttons (up/down) to
select the following settings:
• ACTION/ROCK : Enhanced low and
high-range. Ideal for action movies and
rock or pop music.
• DRAMA/JAZZ : Clear mid and high-
range. Ideal for drama movies and jazz
music.
• GAMING/PARTY : Moderate low-
range and strong mid-range. Ideal for
video games and party.
• CONCERT/CLASSIC : Neutral sound.
Ideal for live concerts and classical
music.
• SPORTS : Moderate mid-range and
surround effects for clear vocals and
the atmosphere of a live sport venue.
• NEWS : Enhanced mid-range for clear
vocals and speech.
4 Press OKtoconrmyourchoice.
Change surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SOUND SETTINGS /
(Sound OPTIONS).
2 Select SURROUND, then press OK.
3 Press the Navigation buttons (up/down) to
select the following settings:
• 360SOUND : 9.1 surround sound
mode, best cinematic experience.
• 360SOUND STEREO : Enhanced
stereo mode with 4.1 channels.
• STEREO : Two-channel stereo sound.
Ideal for listening to music.
• MULTI -CH : Traditional 5.1 channels
for a more relaxing cinematic
experience.
4 Press OKtoconrmyourchoice.
Choose your sound
This section helps you choose the ideal sound for
your video or music.
1 Press SOUND SETTINGS /
(Sound OPTIONS).
2 Press the Navigation buttons (left/right) to
access the sound OPTIONS.
Sound experience Description
AUTO VOLUME Sets a constant output
signal at the speaker
output. This option is best
for TV audio input where
the commercial signal level
is usually higher than the
content.
SOUND Selects a sound mode.
SURROUND Selects a surround sound
or stereo sound.
TREBLE Adjusts the high frequency
output.
MID Adjusts the middle
frequency output.
BASS Adjusts the low frequency
output.
AUDIO SYNC Delays the audio to match
the video.
3 Select an option, then press OK.
4 Press BACK to exit.
Ifyoudonotpressabuttonwithinve
seconds, it automatically exits the menu.
Change auto volume
Select the level of volume which output from
your TV or other devices to the home theater.
1 Press SOUND SETTINGS /
(Sound OPTIONS).
2 Select AUTO VOLUME, then press OK.
3 Press the Navigation buttons (up/down) to
select ON or OFF.
4 Press OKtoconrmyourchoice.
EN
13
Button Action
/
Skips to the previous or
nexttrack,chapterorle.
/
Fast backwards or fast
forwards. Press repeatedly
to change the search speed.
Navigation
buttons
(up/down)
Rotates the picture
counter-clockwise
or clockwise.
SUBTITLE Selects subtitle language
for video.
POP-UP MENU/
DISC MENU /
(Disc menu)
Accesses or exits the disc
menu.
OPTIONS /
(OPTIONS)
Accesses more play
OPTIONS during playback.
For video formats such as, DivX and WMV:
• To stop play, press .
• To resume the video from where you
stopped, press
(Play).
• To play the video from the start,
press OK.
Note
•
ToplayDivXDRM-protectedlesfromadisc
or a USB storage device, connect your home
theater to a TV through an HDMI cable.
Use Bonus View on Blu-ray
Blu-ray discs that support the Bonus View
feature (also known as Picture-In-Picture) allow
you to view special content such as a director’s
commentary while watching the main feature.
1 If necessary, enable BonusView (or Picture-
In-Picture) in the Blu-ray disc menu.
2 During playback of the main feature,
press
OPTIONS / (OPTIONS).
» The OPTIONS menu is displayed.
3 Select [PIP Selection] > [PIP], then
press OK.
» PIP OPTIONS [1]/[2] depend on the
video contents.
» The picture-in-picture video appears in a
small window.
Change treble, mid and bass
Change the high frequency (treble), mid
frequency (mid) and low frequency (bass)
settings of the home theater to suit your video
or music.
1 Press SOUND SETTINGS /
(Sound OPTIONS).
2 Select TREBLE, MID or BASS, then press
OK.
3 Press the Navigation buttons (up/down) to
adjust the frequency level.
4 Press OKtoconrm.
Synchronize audio with video
If the audio and video are not synchronized, you
can delay the audio to match the video.
1 Press SOUND SETTINGS /
(Sound OPTIONS).
2 Select AUDIO SYNC, then press OK.
3 Press the Navigation buttons (up/down) to
sync the audio with the video.
4 Press OKtoconrm.
Play a disc
The home theater can play a wide variety
of discs, including video, audio and mixed media
(for example, a CD-R that contains JPEG pictures
and MP3 music).
1 Insert a disc into the home theater.
2 Press DISC, or select [play Disc] in the
home menu and press OK.
» The disc plays or the disc main menu
appears.
3 Press the following buttons to control play:
Button Action
Navigation
buttons
Navigate menus.
OK Conrmsanentryor
selection.
(Play)
Starts or resumes play.
Pauses play.
Stops play.
English
EN
14
Play 3D video
Your home theater can play 3D videos on 3D TVs.
Before you start, make sure that:
• your TV is a 3D TV, and is connected
to your home theater through HDMI,
• your disc is a Blu-ray 3D disc, and
• you have 3D glasses that are
compatible with your 3D TV.
1 Insert a Blu-ray 3D disc into your home theater.
» Your TV switches to the correct HDMI
source, and the disc plays automatically.
2 If the disc does not play automatically, press
DISC or select [play Disc] in the home
menu, and then press OK.
3 Press the play buttons to control play.
When you search forward or backward,
and in some other play modes, the video
displays in 2D. It returns to 3D when you
play normally again.
4 Put on the 3D glasses to enjoy the 3D
effects.
Play 3D discs in 2D
1 Press (Home).
2 Select [Setup] > [Video] >
[Blu-ray 3D video] > [Off].
3 Press OK.
4 Play your Blu-ray 3D disc.
» The 3D video is displayed in 2D.
Play from a USB storage device
ThehometheateristtedwithaUSBconnector
that allows you to view pictures, listen to music or
watch movies stored on a USB storage device.
1 Connect the USB storage device to the
home theater.
2 Press (Home).
» The home menu appears.
3 Select [browse USB], then press OK.
» A content browser appears.
4 Selectale,thenpressOK.
5 Press the playback buttons to control play
(see ‘Play a disc’ on page 13).
4 Select [2nd Audio Language] or
[2nd Subtitle Language], then press OK.
5 Select the language to play, then press OK.
Note
•
To turn off the Bonus View (Picture-in-
Picture), press
OPTIONS / (OPTIONS),
select [PIP Selection] > [Off], then press OK.
Access BD-Live on Blu-ray
BD-Live enabled Blu-ray discs include exclusive
services such as movies and other online bonuses.
1 Prepare the internet connection and set up
the network (see ‘Connect to a computer
network and the Internet’ on page 10).
2 Connect the USB storage device to the
home theater.
3 Select the BD-Live icon in the disc menu,
then press OK.
» BD-Live starts to load. The loading time
depends on the disc and your internet
connection.
4 Press the Navigation buttons to navigate
BD-Live.
5 Press OK to select an item.
Note
•
The range of BD-Live services depends on
the disc.
• When you use BD-Live, data on the disc and
home theater are accessed by the content
provider.
• Use a USB storage device with at least 1GB of
freespacetostorethedownloadedles.
• Ifthereisinsufcientmemorytodownload
BD-Live content, clear memory space.
EN
15
• [Titles]:Selectsaspecictitle.
• [Chapters]:Selectsaspecicchapter.
• [Angle List] : Selects a different camera
angle.
• [Menus] : Displays the disc menu.
• [PIP Selection] : Displays Picture-in-
Picture window.
• [Zoom] : Zooms into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Repeat] : Repeats a chapter or title.
• [Repeat A-B] : Marks two points
within a chapter or track for repeat
play, or turns off repeat mode.
• [Picture Settings] : Selects a
predenedcolorsetting.
Use picture OPTIONS
Access several useful features while viewing
pictures.
1 Press OPTIONS / (OPTIONS).
» The pictures OPTIONS menu appears.
2 Press the Navigation buttons and OK to
select and adjust:
• [Rotate +90] : Rotates the picture
90 degree clockwise.
• [Rotate -90] : Rotates the picture
90 degree counter-clockwise.
• [Zoom] : Zooms into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Info] : Displays picture information.
• [Duration per slide] : Sets the display
speed for each picture in a slide show.
• [Slide Animation] : Selects animation
for the slide show.
• [Picture Settings] : Selects a
predenedcolorsetting.
• [Repeat] : Repeats a selected folder.
Note
•
IftheUSBstoragedevicedoesnottintothe
connector, use a USB extension cable.
• The home theater does not support digital
cameras that need a computer program to
display photos.
• The USB storage device must be NTFS, FAT
or DOS-formatted, and Mass Storage Class
compliant.
More play features for disc or
USB
Several advanced features are available for video
or picture playback from a disc or USB storage
device.
Use video OPTIONS
Access several useful features while viewing video.
Note
•
Available video OPTIONS depend on the
video source.
1 Press OPTIONS / (OPTIONS).
» The video OPTIONS menu appears.
2 Press the Navigation buttons and OK to
select and adjust:
• [Audio Language] : Selects audio
language for video.
• [Subtitle Language] : Selects subtitle
language for video.
• [Subtitle Shift] : Adjusts the subtitle
position on the screen.
• [Info] : Displays information about
what is playing.
• [Character Set] : Selects a character
set that supports the DivX subtitle.
• [Time Search]:Skipstoaspecicpart
of the video by entering the time of
the scene.
• [2nd Audio Language] : Selects the
second audio language to play.
• [2nd Subtitle Language] : Selects the
second subtitle language to play.
English
EN
16
Set up media server software
Before you start:
• Connect your home theater to your
home network (see ‘Connect to a
computer network and the Internet’
on page 10).
• Connect your PC to the same home
network.
• MakesurethatyourPCrewallallows
you to run Windows Media Player
programs.
In Microsoft Windows Media Player 11
1 Connect the home theater to a network
router (see ‘Connect to a computer
network and the Internet’ on page 10).
2 Switch on the computer and router.
3 Open Windows Media Player on the
computer.
4 Select Library > Media Sharing, then select
settings to share your media.
5 Select Library > Add to Library, then select
settings to share the folder containing your
media.
6 Select Advanced OPTIONS, then add the
folders to share.
7 Select Library > Apply Media Information
Changes to activate the changes.
In Macintosh OS X Twonky Media (v4.4.2)
1 Connect the home theater to a network
router (see ‘Connect to a computer
network and the Internet’ on page 10).
2 Switch on the Macintosh and router.
3 Visit www.twonkymedia.com to purchase
the software or download a free 30-day
trial to your Macintosh.
4 Open Twonky Media on the Macintosh.
» The media sharing setting is turned on by
default, thus enabling you to directly add
folders for media sharing.
5 Select Basic Setup > Sharing, then select
settings to add a folder location or add
more folders.
6 Select Save Changes to activate the
changes.
Use audio OPTIONS
Access several useful features while audio is
played.
1 Press OPTIONS / (OPTIONS)
repeatedly to cycle through the following
functions:
• REPEAT TRACK : Repeats the current
track.
• REPEAT DISC : Repeats all the tracks
on the disc or folder.
• REPEAT RANDOM : Plays audio
tracks in random order.
• REPEAT OFF : Turns off repeat mode.
Play a musical slideshow
Play music and pictures simultaneously to create
a musical slideshow.
1 Select a music track, then press OK.
2 Press BACK and go to the picture
folder.
3 Select a picture, then press OK to start
slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Play from PC (DLNA)
When you connect your home theater to your
home network, you can play music, photo, and
video from a computer or other media server on
that network.
What you need:
• A wired or wireless home network,
connected with a Universal Plug and
Play (uPnP) router.
• A Philips wireless USB adapter or
a LAN able to connect your home
theater to your home network.
• A media server such as:
• PC running Windows Media Player 11
or higher; or
• Mac running Twonky Media Server.
For help to use other media servers, such as
TVersity, see the web site of the media server.
EN
17
Clear browsing history
Clear browsing history to remove passwords,
cookies and browsing data from your home
theater.
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Network] > [Clear Net TV
Memory], then press OK .
Access online video stores
Rent videos from online stores, through your home
theater. You can watch them right away or later.
Many online video stores offer a huge choice of
video, with different rental prices, periods, and
conditions. For some stores, you must create an
account before you can rent.
What you need:
• A high-speed internet connection to
the home theater (see ‘Connect to a
computer network and the Internet’
on page 10).
• An HDMI connection between your
home theater and TV.
• An SD memory card of type SDHC
Class 6, with at least 4GB of memory.
Format an SD card
Before you can rent online videos, your SD card
must be in the SD card slot and formatted. After
formatting, leave the card in place so that you
are always ready to rent or watch.
When you have downloaded a video to your card,
you can watch it only on your home theater. You
can’t move the card and watch it on another device.
If you move the card and format it in another
device, your downloaded video is erased. You must
download your video again before you can watch.
To format an SD card
1 Switch your TV to the correct HDMI source
for your home theater.
Play multimedia content
Note
•
Before playing multimedia content from the
computer, ensure that the home theater is
connected to the computer network and the
media server software is properly set up.
1 Press (Home).
» The home menu appears.
2 Select [browse PC], then press OK.
» A content browser appears.
3 Selectale,thenpressOK.
4 Press the playback buttons to control play
(see ‘Play a disc’ on page 13).
Browse Net TV
With the home theater connected to the Internet,
you can use Net TV to access videos, pictures,
music, information, games and other online
services.
Note
•
Koninklijke Philips Electronics N.V. bears no
responsibility for content provided by Net TV
service providers.
Access Net TV
1 Prepare the internet connection and set up
the network (see ‘Connect to a computer
network and the Internet’ on page 10).
2 Press (Home).
» The home menu appears.
3 Select [browse Net TV], then press OK.
» The Net TV home page appears.
4 Press the Navigation buttons to navigate
Net TV web pages or services.
5 Press OK to view or select an item.
6 Press BACK to return to the previous
page, or press
(Home) to exit.
English
EN
18
Play from radio
The home theater can store up to 40 radio
stations.
1 Check that the FM antenna is connected.
2 Press RADIO.
» “AUTO INSTALL...PRESS PLAY’ appears
on the display panel if you have not
installed any radio stations. Press
(Play).
3 Press the following buttons to control play:
Button Action
/
Selects a preset radio
station.
Navigation
buttons
(left/right)
Searches for a radio station.
Navigation
buttons
(up/down)
Fine tunes a radio frequency.
Press and hold to erase the
preset radio station.
Press to stop the installation
of radio stations.
OPTIONS /
(OPTIONS)
Manual: Press once to access
program mode, and press
again to store the radio
station.
Automatic: Press and hold
forvesecondstoreinstall
radio stations.
RADIO Toggles between stereo and
mono sound.
Note
•
AM and digital radio are not supported.
• If no stereo signal is detected, you are
prompted to install the radio stations again.
• For the best reception, place the antenna away
from the TV or other sources of radiation.
2 Insert the SD memory card into the
SD CARD slot on your home theater.
3 Follow the on-screen instructions to format
the card.
» Any content on the card is erased during
formatting.
4 After formatting, leave the card in the
SD CARD slot.
Rent and play online video
1 Prepare the internet connection (see
‘Connect to a computer network and the
Internet’ on page 10).
2 Press (Home).
3 Select [browse Net TV] > Video stores
(Video stores), and then press OK.
4 Press the Navigation buttons to navigate to
a video store, and press OK.
5 If prompted, follow the video store
instructions to register or log in to an
account.
» You see an option to rent videos.
» If you have rented videos and are still
within the rental period, you also see an
option to watch the videos.
6 Follow the video store instructions to rent
or watch a video.
» The video is downloaded to your SD
memory card. You can watch it now or at
any time within the rental period.
7 Press the play buttons on your remote
control to play, pause, search, and stop the
video.
EN
19
Listen to music
1 Dock your iPod or iPhone (see ‘Dock your
iPod or iPhone’ on page 999).
2 Press DOCK for iPod on the home theater
remote control.
» The playlists are displayed on the TV.
3 Press the Navigation buttons and OK to
select and play tracks.
Watch video or view slideshows
Note
•
On iPod, enable the TV ON setting.
• On iPhone, select the TV Out option.
1 Dock your iPod or iPhone (see ‘Dock your
iPod or iPhone’ on page 999).
2 Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite
cable).
» The TV screen goes blank.
3 Browse on the iPod or iPhone screen to
select videos or photos.
4 Press (Play) to play the video and photos.
» The picture is displayed on the TV.
Use Philips EasyLink
The home theater supports Philips EasyLink,
which uses the HDMI CEC (Consumer
Electronics Control) protocol. EasyLink-
compliant devices that are connected through
HDMI connectors can be controlled by a single
remote control.
Note
•
Philips does not guarantee 100%
interoperability with all HDMI CEC devices.
1 Switch on the HDMI CEC operations on
the TV and other connected devices. See
the manual of the TV or other devices for
details.
2 Press (Home).
Play audio from TV or other
devices
Press SOURCE / AUDIO SOURCE repeatedly
to select the audio output of the connected
device.
Play from an MP3 player
ConnectandplayaudiolesfromanMP3player
or other external audio devices.
1 Connect the MP3 player to the home
theater as described in the Quick start
guide.
2 Press SOURCE / AUDIO SOURCE
repeatedly until ‘MP3 LINK’ appears on the
display panel.
3 Press the buttons on the MP3 player to
selectandplayaudioles.
Play from an iPod or iPhone
By connecting and installing a Philips Dock for
iPod/iPhone, you can use the home theater to
play music, movies and photos from your iPod or
iPhone.
Note
•
You can charge your iPod/iPhone on the dock
while the home theater is in iPod mode.
Dock your iPod or iPhone
1 Move the slide at the bottom of the dock
to ‘STANDARD’, then connect the dock to
the home theater.
2 Connect the yellow composite cable from
the dock to the TV.
3 Switch on the iPod or iPhone and place it in
the dock.
4 On the home theater remote control, press
(Home), then select [browse iPod] and
press OK.
English
EN
20
5 Change settings
This section helps you to change the settings of
your home theater.
Caution
•
Mostofthesettingsarealreadycongured
with the best value for the home theater.
Unlessyouhaveaspecicreasontochangea
setting, it is best to leave it at the default value.
Access the setup menu
1 Press (Home).
2 Select [Setup], then press OK.
» The setup menu appears.
3 Select a setup menu, then press OK.
See the following sections for information
about how to change the settings of your
home theater.
4 Press BACK to return to the previous
menu, or press
to exit.
Note
•
You cannot change a setting that is grayed out.
Change video settings
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Video], then press OK.
4 Select and adjust the following settings:
• [TV Display]: Selects a picture display
formattottheTVscreen.
• [HDMI Video]: Selects the HDMI
video resolution.
• [HDMI Deep Color]: Displays colors
with more shades and hues when
the video content is recorded in
Deep Color and the TV supports this
feature.
3 Select [Setup], then press OK.
4 Select [EasyLink] > [EasyLink], then press
OK.
5 Select [On], then press OK.
6 You can now enjoy the following Philips
EasyLink controls.
One-touch play
When you play a disc, the TV automatically
switches to the correct channel.
One-touch standby
When you press and hold
(Standby) on the
remote control, the home theater and all the
connected HDMI CEC devices (if they support
one-touch standby) switch to standby mode
simultaneously.
System Audio Control
When you play a device that has its audio
output routed to the home theater, the home
theater switches to the corresponding audio
source automatically.
To use one-touch audio, enable this feature and
follow the instructions on the TV to map the
connected devices correctly to the audio input
jacks of the home theater.
Audio Input Mapping
Updates audio input mapping if there are new
devices connected.
EN
21
5 Press OKtoconrmyourchoice.
Note
•
For settings related to HDMI, the TV must be
connected through HDMI.
• Night mode is available for Dolby encoded
DVD and Blu-ray discs (for models support
Blu-ray playback).
Set up surround sound
automatically
Whenyousetupthehometheaterfortherst
time, the setup menu prompts you to calibrate
your speakers for the best surround sound. If you
move your speakers or change the layout of the
room, calibrate the speakers again to continue
getting the best sound.
Before you start, make sure that the calibration
microphone is less than 5m from each of the
speakers. If it is more, set up your sound manually
(see ‘Set up surround sound manually’ on page 22).
1 Connect your speakers and subwoofer as
described in the Quick Start. For the best
surround sound, turn your rear speakers to
face your listening position.
2 Connect the calibration microphone to the
MP3 LINK connector on your home theater
and place it in your usual listening place, at
ear height.
• [Component Video]: Selects the
component video resolution. Copy-
protected DVDs can display only
480p/576p or 480i/576i.
• [Blu-ray 3D video]: Selects the
3-dimensional video output when you
play a 3D video on your home theater.
The home theater must be connected
to a 3D TV through HDMI.
• [Picture Settings]:Selectsapredened
color setting.
5 Press OKtoconrmyourchoice.
Note
•
The best setting is automatically selected for
the TV. If you change the setting, ensure that
the TV supports the new setting.
• For settings related to HDMI, the TV must be
connected through HDMI.
• For settings related to progressive or
component video, the TV must be connected
through Component Video.
Change audio settings
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Audio], then press OK.
4 Select and adjust the following settings:
• [Night Mode]: Selects quiet or full
dynamic sound. Night mode decreases
the volume of loud sounds and
increases the volume of soft sounds
such as speech.
• [HDMI Audio]: Selects HDMI audio
format or disables HDMI audio output
for the TV.
• [360Sound Setup]: Calibrates the
speakers to 360 degrees SOUND
SETTINGS when a calibration
microphone is connected to the home
theater.
• [Speaker Setup]: Sets the volume level
and distance of each speaker to obtain
the best possible surround sound
based on your room setup.
English
EN
22
• [View Network Settings] : Displays
the current network settings.
• [View Wireless Settings] : Displays the
current Wi-Fi settings.
• [Net TV User Location] : Selects the
location for accessing Net TV content
and services.
• [Clear Net TV Memory] : Clears Net
TV memory, delete the temporary
downloadedles(e.g.,cookies)ofthe
Net TV browser.
5 Press OKtoconrmyourchoice.
Set up EasyLink
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [EasyLink], then press OK.
4 Select and adjust the following settings:
• [EasyLink] : Enables or disables EasyLink.
• [One Touch Play] : Enables or disables
One Touch Play.
If enabled, you can use the remote
control to start disc play in the
home theater and the TV switches
automatically to the correct channel.
• [One Touch Standby] : Enables or
disables One Touch Standby.
If enabled, the home theater can
be switched off to standby by a
remote control from the TV or other
connected HDMI CEC devices.
• [System Audio Control] : Enables or
disables System audio control.
If enabled, follow the instructions on
the TV to map the connected devices
correctly to the audio connectors of
the home theater. The home theater
switches automatically to the audio
source of the connected device.
• [Audio Input Mapping] : Updates audio
input mapping if there are new devices
connected.
5 Press OKtoconrmyourchoice.
Note
•
The connected devices must be connected
through HDMI and switched on.
3 Make sure that there is nothing between
the speakers and the microphone to block
the sound, and make sure that the room
is quiet. For example, switch off your TV
or radio, close doors and windows, and
switch off the air conditioning. Don’t put the
microphone on top of speaker.
4 Press (Home) on your home theater
remote control, and select [Setup] >
[Audio] > [360Sound Setup].
5 Follow the onscreen instructions to set up
the sound.
» During the calibration, you hear a series
of test tones from the speakers and the
subwoofer. These sounds are normal -
don’t change the volume or move the
speakers, and be sure to keep quiet until
thecalibrationnishes.
6 After the auto calibration, disconnect the
calibration microphone.
Set up surround sound manually
Your home theater has a calibration microphone that
allows you to calibrate your speakers automatically. If
your speakers are more than 5m (16 feet) away from
the calibration microphone, you can still get the best
surround sound by setting them up manually.
1 Connect your speakers and subwoofer as
described in the Quick Start. For the best
surround sound, turn your rear speakers to
face your listening position.
2 Press (Home) on your home theater
remote control, and select [Setup] >
[Audio] > [Speaker Setup].
3 Enter the distance for each speaker, and
then listen to the test tones and adjust the
volume.
Set up network
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Network], then press OK.
4 Select and adjust the following settings:
• [Network Installation] : Starts wired
(Ethernet) or wireless setup. Follow
the instructions to set up the network
connection.
EN
23
• [Sleep Timer] : Sets a sleep timer to
switch the home theater to standby
afteraspecictime.
5 Press OKtoconrmyourchoice.
Note
•
If your preferred disc language is not available,
you can select [Other] from the list and enter
the 4-digit language code which can be found
at the back of this manual.
• If you select a language that is not available
on a disc, the home theater uses the default
language of the disc.
Change advanced settings
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Advanced], then press OK.
4 Select and adjust the following settings:
• [BD-Live Security] : Restricts or allows
access to BD-Live.
• [Enhanced Audio] : Enables or disables
the audio post processing at the
speaker output.
• [Software Update] : Selects to update
software from the network or from
USB storage device.
• [Clear memory] : Clears local memory,
deletetheBD-Livelesthatyoupreviously
downloaded. If using an USB storage
device, the local storage folder is ‘BUDA’.
• [DivX
®
VOD Code] : Displays the
DivX VOD registration code for the
home theater.
• [Version Info.] : Displays the software
version for the home theater.
• [Restore default settings] : Resets the
home theater to the default settings
programmed at the factory.
5 Press OKtoconrmyourchoice.
Note
•
You cannot restrict internet access on
commercial Blu-ray discs.
• Before you purchase DivX videos and play them
on the home theater, register the home theater
on www.divx.com using the DivX VOD code.
• You cannot reset parental control setting to its
default value.
Multiview
On Philips 21:9 Cinema TV (model
58PFL9955H/12), you can watch two video
sources side by side. The sources can be:
• video from your home theater,
• TV broadcasts, and
• Net TV.
For information about how to set up multi-view,
see your TV user manual.
Change preference settings
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Preference], then press OK.
4 Select and adjust the following settings:
• [Menu language] : Selects the
on-screen display menu language.
• [Audio] : Selects audio language for video.
• [Subtitle] : Selects subtitle language for
video.
• [Disc Menu] : Selects menu language
for video disc.
• [Parental Control] : Restricts access to
discs that are recorded with ratings.
To play all discs irrespective of the
rating, select level ‘8’.
• [Screen Saver] : Enables or disables
screen saver mode. If enabled,
the screen enters idle mode after
10 minutes of inactivity (for example,
in pause or stop mode).
• [Auto Subtitle Shift] : Enables or
disables shift subtitle. If enabled,
it adjusts the subtitle position
automaticallytottheTVscreen.
• [Change Password] : Sets or changes
a PIN code to play a restricted disc.
Enter ‘0000’ if you do not have a PIN
or if you have forgotten your PIN.
• [Display Panel] : Changes the
brightness of the display panel.
• [Auto Standby] : Enables or disables
auto standby. If enabled, the home
theater switches to standby after
30 minutes of inactivity (for example,
in pause or stop mode).
• [VCD PBC] : Displays or skips the
content menu for VCD and SVCD discs.
English
EN
24
Update software from a USB
1 Check for the latest software version on
www.philips.com/support.
• Search for your model and click on
‘software and drivers’.
2 Create a folder named ‘UPG’ in the root
directory of your USB storage device.
3 Download the software into the ‘\UPG’
folder of the USB storage device.
4 Unzip the software in the ‘\UPG’ folder.
5 Connect the USB storage device to the
home theater.
6 Press (Home) and select [Setup].
7 Select [Advanced] > [Software Update] >
[USB].
8 Follow the instructions on the TV to
conrmtheupdate.
» When complete, the home theater
automatically switches off and restarts.
• If not, disconnect the power cord for a
few seconds and then reconnect it.
Caution
•
Do not turn off the power or remove the USB
storage device when the software update is in
progress because you might damage the home
theater.
6 Update software
To check for new updates, compare the current
software version of your home theater with the
latest software version (if available) on the Philips
web site.
Check software version
1 Press (Home).
2 Select [Setup], then press OK.
3 Select [Advanced] > [Version Info.], then
press OK.
» The software version is displayed.
Update software from the
network
1 Prepare the internet connection (see
‘Connect to a computer network and the
Internet’ on page 10).
2 Press (Home) and select [Setup].
3 Select [Advanced] > [Software Update] >
[Network].
» If an upgrade media is detected, you are
prompted to start or cancel the update.
4 FollowtheinstructionontheTVtoconrm
the update.
» When complete, the home theater
automatically switches off and restarts.
• If not, disconnect the power cord for a
few seconds and then reconnect it.
Note
•
If the home theater is unable to connect to the
Philips server, press
(Home), select [Setup] >
[Network] > [Network Installation] to set up
the network.
EN
25
7 Product specifications
Note
•
Specicationanddesignaresubjecttochange
without notice.
Region code
The type plate on the back or bottom of the
home theater shows which regions it supports
Playback media
• AVCHD, BD-RE, BD-Video, DVD-Video,
DVD+R/+RW, DVD-R/-RW, DVD+R/-R
DL, CD-R/CD-RW, Audio CD, Video CD/
SVCD,Pictureles,MP3media,WMA
media, DivX (Ultra)/DivX Plus HD media,
USB storage device
File Format
• Audio: .mp3, .wma, .wav
• Video: .avi, .divx, .mp4, .mkv, .wmv
• Picture: .jpg, .gif, .png
Amplier
• Total output power: 800W RMS
• Frequency response: 40 Hz-20 kHz / ±3dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
Country
DVD BD
Europe,
United Kingdom
Korea
Latin America
Australia,
New Zealand
Russia, India
China
AA
AA
CC
CC
Asia Pacific, Taiwan,
Update electronic user manual
1 Check the current version of the electronic
user manual installed in your home theater
(see ‘Check software version’ on page 24).
2 Insert a USB storage device into your PC.
3 In your web browser, navigate to www.
philips.com/support,andndyourproduct.
4 Click on ‘Software and drivers’ in the left
panel, and then locate the ‘Electronic
Manual’. The electronic user manual is
compressed into a *.zip archive.
5 Ifthe*.zipleatthePhilipsSupportwebsite
isalaterversionthantheleinyourhome
theater,downloadtheleintheroot
directory of your USB storage device.
6 Unzipthedownloadedleintheroot
directory of the USB storage device.
» Alenamed‘HTSxxxxeDFU.zip’ is
extracted in the ‘\UPG’ folder of your
USB storage device, ‘xxxx’ being the
model number of your home theater.
7 Disconnect the USB storage device from
the PC, and connect it to the home theater.
8 Press (Home).
• Ensure that there is no disc inside
the disc compartment of your home
theater and it is closed.
9 Press [3], [3], [8] on the remote control.
» Software update starts. When complete,
the home theater automatically switches
off and restarts.
10 When complete, disconnect the USB
storage device from the home theater.
Caution
•
Do not turn off the power or remove the USB
storage device during the update.
• If power failure occurs during the update,
donotremovetheUSBashdrivefromthe
home theater. The home theater continues the
update as soon as the power is restored.
• If an error occurs during the update, retry
the procedure. If the error reoccurs, contact
Philips Consumer Care.
English
EN
26
Subwoofer
• Impedance: 4 ohm
• Speaker drivers: 165 mm (6.5”) woofer
• Frequency response: 40 Hz-150 Hz
• Dimensions (WxHxD): 196 x 397 x 342 (mm)
• Weight: 6.4 kg
• Cable length: 3 m
Speakers
• System: full range satellite
• Speaker impedance: 4 ohm (center),
6 ohm (Front/Rear)
• Speaker drivers:
• Center: 2 x 2.5” woofer + 1”
soft-dome tweeter
• Front/Rear: 2 x 2.5” full range + 2.5”
woofer + 1” soft-dome tweeter
• Frequency response: 150 Hz-20 kHz
• Dimensions (WxHxD):
• Center: 435 x 85 x 111 (mm)
• Front/Rear : 99 x 247 x 117 (mm)
• Weight:
• Center: 1.67 kg
• Front/Rear : 1.17 kg/each
• Cable length:
• Center: 2 m
• Front: 3 m
• Rear: 10 m
Laser Specication
• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
• Wave length: 405 +5nm/-5nm (BD),
655 +5nm/-10nm (DVD),
790 +10nm/-10nm (CD)
• Output power (Max. ratings):
20mW (BD), 6mW (DVD), 7mW (CD)
• Input sensitivity:
• AUX1, AUX2: 400 mV
• MP3 LINK: 150 mV
Video
• Signal system: PAL / NTSC
• Component video output: 480i/576i,
480p/576p, 720p, 1080i
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 112 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
Radio
• Tuning range:
• Europe/China:
FM 87.5-108 MHz (50 kHz)
• AsiaPacic/Russia/LatinAmerica/India:
FM 87.5-108 MHz (50/100kHz)
• Signal-to-noise ratio: FM 55 dB
• Frequency response:
FM 60 Hz-12.5 kHz / ±3dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: UMS (USB Mass
Storage Class)
• File system: NTFS, FAT16, FAT32
• Maximum memory support: < 160GB
Main Unit
• Power supply:
• Europe/China: 220-240V, ~50 Hz;
• LatinAmerica/AsiaPacic:
110-127V/220-240V, ~50-60Hz;
• Russia/India: 220-240V, ~50Hz
• Power consumption: 125 W
• Standbypowerconsumption:≤0.22W
• Dimensions (WxHxD): 437 x 75 x 342
(mm)
• Weight: 4.5 kg
EN
27
Sound
No sound.
• Ensure that the audio cables are connected
and select the correct input source (for
example,
SOURCE / AUDIO SOURCE)
for the device you want to play.
No sound on HDMI connection.
• You might not hear any sound if the
connected device is not HDCP (High-
bandwidth Digital Content Protection)
compliant or only DVI compatible. Use an
analog or digital audio connection.
• Ensure that the [HDMI Audio] is enabled.
No sound from TV program.
• Connect an audio cable from the audio
input on the home theater to the audio
output on the TV, then press
SOURCE /
AUDIO SOURCE repeatedly to select the
correct audio source.
Distorted sound or echo.
• Ensure that the TV volume is muted or set
to minimum if you are playing audio through
the home theater.
Audio and video are not synchronized.
• 1) Press
SOUND SETTINGS /
(Sound OPTIONS) . 2) Press the
Navigation buttons (left/right) repeatedly
until AUDIO SYNC is displayed, then
press OK. 3) Press the Navigation buttons
(up/down) to sync the audio with the video.
Cannot calibrate the speakers by using the
calibration microphone.
• Ensure that the speakers, subwoofer, and
calibration microphone are connected as
described in the Quick Start.
• Try a different position for the speakers,
and then calibrate the speakers again.
• Ensure that you follow all the steps for auto
calibration (see ‘Set up surround sound
automatically’ on page 21).
• If you cannot calibrate the speakers
automatically, or are unhappy with the
automatic settings, set up the speakers
manually (see ‘Set up surround sound
manually’ on page 22).
Play
Disc cannot be played.
• Clean the disc.
• Ensure that the home theater supports the
disc(see‘Productspecications’onpage25).
8 Troubleshooting
Warning
•
Risk of electric shock. Never remove the
casing of the product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, register your product and get
support at www.philips.com/welcome.
If you contact Philips, you will be asked for the model
and serial number of your product. The model
number and serial number are on the back or
bottom of your product. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Main unit
The buttons on this home theater do not work.
• Disconnect the home theater from the
power outlet for a few minutes, then
reconnect.
No picture.
• Ensure that the TV is switched to the
correct source for the home theater.
No picture on HDMI connection.
• Change the HDMI video setting or wait for
15 seconds for auto recover.
• Check if the HDMI cable is faulty. Replace
with a new HDMI cable.
No picture on the Component (Y Pb Pr)
connection.
• If the HDMI video connection is set to
[Auto] or [1080p/24Hz], there is no video
output through the component connection.
Change the HDMI video setting or remove
the HDMI connection.
No high-denition video signal on the TV.
• Ensurethatthedisccontainshigh-denition
video.
• EnsurethattheTVsupportshigh-denition
video.
English
EN
28
Cannot see pictures from my iPod/iPhone on the TV.
• Connect a yellow composite cable from the
dock to the TV.
• Switch the TV to the AV/VIDEO source
(corresponding to the yellow composite cable).
• Press PLAY on the iPod or iPhone to start
the slideshow.
The audio is interrupted when I play music from
my iPod or iPhone in the docking station.
• Ensure that you have installed the latest
rmwareonyouriPodoriPhone.Formore
information, refer to the support website of
your iPod or iPhone.
My 3D video plays in 2D mode.
• Ensure that your home theater is connected
to your 3D TV through HDMI.
• Ensure that your disc is a Blu-ray 3D disc.
• Ensure that the [Blu-ray 3D video] setting
is turned on (see ‘Change video settings’ on
page 20).
I see black video on my TV screen.
• Ensure that your home theater is connected
to the TV through HDMI.
• Switch to the correct HDMI source on your TV.
I cannot download the video from the online
video store.
• Ensure that your home theater is connected
to the TV through HDMI.
• Ensure that the SD card is in place and
formatted.
• Ensure that the SD memory card has
enough memory to download the video,
and is of type SDHC Class 6.
• Ensure that you have paid for the video and
are within the rental period.
• Check the network connection (see
‘Connect to a computer network and the
Internet’ on page 10).
• Contact the online video store for more
help.
Network
Wireless network not found or distorted.
• Ensure that the wireless network is not
disturbed by the microwave ovens, dect
phones or other Wi-Fi devices in your
neighbourhood.
• Try the wired network installation if the
wireless network does not work properly
(see ‘Set up network’ on page 999).
• Ensure that the home theater supports the
region code of the disc.
• For DVD±RW or DVD±R, ensure that the
discisnalized.
DivX video les cannot be played.
• EnsurethattheDivXleisencoded
accordingtothe‘HomeTheaterProle’
with the DivX encoder.
• EnsurethattheDivXvideoleiscomplete.
DivX subtitles do not display correctly.
• Ensurethatthesubtitlelenameisthe
sameasthemovielename.
• Select the correct character set: 1) Press
OPTIONS / (OPTIONS). 2) Select
[Character Set]. 3) Select the supported
character set. 4) Press OK.
The contents of a USB storage device cannot be
read.
• Ensure that the format of the USB storage
device is compatible with the home theater
(see‘Productspecications’onpage25).
• Ensure that the USB storage device
isformattedwithalesystemthatis
supported by the home theater.
‘No entry’ or ‘x’ sign appears on the TV.
• The operation is not possible.
EasyLink feature does not work.
• Ensure that the home theater is connected
to a Philips brand EasyLink TV and that
EasyLink is on.
I do not want my home theater to be switched
on when I switch on my TV.
• This is the correct behavior for Philips
EasyLink (HDMI-CEC). To make the home
theater work independently, switch off
EasyLink.
I cannot access BD-Live features.
• Check the network connection (see
‘Connect to a computer network and
the Internet’ on page 10) or ensure that
the network has been set up (see ‘Set up
network’ on page 10).
• Clear memory storage. (see ‘Change
advanced settings’ on page 23)
• Ensure that the Blu-ray disc supports BD-
Live feature.
The video (movies, photos, video clips, etc.)
contents of the iPod/iPhone do not display on TV.
• Video and photo browsing is not supported,
you can only browse the video and photo
contents on the iPod/iPhone itself.
EN
29
E
EasyLink
settings 19, 22
F
le formats 25
format SD card 17
H
HDMI CEC (see Easylink) 19
I
Internet
BD-Live 14
connect 10
online video stores 17
software update 24
iPod
play 19
slideshow 19
L
language
audio 15, 23
disc menu 23
on-screen display 23
subtitle 15, 23
M
manual speaker setup 22
media server software
set up 16
MP3
play 19
Multiview 23
N
Net TV 17
network
connect 10
set up 10
software update 24
9 Index
3
360 degree sound 21, 22
3D video 14
A
amplier 25
audio
connection 9
language 23
synchronize with video 13
audio input mapping 19, 22
auto calibration 21
automatic speaker setup 21
B
BD-Live
access 14
set up 10
Bonus View 13
Browse
Net TV 17
PC 17
C
calibration 21
care 2
change settings 20
chapter 15
connect
audio from TV 9, 19
guide 7
network 10
other devices 9
TV 8
wireless module 11
connectors 7
contact us 27
D
disc
play 13
supported discs 25
disposal of your product 3
DivX
character set 15
DLNA 16
Download video 17
English
EN
30
network 22
parental control 23
preferences 23
slideshow
animation 15
duration 15
play from iPod/iPhone 19
play musical slideshow 16
software
update 24
version 24
sound
auto volume 12
mode 12
surround 12
treble and bass 13
troubleshooting 27
speaker setup 21, 22, 21
subtitle
language 15, 23
subtitle shift 15, 23
Surround sound setup 21, 22
system audio control 19
T
time search video 15
title 15
troubleshooting 27
TV
audio from TV 9, 19
connect 8
U
USB
play 14
software update 24
V
video
online video stores 17
OPTIONS 15
rent and watch a video 17
synchronize with audio 13
W
wireless
wireless module 11
O
one-touch play 19, 22
one-touch standby 19, 22
online video stores 17
overview
connectors 7
main unit 4
remote control 4
P
password (PIN code) 23
OPTIONS 15
rotate 15
slide show 16, 15
troubleshooting 27
picture-in-picture
2nd audio language 13
2nd subtitle language 13
enable 13
play
2D video 14
3D video 14
disc 13
from PC 16
MP3 player 19
multimedia content 16
OPTIONS 13
radio 18
troubleshooting 27
USB storage device 14
product care 2
product specications 25
R
radio
play 18
program 18
tune 18
recycle 3
region code 25
remote control 4
rent video 17, 18
repeat 15, 13
rotate pictures 15
S
safety 2
SD card 17
settings
EasyLink 22
EN
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Português 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
Tonga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Turkmen 8475
Twi 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yoruba 8979
Zulu 9085
中文
Language Code
1_HTS5220_12_EN-US.indd Sec2:33 4/14/2010 10:24:07 AM
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
sgptt_1138/12_v4
book1 back page.indd 4book1 back page.indd 4 12/29/2010 3:28:13 PM12/29/2010 3:28:13 PM
