OWNER’S MANUAL

LED LCD MONITOR

E1942TC

E2042TC

E2242TC

E2442TC

Please read this manual carefully before operating

your set and retain it for future reference.

LED LCD MONITOR MODEL

ENGLISH

ENG

ENGLISH

TABLE OF CONTENTS

CONTENTS

3 ASSEMBLINGANDPREPAR-

ING

3 Unpacking

4 Partsandbuttons

5 SettinguptheMonitorset

5 - AttachingtheStandBase

5 - DetachingtheStandBase

6 - Mountingonatable

6 - Usingthecableholder

8 - Mountingonawall

9 USINGTHEMONITORSET

9 ConnectingtoaPC

9 - D-SUBconnection

9 - DVI-Dconnection

11 CUSTOMIZINGSETTINGS

12 CustomizingSettings

12 - MenuSettings

13 -PICTURE

14 -COLOR

15 -DISPLAY

16 -OTHERS

17 SUPERENERGYSAVINGSetting

18 PICTUREMODESetting

19 TROUBLESHOOTING

21 SPECIFICATIONS

21 E1942TC

22 E2042TC

23 E2242TC

24 E2442TC

25 PresetModes(Resolution)

26 Indicator

27 PROPERPOSTURE

27 ProperpostureforusingtheMonitorset.

ENG

ENGLISH

ASSEMBLING AND PREPARING

ASSEMBLINGANDPREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal

dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct

andaccessories.



Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.



Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.



Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.



Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade

ofproductfunctions.

CAUTION

NOTE

StandBody

StandBase

CD(Owner'sManual)/

Card

D-SUBCable

DVI-DCable

(Thiscableisnotincluded

inallcountries.)

(Dependingonthecountry) (Dependingonthecountry)

PowerCord AC-DCAdapter AC-DCAdapter

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

Partsandbuttons

PowerIndicator



LightingOn:Turnedon



LightingOff:Turnedoff

Connectionpanel(Seep.9)

Button(Seep.11)

(PowerButton)

ENG

ENGLISH

ASSEMBLING AND PREPARING

AttachtheStandBodytothemonitorset.

AttachtheStandBase.

Tightenthescrewtotherightwithacoin.

SettinguptheMonitorset

AttachingtheStandBase

 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.

Layafoammatorsoftprotectivecloth

onthesurfacetoprotectthescreenfrom

damage.

CAUTION



StandBase

StandBody



Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.



Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfall

andgetdamagedorinjureyourfoot.

CAUTION

DetachingtheStandBase

 PlacetheMonitorsetwiththescreenside

downonaflatandcushionedsurface.



StandBase

StandBody

PullouttheStandBodyandStandBase

fromthemonitorset.

Turnthescrewtotheleftwithacoin.

PullouttheStandBase.

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonatable

 LiftandtilttheMonitorsetintoitsupright

positiononatable.

Leavea10cm(minimum)spacefromthewall

forproperventilation.

Usingthecableholder

 ConnecttheAC-DCAdapterandPowerCord

toawalloutlet.

 Press (Power)buttononthebottomswitch

paneltoturnthepoweron.

10 cm

Unplugthepowercordbeforemovingthe

Monitortoanotherlocation.Otherwiseelectric

shockmayoccur.

CAUTION

Cableholder

or

ENG

ENGLISH

ASSEMBLING AND PREPARING

UsingtheKensingtonsecuritysystem

TheKensingtonsecuritysystemconnectoris

locatedatthebackoftheMonitorset.Formore

informationofinstallationandusing,refertothe

manualsuppliedwiththeKensingtonsecurity

systemorvisit

http://www.kensington.com

ConnecttheKensingtonsecuritysystemcable

betweentheMonitorsetandatable.

TheKensingtonsecuritysystemisoptional.

Youcanobtainitfrommostelectronicsstores.

NOTE

Whenyouadjusttheangle,donotholdthe

bottomoftheMonitorsetframeasshownon

thefollowingillustration,asmayinjureyour

fingers.

Donottouchorpressthescreenwhen

adjustingtheangleofthemonitor.

Donotholdthissetlikebelowpicture.Monitor

screencandetachfromstandbaseandinjure

yourbody.

WARNING

Tiltfrom+20to-5degreesupordowntoadjust

theangleoftheMonitorsettosuityourview.

NOTE

Front Rear

ENG

ENGLISH

ASSEMBLING AND PREPARING

Mountingonawall

Forproperventilation,allowaclearanceof10cm

oneachsideandfromthewall.Detailed

instructionsareavailablefromyourdealer,seethe

optionalTiltWallMountingBracketInstallationand

SetupGuide.

IfyouintendtomounttheMonitorsettoawall,

attachWallmountinginterface(optionalparts)to

thebackoftheset.

WhenyouinstalltheMonitorsetusingawall

mountinginterface(optionalparts),attachit

carefullysoitwillnotdrop.

Please,Usethescrewandwallmountinterface

inaccordancewithVESAStandards.

Ifyouusescrewlongerthanstandard,the

monitormightbedamagedinternally.

Ifyouuseimproperscrew,theproductmightbe

damagedanddropfrommountedposition.In

thiscase,LGElectronicsisnotresponsiblefor

it.

VESAcompatible.

PleaseuseVESAstandardasbelow.



784.8mm(30.9inch)andunder

*WallMountPadThickness:2.6mm

*Screw:Φ4.0mmxPitch0.7mmx

Length10mm



787.4mm(31.0inch)andabove

*PleaseuseVESAstandardwallmountpad

andscrews.

10 cm



Disconnectthepowercordfirst,andthen

moveorinstalltheMonitorset.Otherwise

electricshockmayoccur.



IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.



UseonlyanauthorizedLGwallmount

andcontactthelocaldealerorqualified

personnel.



Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoid

yourwarranty.



Useonlyscrewsandwallmountsthat

meettheVESAstandard.Anydamages

orinjuriesbymisuseorusinganimproper

accessoryarenotcoveredbythewarranty.



UsethescrewsthatarelistedontheVESA

standardscrewspecifications.



Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.



Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.



Thelengthofscrewsmaydifferdepending

onthewallmount.Besuretousetheproper

length.



Formoreinformation,refertothe

instructionssuppliedwiththewallmount.

CAUTION

NOTE

Model

E1942TC

E2042TC

E2242TC



E2442TC



VESA(AxB) 75x75 100x100

Standard

screw

Numberof

screws

ENG

ENGLISH

USING THE MONITOR SET

USINGTHEMONITORSET

ConnectingtoaPC



YourMonitorsetsupportsPlug&Play*.

*Plug&Play:APCrecognizesaconnected

devicethatusersconnecttoaPCandturn

on,withoutdeviceconfigurationoruser

intervention.

D-SUBconnection

TransmitsanalogvideofromyourPCtothe

Monitorset.ConnectthePCandtheMonitorset

withthesuppliedD-sub15pinsignalcableas

showninthefollowingillustrations.



Macadapter

ForAppleMacintoshuse,aseparateplug

adapterisneededtochangethe15pin

highdensity(3row)D-SUBVGAconnector

onthesuppliedcabletoa15pin2row

connector.



WhenusingaD-Subsignalinputcable

connectorforMacintosh

NOTE

DVI-Dconnection

TransmitsadigitalvideosignalfromyourPCto

theMonitorset.ConnectthePCandtheMonitor

setwithaDVIcableasshowninthefollowing

illustrations.

ENG

ENGLISH

USING THE MONITOR SET



WhenyouwanttousetwoPCinourMonitor,

pleaseconnectthesignalcable(D-SUB/

DVI-D)respectivelyinMonitorset.



IfyouturntheMonitorsetonwhileitiscold,

thescreenmayflicker.Thisisnormal.



Somered,green,orbluespotsmayappear

onthescreen.Thisisnormal.



"SelfImageSetting"Function.

Thisfunctionprovidestheuserwithoptimal

displaysettings.Whentheuserconnects

themonitorforthefirsttime,thisfunction

automaticallyadjuststhedisplaytooptimal

settingsforindividualinputsignals.(Only

supportedinAnalogMode)



‘AUTO’Function.

Whenyouencounterproblemssuchas

blurryscreen,blurredletters,screenflicker

ortiltedscreenwhileusingthedeviceor

afterchangingscreenresolution,pressthe

AUTOfunctionbuttontoimproveresolution.

(OnlysupportedinAnalogMode)

NOTE NOTE



Connectthesignal

inputcableandtighten

itbyturningthescrews

clockwise.



Donotpressthescreenwithyourfingerfor

alongtimeasthismayresultintemporary

distortiononthescreen.



Avoiddisplayingafixedimageonthe

screenforalongperiodoftimetoprevent

imageburn.Useascreensaverifpossible.

CAUTION

SelfImageSettingFunction

Pressthepowerbuttononthebottompanelto

turnthepoweron.Whenmonitorpoweristurned

on,the"SelfImageSetting"Functionisexecuted

automatically.(OnlysupportedinAnalogMode)

ENG

ENGLISH

CUSTOMIZING SETTINGS

CUSTOMIZINGSETTINGS

 PressthedesiredbuttononthebottomoftheMonitorset.

 ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.

Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.

 SelectEXITtoleavetheOSDmenu.

MonitorsetButtons

Button Description

Accessesthemainmenus.(Seep.12)

OSDLOCKED/

UNLOCKED

Thisfunctionallowsyoutolockthecurrentcontrolsettings,so

thattheycannotbeinadvertentlychanged.

PressandholdtheMENUbuttonforseveralseconds.

Themessage"OSDLOCKED"shouldappear.

YoucanunlocktheOSDcontrolsatanytimebypushing

theMENUbuttonforseveralseconds.Themessage"OSD

UNLOCKED"shouldappear.

(SUPERENERGYSAVING)

UsethisbuttontoenterSUPERENERGYSAVINGmenu.Formoreinformation.(Seep.17)

UsethisbuttontoenterCUSTOM,TEXT,PHOTO,CINEMA,GAMEmenus.(Seep.18)

Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR

SETUPOSD.(OnlysupportedinAnalogMode)

Thebestdisplaymode E1942TC:1366x768

E2042TC:1600x900

E2242TC/E2442TC:1920x1080

Youcanchoosetheinputsignal.

• Whentwoinputsignalsareconnected,youcanselecttheinputsignal(D-SUB/DVI)

youwant.

• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis

D-SUB.

EXIT

ExittheOSD(OnScreenDisplay).

(PowerButton)

Turnsthepoweronoroff.

PowerIndicator Thepowerindicatorstaysredifthedisplayisrunningproperly

(OnMode).IfthedisplayisinSleepMode,thepowerindicator

blinksred.

ENG

ENGLISH

CUSTOMIZING SETTINGS

CustomizingSettings

MenuSettings

 PressMENUbuttononthebottomoftheMonitorset

todisplaytheMENUOSD.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 Selectthe"NEXTMENU"buttontoenterthemore

optionsettings.

 SelectEXITtoleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

MENU>NEXTMENU Analog Digital Description


SHARPNESS ● ● Toadjusttheclearnessofthescreen.

COLOR GAMMA

● ● Tocustomizethecolorofthescreen

COLORTEMP

DISPLAY HORIZONTAL

● Toadjustthepositionofthescreen

VERTICAL

CLOCK

● Toimprovetheclarityandstabilityofthescreen

PHASE

OTHERS LANGUAGE

● ●

Tocustomizethescreenstatusforauser'soperating

environment

POWERINDICATOR

WHITEBALANCE ●



Analog:D-SUB(Analogsignal)input.



Digital:DVI-D(Digitalsignal)input.

MENU Analog Digital Description

BRIGHTNESS

● ●

Toadjustthebrightness,contrastofthescreen

CONTRAST ● ●

WIDE/ORIGINAL

● ●

WIDE

Switchtofullscreenmodeaccordingtoinputimagesignal.

ORIGINAL

Changetheinputimagesignalratiotooriginal.

*ThisfunctionworksonlyifinputresolutionislowerthanMonitorsetratio(16:9).

RESET

● ●

Restoreallfactorydefaultsettings.Pressthe

◄

,

►

buttonstoresetimmediately.

ENG

ENGLISH

CUSTOMIZING SETTINGS


 PressMENUbuttononthebottomoftheMonitorset

todisplaytheMENUOSD.

 Selectthe"NEXTMENU"buttontoenterthemore

optionsettings.

 EntertoPICTUREbypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 SelectEXITtoleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

MENU>NEXTMENU>PICTURE Description

SHARPNESS Toadjusttheclearnessofthescreen.

ENG

ENGLISH

CUSTOMIZING SETTINGS

COLOR

 PressMENUbuttononthebottomoftheMonitorset

todisplaytheMENUOSD.

 Selectthe"NEXTMENU"buttontoenterthemore

optionsettings.

 SelectCOLORbypressingthe►button.

 EntertoCOLORbypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 SelectEXITtoleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

MENU>NEXTMENU>COLOR Description

GAMMA Setyourowngammavalue.:GAMMA0,GAMMA1,GAMMA2onthemonitor,

highgammavaluesdisplaywhitishimagesandlowgammavaluesdisplay

blackishimages.

COLORTEMP CUSTOM

•RED:Setyourownredcolorlevels.

•GREEN:Setyourowngreencolorlevels.

•BLUE:Setyourownbluecolorlevels.

Selectthescreencolor.

WARM:Setthescreentowarmcolortemperature(morered).

MEDIUM:Setthescreentomediumcolortemperature.

COOL:Setthescreentocoolcolortemperature(moreblue).

ENG

ENGLISH

CUSTOMIZING SETTINGS

DISPLAY

 PressMENUbuttononthebottomoftheMonitorset

todisplaytheMENUOSD.

 Selectthe"NEXTMENU"buttontoenterthemore

optionsettings.

 SelectDISPLAYbypressingthe►button.

 EntertoDISPLAYbypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 SelectEXITtoleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

MENU>NEXTMENU>DISPLAY Description

HORIZONTAL Tomoveimageleftandright.

VERTICAL Tomoveimageupanddown.

CLOCK Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.The

horizontalscreensizewillalsochange.

PHASE Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveanyhorizontal

noiseandclearorsharpentheimageofcharacters.

ENG

ENGLISH

CUSTOMIZING SETTINGS

OTHERS

 PressMENUbuttononthebottomoftheMonitorset

todisplaytheMENUOSD.

 Selectthe"NEXTMENU"buttontoenterthemore

optionsettings.

 SelectOTHERSbypressingthe►button.

 EntertoOTHERSbypressingthe▼button.

 Settheoptionsbypressingthe◄or►or▼

buttons.

 SelectEXITtoleavetheOSDmenu.

Toreturntotheuppermenuorsetothermenuitems,

usetheuparrow( )button.

Eachoptionisexplainedbelow.

MENU>NEXTMENU>OTHERS Description

LANGUAGE Tochoosethelanguageinwhichthecontrolnamesaredisplayed.

POWER

INDICATOR

Usethisfunctiontosetthepowerindicatoronthebottomsideofthemonitorto

ONorOFF.IfyousetOFF,itwillgooff.

IfyousetONatanytime,thepowerindicatorwillautomaticallybeturnedon.

WHITE

BALANCE

Iftheoutputofthevideocardisdifferenttherequiredspecifications,thecolor

levelmaydeteriorateduetovideosignaldistortion.Usingthisfunction,the

signallevelisadjustedtofitintothestandardoutputlevelofthevideocardin

ordertoprovidetheoptimalimage.Activatethisfunctionwhenwhiteandblack

colorsarepresentinthescreen.

ENG

ENGLISH

CUSTOMIZING SETTINGS

SUPERENERGYSAVINGSetting

 Press (SUPERENERGYSAVING)buttonon

thebottomoftheMonitorsettodisplaytheSUPER

ENERGYSAVINGOSD.

 Settheoptionsbypressingthe◄or►or▼buttons.

 SelectEXITtoleavetheOSDmenu.

Eachoptionisexplainedbelow.

SUPERENERGYSAVING Description

EnablesSUPERENERGYSAVINGyoucansaveenergywiththisenergy-efficientfunction

OFF DisablesSUPERENERGYSAVING.

RESET ResetsthevaluesoftotalenergyconsumptionreductionandCO2emissionreduction

estimates.





TOTALPOWERREDUCTION:Howmuchpowerissavedwhileusingthemonitor.



TOTALCO2REDUCTION:ChangetheTOTALPOWERREDUCTIONtoCO2.



SAVINGDATA(W/h)

470mm

(18.5inch)

508mm

(20inch)

546mm

(21.5inch)

600mm

(23.6inch)

SUPERSAVING 4W/h 5W/h 6W/h 7W/h



SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanel

vendor.



LGcalculatedthesevaluesbyusing“broadcastvideosignal”

(includingbroadcastvideo:IEC62087)



SUPERSAVINGreferstohowmuchpowercanbesavedusingtheSUPERENERGYSAVING

function.

NOTE

ENG

ENGLISH

CUSTOMIZING SETTINGS

Eachoptionisexplainedbelow.

PICTUREMODESetting

 PressMODEbuttononthebottomoftheMonitorsettodisplaythePICTUREMODEOSD.

 Settheoptionsbypressingthe◄or►or▼buttons.

 SelectEXITtoleavetheOSDmenu.

PICTUREMODE Description

CUSTOM Itisamodethattheusercanadjusteachelement.ItcanadjustthecolormodeoftheMainMenu.

TEXT Itisamodethatthescreenisadjustedtothebestforthetextworks.

PHOTO Itisamodethatthescreenisadjustedtothebesttoviewpictures.

CINEMA Itisamodethatthescreenisadjustedtothebesttoviewthevideos.

GAME Itisamodethatthescreenisadjustedtothebesttoplayagame.

ENG

ENGLISH

TROUBLESHOOTING

Checkthefollowingbeforecallingforservice.

Noimageappears

Isthepowercordofthedisplay

connected?





Checkandseeifthepowercordisconnectedproperlytothepower

outlet.

Isthepowerindicatorlighton?





PressthePowerbutton.

Isthepoweronandthepower

indicatorRed?





Adjustthebrightnessandthecontrast.

Isthepowerindicatorflickering?





Ifthedisplayisinpowersavingmode,trymovingthemouseor

pressinganykeyonthekeyboardtobringupthescreen.





TrytoturnonthePC.

Doyouseean"OUTOFRANGE"

messageonthescreen?





ThismessageappearswhenthesignalfromthePC(videocard)is

outofhorizontalorverticalfrequencyrangeofthedisplay.Seethe

'Specifications'sectionofthismanualandconfigureyourdisplay

again.

Doyouseea"NOSIGNAL"

messageonthescreen?





Whenthemonitorison"No-Signal"in5minutes,themonitorgoesto

DPMmode.

Doyouseea"OSDLOCKED"messageonthescreen?

Doyousee“OSDLOCKED”when

youpushMENUbutton?





Youcansecurethecurrentcontrolsettings,sothattheycannotbe

inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime

bypushingtheMENUbuttonforseveralseconds:themessage“OSD

UNLOCKED”willappear.

Displayimageisincorrect

DisplayPositionisincorrect.





PresstheAUTObuttontoautomaticallyadjustyourdisplayimageto

theidealsetting.

Onthescreenbackground,vertical

barsorstripesarevisible.





PresstheAUTObuttontoautomaticallyadjustyourdisplayimageto

theidealsetting.

Anyhorizontalnoiseappearingin

anyimageorcharactersarenot

clearlyportrayed.





PresstheAUTObuttontoautomaticallyadjustyourdisplayimageto

theidealsetting.





CheckControlPanel►Display►Settingsandadjustthedisplay

totherecommendedresolutionoradjustthedisplayimagetotheideal

setting.Setthecolorsettinghigherthan24bits(truecolor).

ENG

ENGLISH

TROUBLESHOOTING

Displayimageisincorrect

Thescreencolorismonoor

abnormal.





Checkifthesignalcableisproperlyconnectedanduseascrewdriver

tofastenifnecessary.





Makesurethevideocardisproperlyinsertedintheslot.





Setthecolorsettinghigherthan24bits(truecolor)atControlPanel

►Settings.

Thescreenblinks.





Checkifthescreenissettointerlacemodeandifyes,changeittothe

recommendresolution.

Doyouseean"Unrecognizedmonitor,Plug&Play(VESADDC)monitorfound"message?

Haveyouinstalledthedisplay

driver?





BesuretoinstallthedisplaydriverfromthedisplaydriverCD(or

diskette)thatcomeswithyourdisplay.Or,youcanalsodownloadthe

driverfromourwebsite:http://www.lg.com.





MakesuretocheckifthevideocardsupportsPlug&Playfunction.





CheckControlPanel►Display►Settingsandseeifthefrequencyortheresolutionwere

changed.Ifyes,readjustthevideocardtotherecommendresolution.



Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthe

screenmaybedimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.



ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentioned

abovemaynotbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputer

orthevideocardmanufacturer.

CAUTION



ENG

ENGLISH

SPECIFICATIONS



Display ScreenType 47.0cm(18.5inch)FlatPanelActivematrix-TFTLCDAnti-

Glarecoating

Visiblediagonalsize:47.0cm

PixelPitch 0.3mmx0.3mm(PixelPitch)

SyncInput HorizontalFrequency 30kHzto61kHz(Automatic)

VerticalFrequency 56Hzto75Hz(D-SUB,DVI-D)

InputForm SeparateSync.Digital

VideoInput SignalInput 15pinD-SUBConnector/DVI-DConnector(Digital)

InputForm RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max D-SUB(Analog):1366x768@60Hz

DVI(Digital):1366x768@60Hz

Recommend VESA1366x768@60Hz

Plug&Play DDC2B(Analog,Digital)

Power

Consumption

OnMode:15W(Typ.)

SleepMode≤0.3W

OffMode≤0.3W

PowerInput 19V

1.2A

AC-DCAdapter

TypeADS-40SG-19-319025G,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPG-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPBR-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPI-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeADS-40FSG-1919025GPCU-1,manufacturedbySHENZHENHONORELECTRONIC

orTypeLCAP21,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-A,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-E,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-I,manufacturedbyLIENCHANGELECTRONICENTERPRISE

orTypeLCAP26-B,manufacturedbyLIENCHANGELECTRONICENTERPRISE

OUTPUT:19V 1.3A

Dimensions

(WidthxHeightx

Depth)

WithStand 44.1cmx34.9cmx16.8cm

WithoutStand 44.1cmx27.5cmx5.5cm

Weight 2.1kg

TiltRange -5°to20°

Environmental

conditions

OperatingTemperature

OperatingHumidity

10°Cto35°C

10%to80%

StorageTemperature

StorageHumidity

-20°Cto60°C

5%to90%non-Condensing

StandBase Attached(),Detached(O)

Powercord Wall-outlettype

Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct

functions.

E1942TC

SPECIFICATIONS

ENG

ENGLISH

SPECIFICATIONS

SPECIFICATIONS

Display ScreenType 50.8cm(20inch)FlatPanelActivematrix-TFTLCDAnti-

Glarecoating

Visiblediagonalsize:50.8cm

PixelPitch 0.276mmx0.276mm(PixelPitch)

SyncInput HorizontalFrequency 30kHzto83kHz(Automatic)

VerticalFrequency 56Hzto75Hz(D-SUB,DVI-D)

InputForm SeparateSync.Digital

VideoInput SignalInput 15pinD-SUBConnector/DVI-DConnector(Digital)

InputForm RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max D-SUB(Analog):1600x900@60Hz

DVI(Digital):1600x900@60Hz

Recommend VESA1600x900@60Hz

Plug&Play DDC2B(Analog,Digital)

Power

Consumption

OnMode:20W(Typ.)
