Installation instructions
Induction hob
GK11TIFKZ | GK11TIFKZS | CTI6T96FKTFHD
1032691-R08
28/02/2020
1032691-R08
1
The appliance should be installed by qualified personnel only. Each step must be carried out and checked in full in
the order specified.
Validity
These installation instructions apply to the following models:
Model designation Model number Type Frameless,
for surface-mounted installa-
tion
Frameless,
for flush installation
GK11TIFK FullFlex 31062 GK11TIFKZ GK11TIFKZ GK11TIFKZ
GK11TIFK FullFlex 31062 GK11TIFKZS GK11TIFKZS GK11TIFKZS
CookTopInduktion V6000 FullFlex 31134 CTI6T-31134 CTI6T96FKTFHD CTI6T96FKTFHD
General notes
If installing into a combustible material, the guidelines and standards for low-voltage installations and fire protection
must be strictly observed.
Identification plate
1
1 Identification plate with serial number (SN)
▸ Affix the second identification plate (supplied) in an accessible position behind the front of the fitted cabinet beneath the appliance.
Installation accessories supplied
Flush installation:
Designation Art. no.
Cementing-in instructions J004133
Sealing strip set H63283
Spacer set H60330
Accessories
Flush installation:
Designation Art. no.
Ventilation protective plate set for niche width 900mm H61089
Steel angle set, installation dimension 90 H63775
Intermediate support kit for the flush-mounted combination of several hobs (contains two intermediate supports) H63789
Instant adhesive for installation of the steel angle (50ml) B11657
Straight mixing nozzle B11656
TREMCLEAN isopropyl alcohol (1000ml) 1056609
Black silicone FA880 (310ml) B11555
Anthracite silicone FA880 (310ml) B11556
White silicone FA880 (310ml) 1031313
Stone grey silicone FA880 (310ml) 1031314
Marble smoothing agent AA320 (1000ml) B11557
Fugenboy (silicone finishing tool) B75158
