4-591-691-11(1)
DSC-RX10M3
Digital Still Camera
Instruction Manual
“Help Guide” (Web manual)
Refer to “Help Guide” for in-depth
instructions on the many functions of
the camera.
http://rd1.sony.net/help/dsc/1610/h_zz/
GB
2
This camera is equipped with a built-in instruction guide.
In-Camera Guide
You can use [Custom Key(Shoot.)] to assign In-Camera Guide to the desired
button.
The In-Camera Guide displays explanations for the currently selected menu
function or setting.
1 MENU button t (Custom Settings) t [Custom Key(Shoot.)] t
Select the desired button assigned to the function. t [In-Camera Guide]
2 Press the MENU button and use the control wheel to select a MENU item
whose explanation you want to read, and then press the button to which
[In-Camera Guide] is assigned.
English
Learning more about the camera (“Help Guide”)
“Help Guide” is an on-line manual. You can read the “Help
Guide” on your computer or smartphone.
Refer to it for in-depth instructions on the many functions of
the camera.
URL:
http://rd1.sony.net/help/dsc/1610/h_zz/
Viewing the Guide
GB
3
Owner’s Record
Record the model and serial number
(which are located on the product) in the
space provided below. Refer to these
numbers whenever you call your Sony
dealer regarding this product.
Model No. DSC-
Serial No. _____________________
To reduce fire or shock hazard,
do not expose the unit to rain
or moisture.
IMPORTANT SAFETY
INSTRUCTIONS
-SAVE THESE
INSTRUCTIONS
DANGER
TO REDUCE THE
RISK OF FIRE OR
ELECTRIC SHOCK,
CAREFULLY
FOLLOW THESE
INSTRUCTIONS
If the shape of the plug does not fit the
power outlet, use an attachment plug
adaptor of the proper configuration for the
power outlet.
[ Battery pack
If the battery pack is mishandled, the
battery pack can burst, cause a fire or even
chemical burns. Observe the following
cautions.
• Do not disassemble.
• Do not crush and do not expose the
battery pack to any shock or force such as
hammering, dropping or stepping on it.
• Do not short circuit and do not allow
metal objects to come into contact with
the battery terminals.
• Do not expose to high temperature
above 60°C (140°F) such as in direct
sunlight or in a car parked in the sun.
• Do not incinerate or dispose of in fire.
• Do not handle damaged or leaking
lithium ion batteries.
• Be sure to charge the battery pack using
a genuine Sony battery charger or a
device that can charge the battery pack.
• Keep the battery pack out of the reach of
small children.
• Keep the battery pack dry.
• Replace only with the same or
equivalent type recommended by Sony.
• Dispose of used battery packs promptly
as described in the instructions.
Use a nearby wall outlet (wall socket)
when using the supplied or recommended
AC Adaptor/battery charger. If any
malfunction occurs while using this
product, disconnect the plug from the wall
outlet (wall socket) immediately to
disconnect from the power source.
If you use the product with a charge lamp,
note that the product is not disconnected
from the power source even when the
lamp turns off.
WARNING
CAUTION
GB
4
[ Notice
If static electricity or electromagnetism
causes data transfer to discontinue
midway (fail), restart the application or
disconnect and connect the
communication cable (USB, etc.) again.
This product has been tested and found
compliant with the limits set out in the
EMC regulation for using connection
cables shorter than 3 meters (9.8 feet).
The electromagnetic fields at the specific
frequencies may influence the picture and
sound of this unit.
[ RECYCLING LITHIUM-ION
BATTERIES
Lithium-Ion batteries
are recyclable.
You can help preserve
our environment by
returning your used
rechargeable batteries to
the collection and recycling location
nearest you.
For more information regarding recycling
of rechargeable batteries, call toll free
1-800-822-8837, or visit http://
www.call2recycle.org/
Caution: Do not handle damaged or
leaking Lithium-Ion batteries.
[ For supplied accessories
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
CAN ICES-3 B/NMB-3 B
This equipment complies with FCC/IC
radiation exposure limits set forth for an
uncontrolled environment and meets the
FCC radio frequency (RF) Exposure
Guidelines and RSS-102 of the IC radio
frequency (RF) Exposure rules. This
equipment has very low levels of RF
energy that are deemed to comply without
testing of specific absorption ratio (SAR).
If you have any questions about this
product, you may call:
Sony Customer Information Center
1-800-222-SONY (7669).
The number below is for the FCC related
matters only.
[ Regulatory Information
This equipment must not be co-located or
operated in conjunction with any other
antenna or transmitter.
For Customers in the
U.S.A. and Canada
For Customers in the
U.S.A.
Declaration of Conformity
Trade Name: SONY
Model No.: WW411000
Responsible Party: Sony Electronics
Inc.
Address: 16535 Via Esprillo,
San Diego, CA 92127
U.S.A.
Telephone No.: 858-942-2230
This device complies with Part15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
GB
5
[ CAUTION
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
[ Note:
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
The supplied interface cable must be used
with the equipment in order to comply
with the limits for a digital device
pursuant to Subpart B of Part 15 of FCC
Rules.
This device complies with Industry
Canada’s licence-exempt RSSs. Operation
is subject to the following two conditions:
(1) This device may not cause
interference; and
(2) This device must accept any
interference, including interference that
may cause undesired operation of the
device.
[ Notice for the customers in
the countries applying EU
Directives
Manufacturer: Sony Corporation, 1-7-1
Konan Minato-ku Tokyo, 108-0075 Japan
For EU product compliance: Sony
Belgium, bijkantoor van Sony Europe
Limited, Da Vincilaan 7-D1, 1935
Zaventem, Belgium
Hereby, Sony Corporation, declares that
this equipment is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC. For
details, please access the following URL:
http://www.compliance.sony.de/
For Customers in Canada
For Customers in Europe
GB
6
[ Disposal of waste batteries
and electrical and electronic
equipment (applicable in the
European Union and other
European countries with
separate collection systems)
This symbol on the
product, the battery or
on the packaging
indicates that the
product and the battery
shall not be treated as
household waste. On
certain batteries this symbol might be used
in combination with a chemical symbol.
The chemical symbols for mercury (Hg)
or lead (Pb) are added if the battery
contains more than 0.0005% mercury or
0.004% lead. By ensuring these products
and batteries are disposed of correctly, you
will help prevent potentially negative
consequences for the environment and
human health which could otherwise be
caused by inappropriate waste handling.
The recycling of the materials will help to
conserve natural resources.
In case of products that for safety,
performance or data integrity reasons
require a permanent connection with an
incorporated battery, this battery should be
replaced by qualified service staff only. To
ensure that the battery and the electrical
and electronic equipment will be treated
properly, hand over these products at end-
of-life to the applicable collection point
for the recycling of electrical and
electronic equipment. For all other
batteries, please view the section on how
to remove the battery from the product
safely. Hand the battery over to the
applicable collection point for the
recycling of waste batteries.
For more detailed information about
recycling of this product or battery, please
contact your local Civic Office, your
household waste disposal service or the
shop where you purchased the product or
battery.
[ Battery Pack
Self Declaration –Conforming to
IS16046:2012, R-41022659
For Customers in
Singapore
For Customers in U.A.E.
For Customers in
Malaysia
For Customers in India
GB
7
The number in parentheses indicates the number of pieces.
• Camera (1)
• Rechargeable Battery Pack NP-FW50 (1)
• Micro USB Cable (1)
• AC Adaptor (1)
• Power Cord (mains lead) (supplied in some countries/regions) (1)
• Shoulder Strap (1)
• Lens Cap (1)
• Lens Hood (1)
• Shoe Cap (1) (Attached on the camera)
• Eyepiece Cup (1) (Attached on the camera)
• Instruction Manual (this manual) (1)
• Wi-Fi Connection/One-touch (NFC) Guide (1)
This guide explains the functions that require a Wi-Fi connection.
About language setting
Change the screen language before using the camera if necessary (page 18).
Checking the supplied items
For further details on Wi-Fi functions/One-touch (NFC) functions, refer to
the “Wi-Fi Connection/One-touch (NFC) Guide” (supplied) or the “Help
Guide” (page 2).
GB
8
A ON/OFF (Power) switch
B Shutter button
C For shooting: W/T (zoom) lever
For viewing: (Index) lever/
Playback zoom lever
D Self-timer lamp/AF illuminator
E Aperture index
F Lens
G Front lens ring
H Rear lens ring
I Exposure compensation dial
J Flash
K Multi interface shoe*
L Mode dial
(Auto Mode)/
(Program Auto)/
(Aperture Priority)/
(Shutter Priority)/
(Manual Exposure)/
(Memory recall)/
(Movie)/ (High Frame
Rate)/ (Sweep Panorama)/
(Scene Selection)
M Hook for Shoulder Strap
N Focus hold button
O Focus mode dial
P Aperture ring
A Microphone
B Viewfinder
C Eye sensor
D Diopter-adjustment dial
E MOVIE (Movie) button
F (Flash pop-up) button
G (Display panel illumination)
button
H Display panel
I C2 button (Custom Button 2)
J C1 button (Custom Button 1)
K Hook for Shoulder Strap
L Memory card slot
M Memory card cover
N Access lamp
Identifying parts
GB
9
A MENU button
B Speaker
C m (Microphone) jack
• When an external microphone is
connected, the camera switches
from the internal microphone to
the external microphone. If the
external microphone is a plug-in-
power type, the power of the
microphone is supplied by the
camera.
D i (Headphones) jack
E Multi/Micro USB Terminal*
• Supports Micro USB compatible
device.
F HDMI micro jack
G Charge lamp
H Monitor
I For shooting: Fn (Function)
button
For viewing: (Send to
Smartphone) button
J Control dial
K For shooting: AEL (AE lock)
button
For viewing: (Playback
zoom) button
L Control wheel
M Center button
N For shooting: C3 button
(Custom Button 3)
For viewing: (Delete) button
O (Playback) button
A Aperture Click Switch
• Set the Aperture Click Switch to
OFF when shooting movies. If
you change the aperture value
while shooting a movie with the
Aperture Click Switch set to ON,
the sound of the aperture ring will
be recorded.
B Wi-Fi antenna (built-in)
C (N Mark)
• Touch the mark when you
connect the camera to a
smartphone equipped with the
NFC function.
• NFC (Near Field
Communication) is an
international standard of the
short-range wireless
communication technology.
D Battery lock lever
E Battery insertion slot
GB
10
F Connection plate cover
Use this when using an AC-PW20
AC Adaptor (sold separately).
Insert the connection plate into the
battery compartment, and then pass
the cord through the connection
plate cover as shown below.
• Make sure that the cord is not
pinched when you close the
cover.
G Battery cover
H Tripod socket hole
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
* For details on compatible accessories
for the multi interface shoe and the
Multi/Micro USB Terminal, visit the
Sony website, or consult your Sony
dealer or local authorized Sony
service facility.
You can also use accessories that are
compatible with the accessory shoe.
Operations with other manufactures’
accessories are not guaranteed.
GB
11
Inserting the battery pack
1
Open the cover.
2
Insert the battery pack.
• While pressing the battery lock lever, insert the battery pack as
illustrated. Make sure that the battery lock lever locks after insertion.
• Closing the cover with the battery inserted incorrectly may damage the
camera.
Battery lock lever
GB
12
Charging the battery pack
1
Connect the camera to the AC Adaptor (supplied),
using the micro USB cable (supplied).
2
Connect the AC Adaptor to the wall outlet (wall socket).
The charge lamp lights orange, and charging starts.
• Turn off the camera while charging the battery.
• You can charge the battery pack even when it is partially charged.
• When the charge lamp flashes and charging is not finished, remove and
re-insert the battery pack.
• For some countries/regions, connect the power cord (mains lead) to the
AC Adaptor, and connect the AC Adaptor to the wall outlet (wall
socket).
Charge lamp
Lit: Charging
Off: Charging finished
Flashing:
Charging error or charging paused temporarily
because the camera is not within the proper
temperature range
GB
13
• If the charge lamp on the camera flashes when the AC Adaptor is connected to the
wall outlet (wall socket), this indicates that charging is temporarily stopped
because the temperature is outside the recommended range. When the temperature
gets back within the appropriate range, the charging resumes. We recommend
charging the battery pack in an ambient temperature of between 10°C to 30°C
(50ºF to 86ºF).
• The battery pack may not be effectively charged if the terminal section of the
battery is dirty. In this case, wipe any dust off lightly using a soft cloth or a cotton
swab to clean the terminal section of the battery.
• Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If
malfunctions occur while using the AC Adaptor, disconnect the plug from the wall
outlet (wall socket) immediately to disconnect from the power source.
• When charging is finished, disconnect the AC Adaptor from the wall outlet (wall
socket).
• Be sure to use only genuine Sony brand battery packs, micro USB cable (supplied)
and AC Adaptor (supplied).
• Power is supplied during shooting/playback if the camera is connected to a wall
outlet (wall socket) with the AC-PW20 (sold separately) AC adaptor.
x
Charging time (Full charge)
The charging time is approximately 150 min. using the AC Adaptor
(supplied). The charge lamp lights up and then turns off immediately when the
battery pack is fully charged.
• The above charging time applies when charging a fully depleted battery pack at a
temperature of 25°C (77°F). Charging may take longer depending on conditions of
use and circumstances.
Notes
Notes
GB
14
x
Charging by connecting to a computer
The battery pack can be charged by connecting the camera to a computer using
a micro USB cable. Connect the camera to the computer with the camera
turned off.
• If the camera is connected to a laptop computer that is not connected to a power
source, the laptop battery level decreases. Do not charge for an extended period of
time.
• Do not turn on/off or restart the computer, or wake the computer to resume from
sleep mode when a USB connection has been established between the computer
and the camera. That may cause the camera to malfunction. Before turning on/off,
or restarting the computer or waking the computer from sleep mode, disconnect
the camera and the computer.
• No guarantees are made for charging using a custom-built computer or a modified
computer.
Notes
To a USB jack
GB
15
x
Battery life and number of images that can be
recorded and played back
• The above number of images applies when the battery pack is fully charged. The
number of images may decrease depending on the conditions of use.
• The number of images that can be recorded is for shooting under the following
conditions:
– Using Sony Memory Stick PRO Duo™ (Mark2) media (sold separately)
– The battery pack is used at an ambient temperature of 25°C (77°F).
– [Display Quality] is set to [Standard]
• The number for “Shooting (still images)” is based on the CIPA standard, and is for
shooting under the following conditions:
(CIPA: Camera & Imaging Products Association)
– DISP is set to [Display All Info.].
– Shooting once every 30 seconds.
– The zoom is switched alternately between the W and T ends.
– The flash strobes once every two times.
– The power turns on and off once every ten times.
• The numbers of minutes for movie shooting are based on the CIPA standard, and
are for shooting under the following conditions:
– [ Record Setting]: XAVC S HD 60p 50M/50p 50M
– Typical movie shooting: Battery life based on repeatedly starting/stopping
shooting, zooming, turning on/off, etc.
– Continuous movie shooting: Battery life based on non-stop shooting until the
limit (29 minutes) has been reached, and then continued by pressing the MOVIE
button again. Other functions, such as zooming, are not operated.
x
Supplying power
You can use the AC Adaptor (supplied) to supply power during shooting or
playing back images, reducing battery pack consumption.
Battery life Number of images
Shooting (still
images)
Monitor — Approx. 420 images
Viewfinder — Approx. 370 images
Typical movie
shooting
Monitor Approx. 65 min. —
Viewfinder Approx. 70 min. —
Continuous
movie shooting
Monitor Approx. 120 min. —
Viewfinder Approx. 130 min. —
Viewing (still images) Approx. 315 min. Approx. 6300 images
Notes
GB
16
• The camera will not activate if there is no remaining battery. Insert a sufficiently
charged battery pack into the camera.
• If you use the camera while power is being supplied from a wall outlet (wall
socket), make sure that the icon ( ) displays on the monitor.
• Do not remove the battery pack while power is being supplied from a wall outlet
(wall socket). If you remove the battery pack, the camera will turn off.
• Do not remove the battery pack while the access lamp (page 8) is lit. The data on
the memory card may be damaged.
• As long as the power is on, the battery pack will not be charged even if the camera
is connected to the AC Adaptor.
• Under certain conditions, power may be supplied from the battery supplementarily
even if you are using the AC Adaptor.
• While power is being supplied via USB connection, the temperature inside the
camera will rise and the continuous recording time may be shortened.
Notes
Inserting a memory card (sold separately)
1
Open the cover.
2
Insert the memory card.
• With the notched corner facing as illustrated, insert the memory card
until it clicks into place.
3
Close the cover.
Ensure the notched corner
faces correctly.
GB
17
x
Memory cards that can be used
*1
Movies cannot be recorded in 100 Mbps or more.
*2
SD Speed Class 4: or faster, or UHS Speed Class 1: or faster
*3
Memory cards that fulfill all of the following conditions:
– Capacity of 4 GB or more
– SD Speed Class 10: , or UHS Speed Class 1: or faster
When recording in 100 Mbps or more, UHS Speed Class 3: is required.
• For details on the number of recordable still images and recordable duration of
movies, refer to pages 33 to 34. Check the tables to select a memory card with the
desired capacity.
• When an SDHC memory card is used to record XAVC S movies over extended
periods of time, the recorded movies will be divided into files of 4 GB. The
divided files can be integrated into a single file using PlayMemories Home™.
• Not all memory cards are guaranteed to operate correctly. For memory cards
produced by manufacturers other than Sony, consult the manufacturers of the
products.
• When using Memory Stick Micro media or microSD memory cards with this
camera, make sure to use with the appropriate adaptor.
Memory card
For still
images
For movies
MP4 AVCHD XAVC S
Memory Stick PRO Duo
(Mark2 only) (Mark2 only)
—
Memory Stick PRO-HG
Duo™
*1
Memory Stick Micro™
(M2)
(Mark2 only) (Mark2 only)
—
SD memory card
*2 *2
—
SDHC memory card
*2 *2 *3
SDXC memory card
*2 *2 *3
microSD memory card
*2 *2
—
microSDHC memory card
*2 *2 *3
microSDXC memory card
*2 *2 *3
Notes
GB
18
x
To remove the memory card/battery pack
Memory card: Push the memory card in once to eject the memory card.
Battery pack: Slide the battery lock lever. Be sure not to drop the battery pack.
• Never remove the memory card/battery pack when the access lamp (page 8) is lit.
This may cause damage to data in the memory card.
Notes
Setting the language and the clock
1
Set the ON/OFF (Power) switch to ON.
Language setting screen is displayed when you turn on the camera for the
first time.
• It may take time for the power to turn on and allow operation.
2
Select a desired language, then press z on the control
wheel.
Date & Time setting screen is displayed.
3
Check that [Enter] is selected on the screen, then press
z.
4
Select a desired geographic location by following the
on-screen instructions, then press z.
Control wheel
ON/OFF (Power)
Select items: v/V/b/B
Set the numeric value of date and
time:
v/V//
Set:
z
GB
19
Shooting still images
Shooting movies
5
Set [Daylight Savings], [Date/Time] and [Date Format],
then press z.
• When setting [Date/Time], midnight is 12:00 AM, and noon is
12:00 PM.
6
Check that [Enter] is selected, then press z.
Shooting still images/movies
1
Press the shutter button halfway down to focus.
When the image is in focus, a beep sounds and the z or indicator
lights.
• When the camera cannot focus automatically, the z indicator flashes.
2
Press the shutter button fully down to shoot an image.
1
Press the MOVIE (Movie) button to start recording.
• Use the W/T (zoom) lever to change the zoom scale.
2
Press the MOVIE button again to stop recording.
Mode dial
Shutter button
: Auto Mode
: Movie
MOVIE
W/T (zoom)
lever
W: zoom out
T: zoom in
GB
20
• Do not pull up the flash manually. This may cause a malfunction.
• The maximum aperture depends on the focal length. The aperture cannot be
opened wider than the maximum even if you set a smaller value using the aperture
ring. Check the correct aperture value on the monitor.
• When using the zoom function while shooting a movie, the sound of the camera
operating will be recorded. Sound from the camera tends to be recorded
particularly when [Zoom Speed] is set to [Fast] and when [Zoom Func. on Ring] is
set to [Quick]. The sound of the MOVIE button when movie recording is finished
or the sound of [Zoom Assist] operation may also be recorded.
• Continuous movie shooting is possible for a maximum of approximately
29 minutes at one time with the camera’s default settings and when the ambient
temperature is approximately 25°C (77°F). When movie recording is finished, you
can restart recording by pressing the MOVIE button again. Recording may stop to
protect the camera depending on the ambient temperature.
x
Selecting next/previous image
Select an image by pressing B (next)/b (previous) on the control wheel or by
turning the control wheel. Press z in the center of the control wheel to view
movies.
Notes
Viewing images
1
Press the (Playback) button.
C3/ (Delete)
Control wheel
(Playback)
W: zoom out
T: zoom in
Select images: B (next)/b (previous) or
turn the control wheel
Set: z
GB
21
x
Deleting an image
1 Press the C3/ (Delete) button.
2 Select [Delete] with v on the control wheel, then press z.
x
Returning to shooting images
Press the shutter button halfway down.
x
Control wheel
DISP (Display Contents): Allows you to change the screen display.
z (Focus Standard): If you press this key when the [Focus Area] is set to
[Flexible Spot] or [Expand Flexible Spot], you can change the position of the
focus area by pressing v/V/b/B on the control wheel. Also, you can change
the position of the focus area while shooting still images. Depending on the
options selected in [Focus Area] or [Center Lock-on AF], the available
functions varies when pressing the key.
x
Fn (Function) button
Allows you to register 12 functions and recall those functions when shooting.
1 Press the Fn (Function) button.
2 Select the desired function by pressing v/V/b/B on the control wheel.
3 Select the setting value by turning the control wheel.
• Some setting values can be finely adjusted by turning the control dial.
Introduction of other functions
Control dial
Control wheel
Fn (Function)
MENU
GB
22
x
Control dial
You can instantly change the appropriate setting for each shooting mode just
by turning the control dial.
x
Menu Items
(Camera Settings)
Image Size Selects the size of still images.
Aspect Ratio Selects the aspect ratio for still images.
Quality Sets the image quality for still images.
Img. Size(Dual Rec)
Sets the size of still images shot when recording a
movie.
Quality(Dual Rec)
Sets the image quality for still images shot when
recording a movie.
File Format Selects the movie file format.
Record Setting Selects the size of the recorded movie frame.
Dual Video REC
Sets whether to simultaneously record an XAVC S
movie and MP4 movie or an AVCHD movie and
MP4 movie.
HFR Settings Sets the High Frame Rate shooting settings.
Panorama: Size Selects the size of panoramic images.
Panorama: Direction Sets the shooting direction for panoramic images.
Drive Mode Sets the drive mode, such as for continuous shooting.
Bracket Settings
Sets self-timer shooting in bracket mode, shooting
order for exposure bracketing, and white balance
bracketing.
Flash Mode Sets the flash settings.
Flash Comp. Adjusts the intensity of flash output.
Red Eye Reduction Reduces the red-eye phenomenon when using flash.
Focus Area Selects the area of focus.
AF Illuminator
Sets the AF illuminator, which provides light for a
dark scene to aid focusing.
Exposure Comp. Compensates for the brightness of the entire image.
GB
23
ISO Sets the ISO sensitivity.
ISO AUTO Min. SS
Sets the slowest shutter speed at which ISO
sensitivity will start to change in [ISO AUTO] mode.
Metering Mode Selects the method for measuring brightness.
White Balance Adjusts color tones of an image.
DRO/Auto HDR
Compensates automatically for brightness and
contrast.
Creative Style
Selects the desired image processing. You can also
adjust contrast, saturation and sharpness.
Picture Effect
Selects the desired effect filter to achieve a more
impressive and artistic expression.
Picture Profile Changes settings such as color and tone.
Rng. of Zoom Assist
Selects the amount to zoom out with the [Zoom
Assist] function.
Focus Magnifier
Enlarges the image before shooting so that you can
check the focus.
Long Exposure
NR
Sets noise reduction processing for shots with a
shutter speed of 1/3 second or longer.
High ISO NR
Sets noise reduction processing for high-sensitivity
shooting.
Center Lock-on AF
Sets the function to track a subject and continue
focusing when pressing the center button in the
shooting screen.
Smile/Face Detect.
Selects to detect faces and adjust various settings
automatically. Sets to automatically release the
shutter when a smile is detected.
Auto Dual Rec
Sets the shutter to release automatically when an
impressive composition including a person is detected
during movie shooting.
Soft Skin Effect Sets the Soft Skin Effect and the effect level.
Auto Obj.
Framing
Analyzes the scene when capturing faces, close-ups,
or subjects tracked by Lock-on AF function, and
automatically trims and saves another copy of the
image with a more impressive composition.
GB
24
(Custom Settings)
Auto Mode
You can shoot selecting either Intelligent Auto or
Superior Auto.
Scene Selection
Selects pre-set settings to match various scene
conditions.
High Frame Rate
Selects the exposure mode during High Frame Rate
shooting to suit your subject or effect.
Movie
Selects the exposure mode to suit your subject or
effect.
SteadyShot
Sets SteadyShot for shooting still images. Reduces
blur from camera shake when shooting while holding
the camera.
SteadyShot Sets SteadyShot for shooting movies.
Color Space Changes the range of reproducible colors.
Auto Slow Shut.
Sets the function that automatically adjusts the shutter
speed following the brightness of the environment in
movie mode.
Audio Recording Sets whether to record audio when shooting a movie.
Audio Rec Level
Adjusts the audio recording level during movie
recording.
Audio Out Timing
Sets the timing of audio output during the movie
recording.
Wind Noise Reduct. Reduces wind noise during movie recording.
Memory recall
Selects a setting registered in advance when the mode
dial is set to MR (Memory recall). Optical zoom scale,
etc. can be registered.
Memory Registers the desired modes or camera settings.
Zebra Displays stripes to adjust brightness.
MF Assist Displays an enlarged image when focusing manually.
Focus Magnif. Time
Sets the length of time the image will be shown in an
enlarged form.
Initial Focus Mag.
Sets the initial magnification when an enlarged image
is displayed using [Focus Magnifier].
GB
25
Grid Line
Sets a grid line display to enable alignment to a
structural outline.
Marker Display
Sets whether to display the marker on the monitor
when recording movies.
Marker Settings
Sets the marker displayed on the monitor when
recording movies.
Audio Level Display
Sets whether or not to display the audio level on the
screen.
Auto Review
Sets auto review to display the captured image after
shooting.
DISP Button
Sets the type of information to be displayed on the
monitor or in the viewfinder by pressing DISP on the
control wheel.
Peaking Level
Enhances the outline of in-focus ranges with a
specific color when focusing manually.
Peaking Color Sets the color used for the peaking function.
Exposure Set. Guide
Sets the guide displayed when exposure settings are
changed in the shooting screen.
Live View Display
Sets whether or not to reflect settings such as
exposure compensation in screen display.
Pre-AF
Sets whether or not to perform auto focus before the
shutter button is half pressed.
Zoom Speed
Sets the zooming speed when you operate the zoom
lever.
Zoom Setting
Sets whether to use the Clear Image Zoom and Digital
Zoom when zooming.
FINDER/MONITOR
Sets the method for switching between the viewfinder
and monitor.
Release w/o Card
Sets whether to release the shutter when a memory
card is not inserted.
AEL w/ shutter
Sets whether to perform AEL when the shutter button
is half pressed. This is useful when you want to adjust
the focus and exposure separately.
Shutter Type
Sets whether a mechanical shutter or an electronic
shutter is used when shooting still images.
GB
26
Exp.comp.set
Sets whether to reflect exposure compensation value
to flash compensation.
Reset EV Comp.
Sets whether to retain the exposure value set without
using the exposure dial, or reset the exposure value to
0 when you turn off the camera.
Face Registration
Registers or changes the person to be given priority in
the focus.
Write Date
Sets whether to record a shooting date on the still
image.
Video Light Mode
Sets the illumination setting for the HVL-LBPC LED
light (sold separately).
Function Menu Set.
Customizes the functions displayed when the Fn
(Function) button is pressed.
Custom Key(Shoot.)
Assigning functions to the various keys allows you to
perform operations more quickly by pressing the keys
when shooting images.
Custom Key(PB)
Assigning functions to the keys allows you to perform
operations more quickly by pressing the keys when
playing back images.
Lens Ring Setup
Sets which of the focus function or the zoom function
to be assigned to the front lens ring and the rear lens
ring.
Focus Ring Rotate
Assigns longer-distance and shorter-distance focus to
the rotational directions of the lens ring to which the
focus function has been assigned.
Zoom Ring Rotate
Assigns zoom in/out to the rotational direction of the
lens ring to which the zoom function has been
assigned.
Zoom Func. on Ring
Sets the zooming function of the lens ring. When you
select [Quick], the zoom position moves in
accordance with the degree of rotation of the lens
ring. When you select [Step], you can move the zoom
position to a fixed step of the focal length.
MOVIE Button Sets whether to always activate the MOVIE button.
GB
27
(Wireless)
(Application)
Dial/Wheel Lock
Sets whether to disable the control dial and the
control wheel temporarily by using the Fn button
when shooting. You can disable/enable the control
dial and the control wheel by pressing and holding
down the Fn button.
Send to Smartphone Transfers images to display on a smartphone.
Send to Computer
Backs up images by transferring them to a computer
connected to a network.
View on TV You can view images on a network-enabled TV.
One-touch(NFC)
Assigns an application to One-touch (NFC). You can
call up the application when shooting by touching an
NFC-enabled smartphone to the camera.
Airplane Mode
You can set this device to not perform wireless
communications.
WPS Push
You can register the access point to the camera easily
by pushing the Wi-Fi Protected Setup™ (WPS)
button.
Access Point Set. You can register your access point manually.
Edit Device Name
You can change the device name under Wi-Fi Direct,
etc.
Disp MAC Address Displays the MAC address of the camera.
SSID/PW Reset
Resets the SSID and password of smartphone
connection.
Reset Network Set. Resets all network settings.
Application List
Displays the application list. You can select the
application you want to use.
Introduction Displays instructions on using the application.
GB
28
(Playback)
(Setup)
Delete Deletes an image.
View Mode
Sets the way in which images are grouped for
playback.
Image Index Displays multiple images at the same time.
Display Rotation Sets the playback direction of the recording image.
Slide Show Shows a slide show.
Rotate Rotates the image.
Enlarge Image Enlarges the playback images.
Enlarge Init. Mag.
Sets the initial magnification when enlarging an
image during playback.
Enlarge Initial Pos.
Sets the initial position when enlarging an image
during playback.
Protect Protects the images.
Motion Interval ADJ
Adjusts the interval for showing the tracking of
subjects in [Motion Shot Video], where the tracking
of the subject’s motion will be shown when playing
back movies.
Specify Printing Adds a print order mark to a still image.
Photo Capture
Captures the desired scene from a movie to be saved
as a still image.
Monitor Brightness Sets the monitor brightness.
Viewfinder Bright. Sets the brightness of the electronic viewfinder.
Finder Color Temp. Sets the color temperature of the viewfinder.
Gamma Disp. Assist
Converts an S-Log image to an ITU709-equivalent
image and displays it on the viewfinder or on the
monitor.
Volume Settings Sets the volume for movie playback.
Audio signals Sets the operating sound of the camera.
Upload Settings
Sets the upload function of the camera when using an
Eye-Fi card.
GB
29
Tile Menu
Sets whether to display the tile menu every time you
press the MENU button.
Mode Dial Guide
Turns the mode dial guide (the explanation of each
shooting mode) on or off.
Delete confirm.
Sets whether Delete or Cancel is preselected in the
Delete confirmation screen.
Display Quality Sets the display quality.
Pwr Save Start Time
Sets the time intervals to automatically switch to
power save mode.
NTSC/PAL Selector
*
By changing the TV format of the device, shooting in
a different movie format is possible.
Demo Mode Sets demonstration playback of a movie to on or off.
TC/UB Settings Sets the time code (TC) and user bit (UB).
HDMI Settings Sets the HDMI settings.
4K Output Sel.
Sets how to record and output 4K movies via HDMI
when the camera is connected to an external recorder/
player that supports 4K.
USB Connection Sets the USB connection method.
USB LUN Setting
Enhances compatibility by limiting the functions of
the USB connection. Set to [Multi] in normal
conditions and to [Single] only when the connection
between the camera and a computer or AV
component cannot be established.
USB Power Supply
Sets whether to supply power via USB connection
when the camera is connected to a computer or USB
device using a micro USB cable.
Language Selects the language.
Date/Time Setup Sets date and time, and daylight savings.
Area Setting Sets the location of use.
Copyright Info Sets copyright information for still images.
Format Formats the memory card.
File Number
Sets the method used to assign file numbers to still
images and movies.
GB
30
* If you switch this item, it will be required to format the memory card in the setting
compatible with the PAL or NTSC system respectively. Also, note that it may not
be possible to play back movies recorded with the NTSC system on a PAL system
TV.
Set File Name
Changes the first 3 characters of the file name for still
images.
Select REC Folder
Changes the selected folder for storing still images
and movies (MP4).
New Folder
Creates a new folder for storing still images and
movies (MP4).
Folder Name Sets the folder format for still images.
Recover Image DB
Recovers the image database file and enables
recording and playback.
Display Media Info.
Displays the remaining recording time of movies and
the recordable number of still images on the memory
card.
Version Displays the camera software version.
Setting Reset Restores settings to their defaults.
GB
31
Installing the following software to your computer will make your camera
experience more convenient.
• PlayMemories Home: Imports images to your computer and lets you use
them in different ways (page 32).
• Image Data Converter: Displays RAW images and processes them.
• Remote Camera Control: Controls a camera connected to your computer via
a USB cable.
You can download and install this software to your computer from the
following URLs.
• When using Remote Camera Control, select the MENU button t (Setup) t
[USB Connection] t [PC Remote] and then connect the camera to your
computer.
Using software
1
Using the Internet browser on your computer, go to one
of the following URLs, and then follow the instructions
on the screen to download the desired software.
Windows:
http://www.sony.co.jp/imsoft/Win/
Mac:
http://www.sony.co.jp/imsoft/Mac/
• An Internet connection is required.
• For details on operation, refer to the support page or Help page of the
software.
Notes
GB
32
The software PlayMemories Home allows you to import still images and
movies to your computer and use them. PlayMemories Home is required for
importing XAVC S movies and AVCHD movies to your computer.
http://www.sony.net/pm/
• An Internet connection is required to use PlayMemories Online or other network
services. PlayMemories Online or other network services may not be available in
some countries or regions.
• If the software PMB (Picture Motion Browser), supplied with models released
before 2011, has already been installed on your computer, PlayMemories Home
will overwrite it during the installation. Use PlayMemories Home, the successor
software of PMB.
• New functions may be installed in PlayMemories Home. Connect the camera to
your computer even if PlayMemories Home is already installed on your computer.
• Do not disconnect the micro USB cable (supplied) from the camera while the
operating screen or the accessing screen is displayed. Doing so may damage the
data.
• To disconnect the camera from the computer, click on the tasktray, then click
[Eject DSC-RX10M3].
Importing images to your computer and using
them (PlayMemories Home)
Notes
Importing images from
your camera
Sharing images on
PlayMemories Online™
Uploading
images to
network services
Creating
movie
discs
Viewing images
on a calendar
For Windows, the following functions are also
available:
Playing back imported
images
GB
33
You can add the desired functions to your camera by connecting to the
application download website (PlayMemories Camera Apps™) via the
Internet.
http://www.sony.net/pmca/
• After installing an application, you can call up the application by touching an
NFC-enabled Android smartphone to the N mark on the camera, using the
[One-touch(NFC)] function.
The number of still images and recordable time may vary depending on the
shooting conditions and the memory card.
x
Still images
The table below shows the approximate number of images that can be
recorded on a memory card formatted with this camera. The values are defined
using Sony standard memory cards for testing.
[ Image Size]: L: 20M
When [ Aspect Ratio] is set to [3:2]*
* When the [ Aspect Ratio] is set to other than [3:2], you can record more
pictures than shown above. (Except when [ Quality] is set to [RAW].)
Adding functions to the camera
Number of still images and recordable time of
movies
Quality
Number of still images
8GB 64 GB
Standard 1150 images 9600 images
Fine 690 images 5500 images
Extra fine 510 images 4150 images
RAW & JPEG 235 images 1900 images
RAW 355 images 2850 images
GB
34
x
Movies
The table below shows the approximate total recording times using a memory
card formatted with this camera. The recording time for XAVC S and AVCHD
movies is the recording time when shooting with [Dual Video REC] set to [Off].
* only when [NTSC/PAL Selector] is set to [NTSC]
• Continuous movie shooting is possible for a maximum of approximately
29 minutes at one time with the camera’s default settings and when the ambient
temperature is approximately 25°C (77°F). The maximum continuous recording
time of an MP4 (28M) format movie is about 20 minutes (limited by the 4 GB file
size restriction).
• The recordable time of movies varies because the camera is equipped with VBR
(Variable Bit-Rate), which automatically adjusts image quality depending on the
shooting scene. When you record a fast-moving subject, the image is clearer but
the recordable time is shorter because more memory is required for recording.
The recordable time also varies depending on the shooting conditions, the subject
or the image quality/size settings.
File
Format
Record Setting
Recordable time
(h (hour), m (minute))
8GB 32 GB 64 GB
XAVC S
4K
30p 100M/25p 100M 9 m 35 m 1 h 15 m
30p 60M/25p 60M 15 m 1 h 2 h 5 m
24p 100M
*
/ – 9m 35m 1h 15m
24p 60M
*
/ – 15m 1h 2h 5m
XAVC S
HD
60p 50M/50p 50M 15 m 1 h 15 m 2 h 35 m
30p 50M/25p 50M 15 m 1 h 15 m 2 h 35 m
24p 50M
*
/ – 15 m 1 h 15 m 2 h 35 m
120p 100M/100p 100M 9 m 35 m 1 h 15 m
120p 60M/100p 60M 15 m 1 h 2 h 5 m
AVCHD
60i 24M(FX)/50i 24M(FX) 40 m 3 h 6 h
60i 17M(FH)/50i 17M(FH) 55 m 4 h 5 m 8 h 15 m
60p 28M(PS)/50p 28M(PS) 35 m 2 h 30 m 5 h 5 m
24p 24M(FX)/25p 24M(FX) 40 m 3 h 6 h
24p 17M(FH)/25p 17M(FH) 55 m 4 h 5 m 8 h 15 m
MP4 1920×1080 60p 28M/
1920×1080 50p 28M
35 m 2 h 35 m 5 h 20 m
1920×1080 30p 16M/
1920×1080 25p 16M
1 h 4 h 10 m 8 h 25 m
1280×720 30p 6M/
1280×720 25p 6M
2h 35m 10h 55m 22h
GB
35
Functions built into this camera
• This camera is compatible with 1080 60p or 50p-format movies. Unlike standard
recording modes up to now, which record in an interlacing method, this camera
records using a progressive method. This increases the resolution, and provides a
smoother, more realistic image. Movies recorded in 1080 60p/1080 50p format
can be played back only on 1080 60p/1080 50p-supported devices.
• This camera is compatible with 4K 30p/4K 25p/4K 24p recording. Movies can be
recorded in a higher resolution than HD format.
• While aboard an airplane, set [Airplane Mode] to [On].
On use and care
Avoid rough handling, disassembling, modifying, physical shock, or impact such as
hammering, dropping, or stepping on the product. Be particularly careful of the lens.
Notes on recording/playback
• Before you start recording, make a trial recording to make sure that the camera is
working correctly.
• This camera is designed to be dust and moisture-resistant, but is not waterproof or
splash-proof.
• Do not directly expose the lens to beams such as laser beams. That may damage
the image sensor and cause the camera to malfunction.
•
Do not expose the camera to sunlight or shoot sunward for a long time. The internal
mechanism may be damaged.
• If moisture condensation occurs, remove it before using the camera.
• Do not shake or strike the camera. It may cause a malfunction and you may not be
able to record images. Furthermore, the recording media may become unusable or
image data may be damaged.
Do not use/store the camera in the following places
• In an extremely hot, cold or humid place
In places such as in a car parked in the sun, the camera body may become
deformed and this may cause a malfunction.
• Storing under direct sunlight or near a heater
The camera body may become discolored or deformed, and this may cause a
malfunction.
• In a location subject to rocking vibration
• Near a location that generates strong radio waves, emits radiation or is strongly
magnetic place. Otherwise, the camera may not properly record or play back
images.
• In sandy or dusty places
Be careful not to let sand or dust get into the camera. This may cause the camera to
malfunction, and in some cases this malfunction cannot be repaired.
Notes on using the camera
GB
36
ZEISS lens
The camera is equipped with a ZEISS lens which is capable of reproducing sharp
images with excellent contrast. The lens for the camera has been produced under a
quality assurance system certified by ZEISS in accordance with the quality
standards of ZEISS in Germany.
Notes on the monitor, electronic viewfinder and lens
• The monitor and electronic viewfinder are manufactured using extremely high-
precision technology, and over 99.99% of the pixels are operational for effective
use. However, some tiny black and/or bright dots (white, red, blue or green) may
appear on the monitor and electronic viewfinder. These dots are a normal result of
the manufacturing process, and do not affect the recording.
• Do not hold the camera by the monitor.
• Take care that your fingers or other objects are not caught in the lens when it is
operating.
Notes on shooting with the viewfinder
This camera is equipped with an Organic Electro-Luminescence viewfinder with
high resolution and high contrast. This viewfinder achieves a wide viewing angle
and a long eye relief. The camera is designed to provide an easily viewable
viewfinder by appropriately balancing various elements.
• The image may be slightly distorted near the corners of the viewfinder. This is not
a malfunction. When you want to check every detail of the entire composition, you
can also use the monitor.
• If you pan the camera while looking into the viewfinder or move your eyes
around, the image in the viewfinder may be distorted or the color of the image may
change. This is a characteristic of the lens or display device and is not a
malfunction. When you shoot an image, we recommend that you look at the center
area of the viewfinder.
Notes on the flash
• Do not carry the camera by the flash unit, or use excessive strength on it.
• If water, dust or sand get into the open flash unit, it may cause a malfunction.
• Take care that your finger is not in the way when pushing the flash down.
• Do not use the Multi Interface Shoe with a commercially available flash that
applies voltage of 250 V or more or has the reverse polarity of the camera. It may
cause a malfunction.
Sony accessories
Use only genuine Sony brand accessories, otherwise it may cause a malfunction.
Sony brand accessories may not come to market for some countries or regions.
On camera’s temperature
Camera body and battery may get warm with use – this is normal.
GB
37
On the overheat protection
Depending on the camera and battery temperature, you may be unable to record
movies or the power may turn off automatically to protect the camera.
A message will be displayed on the screen before the power turns off or you can no
longer record movies. In this case, leave the power off and wait until the camera and
battery temperature goes down. If you turn on the power without letting the camera
and battery cool down enough, the power may turn off again or you may be unable
to record movies.
On charging the battery
• If you charge a battery that has not been used for a long time, you may be unable
to charge it to the proper capacity.
This is due to the battery characteristics. Charge the battery again.
• Batteries which have not been used for more than a year may have become
deteriorated.
Warning on copyright
• Television programs, films, videotapes, and other materials may be copyrighted.
Unauthorized recording of such materials may be contrary to the provisions of the
copyright laws.
• To prevent [Copyright Info] from being used illegally, leave [Set Photographer]
and [Set Copyright] blank when you lend or transfer the camera.
• Sony bears no responsibility for any trouble or damage caused by unauthorized
use of [Copyright Info].
No guarantee in the case of damaged content or recording failures
Sony can provide no guarantees in the event of failure to record or loss or damage of
recorded images or audio data due to a malfunction of the camera or recording
media, etc. We recommend backing up important data.
Cleaning the camera surface
Clean the camera surface with a soft cloth slightly moistened with water, then wipe
the surface with a dry cloth. To prevent damage to the finish or casing:
– Do not expose the camera to chemical products such as thinner, benzine, alcohol,
disposable cloths, insect repellent, sunscreen or insecticide.
Maintaining the monitor
• Hand cream or moisturizer left on the monitor may dissolve its coating. If you get
any on the monitor, wipe it off immediately.
• Wiping forcefully with tissue paper or other materials can damage the coating.
• If fingerprints or debris are stuck to the monitor, we recommend that you gently
remove any debris and then wipe the monitor clean with a soft cloth.
Notes on wireless LAN
We assume no responsibility whatsoever for any damage caused by unauthorized
access to, or unauthorized use of, destinations loaded on the camera, resulting from
loss or theft.
GB
38
Notes on security when using wireless LAN products
• Always make sure that you are using a secure wireless LAN to avoid hacking,
access by malicious third parties, or other vulnerabilities.
• It is important that you set the security settings when using a wireless LAN.
• If a security problem arises because no security precautions are in place or due to
any inevitable circumstances when using a wireless LAN, Sony bears no
responsibility for the loss or damage.
Playback speed
The playback speed will vary as below depending on the assigned [ Frame Rate]
and [ Record Setting].
* only when [NTSC/PAL Selector] is set to [NTSC].
[ Priority Setting] and recordable duration
• Sound will not be recorded.
• The movie will be recorded in XAVC S HD format.
• The image becomes out of focus when the subject is too close, such as during
macro shooting. Shoot from the shortest shooting distance (W side: Approx. 3 cm
(0.10 ft), T side: Approx. 72 cm (2.36 ft) (from the lens)).
Notes on High Frame Rate shooting
Frame Rate
Record Setting
24p 50M
*
30p 50M/
25p 50M
60p 50M/
50p 50M
240fps/250fps 10 times slower
8 times slower/
10 times slower
4 times slower/
5 times slower
480fps/500fps 20 times slower
16 times slower/
20 times slower
8 times slower/
10 times slower
960fps/1000fps 40 times slower
32 times slower/
40 times slower
16 times slower/
20 times slower
Priority Setting Frame Rate
Effective pixel
number read out
from image sensor
Recordable
duration
Quality Priority
240fps/250fps 1824 × 1026
Approx. 2 seconds480fps/500fps 1676 × 566
960fps/1000fps 1136 × 384
Shoot Time Priority
240fps/250fps 1676 × 566
Approx. 4 seconds480fps/500fps 1136 × 384
960fps/1000fps 800 × 270
Notes
GB
39
Camera
[System]
Image device: 13.2 mm × 8.8 mm
(1.0 type) CMOS sensor
Effective pixel number of camera:
Approx. 20.1 Megapixels
Total pixel number of camera:
Approx. 21.0 Megapixels
Lens: ZEISS Vario-Sonnar T 25×
zoom lens
f = 8.8 mm – 220 mm (24 mm –
600 mm (35 mm film equivalent))
F2.4 (W) – F4 (T)
While shooting movies (HD 16:9):
26 mm – 630 mm
*1
While shooting movies (4K 16:9):
28 mm – 680 mm
*1
*1
When [ SteadyShot] is set to
[Standard]
SteadyShot: Optical
File format (Still images):
JPEG (DCF, Exif, MPF Baseline)
compliant, RAW (Sony ARW 2.3
Format), DPOF compatible
File format (Movies):
XAVC S format (XAVC S format
compliant):
Video: MPEG-4 AVC/H.264
Audio: LPCM 2ch (48 kHz 16 bit)
AVCHD format (AVCHD format
Ver. 2.0 compatible):
Video: MPEG-4 AVC/H.264
Audio: Dolby Digital 2ch,
equipped with Dolby Digital Stereo
Creator
• Manufactured under license from
Dolby Laboratories.
Movies (MP4 format):
Video: MPEG-4 AVC/H.264
Audio: MPEG-4 AAC-LC 2ch
Recording media: Memory Stick PRO
Duo media, Memory Stick Micro
media, SD cards, microSD memory
cards
Flash: Flash range (ISO sensitivity
(Recommended Exposure Index)
set to Auto):
Approx. 1.0 m to 10.8 m
(3.28 ft. to 35.43 ft.) (W)/
Approx. 1.0 m to 6.5 m
(3.28 ft. to 21.33 ft.) (T)
[Input/Output connectors]
HDMI connector: HDMI micro jack
Multi/Micro USB Terminal*:
USB communication
USB communication:
Hi-Speed USB (USB 2.0)
Microphone jack:
3.5 mm Stereo mini jack
Headphones jack:
3.5 mm Stereo mini jack
* Supports Micro USB compatible
device.
[Viewfinder]
Type: Electronic viewfinder (Organic
Electro-Luminescence)
Total number of dots:
2 359 296 dots
Frame coverage: 100%
Magnification: Approx. 0.70 ×
(35 mm-format equivalent) with
50 mm lens at infinity, –1 m
–1
Specifications
GB
40
Eye point (CIPA compliant):
Approx. 23 mm from the eyepiece,
approx. 21.5 mm from the eyepiece
frame at –1 m
–1
Diopter adjustment:
–4.0 m
–1
to +3.0 m
–1
[Monitor]
LCD monitor:
7.5 cm (3.0 type) TFT drive
Total number of dots:
1 228 800 dots
[Power, general]
Power: Rechargeable battery pack
NP-FW50, 7.2 V
AC Adaptor AC-UUD12/UUE12,
5V
Power consumption:
Approx. 2.3 W (during shooting
with the monitor)
Approx. 2.6 W (during shooting
with the viewfinder)
Operating temperature: 0 °C to 40 °C
(32 °F to 104 °F)
Storage temperature: –20 °C to +60 °C
(–4 °F to +140 °F)
Dimensions (CIPA compliant)
(Approx.):
132.5 mm × 94.0 mm × 127.4 mm
(5 1/4 inches × 3 3/4 inches ×
5 1/8 inches) (W/H/D)
Mass (CIPA compliant) (Approx.):
1 095 g (2 lb 6.7 oz) (including
NP-FW50 battery pack, Memory
Stick PRO Duo media)
Microphone: Stereo
Speaker: Monaural
Exif Print: Compatible
PRINT Image Matching III:
Compatible
[Wireless LAN]
Supported standard: IEEE 802.11 b/g/n
Frequency: 2.4 GHz
Supported security protocols:
WEP/WPA-PSK/WPA2-PSK
Configuration method: Wi-Fi Protected
Setup™ (WPS) / manual
Access method: Infrastructure Mode
NFC: NFC Forum Type 3 Tag
compliant
Model No. WW411000
AC Adaptor AC-UUD12/UUE12
Power requirements: AC 100 V to
240 V, 50 Hz/60 Hz, 0.2 A
Output voltage: DC 5 V, 1.5 A
Rechargeable Battery Pack
NP-FW50
Battery type: Lithium-ion battery
Maximum voltage: DC 8.4 V
Nominal voltage: DC 7.2 V
Maximum charge voltage: DC 8.4 V
Maximum charge current: 1.02 A
Capacity: 7.3 Wh (1 020 mAh)
Design and specifications are subject to
change without notice.
GB
41
Trademarks
• Memory Stick and are
trademarks or registered trademarks
of Sony Corporation.
• XAVC S and are
registered trademarks of Sony
Corporation.
• “AVCHD Progressive” and
“AVCHD Progressive” logotype are
trademarks of Panasonic Corporation
and Sony Corporation.
• Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
• The terms HDMI and HDMI High-
Definition Multimedia Interface, and
the HDMI Logo are trademarks or
registered trademarks of HDMI
Licensing LLC in the United States
and other countries.
• Windows is a registered trademark of
Microsoft Corporation in the United
States and/or other countries.
• Mac is a registered trademark of
Apple Inc. in the United States and
other countries.
• iPhone and iPad are registered
trademarks of Apple Inc. in the
United States and other countries.
• SDXC logo is a trademark of SD-3C,
LLC.
• Android and Google Play are
trademarks of Google Inc.
• Wi-Fi, the Wi-Fi logo, Wi-Fi
Protected Setup are registered
trademarks or trademarks of the Wi-
Fi Alliance.
• The N Mark is a trademark or
registered trademark of NFC Forum,
Inc. in the United States and in other
countries.
• DLNA and DLNA CERTIFIED are
trademarks of Digital Living
Network Alliance.
• Facebook and the “f” logo are
trademarks or registered trademarks
of Facebook, Inc.
• YouTube and the YouTube logo are
trademarks or registered trademarks
of Google Inc.
• Eye-Fi is a trademark of Eye-Fi, Inc.
• In addition, system and product
names used in this manual are, in
general, trademarks or registered
trademarks of their respective
developers or manufacturers.
However, the ™ or ® marks may not
be used in all cases in this manual.
GB
42
On GNU GPL/LGPL applied
software
The software that is eligible for the
following GNU General Public
License (hereinafter referred to as
“GPL”) or GNU Lesser General
Public License (hereinafter referred
to as “LGPL”) are included in the
product.
This informs you that you have a
right to have access to, modify, and
redistribute source code for these
software programs under the
conditions of the supplied GPL/
LGPL.
Source code is provided on the web.
Use the following URL to download
it.
http://oss.sony.net/Products/Linux/
We would prefer you do not contact
us about the contents of source code.
Licenses (in English) are recorded in
the internal memory of your product.
Establish a Mass Storage connection
between the product and a computer
to read licenses in the “PMHOME” -
“LICENSE” folder.
Additional information on this
product and answers to frequently
asked questions can be found at
our Customer Support Website.
GB
43
© 2016 Sony Corporation Printed in China
