User Manual Pyle PDWR53BTWT Home Wall Mount Speaker System

Documents for Pyle PDWR53BTWT

The following documents are available:
User Manual Specification Photos
PDWR53BTWT photo

User Manual

For PDWR53BTWT. Also, The document are for others Pyle models: PDWR53BTBK

What’s In The Box:
Active Wall Mount Speaker
Passive Wall Mount Speaker
Power Cable
Technical Specs:
Power Output: 300 Watt MAX
Speaker Size:
Sound System: 5.25’ Subwoofers: 0.5’ Tweeters
Subwoofer Type: Polymer PP
Tweeter Type: Mylar Dome
Frequency Response: 70 - 16 kHz (+/-3dB)
Speaker Impedance: 8 Ohm
Audio Sensitivity: 86 dB
Construction Material:
Metal Alloy, Reinforced Polypropylene
Power Cable Length:3.9’ ft.
Power Supply: 120-240V
Single Speaker Dimensions (L x W x H):
7.2'' x 6.5'' x 9.6'' -inches (Each)
PDWR53BTBK - PDWR53BTWT
WIreless BT Streaming
Mount Speaker System
Active Powered Wall Mount Home Speakers
(5.25’’ -inch, 300 Watt MAX)
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Features:
Versatile Wall Mount Speaker System
Includes (2) Speakers (Active + Passive)
Universal Indoor Home Speaker Installation
Bluetooth Wireless Music Streaming
Built-in Digital Sound Amplier
2-Way Full Range Stereo Sound Reproduction
Impressive Bass Response
Rear Panel Audio Settings Control Center
Connect & Stream Audio from External Devices
RCA (L/R) Audio Connector Jacks
Aux (3.5mm) Input Jack (Loop + Sub)
Screw Terminal Block Speaker Connectors
(Active Speaker)
Rotary Volume, Bass, Treble Adjustment
Power LED Indicator Light
Adjustable Angle Wall Mount Brackets
Rugged & Heavy Duty Cabinet Enclosure
Unique Standby / Auto Power On with Audio Signal Input
Removable & Rust Proof Metal Speaker Grills
Daisy-chain Ability (Active to Passive Speaker)
Stereo System
Used for Home, Garage, Enclosed Patio & Porch Deck
Applications
Recommended for Indoor Use Only
Wireless BT Streaming Connectivity:
Built-in BT for Wireless Music Streaming
Simple & Hassle-Free Pairing
Works with All of Today’s Latest Devices
(Smartphones, Tablets, Laptops, Computers, etc.)
Wireless BT Version: 4.2
Wireless BT Network Name: PyleUSA
Wireless Range: 33’+ ft.
Loading ...

Specifications

Pyle PDWR53BTWT Questions and Answers

Find answers or Ask a question.


  • Total questions: 1
  • Questions unAnswered : 1

#1 Was there supposed to be speaker wire w/these? The manual indicates that there was.

Speaker wire is not included. 16AWG is recommended

#2 How much does each of the PDWR53BTBK speaker weigh?

We only have the total weight
Weight: 12.12 lbs.

#3 How do I make the ACTIVE speaker the RIGHT speaker?

There is ni option to switch the speakers left to right

#4 What is the difference between ON and Auto?

ON is continuous power. Auto. During power ON mode, light is constant blue color; During power AUTO mode, lights go off when there is no signal input and it turns to a blue color when the signal comes.

#5 Are you able to connect 4 of these together?

If you wish to connect wirelessly. It is not possible. But it can be connected by wired through loop and aux in

#6 When I try to connect to Bluetooth it’s asking for pin number. I don’t have PIN number

You can use 0000
