RS694N4BC1
RS694N4BB1
2
Contents
Safety and warning information.........2
Installing your new appliance............7
Description of the appliance ............9
Display controls...............................10
Using your appliance.......................14
.......................21
.......................23
Troubleshooting...............................25
Disposaloftheappliance....................27
Cleaning and care....
Helpful hints and tips
This appliance is produced in accordance with the following EU
guidelines: LVD 2014/35/EU, EMC 2014/30/EU, 2009/125/EC,
EC.643/2009 and 2002/96/EC.
Safety and warning information
For your safety, before installing
and first using the appliance,
read this user manual carefully,
including its hints and warnings.
To avoid unnecessary mistakes
and accidents, it is important to
make sure that all people using
the appliance are thoroughly
familiar with its operation and
safety features. Save these
instructions and be sure that
they remain with the appliance if
it is moved or sold, so that
anyone using it, throughout its
life, will be properly informed on
its usage and safety notices.
For the safety of life and
property, keep the warnings
contained within these user's
instructions as the manufacturer
is not responsible for damages
caused by omission.
Safety for children and
others who are vulnerable
This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance should not be
carried out by children without
supervision.
Keep all packaging away
from children as there is risk of
suffocation.
3
If you are discarding the
appliance, pull the plug out of
the socket, cut the connection
cable (as close to the appliance
as you can) and remove the
door to prevent children playing
from suffering an electric shock
or from closing themselves
inside the unit.
General safety
WARNING —This
appliance is intended
to be used to be used in
domestic households and not
intended for use in retail or
commercial environments;
WARNING — The water
supply line should only be
connected to a potable water
supply.
WARNING — Do not store
explosive substances such as
aerosol cans with a flammable
propellant in this appliance.
WARNING — If the supply
cord is damaged, it must be
replaced by a qualified
electrician in order to avoid the
risk of electric shock.
WARNING — Keep
ventilation openings, in the
appliance enclosure or in any
built-in structure clear of
obstruction.
WARNING — Do not use
mechanical devices or other
means to accelerate the
defrosting process, other than
those recommended by the
manufacturer.
WARNING — Do not damage
the refrigerant circuit.
WARNING — Do not use
electrical appliances inside the
food storage compartments of
the appliance, unless they are
of the type recommended by
the manufacturer.
WARNING — The refrigerant
and insulation are flammable.
When disposing of the
appliance, do so only at an
authorized waste disposal
center. Do not expose to flame.
Refrigerant
The refrigerant isobutene
(R600a) is contained within the
refrigerant circuit of the
appliance. This is a natural gas
with a high level of
environmental compatibility,
which is nevertheless
4
flammable. During
transportation and installation
of the appliance, ensure that
none of the components of the
refrigerant circuit becomes
damaged. The refrigerant
(R600a) is flammable.
Caution:risk of fire
If the refrigerant circuit is
damaged:
-Avoid naked flames and
sources of ignition.
-Thoroughly ventilate the room
in which the appliance is
situated. It is dangerous to alter
specifications or modify this
product in any way. Any
damage to the cord may cause
a shortcircuit, fire, and/or
electric shock.
Electrical safety
3. Make sure that you can
access the main plug of the
appliance.
4. Do not pull the main cable.
5. If your wall socket is loose,
do not insert the power plug.
There is a risk of electric shock
or fire.
6. You must not operate the
appliance without the interior
lighting lamp cover.
7. The fridge should only be
supplied with single phase
alternating current of
220~240V/50Hz. If the supply
fluctuates outside this range an
automatic A.C. voltage
regulator of more than 350W
should be used. The fridge
should be plugged into an
adequately earthed supply.
1. The power cord must not be
lengthened.
2. Make sure that the power
plug is not crushed or
damaged. A crushed or
damaged power plug may
overheat and cause a fire.
Daily use
Do not store flammable gas
or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical
appliances in the appliance
(e.g. electric ice cream makers,
mixers etc.).
5
When unplugging always pull
the plug from the mains socket.
Do not pull on the cable.
Do not place hot items near
the plastic components of this
appliance.
Do not place food products
directly against the air outlet on
the rear wall.
Store pre-packed frozen food
in accordance with the frozen
food manufacture’s instructions.
The manufactures storage
recommendations should be
strictly adhered to. Refer to
relevant instructions for
storage.
Do not place carbonated or
fizzy drinks in the freezer
compartment as it creates
pressure on the container,
which may cause it to explode,
resulting in damage to the
appliance.
Do not place food directly
against the air outlet on the rear
wall cause it to explode,
resulting in damage to the
appliance.
Frozen food can cause frost
burns if consumed straight from
the freezer compartment.
Do not place the appliance in
direct sunlight.
Keep burning candles, lamps
and other items with naked
flames away from the
appliance.
The appliance is only
intended for keeping food stuff
and/or beverages for normal
household consumption as
explained in this instruction
booklet.
The appliance is heavy. Care
should be taken when moving it
Do not remove nor touch
items from the freezer
compartment if your hands are
damp/wet, as this could cause
skin abrasions or frost/freezer
burns.
Never use the base, drawers,
doors etc. to stand on or as
supports.
Frozen food must not be
refrozen once it has been
thawed out.
6
To avoid items falling and
causing injury or damage to the
appliance, do not overload the
door racks or put too much food
in the crisper drawers.
Caution!
Care and cleaning
Before performing
maintenance, switch off the
appliance and disconnect the
mains plug from the mains
socket.
Do not clean the appliance
with metal objects, steam
cleaner, ethereal oils, organic
solvents or abrasive cleansers.
Do not use sharp objects to
remove frost from the
appliance. Use a plastic
scraper.
Installation Important!
It is advisable to wait at least
four hours before connecting
the appliance to avoid
damaging the compressor.
Adequate air circulation
should be provided around the
appliance. To achieve sufficient
ventilation, please follow the
instructions relevant to
installation.
Wherever possible the back
of the product should not be too
close flammable materials as
some components are hot in
normal operation.
The appliance must not be
locate close to radiators or
cookers.
Make sure that the mains
plug is accessible following
installation of the appliance.
For electrical connection
carefully, follow the instructions
given in this manual.
Unpack the appliance and
check for damage. Do not
connect the appliance if it is
damaged. Report possible
damage immediately to your
retailer. In this case retain
packing.
Service
This product must be serviced
by an authorized Service
Center or Service Agent, and
only genuine spare parts must
be used.
WARNING
fill with potable water only.
50-70
adjusta e bottom f etbl e
adjusta e bottom f etbl e
0.5
15mm
Beverage Compartment
Water storage box part
Use your appliance according to the following control guidelines, your product
has a control panel as shown in the diagram below.
When the appliance is powered on for
the first time, the backlighting of the
icons on the display panel starts
working. If no buttons have been
touched and the doors are closed, the
backlighting will turn off after 60
seconds.
Caution! When you set a
temperature, you set an average
temperature for the whole refrigerator
cabinet. Temperatures inside each
compartment may vary from the
temperatures displayed on the panel,
depending on how much food you
store and where you place it. High or
low room temperature may also affect
the actual temperature inside the
appliance.
The control panel consists of two
areas about temperature, and one
area about different modes.
Display controls
10
Non Plumbing
You can touch “Ice Off” button to
control the ice maker. When the Child
Lock is off, and the ice function is on,
you can touch the “Ice Off” icon to
close the ice maker, and the icon “ ”
will be illuminated. If you want to open
the ice maker, please touch the “Ice
Off” icon again, and the icon “ ” will
be off.
When the door of fridge or freezer is
open over 2 minutes, the door alarm
will come on. In case of alarm, “ ”
icon will be on and will be buzzing
sound. The buzzer will sound 3 times
per minute and will stop after 10
minutes. Also it can be stoped by
closing the door.
In case of alarm, “ ” icon will be on
and a buzzing sound will be heard.
Touch “Alarm” key to clear alarm then
the “ ” icon will turn off and the
buzzing will stop.
Press and hold “Alarm” for 3 seconds
to lock the all the Control Panel
including dispenser function. If
Control panel is locked, the icon “ ”
will be illuminated, and none of the
buttons on the Control panel work.
OFF
“Child Lock and Door Alarm”
This button serves two purposes:
To unlock the Control panel, please
press and hold “Alarm” for 3 seconds
again.
1.Child Lock
2.Door Alarm
To save energy, please avoid keeping
doors open for along time when
using refrigerator.
When Child Lock is off, and the doors
are open, you can turn alarm off by
touching “Alarm” .
“Ice Control”
This button controls the ice maker.
OFF
“Holiday”
If you are going to be away for a long
period of time such as a long holiday
or business trip, you can activate this
function by touching the “Holiday”
button, and the icon “ ” will be
illuminated.
When the holiday function is
activated, the temperature of the
fridge is automatically switched to
15℃ and the freezer to -18℃ to
minimize the energy consumption.
The fridge temperature seting
displays “ ” and the freezer—
compartment remains on.
When the holiday function is on, you
can switch off it by touching “Holiday”
again, and the icon “ ” will be off.
When the holiday function is on, the
ice maker will automatically turn off.
The refrigerator will retain the setting
when powered off.
Child Lock 3
"
Note: Do not store any food in the
fridge during the “Holiday” time, or it
will quickly deteriorate.
Note: When the
close the ice maker not the dispenser.
“Ice Off” is on, it only
11
“Fridge temperature control”
You can touch the “Fridge” icon to
activate the mode to control the fridge
temperature. When you touch the
button continuously, the temperature
will be set the following sequence.in
If you want to decrease the time
needed to cool products in the Fridge,
please touch and hold this button for
3 seconds, the super cool icon “ ”
will be illuminated, the fridge
temperature setting displays 2℃.
Super cool automatically switches off
after 3 hours, and the refrigerator
temperature setting will revert back to
the previous setting.
When super cool function is on, you
can touch the “Fridge” to switch it off
and it will revert to previous
temperature setting. The fridge will
not retain the Super Cool function
when power off.
“Freezer temperature control”
Press and hold the “Freezer” button
for 3 seconds, the icon “ ”will be
illuminated, the freezer temperature
setting displays -24℃.
Super Freezer can quickly lower the
temperature and freeze your food
faster than usual. This can retain
more of the vitamins and nutrition in
fresh food and keep your food longer.
The super freeze option allows you to
freeze the maximum amount of
possible. We recommend that you let
the appliance operates for 6 hours
first. Super freeze automatically
switches off after 26 hours, and the
freezer temperature setting will revert
back to the previous setting.
When the super freeze function is on,
you can touch “Freezer” for to switch
off the Super Freeze function, and it
will revert to previous temperature
setting. And it will not retain the Super
Freeze function when power off.
“Dispenser control”
You can touch the “Freezer” button to
activate the mode to control the
freezer temperature. When you press
the button continuously, the
temperature will be set thein
When the freezer door is opened or
the Child Lock is on, the dispenser will
not work.
The Ice Type button includes “Cubed”
and “Crushed” options.
Super Cool 3
"
Super Freeze 3
"
Note: On the Super Cool function,
when you touch the “Holiday” or “Eco”
button, “Holiday” or “Eco” function will
be activated, and “Super Cool” mode
will be off.
Note: On the function,
when you touch the “Holiday” or “Eco”
button, “Holiday” or “Eco” function will
be activated, and “Super Freezer”
mode will be off.
Super Freezer
following sequence.
12
When the refrigerator is powered
on, all the icons of the control panel
will light up for 3 seconds, and a
buzzer sounds. The Child Lock is off.
And the temperature setting reverts
back to the previous setting.
You can touch this button to turn
Energy Saver mode on and off .
When you turn Energy Saver on, the
Energy Saver icon “ ” lights.
If Energy Saver is off
and the icon goes off.
The temperature of the fridge is
automatically switched to and the℃6
freezer to -℃.17
If you need water, please touch the
“Water” button, and the water icon
“ ” will light up. The mode is then
set.
When you touch the Ice Type button,
the cubed or crushed ice mode which
you choose will be activated, and the
Cubed “ ” or Crushed “ ” ice icon
lights up.
“Energy Save”
Note!
The control panel will light up when
the door is open or you touch any
button.
The light will go off without touching
any button or the doors have been
closed for one minutes.
If you don’t need ice, turn the function
off to save on water and energy
consumption.(See Ice Off above.)
Filter Reset 3
"
Note!
You can the "Cubed" or
"Crushed" to choose the toption
of Ice to be dispensed. You can touch
the "Water" to activate thebutton
water mode.
press
ype
13
“Water storage box Alarm”
If the water storage box part
is not correctly installed or not
installed, the water storage box
alarm will come on for reminding
users. You can clear the alarm
by holding "Eco" button for 3
seconds.
If water is not dispensed or
dispensing slowly you need to,
check whether the water storage
box part is correctly installed or not
and make sure there is enough
water in the water storage box .
When you touching the "water" button
for water, the water pump will start to
draw, there is little nosie when the
water pump working, it is normal.
②
nut
①
bolt
③
spanner
4
When you remove the shelves, gently
pull them forward until the shelf
comes clear of the shelf guides.
When you return the shelves, make
sure there is no obstacle behind and
gently push the shelf back into the
position.
Bottle rack
It is for storing bottled wine or drinks.
Note: Please use gently when you
removed the bottled wine or drinks.
The shelf can be taken out to be
cleared or you can adjust to save the
shelf space.
Drawers
These are suitable for storage of fruits
and vegetable. And it can be taken
out to be cleaned.
3. Using your freezer compartment
The freezer compartment is suitable
for storage of foods required to be
frozen, such as meat, fish, ice cream
and other perishable items.
15
Caution! Ensure that bottles are not
left in the freezer for longer than
needed as freezing may cause the
bottle break.
Water storage box
It is for providing water for ice maker
and water dispenser, if you need
inpouring water into the water storage
box, you can lift the front small cover,
and then inpourring directly. It can be
removed horizontal outward
If you need clean it
WARNING: fill with potable water only.
Bottled or canned liquid are at risk of
exploding caused by volume
expansion and so should not be
stored in the freezer compartment.
4. Using the dispenser
You can choose the type of ice or
water by touching the “Cubed” or
“Crushed” or “Water” button.
When you choose ice type, push the
dispenser gently with your cup. Ice
will be released from the dispenser.
Make sure the cup is in line with the
dispenser, and the ice exactly fall into
the cup.
If you select Cubed Ice after using
the Crushed Ice feature, a small
amount of residual crushed ice might
fall into your cup.
Do not removing your
cup or glass from under the dispenser
after dispensing water or ice you
need. You should be wait for 2 or 3
seconds to prevent spills.
immediately
Do not pull the lever out as this could
damage or break the lever’s spring.
The dispensed water is cool, not icy
cold. When you want colder water with
ice, dispense ice to your glass first,
then fill with water from the dispenser.
Note:
Super Freeze 3
"
Super Cool 3
"
Filter Reset 3
"
Child Lock 3
"
Super Freeze 3
"
Super Cool 3
"
Filter Reset 3
"
Chi
ld Lock 3
"
16
Do not dispense ice continually more
than one minute during normal use to
avoid the excessive temperature on
the ice crusher motor.
5. Using the Ice Bucket
If you want to remove the Ice Bucket:
Please hold the handle as shown in
the figure below. Then lift up and pull
the Ice Bucket out slowly to prevent
damage.
Note!
When the ice maker dumps ice into
the bucket, any sounds you hear are
part of normal operation.
If you do not dispense ice for a
long periods of time, Ice may clump
in the Ice Bucket. If this occurs,
please remove all the ice and empty
the bucket.
If ice doesn’t come out, please
check for any ice stuck in the chute
and remove it. Or pull out the Ice
Bucket and check for any ice cubes
clump, then remove them.
Ice chute
Ice Maker Cover
Ice Bucket
If you are going on a long vacation
or business trip and won’t be using
the ice dispensers for period of time,
please close the water valve to
prevent leaks.
①L the Ice Bucketift up
②Pull the Ice Bucket out slowly
Removing Steps:
B
B’
A
A’
When you put it back, please make
sure the two side(B&B’) of Ice Bucket
is wedged into the buckles(A&A’).
①
②
Installing Steps:
①
the two side(B&B’) of Ice Bucket
wedge into the buckles(A&A’).
②Pull the Ice Bucket down, and make
sure the Ice Bucket is held the bracket
firmly.
Push the Ice Bucket up, and make
①
②
Pull out
A
B
A
B
Push up
17
If the refrigerator has been power-
off too long,the ice in the bucket will
melt ,and the water will flow out of the
refrigerator to the floor.To avoid
this,you should remove all the ice in
the bucket .
Warning!
Do not put your fingers, hands, or
any other unsuitable objects in the ice
chute or ice bucket. This can cause
personal injury or material damage.
Do not allow your children to hang
off the dispenser or pluck the ice
storage bin. This could cause injury.
If you want more space to store
foods, you can replace
the storage box. The “Ice Off”
should be set on to make sure that
the ice maker is off.
the Ice Bucket
with
To clean the Ice Bucket, wash with a
mild detergent, rinse well, and dry
thoroughly it. Do not use harsh or
abrasive cleaners or solvents.
Before replacing back the Ice
Bucket, please check the two couplers
are at a suitable angle to connect
correctly. If not, please turn the Ice
bucket coupler to the right angle to
match the motor coupler.
The first batch of ice cubes after
installation may be small, because air
has entered the water line. Any air will
be purged during normal use. If the
ice cubes is still small, please check
the water is circulated in line, or water
valve is opened large enough, or the
water is at a high pressure properly.
Do not use excessive force to open
or close the door, or the water may
spill out off the ice maker.
Ice Bucket
Storage Box
Super Free
z
e
3
"
Sup
er C
ool 3
"
Fi
lt
e
r Re
s
et 3
"
Child Lock 3
"
18
Connect
Motor Coupler
Ice Bucket Coupler
There is a water line connection
between ice maker and water
storage box, don't disassemble
the whole water supply system by
yourself. It is recommended that
suitably qualified person to do this..
6.Home bar
Please press the middle position
of the top of the bar door, when you
hear a "click" sound, the bar-door
could be opened.
The lamp in the cold storage room
will be lit when the bar-door is opened,
then it would be convenient for the
internal food to be taken and placed.
Bottles, drinks, wine cup can be put
upper and convenient to be used when
the bar door is opened just like a tray.
but too manyheavy objects can be not
placed to avoid accidents
.
Less than two goblets can be
hang on the cup.
The bar door is safely shut as it
clicks on.
It can be more energy saving
when open or close the bar door
without let the cold storage door
opened.
It is not allowed for children to
climb on the bar door, play swings
on the bar door or sit on the bar door
when the bar door is opened, and
these would avoid effecting buffering
effect of the bar or causing accidents.
Less than four bottles of coke
, drinks, beer and other articles
except the cans can be placed
on the Coca Cola rack inside
the bar. The Coca Cola rack
can be turned upwards to
facilitate the use of the users.
Please do not remove the shelf
of the bar inside the refrigerator,
otherwise the bar can't be used.
hear a click sound, the bar-door
9
Please do not damage the
tray of the bar, such as: using
your hand to press the tray or
scratching the tray with a sharp
tool.
Please clean up the beverage,
liquid and sundries on the tray
of the bar in time.
Please clean up the bar and
around of the bar regularly.
Please do not
remove the shelf
20
1
Door seals cleaning
Take care to keep door seals clean.
Sticky food and drinks can cause
seals to stick to the cabinet and tear
when you open the door. Wash the
seals with a mild detergent and warm
water. Rinse and dry them thoroughly
after cleaning.
Warning!
Only after the door seals are
completely dry should the appliance
be powered on.
Although this appliance automatically
defrosts, a layer of frost may occur on
the freezer compartment’s interior
walls if the freezer door is opened
frequently or kept open too long. If the
frost is too thick, choose a time when
the freezer is nearly empty and
proceed as follow:
1. Remove existing food and
accessories baskets, unplug the
appliance from the mains power and
leave the doors open. Ventilate the
room thoroughly to accelerate the
process.
2. When defrosting is completed,
clean your freezer as described
above.
Warning!
Do not use sharp objects to remove
frost from the freezer compartment.
Only after the interior is completely
dry should the appliance be switched
back on and plugged back into the
mains socket.
Replacing the LED light
Warning: The LED light must be
replaced by a competent person. If
the LED light is damaged, follow the
steps below:
1. Unplug your appliance.
2. Remove light cover by rising up
and puling out the LED light.
3. Hold the LED light with one hand
and pull it with the other hand while
pressing the connector latch.
4.Replace LED light and snap it
correctly in place and recover the light
cover.
22
Water storage box cleaning
You should clean the water storage
box regularly. You can remove the
water storage box along horizontal
outward, and then disassemble the
cover of box. Wipe the inside of the
box and cover with a weaksolution
of bicarbonate of soda, and then
rinse with warm water using a
wrung-out sponge or cloth, clean it
with directly drinking water again.
Thoroughly dry all surfaces and
removable parts before putting them
back into place. You can assemble
the water storage box along
horizontal forward when you finish
cleaning.
Hints for freezing
When first starting-up or after a
period out of use, let the appliance
run at least 2 hours on the higher
settings before putting food in the
compartment.
Prepare food in small portions to
enable it to be rapidly and completely
frozen and make it possible to
subsequently thaw only the quantity
required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are
airtight.
Do not allow fresh, unfrozen food to
touch the food which is already frozen
to avoid patrial defrosting.
Helpful hints and tips
Energy saving tips
We recommend that you follow the
tips to save energy.
Try to avoid keeping the door open
for long periods in order to conserve
energy.
Ensure the appliance is away from
any sources of heat (Direct sunlight,
electric oven or cooker etc.)
Don’t set the temperature colder
than necessary.
Don’t store warm food or
evaporating liquid in the appliance.
Place the appliance in a well
ventilated, humidity free room. Please
refer to the installing your new
appliance chapter.
The description of appliance
diagram shows the correct
combination for the drawers, crisper
and shelves, do not adjust the
combination as this is designed to be
the most energy efficient
configuration.
Hints for refrigeration
Do not place hot food directly into
the refrigerator or freezer, the internal
temperature will increase resulting in
the compressor having to work harder
and will consume more energy.
Do cover or wrap the food,
particularly if it has a strong flavor.
Place food properly so that air can
circulate freely around it.
Meat (All Types) Wrap in polythene
food: wrap and place on the glass
shelf above the vegetable drawer.
Always follow food storage times and
use by dates suggested by
manufacturers.
Cooked food, cold dishes, etc.:
They should be covered and may be
placed on any shelf.
Fruit and vegetables:
They should be stored in the special
drawer provided.
Butter and cheese:
Should be wrapped in airtight foil or
plastic film wrap.
Milk bottles:
Should have a lid and be stored in the
door racks.
Hints for fresh food refrigeration
23
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
Hints for the storage of frozen food
Ensure that frozen food has been
stored correctly by the food retailer
Once defrosted, food will deteriorate
rapidly and should not be re-frozen.
Do not exceed the storage period
indicated by the food manufacturer.
Switching off your appliance
If the appliance needs to be switched
off for an extended period, the
following steps should be taken to
prevent mould on the appliance.
1. Remove all food.
2. Remove the power plug from the
mains socket.
3. Clean and dry the interior
thoroughly.
4. Ensure that all the doors are
wedged open slightly to allow air to
circulate.
24
Troubleshooting
If you experience a problem with your appliance or are concerned that the
appliance is not functioning correctly, you can carry out some easy checks
before calling for service, please see below. You can carry out some easy
checks according to this section before calling for service.
Warning! Don't try to repair the appliance yourself. If the problem persists after
you have made the checks mentioned below, contact a qualified electrician,
authorized service engineer or the shop where you purchased the product.
Appliance is not
working correctly
Check whether the power cord is plugged into the power outlet
properly.
Check the fuse or circuit of your power supply replace if,
necessary.
The ambient temperature is too low. Try setting the chamber
temperature to a colder level to solve this problem.
It is normal that the freezer is not operating during the automatic
defrost cycle, or for a short time after the appliance is switched on to
protect the compressor.
The interior may need to be cleaned.
Some food, containers or wrapping cause odours.
The sounds below are quite normal:
Compressor running noises.
Air movement noise from the small fan motor in the freezer
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.
Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may need
you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers knocking against each other.
Problem
Possible cause & Solution
Odours from the
compartments
Noise from the
appliance
25
You may have left the doors open too long or too frequently; or the
doors are kept open by some obstacle; or the appliance is located
with insufficient clearance at the sides, back and top.
Increase the temperature by following the”Display controls” chapter.
Check whether the top of the refrigerator is tilted back by mm10-15
to allow the doors to self close, or if something inside is preventing
the doors from closing.
The water pan (located at the rear bottom of the cabinet)
may not be properly leveled, or the draining spout under
neath the top of the compressor depot may not be properly
positioned to direct water into this pan, or the water spout
is blocked. You may need to pull the refrigerator away from
the wall to check the pan and spout.
Check if the refrigerator is power-off for a long time, this
may cause the ice in the bucket to melt into water,
and flow to the floor .
The LED light may be damaged. Refer to replace LED lights in
cleaning and care chapter.
The control system has disabled the lights due to the door being
kept open too long, close and reopen the door to reactivate the
lights.
It is normal to frequently hear the sound of the motor, it will need to
run more during following circumstances:
Temperature setting is set colder than necessary.
Large quantity of warm food has recently been stored within the
appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After your installing the appliance or it has been switched off for a
long time.
The motor runs
continuously
Temperature
inside is too warm
Temperature
inside is too cold
Doors can’t be
closed easily
Water drips on
the floor
The light is not
working
before making ice? if it is not sufficiently cool, it may take longer to
make ice, such as when first installed.
Did you manually stop the ice making function? Make sure you
Ice is not
dispensing
A layer of frost
occurs in the
compartment
Check that the air outlets are not blocked by food and ensure food
is placed within the appliance to allow sufficient ventilation. Ensure
the door can be fully closed. To remove the frost, please refer to the
cleaning and care chapter.
26
Did you wait for 10 hours after installation of the water supply line
Is the water storage box installed accurately? Make sure
there is enough water in the water storage box..
Disposal of the appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the
packaging into a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug
Warning! Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause
eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the
return and collection systems or contact the retailer where the
product was purchased. They can take this product for
environmental safe recycling.
Correct Disposal of this product
Water dispenser
is not functioning
This is normal. The bubbling comes from the refrigerant coolant
liquid circulating through the refrigerator.
You can hear
water bubbling in
the refrigerator
27
Is there any ice blocked within the ice maker bucket or ice chute?
Is the freezer temperature too warm? Try setting the freezer
temperature lower.
have set the Cubed or Crushed mode on.
Is the water storage box installed accurately? Make sure
there is enough water in the water storage box.
Is water line broke or bent? Make sure the water line
is unblocked and clear of any obstruction.
Is the water storage box frozen for the refrigerator temperature
is too low? Try selecting a warmer setting on the display panel.
Is the water pump working?
220-240V~, 50Hz, R600a ;
S e rv ic e
:
0 8 4 4 3 4 6 0 0 8 7
H i s e
n s
e
Help Line
Hise
nse UK Ltd
Unit 2 Meadow Court
Leeds
Millshaw Lane
LS11 8LZ
