The number in parentheses indicates the number of pieces.
• Camera (1)
• Rechargeable battery pack NP-BN (1)
(This rechargeable battery pack cannot be used with Cyber-shot that are supplied with
the NP-BN1 battery pack.)
• Dedicated USB cable (1)
• AC Adaptor AC-UB10/UB10B/UB10C/UB10D (1)
• Wrist strap (1)
• Instruction Manual (this manual) (1)
Owner’s Record
The model and serial numbers are located on the bottom. Record the serial number in the space
provided below. Refer to these numbers whenever you call your Sony dealer regarding this product.
Model No. DSC-W730
Serial No. ______________________________
Model No. AC-UB10/AC-UB10B/AC-UB10C/AC-UB10D
Serial No. ______________________________
To reduce fire or shock hazard, do not expose the unit to rain or moisture.
IMPORTANT SAFETY INSTRUCTIONS
-SAVE THESE INSTRUCTIONS
DANGER
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY FOLLOW THESE
INSTRUCTIONS
If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the proper
configuration for the power outlet.
English
Learning more about the camera (“Cyber-shot User
Guide”)
“Cyber-shot User Guide” is an on-line manual. Refer to it for in-depth
instructions on the many functions of the camera.
1 Access the Sony support page.
http://www.sony.net/SonyInfo/Support/
2 Select your country or region.
3 Search for the model name of your camera within the support page.
• Check the model name on the bottom of your camera.
Checking the supplied items
WARNING
4-468-211-11(1)
DSC-W730
© 2013 Sony Corporation Printed in China
Digital Still Camera
Cámara fotografía digital
Instruction Manual
Manual de instrucciones
[ Battery pack
If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical burns.
Observe the following cautions.
• Do not disassemble.
• Do not crush and do not expose the battery pack to any shock or force such as hammering, dropping
or stepping on it.
• Do not short circuit and do not allow metal objects to come into contact with the battery terminals.
• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a car parked
in the sun.
• Do not incinerate or dispose of in fire.
• Do not handle damaged or leaking lithium ion batteries.
• Be sure to charge the battery pack using a genuine Sony battery charger or a device that can charge
the battery pack.
• Keep the battery pack out of the reach of small children.
• Keep the battery pack dry.
• Replace only with the same or equivalent type recommended by Sony.
• Dispose of used battery packs promptly as described in the instructions.
[ AC Adaptor
Use the nearby wall outlet (wall socket) when using the AC Adaptor. Disconnect the AC Adaptor
from the wall outlet (wall socket) immediately if any malfunction occurs while using the apparatus.
The power cord (mains lead), if supplied, is designed specifically for use with this camera only, and
should not be used with other electrical equipment.
[ RECYCLING LITHIUM-ION BATTERIES
Lithium-Ion batteries are recyclable.
You can help preserve our environment by returning your used rechargeable
batteries to the collection and recycling location nearest you.
For more information regarding recycling of rechargeable batteries, call toll free
1-800-822-8837, or visit http://www.rbrc.org/
Caution: Do not handle damaged or leaking Lithium-Ion batteries.
[ Battery pack
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
UL is an internationally recognized safety organization.
The UL Mark on the product means it has been UL Listed.
If you have any questions about this product, you may call:
Sony Customer Information Center
1-800-222-SONY (7669)
The number below is for the FCC related matters only.
[ Regulatory Information
[ CAUTION
You are cautioned that any changes or modifications not expressly approved in this manual could void
your authority to operate this equipment.
[ Note:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
The supplied interface cable must be used with the equipment in order to comply with the limits for a
digital device pursuant to Subpart B of Part 15 of FCC Rules.
CAUTION
For Customers in the U.S.A. and Canada
For Customers in the U.S.A.
Declaration of Conformity
Trade Name: SONY
Model No.: DSC-W730
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo,
San Diego, CA 92127 U.S.A.
Telephone No.: 858-942-2230
This device complies with Part15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
x
Charging time (Full charge)
The charging time is approximately 115 min. using the AC Adaptor (supplied).
x
Charging by connecting to a computer
The battery pack can be charged by connecting the camera to a computer using the
dedicated USB cable.
x
Battery life and number of images that can be recorded and
played back
• The number is based on the CIPA standard.
(CIPA: Camera & Imaging Products Association)
Inserting the battery pack
1
Open the cover.
2
Insert the battery pack.
Charging the battery pack
1
Connect the camera to the AC Adaptor (supplied), using the
dedicated USB cable (supplied).
2
Connect the AC Adaptor to the wall outlet.
• Turn off the camera while charging the battery.
Battery life Number of images
Shooting (still images) Approx. 100 min. Approx. 200 images
Actual shooting (movies) Approx. 40 min. —
Continuous shooting (movies) Approx. 90 min. —
Viewing (still images) Approx. 190 min. Approx. 3800 images
Battery eject lever
Charge lamp
Lit: Charging
Off: Charging finished
Flashing:
Charging error or charging paused
temporarily because the camera is
not within the proper temperature
range
To a USB jack
x
To remove the memory card/battery pack
Memory card: Push the memory card in once to eject the memory card.
Battery pack: Slide the battery eject lever. Be sure not to drop the battery pack.
Shooting still images
Shooting movies
Inserting a memory card (sold separately)
1
Open the cover.
2
Insert the memory card (sold separately).
Setting the clock
1
Press the ON/OFF (Power) button.
2
Select a desired language.
3
Select a desired geographic location by following the on-screen
instructions, then press z on the control button.
4
Set [Date & Time Format], [Summer Time] and [Date & Time],
then select [OK] t [OK].
5
Follow the instructions on the screen.
Shooting still images/movies
1
Press the shutter button halfway down to focus.
2
Press the shutter button fully down to shoot an image.
1
Press the shutter button fully down to start recording.
2
Press the shutter button fully down again to stop recording.
Ensure the notched corner
faces correctly.
Control button
ON/OFF (Power)
Mode switch
Shutter button
W: zoom out
T: zoom in
: Still image
: Sweep Panorama
: Movie
W/T (Zoom)
x
Selecting next/previous image
Select an image by pressing B (next)/b (previous) on the control button. Press z in the
center of the control button to view movies.
x
Deleting an image
1 Press / (Delete) button.
2 Select [This Image] with v on the control button, then press z.
This camera is equipped with a built-in instruction guide. This allows you to search the
camera’s functions according to your needs.
The software “PlayMemories Home” allows you to import still images and movies to
your computer and use them.
• “PlayMemories Home” is not compatible with Macs. Use the applications that are installed
on your Mac. For details, visit the following URL:
http://www.sony.co.jp/imsoft/Mac/
Viewing images
1
Press the (Playback) button.
In-Camera Guide
1
Press the MENU button.
2
Select the desired MENU item, then press the / (In-Camera
Guide) button.
• If you press the / (In-Camera Guide) button when the MENU screen is not
displayed, you can search the guide using keywords or icons.
Features of “PlayMemories Home”
Control button
W: zoom out
T: zoom in
/ (Delete)
(Playback)
/ (In-Camera Guide)
MENU
Viewing images
on Calendar
Importing
images from
your camera
Sharing images on
“PlayMemories Online”
Uploading images to
network services
zDownloading “PlayMemories Home” (for Windows only)
You can download “PlayMemories Home” from the following URL:
www.sony.net/pm
The following computer environment is recommended when using the software
“PlayMemories Home” (Windows) and “Music Transfer” (Windows/Mac) and when
importing images via a USB connection.
Windows
*1
64-bit editions and Starter (Edition) are not supported.
*2
Starter (Edition) is not supported.
Mac
*Equipped with Intel processor
On use and care
Avoid rough handling, disassembling, modifying, physical shock, or impact such as
hammering, dropping, or stepping on the product. Be particularly careful of the lens.
Notes on recording/playback
• Before you start recording, make a trial recording to make sure that the camera is working
correctly.
• The camera is neither dust-proof, nor splash-proof, nor water-proof.
• Avoid exposing the camera to water. If water enters inside the camera, a malfunction may
occur. In some cases, the camera cannot be repaired.
• Do not aim the camera at the sun or other bright light. It may cause the malfunction of the
camera.
• If moisture condensation occurs, remove it before using the camera.
• Do not shake or strike the camera. It may cause a malfunction and you may not be able to
record images. Furthermore, the recording media may become unusable or image data may
be damaged.
Warning on copyright
Television programs, films, videotapes, and other materials may be copyrighted. Unauthorized
recording of such materials may be contrary to the provisions of the copyright laws.
No compensation for damaged content or recording failure
Sony cannot compensate for failure to record or loss or damage of recorded content due to a
malfunction of the camera or recording media, etc.
Note on disposal/transfer of the camera
To protect personal data, perform the following when disposing of or transferring the camera.
• Format the internal memory, record images up to full capacity of the internal memory with
the lens covered, and then format the internal memory again. This will make it difficult to
recover any of your original data.
• Reset all camera settings by performing [Initialize] t [OK].
Camera
[System]
Image device: 7.75 mm (1/2.3 type) CCD, Primary color filter
Total pixel: Approx. 16.4 Megapixels
Effective pixel: Approx. 16.1 Megapixels
Lens: Carl Zeiss Vario-Tessar 8× zoom lens
f = 4.5 mm – 36 mm (25 mm – 200 mm (35 mm film equivalent))
F3.3 (W) – F6.3 (T)
While shooting movies (16:9): 28 mm – 224 mm*
While shooting movies (4:3): 34 mm – 272 mm*
* When [Movie SteadyShot] is set to [Standard].
SteadyShot: Optical
Burst shooting (when shooting with the largest pixel number):
Approx. 1 image/second (up to 3 images)
File format:
Still images: JPEG (DCF, Exif, MPF Baseline) compliant, DPOF compatible
Movies: MPEG-4 AVC/H.264
Recording media: Internal Memory (Approx. 27 MB), “Memory Stick XC Duo” media,
“Memory Stick PRO Duo” media, “Memory Stick Micro” media, SD cards, microSD
memory cards
Flash: Flash range (ISO sensitivity (Recommended Exposure Index) set to Auto):
Approx. 0.3 m to 2.8 m (11 7/8 inches to 9 ft. 2 1/4 inches) (W)
Approx. 1.5 m to 2 m (4 ft. 11 1/8 inches to 6 ft. 6 3/4 inches) (T)
Recommended computer environment
OS (pre-installed) Microsoft Windows XP
*1
SP3/Windows Vista
*2
SP2/
Windows 7 SP1/Windows 8
CPU Intel Pentium III 800 MHz or faster (For playing/editing
the High Definition movies: Intel Core Duo 1.66 GHz or
faster/Intel Core 2 Duo 1.66 GHz or faster)
Memory Windows XP: 512 MB or more (1 GB or more is
recommended.)
Windows Vista/Windows 7/Windows 8: 1 GB or more
Hard Disk (Disk space required
for installation)
Approximately 500 MB
Display 1,024×768 dots or more
OS (pre-installed) USB Connection: Mac OS X v10.5 to v10.8
Music Transfer: Mac OS X v10.5 to v10.8*
Notes on using the camera
Specifications
[Input and Output connectors]
USB / A/V OUT jack:
Video output
Audio output
USB communication
USB communication: Hi-Speed USB (USB 2.0)
[Screen]
LCD screen: 6.7 cm (2.7 type) TFT drive
Total number of dots: 230 400 dots
[Power, general]
Power: Rechargeable battery pack NP-BN, 3.6 V
AC Adaptor AC-UB10/UB10B/UB10C/UB10D, 5 V
Power consumption (during shooting): Approx. 1.2 W
Operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Dimensions (CIPA compliant):
93.1 mm × 52.3 mm × 22.5 mm (3 3/4 inches × 2 1/8 inches × 29/32 inches) (W/H/D)
Mass (CIPA compliant) (including NP-BN battery pack, “Memory Stick Duo” media):
Approx. 122 g (4.3 oz)
Microphone: Monaural
Speaker: Monaural
Exif Print: Compatible
PRINT Image Matching III: Compatible
AC Adaptor AC-UB10/UB10B/UB10C/UB10D
Power requirements: AC 100 V to 240 V, 50 Hz/60 Hz, 70 mA
Output voltage: DC 5 V, 0.5 A
Operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage temperature: –20 °C to +60 °C (–4 °F to +140 °F)
Dimensions:
Approx. 50 mm × 22 mm × 54 mm (2 inches × 7/8 inches × 2 1/4 inches) (W/H/D)
Mass: Approx. 48 g (1.7 oz)
Rechargeable battery pack NP-BN
Used battery: Lithium-ion battery
Maximum voltage: DC 4.2 V
Nominal voltage: DC 3.6 V
Maximum charge voltage: DC 4.2 V
Maximum charge current: 0.9 A
Capacity:
typical: 2.3 Wh (630 mAh)
minimum: 2.2 Wh (600 mAh)
Design and specifications are subject to change without notice.
Trademarks
• The following marks are trademarks of Sony Corporation.
, “Cyber-shot,” “Memory Stick XC Duo,” “Memory Stick PRO Duo,”
“Memory Stick Micro”
• Windows is registered trademark of Microsoft Corporation in the United States and/or other
countries.
• Mac and Mac OS are registered trademarks of Apple Inc.
• SDXC logo is a trademark of SD-3C, LLC.
• Facebook and “f” logo are trademarks or registered trademarks of Facebook, Inc.
• YouTube and the YouTube logo are trademarks or registered trademarks of Google Inc.
• In addition, system and product names used in this manual are, in general, trademarks or
registered trademarks of their respective developers or manufacturers. However, the ™ or ®
marks are not used in all cases in this manual.
Printed using VOC (Volatile Organic Compound)-free vegetable oil based ink.
Additional information on this product and answers to frequently asked questions can
be found at our Customer Support Website.
Loading ...
