![](https://files.manualsfile.com/13272126-vt-415/bg1.png)
LED TRACKLIGHT
VT-415
15W
1050lm
24
IP20
90
1
3
2
90
35 0
OF F
ON
OF F
OF F
ON
ON
Installation instructions:
1, Switch off the power.
2, Fix the lamp into the track and turn adaptor slide switch. (picture 1)
3, Ajust the illumination angle of the luminaire.(picture 2)
4, Switch on the power if above steps done properly without any mistakes.(picture 3)
200mm
50mm
50mm
front frame
lens
screw
cob led
heat sink
rubber ring
housing
led driver
adaptor
universaljont
nut
nut
cover
loacator
card
