LED TRACKLIGHT
1
3
2
90
350
OFF
ON
OFF
OFF
ON
ON
Installation instructions:
1, Switch off the power.
2, Fix the lamp into the track and turn adaptor slide switch. (picture 1)
3, Ajust the illumination angle of the luminaire.(picture 2)
4, Switch on the power if above steps done properly without any mistakes.(picture 3)
2
0
0
m
m
5
0
m
m
5
0
m
m
front frame
lens
screw
cob led
heat sink
rubber ring
housing
led driver
adaptor
universaljont
nut
nut
cover
loacator card
Model Wa�s Lumens Beam Angle PF LED Chip Type CRI Body Type Long Life Input Power Dimension
VT-407 7 490 24° >0.5 COB-Samsung Chip >90 Aluminium 30,000 Hours AC:220-240V,50/60Hz 180xØ40.5x50mm
VT-415 15 1200 24° >0.5 COB-Samsung Chip >90 Aluminium 30,000 Hours AC:220-240V,50/60Hz 200xØ50x50mm
VT-420 20 1600 24° >0.9 COB-Samsung Chip >90 Aluminium 30,000 Hours AC:220-240V,50/60Hz 220xØ60x50mm
