User manual
DLP
®
Projector
English
2
TABLE OF CONTENTS
SAFETY ............................................................................................... 4
Important Safety Instruction....................................................................................................... 4
3D Safety Information ................................................................................................................ 5
Copyright ................................................................................................................................... 6
Disclaimer .................................................................................................................................. 6
Trademark Recognition ............................................................................................................. 6
FCC ........................................................................................................................................... 7
Declaration of Conformity for EU countries ............................................................................... 7
WEEE ........................................................................................................................................ 7
INTRODUCTION ................................................................................ 8
Package Overview..................................................................................................................... 8
Standard accessories ................................................................................................................ 8
Optional accessories ................................................................................................................. 8
Product Overview ...................................................................................................................... 9
Connections.............................................................................................................................. 10
Keypad ..................................................................................................................................... 11
Remote control ......................................................................................................................... 12
SETUP AND INSTALLATION ........................................................... 13
Installing the projector .............................................................................................................. 13
Connecting sources to the projector ......................................................................................... 14
Adjusting the projector image ................................................................................................... 15
Remote setup ........................................................................................................................... 16
USING THE PROJECTOR ............................................................... 18
Powering on / off the projector.................................................................................................. 18
Selecting an input source ......................................................................................................... 20
Menu navigation and features .................................................................................................. 21
OSD Menu tree......................................................................................................................... 22
Display menu ............................................................................................................................ 29
Audio menu .............................................................................................................................. 34
Setup menu .............................................................................................................................. 34
Info menu.................................................................................................................................. 38
MAINTENANCE ................................................................................. 39
Replacing the lamp ................................................................................................................... 39
Installing and cleaning the dust lter ........................................................................................ 41
English
3
ADDITIONAL INFORMATION .......................................................... 42
Compatible resolutions ............................................................................................................. 42
Image size and projection distance .......................................................................................... 44
Projector dimensions and ceiling mount installation ................................................................. 45
IR remote codes ....................................................................................................................... 46
Troubleshooting ........................................................................................................................ 48
Warning indicators .................................................................................................................... 50
Specications ........................................................................................................................... 52
Optoma global ofces ............................................................................................................... 53
English
4
SAFETY
The lightning ash with arrow head within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufcient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Please follow all warnings, precautions and maintenance as recommended in this user's guide.
Important Safety Instruction
To prolong the effective life of the lamp, make sure to keep the lamp on for at least 60 seconds and
avoid performing force shutdown.
RG2
Do not stare into the beam, RG2.
As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015.
Do not block any ventilation openings. To ensure reliable operation of the projector and to protect from
over heating, it is recommended to install the projector in a location that does not block ventilation.
As an example, do not place the projector on a crowded coffee table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book case or a cabinet that restricts air ow.
To reduce the risk of re and/or electric shock, do not expose the projector to rain or moisture. Do not
install near heat sources such as radiators, heaters, stoves or any other apparatus such as ampliers
that emits heat.
Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short
out parts that could result in re or electric shock.
Do not use under the following conditions:
± In extremely hot, cold or humid environments.
(i) Ensure that the ambient room temperature is within 5°C ~ 40°C
(ii) Relative humidity is 10% ~ 85%
± In areas susceptible to excessive dust and dirt.
± Near any appliance generating a strong magnetic eld.
± In direct sunlight.
Do not use the projector in places where ammable gases or explosives gases may be present in the
atmosphere. The lamp inside the projector becomes very hot during operation and the gases may
ignite and result in a re.
Do not use the unit if it has been physically damaged or abused. Physical damage/abuse would be
(but not limited to):
± Unit has been dropped.
± Power supply cord or plug has been damaged.
± Liquid has been spilled on to the projector.
± Projector has been exposed to rain or moisture.
± Something has fallen in the projector or something is loose inside.
Do not place the projector on an unstable surface. The projector may fall over resulting in injury or the
projector may become damaged.
English
5
Do not block the light coming out of the projector lens when in operation. The light will heat the object
and could melt, cause burns or start a re.
Please do not open or disassemble the projector as this may cause electric shock.
Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous
voltages or other hazards. Please call Optoma before you send the unit for repair.
See projector enclosure for safety related markings.
The unit should only be repaired by appropriate service personnel.
Only use attachments/accessories specied by the manufacturer.
Do not look into straight into the projector lens during operation. The bright light may harm your eyes.
When replacing the lamp, please allow the unit to cool down. Follow instructions as described on
pages 39-40.
This projector will detect the life of the lamp itself. Please be sure to change the lamp when it shows
warning messages.
Reset the "Lamp Reset" function from the on-screen display "Lamp Settings" menu after replacing the
lamp module.
When switching the projector off, please ensure the cooling cycle has been completed before
disconnecting power. Allow 90 seconds for the projector to cool down.
When the lamp is approaching to the end of its life time, the message "Lamp life exceeded." will show
on the screen. Please contact your local reseller or service center to change the lamp as soon as
possible.
Turn off and unplug the power plug from the AC outlet before cleaning the product.
Use a soft dry cloth with mild detergent to clean the display housing. Do not use abrasive cleaners,
waxes or solvents to clean the unit.
Disconnect the power plug from AC outlet if the product is not being used for a long period of time.
Note: When the lamp reaches the end of its life, the projector will not turn back on until the lamp module has
been replaced. To replace the lamp, follow the procedures listed under “Replacing the Lamp” section
on pages 39-40.
Do not setup the projector in places where it might be subjected to vibration or shock.
Do not touch the lens with bare hands.
Remove battery/batteries from remote control before storage. If the battery/batteries are left in the
remote for long periods, they may leak.
Do not use or store the projector in places where smoke from oil or cigarettes may be present, as it
can adversely affect the quality of the projector performance.
Please follow the correct projector orientation installation as non standard installation may affect the
projector performance.
Use a power strip and or surge protector. As power outages and brown-outs can KILL devices.
3D Safety Information
Please follow all warnings and precautions as recommended before you or your child use the 3D function.
Warning
Children and teenagers may be more susceptible to health issues associated with viewing in 3D and should be
closely supervised when viewing these images.
Photosensitive Seizure Warning and Other Health Risks
Some viewers may experience an epileptic seizure or stroke when exposed to certain ashing images
or lights contained in certain Projector pictures or video games. If you suffer from, or have a family
history of epilepsy or strokes, please consult with a medical specialist before using the 3D function.
Even those without a personal or family history of epilepsy or stroke may have an undiagnosed
condition that can cause photosensitive epileptic seizures.
English
6
Pregnant women, the elderly, sufferers of serious medical conditions, those who are sleep deprived or
under the inuence of alcohol should avoid utilizing the unit’s 3D functionality.
If you experience any of the following symptoms, stop viewing 3D pictures immediately and consult a
medical specialist: (1) altered vision; (2) light-headedness; (3) dizziness; (4) involuntary movements
such as eye or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions;
(9) cramps; and/ or (10) disorientation. Children and teenagers may be more likely than adults
to experience these symptoms. Parents should monitor their children and ask whether they are
experiencing these symptoms.
Watching 3D projection may also cause motion sickness, perceptual after effects, disorientation, eye
strain and decreased postural stability. It is recommended that users take frequent breaks to lessen
the potential of these effects. If your eyes show signs of fatigue or dryness or if you have any of the
above symptoms, immediately discontinue use of this device and do not resume using it for at least
thirty minutes after the symptoms have subsided.
Watching 3D projection while sitting too close to the screen for an extended period of time may
damage your eyesight. The ideal viewing distance should be at least three times the screen height. It
is recommended that the viewer’s eyes are level with the screen.
Watching 3D projection while wearing 3D glasses for an extended period of time may cause a
headache or fatigue. If you experience a headache, fatigue or dizziness, stop viewing the 3D
projection and rest.
Do not use the 3D glasses for any other purpose than for watching 3D projection.
Wearing the 3D glasses for any other purpose (as general spectacles, sunglasses, protective goggles,
etc.) may be physically harmful to you and may weaken your eyesight.
Viewing in 3D projection may cause disorientation for some viewers. Accordingly, DO NOT place your
3D PROJECTOR near open stairwells, cables, balconies, or other objects that can be tripped over, run
into, knocked down, broken or fallen over.
Copyright
This publication, including all photographs, illustrations and software, is protected under international copyright
laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced
without written consent of the author.
© Copyright 2017
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no representations
or warranties with respect to the contents hereof and specically disclaims any implied warranties of
merchantability or tness for any particular purpose. The manufacturer reserves the right to revise this publication
and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any
person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and pending
applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
DLP
®
, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor
TM
is a
trademark of Texas Instruments.
MHL, Mobile High-Denition Link and the MHL Logo are trademarks or registered trademarks of MHL Licensing,
LLC.
All other product names used in this manual are the properties of their respective owners and are
Acknowledged.
English
7
FCC
This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by turning the device off and on is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the device and receiver.
Connect the device into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain compliance with FCC
regulations.
Caution
Changes or modications not expressly approved by the manufacturer could void the user's authority, which is
granted by the Federal Communications Commission, to operate this projector.
Operation Conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference received, including interference that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian ICES-003.
Remarque à l'intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
Declaration of Conformity for EU countries
EMC Directive 2014/30/EC (including amendments)
Low Voltage Directive 2014/35/EC
R & TTE Directive 1999/5/EC (if product has RF function)
WEEE
Disposal instructions
Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure
utmost protection of the global environment, please recycle it.
English
8
INTRODUCTION
Package Overview
Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items
under optional accessories may not be available depending on the model, specication and your region of
purchase. Please check with your place of purchase. Some accessories may vary from region to region.
The warranty card is only supplied in some specic regions. Please consult your dealer for detailed information.
Standard accessories
Optional accessories
Note: Optional accessories vary depending on model, specication and region.
Projector Remote control Power lead Documentation
Warranty Card*
Basic User Manual
Note:
The actual remote control may vary depending on the region.
The remote control is shipped with the batteries.
* For European warranty Information, please visit www.optoma.com.
HDMI cable Lens cap
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
English
9
INTRODUCTION
Product Overview
21
8 9
9
5
3 4
11 11
10
4
6
7
Minimum
100mm
Minimum
100mm
Minimum
100mm
Minimum
300mm
Minimum
300mm
Minimum 100mm
Note:
Do not block projector intake and exhaust vents.
When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake
and exhaust vents.
No Item No Item
1. Top Cover 7. Lens Shift Dial
2. Focus Ring 8. Zoom Lever
3. Lens 9. Ventilation (outlet)
4. IR Receiver 10. Keypad
5. Input / Output 11. Tilt-Adjustment Foot
6. Ventilation (inlet)
English
10
INTRODUCTION
Connections
532 6 97
1112
1 4 8
10
No Item No Item
1. RS232 Connector 7. USB Power Out (5V 1.5A)
2. HDMI 1 Connector 8. Service Connector
3. HDMI 2 / MHL Connector 9. S/PDIF Connector
4. VGA Connector 10. AUDIO OUT Connector
5. 12V OUT Connector 11. Kensington
TM
Lock Port
6. AUDIO IN Connector 12. Power Socket
English
11
INTRODUCTION
Keypad
1
7
3
4
2
6 5
8
9
No Item No Item
1. Power 6. Lamp LED
2. Enter 7. On/Standby LED
3. Re-Sync 8. Source
4. Menu 9. Four Directional Select Keys
5. Temp LED
English
12
INTRODUCTION
Remote control
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
1
2
4
5
6
7
8
13
14
15
16
20
21
23
24
27
9
22
17
18
19
3
10
11
12
25
26
No Item No Item
1. Power On 15. User 3
2. User 2 16. Contrast
3. User 1 17. Display Mode
4. Brightness 18. Aspect Ratio
5. Keystone 19. 3D Mode
6. Mute 20. Sleep Timer
7. DB (Dynamic Black) 21. Volume +
8. Source 22. Re-Sync
9. Enter 23. Four Directional Select Keys
10. Menu 24. Volume -
11. HDMI1 25. HDMI2
12. VGA1 26. YPbPr (not supported)
13. VGA2 (not supported) 27. Video (not supported)
14. Power Off
Note: Some keys may have no function for models that do not support these features.
English
13
SETUP AND INSTALLATION
Installing the projector
Your projector is designed to be installed in one of four possible positions.
Your room layout or personal preference will dictate which installation location you select. Take into consideration
the size and position of your screen, the location of a suitable power outlet, as well as the location and distance
between the projector and the rest of your equipment.
Table mount front Ceiling mount front
Table mount rear Ceiling mount rear
Projector should be placed at on a surface and 90 degrees / perpendicular to the screen.
How to determine projector location for a given screen size, please refer to distance table on
page 44.
How to determine screen size for a given distance, please refer to distance table on page 44.
Note: The further away the projector is placed from the screen the projected image size increases and vertical
offset also increases proportionally.
IMPORTANT!
Do not operate the projector in any orientation other that table top or ceiling mount. The projector should
be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate
the warranty and may shorten the lifetime of the projector lamp or the projector itself. For none standard
installation advise please contact Optoma.
English
14
SETUP AND INSTALLATION
Connecting sources to the projector
MOLEX
MOLEX
1
8
2
3
4 5
6
10
11
12 79
13
No Item No Item No Item
1. HDMI Cable 6. USB Cable 11. HDMI Dongle
2. MHL Cable 7. S/PDIF Out Cable 12. RS232 Cable
3. RCA Component Cable 8. USB Power Cable 13. Power Cord
4. VGA In Cable 9. Audio Out Cable
5. Audio In Cable 10. 12V DC Jack
English
15
SETUP AND INSTALLATION
Adjusting the projector image
Image height
The projector is equipped with elevator feet for adjusting the image height.
1. Locate the adjustable foot you wish to adjust on the underside of the projector.
2. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector.
Tilt-Adjustment Feet
Tilt-Adjustment Ring
Zoom, lens shift, and focus
To adjust the image size and position, do the following:
a. To adjust the image size, turn the zoom lever clockwise or counterclockwise to increase or decrease
the projected image size.
b. To adjust the image position, turn the lens shift dial clockwise or counterclockwise to adjust the
position of the projected image vertically.
Zoom Lever
Lens Shift
English
16
SETUP AND INSTALLATION
To adjust the focus, turn the focus ring clockwise or counterclockwise until the image is sharp and
legible.
Focus Ring
Note: The projector will focus at a distance of 1.2m to 8.1m.
Remote setup
Installing / replacing the batteries
Two AAA size batteries are supplied for the remote control.
1. Remove the battery cover on the back of the remote control.
2. Insert AAA batteries in the battery compartment as illustrated.
3. Replace back cover on remote control.
Note: Replace only with the same or equivalent type batteries.
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.
Do not mix batteries of different types. Different types of batteries have different characteristics.
Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or
cause chemical leakage in old batteries.
Remove batteries as soon as the are depleted. Chemicals that leak from batteries that come in contact
with skin can cause a rash. If you nd any chemical leakage, wipe thoroughly with a cloth.
The batteries supplied with this product may have a shorter life expectancy due to storage conditions.
If you will not be using the remote control for an extended period of time, remove the batteries.
When you dispose of the batteries, you must obey the law in the relative area or country.
English
17
SETUP AND INSTALLATION
Eective range
Infra-Red (IR) remote control sensor is located on top of the projector. Ensure to hold the remote control at an
angle within 30° (horizontally) or 20° (vertically) perpendicular to the projector’s IR remote control sensor to function
correctly. The distance between the remote control and the sensor should not be longer than 7 meters (~22 feet).
Note: When pointing the remote control directly (0 degrees angle) on the IR sensor, the distance between the
remote control and the sensor should not be longer than 10 meters (~32 feet).
Make sure that there are no obstacles between the remote control and the IR sensor on the projector
that might obstruct the infra-red beam.
Make sure the IR transmitter of the remote control is not being shined by sunlight or uorescent lamps
directly.
Please keep the remote controller away from uorescent lamps for over 2 meters or the remote
controller might become malfunction.
If the remote control is close to Inverter-Type uorescent lamps, it might become ineffective from time
to time.
If the remote control and the projector are within a very short distance, the remote control might
become ineffective.
When you aim at the screen, the effective distance is less than 7 meters from the remote control to the
screen and reecting the IR beams back to the projector. However, the effective range might change
according to screens.
ON
OFF
Menu
VGA1
HDMI1
User2
Con trast
Asp ect ra tio
DB
Vol ume
Sou rce
Re- sync
User1
Bri ghtnes s
Key stone
Mut e
User3
Mod e
3D
Sle ep Tim er
Vol ume
HDMI2
VGA2
Video
YPbPr
ON
OFF
Menu
VGA1
HDMI1
User2
Con trast
Asp ect ra tio
DB
Vol ume
Sou rce
Re- sync
User1
Bri ghtnes s
Key stone
Mut e
User3
Mod e
3D
Sle ep Tim er
Vol ume
HDMI2
VGA2
Video
YPbPr
Approx. ±15° (horizontally)
or ±10° (vertically)
Approx. ±15° (horizontally)
or ±10° (vertically)
English
18
USING THE PROJECTOR
Powering on / o the projector
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
or
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
ON
OFF
User2
Contrast
User1
Brightness
User3
Mode
Powering on
1. Securely connect the power lead and signal/source cable. When connected, the On/Standby LED will
turn red.
2. Turn on the projector by pressing the “
” button on the projector keypad or the remote control.
3. A start up screen will display in approximately 10 seconds and the On/Standby LED will be ashing
blue.
Note: The rst time the projector is turned on, you will be prompted to select the preferred language, projection
orientation, and other settings.
English
19
USING THE PROJECTOR
Powering o
1. Turn off the projector by pressing the “ ” button on the projector keypad or the “ ” button on the
remote control.
2. The following message will be displayed:
Power Off
Power Off?
Press power key again.
3. Press the “ ”/“ ” button again to con rm, otherwise the message will disappear after 15 seconds.
When you press the “
”/“ ” button for the second time, the projector will shut down.
4. The cooling fans will continue to operate for about 10 seconds for the cooling cycle and the On/
Standby LED will ash green or ash blue. When the On/Standby LED turns solid red, this indicates
the projector has entered standby mode. If you wish to turn the projector back on, you must wait until
the cooling cycle has nished and the projector has entered standby mode. When the projector is in
standby mode, simply press the “
” button again to turn on the projector.
5. Disconnect the power lead from the electrical outlet and the projector.
Note: It is not recommended that the projector is turned on immediately, right after a power off procedure.
English
20
USING THE PROJECTOR
Selecting an input source
Turn on the connected source that you want to display on the screen, such as computer, notebook, video player,
etc. The projector will automatically detect the source. If multiple sources are connected, press the “ ” button on
the projector keypad or the Source button on the remote control to select the desired input.
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
Menu
Volume
or
English
21
USING THE PROJECTOR
Menu navigation and features
The projector has multilingual on-screen display menus that allow you to make image adjustments and change a
variety of settings. The projector will automatically detect the source.
1. To open the OSD menu, press
on the remote control or the projector keypad.
2. When OSD is displayed, use keys to select any item in the main menu. While making a selection
on a particular page, press
on the remote control or the projector keypad to enter sub menu.
3. Use keys to select the desired item in the sub menu and then press
to view further settings.
Adjust the settings by using keys.
4. Select the next item to be adjusted in the sub menu and adjust as described above.
5. Press
to con rm, and the screen will return to the main menu.
6. To exit, press
again. The OSD menu will close and the projector will automatically save the new
settings.
Sub Menu
Main Menu
Settings
Navigation guide
Display
Image Settings
3D
Aspect Ratio
Edge Mask
Digital Zoom
Image Shift
Select Exit Enter
English
22
USING THE PROJECTOR
OSD Menu tree
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Display Image Settings
Display Mode
Cinema
HDR
HDR SIM.
Game
Reference
Bright
User
3D
ISF Day
ISF Night
ISF 3D
Wall Color
Off [Default]
Blackboard
Light Yellow
Light Green
Light Blue
Pink
Gray
Dynamic Range
HDR
Off
Auto [Default]
HDR Picture
Mode
Bright
Standard [Default]
Film
Details
HDR Demo
Mode
Off [Default]
On
Brightness -50 ~ 50
Contrast -50 ~ 50
Sharpness 1 ~ 15
Color -50 ~ 50
Tint -50 ~ 50
Gamma
[Not 3D Mode]
Film
Video
Graphics
Standard(2.2)
1.8
2.0
2.4
Gamma
[3D Mode]
3D
English
23
USING THE PROJECTOR
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Display Image Settings Color Settings
BrilliantColor
TM
1 ~ 10
Color
Temperature
D55
D65
D75
D83
D93
Native
Color Gamut
Native
HDTV
Presentation
Cinema
Game
CMS
Color
R [Default]
G
B
C
Y
M
W
x offset -50 ~ 50 [Default: 0]
y offset -50 ~ 50 [Default: 0]
Brightness -50 ~ 50 [Default: 0]
Reset
Cancel [Default]
Yes
Exit
RGB Gain/Bias
Red Gain -50 ~ 50
Green Gain -50 ~ 50
Blue Gain -50 ~ 50
Red Bias 0 ~ 100
Green Bias 0 ~ 100
Blue Bias 0 ~ 100
Reset
Cancel [Default]
Yes
Exit
Color Space
[Not HDMI Input]
Auto [Default]
RGB
YUV
Color Space
[HDMI Input]
Auto [Default]
RGB(0~255)
RGB(16~235)
YUV
English
24
USING THE PROJECTOR
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Display
Image Settings
Signal
Automatic
Off
On [Default]
Frequency
-50 ~ 50 (depends on signal)
[Default: 0]
Phase
0 ~ 31 (depends on signal)
[Default: 0]
H. Position
-50 ~ 50 (depends on signal)
[Default: 0]
V. Position
-50 ~ 50 (depends on signal)
[Default: 0]
Exit
UltraDetail
Off
1
2
3
Dynamic Black
Off [Default]
On
Brightness Mode
Bright [Default]
Eco.
3D
3D Mode
Off [Default]
On
3D Sync Invert
Off [Default]
On
Aspect Ratio
4:3
16:9
LBX
Superwide
Native
Auto
Edge Mask 0 ~ 10 [Default: 0]
Digital Zoom -5 ~ 25 [Default: 0]
Image Shift
H
-100 ~ 100 [Default: 0]
V
-100 ~ 100 [Default: 0]
Audio
Internal
Speaker
Auto [Default]
Off
On
Mute
Off [Default]
On
Volume 0 ~ 10 [Default: 5]
Setup Projection
Front [Default]
Rear
Ceiling-top
Rear-top
English
25
USING THE PROJECTOR
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Setup
Lamp Settings
Lamp Reminder
Off
On [Default]
Lamp Reset
Cancel [Default]
Yes
Filter Settings
Filter Usage
Hours
(read only)
Optional Filter
Installed
Yes
No
Filter Reminder
Off
300hr
500hr [Default]
800hr
1000hr
Filter Reset
Cancel [Default]
Yes
Power Settings
Direct Power On
Off [Default]
On
Auto Power Off
(min.)
0 ~ 180 (5 min increments)
[Default: 0]
Sleep Timer
(min.)
0 ~ 990 (30 min increments)
[Default: 0]
Always On
No [Default]
Yes
Power Mode
(Standby)
Active
Eco [Default]
Security
Security
Off
On
Security Timer
Month
Day
Hour
Change
Password
Test Pattern
Green Grid
Magenta Grid
White Grid
White
Off
Remote
Settings
[depends on
remote]
IR Function
On
Front
Back
Off
English
26
USING THE PROJECTOR
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Setup
Remote
Settings
[depends on
remote]
User1
Test Pattern
CMS
Color Temp
Gamma
Auto Source
Projection
Lamp Settings
Digital Zoom
MHL
Dynamic Range [Default]
Dynamic Black
User2
Test Pattern
CMS
Color Temp
Gamma
Auto Source
Projection
Lamp Settings
Digital Zoom
MHL [Default]
Dynamic Range
Dynamic Black
User3
Test Pattern
CMS
Color Temp
Gamma
Auto Source
Projection
Lamp Settings
Digital Zoom
MHL
Dynamic Range
Dynamic Black [Default]
Projector ID 00 ~ 99
12V Trigger
On
Off
English
27
USING THE PROJECTOR
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Setup Options
Language
English [Default]
Deutsch
Français
Italiano
Español
Português
簡体中文
日本語
한국어
Русский
Menu Settings
Menu Location
Top Left
Top Right
Center [Default]
Bottom Left
Bottom Right
Menu Timer
Off
5sec
10sec [Default]
Auto Source
Off [Default]
On
Input Source
HDMI1
HDMI2/MHL
VGA
High Altitude
Off [Default]
On
Display Mode
Lock
Off [Default]
On
Keypad Lock
Off [Default]
On
Information Hide
Off [Default]
On
Logo
Default [Default]
Neutral
Background
Color
None [Default]
Blue
Red
Green
Gray
HDMI 1 EQ 1 ~ 7 [Default: 4]
HDMI 2 EQ 1 ~ 7 [Default: 4]
English
28
USING THE PROJECTOR
Main
Menu
Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values
Setup Reset
Reset OSD
Cancel [Default]
Yes
Reset to Default
Cancel [Default]
Yes
Info
Regulatory
Serial Number
Source
Resolution 00x00
Refresh Rate 0.00Hz
Display Mode
Power Mode
(Standby)
Light Source
Hours
Projector ID 00 ~ 99
Color Depth
Color Format
Filter Usage
Hours
Brightness
Mode
FW Version
System
MCU
English
29
USING THE PROJECTOR
Display menu
Image settings menu
Display Mode
There are many factory presets optimized for various types of images.
Cinema: Provides the best colors for watching movies.
HDR: Decodes and displays High Dynamic Range (HDR) content for the deepest blacks, brightest
whites, and vivid cinematic color using REC.2020 color gamut. This mode will be automatically
enabled if HDR is set to ON (and HDR Content is sent to projector – 4K UHD Blu-ray, 1080p/4K UHD
HDR Games, 4K UHD Streaming Video). While HDR mode is active, other display modes (Cinema,
Reference, etc.) cannot be selected as HDR delivers color that is highly accurate, exceeding the color
performance of the other display modes.
HDR SIM.: Enhances non-HDR content with simulated High Dynamic Range (HDR). Choose this
mode to enhance gamma, contrast, and color saturation for non-HDR content (720p and 1080p
Broadcast/Cable TV, 1080p Blu-ray, non-HDR Games, etc). This mode can ONLY be used with non-
HDR content.
Game: Select this mode to increase the brightness and response time level for enjoying video games.
Reference: This mode is intended to reproduce as close as possible the image the way the movie
director intended. Color, color temperature, brightness, contrast and gamma settings are all congured
to standard reference levels. Select this mode to watch a video.
Bright: Maximum brightness from PC input.
User: Memorize user’s settings.
3D: To experience the 3D effect, you need to have 3D glasses. Make sure your PC/portable device
has a 120 Hz signal output quad buffered graphics card and a 3D Player installed.
ISF Day: Optimize the image with the ISF Day mode to be perfectly calibrated and high picture quality.
ISF Night: Optimize the image with the ISF Night mode to be perfectly calibrated and high picture
quality.
ISF 3D: Optimize the image with the ISF 3D mode to be perfectly calibrated and high picture quality.
Note: For access and calibration of ISF daytime and night viewing modes, please contact your local dealer.
Wall Color
Use this function to obtain an optimized screen image according to the wall color. Select between off, blackboard,
light yellow, light green, light blue, pink, and gray.
Dynamic Range
Congure the High Dynamic Range (HDR) setting and its effect when displaying video from 4K Blu-ray players and
streaming devices.
Note: HDMI1 and VGA do not support Dynamic Range.
HDR
O: Turn off HDR Processing. When set to Off, the projector will NOT decode HDR content.
Auto: Auto detect HDR signal.
HDR Picture Mode
Bright: Choose this mode for brighter more saturated colors.
Standard: Choose this mode for natural looking colors with a balance of warm and cool tones.
Film: Choose this mode for improved detail and image sharpness.
Details: Choose this mode for improved detail and image sharpness in dark scenes.
English
30
USING THE PROJECTOR
HDR Demo Mode
This feature enables you to see the difference in the image quality between the raw unprocessed image
and the image processed as processed by the HDR.
Brightness
Adjust the brightness of the image.
Contrast
The contrast controls the degree of difference between the lightest and darkest parts of the picture.
Sharpness
Adjust the sharpness of the image.
Color
Adjust a video image from black and white to fully saturated color.
Tint
Adjust the color balance of red and green.
Gamma
Set up gamma curve type. After the initial setup and ne tuning is completed, utilize the Gamma Adjustment steps
to optimize your image output.
Film: For home theater.
Video: For video or TV source.
Graphics: For PC / Photo source.
Standard(2.2): For standardized setting.
1.8 / 2.0 / 2.4: For specic PC / Photo source.
Note: These options are only available if the 3D mode function is disabled. In 3D mode, user can only select 3D
for Gamma setting.
Color Settings
Congure the color settings.
BrilliantColor
TM
: This adjustable item utilizes a new color-processing algorithm and enhancements to
enable higher brightness while providing true, more vibrant colors in picture.
Color Temperature: Select a color temperature from D55, D65, D75, D83, D93, or Native.
Color Gamut: Select an appropriate color gamut from Native, HDTV, Presentation, Cinema, or Game.
CMS (Color Management System): Select one of the colors (R/G/B/C/M/Y) to adjust its x/y offset and
brightness.
± Color: Select between red (R), green (G), blue (B), cyan (C), yellow (Y), magenta (M), and white
(W) color.
± x offset: Adjust the x offset value of the selected color.
± y offset: Adjust the y offset value of the selected color.
± Brightness: Adjust the brightness value of the selected color.
± Reset: Return the factory default settings for color adjustments.
± Exit: Exit the “CMS” menu.
RGB Gain/Bias: This settings allows to congure the brightness (gain) and contrast (bias) of an
image.
± Reset: Return the factory default settings for RGB gain/bias.
± Exit: Exit the “RGB Gain/Bias” menu.
English
31
USING THE PROJECTOR
Color Space (non-HDMI input only): Select an appropriate color matrix type from the following:
AUTO, RGB, or YUV.
Color Space (HDMI input only): select an appropriate color matrix type from the following: Auto,
RGB(0-255), RGB(16-235), and YUV.
Signal
Adjust the signal options.
Automatic: Congure automatically the signal (the frequency and phase items are grayed out). If
automatic is disabled, the frequency and phase items will appear for tuning and saving the settings.
Frequency: Change the display data frequency to match the frequency of your computer’s graphic
card. Use this function only if the image appears to icker vertically.
Phase: Synchronize the signal timing of the display with the graphic card. If the image appears to be
unstable or ickers, use this function to correct it.
H. Position: Adjust the horizontal positioning of the image.
V. Position: Adjust the vertical positioning of the image.
Exit: Exit the “Signal” menu.
Note: This menu is only available if the input source is RGB/Component.
UltraDetail
Adjust the edges of the projected image in order to provide more perceived details.
Dynamic Black
Use to automatically adjust the picture brightness to give optimum contrast performance.
Brightness Mode
Adjust the brightness mode settings.
Bright: Choose “Bright” to increase the brightness.
Eco: Choose “Eco” to dim the projector lamp which will lower power consumption and extend the lamp
life.
Reset
Return the factory default settings for color settings.
3D menu
3D Mode
Use this option to enable/disable the 3D mode function.
3D Sync Invert
Use this option to enable/disable the 3D sync invert function.
English
32
USING THE PROJECTOR
Aspect ratio menu
Select the aspect ratio of the displayed image between the following options:
4:3: This format is for 4:3 input sources.
16:9: This format is for 16:9 input sources, like HDTV and DVD enhanced for Wide screen TV.
LBX: This format is for non-16x9, letterbox source and if you use external 16x9 lens to display 2.35:1
aspect ratio in full resolution.
Superwide: Use this special 2.0:1 aspect ratio to display both 16:9 and 2.35:1 aspect ratio movies
without black bars at the top and bottom of the screen.
Native: This format displays the original image without any scaling.
Auto: Automatically selects the appropriate display format.
Note:
It is considered normal that black bars appear around the image with a resolution of 4K in each aspect
mode.
The black bars and border will change in size depending on the aspect ratio.
Black bars
4K active area
4K 3840x2160 pixels
Note:
Detailed informations about LBX mode:
± Some Letter-Box Format DVDs are not enhanced for 16x9 TVs. In this situation, the image
will not look right when displaying image in 16:9 mode. In this situation, please try to use the
4:3 mode to view the DVD. If the content is not 4:3, there will be black bars around the image
in 16:9 display. For this type of content, you can use LBX mode to ll the image on the 16:9
display.
± If you use an external anamorphic lens, this LBX mode also allows you to watch a 2.35:1
content (include Anamorphic DVD and HDTV lm source) that supports anamorphic wide is
enhanced for 16x9 Display in a wide 2.35:1 image. In this case, there are no black bars. Lamp
power and vertical resolution are fully utilized.
To use the superwide format, do the following:
a) Set the screen aspect ratio to 2.0:1.
b) Select “Superwide” format.
c) Align the projector image correctly on the screen.
English
33
USING THE PROJECTOR
4K UHD scaling table:
16 : 9 screen 480i/p 576i/p 720p 1080i/p 2160p
4x3 Scale to 2880 x 2160.
16x9 Scale to 3840 x 2160.
LBX Get the central 3840 x 1620 image, and then scale to 3840 x 2160 for display.
Native mode 1:1 mapping centered.
No scaling will be made; the displayed resolution depends on input source.
Auto -If source is 4:3, the screen type will be scaled to 2880 x 2160.
-If source is 16:9, the screen type will be scaled to 3840 x 2160.
-If source is 15:9, the screen type will be scaled to 3600 x 2160.
-If source is 16:10, the screen type will be scaled to 3456 x 2160.
Auto mapping rule:
Input resolution Auto/Scale
H-resolution V-resolution 3840 2160
4:3
640 480 2880 2160
800 600 2880 2160
1024 768 2880 2160
1280 1024 2880 2160
1400 1050 2880 2160
1600 1200 2880 2160
Wide Laptop
1280 720 3840 2160
1280 768 3600 2160
1280 800 3456 2160
SDTV
720 576 2700 2160
720 480 3240 2160
HDTV
1280 720 3840 2160
1920 1080 3840 2160
Edge mask menu
Use this function to remove the video encoding noise on the edge of video source.
Digital zoom menu
Use to reduce or magnify an image on the projection screen.
Image shift menu
Adjust the projected image position horizontally (H) or vertically (V).
English
34
USING THE PROJECTOR
Audio menu
Internal Speaker
Use this option to turn on or off the internal speaker.
Auto: Choose “Auto” to automatically turn off the internal speaker when an external speaker is
connected to the projector.
O: Choose “Off” to turn off the internal speaker.
On: Choose “On” to turn on the internal speaker.
Mute
Use this option to temporarily turn off the sound.
O: Choose “Off” to turn mute off.
On: Choose “On” to turn mute on.
Note: “Mute” function affects both internal and external speaker volume.
Volume
Adjust the volume level.
Setup menu
Projection
Select the preferred projection between front, rear, ceiling-top, and rear-top.
Lamp settings menu
Lamp Reminder
Choose this function to show or to hide the warning message when the changing lamp message is displayed. The
message will appear 30 hours before suggested replacement of lamp.
Lamp Reset
Resets the lamp hour counter after replacing the lamp.
Filter settings menu
Filter Usage Hours
Display the lter time.
Optional Filter Installed
Set the warning message setting.
Yes: Display warning message after 500 hours of use.
Note: “Filter Usage Hours / Filter Reminder / Filter Reset” will only appear when “Optional Filter
Installed” is “Yes”.
No: Turn off warning message.
Filter Reminder
Choose this function to show or hide the warning message when the changing lter message is displayed. The
available options include 300hr, 500hr, 800hr, and 1000hr.
Filter Reset
Reset the dust lter counter after replacing or cleaning the dust lter.
English
35
USING THE PROJECTOR
Power settings menu
Direct Power On
Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied,
without pressing the “Power” key on the projector keypad or on the remote control.
Auto Power O (min.)
Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the
projector. The projector will automatically power off when the countdown has nished (in minutes).
Sleep Timer (min.)
Congure the sleep timer.
Sleep Timer (min.): Sets the countdown timer interval. The countdown timer will start, with or without
a signal being sent to the projector. The projector will automatically power off when the countdown has
nished (in minutes).
Note: The Sleep Timer is reset every time when the projector is powered off.
Always On: Check to set the sleep timer always on.
Power Mode (Standby)
Set the power mode setting.
Active: Choose “Active” to return to normal standby.
Eco: Choose “Eco.” to save power dissipation further < 0.5W.
Security menu
Security
Enable this function to prompt for a password before using the projector.
O: Choose “Off” to be able to switch on the projector without password verication.
On: Choose “On” to use security verication when the turning on the projector.
Security Timer
Can be select the time (Month/Day/Hour) function to set the number of hours the projector can be used. Once this
time has elapsed you will be requested to enter your password again.
Change Password
Use to set or modify the password that is prompted when turning the projector on.
Test pattern menu
Select the test pattern from green grid, magenta grid, white grid, white, or disable this function (off).
English
36
USING THE PROJECTOR
Remote settings menu
IR Function
Set the IR function setting.
On: Choose “On”, the projector can be operated by the remote control from top and front IR receivers.
Front: Choose “Front”, the projector can be operated by the remote control from the front IR receiver.
Back: Choose “Back”, the projector can be operated by the remote control from the rear IR receiver.
O: Choose “Off”, the projector can’t be operated by the remote control. By selecting “Off”, you will be
able to use the Keypad keys.
User1/ User2/ User3
Assign the default function for User1, User2, or User3 between Test Pattern, CMS, Color Temp, Gamma, Auto
Source, Projection, Lamp Settings, Digital Zoom, MHL, Dynamic Range, or Dynamic Black.
Projector ID menu
ID denition can be set up by menu (range 0-99), and allow user control an individual projector by using RS232 command.
12V trigger menu
Use this function to enable or disable the trigger.
Reserved
IR_IN & detect
GND
On: Choose “On” to enable the trigger.
O: Choose “Off” to disable the trigger.
Options menu
Language
Select the multilingual OSD menu between English, German, French, Italian, Spanish, Portuguese,
Simplied Chinese, Japanese, Korean, and Russian.
Menu Settings
Set the menu location on the screen and congure menu timer settings.
Menu Location: Select the menu location on the display screen.
Menu Timer: Set the duration where the OSD menu stays visible on the screen.
Auto Source
Choose this option to let the projector automatically nd an available input source.
Input Source
Select the input source between HDMI1, HDMI2/MHL, and VGA.
High Altitude
When “On” is selected, the fans will spin faster. This feature is useful in high altitude areas where the air is thin.
Display Mode Lock
Choose “On” or “Off” to lock or unlock adjusting display mode settings.
Keypad Lock
English
37
USING THE PROJECTOR
When the keypad lock function is “On”, the Keypad will be locked. However, the projector can be operated by the
remote control. By selecting “Off”, you will be able to reuse the Keypad.
Information Hide
Enable this function to hide the information message.
O: Choose “Off” to show the “searching” message.
On: Choose “On” to hide the info message.
Logo
Use this function to set the desired startup screen. If changes are made, they will take effect the next time the
projector is powered on.
Default: The default startup screen.
Neutral: Logo is not displayed on startup screen.
Background Color
Use this function to display a blue, red, green, gray color, or none when no signal is available.
HDMI 1 EQ
Set the HDMI port EQ value for HDMI1.
HDMI 2 EQ
Set the HDMI port EQ value for HDMI2/MHL.
Note:
HDMI EQ analyses the signal data and eliminates distortion due to signal loss when using long HDMI
cables. The HDMI receiver also includes a timing adjustment circuit that removes timing jitter, restoring
the HDMI signal to optimal transmission levels.
3840x2160@60Hz suggests using the HDMI cable under 5 meters.
3840x2160@30Hz/25Hz/24Hz suggests using the HDMI cable under 15 meters.
Reset menu
Reset OSD
Return the factory default settings for OSD menu settings.
Reset to Default
Return the factory default settings for all settings.
English
38
USING THE PROJECTOR
Info menu
View the projector information as listed below:
Regulatory
Serial Number
Source
Resolution
Refresh Rate
Display Mode
Power Mode (Standby)
Light Source Hours
Projector ID
Color Depth
Color Format
Filter Usage Hours
Brightness Mode
FW Version
English
39
MAINTENANCE
Replacing the lamp
The projector automatically detects the lamp life. When the lamp life is nearing the end of use, a warning message
will appear on the screen.
When you see this message, please contact your local reseller or service center to change the lamp as soon as
possible. Make sure the projector has been cooled down for at least 30 minutes before changing the lamp.
Warning: If ceiling mounted, please use caution when opening the lamp access panel. It is
recommended to wear safety glasses if changing the bulb when ceiling mounted. Caution must be used
to prevent any loose parts from falling out of projector.
Warning: Lamp compartment is hot! Allow it to cool down before changing lamp!
Warning: To reduce the risk of personal injury, do not drop the lamp module or touch the lamp bulb. The
bulb may shatter and cause injury if it is dropped.
English
40
MAINTENANCE
Replacing the lamp (continued)
3
2
1
1
6
4
5
Procedure:
1. Switch off the power to the projector by pressing the “ ” button on the projector keypad or the “ ”
button on the remote control.
2. Allow the projector to cool down for at least 30 minutes.
3. Disconnect the power cord.
4. Remove the 2 screws securing the top cover. 1
5. Remove the top cover. 2
6. Remove the screw on the lamp module. 3
7. Lift up the lamp handle. 4
8. Remove the lamp cord. 5
9. Remove the lamp module carefully. 6
10. To replace the lamp module, reverse the previous steps.
11. Turn on the projector and reset the lamp timer.
12. Lamp Reset: (i) Press "Menu" (ii) Select "Setup" (iii) Select "Lamp Settings"
(iv) Select "Lamp
Reset"
(v) Select "Yes".
Note:
The projector cannot be turned on if the lamp cover has not been placed back on the projector.
Do not touch the glass area of the lamp. Hand oil can cause the lamp shatter. Use a dry cloth to clean
the lamp module if it was accidentally touched.
English
41
MAINTENANCE
Installing and cleaning the dust lter
Installing the dust lter
Note: Dust lters are only required/supplied in the selected regions with excessive dust.
Cleaning the dust lter
We recommend you to clean the dust lter every three months. Clean it more often if the projector is used in a
dusty environment.
Procedure:
1. Switch off the power to the projector by pressing the “ ” button on the projector keypad or the “ ”
button on the remote control.
2. Disconnect the power cord.
3. Pull the dust lter compartment downwards to remove it out from the bottom of the projector. 1
4. Carefully remove the air lter. Then clean or replace the dust lter. 2
5. To install the dust lter, reverse the previous steps.
1
2
English
42
ADDITIONAL INFORMATION
Compatible resolutions
Digital (HDMI 1.4)
Native resolution: 1920 x 1080 @ 60Hz
Established Timing Standard Timing Descriptor Timing Supported Video Mode Detail Timing
720 x 400 @ 70Hz 1280 x 720 @ 60Hz 1920 x 1080 @ 60Hz
(default)
720 x 480i @ 60Hz 16:9 1920 x 1080p @ 60Hz
640 x 480 @ 60Hz 1280 x 800 @ 60Hz 720 x 480p @ 60Hz 4:3
640 x 480 @ 67Hz 1280 x 1024 @ 60Hz 720 x 480p @ 60Hz 16:9
640 x 480 @ 72Hz 1920 x 1200 @ 60Hz
(reduced)
720 x 576i @ 50Hz 16:9
640 x 480 @ 75Hz 1366 x 768 @ 60Hz 720 x 576p @ 50Hz 4:3
800 x 600 @ 56Hz 720 x 576p @ 50Hz 16:9
800 x 600 @ 60Hz 1280 x 720p @ 60Hz 16:9
800 x 600 @ 72Hz 1280 x 720p @ 50Hz 16:9
800 x 600 @ 75Hz 1920 x 1080i @ 60Hz 16:9
832 x 624 @ 75Hz 1920 x 1080i @ 50Hz 16:9
1024 x 768 @ 60Hz 1920 x 1080p @ 60Hz 16:9
1024 x 768 @ 70Hz 1920 x 1080p @ 50Hz 16:9
1024 x 768 @ 75Hz 1920 x 1080p @ 24Hz 16:9
1280 x 1024 @ 75Hz 3840 x 2160 @ 24Hz
1152 x 870 @ 75Hz 3840 x 2160 @ 25Hz
3840 x 2160 @ 30Hz
4096 x 2160 @ 24Hz
Digital (HDMI 2.0)
Native resolution: 1920 x 1080 @ 60Hz
B0 / Established Timing B0 / Standard Timing B1 / Video Mode B1 / Detail Timing
720 x 400 @ 70Hz 1280 x 720 @ 60Hz 720 x 480i @ 60Hz 16:9 1920 x 1080p @ 60Hz
640 x 480 @ 60Hz 1280 x 800 @ 60Hz 720 x 480p @ 60Hz 4:3
640 x 480 @ 67Hz 1280 x 1024 @ 60Hz 720 x 480p @ 60Hz 16:9
640 x 480 @ 72Hz 1920 x 1200 @ 60Hz (reduced) 720 x 576i @ 50Hz 16:9
640 x 480 @ 75Hz 1366 x 768 @ 60Hz 720 x 576p @ 50Hz 4:3
800 x 600 @ 56Hz 720 x 576p @ 50Hz 16:9
800 x 600 @ 60Hz 1280 x 720p @ 60Hz 16:9
800 x 600 @ 72Hz 1280 x 720p @ 50Hz 16:9
800 x 600 @ 75Hz 1920 x 1080i @ 60Hz 16:9
832 x 624 @ 75Hz 1920 x 1080i @ 50Hz 16:9
1024 x 768 @ 60Hz 1920 x 1080p @ 60Hz 16:9
1024 x 768 @ 70Hz 1920 x 1080p @ 50Hz 16:9
1024 x 768 @ 75Hz 1920 x 1080p @ 24Hz 16:9
1280 x 1024 @ 75Hz 3840 x 2160 @ 24Hz
1152 x 870@ 75Hz 3840 x 2160 @ 25Hz
3840 x 2160 @ 30Hz
3840 x 2160 @ 50Hz
3840 x 2160 @ 60Hz
4096 x 2160 @ 24Hz
4096 x 2160 @ 25Hz
English
43
ADDITIONAL INFORMATION
B0 / Established Timing B0 / Standard Timing B1 / Video Mode B1 / Detail Timing
4096 x 2160 @ 30Hz
4096 x 2160 @ 50Hz
4096 x 2160 @ 60Hz
Note: Support 1920 x 1080 @ 50Hz.
Analog
Native resolution: 1920 x 1080 @ 60Hz
B0 / Established Timing B0 / Standard Timing B0 / Detail Timing B1 / Detail Timing
720 x 400 @ 70Hz 1280 x 720 @ 60Hz 1920 x 1080 @ 60Hz (default) 1366 x 768 @ 60Hz
640 x 480 @ 60Hz 1280 x 800 @ 60Hz
640 x 480 @ 67Hz 1280 x 1024 @ 60Hz
640 x 480 @ 72Hz 1400 x 1050 @ 60Hz
640 x 480 @ 75Hz 1600 x 1200 @ 60Hz
800 x 600 @ 56Hz
800 x 600 @ 60Hz
800 x 600 @ 72Hz
800 x 600 @ 75Hz
832 x 624 @ 75Hz
1024 x 768 @ 60Hz
1024 x 768 @ 70Hz
1024 x 768 @ 75Hz
1280 x 1024 @ 75Hz
1152 x 870 @ 75Hz
Note: Support 1920 x 1080 @ 50Hz.
English
44
ADDITIONAL INFORMATION
Image size and projection distance
Diagonal length (inch) size
of 16:9 Screen
Screen Size W x H Projection Distance (D)
Oset (HD)
(m) (inch) (m) (feet)
Width Height Width Height Wide Tele Wide Tele (m) (feet)
30 0.66 0.37 25.97 14.61 - 1.05 - 3.44 0.02 0.07
40 0.89 0.50 34.86 19.61 1.07 1.41 3.51 4.62 0.03 0.09
60 1.33 0.75 52.29 29.42 1.61 2.11 5.27 6.93 0.04 0.13
70 1.55 0.87 61.01 34.32 1.88 2.46 6.15 8.08 0.05 0.16
80 1.77 1.00 69.73 39.22 2.14 2.82 7.03 9.23 0.05 0.18
90 1.99 1.12 78.44 44.12 2.41 3.17 7.91 10.39 0.06 0.20
100 2.21 1.25 87.16 49.03 2.68 3.52 8.78 11.54 0.07 0.22
120 2.66 1.49 104.59 58.83 3.21 4.22 10.54 13.85 0.08 0.27
150 3.32 1.87 130.74 73.54 4.02 5.28 13.18 17.31 0.10 0.34
180 3.98 2.24 156.88 88.25 4.82 6.34 15.81 20.78 0.12 0.40
200 4.43 2.49 174.32 98.05 5.36 7.04 17.57 23.08 0.14 0.45
250 5.53 3.11 217.89 122.57 6.70 8.80 21.96 28.85 0.17 0.56
300.6 6.65 3.74 262.00 147.37 8.05 - 26.40 - 0.21 0.68
Width
Height
Diagonal
Top View
Side View
Projection Distance (D)
Projection Distance (D)
Screen
Screen
Screen (W)
Screen (H)
Offset (Hd)
English
45
ADDITIONAL INFORMATION
Projector dimensions and ceiling mount installation
1. To prevent damage to your projector, please use the Optoma ceiling mount.
2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to
the projector meet the following speci cations:
Screw type: M4*3
Minimum screw length: 10mm
Lens
Note: Please note that damage resulting from incorrect installation will void the warranty.
Warning:
If you buy a ceiling mount from another company, please be sure to use the correct screw size.
Screw size will vary depending on the thickness of the mounting plate.
Be sure to keep at least 10 cm gap between the ceiling and the bottom of the projector.
Avoid installing the projector near a heat source.
English
46
ADDITIONAL INFORMATION
IR remote codes
ON
OFF
Menu
VGA1
HDMI1
User2
Contrast
Aspect ratio
DB
Volume
Source
Re-sync
User1
Brightness
Keystone
Mute
User3
Mode
3D
Sleep Timer
Volume
HDMI2
VGA2 Video YPbPr
Key
NEC
format
Customer code Key code
Description
Byte 1 Byte 2 Byte 3 Byte 4
Power on Format 1 32 CD 02 FD Press to turn on the projector.
Power off Format 1 32 CD 2E D1 Press to turn off the projector.
User1 Format 1 32 CD 36 C9
User dened keys.User2 Format 1 32 CD 65 9a
User3 Format 1 32 CD 66 99
Brightness Format 1 32 CD 41 BE Adjust the brightness of the image.
Contrast Format 1 32 CD 42 BD
Control the degree of difference between
the lightest and darkest parts of the
picture.
Display
mode
Format 1 32 CD 05 FA
Select a display mode for optimized
settings for different applications.
Keystone Format 1 32 CD 07 F8
Press to adjust image distortion caused
by tilting the projector.
Aspect
ratio
Format 1 32 CD 64 9B
Press to change aspect ratio of a
displayed image.
3D Format 1 32 CD 89 76
Press to enable/disable the 3D mode
function.
English
47
ADDITIONAL INFORMATION
Key
NEC
format
Customer code Key code
Description
Byte 1 Byte 2 Byte 3 Byte 4
Mute Format 1 32 CD 52 aD Momentarily turns off / on the audio.
DB
(Dynamic
Black)
Format 1 32 CD 44 BB
Automatically adjusts the picture
brightness to give optimum contrast
performance.
Sleep timer Format 1 32 CD 63 9C Sets the countdown timer interval.
Volume + Format 2 32 CD 11 EE Adjust to increase volume.
▲ Format 2 32 CD 11 EE
Use ▲, ◄, ►, or ▼ to select items or
make adjustments to your selection.
◄ Format 2 32 CD 10 EF
► Format 2 32 CD 12 ED
▼ Format 2 32 CD 14 EB
Source Format 2 32 CD 10 EF Press “Source” to select an input signal.
Enter key Format 1 32 CD 0F F0 Conrm your item selection.
Re-sync Format 2 32 CD 12 ED
Automatically synchronizes the projector
to the input source.
Volume - Format 2 32 CD 14 EB Adjust to decrease volume.
Menu Format 1 32 CD 0E F1
Display or exit the on-screen display
menus for projector.
HDMI1 Format 1 32 CD 16 E9
Press “HDMI1” to choose source from
HDMI 1 connector.
HDMI2 Format 1 32 CD 30 CF
Press “HDMI2” to choose source from
HDMI 2 connector.
VGA1 Format 1 32 CD 1B E4
Press “VGA1” to choose source from
VGA connector.
VGA2 Format 1 32 CD 1E E1 No function
Video Format 1 32 CD 1C E3 No function
YPbPr Format 1 32 CD 17 E8 No function
English
48
ADDITIONAL INFORMATION
Troubleshooting
If you experience a problem with your projector, please refer to the following information. If a problem persists,
please contact your local reseller or service center.
Image problems
No image appears on-screen
Ensure all the cables and power connections are correctly and securely connected as described in the
"Installation" section.
Ensure the pins of connectors are not crooked or broken.
Check if the projection lamp has been securely installed. Please refer to the "Replacing the Lamp"
section on pages 39-40.
Ensure that the "Mute" feature is not turned on.
Image is out of focus
Adjust the Focus Ring on the projector lens. Please see page 16.
Make sure the projection screen is between the required distance from the projector. (Please refer to
page 44).
The image is stretched when displaying 16:9 DVD title
When you play anamorphic DVD or 16:9 DVD, the projector will show the best image in 16: 9 format
on projector side.
If you play the LBX format DVD title, please change the format as LBX in projector OSD.
If you play 4:3 format DVD title, please change the format as 4:3 in projector OSD.
Please setup the display format as 16:9 (wide) aspect ratio type on your DVD player.
Image is too small or too large
Adjust the zoom lever on the top of the projector.
Move the projector closer to or further from the screen.
Press "Menu" on the projector panel, go to "Display-->Aspect Ratio". Try the different settings.
Image has slanted sides:
If possible, reposition the projector so that it is centered on the screen and below the bottom of the
screen.
Image is reversed
Select "Setup-->Projection" from the OSD and adjust the projection direction.
Blurry double image
Make sure “Display Mode” is not 3D to avoid normal 2D image appear blurry double image.
English
49
ADDITIONAL INFORMATION
Other problems
The projector stops responding to all controls
If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before
reconnecting power.
Lamp burns out or makes a popping sound
When the lamp reaches its end of life, it will burn out and may make a loud popping sound. If this
happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp,
follow the procedures in the "Replacing the Lamp" section on pages 39-40.
Remote control problems
If the remote control does not work
Check the operating angle of the remote control is pointed within ±15° (horizontally) or ±10° (vertically)
to the IR receiver on the projector.
Make sure there are not any obstructions between the remote control and the projector. Move to within
7 m (~22 ft) of the projector.
Make sure batteries are inserted correctly.
Replace batteries if they are exhausted.
English
50
ADDITIONAL INFORMATION
Warning indicators
When the warning indicators (see below) light up or ash, the projector will automatically shutdown:
"LAMP" LED indicator is lit red and if "On/Standby" indicator ashes red.
"TEMP" LED indicator is lit red and if "On/Standby" indicator ashes red. This indicates the projector
has overheated. Under normal conditions, the project can be switched back on.
"TEMP" LED indicator ashes red and if "On/Standby" indicator ashes red.
Unplug the power cord from the projector, wait for 30 seconds and try again. If the warning indicator light up or
ash, please contact your nearest service center for assistance.
LED lightning messages
Message
On/Standby LED Temp LED Lamp LED
(Red) (Blue) (Red) (Red)
Standby state
(Input power cord)
Steady light
Power on (Warming)
Flashing
(0.5 sec off / 0.5 sec
on)
Power on and Lamp lighting Steady light
Power off (Cooling)
Flashing
(0.5 sec off / 0.5
sec on). Back to red
steady light when
cooling fan turns off.
Error (Lamp failure) Flashing Steady light
Error (Fan failure) Flashing Flashing
Error (Over temp.) Flashing Steady light
Standby State
(Burn in mode)
Flashing
Burn in (Warming) Flashing
Burn in (Cooling) Flashing
Burn in (Lamp lighting)
Flashing
(3 sec on / 1 sec off)
Burn in (Lamp off)
Flashing
(1 sec on / 3 sec off)
English
51
ADDITIONAL INFORMATION
Power off:
Power Off
Power Off?
Press power key again.
Temperature warning:
Warning
TEMPERATURE TOO HIGH
Please:
1. Make sure air in and outlets are not blocked.
2. Make sure the environment temperature is under 45 degree C.
If the problem persists in spite of the above.
Please contact a service center for repair.
Lamp warning:
Warning
Lamp Warning
Lamp life exceeded.
Fan failed:
Warning
FAN LOCKED
The projector will switch off automatically
Please contact a service center for repair.
Out of display range:
HDMI
Out Of Range
Power down warning:
Power Down
Power Down Timer Active
Power down in sec.
English
52
ADDITIONAL INFORMATION
Specications
Optical Description
Maximum resolution
- Graphic up to 2160p@60Hz
- Maximum Resolution: HDMI1 (2.0): 2160p@60Hz
HDMI2 (1.4): 2160p@60Hz
Native resolution (w/o actuator) 1920x1080
Lens Manual zoom and manual focus
Image size (diagonal) 34.1”~302.4”, optimized@wide 82”(2.2m)
Projection distance 1.2~8.1m, [email protected]
Electrical Description
Inputs
- HDMI V1.4
- HDMI V2.0 (MHL)
- VGA IN
- Audio In 3.5mm
- USB-A x2 (1 for Service, 1 for 5V PWR 1.5A)
- RS232C male (9-pin D-SUB)
Outputs
- Audio Out 3.5mm
- SPDIF Out
- 12V Trigger (3.5mm jack)
Color reproduction 1073.4 Million color
Scan rate
Horizontal scan rate: 15.375 ~ 91.146 KHz
Vertical scan rate: 24 ~ 85 Hz (120Hz for 3D feature projector)
Built-in speaker Built-in speakers (x2)
Power requirement 100 - 240V ±10%, AC 50/60Hz
Input current 3.8A
Mechanical Description
Installation orientation Front, Rear, Ceiling - Front, Rear - top
Dimensions
(W x D x H)
- 392.6 x 281.6 x 118.4 mm (without feet)
- 392.6 x 281.6 x 129 mm (with feet)
Weight 6.5 ±0.5 kg
Environmental conditions Operating in 5 ~ 40°C , 10% to 85% humidity (non-condensing)
Note: All specications are subject to change without notice.
English
53
ADDITIONAL INFORMATION
Optoma global oces
For service or support, please contact your local ofce.
USA
3178 Laurelview Ct. 888-289-6786
Fremont, CA 94538, USA 510-897-8601
Canada
3178 Laurelview Ct. 888-289-6786
Fremont, CA 94538, USA 510-897-8601
Latin America
3178 Laurelview Ct. 888-289-6786
Fremont, CA 94538, USA 510-897-8601
Europe
Unit 1, Network 41, Bourne End Mills,
Hemel Hempstead, Herts,
HP1 2UJ, United Kingdom +44 (0) 1923 691 800
www.optoma.eu +44 (0) 1923 691 888
Benelux BV
Randstad 22-123 +31 (0) 36 820 0252
1316 BW Almere +31 (0) 36 548 9052
The Netherlands
www.optoma.nl
France
Bâtiment E +33 1 41 46 12 20
81-83 avenue Edouard Vaillant +33 1 41 46 94 35
Spain
C/ José Hierro,36 Of. 1C +34 91 499 06 06
28522 Rivas VaciaMadrid, +34 91 670 08 32
Spain
Deutschland
Wiesenstrasse 21 W +49 (0) 211 506 6670
D40549 Düsseldorf, +49 (0) 211 506 66799
Scandinavia
Lerpeveien 25 +47 32 98 89 90
3040 Drammen +47 32 98 89 99
PO.BOX 9515
3038 Drammen
Norway
Korea
WOOMI TECH.CO.,LTD. +82+2+34430004
4F, Minu Bldg.33-14, Kangnam-Ku, +82+2+34430005
Seoul,135-815, KOREA
korea.optoma.com
Japan
東京都足立区綾瀬3-25-18
株式会社オーエス [email protected]
コンタクトセンター:0120-380-495 www.os-worldwide.com
Taiwan
12F., No.213, Sec. 3, Beixin Rd., +886-2-8911-8600
Xindian Dist., New Taipei City 231, +886-2-8911-6550
Taiwan, R.O.C. [email protected]
www.optoma.com.tw asia.optoma.com
Hong Kong
Unit A, 27/F Dragon Centre,
79 Wing Hong Street, +852-2396-8968
Cheung Sha Wan, +852-2370-1222
Kowloon, Hong Kong www.optoma.com.hk
China
5F, No. 1205, Kaixuan Rd., +86-21-62947376
Changning District +86-21-62947375
Shanghai, 200052, China www.optoma.com.cn
www.optoma.com
*36.7CM01G001-A*
P/N:36.7CM01G001-A
