WEEE Number: 80133970
INSTALLATION INSTRUCTION
T5 INTERGRATED FITTING
VT-035, VT-065, VT-125
Model Wa�s Lumens CRI
Beam
Angle
Body
Type
Long Life
On/Off
Cycles
Dimension Input Power
VT-035 4W 360 >80 120 PC 30,000 Hours >15000 320x22.8x30mm AC:220-240V,50Hz
VT-065 7W 630 >80 120 PC 30,000 Hours >15000 580x22.8x30mm AC:220-240V,50Hz
VT-125 16W 1440 >80 120 PC 30,000 Hours >15000 1180x22.8x30mm AC:220-240V,50Hz
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of
electric shock.
WARNING!
TECHNICAL DATA
1. Please make sure to turn off the power before starting the installation.
2. The light source of this luminaire is not replaceable, when the light
source reaches its end of life the whole luminaire should be replaced.
3. If the external flexible cable or cord of this luminaire is damaged, it
shall be exclusively replaced by the manufacturer or his service agent or
a similar qualified person in order to avoid a hazard
4. Install only by certified Electrician.
UP T O 1 0 0 WATTS T O GETHER
L I NKABLE
5
YEARS
WARRANTY
