HR6BF170R
HR6BF170B
HR6BF170G
9
Hisense Refrigerator
Hisense Refrigerator
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to.Refer to relrelevant instructions
for storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container,which
may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could cause
skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Hisense Refrigerator
Hisense Refrigerator
8
energy concumption. Otherwise, it would
result the conservation of energy.
position stops the cooling cycle,but does not
shut off the power of the refrigerator.
Turning the temperature control to the “off”
Description of the appliance
1. Freezer chamber
2. Ice tray(in Freezer chamber )
3.
Controller box
4. Lamp cover
5. LED light(in the lamp cover)
6. Control knob
7. Storage shelves
8. Wine rack
9. Crisper cover
10. Crisper
11. Door
12. Door racks
13. Adjustable feet
View of the appliance
Control panel
Starting up and temperature regulation
Insert the plug of the connection lead into
the plug socket with a protective grounding
contact. When the refrigerator compartment
door is opened, the internal lighting is
switched on.
The temperature selector knob is located on
the back side of the refrigerator
compartment.
Setting “off” means no cooling
Setting “1” means
Highest temperature, warmest setting.
Setting “7” (end-stop) means
Lowest temperature, coldest setting.
Important! High ambient temperatures (e.g.
on hot summer days) and a cold setting
(position 6 to 7) may cause the compressor
to run continuously or even non-stop!
Reason: When the ambient temperature is
high, the compressor must run continuously
to maintain the low temperature in the
appliance.
Warning!
Don’t try to repair the appliance
and change the LED light
yourself.
If the LED light can’t work, please contact
your specialist dealer or your local
Customer Service Center to change it.
Important! Normally, we advise you select a
setting of 2, 3 or 4; if you want the
temperature higher or lower, please turn the
knob to a warmer or colder setting
accordingly. When you turn the knob to a
colder setting, this can lead to the more
1
2
3
4
5
6
7
8
9
10
11
12
13
9
lo wer base cover
cross
scre w drawe r
The appliance should be level in order to
eliminate vibration. To make the appliance
level, it should be upright and both
adjusters should be in stable contact with
the floor. You can also adjust the level by
unscrewing the appropriate level
adjustment in the front (use your fingers or
a suitable spanner).
Levelling
with the exception of special cases.
Food once thawed should be re-frozen
wine rack are included with your appliance,
Crisper
For storing fruit and vegetables.
Ice tray
It is used for making ice.
There are some notes during the ice
making:
1. If the ice tray is used for the first time
or has not been used for a long time,
please clean it before using.
2. When you pour water into the ice
tray, the water level shall not exceed
the top line.
Refrigerator compartment 2)
For storing the food that does not need to
be frozen and different sections suitable
for different kinds of food.
Freezer food compartment 2)
For freezing fresh food and storing frozen
and deep-frozen food for a long time.
Thawing food 2)
In the refrigerator compartment.
At room temperature.
In a microwave oven.
In a conventional or convection oven.
1) If the appliance contains related accessories
and functions.
2) If the appliance contains a freezer compartment.
Daily use
Accessories
Various glass, plastic storage shelves or
different models have different
combinations and different models have
different features.
Movable shelves/trays
3. The ice tray should be carefully placed
in the huge freezer without the water spilt
otherwise the spilt water will be frozen and
cause the ice tray stuck.
4. To take out the ice cubes, you should
gently twist the ice tray and bend it
over.
.
Freezer Door
2)
Note:Press the door to make sure it is
closed tight.
11
Caution! Any electrical work required to
install this appliance should be carried out by
qualified or authorized personnel.
Warning! This appliance must be grounded.
The manufacturer declines any liability should
these safety measures not be observed.
Electrical connection
out from the freezer compartment may
make the skin frostbite.
The frozen food that has just been taken
putting the food in the compartment.
least 2 hours on the colder settings,before
long time.Keep the appliance running at
When first staring-up or out of use for a
Milk bottles: theses should be covered
shelf only one or two days at most.
freely around.
Position food where air can circulate
special drawer.
Fruits and vegetables: these should be
according to the installation tips.
Keep the appliance away from the wall
Reduce the times of opening the door.
Helpful hints and tips
Noises during operation
Clicks - Whenever the compressor
switches on of off, a click can be heard.
Humming - As soon as the compressor is
in operation, you can hear it humming.
Bubbling - When refrigerant flows into thin
tubes, you can hear bubbling or splashing
noises.
Splashing - Even after the compressor has
been switched off, this noise can be heard
for a short time.
Energy saving tips
Do not install the appliance near stoves,
radiators or other sources of warmth.
Do not set the temperature colder than
necessary.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination
as it would produce an effect on energy
consumption.
Hints for freezing
Prepare food in small portions to enable
it to rapidly and completely frozen and to
make it possible to subsequently thaw
only the quantity required.
‘Wrap up the food in aluminum foil or
polyethylene (plastic) and make sure that
the packages are airtight.
Do not allow fresh, unfrozen food to
touch food that is already frozen, thus
avoiding a rise in the temperature of
latter.
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
Hints for the storage of frozen food
Make sure that commercially frozen food
was stored by the retailer.
Once defrosted, foods deteriorate rapidly
and can not be re-frozen.
Do not exceed the storage period
indicated by the food manufacturer.
Note: If the appliance contains related
accessories and functions.
Hints for fresh food refrigeration
Do not store warm foods or evaporating
liquids in the appliance.
Do cover or wrap the food, particularly if
it has strong flavor or odor.
Hints for refrigeration
Meat (all types): wrap in polyethylene
(plastic) bags and place on the glass
Cooked foods, cold dishes, etc...: these
should be covered and may be placed on
any shelf.
thoroughly cleaned and placed in the
Butter and cheese: these should be
placed in aluminum foil or polyethylene
(plastic) bags while removing as much
air as possible.
and should be stored in the bottle rack
on the door.
12
Defrosting in the frozen food
storage compartment
Defrosting in the freezer chamber is
operated manually. Before defrosting,
take the foot out.
Tale the ice tray and drawers out or put
them into the fresh food compartment
temporarily.
In order to speed up the process of
defrosting, you may put a bowl of warm
water (about 50℃) into the freezer
chamber and scrape away the ice and
frost with a defrosting spatula. After
doing so, be sure to set the knob of the
controller box to the original position.
It is not advisable to heat the freezer
chamber directly with hot water or hair
dryer while defrosting to avoid
deformation of the inner case.
It is also not advisable to scrape off ice
and frost or separate foods from the
containers which have been congealed
together with the food with sharp tools or
wooden bars, so as not to damage the
inner casing or the surface of the
evaporator.
Notice! The appliance should be defrosted
at least once a month. During its usage, if
the door has been used in extreme
humidity, we advise the user to defrost
every two weeks.
Taking the appliance out of service
Empty the appliance
Pull out the power plug
Clean thoroughly (see section: Cleaning
and Care).
Leave the door open to prevent odours
Cleaning and care
Cleaning and care
For hygienic reasons, the appliance interior,
including interior accessories, should be
cleaned regularly.
The appliance should be cleaned and
maintained at least every two months.
Warning! Danger of electrical shock!
The appliance should not be connected
to the main power supply during
cleaning. Before cleaning, switch the
appliance off and remove the plug from
the main power supply, switch off, or
shut off the circuit breaker of fuse.
Notice!
Remove the food from the appliance
before cleaning. Store them in a cool
place and keep well covered.
Never clean the appliance with a steam
cleaner. Moisture could accumulate in
electrical components.
Hot vapors can lead to the damage of
plastic parts.
Ethereal oils and organic solvents can
attack plastic parts, e.g. lemon juice or
the juice from an orange peel, butyric
acid, or cleansers that contain acetic acid.
Do not use any abrasive cleansers.
Clean the appliance and the interior
accessories with a cloth and lukewarm
water. Commercially available dish
washing detergents may also be used.
After cleaning, wipe with fresh water and
a clean dish cloth.
Accumulation of dust at the condenser
increases energy consumption; clean the
condenser at the back of the appliance
once a year with a soft brush or a vacuum
cleaner.(Only for the outside-condenser
product)
Check the water drain hole on the rear
wall of the refrigerator compartment.
Clear a blocked drain hole with the aid of
something like soft green peg, an be
careful not to create any damage to the
cabinet by sharp objects.
After everything is dry, the appliance back
into service.
Defrosting
Defrosting in the fresh food
storage compartment
Water from the defrosting option will
automatically be drained into a drip tray
through a drain pipe at the back of the
appliance.
13
Problem Possible cause Solution
Appliance dose not
work.
Appliance is not switched on.
Main plug is not plugged in or is
loose.
Fuse has blown or is defective.
Outlet is defective.
Switch on the appliance.
Plug the appliance into the
electrical socket.
Check fuse, replace if necessary.
Defective parts need to be
repaired by an electrician.
Appliance cools too
much.
Temperature is set too cold.
The food is too warm.
Temperature is not properly
adjusted.
Door was open for an extented
period.
A large quantity of warm food
was placed in the appliance
within the last 24 hours.
The appliance is near a heat
source.
Turn the controller box to a
warmer setting temporarily.
Please refer to the “Initial Start
Up” section.
Open the door only as long as
necessary.
Turn the controller box to a
colder setting temporarily.
Please look in the “Control panel”
section.
Please refer to the “Installation
Location” section.
Interior lighting dose
not work.
LED light is defective.
Heavy build-up of
frost, possibly also on
the door seal.
Door seal is not air-tight
(possibly after reversing the
door) .
Carefully warm the leaking
sections of the door seal with a
hair dryer (on a cool setting). At
the same time, shape the
warmed door seal by hand so
that it sits correctly.
Unusual noises.
Appliance is not level.
The appliance is touching the
wall or other objects.
A component, e.g. a pipe, on
the rear of the appliance is
touching another part of the
appliance or the wall.
Readjust the feet.
Move the appliance slightly.
If necessary, carefully bend the
component out of the way.
The compressor dose
not start immediately
after changing the
temperature setting.
This is normal, no error has
occurred.
The compressor starts after a
period of time.
Refer the “Cleaning and Care”
section.
Water on the floor or
storage shelves.
Water drain hole is blocked.
What to do if...
Warning! Before troubleshooting,
disconnect the power supply. Only a
qualified electrician or other
personnel must carry out the
troubleshooting that is not in the manual.
performed by competent service engineers.
Improper repairs can give rise to significant
hazards for the user. If your appliance
needs repairing, please contact your
specialist dealer or your local Customer
Service Center.
Important!
Repairs to the appliance may only be
14
Disposal of the appliance
It is prohibited to dispose of this appliance in domestic household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the packaging in a
suitable waste collection container to recycle it.
Before disposal of the appliance.
1. disconnect the main plug from the main socket.
2. Cut off the main cable and discard it.
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this
product for environmental safe recycling.
Correct Disposal of this product
15
