Pairing with a computer running Windows
Note: Before you pair the headphones with the computer, make sure that the
computer is equipped with Bluetooth. Refer to the computer’s documentation or
contact the computer manufacturer for more information. If your computer is not
Bluetooth compatible, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see the
computer’s documentation or contact the computer manufacturer.
2 Double-click the Bluetooth icon in the system tray, then click Add a
device (Add Wireless Device using Windows Vista).
3 With the headphones turned o, press and hold for four seconds.
The LED blinks blue and red alternately. Pairing mode is activated.
4 Double-click the INSIGNIA NS-CAHBT02 icon on the computer or
highlight the icon, then click Next.
Note: If you are unable to locate the INSIGNIA NS-CAHBT02 icon, click the
Search Again button.
5 If required, enter 0000 (four zeros) in the Bluetooth security code
eld, then click Next.
6 After the headphones have been paired, click Close. If you are using
Windows XP, continue with steps 7 through 9.
7 Select one of the Bluetooth hands-free types shown on the Add a
Bluetooth Device Wizard screen, then click Next.
8 Select the services shown on the wizard screen to use with your
Bluetooth headphones, then click Finish.
9 To connect the device, double-click the INSIGNIA NS-CAHBT02
Hands-Free Unit icon or the INSIGNIA NS-CAHBT02 Stereo
Audio icon.
Note: The headphones should be automatically selected as the default playback
device (Windows® 8, Windows® 7, or Windows Vista®) or the default recording
and playback device (Windows XP). To make those settings manually, refer to the
User Guide.
Quick Setup Guide
|
NS-CAHBT02-BL/NS-CAHBT02-BK
Bluetooth Over-the-Ear Headphone
PACKAGE CONTENTS
• Bluetooth over-the-ear headphone • Sweatproof earpads
• USB charging cable • Quick Setup Guide
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, then click Support & Service.
Enter NS-CAHBT02 in the box under Manual, Firmware, Drivers &
Product Information, then click ►.
FEATURES
• Sweatproof earpads for sports use
• Comfortable foam earpads
• Reective headband
• Volume control
• Listen to music and talk on the phone wirelessly.
Music playback: 10 hours
• Echo cancellation and noise suppression
• Voice prompts and easy pairing
• High quality sound
CHARGING YOUR STEREO
HEADPHONES
• When the red indicator LED blinks three times every one
minute, the battery is low. To charge the battery, plug the
microUSB charging cable into your computer and into the
microUSB port on your headphones. The red LED turns on to
indicate that the battery is charging and turns o when fully
charged.
Before using your new product, please read
these instructions to prevent any damage.
V2 ENGLISH 16-0289
BLUETOOTH BASIC INDICATION
Bluetooth function indication
# DESCRIPTION
1 +/- Volume Up
Volume Down
2 Reective strip
3 Indicator LED
4 (Power/Talk/
Play/Pause/
Pairing) button
5 Microphone
6 /
Next Track
Previous Track
7 Micro USB port
FUNCTION
Press + to increase the volume.
Press - to decrease the volume.
Provides extra safety in low-light
conditions.
Shows current status of the headphones.
Press to turn on your stereo headphones.
If you receive a phone call, press to talk.
Allows you to talk on the telephone.
Press to skip to the next track/fast
forward.
Press to skip to the previous
track/fast rewind.
Plug the micro USB connector into this
port to charge your headphones.
REPLACING THE EARPADS
1 Turn counter-clockwise to disassemble.
2 Take it out and replace with another pair of earpads.
3 Turn clockwise to assemble.
Bluetooth version:
Supported proles:
Frequency spectrum:
Working distance:
Operating temperature:
Operating time:
Standby time:
Size:
Weight:
Average charging time:
Bluetooth 4.1
A2DP, AVRCP, HFP, HSP
2.4 ~ 2.4835 GHz ISM Band
Up to 33 ft. (10 m)
23 ~ 122° F (-5 ~ 50° C)
Talk: 10 hours
Music: 10 hours, playback music
track
Up to 250 hours
2.3 × 4.49 × 5.39 inches
(5.85 × 11.4 × 13.7 cm)
1.64 oz (46.5 g)
2.5 hours
PAIRING YOUR STEREO
HEADPHONES
Notes:
• Range is 33 feet (10 meters)
• Supports easy pairing
• Prompts you by saying “Device Connected,” when connected
• Supports a battery indicator icon on an iOS device
Pairing with a cell phone or MP3 player
1 With your stereo headphones turned o, press and hold for four
seconds. The blue and red LEDs blink alternately.
2 On your phone or MP3 player, select INSIGNIA NS-CAHBT02 from the
list of discovered devices, then enter the password 0000 (four zeros) (if
required) to pair your headphones.
For more information on pairing Bluetooth devices to your cell phone
or MP3 player, see the device’s documentation.
Note: After the headphones have been successfully paired with the cell phone or MP3
player, the headphones will automatically reconnect to the phone or MP3 player.
ACTION
Power on
Power o
Pairing mode
Play/Pause
Volume Up/Down
Next Track/Previous Track
Fast Forward/Fast Rewind
Incoming call
Answer call
Reject call
Redial
Reset device list
OPERATION
Press and hold more than two seconds
Press and hold more than three seconds
Press and hold more than four seconds in
power o mode
Press and release button
Press and release + / - button
Press and release / button
Press and hold / button
Press and release when a call is incoming
Press and hold when a call is incoming
Double press
Long press button more than
10 seconds in power o mode
LED INDICATION
Blue LED lights for 1.5 seconds
Red LED lights for 1.5 seconds
Blue and red LED blinking
alternately
Blue LED blinks three times every
ve seconds when a call is received
All LEDs turn o
SOUND
“power on”
“power o ”
Two short beeps
Two high beeps for maximum volume.
Two low beeps for minimum volume
Ring tone
One short beep
One long beep
Two short beeps
USING YOUR STEREO
HEADPHONES
Turning your stereo headphones on and o
1 Place the headphones around your neck.
2 Press and hold the button for three seconds. The LED blinks blue
(when turned on) or red (when turned o) and the voice prompt says
“Power on”, or “Power o.”
Pairing with a Mac computer
Note: Before you pair the headphones with the computer, make sure that the
computer is Bluetooth compatible. Refer to the computer’s documentation or contact
the computer manufacturer for more information. If your computer is not Bluetooth
compatible, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see the
computer’s documentation or contact the computer manufacturer.
2 Click the Bluetooth status menu.
3 Click Set up Bluetooth Device. The Bluetooth Setup Assistant opens.
4 Click Continue.
5 Select Headset as the device type, then click Continue.
6 With the headphones turned o, press and hold for four seconds.
The LED blinks blue and red alternately. Pairing mode is activated.
7 Select INSIGNIA NS-CAHBT02, then click Continue. The computer
gathers information.
8 Click Continue.
9 Enter 0000 (four zeros) into the Passkey eld, then click Continue.
10 Click Quit to nish.
Note: To use the headphones, they must be selected as the default input and
output device on the computer.
11 Click System Preferences, then click Sound.
12 Under Input, select INSIGNIA NS-CAHBT02, then under Output,
select INSIGNIA NS-CAHBT02.
For more information on using your headphones with Skype, refer to
your User Guide.
RESETTING YOUR STEREO
HEADPHONES
• To reset your headphones, with your stereo headphones turned o,
press and hold for 10 seconds.
SPECIFICATIONS
TROUBLESHOOTING
• Reset your BT headphone
• Plug micro USB cable for charging
LEGAL NOTICES
FCC statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution:
Changes or modications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
FCC Statement:
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, maybe cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent form that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RSS‐Gen & RSS‐247 Statement:
This device complies with Industry Canada licence‐exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil
ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
RSS-102 Statement
This equipment complies with Industry Canada radiation exposure limits set forth for an
uncontrolled environment.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites
établies pour un environnement non contrôlé.
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
1-877-467-4289 (U.S. and Canada)
01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
©2016 Best Buy. All rights reserved.
Made in China
