imagine the possibilities
Thank you for purchasing a Samsung product. To
receive a more complete service, please register
your product at
www.samsung.com/global/register
Microwave Oven
user manual
SMH7185
SMH7185BG_XAC-GB.indd 1 2007-06-25 10:57:17
features
Professional Design
Samsung New OTR with Stainless Steel, it has professional look and the design matches great
with other kitchen appliances, so that it provides harmonious kitchen interior and finally completes
total kitchen solution.
Turbo vent
With 400CFM ventilation power, New OTR can keep the comfortable cooking condition by
absorbing smoke and odor from cook-top. Moreover, it provides the silent condition that is
equivalent noise level to other OTR with lower ventilation power.
The Strongest power without additional noise! That’s the benefit you can feel from New OTR!
Big Interior capacity for convenience
With the 1.8 cu.ft capacity, it offers enough space to cook. The big capacity combined with 1,100
watts of output achieves superior cooking results.
Sensor cook
Don’t worry about failure of your cooking! New OTR’s sensor technology offers the best dish.
Only thing you need to do is just select the cooking menu, and then you will be satisfied with the
cooking results by sensor cook.
VFD display
With more informative VFD display, the OTR helps you use all the function it has with ease.
SMH7185BG_XAC-GB.indd 2 2007-06-25 10:57:17
Safety information _3
SAVE THESE INSTRUCTIONS
wHAT THE ICONS ANd SIgNS IN THIS mANUAl mAEN:
WARNING: Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION: Hazards or unsafe practices that may result in minor personal injury or
property damage.
Do not attempt or use.
Do not repaire.
Do not touch.
Be careful
Follow directions explicity.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Note
PRECAUTIONS TO AVOId POSSIblE ExPORSURE TO
ExESSIVE mICROwAVE ENERgy:
Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
Do not operate the oven if it is damaged. It is particularly important that the oven door
close properly and that there is no damage to the
Door (bent or dented),
Hinges and latches (broken or loosened),
Door seals and sealing surfaces.
•
•
•
The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
safety infomation
SMH7185BG_XAC-GB.indd 3 2007-06-25 10:57:18
4_ Safety information
SAVE THESE INSTRUCTIONS
ImPORTANT SAFETy INSTRUCTIONS
When using any electrical appliance, basic safety precautions should be followed, including the
following:
wARNINg
Always observe Safety Precautions when using your oven. Never try to repair the oven
on your own - there is dangerous voltage inside. If the oven needs to be repaired, call
1-800-SAMSUNG (7267864) for the name of an authorized service center near you.
TO REDUCE RISK OF BURNS, ELECTRIC SHOCK, FIRE, PERSONAL INJURY OR
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY:
Read all safety instructions before using the appliance.
Read and follow the specific “PRECAUTIONS TO AVOID EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY” on page 3.
This appliance must be grounded. Connect only to properly grounded outlets. See
“IMPORTANT GROUNDING INSTRUCTIONS” on page 7 of this manual.
Install or place this appliance only in accordance with the installation instructions
provided.
Use this appliance only for its intended use as described in the manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically designed
to heat, cook, or dry food. It is not designed for industrial or laboratory use.
As with any appliance, close supervision is necessary when used by children.
Keep the inside of the oven clean. Food particles or spattered oils stuck to the oven
walls or floor can cause paint damage and reduce the efficiency of the oven.
Keep cord away from heated surfaces.
When cleaning door and oven surfaces, use only mild, nonabrasive soaps or detergents
applied with a sponge or soft cloth.
Remove lids from baby food before heating. After heating baby food, stir well and test
temperature by tasting before serving.
This over-the-range oven was designed for use over ranges no wider than 91.44 cm(36
inches). It may be installed over both gas and electric cooking equipment.
SMH7185BG_XAC-GB.indd 4 2007-06-25 10:57:18
Safety information _5
SAVE THESE INSTRUCTIONS
Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container
is removed from the microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
Carefully remove container coverings, directing steam away from hands and face.
Some items, like whole eggs and food in sealed containers, may explode if heated in
this oven.
Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged.
Do not cover or block any of the openings on this appliance.
Do not store this appliance outdoors. Do not use near water - for example, near a
kitchen sink, in a wet basement, or near a swimming pool, etc.
Do not immerse cord or plug in water.
Do not let cord hang over edge of table or counter.
Do not try to preheat oven or operate while empty.
Do not cook without the glass tray in place on the oven floor. Food will not cook properly
without the tray.
Do not defrost frozen beverages in narrow-necked bottles. The containers can break.
Dishes and containers can become hot. Handle with care.
Do not operate any other heating or cooking appliance beneath this appliance.
Do not mount unit over or near any portion of a heating or cooking appliance.
Do not mount over a sink.
Do not store anything directly on top of the appliance when it is in operation.
This appliance should be serviced only by qualified service personnel. Contact the
nearest authorized service facility for examination, repair, or adjustment.
SMH7185BG_XAC-GB.indd 5 2007-06-25 10:57:18
6_ Safety information
SAVE THESE INSTRUCTIONS
ImPORTANT SAFETy INSTRUCTIONS, CONTINUEd
TO REDUCE THE RISK OF FIRE IN THE OVEN:
Remove wire twist-ties from plastic cooking bags before placing bags in oven.
Do not use the oven compartment for storage purposes. Do not leave paper products,
cooking utensils, or food in the oven when not in use.
Do not overcook food. Watch appliance carefully if paper, plastic, or other combustible
materials are inside.
If materials inside the oven ignite, keep the oven door closed, turn the oven off,
disconnect the power cord, or shut off the power at the fuse or circuit breaker panel. If
the door is opened, the fire may spread.
TO REDUCE THE RISK OF INJURY TO PERSONS:
Stir the liquid both before and halfway through heating it.
After heating, allow the container to stand in the microwave oven for a short time before
removing the container.
Do not use straight-sided containers with narrow necks.
Do not overheat the liquid.
Use extreme care when inserting a spoon or other utensil into the container.
SMH7185BG_XAC-GB.indd 6 2007-06-25 10:57:18
Safety information _7
SAVE THESE INSTRUCTIONS
ImPORTANT gROUNdINg INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electrical current.
This appliance is equipped with a cord that includes a grounding wire and a grounding
plug. The plug must be plugged into an outlet that is properly installed and grounded.
Plug the three-prong power cord into a properly grounded outlet of standard 115-120
voltage, 60 Hz. Your oven should be the only appliance on this circuit.
wARNINg
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or servicer if you do not understand the grounding instructions or if
you are not sure if the appliance is properly grounded.
Do not use an extension cord with this appliance. If the power cord is too short, have a
qualified electrician or service technician install an outlet near the appliance.
Do not cut or remove the third (ground) prong from the power cord under any
circumstances.
Connect the oven only to a 15A dedicated circuit.
THE VENT FAN
The fan will operate automatically under certain conditions. Take care to prevent the
starting and spreading of accidental cooking fires while the vent fan is in use.
In the event of a grease fire on the surface units below the microwave oven, smother a
flaming pan on the surface unit by covering the pan completely with a lid, a cookie sheet
or a flat tray.
Clean Ventilating Hoods Frequently - Grease should not be allowed to accumulate on
hood of filter.
When flaming foods under the hood, turn the fan on.
Use care when cleaning the vent-hood filter. Corrosive cleaning agent, such as lye-
based oven cleaner, may damage the filter.
Never leave surface units beneath your microwave oven unattended at high heat
settings. Boilovers cause smoking and greasy spillovers that may ignite and spread if
the microwave vent fan is operating. To minimize automatic fan operation, use adequate
sized cookware and use high heat on surface units only when necessary.
SMH7185BG_XAC-GB.indd 7 2007-06-25 10:57:18
8_ Contents
YOUR NEW MICROWAVE OVEN
10
10 Checking parts
11 Warranty and service informatio
n
11 Setting up your microwave ove
n
12 Control panel fetur
e
BEGINNING
14
14 Turning on the power
14 Using the my choice featur
e
15 Setting the cloc
k
15 Setting the child protection loc
k
QUICK GUIDE
16
16 Using the your new microwave oven
OPERATING THE OVEN
17
17 Using the help button
17 Using the pause/cancel butto
n
17 Using the kitchen time
r
17 Using the one minute+ butto
n
17 Using the more/less button
s
18 Using the sensor cook button
s
18 Using the sensor reheat butto
n
18 Using the power/auto defrostin
g
19 Using the handy helper butto
n
20 Using the kids meals butto
n
21 Using the snack bar butto
n
22 Setting cooking times & power level
s
23 Setting and using the custom cook butto
n
23 Turning the Turntable On/Of
f
23 Turning the Light On/Night/Of
f
23 Turning the Vent Fan Turbo/Hi/Low/Of
f
24 Using the metal shel
f
contents
SMH7185BG_XAC-GB.indd 8 2007-06-25 10:57:18
Contents _9
COOKING INSTRUCTIONS
25
25 Cooking utensils
26 Testing utensil
s
26 General microwave tip
s
27 Cooking technique
s
28 Auto sensor coo
k
28 Utensils & cover for sensor cookin
g
29 Sensor Cooking Guid
e
30 Sensor Reheat Guid
e
30 Power/Auto Defrosting Guid
e
31 Cooking Guid
e
34 Recipe
s
MAINTENANCE
36
36 Troubleshooting
37 Care and Cleanin
g
38 Light bulb replacemen
t
39 The vent fa
n
41 Specication
s
WARRANTY
42
contents
SMH7185BG_XAC-GB.indd 9 2007-06-25 10:57:18
10_ Your new microwave oven
your new microwave oven
CHECKING PARTS
Unpack your microwave oven and check to make sure that you have all the parts shown here. If
any part is missing or broken, call your dealer.
Microwave oven Shelf
Glass Tray Roller Guide Ring Charcoal filter
Grease Filters (2ea) Exhaust adaptor Hardware-kit
Manuals
(User & Installations)
Templates (Top & Wall) Registration Card
SMH7185BG_XAC-GB.indd 10 2007-06-25 10:57:19
01 YOUR NEW MIRCOWAVE OVEN
Your new microwave oven _11
WARRANTY AND SERVICE INFORMATION
To help us to serve you better, please complete the enclosed registration card and promptly return
it by mail. If the registration card is missing, you can call Samsung Electronics Canada, Inc., at
1-800-SAMSUNG (7267864)
.
When contacting Samsung, please provide the specific model and serial number information
which is usually located on the back or bottom of the product. Please record these numbers
below, along with the other requested information. Keep this information in a safe place as a
permanent record of your purchase to aid in identification in case of theft or loss, and a copy of
your sales receipt as a proof of purchase if warranty service is needed.
MODEL NUMBER
SERIAL NUMBER
DATE PURCHASED
PURCHASED FROM
Warranty service can only be performed by a Samsung Authorized Service Center. If you should
require warranty service, provide the above information with a copy of your sales receipt to the
Samsung Authorized Service Center.
For service assistance and the location of the nearest service center, please call 1-800-
SAMSUNG (7267864).
SETTING UP YOUR MICROWAVE OVEN
1. Open the oven door by pulling the handle on the right side of the door.
2. Wipe the inside of the oven with a damp cloth.
3. Place the pre-assembled ring in the indentation in the center
of the oven.
4. Place the glass tray securely in the center of the pre-
assembled roller guide.
SMH7185BG_XAC-GB.indd 11 2007-06-25 10:57:19
12_ Your new microwave oven
CONTROL PANEL FETURE
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE MICROWAVE OVEN. For satisfactory use of your oven, become familiar with the various
features and functions of the oven as described below. Detailed instructions for each feature and function follow later in this user manual.
One Minute +
Press once for every minute of cooking at High power
Learn more about this feature on page 17.
Sensor Reheat
Learn more about this feature on page 18.
Power/Auto Defrost
Sets weight of food to be defrosted
Learn more about this feature on page 18.
Sensor Cook buttons
Sensor settings to cook popular foods
Learn more about this feature on page 18.
Handy Helper, Kids Meals, Snack Bar
Selects type of dish to be reheated
Learn more about this feature on page 19~21.
Display window
SMH7185BG_XAC-GB.indd 12 2007-06-25 10:57:19
01 YOUR NEW MIRCOWAVE OVEN
Your new microwave oven _13
More, Less
Increase or decrease cooking time
Learn more about these features on page 17.
My Choice
Press to set non-cooking feature
Learn more about this feature on page 14.
Custom Cook
Learn more about this feature on page 23.
Help
Press to see help information about the feature you are
using
Learn more about this feature on page 17.
Clock
Sets current time
Learn more about this feature on page 15.
Kitchen Timer
Sets kitchen or convenience timer
Learn more about this feature on page 17.
Power Level
Press this button to set a power level
Learn more about this feature on page 22.
Pause/Cancel
Press to pause or cancel the oven
Learn more about this feature on page 17.
Start
Press to start cooking
Turntable On/Off
Learn more about this feature on page 23.
Light
Learn more about this feature on page 23.
Turbo Vent
Learn more about this feature on page 23.
SMH7185BG_XAC-GB.indd 13 2007-06-25 10:57:19
14_ Beginning
TURNING ON THE POWER
The first time you plug the power cord into an outlet, or after there has been an interruption in
power, the display shows after four seconds ENJOY YOUR COOKING -- -- -- PRESS MY CHOICE
FOR PERSONAL OPTIONS.
USING THE MY CHOICE FEATURE
Your new microwave oven can be customized to suit your personal tastes. Simply press MY
CHOICE
to set these options. For your convenience, all the options are summarized in the
following table:
NUMBER MY CHOICE OPTIONS DESCRIPTION
1 Language choice Language options are english, french and spanish.
2 Display weight Weight options are pounds or kilograms.
3 Remind end signal The remind end signal can be turned on and off.
4
Daylight savings time
adjustment
The time can be advanced one hour for dst without
resetting the clock.
Selecting a display language
1. Press MY CHOICE button immediately after plugging in your microwave and then press
number 1 button. The display will show: LANGUAGE CHOICE PRESS MY CHOICE
3. Press MY CHOICE button. The display will show: ENGLISH PRESS START
4. Press MY CHOICE button repeatedly to select the language you wish to use.
If you continue to press My Choice, the settings will cycle in the order shown here: ENGLISH,
FRENCH, SPANISH
5. Press the START button.
Selecting the display weight
You can choose between pounds(LBS) and kilograms(KG).
1. Press MY CHOICE
button and then press the number 2 button. The display shows: LBS OR
KG PRESS MY CHOICE
2. Press MY CHOICE button. The display shows: LBS
3. Press the MY CHOICE button repeatedly to select the weight measurements you wish to use.
4. Press the
START button.
•
beginning
SMH7185BG_XAC-GB.indd 14 2007-06-25 10:57:20
02 BEGINNING
Beginning _15
Setting the remind end signal
The Remind End Signal can be set On or Off.
1. Press the MY CHOICE
button and then press number 3 button. The display shows: REMIND
END SIGNAL ON/OFF PRESS MY CHOICE
2. Press the MY CHOICE button to select ON. The display shows: ON
3. Press the START button. The display returns to the time of day.
To turn Remind End Signal off, repeat steps 1-3 above.
Setting the daylight saving time adjustment
1. Press the MY CHOICE button and then number 4 button. The display will show: DAYLIGHT
SAVING TIME ON/OFF PRESS MY CHOICE
2. Press the MY CHOICE button to select ON. Press MY CHOICE button again to select OFF.
3. Press the
START button. Time of day will advance one hour. If OFF is selected, time will go
back one hour.
If the clock is set for standard time, this function allows convenient time changes without
needing to reset the clock. Daylight Saving Time begins for most of the United States at 2
a.m. on the first Sunday of April, and reverts to Standard time at 2 a.m. on the last Sunday of
October.
SETTING THE CLOCK
1. Press the CLOCK button. The display will show: SELECT AM/PM
2. To select AM or PM, press the CLOCK button.
3. Use the number buttons to enter the current time. You must press at least three numbers to set
the clock. For example, if the current time is 5:00, enter 5,0,0. The display will show: 500
4. Press CLOCK again. A colon will appear, indicating that the time is set.
If there is a power interruption, you will need to reset the clock.
You can check the current time while cooking is in progress by pressing the Clock button.
SETTING THE CHILD PROTECTION LOCK
You can lock your microwave oven so it can’t be used by unsupervised children.
1. Press the MY CHOICE
button and the number 5 button at the same time for 3 seconds. The
display shows : CHILD LOCK ON
2. The display returns to the time of day.
At this point, the microwave oven cannot be used until it is unlocked. To unlock it, repeat steps
1-2 above.
•
•
•
•
•
SMH7185BG_XAC-GB.indd 15 2007-06-25 10:57:20
16_ Quick guide
USING THE YOUR NEW MICROWAVE OVEN
quick guide
One minute cooking
1. Press the ONE MINUTE + button once for each minute of cooking.
2. The time will display and the oven will start.
See page 17 for more informations•
Sensor Reheat
1. Press SENSOR REHEAT button.
2. The display will show
REHEAT and the oven will start automatically.
See page 18 for more informations•
Sensor Cook
1. Press button that corresponds to the food you are cooking (for example POTATO).
2. The display will show the food you have chosen and the oven will start automatically.
See page 18 for more informations•
Defrost
1. Press POWER/AUTO DEFROST button.
2. Enter weight of food by pressing
POWER/AUTO DEFROST button repeatedly or using the
number buttons.
3. When the oven beeps, turn food over. Press
START to resume defrosting cycle.
See page 18 for more informations•
Handy Helper, Kids Meals, Snack Bar
1. Press HANDY HELPER or KIDS MEALS or SNACK BAR button repeatedly to select type of
dish to reheat.
2. To increase serving size, press the corresponding number button.
3. Press
START button to begin cooking.
See page 19~21 for more informations•
Set cooking time and power levels
1. Use number buttons to set cooking time.
2. To set power level at other than HIGH, press
POWER LEVEL and use the number buttons to
enter the power level.
3. Press
START to begin cooking.
See page 22 for more informations•
SMH7185BG_XAC-GB.indd 16 2007-06-25 10:57:20
04 OPERATING THE OVEN
Operating the oven _17
operating the oven
USING THE HELP BUTTON
Your microwave offers helpful instructions for many procedures.
When you need feature information and helpful hints, press the HELP button and then press the
button that you want to get information on. Help information is available in 3 languages (English,
French and Spanish).
USING THE PAUSE/CANCEL BUTTON
The PAUSE/CANCEL button allows you to clear instructions you have entered. It also allows you
to pause the oven’s cooking cycle, so that you can check the food.
To pause the oven during cooking: press PAUSE/CANCEL button once. To restart, press
START button.
To stop cooking, erase instructions, and return the oven display to the time of day: press
PAUSE/CANCEL button twice.
To clear instructions you have just entered: press PAUSE/CANCEL button once, then re-enter
the instructions.
To cancel a timer setting: press PAUSE/CANCEL button once.
USING THE KITCHEN TIMER
1. Use the number buttons to set the length of time you want the timer to run.
2. Press the KITCHEN TIMER
button.
3. The display counts down and beeps when the time has elapsed.
4. To cancel timer setting: Press
PAUSE/CANCEL button twice.
USING THE ONE MINUTE+ BUTTON
This button offers a convenient way to heat food in one minute increments at the High power level.
1. Press the
ONE MINUTE+ button once for each minute you wish to cook the food. For
example, press it twice for two minutes. The time will display, and the oven starts automatically.
2. Add minutes to a program in progress by pressing the
ONE MINUTE+ button for each minute
you want to add.
USING THE MORE/LESS BUTTONS
The MORE/LESS buttons allow you to adjust pre-set cooking times. They only work in the Sensor
Reheat, Sensor Cooking(except Beverage), One minute +, Custom Cook, Kitchen Timer,
Handy Helper, Kids Meals, Snack Bar or Time Cook modes. Use the MORE/ LESS button
only after you have already begun cooking with one of these procedures.
1. To add more time to an automatic cooking procedure: Press the MORE(9)
button.
2. To reduce the time of an automatic cooking procedure: Press the
LESS(1) button.
•
•
•
•
SMH7185BG_XAC-GB.indd 17 2007-06-25 10:57:20
18_ Operating the oven
USING THE SENSOR COOK BUTTONS
By actually sensing the humidity that escapes as food heats, this feature automatically adjusts the
oven’s heating time for various types and amounts of food.
Press the SENSOR COOK button corresponding to the food you are cooking (POTATO,
for example). The display shows POTATO and your microwave oven will begin cooking
automatically.
When cooking popcorn, wait at least five minutes between each bag to avoid overheating the
glass tray. If you want to adjust the cooking time, you can use the MORE or LESS buttons. If
you want to check the current time while cooking is in progress, press the CLOCK button.
USING THE SENSOR REHEAT BUTTON
Heating leftovers and precooked foods is easy with your new microwave. By actually sensing the
humidity that escapes as food heats, this feature automatically adjusts the oven’s heating time for
various types and amounts of precooked food. All food should be precooked. Plate of food and
casserole should be stored at refrigerator temperature. To use sensor reheating:
Press SENSOR REHEAT button.The display will show REHEAT and the oven will start
automatically.
If you want to adjust the heating time, use the MORE/LESS buttons.
If you want to check the current time while reheating, press the CLOCK button.
USING THE POWER/AUTO DEFROSTING
To thaw frozen food, set the weight of the food and the microwave automatically sets the
defrosting time, power level and standing time.
The Power Defrost function will automatically activate when defrosting foods that weigh less than
1.0 lbs.
The Auto Defrost function will automatically activate when desfrosting foods that weigh over 1.0
lbs.
Please note that Auto Defrost function (function that defrosts foods which weigh more than
1.0 lbs) will take several minutes longer than the Power Defrost function (function that defrosts
foods which weigh less than 1.0 lbs).
1. Press the
POWER/AUTO DEFROST button. The display shows : 0.5 LB (0.2Kg if you have
set your oven for metric measure).
2. To set the weight of your food, press the
POWER/AUTO DEFROST repeatedly. This increases
the weight by 0.5 lb increments, up to 6.0 lbs. You can also use the number buttons to enter
the weight of the food directly. The oven calculates the defrosting time and starts automatically.
Twice during defrosting, the oven will beep and the display will read TURN THE FOOD OVER
3. Open the oven door, and turn the food over.
4. Press the
START button to resume defrosting.
Even if you do not turn the food over when TURN THE FOOD OVER is displayed.
•
•
•
•
•
•
•
See “Sensor cooking guide” on page 29 for more informations.
See “Sensor reheat guide” on page 30 for more informations.
See “Power/auto defrosting guide” on page 30 for more informations.
SMH7185BG_XAC-GB.indd 18 2007-06-25 10:57:20
04 OPERATING THE OVEN
Operating the oven _19
USING THE HANDY HELPER BUTTON
1. Press the HANDY HELPER button corresponding to the food you are cooking. The display
shows: MELT CHOCOLATE 1CUP CHIPS.
Press the HANDY HELPER button repeatedly to select the item you want.(Refer to the handy
helper chart)
2. Press the number
1 or 2 button to select the serving size you want. Only the number 1
button(serving) is available for Soften Cream Cheese and Melt Chocolate items. (Refer to the
handy helper chart for the serving)
3. Press the
START button to begin cooking.
Handy helper chart
ITEM AMOUNT REMARKS
Melt
chocolate
1 cup chips or
1 square
Place chocolate chips or square in a microwave-safe
container.
When oven beeps, stir chocolate and re-start oven.
Stir and let stand 1 minute.
Soften cream
cheese
8-oz package
Unwrap cream cheese and place on microwave-safe
container.
Cut in half vertically.
Let stand 2 minutes.
Melt butter
1 stick
2 sticks
Unwrap butter and place in a microwave-safe container.
Cut in half vertically.
Cover with wax paper.
Let stand 2 minutes, then stir
•
SMH7185BG_XAC-GB.indd 19 2007-06-25 10:57:20
20_ Operating the oven
USING THE KIDS MEALS BUTTON
1. Press the KIDS MEALS button corresponding to the food you are cooking. The display shows:
CHICKEN NUGGETS
Press the KIDS MEALS button repeatedly to select the item you want. (Refer to the kids meals
chart.)
2. Press the number
1 or 2 button to select the serving size you want. (Refer to the kids meals
chart for the serving.)
3. Press the
START button to begin cooking.
Kids meals chart
ITEM AMOUNT REMARKS
Chicken
nuggets
(frozen)
1 serving
2 servings
Put a paper towel on top of plate and arrange nuggets in
spoke fashion.
Do not cover.
Let stand 1 minute after heating.
NOTE: Refer to package directions for serving size and
amount of food. Use the More button if chicken nuggets
are not hot enough.
Hot dogs
2 hot dogs
4 hot dogs
Prick hot dogs and place on plate
When oven beeps, add buns and re-start oven.
Let stand 1 minute after heating.
NOTE: For the best texture, buns should be added to hot
dogs when the oven beeps.
French fries
(frozen)
1 serving
2 servings
Place 2 paper towels on microwave-safe plate.
Arrange french fries on towels. Do not overlap.
After cooking, plot with additional paper towel.
Let stand 1 minute after heating.
NOTE: Refer to package directions for serving size and
amount of food.
Frozen
sandwiches (in
crisping sleeve)
9-oz package
size
1 sandwich
2 sandwiches
Place frozen sandwich in susceptor “crisping sleeve”
packaged with sandwich.
Place on microwave-safe plate.
Remove from “crisping sleeve”.
Let stand 2 minutes after heating.
NOTE: For larger size sandwiches, use the MORE button
to increase the heating time.
•
SMH7185BG_XAC-GB.indd 20 2007-06-25 10:57:20
04 OPERATING THE OVEN
Operating the oven _21
USING THE SNACK BAR BUTTON
1. Press the SNACK BAR button corresponding to the food you are cooking. The display shows:
NACHOS 1 SERVING
Press the SNACK BAR button repeatedly to select the item you want. (Refer to the snack bar
chart)
2. Press the number
1 or 2 button to select the serving size you want. Only the number 1
button(serving) is available for Nachos. (Refer to the snack bar chart for the serving)
3. Press
START button to begin cooking.
Snack bar chart
ITEM AMOUNT REMARKS
Nachos 1 serving
Place tortilla chips on plate without overlapping.
Sprinkle evenly with cheese.
CONTENTS:
2 cups tortilla chips
1
/3 cup grated cheese
•
•
Chicken
wings
5-6 oz.
7-8 oz.
Use pre-cooked, refrigerated chicken wings.
Place chicken wings around plate in spoke fashion.
Cover with wax paper.
Let stand 1 to 2 minutes after heating.
Potato
skins
1 cooked potato
2 cooked potatoes
Cut cooked potato into 4 even wedges. Scoup or cut out
potato flesh, leaving about
1
/4” of skin.
Place skins in spoke fashion around plate.
Sprinkle with bacon, onions and cheese.
Do not cover.
Let stand 1 to 2 minutes after heating.
Cheese
sticks
(frozen)
5-7 pcs
8-10 pcs
Place cheese sticks on plate in spoke fashion.
Do not cover.
Let stand 1 to 2 minutes after heating.
NOTE: Sizes of cheese stick vary. For smaller size cheese
nuggets, use the LESS button to decrease the heating
time. For larger size cheese sticks, use the MORE button
to increase heating time.
•
SMH7185BG_XAC-GB.indd 21 2007-06-25 10:57:20
22_ Operating the oven
SETTING COOKING TIMES & POWER LEVELS
Your microwave allows you to set up to three different stages of cooking, each with its own time
length and power level. The power level lets you control the heating intensity from Warm (1) to
High (0).
One-stage cooking
For simple one-stage cooking, you only need to set a cooking time. The power level is
automatically set at High. If you want the power set at any other level, you must set it using the
POWER LEVEL button.
1. Use the number buttons to set a cooking time. You can set a time from one second to 99
minutes, 99 seconds. To set a time over one minute, enter the seconds too. (For example, to
set 20 minutes, enter 2, 0, 0, 0.)
2. If you want to set the power level to something other than High, press the
POWER LEVEL
button, then use the number buttons to enter a power level. The display shows: PRESS START
OR ENTER NEXT STAGE COOKING TIME.
POWER LEVEL
1 Warm 6 Simmer
2 Low 7 Medium high
3 Deforst 8 Reheat
4 Medium low 9 Saute
5 Medium 0 High
3. Press the
START button to begin cooking. If you want to change the power level, press
PAUSE/CANCEL button before you press the START button, and re-enter all of the
instructions.
Some recipes require different stages of cooking at different temperatures. You can set multiple
stages of cooking with your microwave.
Multi-stage cooking
1. Follow steps 1 and 2 in the “One-stage cooking” section. PRESS START OR ENTER NEXT
STAGE COOKING TIME appears in the display.
When entering more than one cooking stage, the Power Level button must be pressed before
the second cooking stage can be entered.
To set the power level at High for a stage of cooking, press the Power Level button twice.
2. Use the number buttons to set a second cooking time.
3. Press the
POWER LEVEL button, then use the number buttons to set the power level of the
second stage of cooking. The display shows the power level you have set and PRESS START
OR ENTER NEXT STAGE COOKING TIME
4. Press the START button to begin cooking, or repeat steps 2 and 3 to set a cooking time and
power level for a third stage of cooking. When finished, press START button.
•
•
•
SMH7185BG_XAC-GB.indd 22 2007-06-25 10:57:20
04 OPERATING THE OVEN
Operating the oven _23
SETTING AND USING THE CUSTOM COOK BUTTON
The Custom button memorizes the time and power setting for a particular food.
Programming the Custom Cook button
1. Press the CUSTOM COOK button. Press the button twice to delete the previous Custom
setting. The display shows: ENTER COOKING TIME AND POWER
2. Use the number buttons to enter the amount of cooking time. The display will show the amount
of time you have set.
3. Press the
POWER LEVEL button and use the number buttons to enter the power level. The
display will show the power level you have set. You can set the power level from 0 to 9.
4. Press the CUSTOM COOK
button again. The display will read CUSTOM RECIPE SAVED.
Using the Custom Cook button
Press the Custom Cook button, then press Start button. You can check the power level while
cooking is in progress by pressing the Power Level button.
TURNING THE TURNTABLE ON/OFF
For best cooking results, leave the turntable on.
It can be turned off for large dishes.
Press TURNTABLE ON/OFF button to turn the turntable on or off.
Sometimes the turntable can become too hot to touch. Use pot holders touching the turntable
during and after cooking.
TURNING THE LIGHT ON/NIGHT/OFF
Press the LIGHT button to adjust the light or turn it on/off.
Press the LIGHT button once for on light, twice for the night light and three times to turn the
light off.
TURNING THE VENT FAN TURBO/HI/LOW/OFF
The vent fan removes steam and other vapors from surface cooking.
Press TURBO VENT button once for turbo fan speed, twice for high fan speed and three times
for low fan speed or four times to turn the fan off.
The Vent Fan protects the microwave from too much heat rising from the cooktop below it.
It automatically turns on if it senses too much heat. If you have turned the fan on, you may
find that you cannot turn it off. The fan will automatically turn off when the internal parts
are cool. It may stay on for 30 minutes or more after the cooktop and microwave controls
are turned off.The Vent Fan will operate only in Hi/Low/Off mode while the microwave is
working.
•
•
•
•
•
•
•
•
(Refer page 22 for more informations.)
SMH7185BG_XAC-GB.indd 23 2007-06-25 10:57:20
24_ Operating the oven
USING THE METAL SHELF
How to use the metal shelf when microwaving
Make sure the shelf is positioned properly inside the microwave to prevent damage to the oven
from arcing.
Do not use a microwave browning dish on the shelf. The shelf could overheat.
Do not use the oven with the shelf on the microwave floor. This could damage the microwave.
Use pot holders when handling the shelf-it may be hot.
Do not use the metal shelf when cooking popcorn.
Food microwaves best when placed on the turntable or on the shelf in the lower position.
For best results
Uneven results
The shelf gives you the option to reheat more than one dish of food at the same time.
Shelf and reheating
To reheat on 2 levels or to reheat dishes on the lower level:
Multiply reheat time by 1½.
Switch places after ½ the time.
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 24 2007-06-25 10:57:21
05 COOKING INSTRUCTIONS
Cooking instructions _25
cooking instructions
COOKING UTENSILS
Recommended use
Glass and glass - ceramic bowls and dishes - Use for heating or cooking.
Microwavable plastic wrap - Use to cover. Leave a small opening for some steam to escape
and avoid placing it directly on the food.
Wax paper - Use as a cover to prevent spattering.
Paper towels and napkins - Use for short-term heating and covering; they absorb excess
moisture and prevent spattering. Do not use recycled paper towels, which may contain metal
and can catch fire.
Paper plates and cups - Use for short-term heating at low temperatures. Do not use recycled
paper, which may contain metal and can catch fire.
Thermometers - Use only those labeled “Microwave-Safe” and follow all directions. Check
the food in several places. Conventional thermometers may be used once the food has been
removed from the oven.
Limited use
Aluminum foil - Use narrow strips of foil to prevent overcooking of exposed areas. Using too
much foil can damage your oven, so be careful.
Ceramic, porcelain, and stoneware - Use these if they are labeled “Microwave-Safe”. If they
are not labeled, test them to make sure they can be used safely. Never use dishes with metallic
trim.
Plastic - Use only if labeled “Microwave-Safe”. Other plastics can melt.
Straw, wicker, and wood - Use only for short-term heating, as they can be flammable.
Not recommended
Glass jars and bottles - Regular glass is too thin to be used in a microwave, and can shatter.
Paper bags - These are a fire hazard, except for popcorn bags that are designed for
microwave use.
Styrofoam plates and cups - These can melt and leave an unhealthy residue on food.
Plastic storage and food containers - Containers such as margarine tubs can melt in the
microwave.
Metal utensils - These can damage your oven. Remove all metal before cooking.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 25 2007-06-25 10:57:21
26_ Cooking instructions
TESTING UTENSILS
If you are not sure whether a dish is microwave-safe or not, you can perform this test:
1. Fill 1 cup of glass measuring cup with water and
put it inside your oven, next to the dish you want to
test.
2. Press the ONE MINUTE + button once to heat them for one minute at High power.
The water should be warm and the dish you are testing should be cool. If the dish is warm, then it
is absorbing microwave energy and is not acceptable for use in the microwave.
GENERAL MICROWAVE TIPS
Dense foods, such as potatoes, take longer to heat than lighter foods. Foods with a delicate
texture should be heated at a low power level to avoid becoming tough.
Altitude and the type of cookware you are using can affect cooking time. When using a new
recipe, use the minimum cooking time and check the food occasionally to prevent overcooking.
Foods with a non-porous skin such as potatoes or hot dogs, should be pierced to prevent
bursting.
Frying with heating oil or fat is not recommended. Fat and oil can suddenly boil over and cause
severe burns.
Some ingredients heat faster than others. For example a jelly doughnut will be hotter than the
dough. Keep this in mind to avoid burns.
Home canning in the microwave oven is not recommended because all harmful bacteria may
not be destroyed by the microwave heating process.
Although microwaves do not heat the cookware, the heat from the food is often transferred to
the cookware. Always use pot holders when removing food from the microwave and instruct
children to do the same.
Making candy in the microwave is not recommended as candy can be heated to very high
temperatures. Keep this in mind to avoid injury.
•
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 26 2007-06-25 10:57:21
05 COOKING INSTRUCTIONS
Cooking instructions _27
COOKING TECHNIQUES
Stirring
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly. Food at the
outside of the dish absorbs more energy and heats more quickly, so stir from the outside to the
center. The oven will turn off when you open the door to stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken pieces or chops, with the thicker, meatier
parts toward the outside of the turntable where they receive more microwave energy. To prevent
overcooking, place thin or delicate parts toward the center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to prevent overcooking. Areas that need shielding
include poultry wing-tips, the ends of poultry legs, and corners of square baking dishes. Use only
small amounts of aluminum foil. Larger amounts can damage your oven.
Turning
Turn foods over midway through cooking to expose all parts to microwave energy. This is
especially important with large items such as roasts.
Standing
Foods cooked in the microwave build up internal heat and continue to cook for a few minutes
after the oven stops. Let foods stand to complete cooking, especially foods such as roasts and
whole vegetables. Roasts need this time to complete cooking in the center without overcooking
the outer areas. All liquids, such as soup or hot chocolate, should be shaken or stirred when
cooking is complete. Let liquids stand a moment before serving. When heating baby food, stir well
and test the temperature before serving.
Adding moisture
Microwave energy is attracted to water molecules. Food that is uneven in moisture content should
be covered or allowed to stand so that the heat disperses evenly. Add a small amount of water to
dry food to help it cook.
Venting
After covering dish with plastic wrap, you vent plastic wrap by turning back one corner so excess
steam can escape.
SMH7185BG_XAC-GB.indd 27 2007-06-25 10:57:21
28_ Cooking instructions
AUTO SENSOR COOK
The Auto Sensor allows you to cook your food automatically by detecting the amount of humidity
generated from the food while cooking.
When cooking food, the humidity is generated. The Auto Sensor determines the proper time
and power level by detecting the humidity from the food, eliminating the need to set the
cooking time and power level.
When you cover a container with its lid or plastic wrap during Sensor Cooking, the Auto Sensor
will detect the humidity generated after the container has been saturated with steam.
Shortly before cooking ends, the remaining cooking time will begin its count down. This will be
a good time for you to rotate or stir the food for even cooking if it is necessary.
Before auto sensor cooking food may be seasoned with herbs, spices or browning sauces.
A word of caution though, salt or sugar may cause burn spots on food so these ingredients
should be added after cooking.
The MORE/LESS buttons is used to increase or decrease cooking time. You should use this
function to adjust the degree of cooking to suit your personal taste.
UTENSILS & COVER FOR SENSOR COOKING
To obtain good cooking results with this function, follow the directions for selecting appropriate
containers and covers in the charts in this book.
Always use microwave-safe containers and cover them with their lids or with plastic wrap.
When using plastic wrap, turn back one corner to allow steam to escape at the proper rate.
Always cover with the lid intended for the utensil being used. If the utensil does not have its
own lid, use plastic wrap.
Fill containers at least half full.
Foods that require stirring or rotating should be stirred or turned at the end of the Sensor Cook
cycle, when the time has started to count down on the display.
It is not advisable to use the Auto Sensor cooking feature on a continuous cooking
operation, i.e. one cooking operation immediately after another.
Install the oven in a well ventilated location for proper cooling and airflow and to ensure
the sensor will operate accurately.
To avoid poor results, do not use the Auto Sensor when the room ambient temperature
is too high or too low.
Avoid placing the oven near high moisture appliances, since this will interfere with the
proper performance of the Auto Sensor.
Always keep the inside of the oven clean. Wipe all spills with a damp cloth.
This oven is designed for household use only.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 28 2007-06-25 10:57:22
05 COOKING INSTRUCTIONS
Cooking instructions _29
SENSOR COOKING GUIDE
Follow the instructions below when sensor cooking different types of food.
FOOD AMOUNT PROCEDURE
Popcorn
3.0 - 3.5 oz
1 package
Use only one microwave-only bag of popcorn at a time.
Use caution when removing and opening the hot bag from
oven. Let oven cool for at least 5 minutes before using
again.
Potatoes 1 to 6 potatoes.
Prick each potato several times with fork. Place on
turntable in spoke-like fashion. Let stand 3-5 minutes. Let
oven cool for at least 5 minutes before using again.
Beverage
8 oz.
Use measuring cup or mug ; do not cover. Place the
beverage in the oven. After heating, stir well. Let oven cool
for at least 5 minutes before using again.
Frozen dinner 8 to 14 oz.
Remove food from outer wrapping and follow box
instructions for covering and standing. Let oven cool for at
least 5 minutes before using again.
Pizza reheat 1 to 3 slices
Put 1-3 slices of pizza on a microwave-safe plate with wide
end of slice towards the outside edge of the plate. Do not
let slices overlap. Do not cover. Let oven cool for at least 5
minutes before using again. Use MORE button to increase
reheat time for thick crust pizza.
Frozen
vegetables
1 to 4 servings
Place frozen vegetables in microwave-safe ceramic,
glass or plastic dish and add 2-4 Tbs. water. Cover with
lid or vented plastic wrap during cooking and stir before
standing. Let oven cool for at least 5 minutes before using
again.
Chicken
breast
8 to 16 oz.
Place chicken breasts on a microwave safe plate and cover
with plastic wrap. Cook to an internal temperature of 170
degrees F. Let stand 5 minutes. Use the MORE button to
increase cooking time for larger or thicker chicken breasts.
Frozen
breakfast
4 to 8 oz.
Follow package instructions for covering and standing.
Use this button for frozen sandwich, breakfast entree,
pancakes, waffles, etc. Let oven cool for at least 5 minutes
before using again.
Fresh
vegetables
1to 4 cups
Place fresh vegetables in microwave-safe ceramic, glass
or plastic dish and add 2-4 Tbs. water. Cover with lid
or vented plastic wrap during cooking and stir before
standing. Let oven cool for at least 5 minutes before using
again.
Desired food temperature varies from person to person. Use the MORE/LESS buttons to
fit your temperature preference.
SMH7185BG_XAC-GB.indd 29 2007-06-25 10:57:22
30_ Cooking instructions
SENSOR REHEAT GUIDE
Follow the instructions below when sensor reheating different types of food.
FOOD AMOUNT PROCEDURE
Plate of food
1 serving
(1 plate).
Use only pre-cooked, refrigerated foods.
Cover plate with vented plastic wrap or waxed paper, tucked
under plate. If food is not as hot as you prefer after heating
with Sensor Reheat, continue heating using time and power.
CONTENTS
3-4 oz. meat, poultry or fish (up to 6 oz. with bone)
1
/2 cup starch (potatoes, pasta, rice, etc.)
1
/2 cup vegetables (about 3 - 4 oz.)
•
•
•
Casserole
1 to 4 servings.
Cover plate with lid or vented plastic wrap. If food is not as
hot as you prefer after heating with Sensor Reheat, continue
heating using time and power.
Stir foods once before serving.
CONTENTS
Casserole-refrigerated foods.
Pasta-Canned spaghetti and ravioli.
•
•
Pasta reheat
POWER/AUTO DEFROSTING GUIDE
Follow the instructions below when defrosting different types of food.
FOOD AMOUNT PROCEDURE
Roast beef,
pork
2.5-6.0 lbs.
Start with the food placed fat side down. After each stage,
turn the food over and shield any warm portions with narrow
strips of aluminum foil. Let stand, covered, for 10-20
minutes.
Steaks,
chops, fish
0.5-3.0 lbs.
After each stage, rearrange the food. If there are any warm or
thawed portions of food, shield them with narrow flat pieces
of aluminum foil. Remove any pieces of food that are nearly
defrosted. Let stand, covered, for 5-10 minutes.
Ground meat 0.5-3.0 lbs.
After each stage, remove any pieces of food that are nearly
defrosted. Let stand, covered with foil, for 5-10 minutes.
Whole
chicken
2.5-6.0 lbs.
Remove giblets before freezing poultry. Start defrosting with
the breast side down. After the first stage, turn the chicken
over and shield any warm portions with narrow strips of
aluminum foil. After the second stage, again shield any
warm portions with narrow strips of aluminum foil. Let stand,
covered, for 30-60 minutes in the refrigerator.
Chicken
pieces
0.5-3.0 lbs.
After each stage, rearrange or remove any pieces of food that
are nearly defrosted. Let stand for 10-20 minutes.
Check foods when the oven signals. After the final stage, small sections may still be icy; let
them stand to continue thawing. Do not defrost until all ice crystals have thawed. Shielding
roasts and steaks with small pieces of foil prevents the edges from cooking before the
center of the food has defrosted. Use narrow, flat, smooth strips of aluminum foil to cover
the edges and thinner sections of the food.
SMH7185BG_XAC-GB.indd 30 2007-06-25 10:57:22
05 COOKING INSTRUCTIONS
Cooking instructions _31
COOKING GUIDE
Guide for cooking meat in your microwave
Place meat on a microwave-safe roasting rack in a microwave-safe dish.
Start meat fat-side down. Use narrow strips of aluminum foil to shield any bone tips or thin
meat areas.
Check the temperature in several places before letting the meat stand the recommended time.
The following temperatures are removal temperatures. The temperature of the food will rise
during the standing time.
FOOD COOK TIME/POWER LEVEL DIRECTIONS
Roast beef
boneless
Up to 4 lbs.
Cooking Time:
7-11 min. / lb. for 145° F - Rare
8-12 min. / lb. for 160° F - Medium
9-14 min. / lb. for 170° F - Well Done
Place roast fat-side down on
roasting rack. Cover with wax
paper. Turn over half way
through cooking. Let stand
10 minutes.
Power Level:
High(0) for first 5 minutes, then Medium(5).
Pork boneless
or bone-in
Up to 4 lbs.
Cooking Time:
11-15 min. / lb. for 170° F Well Done
Place roast fat-side down on
roasting rack. Cover with wax
paper. Turn over half way
through cooking. Let stand
10 minutes.
Power Level:
High(0) for first 5 minutes, then Medium(5).
Expect a 10°F rise in temperature during the standing time.
FOOD REMOVE FROM OVEN AFTER STANDING (10 MIN.)
Beef
Rare
Medium
Well Done
135°F
150°F
160°F
145°F
160°F
170°F
Pork
Medium
Well Done
150°F
160°F
160°F
170°F
Poultry
Dark meat
Light meat
170°F
160°F
180°F
170°F
•
•
•
•
SMH7185BG_XAC-GB.indd 31 2007-06-25 10:57:22
32_ Cooking instructions
Guide for cooking poultry in your microwave
Place poultry on a microwave-safe roasting rack in a microwave-safe dish.
Cover poultry with wax paper to prevent spattering.
Use aluminum foil to shield bone tips, thin meat areas, or areas that start to overcook.
Check the temperature in several places before letting the poultry stand the recommended
time.
FOOD COOK TIME/POWER LEVEL DIRECTIONS
Whole chicken
Up to 4 lbs.
Cooking Time: 6-9 min. / lb.
180°F dark meat
170°F light meat
Place roast fat-side down on roasting
rack. Cover with wax paper. Turn
over half way through cooking. Let
stand 10 minutes.
Power Level:
Medium High(7).
Chicken pieces
Up to 2 lbs.
Cooking Time: 6-9 min. / lb.
180°F dark meat
170°F light meat
Place roast fat-side down on roasting
rack. Cover with wax paper. Turn
over half way through cooking. Let
stand 10 minutes.
Power Level:
Medium High(7).
Guide for cooking seafood in your microwave
Cook fish until it flakes easily with a fork.
Place fish on a microwave-safe roasting rack in a microwave-safe dish.
Use a tight cover to steam fish. A lighter cover of wax paper or paper towel provides less
steaming.
Do not overcook fish; check it at minimum cooking time.
FOOD COOK TIME/POWER LEVEL DIRECTIONS
Steaks
Up to 1.5 lbs.
Cooking Time:
6-10 min. / lb.
Arrange steaks on roasting rack with meaty
portions towards the outside of rack. Cover
with wax paper. Turn over and rearrange
when cooking time is half up. Cook until
fish flakes easily with a fork. Let stand 3-5
minutes.
Power Level:
Medium-High(7).
Fillets
Up to 1.5 lbs.
Cooking Time:
3-7 min. / lb
Arrange fillets in a baking dish, turning any
thin pieces under. Cover with wax paper. If
over ½ inch thick, turn over and rearrange
when cooking time is half up. Cook until
fish flakes easily with a fork. Let stand 2-3
minutes.
Power Level:
Medium-High(7).
Shrimp
Up to 1.5 lbs.
Cooking Time:
3-5½ min. / lb.
Arrange shrimp in a baking dish without
overlapping or layering. Cover with wax
paper. Cook until firm and opaque, stirring 2
or 3 times. Let stand 5 minutes.
Power Level:
Medium-High(7).
•
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 32 2007-06-25 10:57:22
05 COOKING INSTRUCTIONS
Cooking instructions _33
Guide for cooking eggs in your microwave
Never cook eggs in the shell, and never warm hard-cooked eggs in the shell; they can explode.
Always pierce whole eggs to keep them from bursting.
Cook eggs just until set; they become tough if overcooked.
Guide for cooking vegetables in your microwave
Vegetables should be washed just before cooking. Often, no extra water is needed. If dense
vegetables such as potatoes, carrots and green beans are being cooked, add about ¼ cup
water.
Small vegetables (sliced carrots, peas, lima beans, etc.) will cook faster than larger ones.
Whole vegetables, such as potatoes, acorn squash or corn on the cob, should be arranged in
a circle on the turntable before cooking. They will cook more evenly if turned over after half the
cooking time has passed.
Always place vegetables like asparagus and broccoli with the stem ends pointing towards the
edge of the dish and the tips toward the center.
When cooking cut vegetables, always cover the dish with a lid or vented microwavable plastic
wrap.
Whole, unpeeled vegetables such as potatoes, squash, eggplant, etc., should have their skin
pricked in several spots before cooking to prevent them from bursting.
For more even cooking, stir or rearrange whole vegetables halfway through the cooking time.
Generally, the denser the food, the longer the standing time. (Standing time refers to the time
necessary for dense, large foods and vegetables to finish cooking after they come out of the
oven.) A baked potato can stand on the counter for five minutes before cooking is completed,
while a dish of peas can be served immediately.
•
•
•
•
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 33 2007-06-25 10:57:22
34_ Cooking instructions
RECIPES
Beef and barley stew
1½ lbs. beef stew cubes, cut into ½-inch pieces
½ cup chopped onion
2 Tbs. all-purpose flour
1 Tbs Worcestershire sauce
1 can (13.75-14.5 oz.) beef broth
2 medium carrots, cut into ½-inch slices (about 1 cup)
½ cup barley
1 bay leaf
¼ tsp. pepper
1 pkg. (9-10 oz.) frozen peas, thawed
•
•
•
•
•
•
•
•
•
•
1. In a 2-quart casserole, combine beef, onion, flour, and Worcestershire; mix well. Cover with lid.
Cook at High for 6 to 8 minutes until beef is no longer pink, stirring once.
2. Stir in beef broth, carrots, barley, bay leaf, and pepper. Cover with lid. Cook at Medium for 1 to
1½ hours until carrots and beef are tender, stirring 2 to 3 times.
3. Stir in peas. Cover with lid. Cook at Medium for 10 minutes. Let stand for 10 minutes. Remove
bay leaf before serving.
Makes 6 servings.
Broccoli and cheese casserole
¼ cup butter or margarine
¼ cup chopped onion
1½ Tbs. flour
½ tsp. salt
¼ tsp. dry mustard
1/8 tsp. pepper
1½ cups milk
¼ cup chopped red pepper
8 oz. (2 cups) cheddar cheese, shredded
1 pkg. (9-10 oz.) frozen chopped broccoli, thawed
4 cups cooked spiral shaped pasta (8 oz. dry)
•
•
•
•
•
•
•
•
•
•
•
1. In a 2-quart casserole, cook butter and onion at High for 1 to 2 minutes until onion is soft,
stirring once.
2. Add flour, salt, mustard, and pepper; mix well. Cook at High for 30 to 60 seconds until mixture
boils. Stir in milk until smooth.
3. Stir in red pepper. Cook at High for 2 to 3 minutes until mixture boils and thickens slightly,
stirring twice. Stir in cheese until melted.
4. Add broccoli and pasta, mix well. Cover with lid. Cook at High for 4 to 6 minutes until heated
through, stirring once. Stir before serving.
Makes 6 servings.
SMH7185BG_XAC-GB.indd 34 2007-06-25 10:57:22
05 COOKING INSTRUCTIONS
Cooking instructions _35
Warm potato salad
2 lbs. small red potatoes, cut into ½-inch pieces
4 slices bacon (uncooked), cut into ½-inch pieces
¼ cup chopped onion
2 tsp. sugar
1 tsp. salt
1 tsp. flour
½ tsp. celery seed
1/8 tsp. pepper
2½ Tbs. apple cider vinegar
•
•
•
•
•
•
•
•
•
1. In a 2-quart casserole, combine potatoes and ¼ cup water. Cover with lid. Cook at High until
potatoes are tender (7-10 minutes); stir twice. Drain and set aside to cool slightly.
2. In a medium bowl, cook bacon at High until crisp (2½-3½ minutes); stir once. Place bacon on a
paper towel. Reserve 1 Tbs. drippings.
3. Combine drippings and onion. Cover with plastic wrap; turn back a corner to vent steam. Cook
at High until tender (1½-2½ minutes); stir once.
4. Stir in sugar, salt, flour, celery seed, and pepper. Cook at High until mixture boils (30-40
seconds). Stir in vinegar and ½ cup water. Cook at High until liquid boils and thickens slightly
(1-2 minutes); stir once. Add bacon to dressing. Pour dressing over potatoes. Stir well.
Makes 6 servings.
Black bean soup
1 cup chopped onion
1 clove garlic, minced
2 cans (15 oz. each) black beans, drained
1 can (14-16 oz.) stewed tomatoes, chopped
1 can (13.75-14.5 oz.) chicken broth
1 can (7-8.5 oz.) corn
1 can (4 oz.) chopped green chilies
1-2 tsp. ground cumin, or to taste
•
•
•
•
•
•
•
•
1. Place onion and garlic in a 3-quart casserole. Cover with lid. Cook at High for 2 to 4 minutes
until tender.
2. Add one can of beans, mash beans with a fork. Add remaining ingredients; mix well.
3. Cook uncovered, at High for 10 minutes; stir. Reduce power to Medium and cook for 5
minutes. Stir before serving.
Makes about 2 quarts.
SMH7185BG_XAC-GB.indd 35 2007-06-25 10:57:22
36_ Maintenance
maintenance
TROUBLESHOOTING
Before you call a repair person for your oven, check this list of possible problems and solutions.
PROBLEM SOLUTIONS
Neither the oven’s
display nor the oven
operate.
Properly insert the plug into a grounded outlet.
If the outlet is controlled by a wall switch, make sure the wall
switch is turned on.
Remove the plug from the outlet, wait ten seconds, then plug it
in again.
Reset the circuit breaker or replace any blown fuse.
Plug another appliance into the outlet; if the other appliance
doesn’t work, have a qualified electrician repair the outlet.
Plug the oven into a different outlet.
•
•
•
•
•
•
The oven’s display
works, but the power
won’t come on.
Make sure the door is closed securely.
Check to see if packing material or other material is stuck to the
door seal.
Check for door damage.
Press Cancel twice and re-enter all cooking instructions.
•
•
•
•
The power goes off
before the set time has
elapsed.
If there has not been a power outage, remove the plug from
the outlet, wait ten seconds, then plug it in again. If there was
a power outage, the time indicator will display: ENJOY YOUR
COOKING - - - PRESS MY CHOICE FOR PERSONAL OPTIONS.
Reset the clock and any cooking instructions.
Reset the circuit breaker or replace any blown fuse.
•
•
•
The food is cooked too
slowly.
Make sure the oven is on its own 20 amp circuit line. Operating
another appliance on the same circuit can cause a voltage
drop. If necessary, move the oven to its own circuit.
•
You see sparks or
arcing.
Remove any metallic utensils, cookware, or metal ties. If using
foil, use only narrow strips and allow at least one inch between
the foil and interior oven walls.
•
The turntable makes
noises or sticks.
Clean the turntable, roller ring and oven floor.
Make sure the turntable and roller ring are positioned correctly.
•
•
Using your microwave
causes tv or radio
interference.
This is similar to the interference caused by other small
appliances, such as hair dryers. Move your microwave further
away from other appliances, like your TV or radio.
•
If the oven is set to cook for more than 25 minutes, it will automatically adjust itself to 70
percent power after 25 minutes to avoid overcooking.
SMH7185BG_XAC-GB.indd 36 2007-06-25 10:57:22
06 MAINTENANCE
Maintenance _37
CARE AND CLEANING
Follow these instructions to clean and care for your oven.
Keep the inside of the oven clean. Food particles and spilled liquids can stick to the oven walls,
causing the oven to work less efficiently.
Wipe up spills immediately. Use a damp cloth and mild soap. Do not use harsh detergents or
abrasives.
To help loosen baked on food particles or liquids, heat two cups of water (add the juice of one
lemon if you desire to keep the oven fresh) in a four-cup measuring glass at High power for five
minutes or until boiling. Let stand in the oven for one or two minutes.
Remove the glass tray from the oven when cleaning the oven or tray. To prevent the tray from
breaking, handle it carefully and do not put it in water immediately after cooking. Wash the tray
carefully in warm sudsy water or in the dishwasher.
Clean the outside surface of the oven with soap and a damp cloth. Dry with a soft cloth. To
prevent damage to the operating parts of the oven, don’t let water seep into the openings.
Wash the door window with very mild soap and water. Be sure to use a soft cloth to avoid
scratching.
If steam accumulates inside or outside the oven door, wipe with a soft cloth. Steam can
accumulate when operating the oven in high humidity and in no way indicates microwave
leakage.
Never operate the oven without food in it; this can damage the magnetron tube or glass tray.
You may wish to leave a cup of water in the oven when it is not in use to prevent damage if the
oven is accidentally turned on.
How to clean the outside
Do not use cleaners containing ammonia or alcohol on the microwave oven. Ammonia or alcohol
can damage the appearance of the microwave.
Case Clean the outside of the microwave with a sudsy cloth. Rinse and then
dry. Wipe the window clean with a damp cloth.
•
Control panel
and door
Wipe with a damp cloth. Dry thoroughly. Do not use cleaning sprays,
large amounts of soap and water, abrasives or sharp objects on the
panel—they can damage it. Some paper towels can also scratch the
control panel.
•
Door surface It’s important to keep the area clean where the door seals against
the microwave. Use only mild, nonabrasive detergents applied with a
clean sponge or soft cloth. Rinse well.
•
Bottom
Clean off the grease and dust on the bottom often.
Use a solution of warm water and detergent.
•
•
•
•
•
•
•
•
•
•
•
SMH7185BG_XAC-GB.indd 37 2007-06-25 10:57:22
38_ Maintenance
LIGHT BULB REPLACEMENT
Cooktop light
Replace the burned-out bulb with a 40-watt incandescent bulb.
To replace the bulb(s), fi rst disconnect the power at the main fuse or circuit breaker panel or pull
the plug.
1. Remove the screw at the front of the light cover and lower the cover.
2. Be sure the bulb(s) to be replaced are cool before removing. After breaking the adhesive seal,
remove the bulb by gently turning. Put in new bulb.
3. Replace the light cover and screw. Connect electrical power to the oven.
Oven light
Replace the burned-out bulb with a 40-watt incandescent bulb.
To replace the oven light, fi rst disconnect the power at the main fuse or circuit breaker panel or
pull the plug.
1. Remove the top grille by taking out the 2
screws that hold it in place.
Next, remove the screw located above the
door near the center of the oven that secures
the light housing. Remove the housing and
bulb.
2. Insert new bulb. Replace the light housing
and screw.
3. Replace the top grille and 2 screws, Connect
electrical power to the oven.
Screw
SMH7185BG_XAC-GB.indd 38 2007-06-25 10:57:24
06 MAINTENANCE
Maintenance _39
THE VENT FAN
The exhaust fan has 2 metal reusable grease fi lter.
A charcoal fi lter can be used for removing smoke and odors in case the fan is not vented outside.
Grease lters
The metal fi lters trap grease released by foods on the cooktop. They also prevent fl ames from
foods on the cooktop from damaging the inside of the microwave.
For this reason, the fi lters must ALWAYS be in place when the vent fan is used. The grease fi lters
should be cleaned once a month, or as needed.
TO REMOVE, slide it to the left (or right) using the tab. Pull it down and out.
TO CLEAN THE GREASE FILTERS, soak
and then swish them around in hot water and
detergent.
Don’t use ammonia or ammonia products
because they will darken the metal.
Light brushing can be used to remove
embedded dirt.
Rinse, shake and let them dry before replacing.
TO REPLACE, slide the fi lters in the frame slot on the left (or right) of the opening. Pull up and to
the right (or left) to lock into place.
•
•
SMH7185BG_XAC-GB.indd 39 2007-06-25 10:57:26
40_ Maintenance
Charcoal lter
The charcoal fi lter cannot be cleaned. It must be replaced.
If the oven is installed on the wall(or cabinet) and not vented to the outside, the air will be
recirculated through a disposable charcoal fi lter that helps remove smoke and odors.
The charcoal fi lter should be replaced when it is noticeably dirty or discolored (usually after 6 to 12
months, depending on hood usage).
TO REMOVE THE CHARCOAL FILTER,
disconnect power at the main fuse or circuit
breaker panel or pull the plug.
Remove the top grille by removing the 2 screws
that hold it in place. Slide the fi lter towards the
front of the oven and remove it.
TO INSTALL A NEW FILTER, remove plastic
and other outer wrapping from the new fi lter.
Insert the fi lter into the top opening of the oven
as shown. It will rest at an angle on 2 side
support tabs and in front of the right rear tab.
Replace the grille and 2 screws.
SMH7185BG_XAC-GB.indd 40 2007-06-25 10:57:27
06 MAINTENANCE
Maintenance _41
SPECIFICATIONS
MODEL NUMBER SMH7185BG / SHM7185WG
Oven Cavity 1.8 cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Consumption 1500 Watts
Power Output 1000 Watts
Oven Cavity Dimensions 20
7
/8”(W) X 9
31
/32”(H) X 14
9
/16”(D)
Outside Dimensions 29
7
/8”(W) X 16
1
/2”(H) X 15
15
/32”(D)
Shipping Dimensions 33
3
/8”(W) X 19
15
/16”(H) X 19
13
/32”(D)
Net/Gross Weight 50.56/61.12 lbs
MODEL NUMBER SMH7185STG
Oven Cavity 1.8 cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Consumption 1500 Watts
Power Output 1000 Watts
Oven Cavity Dimensions 20
7
/8”(W) X 9
31
/32”(H) X 14
9
/16”(D)
Outside Dimensions 29
7
/8”(W) X 16
1
/2”(H) X 15
15
/32”(D)
Shipping Dimensions 33
3
/8”(W) X 19
15
/16”(H) X 19
13
/32”(D)
Net/Gross Weight 51.6/62.7 lbs
IF YOU HAVE A PROBLEM YOU CANNOT SOLVE, PLEASE CALL OUR SERVICE LINE:
1-800-SAMSUNG (7267864)
SMH7185BG_XAC-GB.indd 41 2007-06-25 10:57:28
42_ Warranty
warranty
SAMSUNG OVER-THE-RANGE(OTR) MICROWAVE OVEN
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by Samsung Electronics Canada, Inc. and delivered new, in the
original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials
and workmanship for a limited warranty period of:
ONE (1) YEAR PARTS AND LABOR, TEN (10) YEARS PARTS WARRANTY FOR MAGNETRON
This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the Canada.
To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures.
Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be
presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned
parts or products if found to be defective during the limited warranty period specied above. All replaced parts and products
become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the
remaining original warranty, or ninety (90) days, whichever is longer.
In-home service will be provided during the warranty labor period subject to availability within the Canada. In-home service is
not available in all areas. To receive in-home service, the product must be unobstructed and accessible to service personnel.
If during in-home service repair can not be completed, it may be necessary to remove, repair and return the product. If in-
home service is unavailable, SAMSUNG may elect, at our option, to provide for transportation of our choice to and from a
SAMSUNG authorized service center. Otherwise, transportation to and from the SAMSUNG authorized service center is the
responsibility of the purchaser.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial
use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment;
delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers;
cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products,
equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or
connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect
electrical line voltage, uctuations and surges;
customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instructions that
are covered and prescribed in the instruction book; problems caused by pest infestations, and overheating or overcooking
by user; glass tray or turntable; reduced magnetron power output related to normal aging. SAMSUNG does not warrant
uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED
ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION
WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR
LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT,
REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER
IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED
DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE
OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT
OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE
NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some province do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal
rights, and you may also have other rights which vary from state to state.
To obtain warranty service, please contact SAMSUNG at:
1-800-SAMSUNG (7267864) and www.samsung.com/ca
SMH7185BG_XAC-GB.indd 42 2007-06-25 10:57:28
SMH7185BG_XAC-GB.indd 43 2007-06-25 10:57:28
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
IN CANADA 1-800-SAMSUNG (7267864) www.samsung.com/ca
DE68-00356X
SMH7185BG_XAC-GB.indd 44 2007-06-25 10:57:28
