User Manual Bosch WAT24440AU Washer

Documents for Bosch WAT24440AU

The following documents are available:
User Manual

User Manual - (English) Read Online | Download pdf

Photos

Photos: View Photos

User Manual

For WAT24440AU. Also, The document are for others Bosch models: WAT...

en Instruction Manual and Installation Instructions

Washing machine

WAT...

Loading ...

Summary of Contents for Bosch WAT24440AU:

Your new washing machine2
Display rules2
: Warning!2
Caution!2
Note/tip2
1. 2. 3. / a) b) c)2
Contentsen Instruction Manual and Installation Instructions3
- 8 Intended use 43
- ( Safety instructions 53
- 7 Environmental protection 73
- 5 Positioning and connecting 83
- * Getting to know the appliance 163
- Z Laundry 193
- C Detergent 203
- 0 Programme default settings 213
- \ Additional programme settings 233
- 1 Operating the appliance 243
- H Sensors 294
- M Setting the signal 304
- 2 Cleaning and maintenance 304
- 3 Faults and what to do about them 334
- 4 After-sales service 384
- J Technical data 384
- r Aqua-Stop warranty 394
- 8 Intended use4
  - Intended use4
Children must not perform cleaning or maintenance work unsupervised.4
- ( Safety instructions5
- 7 Environmental protection7
Overview of programmes7
~ Supplementary sheet for the operating and installation instructions.7
The display provides information about the relative energy consumption in the selected program.7
The more indicator lights light up, the higher the program's consumption.7
This enables you to compare the consumption levels of the different programs when choosing your program settings and to decide on an energy- and water-saving program setting for the selected program.7
Energy-saving mode is not activated if a programme is running.7
- 5 Positioning and connecting8
- 1. Take the hoses out of the holders.10
  - 2. Unscrew and remove all four transport brace screws.10
Remove the sleeves. To do this, remove the mains cable from the holders.10
- 3. Fit the covers. Lock the covers firmly in place by applying pressure to the snap-in hooks.10
- Hose and cable lengths11
  - Tip:11
- Water inlet11
- Water outlet12
Make sure that:13
The connection point must be secured using a hose clamp with a diameter of 24-40 mm (available from specialist dealers).13
- Levelling13
- 1. Loosen the lock nuts using a wrench, by turning it in a clockwise direction.13
  - 2. Check the alignment of the washing machine with a spirit level, and adjust it if necessary. Change the height by turning the appliance feet.13
All four appliance feet must stand firmly on the ground.13
- 3. Tighten the lock nut against the housing.13
In doing so, hold the foot tight and do not adjust its height.13
The lock nuts on all four appliance feet must be screwed tightly against the housing.13
- Electrical connection13
- Before washing for the first time14
  - Notes14
- 1. Check the machine.15
- 1. Turn off the water tap.15
  - 2. Reduce the water pressure in the supply hose.15
Maintenance – filter in the water supply ~ Page 3215
- 3. Disconnect the washing machine from the main plug.15
- 4. Drain the remaining detergent solution.15
Maintenance – detergent solution pump blocked ~ Page 3115
- 5. Remove the hoses.15
- Installing the transport locks:15
- 1. Remove the covers and keep them in a safe place.15
Use a screwdriver if necessary.15
- 2. Insert all four sleeves.15
Clip the mains cable securely in the holders. Insert and tighten the screws.15
- Notes15
* Getting to know the appliance16
- Getting to know the appliance16
- Washing machine16
- Control panel17
  - Note:17
- Display panel17
  - Button17
  - Display indicator17
  - Description17
- More information on the display panel18
  - Display indicator18
  - Description18
  - Z Laundry19
- Wash laundry with the same level of soiling together.19
- You can find examples of levels of soiling on ~ Page 2119
- The numbers in the symbols indicate the maximum washing temperature which may be used.19
  - Starching19
    - Note:19
  - Dyeing/bleaching20
  - Soaking20
  - 1. Pour soaking agent/detergent into compartment II in accordance with the manufacturer's instructions.20
- Suitable for boil-washable white laundry made from linen or cotton20
- Programme: Cottons/20
- cold - max. 90 °C20
- Suitable for coloured laundry made from linen or cotton20
- Programme: Cottons/20
- cold - max. 60 °C20
- Suitable for coloured laundry made from easy-care fibres, synthetic fibres20
- Programme: Easy-Care/20
- cold - max. 60 °C20
- Suitable for delicate, fine fabrics, silk or viscose20
- Programme: Delicate/Silk/20
- cold - max. 40 °C20
- Suitable for wool20
- Programme: Wool/20
- cold - max. 40 °C20
  - Saving energy and detergent21
  - 0 Programme default settings21
  - To do this:22
  - 1. Select a program.22
- The program duration is displayed for the selected program, e.g. 2:30 (hours:minutes).22
  - 2. Press the Finished in-time button repeatedly until the required number of hours is displayed.22
  - 3. Press the A button.22
- The door will be locked.22
- The selected number of hours (e.g. 8 h) is shown in the display panel and counts down until the wash program starts. The duration of the program is then displayed.22
  - During the timer count-down, you can change the preselected number of hours as follows:22
  - 1. Press the A button.22
  - 1. Press the A button.22
- Washing in a shorter time while achieving a washing result that is consistent with, but uses more energy than the selected program without the Speed setting.23
  - Note:23
- Energy-optimised washing by reducing the temperature while achieving a washing result that is consistent with the selected program without the Eco setting.23
  - Easy-Iron23
    - Note:23
  - Prewash23
    - Note:23
  - Water Plus23
  - Rinse Plus23
  - 1 Operating the appliance24
    - Operating the appliance24
    - Preparing the washing machine24
      - Note:24
  - 1. Connect the mains plug.24
  - 1. Place presorted items of laundry unfolded in the washing drum.25
    - 2. Make sure that no items of laundry are trapped between the washing machine door and the rubber seal, and close the door.25
    - The A button indicator lamp flashes to indicate that the washing program can be started. It is possible to change the settings. ~ "Dyeing/bleaching" on page 20~ "Spin speed" on page 2125
      - Measure and add detergent and care products25
        Caution!25
        Damage to the appliance25
        : Warning25
        Eye/skin irritation!25
        Note:25
  - 1. Pull out the detergent drawer as far as possible.26
  - 1. Pull out the detergent drawer. Press down the insert and fully remove the drawer.26
  - 1. Press the A button.27
  - 1. Press the A button.27
  - 1. Press the A button.27
  - 1. Open the door and remove the laundry.28
  - Activating the setting mode30
    - 1. Select the i Cottons program at position 1. The washing machine is switched on.30
    - 1. Pull out the detergent drawer. Press down the insert and fully remove the drawer.31
  - After the water has cooled down:31
    - 1. Turn off the water tap so that no more water can flow in and has to be drained via the drain pump.31
- Remove the sealing cap, allow the water to flow out into a suitable container.31
- Replace the sealing cap and place the drainage hose in the retainer.31
  - 6. Carefully unscrew the pump cover, residual water may leak out.31
- Clean the interior, pump cover thread and pump housing. The impeller in the detergent solution pump must be able to rotate.31
- Refit the pump cover and screw it on tightly. The handle must be in a vertical position.31
  - 7. Place the service flap back on, lock it into place, and close it.32
  - Note:32
  - The drain hose at the siphon is blocked32
  - 1. Switch off the appliance.32
  - 1. Turn off the tap.32
- Disconnect the hose from the tap.32
- Clean the filter with a small brush.32
  - 7. For standard and Aqua-Secure models, clean the filter on the rear of the appliance:32
- Remove the hose from the rear of the appliance.32
- Use pliers to remove the filter and then clean it.32
  - 8. Insert the filter, connect the hose and check for leaks.32
  - 3 Faults and what to do about them33
    - Faults and what to do about them33
    - Emergency release33
      - Note:33
        : Warning33
        Risk of scalding!33
        : Warning33
        Risk of injury!33
        Caution!33
        Water damage33
  - If the laundry has to be removed, the washing machine door can be opened as follows:33
    - 1. Switch off the appliance.33
- The washing machine door can now be opened.33
  - Information on the display panel34
  - Faults and what to do about them35
  - You can find this information:38
- Our warranty does not cover defective feed lines or fittings leading to the Aqua-Stop connection at the tap.39
  - 4. Appliances with Aqua-Stop do not need to be supervised during operation, nor secured afterwards by turning off the tap.39
- The tap only needs to be turned off if you are away from home for a long period, e.g. for several weeks' holiday.39
