AirInstinct
Air Purier
Important!
Read this manual
carefully, and
keep for future
reference.
User’s
Guide
Model:
AIR75B
TM
2
Other Oreck accessories available at:
Other Oreck accessories available at:
Congratulations on your purchase of the Oreck AirInstinct
TM
Air Purier. Use this manual to learn the features, operation
and maintenance of the Oreck Air Purier.
Welcome to our Call. Click. customer service program. To
speak with an Oreck representative call:
Enjoy
Click
Call
USA: 1•800•989•3535
Canada: 1•888•676•7325
On the web, point and click at: www.oreck.com
and click locate a store on the top right.
3
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
General Warnings . . . . . . . . . . . . . . . . . . . . . . . 4
Placement Warnings . . . . . . . . . . . . . . . . . . . . . . 5
Features ................................6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance .............................9
Cleaning and Filter Replacement Intervals . . . 10
Replacing the lters .......................11
Filter Reset Mode........................ 12
Forced Reset Mode . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning the Air Sensor . . . . . . . . . . . . . . . . . . 13
Adjusting the Air Sensor .................. 14
Troubleshooting15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4
Safety
General Warnings
• Do not operate unit if cord or plug is damaged. Doing so can
result in electric shock. Discard the damaged unit or take
it to an authorized service facility for examination and/or
repair. USA: 1•800•989•3535 Canada: 1•888•676•7325
• Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or similar coverings. Do not route
cord under furniture or appliances. Arrange cord away
from traffic area and where it will not be tripped over.
• Only use the air purifier as described in this manual.
• Do not handle the unit with wet hands. Thoroughly dry
your hands before handling any part of the air purifier.
• Hair, loose clothing and body parts can get caught in the
machine resulting in injury. Keep hair, loose clothing and
body parts away from openings and moving parts.
• Do not unplug by pulling on the cord. Doing so may result
in electrical spark or fire. Unplug the unit by grasping, and
pulling the plug.
• Do not use an extension cord.
• Do not place the air purier near sources of heat, such as:
stove tops, ovens, radiators or computers.
• Unplug the appliance from the power supply before
servicing.
• This equipment should be inspected frequently and the dirt
that has collected should be removed regularly to prevent
excessive accumulation that may result in flashover or fire.
• Do not use the air purier outdoors or on wet surfaces.
• Do not use the air purier in an enclosed space where
flammable, combustible or explosive gases are present.
!
WARNING: To reduce the risk of re, electric shock or
injury, read and understand this user guide before operating
this appliance.
Cleaning the unit while it is plugged in may
result in electric shock, electric spark and
serious injury. Unplug the unit before cleaning
or maintenance
IMPORTANT SAFETY
INSTRUCTIONS
5
• Do not use in an area where toxic vapors, ammable dust
or oxygen tanks are present. Check the location and make
sure these elements are not present.
• Warning: Product contains chemicals known to the State
of California to cause cancer, birth defects, or other
reproductive harm.
• Do not place open flames, including candles, directly in
front of the air purifier.
• It is important to keep all objects away from the air intake
grille.
• Place the air purier on a at, solid, stable surface. Never
place the unit on soft surfaces such as a bed or sofa.
• Position the air purier so that the dirty air is not drawn
across your head or body while sitting or sleeping.
• Place the air purier so the plug on the power cord easily
reaches a standard electrical outlet for a polarized plug.
• Children should be supervised when product is in use. Do
not allow children to play on or near the air purifier. Keep
children’s hair, loose clothing, and body parts away from/
out of the intake grille, vents, holes, or openings.
• This product is suitable for use with solid-state speed
controls.
READ AND SAVE THESE
INSTRUCTIONS
Note: To reduce the risk of electric shock this product has a
polarized plug (one blade wider than the other). The plug will
only fit in a polarized outlet only one way. If the plug does
not fit properly, reverse the plug. If it still does not fit, contact
qualied personnel to install the proper outlet. Do not alter
the plug in any way.
6
Features
1 Display Panel: Air purier controls and indicator lights.
2 Power Button: Turns the purier On and Off.
3 A U T O M o de a nd S p e e d B u t t o n : Auto Mode automatically
adjusts the fan speed. Speed button manually sets the
fan speed to low, medium or high.
4 Check Filter Light: Indicates the lters may need to be
replaced.
5 Air Indicator: Visually displays either a blue, purple, or
red light based on the level of particles detected by the
Air Sensor.
6 Timer Button: Turns unit off after a predetermined
period of time. Time settings are 1, 4 and 8 hours.
7 Air Sensor: Measures the level of particles passing
through the sensor.
8 Front Grille: Air enters here for the rst stage of cleaning.
9 Handle: Use handle to move the purier.
2
3
4
5
6
7
8
1
7
10 Exhaust Grille: Directs the ow of air as it exits the unit.
11 Power Cord: Plug into the outlet to begin use.
12 Pre-lter: Filters large particles such as dust, hair and
lint that pass through the lter.
13 Odor Filter: Reduces odors and VOC’s from the air that
passes through the lter.
14 HEPA Filter: Captures dust, allergens, pet dander, mold
and smoke from the air that passes through the lter.
9
11
12
13
14
10
8
Operation
1 Place Place the air purier on a solid surface. Do not
block the grille with objects and remove candles or
ames near the unit.
2 Plug In Plug into the nearest standard electrical outlet
that accepts a polarized plug.
3 Press T he power button turns the purier On. Press and
hold the POWER button approximately two seconds to
turn the purier OFF.
4 Select Choose the desired air cleaning mode (manual or
automatic) and the fan speed. The fan speed is controlled
manually in manual mode or by the Air Sensor in the
automatic mode.
Note: Make sure to open cover and remove each lter’s
plastic packaging before turning unit on. Order of
lters: pre-lter, odor lter, Hepa lter
2
3
4
9
Automatic (AUTO) Mode
Important: The Air Sensor is set to standard sensitivity
when shipped from the factory. If you prefer the air purier
to adjust its speed more or less frequently, you can set the
sensitivity of the Air Sensor (see page 14).
A Press the button to set the purifier in automatic
mode. In automatic mode the air purier will self-adjust
the fan speed. The Auto mode indicator light will illuminate
after the highest speed setting is pushed.
B The indicator light will show when unit has reached
auto mode.
Press the button to set the purier in automatic mode.
In automatic mode the air purier will self-adjust the fan
speed. The auto mode indicator light will illuminate after
the highest speed setting is pushed.
Manual Mode
A Press and release the button for the desired fan
speed: Lowee , Medium , High .
B The indicator lights will display the speed.
Maintenance
B
A
B
A
10
WARNING !
!
Cleaning the unit while it is plugged in may
result in electric shock, electric spark and
serious injury. Unplug the unit before cleaning
or maintenance
Cleaning and Filter Replacement Intervals
Proper care and cleaning of the air purier is critical to
performance. The following chart shows the recommended
cleaning intervals and method.
Part Time Method
Cabinet As needed Wipe with damp cloth rst.
If required, follow with mild,
non-abrasive cleaner.
Air Inlet
and Outlet
Every two
months
Brush with soft brush. Do not
allow dust to fall inside the
purier.
Air Sensor Every two
months
See page 13 for instructions.
Pre-Filter Two to four
weeks
Rinse thoroughly in warm
water as needed. Let dry
before reinstalling.
Odor Filter 1 year
*
Replace
HEPA Filter 2 years
*
Replace
*
Filter life will vary by usage and environment.
11
Replacing the Filters
IMPORTANT: A lways remove the protective plastic
packaging from the lter before installing the lter.
1 Unplug the air purier.
2. Open the cover by gently pulling from the bottom corners.
3 Press the two hooks above the pre-lter, pull straight out
of the cabinet. Remove the used odor lter and HEPA
lter. Thoroughly rinse the pre-lter and let it air dry
before placing it back in the cabinet. Note: Do not
use heated or compressed air as part of the drying
process.
4 Remove the plastic bag from the lters.
5
Place the lters back in the cabinet in the following
order: HEPA lter, odor lter, and pre-lter.
Note: Insert odor filter into the pre-filter
frame before inserting into the unit.
6 Replace the cover by connecting at the top and securing
at the bottom.
2
4 5 6
3
12
Filter Reset Mode
1 When the indicator light comes on, the odor, Hepa or
both indicator lights will illuminate; indicating which
lter needs to be replaced.
2 After installing a new or replacement lter, press and hold
the reset button for approximately two seconds.
Forced Reset Mode
If you have replaced a lter before the lter replacement
light is illuminated:
1 Press and hold the reset button for 2 seconds.
2 Push the reset button to select the desired lter to forcibly
reset. Push once for odor lter and twice for the Hepa
lter.
3 To complete forced reset, press and hold the reset button
for approximately 2 seconds.
If 10 seconds have passed in the forced reset mode, the
forced reset mode is cancelled.
*
Filter life will vary by usage and environment.
2
1
1
13
Cleaning the Air Sensor
1 Open the air sensor cover on the side of the product.
2
Clean the air inlet, outlet vents, and air sensor.
Air outlets
Air inlets
3
Wet a cotton swab lightly and clean the lens, dust inlet,
and dust outlet. After cleaning, use a dry cotton swab to
remove any moisture.
Dust outlet
Dust outlet
Note: Without regular cleaning, the sensor will decline in
performance.
WARNING !
!
Cleaning the unit while it is plugged in may
result in electric shock, electric spark and
serious injury. Unplug the unit before cleaning
or maintenance
14
Adjusting the Air Sensor
The purier is shipped with the Air Sensor set to standard
sensitivity. Adjust the sensitivity of the sensor if you want
the air purier to adjust its fan setting in Auto Mode to more
or less frequently.
To adjust the sensitivity of Air Sensor:
1 Turn the power On.
2 Press and hold the Auto/Speed button for two seconds.
3 The speed indicator blinks according to the current
sensitivity of the air sensor.
4 Press the Auto/Speed button for the desired sensitivity.
5 Press and hold the Auto/Speed button for two seconds to
set the sensor.
Note: If ten seconds have passed while in the setting
mode the new setting will automatically be set.
Low Medium High
Sensitive Standard Insensitive
1
2
3
4
15
Problem Check Solution
Unit does not turn
ON.
• Power Cord
• Cover
• Plug in power cord.
• Make sure that the cover is
securely closed.
• Check electrical outlet.
No air is blowing. • Power Cord
• Is the power On?
• Plug in power cord.
• Press and hold the POWER
button to turn On.
Airow speed is
weak.
• Filters • Check the lters. Replace
if necessary.
• Were the plastic bags
removed from lters?
Color of Mood
Light is always the
same.
• Purple or Red
• Blue
• Adjust the sensitivity of the
air sensor to less sensitive
or standard.
• Adjust the sensitivity of the
air sensor to more sensitive
or standard.
Unit does not
capture particles.
• Filters • Check the lters. Replace
if necessary.
• Unit may be damaged
Contact Oreck for service.
Unit still does not
operate properly.
Review all of the above Contact Oreck for service.
Trouble-
shooti ng
Service problems that appear to be major can often be solved
easily. You can be your own troubleshooter by reviewing,
this guide.
All other servicing should be done by an Oreck
authorized service center.
16
Warranty
ORECK M A N U FACTU R I NG COMPAN Y: (Oreck Ma nufact u r i ng
Company gives you the following limited warranty for this product
only if it was originally puchased by you for residential use, not for
resale, from Oreck or an Oreck Authorized Retail Dealer.)
Oreck will repair or replace, free of charge, to the original
purchaser, any part that is found to be defective in material or
workmanship within three (3) years following the date of purchase
for all residential models. NOTE: If the unit is used commercially,
a one (1) year overall warranty applies.
This limited warranty does not cover the replacement of
expendable or consumable parts such as lters, cartridges, and
other parts subject to normal wear unless they are defective in
material or workmanship.
This limited warranty does not apply to any part subjected to
accident, abuse, commercial use, alteration, misuse, damage
caused by act of God, the use of voltages other than on the data
plate of this product or service of this product by other than Oreck
or a participating Factory Authorized Service Center.
Oreck does not authorize any person or representative to assume
or grant any other warranty obligation with the sale of this product.
Oreck’s limited warranty is valid only if you retain proof of
purchase from Oreck or an Oreck Authorized Retail Dealer for
this product. If you purchase this product from any other source,
your purchase is “AS IS,” which means Oreck grants you no
warranty, and that you, not Oreck, assume the entire risk of the
quality and performance of this product, including the entire cost
of any necessary servicing or repairs of any defects.
Oreck’s liability for damages to you for any costs whatsoever
arising out of this statement of limited warranty shall be limited to
the amount paid for this product at the time of original purchase,
and Oreck shall not be liable for any direct, indirect, consequential
or incidental damages arising out of the use or inability to use this
product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES OTHER THAN
THE LIMITED WARRANTY SET FORTH ABOVE, FOR
THIS PRODUCT, INCLUDING IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE EXPRESSLY DENIED.
If there is an issue with your air purier that you believe is covered
by this warranty, contact Oreck customer service at 1-800-989-
3535. This warranty gives you specic legal rights, and you may
also have other rights which vary from state to state.
17
18
19
© 2011 Oreck Holdings, LLC.
All rights reserved. All marks, text, logo’s, product
configurations and registered trademarks are owned
and used under the authority of Oreck Holdings, LLC.
22103-02 12/11 ECN # R-10883
