Wide-Mouth, 2-Speed Centrifugal Juicer with Juice Jug and
Pulp Container, Stainless Steel
Extractor de Jugos Centrífugo de 2Velocidades y Boca Ancha,
con Jarra para Jugo y Depósito de Pulpa
Extracteur de Jus par Centrifugation à 2Vitesses et Large
Ouverture avec Carafe à Jus et Récipient à Pulpe
B07VGG1DDY
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3
EN
IMPORTANT SAFEGUARDS
Read these instructions carefully and retain them for future
use. If this product is passed to a third party, then these
instructions must be included.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to
persons including the following:
CAUTION
Risk of electric shock! Unplug from outlet when
not in use, before putting on or taking off parts,
andbeforecleaning.
CAUTION
Risk of injury! Never insert any body parts (e.g. fingers)
or kitchen utensils into the feeding chute. Always use
the pusher.
• Read all instructions.
• To protect against risk of electrical shock do not put in water or
otherliquid.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they are closely supervised and
instructed concerning use of the appliance by a person responsible
for their safety. Close supervision is necessary when any appliance
is used by or near children. Children should be supervised to ensure
that they do not play with the appliance.
• Turn the appliance OFF, then unplug from the outlet when not in
use,before assembling or disassembling parts and before cleaning.
To unplug, grasp the plug and pull from the outlet. Never pull from
thepower cord.
• Avoid contacting moving parts.
• Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or is dropped or damaged in any
manner. Return appliance to the nearest authorized service facility
forexamination, repair or electrical or mechanical adjustment.
• The use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter.
• Do not let cord contact hot surface, including the stove.
4
EN
• Always make sure juicer cover is clamped securely in place before
motor is turned on. Do not unfasten clamps while juicer is in operation.
• Be sure to turn switch to OFF position after each use of your juicer.
Make sure the motor stops completely before disassembling.
• Do not put your fingers or other objects into the juicer opening while
it is in operation. If food becomes lodged in opening, use food pusher
or another piece of fruit or vegetable to push it down. When this
method is not possible turn the motor off and disassemble juicer
toremove the remaining food.
• Do not use the appliance if the rotating sieve is damaged.
• Do not operate without the pulp container in place.
• This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug will fit outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not modify the plug
in any way.
DO NOT DRAPE CORD!
KEEP AWAY FROM
CHILDREN!
SAVE THESE INSTRUCTIONS
Intended Use
• The product is intended for juicing fresh fruits and vegetables with
two different speed settings.
• This product is intended for household use only. It is not intended
forcommercial use.
• This product is intended to be used in dry indoor areas only.
• No liability will be accepted for damages resulting from improper use
or non-compliance with these instructions.
5
EN
Product Description
A Pusher F Pulp container
B Cover with feeding chute G Housing
C Sieve H Juice jug
D Juice collector with spout I Speed knob 0/1/2
E Clamp J Power cord with plug
A
B
C
D
F
E
G
J
H
I
6
EN
Before First Use
• Check for transport damages.
• Clean the product before first use.
• Before connecting the product to the power supply, check that the
power supply voltage and current rating corresponds with the power
supply details shown on the product rating label.
DANGER
Risk of suffocation! Keep any packaging materials away
from children – these materials are a potential source of danger, e.g.
suffocation.
Assembly
Step 1:
NOTICE
For disassembling, proceed in a reverse order (last step first).
D
G
7
EN
Step 2:
Step 3:
G
C
F
8
EN
Step 4:
Step 5:
NOTICE
The product does not operate if the clamp (E) is not
properly engaged.
B
E
9
EN
Operation
Switching on/off
CAUTION
Risk of injury! Check the sieve before every use.
Do not use the product if any cracks or damage is present.
CAUTION
Risk of injury! Do not insert any body parts (e.g. fingers)
or kitchen utensils into the sieve (C). Always use the provided pusher only.
• Place the product on a firm, level surface away from the surface edge.
• Connect the plug (J) to a suitable socket outlet.
• Place the juice jug (H) under the chute.
• Switch the product on by turning the speed knob (I) to 1 or 2.
• Place the fruits/vegetables in the feeding chute (B) and use the
pusher (A) to gently press them down.
• Switch the product off by turning the speed knob (J) to 0.
Tips
Speed
setting
Ingredients Quantity Time
1
Soft fruits/vegetables: grapes,
melons, plums, peaches,
tomatoes
3 lb
(≤ 1.5 kg)
60 sec.
2
Hard fruits/vegetables: carrots,
celery, beetroot, apples,
pineapple, fennel
• The juicer is not suitable for processing very hard and/or fibrous or
starchy fruits or vegetables such as sugar cane.
1 2
3
4
J
I
A
H
10
EN
• Fruit that contain starch such as bananas, papayas, avocados, figs
and mangoes are not suitable for processing in the juicer. Use a food
processor, blender or hand blender to process these fruits.
• Do not exert too much pressure on the pusher (A), as this could
affect the quality of the juice. It could also cause the sieve (C)
to come to a halt.
• Remove hard seeds from cherries, plums, peaches, etc. The cores
or seeds from fruits like melons, apples and grapes do not have
to be removed.
•
Remove tough skins from melons, pineapples, cucumbers, potatoes etc.
• Soft-skinned and other foods just need washing (apples, pears,
carrots, radishes, lettuce, cabbage, parsley, spinach, grapes,
strawberries, celery etc.).
• Insert soft fruits/vegetables slowly to get the most juice.
• Vitamins disappear, the sooner you drink your juice, the more
vitamins you will absorb.
• When storing the juice for a few hours put it in the refrigerator.
• Juice from dark vegetables (broccoli, spinach etc.) or dark vegetables
(beetroot, red cabbage etc.) is extremely strong - always dilute it.
• Avoid reaching the Pulp container’s (F) maximum capacity. Otherwise,
the pulp might end up in the sieve (C), juice collector (D), cover (B)
and the juice.
NOTICE
The product is equipped with a thermal protection device.
If the product overheats, it switches off automatically. Unplug the product
and let it cool down to room temperature before resuming operation.
Cleaning and Maintenance
WARNING
Risk of electric shock! To prevent electric shock,
unplug before cleaning.
WARNING
Risk of electric shock! During cleaning do not immerse
the electrical parts of the product in water or other liquids. Never hold the
product under running water.
CAUTION
Risk of cuts! The sieve has tiny blades at the base.
Handle it carefully while cleaning.
11
EN
Cleaning
NOTICE
For hygienic reasons, it is best to clean the juicer’s
accessories immediately after use.
• Dry the product after cleaning.
• Never use corrosive detergents, wire brushes, abrasive scourers,
metal or sharp utensils to clean the product.
Cleaning the sieve
• Carefully clean the sieve (C) with a cleaning brush in warm water with
some washing-up liquid. Rinse it with fresh water.
C
12
EN
Storage
• Wind the power cord (J) onto cord compartment on the bottom of
the housing (G).
• Store the product in its original packaging in a dry area. Keep away
from children and pets.
Maintenance
• Any other servicing than mentioned in this manual should be
performed by an authorized service representative.
Specifications
Rated voltage: 120V~, 60Hz
Rated power: 600 W
Power at speed setting 1: 220 W ±10 %
Power at speed setting 2: 320 W ±10 %
Juice cup capacity: approx. 42,3 fl.oz (1.25 L)
Pulp container capacity: approx. 50.7 fl. oz (1.3 L)
Net weight: approx. 8 lb (3.65 kg)
Dimensions (D x W x H):
approx. 11.4 x 8.6 x 15.4"
(290 x 210 x 390mm)
