Assembling
1
Assemble the poles and stand base in order of .
Take care not to pinch the power cord between the poles.
Route the power cord between two rubber feet under the stand base.
Preventing tipping over by securing to the
wall
1
Drive the wall strap screw (supplied) into a solid wall.
Drive the wall strap screw at a height of 70 cm (27
5
/
8
inches) to 80 cm
(31
1
/
2
inches) above the floor.
2 From the mounting plate, pass the stand through the larger loop of
the wall strap (supplied).
3 Hook the smaller loop of the wall strap onto the wall strap screw.
Checking the contents
•Floor stand (1)
Power cord connector
Stand base
Power cord
Poles
Mounting plate
Charge contact
Quick release
•Wall strap (1) •Wall strap screw (1) •Hex key (1.5 mm) (1)
•Warranty (1) •Operating Instructions (this document) (1)
Use the AC adaptor supplied with the LSPX-P1 projector.
Continued
4-582-834-11(1)
Floor Stand
Operating Instructions
©2016 Sony Corporation
Printed in China
LSPX-PS1
