Contents
Introduction
Safety Warnings ............................................................................. 6
System Components and Controls ............................................... 7
Loading the map disc..................................................................... 9
Navigation
Before Use..................................................................................... 12
Starting Up the Navigation System ............................................ 16
Volume .......................................................................................... 18
Markers and Controls Displayed on Maps ................................. 19
Screens During Route Setting.................................................................. 19
Screens During Route Guidance ............................................................. 21
Menu Screen Keys and Functions ............................................... 22
Map Operations............................................................................ 24
Selecting Map Orientation ........................................................................ 24
Changing Map Scale.................................................................................... 25
Setting Route................................................................................ 27
Setting Destination...................................................................................... 27
■ Setting destination/waypoints by scrolling the map.................................................... 27
■ Setting the destination from the navigation menu....................................................... 29
Route Guidance ............................................................................ 43
Route Guidance Screen .............................................................................. 43
Zoom-in Map at Intersection.................................................................... 44
Dual Map Display.......................................................................................... 45
Freeway Information................................................................................... 46
Replaying Voice Guidance ........................................................................ 47
Compass Mode ............................................................................................. 48
Route Options .............................................................................. 49
Setting Route Options................................................................................ 49
■ Search condition................................................................................................................................... 50
■ Detour.......................................................................................................................................................... 51
■ Route preferences................................................................................................................................ 52
■ Destination and waypoints ............................................................................................................ 52
■ Display route............................................................................................................................................ 56
■ Route preview......................................................................................................................................... 57
Navigation Setup ......................................................................... 60
Setting Your Navigation System............................................................. 60
■ User settings............................................................................................................................................ 61
■ Quick POI selection.............................................................................................................................. 63
■ Language Selection ............................................................................................................................ 64
■ Calibration................................................................................................................................................. 64
■ Set clock...................................................................................................................................................... 66
■ Vehicle signal........................................................................................................................................... 67
■ Restore system defaults.................................................................................................................... 67
Stored Locations .......................................................................... 69
■ Memory points....................................................................................................................................... 70
■ Avoid area.................................................................................................................................................. 75
■ Previous destination (deleting stored locations).............................................................. 77
Other Functions............................................................................ 79
■ Displaying POIs on a map ............................................................................................................... 79
■ Displaying POI data............................................................................................................................. 81
■ Deleting POI markers.......................................................................................................................... 82
■ Editing Quick POI categories......................................................................................................... 82
■ SUBARU dealership search.............................................................................................................. 84
2
Version and Initialization ............................................................ 87
Version.............................................................................................................. 87
Initialization of the navigation settings................................................ 88
General Information .................................................................... 90
When a Problem Occurs............................................................................. 93
Audio and Visual
Before using the Audio and Visual.............................................. 96
Precautions when using the system...................................................... 96
Discs that can be used ................................................................................ 99
Player.............................................................................................................. 101
Character information displayed ......................................................... 102
Basic operation of the Audio and Visual .................................. 103
Name of each part..................................................................................... 103
Turning on the power .............................................................................. 106
Selecting the source ................................................................................. 107
■ Pressing the button for selection............................................................................................ 107
■ Making a selection by touching .............................................................................................. 109
Setting and adjusting the sound ......................................................... 110
■ Adjusting the sound volume..................................................................................................... 110
■ Turning off the sound .................................................................................................................... 110
Handling the disc....................................................................................... 111
■ Setting the disc................................................................................................................................... 111
■ Taking out the disc........................................................................................................................... 112
Listening to the radio................................................................. 113
Listening to the radio............................................................................... 113
■ FM radio screen displayed........................................................................................................... 113
■ AM radio screen displayed.......................................................................................................... 114
Selecting a station...................................................................................... 116
■ Selecting a station that is preset.............................................................................................. 116
■ Setting the frequency..................................................................................................................... 116
■ Searching a station automatically........................................................................................... 117
■ Searching a FM station from a category of interest..................................................... 117
Presetting a station.................................................................................... 119
■ Presetting a station that is now being tuned in to....................................................... 119
■ Presetting a station that can receive radio waves automatically ........................ 119
Listening to the CD .................................................................... 120
Listening to a tune in the CD ................................................................. 120
CD screen displayed.................................................................................. 121
Selecting a tune .......................................................................................... 123
■ Selecting the preceding tune.................................................................................................... 123
■ Selecting the succeeding tune................................................................................................. 123
■ Selecting a tune from the list..................................................................................................... 124
■ Searching a tune while listening.............................................................................................. 125
■ Fast-rewinding or fast-forwarding a tune .......................................................................... 125
Listening to a tune repeatedly .............................................................. 126
Listening to tunes in random order..................................................... 127
Listening to MP3/WMA disc ...................................................... 128
MP3/WMA..................................................................................................... 128
Listening to tunes (file) in the MP3/WMA disc................................. 131
MP3/WMA disc screen displayed ......................................................... 132
Selecting a tune .......................................................................................... 134
■ Selecting a folder that you want to hear ............................................................................ 134
■ Selecting a tune (file) you want to hear .............................................................................. 135
■ Fast-rewinding or fast-forwarding a tune .......................................................................... 137
■ Listening to a tune repeatedly.................................................................................................. 138
■ Listening the tunes in random order.................................................................................... 139
3
Looking at the DVD .................................................................... 140
What must be known............................................................................... 141
■ Operations while in the playback of the disc.................................................................. 141
■ DVD video and DVD audio.......................................................................................................... 141
Playing back the DVD............................................................................... 142
DVD control screen displayed............................................................... 143
Selecting the title and the chapter...................................................... 145
■ Selecting the chapter..................................................................................................................... 145
■ Searching a title with the title number specified.......................................................... 145
Controlling the playback of the DVD ................................................. 147
Operating the menu screen................................................................... 149
■ Selecting the menu......................................................................................................................... 149
■ Changing over the position of the menu operation key......................................... 150
Changing the language and the angle.............................................. 151
■ Changing the superimposed language.............................................................................. 151
■ Changing the voice language .................................................................................................. 152
■ Changing over the angle ............................................................................................................. 153
Setting the screen ..................................................................................... 154
■ Adjusting the image quality....................................................................................................... 154
■ Setting the SCREEN MODE.......................................................................................................... 155
Looking at the VIDEO ............................................................................... 156
Satellite radio operation (if equipped)..................................... 157
Setting the audio........................................................................ 158
Setting the equalizer ................................................................................ 158
■ Setting the equalizer with ease................................................................................................ 158
■ Setting the equalizer in detail ................................................................................................... 159
■ Invoking the equalizer setting that has been preset.................................................. 160
Setting the balance of the audio volume ......................................... 162
Setting the surround ................................................................................ 164
Setting the speaker................................................................................... 166
Initializing the DVD.................................................................................... 168
■ Setting the screen............................................................................................................................. 169
■ Setting the dynamic range.......................................................................................................... 170
■ Setting the language....................................................................................................................... 171
■ Setting the password of the parental level ....................................................................... 172
■ Setting the parental level ............................................................................................................. 173
Handsfree
Before using the Handsfree ...................................................... 176
What can be made with the handsfree .............................................. 176
■ What cannot be done with the handsfree ........................................................................ 176
Precautions to be taken when using the Bluetooth
equipment............................................................................................... 177
Name of each part...................................................................................... 178
Phone voice.................................................................................................. 179
Various types of displays ......................................................................... 180
■ Reception level display .................................................................................................................. 180
■ Battery indicator................................................................................................................................. 180
■ Bluetooth connection status display..................................................................................... 181
■ Roaming display................................................................................................................................. 181
When parting with your car.................................................................... 182
Making preparations of the handsfree .................................... 183
Registering the Bluetooth Phone......................................................... 183
Connecting the Bluetooth Phone ........................................................ 185
Speaking over the handsfree.................................................... 187
Making a phone call .................................................................................. 187
■ Entering a phone number to make a phone call .......................................................... 187
■ Making a phone call from the outgoing or incoming call history...................... 188
■ Making a phone call from the phone book...................................................................... 190
4
■ Making a phone call from the Speed Dial......................................................................... 192
■ Making a phone call to the phone number of the Memory Point..................... 193
■ Making a phone call from the Bluetooth Phone........................................................... 194
Taking a phone call and declining a incoming call ....................... 195
■ Taking a phone call.......................................................................................................................... 195
■ Putting an incoming phone call on hold........................................................................... 195
■ Hanging up an incoming call before answering it
(Denial of an incoming call)........................................................................................................ 196
Speaking over the phone ....................................................................... 197
■ Adjusting the tonal volume........................................................................................................ 197
■ Muting the voice on this side.................................................................................................... 197
■ Transmitting the phone call....................................................................................................... 198
■ Hanging up the phone.................................................................................................................. 198
Using the outgoing or incoming call history ........................... 199
Checking the outgoing or incoming call history ........................... 199
Deleting all the outgoing and incoming call history.................... 200
Using the phone book................................................................ 201
Registering the phone book data........................................................ 201
■ Transmitting the phone book of the Bluetooth Phone............................................ 201
■ Registering a new data with the phone book................................................................ 203
■ Registering data with the phone book from the outgoing or incoming
call history.............................................................................................................................................. 206
Editing or deleting a phone book data.............................................. 208
■ Editing a phone book data ......................................................................................................... 208
■ Selecting a phone book data to delete it .......................................................................... 210
■ Deleting all the phone book data........................................................................................... 212
Other Bluetooth settings........................................................... 214
Deleting the registered Bluetooth Phone from the in-vehicle
equipment .............................................................................................. 214
Changing the Device Name of the in-vehicle equipment
displayed in the Bluetooth Phone.................................................. 216
Editing the Speed Dial setting............................................................... 218
■ Adding the phone number to the Speed Dial memory........................................... 218
■ Deleting the phone number from the Speed Dial memory .................................. 220
Changing the Pass-Key used when certificating the Bluetooth
Phone ........................................................................................................ 222
Vehicle Information
Before Use................................................................................... 226
Precautions when using the system ................................................... 226
Displaying Vehicle Information Screen.................................... 229
Displaying Vehicle Information and Programming Vehicle
System Functions................................................................... 230
■ Displaying fuel consumption information and programming for the
automatic alarm display................................................................................................................ 230
■ Displaying, retaining, and erasing driving record data.............................................. 232
■ Displaying three meters................................................................................................................ 237
■ Maintenance schedule................................................................................................................... 238
■ Programming vehicle system functions ............................................................................. 239
■ The calculator functions................................................................................................................ 242
■ The calendar functions................................................................................................................... 244
Adjusting Brightness/Contrast ................................................. 245
■ Adjusting brightness/contrast................................................................................................... 245
Introduction
6Introduction
Safety Warnings
You will find a number of WARNINGs, CAUTIONs and NOTEs in this
supplement.
These safety warnings alert you to potential hazards that could
result in injury to you or others.
Please read these safety warnings as well as all other portions of
this supplement carefully in order to gain a better understanding
of how to safely use the systems it describes.
NOTE
A NOTE gives information or suggestions how to make better use of the
systems described in this supplement.
WARNING
A WARNING indicates a situation in which serious injury or
death could result if the warning is ignored.
CAUTION
A CAUTION indicates a situation in which injury or damage to
your vehicle including the systems described in this supple-
ment, or both, could result if the caution is ignored.
Introduction 7
System Components and Controls
(1)
This button is used to display the destination entry screen of
the navigation system.
(2)
This button is used to display the menu screen of the naviga-
tion system.
(3)
This button is used to switch to the navigation system’s cur-
rent map screen from any other screen.
(4) POWER/VOL
This button is used to operate the audio system.
(5)
This button is used to operate the audio system.
(6)
This button is used to operate the audio system.
(7)
This button is used to operate the audio system.
(8)
This button allows you to display SCREEN in which adjust-
ments can be made to the screen.
(9)
This button is used to display the vehicle information screen.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
8Introduction
System Components and Controls
(10) MODE/TUNE
This button is used to operate the audio system.
(11)
This button is used to operate the audio system.
(12)
This button is used to take out a disc and/or adjust the tilt of
the monitor.
Introduction 9
Loading the map disc
When changing the map disc with a disc appropriate to the
present location, or when updating the map disc while in the
version upgrade of a map disc, it is necessary to change it
with another map disc by following the procedure as
described below.
NOTE
• When changing a map disc with another one, be sure to stop your vehicle in a
safe place.
• For details of the map discs, see "Map Discs" on (See Page 41).
1 Press the button.
2 Select (MAP).
The monitor section is tilted and, when a disc has been set, it is
ejected.
3 When the map disc is ejected, take it out.
4 Insert a map disc that contains the area showing the cur-
rent position.
The monitor automatically gets back to the normal condition to
start the playback of the disc.
CAUTION
• You must insert the map disc into the second slot from the top.
• When inserting a map disc, do not insert 2 or more map
discs in piles. This may cause a malfunction to the machine,
resulting in the take-off of the discs unavailable.
10 Introduction
Loading the map disc
Navigation
12 Navigation
Before Use
WARNING
READ THIS MANUAL FIRST
Read this supplement carefully before using your navigation
system. We are not liable for accidents or other problems
resulting from failure to follow the instructions in this sup-
plement.
OBEY LOCAL ROAD SIGNS AND REGULATIONS
Always obey local road signs and regulations while following
instructions given by the navigation system. Some of the
data on the DVD-ROM disc may be outdated due to changes
in local road signs and regulations. Furthermore, the data on
the DVD-ROM disc does not take into account variable fac-
tors such as the weather, road congestion at different times
of the day, temporary road closures due to road construc-
tion, and special events. Local road signs and regulations
always take precedence over directions given by the system.
Failure to obey them could place you in physical danger or in
violation of the law.
DRIVE SAFELY
• Before following an instruction (for example, in the case of
changing direction) given by the system, check that the action
would be safe to take in the current traffic conditions. Continue
to pay attention to safety while following any instruction.
• Do not be distracted by the navigation screen.
Failure to keep your attention on the road could lead to an acci-
dent. When you need to look at the screen while driving, do so
for the shortest time possible and avoid staring at the screen.
• You must stop the vehicle in a safe place before operating
the navigation system. For safety's sake, some of the naviga-
tion system's controls and functions cannot be used unless
the vehicle is stationary.
• When you need to look at the navigation screen, do so for
the shortest time possible. Looking away from the road for
too long could lead to an accident.
• Use this system only in locations where it is legal to do so.
Some states/provinces may have laws prohibiting video
screens within sight of the driver.
• If you stare at the display with too much enthusiasm or oper-
ate the switches of the system while in driving, the naviga-
tion system could cause your attention to be distracted from
the current traffic conditions. Please be sure to input in the
system as much information as possible before taking your
departure. And also please be sure to bring your car to a
stop in a safe place if you need to input information.
• The buttons for the touch screen that cannot be used are
displayed in light color (tone down).
Operating the navigation system while in driving could cause
your attention to be distracted from the current traffic condi-
tions. And in consequence, this could result in a severe or fatal
accident. Follow the descriptions of all operations and the
instructions for safety given in this manual without fail.
VOLUME LEVEL
• Keep the system's volume level low enough for you to be
able to hear outside sounds while driving. To do otherwise
may prevent you from reacting appropriately to traffic con-
ditions and could result in an accident.
Navigation 13
Before Use
NOTE
• In the interest of safety, the use of some functions may be unavailable
while in driving. The button for a touch screen that cannot be used will
be displayed in tint color (toned down).
• Liquid-crystal displays may be difficult to read when wearing polarized
glasses.
CAUTION
FOREIGN OBJECTS
Do not allow foreign objects to enter the disc insertion slot,
including your fingers.
Foreign objects inside the system's main unit could cause an
electric shock or a fire. If the main unit emits smoke or an
unusual smell, stop using the system immediately and you
contact the nearest SUBARU dealer.
NEVER DISASSEMBLE OR MODIFY THE SYSTEM
Any attempt to disassemble or modify any part of the system could
lead to an electric shock or a fire, or some other type of accident.
Do not continue using the navigation system if it malfunctions
If the system shows any sign of malfunctioning (for example,
the navigation system gives no picture), stop using it imme-
diately and contact the nearest SUBARU dealer.
Continuing to use the system could lead to a fire, an electric
shock, or some other type of accident.
CAUTION
If the navigation system gets contaminated, emits smoke or an
odd smell, stop using it
If a foreign object gets inside the system, liquid is spilled
onto the system, or the system emits smoke or an unusual
smell, stop using it immediately and contact the nearest
SUBARU dealer. Continuing to use the system could lead to a
fire, an electric shock, or some other type of accident.
14 Navigation
Before Use
■ Points to note before use
Starting the engine before using the system
The navigation system can be used with the ignition key in either the
ON position or the ACC position. To preserve the battery, however, it
should be used with the engine running whenever possible. Using
the system for a long time with the engine off can cause the battery
to run down.
Delay before display of current position
The system will not immediately display a correct indication of your
vehicle's current position after being switched on for the first time or
after the battery has been disconnected for a long time. It will display
a correct current position indication as soon as it receives Global Posi-
tioning System (GPS) signals.
Program reloading after battery disconnection
The navigation program will be erased from the system's memory if
the battery is disconnected. If this happens, load the provided DVD-
ROM disc in the system's main unit and turn the ignition switch to
the ON or ACC position. The system will automatically reload the pro-
gram and start operating normally again.
Incorrect operation on rough roads
The system may operate incorrectly or be unable to read the data on
the DVD-ROM disc when subjected to severe vibration caused by
driving on rough roads.
Handling the GPS antenna
Do not paint the antenna. Doing so could impair or prevent signal
reception.
Disabled switches
Some switches are disabled during operation of the system. These
switches are displayed in fainter colors and no messages are dis-
played for them.
Risk of damage to the main unit
Be mindful of the occupant compartment temperature. Using the
system when the occupant compartment temperature is extremely
high or low can damage it or cause it to malfunction. Also, note that
the system's main unit can be damaged by strong vibration and by
any metallic object or water that gets inside.
Condensation
Condensation can form on the lens inside the main unit when there
is a rapid change in occupant compartment temperature (for exam-
ple, when the heater is switched on in cold weather). Such condensa-
tion can cause the system to operate abnormally. If you wait an hour
or so for the condensation to disappear, the system should start
working normally again. If normal operation is still not restored after
several hours, we recommend that you contact the nearest SUBARU
dealer.
Replacing the DVD-ROM disc
If you need to replace the DVD-ROM disc, make sure the replacement
disc is compatible with your system's main unit. Inserting an incom-
patible disc could damage the unit.
Navigation 15
Before Use
■ Handling precautions for DVD-ROM discs
• Handle DVD-ROM discs carefully. Any DVD-ROM disc with excessive
warping or scratches on its surface can cause reading errors.
• Store DVD-ROM discs away from direct sunlight, which can cause
warping and render them unusable.
• DVD-ROM discs rotate at high speeds inside the system's main unit.
Never use a cracked or badly warped disc; doing so could damage
the unit.
• To clean a DVD-ROM disc, lightly wipe it with a soft cloth in straight
lines from the center hole toward the outer edge.
• Never clean DVD-ROM discs with benzene, thinner, record spray,
antistatic spray, or chemical swabs.
• Do not touch the DVD-ROM disc's data surface (the surface without
a printed label). A dirty data surface can cause reading errors. Always
hold a DVD-ROM disc by the center hole and at one point on the
outer edge, or by two points on the outer edge.
• Do not write anything on DVD-ROM discs or affix anything, such as
stickers, to them.
16 Navigation
Starting Up the Navigation System
Use the following procedure to start up the navigation system
and display the current map screen.
1 Start the engine.
The CAUTION screen will appear, followed by the opening screen.
2 Carefully read the instructions on the CAUTION screen
(cited below), then select .
The current map screen will appear.
CAUTION
Make selections only when vehicle is stopped.
Watching screen while driving can lead to a serious accident.
Some map data may be incorrect.
Use judgment and obey traffic rules.
See Owner's Manual for complete operating instructions.
Navigation 17
Starting Up the Navigation System
NOTE
• To make a selection, touch the desired key displayed on the screen.
• The CAUTION screen remains on the display unless you select .
• When you use the navigation system for the first time, Eastern Standard Time
(EST) will be displayed. Adjust the system's clock to the right time using the
clock setting screen ("SET CLOCK") as described on Page 66.
18 Navigation
Volume
Use this function if you want to change the voice guidance
volume setting from the default setting.
1 Press the button.
2 Select or to adjust the sound volume.
•
Each time is selected, the sound volume turns down.
Each time is selected, the sound volume turns up.
• If you want to turn off the sound of the navigation sys-
tem, select to display "OFF".
• To make sure the volume level, select .
Navigation 19
Markers and Controls Displayed on Maps
Screens During Route Setting
Touch a point on the map. A crosshair (scroll mark) will appear
on the screen. Then touch a desired point on the map. The
map will scroll with the selected point at the center.
(1) Time
Indicates the current time.
(2) Map orientation control
Used to select either a "north up" display or "heading up" dis-
play of the map. (See Page 24.)
(3) GPS marker
Shows the status of the signal from GPS satellites. When this
marker appears, your navigation system is receiving GPS sig-
nals and using them to calculate the position of your vehicle.
(4) Screen configuration control
Allows you to select a preferred display type for route guid-
ance. (See Page 43.)
(5) Map scale
Used to display the map scale.
(6) Zoom-out/zoom-in control
or is used to zoom out or zoom in the map.
Select or to select the map scale.
(7) Vehicle marker
Indicates the current position and direction of your vehicle.
(4)
Scroll the map
<Current Position screen>
<Scroll screen>
Press button to
return to the current map
screen.
(1)
(2)
(6)
(7)
(5)
(10)
(9)(8)(11)
(3)
20 Navigation
Markers and Controls Displayed on Maps
(8) "Store memory point" key
Stores markers on the map.
This key appears just for a few seconds after a map screen is
selected.
(9) Point of interest (POI) key
Allows you to display the POI selection screen (See Page 79).
On the screen, you can program POIs to appear on a map as
markers. This key appears just for a few seconds after a map
screen is selected.
(10) Distance from current position
Indicates the distance from the current position to the posi-
tion marked by .
(11) Destination/waypoint key
Used to program a destination or waypoint at the position
marked by on a scroll screen.
Navigation 21
Markers and Controls Displayed on Maps
Screens During Route Guidance
(1) Distance and time to destination
Indicates the time (either approximate time required or time
of arrival) and the distance to the destination or a waypoint.
(2) Route
A thick blue line indicates the route you should follow.
(3) Turn guidance arrow
Indicates the direction of your turn at the next intersection/
intersection as well as the distance to the intersection/inter-
section.
(4) "Repeat voice" key
If this key is selected, the last voice guidance will be repeated.
(5) Current road name
Shows the name of the road you are currently driving on.
(6) "Display whole route" key
If this key is selected, a map containing the entire route will
be displayed. (See Page 56.)
(7) Detour
If this key is selected, the system will calculate an alternative
route that detours from the current location.
(8) "Change route" key
Selecting this key displays the route option menu. Selecting a
new route option causes the system to calculate the selected
route.
(3)
(2)
(1)
(4)
(5)
(6)
(7)
Select the screen(5 seconds)
(8)
22 Navigation
Menu Screen Keys and Functions
The table below shows the keys displayed on the MENU screen,
the functions accessible by selecting these keys, and the pages of
this manual that describe the instructions you should follow when
using these functions.
Select to return to
the current map screen.
<Current map screen>
<Menu screen>
Press button to
display the menu screen.
Menu screen key Function Reference page
Stored Locations Memory Points page 70
Avoid Area page 75
Previous Dest. page 77
Navigation Set Up User Settings page 61
Quick POI Selection page 63
Language Selection page 64
Calibration page 64
Set Clocks page 66
Vehicle Signal page 67
Restore System Defaults page 67
Route Options Search Condition page 50
Detour page 51
Route Pref. page 52
Dest. & Way Pt. page 52
Display Route page 56
Route Preview page 57
Navigation 23
Menu Screen Keys and Functions
Phone Bluetooth Phone page 187
Redial List page 199
Received Calls page 199
Phone Book page 201
Memory Points page 193
Bluetooth Settings page 183
Version Version page 87
VOL Volume page 18
Menu screen key Function Reference page
24 Navigation
Map Operations
Selecting Map Orientation
You can select either "heading up" or "north up" display on
the current map screen by using the following procedure.
1 Select or .
If you select ("north up" display), the system rotates the
map so that north is always directly upwards on the screen.
If you select ("heading up" display), the system rotates the
map so that the direction in which you are heading is always
directly upwards on the screen (the red arrow points to the north).
<"Heading up" display>
<"North up" display>
Navigation 25
Map Operations
Changing Map Scale
You can increase or decrease the scale of the map using the
following procedure:
1 Select or to change the map scale.
2 Selecting or changes the scale as shown
below.
26 Navigation
Map Operations
NOTE
• Selecting or allows you to change the map scale.
• You can keep selecting or allows you to change the map scale.
• Selecting either of the following on the scale bar displayed by
selecting or allows you to change to the specified map scale.
• The scale can be displayed in Imperial or metric units. To change the units, See
Page 61.
Imperial display
Metric display
1/32 mi (mile)
50 m
1/4 mi (mile)
500 m
2 mi (mile)
4 km
16 mi (mile)
32 km
128 mi (mile)
256 km
Current scale
<Scale Bar>
Scale to be changed
Navigation 27
Setting Route
Setting Destination
Setting destination/waypoints by scrolling the
map
Even if you do not know the exact address of your destination or a way-
point on your route to the destination, you can set it by scrolling the
map as follows:
1 Touch the screen and scroll the map until the crosshair
reaches the destination or a waypoint.
2 Select the (destination or waypoint) key.
The key will separate into the destination key and the waypoint key.
3 Select for setting the destination
The system will calculate the route and display the entire route to
the destination on the map.
Select for a waypoint. The system will program the
address of the waypoint on your route (See Page 69). You can set
up to 5 waypoints per trip.
28 Navigation
Setting Route
4 Select (start).
Route guidance will begin along the displayed route.
NOTE
• If the system cannot find your desired route, select (change
route). This will allow you to access the ROUTE OPTIONS screen, from which
you can prompt the system to calculate a new route. (See Page 49.)
• Selecting (start) for more than 5 seconds will start the demon-
stration mode operation.
■ Selecting route
Upon setting the destination, the system prepares to calculate three
types of routes to the destination (Quick, Alt., and Short). You can select
from any of the three options as follows:
1 Select (3 routes).
The system will be ready for calculation of any route you select
from the three options, namely, Quick (the fastest route), Alt.
(alternative route), and Short (the shortest route).
Navigation 29
Setting Route
2 Select (information).
The screen will display details (required time, total distance, roads
used, etc.) regarding each option.
3 Select (Quick), (Alt.), (Short)
or as you desire, and then select (Start) to con-
firm your selection.
Setting the destination from the navigation menu
You can set your destination using a variety of methods if you start set-
ting from the DESTINATION ENTRY screen. Before you can use any of
these methods, perform the following steps:
1 Press the button.
2 Select the method you want to use.
30 Navigation
Setting Route
You can switch between screens by selecting (next page)
or (previous page).
NOTE
• If the set destination area is different from the one displayed under "Search
Area" in the right part of the screen, you must select the (change)
key and specify the desired area again.
• For the methods marked with an asterisk ( * ), you can use the "Change Search
Area" function to narrow the area where a destination or waypoint is located
by selecting the (change) key (See Page 41).
• Depending on the method used or the status of the map displayed, the
located point may differ from where the facility you want to visit actually
exists.
(Address)* See Page 31.
(Point of Interests)* See Page 34.
(Select from Map) See Page 35.
(Emergency) See Page 37.
(Memory Point) See Page 33.
(Previous Destination) See Page 35.
(Intersection)* See Page 39.
(Freeway Ent/Exit) See Page 36.
(Phone number) See Page 40.
(Coordinates) See Page 38.
(Home) See Page 33.
-(Category1) - (Category5)
Navigation 31
Setting Route
■ "Address" method
1 Press the button and select (address).
2 Enter a house number using the keypad on the house
number input screen and select .
3 Enter the street name.
If you enter enough letters to identify a street name and advance
to Step 4, a list showing several street names will be displayed.
Select the desired street name from the list.
: Use this key to delete the last character entered. Select it
repeatedly if you want to delete all the characters entered.
You can switch between keypad screens showing different characters
by selecting (others), (symbols) or (alphabet).
4 Select (list).
5 Select the desired street from the list.
If the same street name exists in more than one city, a list of these
cities will be shown.
32 Navigation
Setting Route
6 Select the correct city from the list.
(input name): Use this key to input the city name from the
keypad.
7 Select (destination) to set the address entered
in the above steps as your final destination
The system will calculate the route and display the entire route on
the map.
Select (waypoint) to set the address entered in the
above steps as a waypoint on your route.
You can program up to five waypoints per trip.
8 Select (start).
Route guidance begins along the displayed route.
NOTE
• If the system cannot find your desired route, select (change
route). This will allow you to access the ROUTE OPTIONS screen, from which
you can prompt the system to calculate a new route. (See Page 49.)
• If your DVD-ROM disc does not contain the relevant house number data, an
error message will be displayed and a street map will appear, allowing you to
set the destination using the map.
• If your destination is not on a road, set a destination point on a main road
nearest to your true destination.
• Selecting the (city) will display a screen that searches the destination
on a city basis.
: Search the destination from all cities.
: Search the destination from the nearby five cities
within 20 miles from the current position.
: Search the destination by inputting the city name.
You can also search the destination from the five cities that you searched in
the past.
Navigation 33
Setting Route
■ "Memory Point" method
If you have saved some locations in the system's memory, you can
make use of an appropriate one to set the destination.
1 Press the button and select (memory
point).
2 Select the address of the desired location (memory
point).
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
3 Select (destination) or (waypoint).
NOTE
• Select the (Attribute), (icon), (name), or
(date) key to change the sequence in which memory points are
displayed.
• You cannot use the "Memory Point" method unless there are memory points
stored. To store memory points, See Page 70.
■ "Home" method or method using stored destinations
If you have stored your home address in the system's memory, you can
use it for your destination or a waypoint. Similarly, if other locations are
stored in the memory, they can be conveniently used for quick setting
of destination and waypoints.
1 First, choose either of the two procedures below to fol-
low the "home" method.
Press the button.
2 Select (home) or one of the locations pro-
grammed to keys (Category 1)
through (Category 5).
34 Navigation
Setting Route
The map including your home location or the selected location
will be displayed.
3 Select (destination) or (waypoint).
NOTE
Icon (home) and keys (Category 1) through (Category
5) are displayed only when you have stored your home location and other loca-
tions in the memory. For instructions on how to store your home location and
other locations.
■ "Point of Interest" method
You can use a selection from the "Point of Interest" listing as your desti-
nation or a waypoint.
1 First, choose either of the two procedures below to fol-
low the "point of interest" method.
Press the button and select (point of interest).
2 Enter the name of the desired point of interest and
select .
3 Select the desired point of interest from the list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
4 Select (destination) or (waypoint).
Navigation 35
Setting Route
NOTE
• If two or more points of interest share the same name, they will both be listed
on the screen. Choose an appropriate one from the list.
• If there are two or more points of interest with the same name,
select (category) or (Town) to shorten the list.
• Displayed information about a specific facility might not include recent
changes. It is recommended that you check the location or business days/
hours of a desired point of interest before departure.
■ "Previous Destination" method
This method allows you to choose one of the most recently used 100
destinations or waypoints as your new destination or waypoint.
1 Press the button, select , and then
select (previous destination).
2 Select a desired location from the Previous Destination
list.
:Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
3 Select (destination) or (waypoint).
NOTE
• You can select (name) or (date) to change the
sequence in which previous destinations are displayed.
• Selecting displays the start point of the
previous guide.
■ "Select from Map" method
You can specify a location on the map that was last displayed and use it
for setting the destination or a waypoint.
1 Press the button and select (select from
map).
2 Scroll the map until the crosshair is at the desired
destination or waypoint.
36 Navigation
Setting Route
3 Select (destination) or (waypoint).
■ "Freeway Entrance/Exit" method
You can use the name of a Freeway entrance or exit selected from the
"Freeway Ent./Exit" list for setting your destination or a waypoint.
1 Press the button, select , and then select
(Freeway Ent./Exit).
2 Enter the name of the desired freeway and select .
3 Select the name of the freeway from the list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
4 Select (entrance) or (exit).
5 Select the name of the street from which you will enter
the freeway or to which you will go after leaving the free-
way.
Navigation 37
Setting Route
: You must select this key before you can enter the street
name.
: Use this key to search through the list by distance.
: Use this key to search through the list by name (alphabeti-
cal search)
6 Select (destination) or (waypoint).
■ "Emergency" method
This function allows the nearest police station or hospital to be set as
the destination.
1 Press the button and select (emergency).
2 Select either (Police sta-
tion) or (Hospital).
The nearest police stations or hospitals will be displayed accord-
ingly.
3 Select the desired institution from the list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
: Sorts the list by distance.
: Sorts the list in alphabetical order by name.
4 Select (destination) or (waypoint).
NOTE
Displayed information about each facility might be changed. It is recommended
that you check the location or business days/hours before departure.
38 Navigation
Setting Route
■ "Coordinates" method
You can set destinations or waypoints using their latitudes and longi-
tudes as follows:
1 Press the button, select , and then select
(coordinates).
2 Enter the latitude of the desired location.
Use the numeric keys together with the [°] (degrees), ['] (minutes),
and ["] (seconds) keys.
3 Enter the longitude of the location.
: Use this key to switch over to the north latitude.
: Use this key to switch over to the south latitude.
: Use this key to switch over to the west longitude.
: Use this key to switch over to the east longitude.
: Use this key to delete the character last entered. Select it
repeatedly if you want to delete all the characters entered.
4 Select (OK).
Navigation 39
Setting Route
5 Select (destination) or (waypoint).
■ "Intersection" method
You can use a intersection defined by two street names as a location for
setting your destination or a waypoint.
1 Press the button, select , and then
select (Intersection).
2 Enter the name of the first street and then select .
3 Select the street from the "Intersection" list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
4 Specify the second street using the same procedure as
the first street. Select (List).
40 Navigation
Setting Route
5 When there are two or more candidates, a list of intersec-
tions will be displayed. Select an intersection of your des-
tination.
6 Select (destination) or (waypoint).
NOTE
No intersection is defined if
• the two streets do not cross each other,
• the two streets are a freeway and a highway,
• either street is for right or left turns only,
• both are one-way streets,
• either street is for U-turns,
• the two streets cross on the inside lane,
• either street is an on/off ramp,
• either street is a frontage street, and/or
■ "Phone number" method
This function allows buildings and the like to be located using their
phone numbers.
1 Press the button, select , and then select
(phone number).
2 Enter the phone number starting with the area code.
3 Select .
Navigation 41
Setting Route
4 Select your destination.
5 Select (destination) or (waypoint).
NOTE
If a number of candidates exist as a result of, for example, different area codes,
these will be displayed in a list. Your desired destination can then be selected
from the list.
■ Using "Change Search Area" function
This function designates a general geographical area where the desti-
nation or waypoint you want to set is located.
This function can be used in the methods marked with an asterisk (*) on
Page 30.
1 Press the button and select (change).
2 Select the desired area.
The DESTINATION ENTRY menu screen will appear.
NOTE
• The SEARCH AREA screen shown above is a sample image. It may be slightly
different from the actual screen image.
• Three map discs are contained in this system. When performing a search for a
different area in your destination search, it is necessary to change the map
disc with another map disc. If an area you want to find is not displayed on the
screen shown above, take out the map disc and change it with a map disc
containing the relevant area.
For details of the map disc, refer to the description below.
■ Map Discs
The three map discs contain different areas, respectively. (West, Mid and
East) Select the map disc containing the destination area you wish and
insert the disc in the navigation system.
Make sure to reselect your destination when you change the map disc.
Refer to the section Set Route in the Instruction Manual for instructions
on reselecting the destination.
42 Navigation
Setting Route
■ Area (West)
Arizona, California, Colorado, Idaho, Kansas, Montana, Nebraska,
Nevada, New Mexico, North Dakota, Oklahoma, Oregon, South Dakota,
Texas, Utah, Washington, Wyoming, Canada
■ Area (Mid)
Alabama, Arkansas, Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana,
Michigan, Minnesota, Mississippi, Missouri, Nebraska, North Dakota,
Ohio, Oklahoma, South Dakota, Tennessee, Texas, Wisconsin, Canada
■ Area (East)
Alabama, Connecticut, Delaware, Florida, Georgia, Kentucky, Maine,
Massachusetts, Maryland, New Hampshire, New Jersey, New York, North
Carolina, Ohio, Pennsylvania, Rhode Island, South Carolina, Tennessee,
Vermont, Virginia, Washington D.C., West Virginia, Canada
NOTE
• Road information for all of the above locations is included on the map discs.
This means that the following operations can be performed regardless of
which map disc is loaded in the system;
- Scrolling Map to Select Destination (Select from Map)
- Selecting Destination from the previously registered points as a memory
point (Home, Memory Point, Previous Destination) within the same area.
- Selecting Destination by Latitude and Longitude (Coordinates), Phone num-
ber, Emergency, and Quick POI.
• After replacing the map disc, stored data including the POI icon on the map
and stored Avoid Street settings will be deleted, and Quick POI selections will
return to default.
• In the Current Location display, the arrival time and the distance to the desti-
nation are displayed for Next Way Point.
Navigation 43
Route Guidance
Route Guidance Screen
During route guidance, the system can indicate on a second
screen the directions in which you must make turns at the
next and following intersection in either of two ways: "turn
arrow" or "turn list". Specify your preferred method of indica-
tion as follows:
1 Select (screen configuration).
2 Select for turn arrow indication or for turn list
indication.
If you need not make any further selection, select . The rele-
vant keys will disappear.
<Turn arrow>
Turn direction is indicated by an arrow.
Turn directions are indicated in a list.
<
T
urn
li
st>
44 Navigation
Route Guidance
Zoom-in Map at Intersection
Before you arrive at an intersection, the system will automati-
cally show a zoom-in map of the intersection on a second
screen to make the guidance clearer.
As you approach an intersection during route guidance, a zoom-in map
of the intersection automatically appears on a second screen. After you
drive past the intersection, the zoom-in map disappears.
As you approach a fork on a freeway during route guidance, a zoom-in
map of the freeway automatically appears on a second screen, making
the route guidance clearer.
NOTE
Use the following procedure to recall the most recently displayed zoom-in map
of an intersection or a freeway fork.
1. Select (screen configuration).
2. Select (re-display of intersection/range guidance).
If you need not make any further selection, select . The relevant keys
will disappear.
Navigation 45
Route Guidance
Dual Map Display
You can configure the screen for a dual map display.
1 Select (screen configuration).
2 Select (dual map).
If you wish to return to the single map display, select (sin-
gle map).
If you need not make any further selection, select . The rele-
vant keys will disappear.
NOTE
If you wish to modify the display selections that have been made for a second
screen, touch the top of the screen. After completing the modification,
select .
• See Page 25 for details on scale changes.
• See Page 79 for details on setting with .
<Single map display>
<Dual map display>
46 Navigation
Route Guidance
Freeway Information
A list of buildings and facilities along a freeway can be dis-
played on the screen.
1 Select (screen configuration).
2 Select (freeway information).
If you need not make any further selection, select .
The relevant keys will disappear.
The information of a freeway is displayed.
Select to display the map in the neighborhood together
with the icons of hotels and banks.
This map allows you to set your destination and waypoints. It also
allows you to register them with the Memory Point with the cur-
sor placed on the icon.
Navigation 47
Route Guidance
Replaying Voice Guidance
If you want to listen to the last voice guidance again during
route guidance, use the following procedure:
1 Select .
You can hear the voice guidance again.
48 Navigation
Route Guidance
Compass Mode
Longitude and latitude of present location can be displayed
on the screen.
1 Select (screen configuration).
2 Select (compass).
3 Longitude and latitude of present location are displayed
at upper right of the screen.
Navigation 49
Route Options
Setting Route Options
Using the functions available from the Route Options screen,
you can change the route options, stop the route guidance or
check the route. Use the following procedures:
1 Press the button.
2 Select (route options).
The Route Options screen will appear. Select any of the following
displayed functions as necessary:
(search condition):
This function allows you to specify the way in which the system
calculates the route to the destination. (See Page 50.)
(detour):
This function allows you to prompt the system to calculates an
alternative route from your current position within a specified dis-
tance. (See Page 51.)
(route preferences):
This function allows you to prompt the system to alter the route
search conditions and recalculate the route accordingly. (See Page
52.)
(destination and waypoint):
This function allows you to modify the destination and waypoints,
and prompt the system to recalculate the route accordingly. (See
Page 52.)
(display route):
This function allows you to confirm the entire route and, if neces-
sary, prompt the system to recalculate the route according to your
specification. (See Page 56.)
(route preview):
This function allows you to simulate a drive along the system-cal-
culated route before departure. (See Page 57.)
(calculate):
Selecting this key prompts the system to recalculate the route.
50 Navigation
Route Options
(cancel guidance):
Selecting this key prompts the system to stop route guidance.
Note that this erases the destination and waypoints. To prompt
the system to start guidance again, select (calculate).
NOTE
A recalculated route will sometimes be the same route as the one displayed
before recalculation.
Search condition
You can specify the way in which the system calculates your route.
1 Press the button, then select (route
options), and then select (search condition).
2 Select (Quick), (Alt.),
or (Short) to specify the way of calculating the
route to reach the next waypoint or the destination from
the current point.
: The system will calculate a route with the shortest
driving time required.
: The system will calculate an alternative route.
(You can select , or for the first
waypoint. Only or can be specified for the
second and subsequent waypoints.)
: The system will calculate a route with the shortest
driving distance.
Navigation 51
Route Options
3 Select (calculate)
4 Select (start).
Detour
You can specify a detour distance from your current position. The sys-
tem will calculate an alternative route according to the distance specifi-
cation, enabling you to take a detour.
1 Press the button, then select (route
options), and then select (detour).
2 Select a detour distance using , , ,
or (whole route).
The system will then calculate an alternative route that detours
from the current location within the specified distance.
When driving on the freeway, make a selection from among
, 15 mi, 25 mi and .
3 Select (start).
NOTE
If you are driving off the route, it is not possible to calculate a detour route.
52 Navigation
Route Options
Route preferences
Use this function to specify preferred route search conditions. The sys-
tem will start recalculating the route according to your specified condi-
tions.
1 Press the button, then select (route
options), and then select (route preferences).
2 Specify conditions by selecting keys.
Each time you select a key, it will toggle between "usage" and
"non-usage" of the corresponding roads or ferries.
3 Select (calculate).
NOTE
• The (calculate) key can be selected during route guidance.
• The route calculation will not always be able to follow the specified condi-
tions.
Destination and waypoints
You can change the destination or waypoints for the route calculation
by using this function.
■ Addition of waypoints
Use the following procedure to add new waypoints to the current route
for recalculation.
1 Press the button, then select (route
options), and then select (destination and way-
points).
2 Select (add).
Navigation 53
Route Options
3 Set a waypoint using any method available from the
screen.
4 Specify the order in which all the set waypoints are to be
visited.
Choose the location of the waypoint to be added, and then
select (add).
5 Select (calculate).
NOTE
• When a new destination is set using (destination), it will replace the
current destination and the route calculation will be carried out again.
• Step 4 must be performed for the second and any subsequent waypoints.
• Repeat Steps 1 to 4 for each waypoint to be set.
■ Modifying destination or waypoint positions
Use this procedure to modify the destination or waypoint positions. The
screen will display the calculated route and the positions of the destina-
tion or waypoints that you will be able to modify.
1 Press the button, then select (route
options), and then select (destination and way-
points).
2 Select (list).
3 Select (change location).
54 Navigation
Route Options
4 Select the key corresponding to the location that is to be
modified.
The map for the area around your current location will be dis-
played.
5 Scroll the map to bring the crosshair to the location
and then select .
6 Select (calculate).
■ Modifying visiting order
You can change the order for visiting your waypoints by using this pro-
cedure.
1 Press the button, then select (route
options), and then select (destination and way-
points)
2 Select (list).
3 Select the waypoint keys according to the order of your
visit.
If you wish to cancel the visiting order number indication, select
(undo).
4 When you complete the sequencing, the visiting order
will be updated automatically.
5 Select .
6 Select (calculate).
Navigation 55
Route Options
■ Deleting destination or waypoints
Use this procedure when you wish to delete the previously set destina-
tion or waypoint.
1 Press the button, then select (route
options), and then select (destination and way-
points).
2 Select (delete).
3 Select the key corresponding to the destination or way-
point you wish to delete.
4 Confirmation message will be displayed. Select
(yes).
Select (no) to cancel the deletion.
5 Select (calculate).
56 Navigation
Route Options
■ Deleting destination and all waypoints
You can delete the destination and all previously set waypoints in a sin-
gle process.
1 Press the button, then select (route
options), and then select (destination and way-
points).
2 Select (delete all).
3 Confirmation message will be displayed. Select
(yes).
Select (no) to cancel the deletion.
Display route
Use this function to display the entire route. You can also specify an area
you wish to avoid and prompt the system to recalculate the route
accordingly.
1 Press the button, then select (route
options), and then select (display route).
2 Select (turn list).
The entire route screen will appear and then it will change to the
Turn List screen.
Navigation 57
Route Options
(avoid):
Select this key if you wish to specify any areas to avoid from the
list of street names.
(Reroute):
The system will recalculate the route.
If the data for the route cannot be shown on one screen, scroll the
screen using the and keys.
3 When the Reroute is selected: Select (start).
Route preview
The system can show you an automated simulation of the calculated route.
1 Press the button, then select (route
options), and then select (route preview).
2 Start the simulation drive according to the calculated
route using the keys on the screen as follows:
: Move to the start point.
: The simulation drive will start toward the start point. After the
start, this key will be displayed as ,and when it is
selected, the simulation drive will switch to high-speed driving.
: The simulation drive will stop.
: The simulation drive will start toward the destination.
After the start, this key will be displayed as , and
when it is selected, the simulation drive will switch to
high-speed driving.
58 Navigation
Route Options
: Move to the destination.
: The EDIT ROUTE PREVIEW screen will be displayed. (See
Page 58.)
NOTE
The visual speed of the simulation vehicle varies with the map scale selected.
The speed appears to be faster with a wide-area map than with a zoom-in map.
■ Setting conditions for simulation drive
You can change the simulation drive conditions using this procedure.
1 Press the button, then select (route
options), and then select (route preview).
2 Select (edit).
The EDIT ROUTE PREVIEW screen will appear.
(to destination or next waypoint):
The simulation drive will stop at the destination or the next way-
point.
(to next POI):
The simulation drive will stop at a point of interest that has been
set up on the route.
(delete):
A selected POI will be deleted.
Navigation 59
Route Options
POI keys:
When you select one of the six POI category keys, the system will
retrieve the selected POI from the Quick POI storage and display it on
the map. When you select the (others)
key, you can find POIs of other categories. For more details, See Page
63
.
If, for example, the (to next POI) category
key is selected and a simulation drive is started, your simulation
vehicle will then stop at a restaurant on the route.
If you then select (information), the system will display
information on the restaurant.
.
Selecting allows you to make a phone call to the phone
number displayed.
* The Bluetooth Phone is required to be set in advance.
NOTE
You must finish the simulation drive before you actually start to drive. Although
the simulation drive will automatically stop when you actually start to drive, not
finishing it properly can lead to an error in the display of your vehicle's current
position.
60 Navigation
Navigation Setup
Setting Your Navigation System
Using the functions available from the Navigation Setup
screen, you can change the map display conditions and alter
the route guidance conditions.
1 Press the button.
2 Select (navigation setup).
The NAVIGATION SET UP screen will appear.
Select any of the displayed functions as necessary. This screen
consists of two pages. Change the page by using
the or keys.
Navigation 61
Navigation Setup
(user settings):
This function allows you to change the screen display and sound
settings. (See Page 61.)
(quick POI selection):
This function allows you to set the point of interest categories that
are displayed when you select the menu from the current position
screen. (See Page 63.)
(language):
This function allows you to change the language for the menu
screens and the voice guidance. (See Page 64.)
(calibration):
You can use this function to correct display errors in the vehicle's
position and direction. (See Page 64.)
(set clock):
This function allows you to set the time. (See Page 66.)
(Vehicle Signal):
This function allows you to confirm the vehicle signal, the version
of the DVD-ROM disc. (See Page 67.)
(restore system defaults):
This function allows you to change the system's current settings
back to the default settings (factory settings). (See Page 67.)
User settings
You can change the screen display and sound settings using this procedure.
1 Press the button, then select (navigation
setup), and then select (user settings).
2 Select the setting item you wish to change.
The USER SETTINGS screen consists of three pages. Use the
or keys to change the screen page when selecting a setting item.
Impreza_B1962BE-A.book Page 61 Wednesday, May 7, 2008 9:01 PM
62 Navigation
Navigation Setup
Distance:
Units of distance can be selected from (km)
and (mile).
Road Restriction Warnings:
You can select or deselect display of traffic restriction warnings
during route guidance.
Keyboard layout:
The layout of input keys can be selected from ("ABC" lay-
out) or ("QWERTY" layout).
Arrival Time:
Time of arrival at the destination or a waypoint can be displayed in
two different ways: estimated arrival time or remaining driving
time. Select for the estimated arrival time display
or for the remaining time display.
Map Mode:
The map display mode can be set to any of the automatic, day-
time, and nighttime modes.
(automatic):
The brightness of the display will automatically change to day-
time brightness and nighttime brightness when the headlights
are turned off and on, respectively.
(daytime):
The brightness of the display is fixed at the daytime setting
regardless of whether the headlights are on or off.
(nighttime):
The brightness of the display is fixed at the nighttime setting
regardless of whether the headlights are on or off.
Guidance Screen:
This function allows you to select or deselect display of guidance
messages on the screen.
Freeway Information:
This function allows you to select or deselect display of guidance
messages when driving on freeway.
Auto Volume:
A setting can be made so that the sound volume of the naviga-
tion system automatically increases as the speed of the vehicle
increases.
Beep:
A setting can be made so that a beep sounds.
Clock Display:
A setting can be made so that the clock is displayed.
Audio Status Display:
A setting can be made so that the status of the audio system is
displayed.
Reverse Mute:
A setting can be made so that the sound volume of the audio sys-
tem is reduced while reversing the vehicle.
<Estimated arrival time>
<Required remaining time>
Navigation 63
Navigation Setup
Quick POI selection
Using this function, you can set the point of interest categories that are
displayed when you select the Point of Interest menu key on the cur-
rent map screen. Set up to six different categories that you use most fre-
quently. (See Page 79 for the method of displaying POI categories on
the map and searching for the nearest points of interest.)
1 Press the button, then select (navigation
setup), and then select (quick POI selection).
2 Select one of the six category keys you wish to program
into the Quick POI storage.
(default):
Use this key to restore the factory settings.
3 Select a category.
Once you have selected a category key, subcategories will be dis-
played.
(all category list):
Subcategories from all individual categories will be displayed
together.
4 Select the subcategories to be displayed on the map.
NOTE
Repeat Steps 1 to 4 to add more POI categories for display on the menu screen.
64 Navigation
Navigation Setup
Language Selection
Use the following procedure to select your preferred language for the
menu screens and the voice guidance.
1 Press the button, then select (navigation
setup), and then select (language)
2 Select your preferred language from the list.
Calibration
This function allows you to correct any display errors in the position and
direction of your vehicle on the map display.
■ Adjusting current position and direction
1 Press the button, then select (navigation
setup), and then select (calibration).
2 Select (position/direction).
Navigation 65
Navigation Setup
3 Move the crosshair to the correct position, and then
select
.
4 Use or to adjust the direction in which you are
heading, and then select .
■ Distance
When selected, this function automatically corrects an error in the cur-
rent position display that might occur after tire replacement.
1 Press the button, then select (navigation
setup), and then select (calibration).
2 Select .
NOTE
You will have to drive about 6 miles (10 km) before the distance correction is
complete.
66 Navigation
Navigation Setup
Set clock
Since the adjustments for minutes and seconds are made automatically
using the time data provided by GPS satellites, you can set your clock by
simply performing a time-zone and daylight saving time adjustment
using this function.
1 Press the button, then select (navigation
setup), and then select (set clock).
2 Select if you prefer 24-hour display; select for
12-hour display.
3 Select the time-zone by pressing or .
NOTE
Initial time-zone setting of this navigation unit is Eastern (Disc A)/Mid (Disc B)/
Pacific (Disc C).
4 Select the daylight saving time mode by pressing
or .
NOTE
Select to advance the time by one hour.
Navigation 67
Navigation Setup
Vehicle signal
This function allows certain vehicle data and GPS satellite data to be dis-
played.
1 Press the button, then select (navigation
setup), select and then select (vehicle signal).
The VEHICLE SIGNAL screen will appear.
Restore system defaults
Use this function if you want to change all of the system's current set-
tings back to the default settings.
1 Press the button, then select (navigation
setup), select and then select (restore system
defaults).
2 Select to return all current systems settings to
default.
Select (default) to return average speed set-
ting to default.
NOTE
If you select this function, all your settings will be deleted.
68 Navigation
Navigation Setup
[Default List]
Item Initial condition
Map display
Search Area
Display Guidance Language
Map Orientation (1 and 2 screen)
Map Display Mode
Map Display Scale
Map Configuration
Q-POI Map Display
Show POI Icon Display
Right Screen Setting, POI
Passage Point Display/
Current Location, Map Screen (Time
Requirement, Time, Direction / Distance)
Passage Point Display/
Full Route, Map Screen (Time Require-
ment, Time, Direction / Distance)
Restricted Road
Freeway Information
Disc A (WEST): CA
Disc B (MID): IL
Disc C (EAST): DC
US English, female
North up
Single-screen display
Single-screen:
10,000 map (1/16 mi) (100 m)
Dual-screen:
40,000 map (1/4 mi) (500 m)
Arrow Mode
Off
Off
On
Next passage point
Destination
On
Off
Volume Control
Volume Preset
4
Navigation Setup Menu
Distance
Road Restriction Warnings
Reverse Mute
Keyboard Layout
Arrival Time
mile
On
Off
ABC
Required remaining time
Item Initial condition
Map Mode
Guidance Screen
Q-POI Selection
Language Selection
Auto
On
A: Gas station
B: ATM
C: Parking
D: Grocery store
E: All Restaurants
F: Hotel
US English, female, male,
French, Espanõl
Route Options
Search Condition
Route Preferences
Quick
Allow Toll Road: Off
Allow Ferry: Off
Allow Major Roads: On
Allow Time Restricted Road:
Off
Item Initial condition
Navigation 69
Stored Locations
You can store, edit, or delete any destinations, waypoints, and
other marked points using the procedures described in this
section.
1 Press the button.
2 Select (stored locations).
3 Select the desired item.
(Memory Points):
Use this function to place markers on the map. (See Page 70.)
(Avoid Area):
Use this function to store into the system's memory any areas you
want to avoid. (See Page 75.)
(Previous Destination):
Use this function to delete previously stored destinations and
waypoints. (See Page 77.)
(Display memory point icons):
Selecting this key allows you to display icons for memory points.
Each of the above six functions has some or all of the following
four standard editing functions (see the table below):
(add):
You can store a new location into memory.
(list):
You can see a list of the stored locations.
(delete):
You can delete stored locations.
(delete all):
You can delete all stored locations.
70 Navigation
Stored Locations
Editing keys displayed for each function are as follows:
The numbers in parentheses following the function names indicate the
maximum locations you can store in the memory.
Memory points
■ Storing new memory points
Memory points can be stored into any of the six categories (including
Home) of storage locations.
1 Press the button, then select (stored loca-
tions), and then select (memory points).
2 Select (add).
Memory Points (100)
Avoid Area (10)
Previous Dest. (5)
Navigation 71
Stored Locations
3 Set the memory point using the preferred method avail-
able on the displayed screen.
NOTE
Up to 100 memory points can be stored. Once that number has been reached,
you must delete memory points that you no longer require (See Page 74) before
you can store new memory points. The number of memory points you can store
is indicated on the screen.
■ Reviewing and modifying memory points
Using this function, you can review the stored memory points in the
form of a list on the screen and modify names, icons, telephone num-
bers, and other memory point data.
1 Press the button, then select (stored loca-
tions), and then select (memory points).
2 Select (list).
72 Navigation
Stored Locations
3 Select the memory point to be modified.
You can change the sequence in which memory points are listed by
selecting (Attribute), (icon), (na
me), or (date)
.
4 Select the category key corresponding to the memory
point to be modified.
(icon): Selecting this key allows you to choose a dis-
play icon. (Page 1) and (Page 2) of
the CHANGE ICON screen contain standard icons, whereas the
"With Sound" (with sound) page contains icons that are accompa-
nied by response sounds. Select (with sound) to
listen to these sounds.
Navigation 73
Stored Locations
NOTE
The "With direction" ( / ) keys in the "With Sound" page are
used to activate response sounds only when you come near the mem-
ory point from the specified direction. Select or and set
the direction using or . Selecting allows you to listen to
respective sounds.
(category): Use this key to change the storage cate-
gory. After selecting this key, select either key of HOME or Preset
Destinations 1 to 5.
For memory points to which the category has been set, it is possi-
ble to set them quickly as a destination. It is convenient to set in
advance the category to your home or a spot to which you go fre-
quently. When setting it as a destination, select the relevant key
on the DESTINATION ENTRY screen. See Page 29.
(name): Select this key to change the name of a mem-
ory point. When the change has been completed,
select (OK). Then select (on) if the name is to be
displayed on the map, or (off ) if it is not to be displayed.
(position): Select this key to review the memory
points and modify a memory point on the map screen. After
checking or modifying it, select (OK).
(Tel): Select this key to modify a telephone number.
When the modification has been completed, select (OK).
74 Navigation
Stored Locations
■ Deleting memory points
You can delete stored memory points by using this function.
1 Press the button, then select (stored loca-
tions), and then select (memory points).
2 Select the category of the memory point to be deleted.
3 Select (delete).
4 Select the memory point to be deleted.
5 Confirmation message will be displayed. Select
(yes).
Select (no) to cancel the deletion.
■ Deleting all memory points
Using this function, you can delete all memory points.
1 Press the button, then select (stored loca-
tions), and then select (memory points).
2 Select the category of the memory points to be deleted.
3 Select (delete all).
Navigation 75
Stored Locations
4 Confirmation message will be displayed. Select
(yes).
Select (no) to cancel the deletion.
Avoid area
■ Storing avoid areas
If you use this function to store into the system's memory the areas you
want to avoid, the system will avoid the areas when calculating routes.
1 Press the button, then select (stored loca-
tions), and then select (avoid area).
2 Select (add).
3 Set an avoid area using your preferred method.
A map including the specified avoid area will appear.
The method of setting avoid areas is identical to that of setting
destinations.
76 Navigation
Stored Locations
4 Select (reduce) or (enlarge).
(reduce): Reduces the size of the avoid area.
(enlarge): Increases the size of the avoid area.
5 Select (OK).
NOTE
• Reduce the scale of the map to specify a larger area.
• Avoid areas can be set only when the scale of the map is 0.6 mile (1 km) or
less.
■ Reviewing and modifying avoid areas
Using this function, you can review the stored avoid areas in the form of
a list and modify them if necessary.
1 Press the button, then select (stored loca-
tions), and then select (avoid area).
2 Select (list).
3 Select the avoid area to be modified.
4 Select the key corresponding to the item to be modified.
For details regarding the function of each key, refer to "Reviewing
and modifying memory points" on Page 71.
NOTE
The methods for deleting individual and all avoid areas are the same as those
described on Page 74 for memory points.
Navigation 77
Stored Locations
Previous destination (deleting stored locations)
Use this function to delete previously set destinations.
1 Press the button, then select (stored loca-
tions), and then select (previous destinations).
2 Select (delete).
If (all delete) is selected, all previously set
destinations will be deleted.
3 Select the destination to be deleted.
: Use this key to display up to five previous destinations.
: Use this key to display the previous destination.
: Use this key to display the next destination.
: Use this key to display up to five of the next destinations.
(name): Use this key to search through the list by name
(alphabetical search).
(date): Use this key to search through the list by date.
78 Navigation
Stored Locations
4 Confirmation message will be displayed. Select
(yes).
Select (no) to cancel the deletion.
Navigation 79
Other Functions
Displaying POIs on a map
Using this function, you can display POIs on the current map screen.
1 Touch the current map screen.
2 Select (points of interest).
3 Select desired POIs using the displayed category keys.
When selecting two or more categories,
select to make a selection of them. The
selection of up to five categories is available.
(all local POIs): Use this key to search for all
local points of interest (see below).
Once you have made your selection of POIs, corresponding mark-
ers will appear on the current map screen.
To delete the markers for these POIs, See Page 82.
NOTE
Displayed information about each POI facility might not include recent changes.
It is recommended that you check the location or business days/hours before
departure.
80 Navigation
Other Functions
■ Local search
1 Touch the current map screen.
2 Select (points of interest).
3 Select (all local points of interest).
When searching local points of interest, it is necessary to set in
advance the category you want to make a search to the Quick POI.
(See Page 63.)
4 Select the POI you want to find from the list of catego-
ries.
: Use this key to display up to five previous POIs.
: Use this key to display the previous POI.
: Use this key to display the next POI.
: Use this key to display up to five of the next POIs.
: Use this key to search through the list by distance.
: Use this key to search through the list by icon type.
: Use this key to search through the list by name (alpha-
betical search).
: Use this key to display a list of POIs only along the
route up to the destination.
Once you have made your selection of POIs, corresponding mark-
ers will appear on the map.
Navigation 81
Other Functions
Displaying POI data
You can display the information on a POI, such as the name, address
and telephone number.
1 Display the desired POI markers on the current map
screen. (See Page 63 and 79 for the procedure.)
2 Select the POI marker for which you want information by
moving the crosshair over it.
The name of the POI will appear.
If no data is stored for the selected POI, no name is displayed.
3 Select (information).
The information on the POI will be displayed.
: Use this key to store the POI location as a memory point.
82 Navigation
Other Functions
Deleting POI markers
Use this function when you want to delete any POI markers on the map.
1 Touch the current map screen.
2 Select (point of interest).
3 Select (point of interest off).
The marker for the POI will disappear from the map.
Editing Quick POI categories
Use this function when you want to edit the Quick POI categories on
this unit.
1 Select (menu).
2 Select (navigation set up).
Navigation 83
Other Functions
3 Select (quick POI selection).
4 Select the item that you want to edit.
(Following procedure show how to change the category from
ATM to SUBARU dealership on Quick POI for example.)
5 Select (automotive).
6 Select (SUBARU dealership).
84 Navigation
Other Functions
ATM bookmarked as to Quick POI.
Selecting [Default] returns the Q-POI SELECTION items to their
default settings.
SUBARU dealership search
■ SUBARU dealership search from POI
1 Press the button and select (point of inter-
est).
2 Press the (category).
3 Press the (automotive).
Navigation 85
Other Functions
4 Select (SUBARU dealer-
ship) from the list.
NOTE
• Displayed information about a specific facility might not include recent
changes. It is recommended that you check the location or business days/
hours of a desired point of interest before departure.
5 The system refine the destination search only for SUB-
ARU dealership.
■ Displaying SUBARU dealership on map
1 Touch the current map screen.
2 Select (points of interest).
3 Select (list categories).
If (SUBARU DEALER) has been registered
as a quick POI on the screen shown above, turn it on and then
proceed to step 6.
86 Navigation
Other Functions
4 Select (automotive).
5 Select (SUBARU dealer-
ship) and press (show).
The POI marker of SUBARU dealership will appear.
6 Select the SUBARU dealership marker by moving the
cross hair over it.
7 Select (info).
8 The information of SUBARU dealership will be displayed.
Navigation 87
Version and Initialization
Version
Use this function to check the version of the DVD-ROM disc
you are presently using.
1 Press the button.
2 Select (version).
3 The version of the DVD-ROM disc will be displayed on
the screen.
88 Navigation
Version and Initialization
Initialization of the navigation settings
The settings of the navigation system can be initialized. When
initialized, data such as memory points, travel history and
telephone numbers are all deleted. Data once deleted cannot
be restored.
1 Press the button.
2 Select (version).
3 Select .
4 Select .
Navigation 89
Version and Initialization
5 Select .
6 The navigation system is restarted automatically.
All of the settings are initialized.
90 Navigation
General Information
■ Accuracy of vehicle position
Area in which GPS signals cannot be received
Because the radiowave signals from the GPS satellites travel primarily
by line of sight, the navigation system might not be able to receive
the signals in the areas described below.(If the GPS mark does not
appear on the map screen, it means that the GPS radiowave signals
are not being properly received.)
(1) Inside a tunnel
(2) Inside a building
(3) Under a three-dimensional road system such as for high speed
roads
(4) On boulevards lined with trees
(5) Between buildings
(6) Under a cliff or in a cave
• If the GPS antenna or its surroundings are blocked by an obstacle
(including cargo), it might not be possible for the system to
receive the GPS radiowave signals.
• If multiple paths are created due to the reflection from buildings,
a large measurement error could occur, causing the vehicle's
mark to deviate from its actual position.
Deviation of the vehicle's position mark
The vehicle's position mark could deviate from its actual position
when the vehicle is being driven under the conditions listed below or
due to conditions of the GPS satellites.
If the vehicle travels on a road whose actual shape differs from that in
the map data, the vehicle's mark could deviate from the actual posi-
tion. The correct position will eventually appear on the screen
through the correction function. If the screen does not show the cor-
rect position for an excessively long time, correct the current position
or make an automatic correction.
(1) The vehicle's mark could appear on a parallel road.
(2) When the road splits into a narrow Y, the vehicle's mark could
appear on the other fork of the Y.
(3) When the vehicle makes a right or left turn, the vehicle's mark
could appear on one street ahead or behind.
(4) If the vehicle is transported by means other than the vehicle's
own power, such as on a ferryboat, the vehicle's mark will
remain in the position it was before the transport until the sys-
tem can calculate the position through the GPS.
(5) When the vehicle is driven on a steep incline, the vehicle's mark
could deviate from its actual position.
(6) If there are continuous gradual curves in the same direction, the
vehicle's mark could deviate from its actual position.
(7) If the vehicle is driven in a zigzag pattern, such as through fre-
quent lane changes, the vehicle's mark could deviate from its
actual position.
(8) If the vehicle is placed on a turntable, such as in a parking area,
and turned with the ignition OFF, the vehicle's mark could devi-
ate from its actual orientation. The vehicle's mark could also
deviate even after the vehicle has exited the parking area.
(9) The vehicle's mark could deviate from its actual position if the
vehicle is driven using tire chains or snow tires on a snow-cov-
ered road or on a mountainous road.
Navigation 91
General Information
(10) The vehicle's mark could deviate from its actual position after
the tires have been replaced.
■ How the vehicle position is detected
Detecting the vehicle's position through the GPS
GPS stands for "Global Positioning System", which is a system used for
detecting an object's position through the use of satellites of the U.S.
Department of Defense.
Radiowave signals from three or more satellites are received by the
navigation system, which utilizes the principle of triangulation to
detect the position at which the radiowave signals are received.
When the navigation unit is receiving the GPS radiowave signals, a
"GPS" mark will appear on the map screen.
Detecting the vehicle's position through self-contained naviga-
tion
Self-contained navigation is a system that detects the vehicle's posi-
tion by calculating the vehicle's driven distance and turning angle
though the use of various types of sensors that are mounted on the
vehicle.
Through the use of self-contained navigation, the vehicle's position
can be detected even in an area where the GPS radiowave signals
cannot be received.
Making corrections to the detection of the vehicle's position
through map matching
• In map matching, the position information resulting from the
detection of the vehicle's position and the locus of the travel of
the vehicle up to the present are constantly compared to the
shape of the roads on the map in order to correct the vehicle's
position mark to the most appropriate road.
• If the vehicle is driven on a road whose actual shape differs from
its map data, the vehicle's position mark on the map could devi-
ate from its actual position.
Occasionally, the correction of the vehicle's position mark to the
actual road on the map can be observed, particularly after the
vehicle has turned at an intersection or has exited from a parking
area.
■ Accuracy of the route guidance
The conditions listed below do not indicate a malfunction.
(1) The guidance might prompt the driver to drive straight even
though the vehicle is being driven on a straight road.
(2) The directional guidance could display multiple place names.
(3) If the vehicle makes a turn at an intersection before the guided
route, the wrong type of voice guidance could be outputted.
(4) The guidance might not be outputted while the vehicle is mak-
ing a turn at an intersection.
(5) The system might not be able to search for the proper route.
(6) If there is no road to the destination or if there is only a narrow
road, the route might be indicated up to an area that is short of
the destination.
(7) The repeat search could take a long time while the vehicle is
being driven at high speeds.
(8) While the system is searching again for the route, the route indi-
cation might not appear in time for the next right or left turn.
(9) The route might not change even if a search is made again.
92 Navigation
General Information
(10) The system might guide the driver to make a U-turn.
(11) The system might guide the driver to a road that cannot actu-
ally be travelled (such as a road to which entry is prohibited).
(12) The system might not output guidance even if the vehicle is
driven in reverse on the guided route.
(13) The system might not use a local ferryboat even if the ferry pri-
ority is selected.
(14) If the intersection that you're being guided to is near the end of
the route search, the system might not be able to provide guid-
ance.
(15) The route might not go on a toll road even if the toll-road prior-
ity is selected.
Similarly, a route that uses a toll road could appear on the
screen even if the toll-road priority is not selected. (The driver
may or may not be able to select "toll-road priority" if both toll
and free roads are available.)
Navigation 93
General Information
When a Problem Occurs
Confirm whether the problem is due to a minor operational error or a malfunction in the system by referring to the table below
before you contact your SUBARU dealer for any repair service.
The map does not scroll even when the vehicle is moving.
The screen shown might not be the current map screen.
See Page 19 of this manual for instructions on displaying the current map
screen.
The vehicle marker does not appear.
The screen shown might not be the current map screen.
See Page 19 of this manual for instructions on displaying the current map
screen.
The GPS marker is not displayed.
The GPS antenna or your vehicle might be in a position where GPS signals
cannot be received.
Try moving the GPS antenna or your vehicle to a position where there are no
obstacles around.
There is no voice guidance.
• Route guidance might be suspended.
• The guidance volume might be too low.
• See "Volume" on Page 18.
Small spots or bright flashes appear on the screen display.
This is probably due to the natural characteristics of the liquid crystal
display (LCD).
There is nothing wrong with the display and no need for concern.
The DVD-ROM disc cannot be ejected.
The disc might be incompatible or might have been inserted incorrectly.
94 Navigation
General Information
Audio and
Visual
96 Audio and Visual
Before using the Audio and Visual
Precautions when using the system
WARNING
READ THIS MANUAL FIRST
Read this supplement carefully before using your audio and visual
system. We are not liable for accidents or other problems resulting
from failure to follow the instructions in this supplement.
AVOID OPERATING THE AUDIO AND VISUAL system WHILE
DRIVING
You should stop the vehicle in a safe place before operating
the audio and visual system. For safety’s sake, some of the
audio and visual system’s functions cannot be used unless the
vehicle is stationary.
If you stare at the display with too much enthusiasm or oper-
ate the switches of the system while in driving, the navigation
system could cause your attention to be distracted from the
current traffic conditions. Please be sure to input in the system
as much information as possible before taking your departure.
And also please be sure to bring your car to a stop in a safe
place if you need to input information.
The buttons for the touch screen that cannot be used are dis-
played in light color (tone down).
Operating the navigation system while in driving could cause
your attention to be distracted from the current traffic condi-
tions. And in consequence, this could result in a severe or fatal
accident. Follow the descriptions of all operations and the
instructions for safety given in this manual without fail.
LOOK AT THE AUDIO AND VISUAL SCREEN ONLY WHEN NECES-
SARY
When you need to look at the audio and visual screen, do so
for the shortest time possible. Looking away from the road
for too long could lead to an accident.
KEEP THE VOLUME LOW ENOUGH FOR YOU TO HEAR OUTSIDE
SOUNDS
Keep the system’s volume level low enough for you to be
able to hear outside sounds while driving. To do otherwise
may mean that you are unable to react appropriately to traf-
fic conditions thus resulting in an accident.
Audio and Visual 97
Before using the Audio and Visual
■ About the audio and visual screen
• Subjecting the control buttons or liquid crystal display to excessive
shock could result in audio and visual screen deformation or other
damage.
• Keep any heat source (including lighted cigarettes) away from the
audio and visual screen. If a heat source is brought into contact with
the audio and visual system cabinet and panel, they could be
deformed or otherwise degraded.
• In extreme cold, the audio and visual screen may operate sluggishly
and the display may dim. Such conditions do not indicate a problem.
They will disappear when the cabin temperature rises to a normal
temperature.
• Tiny black and white dots may occasionally appear in the liquid crys-
tal display. These dots are a normal characteristic of the display. They
do not indicate a problem.
•
When the
audio and visual screen
requires cleaning, gently wipe it
with a silicone cloth or other soft cloth. If necessary, spray the cloth
with neutral cleaning fluid. Be sure to wipe away any cleaning fluid
left on the audio and visual screen. Do not spray the cleaning fluid
directly onto the
audio and visual screen
. Spraying cleaning fluid
directly onto the
audio and visual screen
could cause an adverse
effect on internal components. It is also not a good idea to wipe the
audio and visual screen
with a stiff cloth or attempt to clean it using
thinners, alcohol, or any other volatile solvent. Doing so could leave
scratches and/or erase the control button labels
.
• Do not allow the audio and visual screen to get wet. If it gets wet
(allowing, for example, to a spilled drink or wet umbrella), its internal
electronic circuitry may malfunction.
CAUTION
NEVER DISASSEMBLE OR MODIFY THE AUDIO AND VISUAL SYSTEM
Any attempt to disassemble or modify the audio and visual
system could lead to a fire, an electric shock, or some other
type of accident.
Do not continue using the audio and visual system if it mal-
functions
If the system shows any sign of malfunctioning (for example,
the monitor gives no picture), stop using it immediately and
contact the nearest SUBARU dealer. Continuing to use the
system could lead to a fire, an electric shock, or some other
type of accident.
If the audio and visual system gets contaminated, emits smoke
or an odd smell, stop using it
If a foreign object gets inside the system, liquid is spilled
onto the system, or the system emits smoke or an unusual
smell, stop using it immediately and contact the nearest
SUBARU dealer. Continuing to use the system could lead to a
fire, an electric shock, or some other type of accident.
98 Audio and Visual
Before using the Audio and Visual
• In hot weather, cool the passenger compartment down before using
the audio and visual system. The liquid crystal display operates cor-
rectly at temperatures between 0°C and 60°C (32°F and 140°F). When
the temperature exceeds 60°C (140°F), the audio and visual system
circuit protection function is activated, causing the display to dim.
NOTE
• In the interest of safety, the use of some functions may be unavailable while in
driving. The button for a touch screen that cannot be used will be displayed in
tint color (toned down).
• Liquid-crystal displays may be difficult to read when wearing polarized
glasses.
Audio and Visual 99
Before using the Audio and Visual
Discs that can be used
For the in-vehicle equipment, it is possible to look and listen
to discs attached with the marks shown below.
NOTE
• Special discs are not supported that are not compliant with the formal CD
specifications such as the copy control CD.
• Discs such as CD-R(CD-Recordable) and CD-RW(CD-ReWritable) may not be
played back when they are inferior in their recording condition and character-
istics, when they get scratched or stained, or when they get deteriorated due
to being left in the vehicle for a long time. And when CD-R and CD-RW has
not been treated for finalization, they cannot be played back.
Music CD DVD Video
CAUTION
• Handle the disc with care so that it does not get smeared
with fingerprints and stain, or does not get scratched.
• When handling the disc, be sure to hold it at the center hole
and the edge with the labeled side up.
• When the disc gets stained, wipe it lightly with a soft, dry
cloth for spectacles with plastic lenses. Pressing the disc hard
with your hand or rubbing it with a hard cloth may cause
scratches on the surface. And, avoid the use of a solution
such as record spray, antistatic agent, alcohol, benzine and
thinner, or chemical duster. This may cause damage to the
disc, rendering it unusable.
• After pressing the disc eject switch, do not leave it in the
ejected condition for a long stretch of time. This may cause
warp to the disc, thus rendering it unusable.
• Store the disc away from direct sunlight, which may cause
warp to it, thus rendering it unusable.
• Discs that can be played back are limited only to those with a
circular form 12 or 8 cm in diameter.
Avoid using irregular sized discs, which may cause malfunc-
tion to the equipment.
• The DualDisc is not supported. Avoid using it, which may
cause malfunction to the equipment.
100 Audio and Visual
Before using the Audio and Visual
• Avoid the use of discs of which the recording section is trans-
parent or translucent. These discs may not be inserted or
ejected, or played back normally.
• Using lens cleaner may cause malfunction to the pick-up sec-
tion of the player. Be sure not to use it.
• Do not use discs attached with scotch tape, seal or CD-R
label, or those having traces of them. Using these discs may
cause malfunction to the player with the ejection of discs
unavailable.
Audio and Visual 101
Before using the Audio and Visual
Player
When there occurs an abnormal condition, the player stops
automatically to protect the inside mechanism of the player.
Even when conducting the operation according to the mes-
sage displayed on the screen and the function is stopped, a
malfunction may result. Get a checkup of the player at Subaru
Dealer.
In the following cases other than malfunction, the player may not oper-
ate normally.
• When the disc can not read due to it being stained.
• When the player is out of order.
• When an abnormal temperature of the player has been detected.
(When the sign disappears after the temperature of the player gets
back to the normal temperature, the player can be used.)
• When there occurs a dew condensation. (When it is cold or rains,
there occurs a dew condensation inside the player just as the inner
surface of the vehicle glass clouds up. In such a case, the audio
sound may be disturbed or the playback may be stopped. Ventilate
or dehumidify the player for a while before using it.)
• When vibrated severely due to driving on rough roads. (The sound
may be disturbed.)
102 Audio and Visual
Before using the Audio and Visual
Character information displayed
The number of characters that can be displayed as informa-
tion on various screens and the audio display is limited, and it
sometimes occurs that all of the characters cannot be dis-
played. And also, they may not be, or cannot be, displayed
correctly depending on the contents of the recorded informa-
tion like these.
And the contents of the character information like these may
sometimes differ for various screens and the audio display.
Audio and Visual 103
Basic operation of the Audio and Visual
Name of each part
The following are the name of each part that is used when
using the audio and visual function.
■ In-vehicle equipment
Operating the touch switches and buttons of the in-vehicle equipment
allows you to use the audio function.
(1) Touch Switch
Selecting the touch switch displayed on the screen allows
you to play back the disc and/or tune in to a radio station.
(2) POWER/VOLUME
Pressing this button allows you to turn on/off the audio func-
tion, and turning it allows you to adjust the sound volume.
(3) SEEK / TRACK
Pressing these buttons allows you to select a tune, track and/
or radio station with the source that you are now looking and
listening to. And pressing them continuously for more than
0.5 seconds allows you to fast-forward or fast-rewind a tune,
and/or search a radio station automatically.
(4)
Using this button allows you to search a tune, track or radio
station with the source that you are now looking and listen-
ing to.
(5) MODE/TUNE
Pressing this button allows you to select a source such as CD,
radio, SAT and VIDEO. (When selecting SAT or VIDEO, it is nec-
essary for the relevant unit to be connected.) And turning it
in either direction allows you to tune in on a radio station or
forward/rewind a CD track.
(6)
Used to switch over to the screen of the source that you are
now looking and listening to.
(7)
This allows you to set a disc and eject it, and it also allows you
to tilt the screen.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
104 Audio and Visual
Basic operation of the Audio and Visual
■ Audio control buttons (if equipped)
These buttons are located on the spokes of the steering wheel. They
allow the driver to control audio functions without taking his/her hands
off the steering wheel.
MODE button
This button is used to select the desired audio mode. Each time it is
pressed, the mode changes to the next one in the following sequence:
*1: The frequency last received in the selected waveband will be displayed.
*2: Only when a DISC is in the player.
and buttons
These are used for various operations within each source of the audio
and visual.
• With radio mode selected
Pressing the button or button for a short time allows you
to skip to a preset channel, and pressing it for a long time also allows
you to seek a next receivable station.
• With CD mode selected
Press the button to skip forward in the track/file (track) order.
Press the button to skip backward in the track/file (track) order.
The track/file (track) number will be shown on the audio display.
• With SAT mode selected
Press the button to skip forward in the channel order. Press the
button to skip backward in the channel order. The channel will
be shown on the audio display.
MODE
MODE
Audio and Visual 105
Basic operation of the Audio and Visual
Volume control buttons
Press the “+” button to increase the volume. Press the “-” button to
reduce the volume.
A number indicating the volume will be shown on the audio display.
MUTE button
Press this button if you wish to immediately cut the volume to zero.
The audio display will show “MUTE”.
If you press the button again, the original sound volume will return and
“MUTE” goes off.
MODE
MODE
106 Audio and Visual
Basic operation of the Audio and Visual
Turning on the power
Turn on the power for the audio and visual.
1 Conduct either of the following operations.
• Press the [POWER/VOL] button.
• Press the [MODE/TUNE] button.
• Press the [MODE] switch of the steering switch.
• With the button pressed, select the source.
NOTE
• Each time the [POWER/VOL] button or the [MODE] switch of the steering
switch is pressed, the audio function is turned on and off.
• Inserting the disc turns on the power automatically to start the playback of
the disc.
Audio and Visual 107
Basic operation of the Audio and Visual
Selecting the source
It is possible to make a switch among AM radio, FM radio, SAT,
VIDEO, CD, DVD, MP3/WMA and other externally connected
equipment for looking and listening. When selecting SAT and
VIDEO, it is necessary for the relevant units to be connected.
Pressing the button for selection
Pressing the button or the steering switch of the in-vehicle equipment
allows you to switch over the source.
1 Press the [MODE/TUNE] button or the [MODE] button of
the steering switch.
Each time the button is pressed, the source is changed over.
When the operations above are conducted on other than the
audio screen, the brief description of the audio is displayed in the
upper section of the screen for a few seconds.
Example of the CD information displayed while in the map display
When the operations above are conducted on the audio screen,
each source screen is displayed as following example.
FM radio screen
AM radio screen
108 Audio and Visual
Basic operation of the Audio and Visual
CD screen
DVD screen
MP3/WMA screen
VIDEO screen (The display varies with the externally connected
equipment.)
NOTE
• When the disc is not set or when no externally connected equipment is pro-
vided, the source is not displayed.
• When the satellite radio is connected, it is displayed on the dedicated source
screen in the same manner as with the AM or FM radio.
Audio and Visual 109
Basic operation of the Audio and Visual
Making a selection by touching
Touching the source display allows you to select a source.
1 Press the button.
When the source display is shown, proceed to step 3.
2 Press again the button.
3 Select a source.
Each of the source screens is displayed.
NOTE
Sources displayed vary with the equipment connected.
110 Audio and Visual
Basic operation of the Audio and Visual
Setting and adjusting the sound
Adjusting the sound volume
It is possible to adjust the sound volume while looking and listening to
the source.
NOTE
When the voice of the navigation system breaks in, the sound volume is auto-
matically reduced temporarily.
1 Rotate the [POWER/VOL] button in either direction or
press the [+][-] switches of the steering switch.
• Turning the [POWER/VOL] button counterclockwise decreases
the sound volume while turning it clockwise increases the
sound volume.
• Each time the [-] button of the steering switch is pressed, the
sound volume decreases, and each time the [+] button is
pressed, it increases.
• The volume level is displayed in figures on the upper right sec-
tion of the screen.
NOTE
For detailed setting of the sound quality and balance, refer to "Setting the audio"
on Page 158.
Turning off the sound
It is possible to mute temporarily.
1 Press the (mute) switch of the steering switch.
Press again the (mute) switch of the steering switch or
adjust the sound volume to cancel the mute.
NOTE
• When pressing the
(mute) switch while in the use of the hands-
free function, the audio sound volume turns off automatically and the follow-
ing operations are available.
• Pressing the
(mute) switch while in the incoming call with the
handsfree allows you to take a phone call.
• Pressing the switch continuously for more than 0.5 seconds while in the
incoming call with the handsfree allows you to put a phone call on hold.
• While in the incoming call with the handsfree, pressing the switch continu-
ously for more than 0.5 seconds with a phone call put on hold allows you to
hang up the phone.
• For details of the sound volume adjustment, refer to "Adjusting the sound vol-
ume" on Page 110.
Audio and Visual 111
Basic operation of the Audio and Visual
Handling the disc
Setting the disc
Set a CD, DVD, or MP3/WMA disc.
For details of the discs that can be used, refer to "Discs that can be used"
on Page 99.
1 Press the button.
2 Select (DVD/CD).
The monitor section is tilted and, when a disc has been set, it is
ejected.
3 When the disc is ejected, take it out.
4 Insert the disc.
The monitor automatically gets back to the normal condition to
start the playback of the disc.
CAUTION
When inserting a CD, do not insert 2 or more CD's in piles. This
may cause a malfunction to the player, resulting in the take-off
of the discs unavailable.
112 Audio and Visual
Basic operation of the Audio and Visual
Taking out the disc
Take out a CD, DVD or MP3/WMA disc from the in-vehicle equipment.
1 Press the button.
2 Select (DVD/CD).
The monitor section is tilted and the disc is ejected.
3 Take out the disc.
4 Press the button.
The monitor will get back to the normal condition.
Audio and Visual 113
Listening to the radio
Listening to the radio
It is possible to tune in to a radio station to listen to the AM or
FM radio.
1 Change the source over to the FM radio or AM radio.
(See Page 107.)
2 Tune in to a station. (See Page 116.)
FM radio screen displayed
When no FM radio screen is displayed while listening to the FM radio,
press the button to display the FM radio screen.
(1) Clock
The current time is displayed.
(2) FM display
The difference between the FM1 and FM2 frequency bands is
displayed.
(3) Station tuned in to
The name of the station tuned in to and its frequency are dis-
played. When the station is preset, the preset number is also
displayed.
(4) LOCAL
Displayed while in the LOCAL mode.
(5) ST
Displayed while in the stereophonic broadcast.
(6) VOL
The volume level is displayed. (See Page 110.)
(7) SCAN
Displayed when scanning a station to which you can tune in.
(See Page 117.)
(8) Preset keys 1 to 6
It is possible to preset a station and invoke it later. (See Page
119.)
(1) (2)
(4) (5)
(7)
(3)
(6)
(8)
(9) (10) (11) (12)
114 Audio and Visual
Listening to the radio
(9) (SETTING)
Select this to display the screen set for the audio. (See Page
158.)
(10) (BAND)
Each time this is selected the discrimination of the frequency
band (FM1/FM2) changes over.
(11) (LO/DX)
Each time this is selected, the local mode can be turned on
and off. When the local mode is set, the search of a station
can be made starting with a station that is located in the area
receiving higher-intensity radio waves clearly.
(12) (PTY SEARCH)
Selecting this allows you to search a station with a category
of interest selected. (See Page 117.)
AM radio screen displayed
When the AM radio screen is not displayed while listening to the AM
radio, press the button to display the AM radio screen.
(1) Clock
The current time is displayed.
(2) AM display
AM is displayed.
(3) Station tuned in to
The name of the station tuned in to and its frequency are dis-
played. When the station is preset, the preset number is also
displayed.
(4) LOCAL
Displayed while in the LOCAL mode.
(1) (2)
(4) (5)
(6)
(3)
(7)
(8) (9)
Audio and Visual 115
Listening to the radio
(5) VOL
The volume level is displayed. (See Page 110.)
(6) SCAN
Displayed when scanning a station to which you can tune in.
(See Page 117.)
(7) Preset keys 1 to 6
It is possible to preset a station and invoke it later. (See Page
119.)
(8) (SETTING)
Select this to display the screen set for the audio. (See Page
158).
(9) (LO/DX)
Each time this is selected, the local mode is turned on and off.
When the local mode is set, the search of a station can be
made starting with a station that is located in the area receiv-
ing radio waves clearly.
116 Audio and Visual
Listening to the radio
Selecting a station
Selecting a station that is preset
Presetting a station in advance in the in-vehicle equipment allows you
to invoke that station.
1
Select the station preset on the FM radio screen or AM radio
screen, or press the or button of the steering switch.
• When the FM radio screen or AM radio screen is not displayed,
press the button.
• Each time the or button of the steering switch is
pressed, the station preset changes over. Pressing the
button changes over the station in the descending order of the
preset number, while pressing the button changes it over
in ascending order of the preset number.
NOTE
For detailed method for presetting a station, refer to "Presetting a station" on
Page 119.
Setting the frequency
It is possible to set the frequency manually to listen to the radio.
1 Rotate the [MODE/TUNE] button in either direction.
• Turning the [MODE/TUNE] button counterclockwise lowers the
frequency and turning it clockwise heighten the frequency.
• For the FM radio, select (BAND) to make selection of the
BAND. Each time (BAND) is selected, a changeover is
made between FM1 and FM2.
Audio and Visual 117
Listening to the radio
Searching a station automatically
It is possible to search a station that can be tuned in to automatically to
listen to a radio.
1 Press the or button.
• Pressing the button allows you to search a station that
can be tuned in to in the higher-intensity frequency direction,
while pressing the button allows you to make a search of
a station in the lower-intensity frequency direction.
• Conducting this operation with "LOCAL" displayed on the FM
screen after selecting (LO/DX) allows you to search a sta-
tion with excellent radio waves in the surrounding. However, in
the condition in which "LOCAL" is displayed, a radio station is
searched with the detection sensitivity of radio waves reduced.
Accordingly, it becomes difficult to search a station in the area
with low-intensity radio waves.
• For the FM radio, select (BAND) to make selection of the
BAND. Each time (BAND) is selected, a changeover is
made between FM1 and FM2.
Searching a FM station from a category of interest
It is possible to select a category of interest and make search of a station
to listen to a radio.
1 Select (PTY SEARCH).
2 Select a category of interest and then select [SEARCH].
Categories that can be selected are as shown below.
•INFO
•WEATHER
118 Audio and Visual
Listening to the radio
•ROCK
•SOFT
•TOP40
• COUNTRY
•OLDIES
•JAZZ
•CLASSIC
•R&B
• RELIGIOUS
•MISC
•ALL
• Selecting scrolls the display to display a category 5 posi-
tions ahead.
• Selecting scrolls the display to display a category 5 posi-
tions behind.
A station corresponding to the category is selected.
NOTE
• This function is available only for the FM radio.
• Each time [SEARCH] is selected, another station can be searched.
Audio and Visual 119
Listening to the radio
Presetting a station
It is possible to store in the memory a station frequently lis-
tened to and invoke it later.
Presetting a station that is now being tuned in to
It is possible to preset a station that is now being tuned in to. Conduct-
ing this operation with a key that is preset already causes the preset key
to be overwritten.
1 Press the preset key for more than 2 seconds.
• When the FM radio screen or AM radio screen is not displayed,
press the button (12).
• For the FM radio, select (BAND) to make selection of the
BAND. Each time (BAND) is selected, a changeover is
made between FM1 and FM2.
The frequency preset is displayed in the preset key.
NOTE
For detailed method for invoking a station preset, refer to "Selecting a station
that is preset" on Page 116.
Presetting a station that can receive radio waves
automatically
It is possible to search and preset a station that can receive radio waves
automatically.
1 Press the button.
• SCAN is displayed on the screen. Pressing the button
again terminates the search of a station.
• Conducting this operation with "LOCAL" displayed on the FM
screen after selecting (LO/DX) allows you to make search
of a station with excellent radio waves in the surrounding.
• For the FM radio, select (BAND) to make selection of the
BAND. Each time (BAND) is selected, a changeover is
made between FM1 and FM2.
The frequency preset is displayed in the preset key.
120 Audio and Visual
Listening to the CD
Listening to a tune in the CD
It is possible to set the CD in the in-vehicle equipment to lis-
ten to a tune in the CD.
1 Change the source over to the disc. (See Page 107.)
The track of the CD is played back from the start.
When the track of the CD is played back to the last, the playback
resumes from the start.
NOTE
When no CD is set in the in-vehicle equipment, set the CD. (See Page 111.)
Audio and Visual 121
Listening to the CD
CD screen displayed
When the CD screen is not displayed while looking and listen-
ing to the CD, press the button to display the CD
screen.
(1) Clock
The current time is displayed.
(2) TRACK
The track number is displayed.
(3) STATE
The playback status is displayed.
: Playback is going on.
: Fast rewind is going on.
: Fast forward is going on.
Pause
(4) FUNCTION
The playback status such as repeat and random is displayed.
RPT: A tune is being played back repeatedly.
F. RPT: Tunes in the folder are being played back repeatedly.
RDM: Tunes in the CD are being played back in random
order.
SCAN: Each of the tunes in the CD is being played back for
10 seconds.
(5) VOL
The volume level is displayed. (See Page 110.)
(6) TIME
The playback time of a tune is displayed.
(7) DISC
When corresponding to the CD text, the disc name is dis-
played.
(8) TRACK
When corresponding to the CD text, the title of a tune is dis-
played.
(9) ARTIST
When corresponding to the CD text, the name of an artist is
displayed.
:Displayed when the contents of the CD text cannot be displayed for
each item. Selecting this scrolls the characters. When scrolled up to the
end of the text, is displayed.
(1) (2)
(3)
(4)
(5)
(6)
(10)
(11) (12)
(7)
(8)
(9)
(13)
122 Audio and Visual
Listening to the CD
(10) (SETTING)
Selecting this displays the screen set for the audio. (See Page
158.)
(11) (RDM)
The playback method of tunes is changed over in random
order. (See Page 127.)
(12) (RPT)
The playback method of tunes is changed over to the
repeated playback. (See Page 126.)
(13) (LIST)
Tunes contained in the CD are displayed in the list. (See Page
124.)
Audio and Visual 123
Listening to the CD
Selecting a tune
Selecting the preceding tune
It is possible to play back a tune preceding the one that is now being
played back.
1 Conduct either of the following operations while playing
back a tune.
• Press the button.
• Rotate the [MODE/TUNE] button counterclockwise.
• Press the button of the steering switch.
A tune preceding the one that is now being played back is played
back.
Selecting the succeeding tune
It is possible to play back a tune succeeding to the one that is now
being played back.
1 Conduct either of the following operations while playing
back a tune.
• Press the button.
• Rotate the [MODE/TUNE] button counterclockwise.
• Press the button of the steering switch.
The succeeding tune is played back.
124 Audio and Visual
Listening to the CD
Selecting a tune from the list
It is possible to display in the list tunes contained in the CD, and select a
tune from the list to play it back.
1 Press the button.
When the CD screen has been displayed, this operation is not
required. Proceed to step 2.
2 Select (LIST).
3 Select a tune you want to listen to.
• Selecting scrolls the display to display a tune 5 positions
ahead.
• Selecting scrolls the display to display a tune 5 positions
behind.
A tune that is selected is played back.
NOTE
• Selecting (HOME) displays a page containing a tune that is now
being played back.
• Selecting (CONTROL) gets back to the screen in which the tune infor-
mation is displayed.
Audio and Visual 125
Listening to the CD
Searching a tune while listening
It is possible to search a tune you want to hear while listening to each
tune in the CD for 10 seconds.
1 Press the button while playing back a tune.
"SCAN" is displayed for the FUNCTION on the CD screen.
After a tune you want to hear is played back, press again the
button.
Fast-rewinding or fast-forwarding a tune
It is possible to fast-rewind or fast-forward a tune that is now being
played back.
■ To rewind a tune quickly
1 Keep pressing the button while playing back a tune.
A tune is rewound quickly while the button is kept pressed. When
releasing the button, the tune is played back from the point
to which the tune was fast-rewound.
■ To fast-forward a tune
1 Keep pressing the button while playing back a tune.
A tune is forwarded quickly while the button is kept pressed.
When releasing the button, the tune is played back from the
point to which the tune was fast-forwarded.
126 Audio and Visual
Listening to the CD
Listening to a tune repeatedly
It is possible to play back a tune repeatedly.
1 Select (RPT) while playing back a tune.
"RPT" is displayed for FUNCTION on the CD screen to play back a
tune repeatedly.
Selecting again (RPT) releases the repeated playback.
Audio and Visual 127
Listening to the CD
Listening to tunes in random order
It is possible to play back the tunes in the CD in random order.
1 Select (RDM) while playing back a tune.
With "RDM" displayed for FUNCTION on the CD screen, tunes are
played back in random order.
Selecting again (RDM) releases the playback in random
order.
128 Audio and Visual
Listening to MP3/WMA disc
MP3/WMA
MP3/WMA can be played back by this in-vehicle equipment.
However, media and formats are limited in which MP3/WMA
files that can be used are recorded. Please note the following
when writing MP3/WMA files. The limited number of charac-
ters given below is the number of characters when using 1-
byte characters.
■ Media that can be used
Media used to include MP3/WMA that can be used are CD-R and CD-
RW.
Media created in a simplified format cannot be played back with this in-
vehicle equipment.
■ MP3 formats that can be played back
MP3 formats that can be played back with this in-vehicle equipment are
as shown below.
Specification
MPEG-1 Layer 3
MPEG-2 Layer 3
MPEG-2.5 Layer 3
Sampling frequency
8, 11.025, 12, 16, 22.05, 24, 32, 44.1, 48 (kHz)
Bit rate
8 to 320 (kbps)
Variable bit rate compliant
■ WMA formats that can be played back
WMA files that can be played back with the in-vehicle equipment are as
shown below.
Specifications
WMA Ver. 7, 8 and 9
Sampling frequency
Ver. 7: 44.1, 48 (kHz)
Ver. 8 and 9: 32, 44.1, 48 (kHz)
Bit rate
Ver. 7: 64 to 192 (kbps)
Ver. 8 and 9: 48 to 192 (kbps)
Variable bit rate compliant
■ Disc formats that can be used
Discs that can be used with this in-vehicle equipment are as shown
below. The number of characters following the format name is the max-
imum number of characters (a delimiter "." and 3 characters of exten-
sion included) specified for the file name.
• ISO 9660 Level 1: 12 characters
• ISO 9660 Level 2: 31 characters
• Joliet: 64 characters
• Romeo: 128 characters
And when written in a long file name format, it is possible to display up
to the number of characters as shown below.
64 character (all 1-byte characters)
Audio and Visual 129
Listening to MP3/WMA disc
For details of the characters that can be used, refer to the instruction
manual of the writing software and "Input of file name and folder
name."
However, characters that can be displayed are as shown below.
• Half size characters (alphanumeric, and ASCII codes)
Characters other than the above are displayed with an asterisk "?."
However, discs that can be played back with this in-vehicle equipment
are accompanied by the following restrictions.
• Maximum directory layers: 8 layers
• Maximum number of files in a folder: 255
• Maximum number of folders: 254 (including the ROOT)
• Maximum number of characters used in a folder name: 64 characters
MP3/WMA files that are written in formats other than the above may
not be played back normally, and the file name and the folder name of
which may not be displayed correctly.
■ Setting of the compression software and the writing
software
When compressed into an MP3/WMA file, it is recommended that the
setting of the transfer bit rate of the compression software is "fixed" to
"128 kbps."
When recording a blank media up to the maximum capacity at once,
make a setting to "Disc at Once."
■ Input of a file name and a folder name
When inputting a file name and a folder name, input them in half size
alphanumeric characters. File names and folder names that are written
in characters other than the above may not be displayed correctly. And
depending on a writing software or a disc format used, characters that
can be displayed are restricted. For details, refer to the instruction man-
ual of the writing software. And files that can be acknowledged and
played back are restricted only to those attached with an extension
".M P3" o r ".W MA." Whe n sav ing a n MP 3/WMA file, be sure to attach it
with an extension ".MP3" or ".WMA."
Forbidden
If a file other than MP3/WMA is attached with an extension ".MP3" or
".WMA," it may be mistakenly acknowledged as an MP3/WMA file,
thus causing the generation of loud noises to damage the speaker.
So, do not attach any file other than MP3/WMA with an extension
".MP3 " o r ". W MA ."
■ ID3/WMA Tag
ID3/WMA Tag is compliant (Ver.1.0, 1.1).
130 Audio and Visual
Listening to MP3/WMA disc
■ Files that are written into media
When media that contains MP3/WMA files is inserted, first of all, all the
files in the disc are checked.
So, when a lot of folders and files other than MP3/WMA are written into
the media to be played back, a lot of time is required before starting the
playback of the media.
And time may be required before proceeding to the playback of the
next MP3/WMA file, and a file search and a folder search cannot be con-
ducted smoothly.
■ Sequence in which MP3/WMA files are played back.
The sequence in which files and folders are selected while in the play-
back, folder search, file search and the folder selection is in the order in
which they are written with the writing software. Accordingly, the
sequence in which the files are expected to be played back may not
conform to the sequence in which the files are actually played back.
Depending on the writing software, entering "01" to "90" at the head of
the file name as a playback sequence with it written in CD-R may allow
you to set the sequence in which files are played back. Conducting a
folder search, a file search and a folder selection in the media of the fol-
lowing folder/file layer results in a media hierarchy as shown below.
■ Example of Media hierarchy
Audio and Visual 131
Listening to MP3/WMA disc
Listening to tunes (file) in the MP3/WMA disc
It is possible to set the MP3/WMA disc in the in-vehicle equip-
ment to listen to tunes (files) in the disc.
1 Change the source over to the disc. (See Page 107.)
The first tune in the lead folder in the MP3/WMA disc is played
back from the start.
When the tunes in the folder are played back to the last, the first
tune in the lower-order or next folder is played back.
When the tunes in the MP3/WMA disc are played back to the last,
the playback is resumed from the first tune in the lead folder.
NOTE
When no MP3/WMA disc is set in the in-vehicle equipment, set the MP3/WMA
disc. (See Page 111.)
132 Audio and Visual
Listening to MP3/WMA disc
MP3/WMA disc screen displayed
When no MP3/WMA disc screen is displayed while looking
and listening to the MP3/WMA disc, press the button
to display the MP3/WMA disc screen.
(1) Clock
The current time is displayed.
(2) STATE
The playback status is displayed.
: Play back is going on.
: Fast rewind is going on.
: Fast forward is going on.
Pause
(3) FUNCTION
The playback status such as repeat and random is displayed.
RPT: A tune is being played back repeatedly.
RDM: Tunes in the MP3/WMA disc are being played back in
random order.
SCAN: Each of the tunes in the MP3/WMA disc is being
played back for 10 seconds.
(4) VOL
The volume level is displayed. (See Page 110.)
(5) TIME
The playback time of a tune is displayed.
(6) FOLDER
The folder name is displayed.
(7) FILE
The file name is displayed.
(8) TITLE
The title of a tune is displayed.
(9) ALBUM
The name of an album is displayed.
(1) (2)
(3)
(4)
(5)
(11)
(13) (14)
(6)
(7)
(8)
(15)
(9)
(10)
(12)
Audio and Visual 133
Listening to MP3/WMA disc
(10) ARTIST
The name of an artist is displayed.
(11) (SETTING)
Selecting this displays the screen set for the audio. (See Page
158.)
(12)
Used to play back the first tune in the succeeding/preceding
folder. (See Page 134.)
(13) (RDM)
Used to change over the playback method of tunes in ran-
dom order. (See Page 127.)
(14) (RPT)
Used to change the playback method of tunes over to the
repeated playback. (See Page 126.)
(15) (LIST)
Used to display the folders or tunes in the MP3/WMA disc in
the list. (See Page 134 and 136.)
:Displayed when the contents of the CD text cannot be displayed for
each item. Selecting this scrolls the characters. When scrolled up to the
end of the text, is displayed.
134 Audio and Visual
Listening to MP3/WMA disc
Selecting a tune
Selecting a folder that you want to hear
Select a folder in the MP3/WMA disc.
■ To select a folder
1 Select or .
Selecting plays back the first tune in the succeeding folder.
Selecting plays back the first tune in the preceding folder.
■ To select a folder from the list
1 Select (LIST).
2 Select (UP).
3 Select the folder name.
• Selecting scrolls the display to display a folder 5 positions
ahead.
• Selecting scrolls the display to display a folder 5 positions
behind.
• Selecting (HOME) displays in the list the tunes in the
folder in which a tune that is now being played back is con-
tained.
Audio and Visual 135
Listening to MP3/WMA disc
• When the tunes are displayed in the list, selecting [UP] displays
the folder list.
• Selecting (CONTROL) gets back to the MP3/WMA disc
in which the tune information is displayed.
The first tune in the folder selected is played back.
Selecting a tune (file) you want to hear
Select a tune (file) in the MP3/WMA disc.
■ To select the preceding tune
It is possible to play back a tune in the high-order folder of the tune that
is now being played back or the preceding tune.
1 Conduct either of the following operations while playing
back a tune.
• Press the button.
• Rotate the [MODE/TUNE] button counterclockwise.
• Press the button of the steering switch.
The preceding tune is played back.
■ To select the succeeding tune
It is possible to play back a tune succeeding the tune that is now being
played back.
1 Conduct either of the following operations while playing
back a tune.
• Press the button.
• Rotate the [MODE/TUNE] button clockwise.
• Press the button of the steering switch.
The succeeding tune is played back.
136 Audio and Visual
Listening to MP3/WMA disc
■ To select a tune from the list
1 Select (LIST).
2 Select the tune name.
• Selecting scrolls the display to display a folder 5 positions
ahead.
• Selecting scrolls the display to display a folder 5 positions
behind.
• Selecting (HOME) displays in the list the tunes in the
folder in which the tune that is now being played back is con-
tained.
• When the tunes are displayed in the list, selecting up displays
the folder list.
• Selecting (CONTROL) gets back to the MP3/WMA disc
in which the tune information is displayed.
The tunes in the folder are displayed in the list.
A tune selected is played back.
Audio and Visual 137
Listening to MP3/WMA disc
■ To search a tune while listening to tunes in the folder
It is possible to search a tune you want to hear while listening to each of
the tunes in the folder for 10 seconds. After all the tunes in the folder
are played back, the player gets back to the normal playback mode.
1 Press the button while playing back a tune.
"SCAN" is displayed for FUNCTION on the MP3/WMA screen.
After completion of the playback of a tune you want to hear, press
again the button.
Fast-rewinding or fast-forwarding a tune
It is possible to rewind or forward quickly a tune that is now being
played back.
■ To rewind a tune quickly
1 Keep pressing the button while playing back a tune.
A tune is rewound quickly while the button is kept pressed. When
releasing the button, the tune is played back from the point
to which the tune was rewound.
■ To forward a tune quickly
1 Keep pressing the button while playing back a tune.
A tune is forwarded quickly while the button is kept pressed.
When releasing the button, the tune is played back from the
point to which the tune was forwarded.
138 Audio and Visual
Listening to MP3/WMA disc
Listening to a tune repeatedly
It is possible to listen to the same tune or the tunes in the folder repeat-
edly.
■ To listen to the same tune repeatedly
It is possible to play back the same tune repeatedly.
1 Select (RPT) while playing back a tune.
With "RPT" displayed for FUNCTION on the MP3/WMA screen, the
tune is played back repeatedly.
• Selecting (RPT) allows you to listen to the tunes in the
folder repeatedly. Select again (RPT) to release the
repeated playback.
• When "F.RPT" is displayed for FUNCTION, the MP3/WMA is set to
the mode for listening to the tunes in the folder.
■ To listen to the tunes in the folder repeatedly
It is possible to play back the tunes in the folder repeatedly.
1 Select (RPT) twice while playing back a tune.
With "F.RPT" displayed for FUNCTION on the MP3/WMA screen,
the tunes in the folder are played back repeatedly.
• Selecting again (RPT) releases the repeated playback.
• When "RPT" is displayed for FUNCTION, the mode is set in
which the same tune is played back repeatedly. Select
(RPT) again.
Audio and Visual 139
Listening to MP3/WMA disc
Listening the tunes in random order
It is possible to play back the tunes in the folder in random order. After
all the tunes in the folder are played back, the tunes in the next folder
are played back in random order.
1 Select (RDM) while playing back a tune.
With "RDM" displayed for FUNCTION on the MP3/WMA screen, the
tunes in the folder are played back in random order.
• After all the tunes in the folder are played back, the tunes in the
next folder are played back in random order.
• Selecting (RDM) again releases the random playback.
140 Audio and Visual
Looking at the DVD
NOTE
• Using the Audio and Visual System with the engine stopped could lower the
battery’s electricity level. If the initial charge level is too low, the engine may
not start the next time. It is recommended that the system be used only when
the engine is running expect when the vehicle is parked in a garage or other
enclosed area.
• In the interest of safety, the use of some functions may be unavailable while in
driving. The button for a touch screen that cannot be used will be displayed in
tint color (toned down).
• Liquid-crystal displays may be difficult to read when wearing polarized glasses.
WARNING
• Never try watching videos or using other entertainment pro-
grams with your Audio and Visual System by keeping the
vehicle engine running in a garage or other enclosed area.
Exhaust gases accumulated in such an area or entering the
vehicle are dangerous, or even lethal.
• The driver must not attempt to operate or watch the DVD
while the vehicle is in motion. Doing so will distract attention
from driving and the road, and could lead to an accident.
• If you wish to park your vehicle and enjoy an entertainment
program on this system, select a safe place that does not
hinder traffic and has no parking ban.
Audio and Visual 141
Looking at the DVD
What must be known
Manufactured under license from Dolby Laboratories.
"Dolby," "Pro Logic," and the double-D symbol are trademarks of Dolby
Laboratories.
Non disclosed confidential writings: Copyright: Dolby Laboratories,
1992 to 1997
No reproduction allowed
"DTS" and "DTS Digital Surround" are registered trademarks of Digital
Theater Systems, Inc.
Operations while in the playback of the disc
For DVD video, DVD audio and video CD, the playback condition has
been specified according to the instruction of software manufacturers.
This DVD player, because of it being played back according to the
instructions intended by the software manufacturer, may not some-
times function as intended when operated. Be sure also to read
through the instruction manual attached to a disc to be played back.
DVD video and DVD audio
They are compliant with the NTSC color television format.
■ Region code of discs that can be played back
For some discs, a region code is displayed that stands for a region
(country) of the player in which a disc can be played back.
Of discs attached with a region code, those with "1" (a code standing
for North America) not included in its region code list or those with
"ALL" (for worldwide use) not displayed cannot be played back with this
DVD player.
When playing back a disc like this, a message "REGION CODE ERROR" is
displayed on the screen. And for discs with no region code displayed,
their region for use may have been restricted. On an occasion like this,
the playback with this DVD player may not be available.
142 Audio and Visual
Looking at the DVD
Playing back the DVD
It is possible to set a DVD on the in-vehicle equipment to look
at and listen to it.
1 Change the source over to the disc. (See Page 107.)
When a DVD is not yet set on the in-vehicle equipment, set a DVD.
(See Page 111.)
The DVD is played back.
Audio and Visual 143
Looking at the DVD
DVD control screen displayed
When the DVD screen is not displayed while in the playback
of a DVD, press the button to display the DVD screen.
And then selecting the screen displays the DVD control
screen.
NOTE
When 10 seconds has elapsed with no key selected, the display disappears.
(1) Clock
The current time is displayed.
(2) TITLE
The title number of the DVD that is being played back is dis-
played.
(3) CHAPTER
The chapter number of the DVD that is being played back is
displayed.
(4) STATE
The playback condition of the chapter is displayed.
: The playback is in progress.
: The playback is stopped.
: The playback is stopped while keeping the playback
condition just before stop.
: The playback is stopped temporarily.
: The DVD is rewinding quickly.
: The DVD is forwarding quickly.
(5) TIME
The playback time of the chapter is displayed.
(6) VOLUME
The volume level is displayed.
(7) (CONTROL)
Selecting this displays the DVD setting screen.
(8) (PAUSE)
The DVD image is stopped temporarily.
(9) (PLAY)
The playback of the DVD image is started.
(1) (2)
(3)
(4)
(7)
(8) (9) (11)
(5)
(6)
(10) (12)
144 Audio and Visual
Looking at the DVD
(10) (STOP)
The playback of the DVD image is stopped.
(11) (MENU CONTROL)
The screen is changed over in which the menu is operated.
See Page 149.
(12) (T.SEARCH)
The DVD image can be played back with the title specified.
See Page 145.
Audio and Visual 145
Looking at the DVD
Selecting the title and the chapter
Selecting the chapter
■ To play back the preceding chapter
1 Conduct either of the following operations while in the
DVD playback.
• Press the button.
• Rotate the [MODE/TUNE] button counterclockwise.
• Press the button of the steering switch.
A chapter preceding the chapter that is now being played back
will be played back.
■ To play back the succeeding chapter
1 Conduct either of the following operations while in the
DVD playback.
• Press the button.
• Rotate the [MODE/TUNE] button clockwise.
• Press the button of the steering switch.
A chapter succeeding the chapter that is now being played back
will be played back.
Searching a title with the title number specified
It is possible to search a title with the title number specified and then
play it back.
1 Select the screen while in the DVD playback.
2 Select (T.SEARCH).
146 Audio and Visual
Looking at the DVD
3 Select , , , to enter a title number and
then select (ENTER).
A title selected is played back.
NOTE
When selecting (ENTER) with a title number entered that is not in the
DVD, the screen displayed is not changed.
Audio and Visual 147
Looking at the DVD
Controlling the playback of the DVD
It is possible to pause, stop, rewind quickly or forward quickly
the DVD for control.
■ To stop the DVD temporarily
1 Select the DVD screen while in the DVD playback.
2 Select .
The DVD stops temporarily.
NOTE
Selecting or gets back to the normal playback mode.
■ To stop the DVD
1 Select the DVD screen while in the DVD playback.
2 Select .
The DVD is stopped.
NOTE
Selecting resumes the playback.
■ To rewind the DVD image quickly
1 Keep pressing the button while in the DVD play-
back.
While the button is being pressed, the DVD image is rewound
quickly. Releasing the button resumes the playback of the
DVD image from the point to which the DVD image was rewound
quickly.
■ To forward the DVD image quickly
1 Keep pressing the button while in the DVD play-
back.
While the button is being pressed, the DVD image is forwarded
quickly. Releasing the button resumes the playback of the
DVD image from the point to which the DVD image was for-
warded quickly.
148 Audio and Visual
Looking at the DVD
■ To forward the DVD image in single frame step
1 Select the screen while in the DVD playback.
2 Select .
The DVD is stopped temporarily.
3 Conduct either of the following operations while in the
DVD playback.
• Press the button.
• Rotate the [MODE/TUNE] button clockwise.
• Press the button of the steering switch.
The DVD image is played back in single frame forward step.
NOTE
Selecting or gets back to the normal playback mode.
Audio and Visual 149
Looking at the DVD
Operating the menu screen
Selecting the menu
It is possible to operate the menu screen of the DVD.
1 Select the screen while in the DVD playback.
2 Select (MENU CONTROL).
3 Selecting to select a menu item, and then
select (ENTER).
• Selecting (RETURN) starts the playback from a point
specified for each DVD.
• Selecting (TOP MENU) displays the top menu.
• Selecting (MENU) displays the menu.
• The configurations of the top menu and the menu vary with
the DVDs.
The image is played back as a menu is selected.
150 Audio and Visual
Looking at the DVD
Changing over the position of the menu opera-
tion key
The menu operation key is used to operate the menu of the DVD. It is
possible to relocate the position of the menu operation key so that it
does not interfere with the DVD image.
1 Select the screen while in the DVD playback.
2 Select (MENU CONTROL).
3 Select (CHANGE).
The location of the menu handling key is changed over.
Selecting (CHANGE) again gets back to the original
menu location.
Audio and Visual 151
Looking at the DVD
Changing the language and the angle
Changing the superimposed language
It is possible to change over the superimposed language while in the
playback of a DVD.
1 Select the screen while in the DVD playback.
2 Select (CONTROL).
3 Select (SUB).
Each time selecting (SUB), the superimposed lan-
guage is changed over.
NOTE
• The superimposed language is indicated by a numeric character. When a
numeric character is not displayed, the DVD is not compliant with multiple
languages.
• Selecting the screen allows you to check the superimposed language on the
playback screen.
152 Audio and Visual
Looking at the DVD
Changing the voice language
It is possible to change the voice language while in the DVD playback.
1 Select the screen while in the DVD playback.
2 Select (CONTROL).
3 Select (AUDIO).
Each time (AUDIO) is selected, the voice is changed
over.
NOTE
• The voice language is indicated by a numeric character. When a numeric
character is not displayed, the DVD is not compliant with multiple languages.
• Selecting the image section in the screen allows you to check the voice lan-
guage on the playback screen.
Audio and Visual 153
Looking at the DVD
Changing over the angle
It is possible to change over the angle to look at the DVD image in the
multi-angle scene while in the playback of the DVD compliant with
multi-angle.
1 In the scene compliant with multi-angle, select the
screen while in the DVD playback.
When a setting is made in the initial setting of the DVD so that the
(angle mark) is displayed, an angle mark is displayed in the
scene compliant with multi-angle. (See Page 169.)
2 Select (CONTROL).
3 Select (ANGLE).
Each time (ANGLE) is selected, the DVD is played back
with the angle changed over.
NOTE
• The type of the angle is indicated by a numeric character. When a numeric
character is not displayed, or when it is displayed as 1/1, the DVD is not com-
pliant with multiple languages.
• Selecting the image section in the screen allows you to check the angle on
the playback screen.
154 Audio and Visual
Looking at the DVD
Setting the screen
Adjusting the image quality
The image quality can be adjusted while looking and listening to the
DVD.
1 Press [DISP].
2 Select or of each item to adjust the image quality.
• Selecting or of allows you to adjust the tint of a
color.
Each time is selected, the tint of red is increased and each
time is selected, the tint of green is increased.
• Selecting or of allows you to adjust the shade of a
color.
Each time is selected, the shade of a color is increased and
each time is selected, the shade of a color is decreased.
• Selecting or of allows you to adjust the brightness.
Each time is selected, the brightness is increased and each
time is selected, the brightness is decreased.
• Selecting or of allows you to adjust the contrast.
Each time is selected, the contrast is increased and each
time is selected, the contrast is decreased.
NOTE
Selecting (DEFAULT) returns the settings to the default settings.
Audio and Visual 155
Looking at the DVD
Setting the SCREEN MODE
The screen mode can be set while looking and listening to the DVD.
1 Press [DISP].
2 Select (MODE).
3 Select either of the SCREEN MODE's below.
(NORMAL):
Displayed in the horizontal to vertical ratio of 3:4 screen (normal size
of TV screen) with both ends black.
(FULL):
Displayed in the horizontal to vertical ratio of 3:4 screen (normal size
of TV screen) that is expanded uniformly in the left and right direc-
tions.
(ZOOM):
Displayed in the horizontal to vertical ratio of 3:4 screen (normal size
of TV screen) that is expanded uniformly in the top and bottom direc-
tions and the left and right directions.
When receiving a wide screen broadcast, change over to this mode.
There is no legal restriction imposed so long as you enjoy the DVD personally.
However, if the screen is compressed or expanded for a commercial purpose,
or with the view of letting the general public enjoy the DVD, please note that
this may infringe the right of authorship that is protected by the copyright
law.
NOTE
Pressing the button allows you to look and listen to the DVD in the size set.
156 Audio and Visual
Looking at the DVD
Looking at the VIDEO
It is possible to look at the VIDEO with the VIDEO equipment
externally connected.
1 Change the source over to VIDEO. (See Page 107.)
NOTE
• The VTR equipment is required to be connected externally.
• When "VIDEO" is displayed even after the source is changed over to VIDEO,
the VIDEO equipment is not externally connected.
Audio and Visual 157
Satellite radio operation (if equipped)
To receive satellite radio, it is necessary to install the Subaru
genuine satellite receiver (dealer option) and to enter into a
contract. For details, please contact your SUBARU dealer.
■ XM™ satellite radio
XM™ is a continental U.S. based satellite radio service that offers more
than 160 coast to coast channels, including music, news, sports, talk
and children’s programming.
XM™
provides digital quality audio and text information, including song
title and artist name. A service fee is required to receive the XM™ ser-
vice. For more information, contact XM™ at www.xmradio.com
or call 1-
800-XMRADIO (1-800-967-2346) for U.S., www.xmradio.ca
or 1-877-GET-
XMSR (1-877-438-9677) for Canada.
■ Sirius satellite radio
Sirius satellite radio is a recent innovation that allows the listener to
experience digital sound quality and to have a greater variety of chan-
nels to choose from (more than 160 channels with the relevant sub-
scription).
Use of satellite radio (Sirius) requires a tuner, antenna and a service con-
tract. For details, please contact your SUBARU dealer or visit Sirius Satel-
lite Radio at www.sirius.com or call 1-888-539-SIRIUS (7474) for more
information. Sirius, the Sirius dog logo, channel names and logos are
trademarks of SIRIUS Satellite Radio Inc.
■ Satellite radio reception
Satellite radio signals are best received in areas with a clear view of the
open sky. In areas where there are tall buildings, trees, tunnels or other
structures that may obstruct the signal of the satellites, there may be
signal interruptions. Other circumstances that may result in signal loss
include driving near a wall, steep cliff, hill or driving on the lower level of
a multi-tiered road or inside of a parking garage.
To help reduce this condition, satellite radio providers have installed
ground-based repeaters in heavily populated areas. However, you may
still experience reception problems in some areas.
158 Audio and Visual
Setting the audio
Setting the equalizer
It is possible to set the audio to the sound quality of your pref-
erence.
Setting the equalizer with ease
It is possible to select a sound category to set the equalizer with ease.
1 Press the button.
2 Select (SETTING).
• Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
• When the DVD playback screen is displayed, press
the button again to display the screen shown above.
3 Select (EQUALIZER) in the SETTING screen.
4 Select either of the categories.
NATURAL: Suitable for natural sound like voice of people.
ROCK: Suitable for rock music
POPS: Suitable for pop music
EASY: Suitable for easy listening music
JAZZ: Suitable for jazz music
Audio and Visual 159
Setting the audio
Setting the equalizer in detail
Setting the numeric value of the equalizer in detail allows you to enjoy
a sound quality more suited to your taste. Presetting the equalizer
allows you to invoke it later.
1 Press the button.
2 Select (SETTING).
• Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
• When the DVD playback screen is displayed, press the button
again to display the screen shown above.
3 Select (EQUALIZER) in the SETTING screen.
4 Select either of the BANDs 1 to 4 and then select to
set a numeric value for each band.
FREQ:
Used to set the frequency.
BAND1
60/80/100/120/160/200
BAND2
250/315/400/500/630/800/1k
BAND3
1.25k/1.6k/2k/2.5k/3.15k/4k
BAND4
5k/6.3k/8k/10k/12.5k/16k
160 Audio and Visual
Setting the audio
The larger the value of Q factor (degree of acumination) is, the
more the gain of the center frequency is enhanced.
5 When presetting the equalizer setting, select either of
to of the USER PRESET for more than 2
second.
NOTE
When not preset, it is not possible to invoke the setting later. However, you can
enjoy the audio as you have set it.
Invoking the equalizer setting that has been
preset
It is possible to invoke the equalizer preset to make use of it.
1 Press the button.
2 Select (SETTING).
• Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
• When the DVD playback screen is displayed, press
the button again to display the screen shown above.
Q:
Used to set the degree of
acumination.
0.25/0.5/1/2
GAIN:
Used to set the value of gain.
-9/-7/-5/-3/-2/-1/0/1/2/3/5/7/9
Audio and Visual 161
Setting the audio
3 Select (EQUALIZER) in the SETTING screen.
4 Select either of to of USER PRESET.
162 Audio and Visual
Setting the audio
Setting the balance of the audio volume
Set the balance of the audio volume and the sound volume of
the sub woofer in the vehicle.
1 Press the button.
2 Select (SETTING).
• Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
• When the DVD playback screen is displayed, press the button
again to display the screen shown above.
3 Select (BALANCE/FADER) in the SETTING screen.
4 Select given in the in-vehicle illustration to
set the balance of the sound volume. And then select
of the SUB WOOFER LEVEL to set the sound vol-
ume of the SUB WOOFER.
Set "+" to the position at which you want to tone up the sound
volume most.
Audio and Visual 163
Setting the audio
NOTE
• Selecting (DEFAULT) gets "+" back to the center position.
• The setting of the sub woofer level is available only when the sub woofer is
connected. (See Page 166.)
• The larger the numeric value of the sub woofer level, the bigger the sub
woofer volume.
164 Audio and Visual
Setting the audio
Setting the surround
The setting of the surround is made for each source. Set the
surround for the source currently selected.
1 Press the [MODE/TUNE] button to select the source for
which the surround is to be set.
2 Press the button.
3 Select (SETTING).
Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
4 Select (SURROUND) in the SETTING screen.
5 Select either of the surround modes.
Bypass: Selected when no surround setting is made.
Music: In the Music mode, it is possible to use the mode con-
trollers such as "Dimension," "Center Width" and "Pan-
orama" to adjust the sound space to the optimum
condition according to your taste.
• "Dimension": This is used to adjust the condition of the sound
space back and forth.
The more is selected, the more the distribution of the sound
volume to the front speaker is increased, and the more is
selected, the more the distribution of the sound volume to the
rear speaker is increased.
• "Center Width" : This is used to adjust the balance of the left and
right speakers and the center speaker (sold separately). The
larger the value gets, the more the distribution of the sound
volume is increased.
Audio and Visual 165
Setting the audio
• "Panorama": This enhances greatly the stereo effect in front
including the surround speaker. With the entire vehicle used,
you can enjoy the feeling like "being wrapped in sound." It is
recommended that you use this mode when playing back the
stereo signals of an audio CD.
Movie: The MOVIE mode of PRO LOGIC II is programmed so
that the playback is made in the calculated high quality
sound. It is recommended that you use this mode
when playing back a DVD video attached with the
mark.
Matrix: In the Matrix mode, the directionally enhanced circuit is
turned off. So, it is possible to enhance monaural signals
to make them look large. It is recommended that you
use this mode when the reception condition of the ste-
reo signals of FM radio and TV is unstable and is offen-
sive to the ear, or when playing back monaural signals.
Dolby PL: The PRO LOGIC mode is used when the sound quality
of source contents is not optimal, or when you want to
listen to a program in the "familiar" sound quality.
166 Audio and Visual
Setting the audio
Setting the speaker
Make a setting for the connection of the center speaker and
the sub woofer.
The center speaker and the sub woofer are sold separately.
When using them, contact the Subaru dealer.
1 Press the button.
2 Select (SETTING).
• Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
• When the DVD playback screen is displayed, press the button
again to display the screen shown above.
3 Select (SET UP).
4 Select (SPEAKER).
Audio and Visual 167
Setting the audio
5 Make a setting to decide whether or not the SUB
WOOFER and the center speaker are connected.
• Select [ON] of the SUB WOOFER when connecting the sub
woofer. And select (OFF) when not connecting it.
• Select [ON] of the CENTER when connecting the center speaker.
And select (OFF) when not connecting it.
• A speaker that is set to be connected is displayed lit on the illus-
tration left.
168 Audio and Visual
Setting the audio
Initializing the DVD
The DVD player is initialized. The selection of the superim-
posed language and the sound can be set while in the look-
ing and listening of the DVD. However, it is convenient if you
initialize in advance the settings frequently used.
1 Press the button.
2 Select (SETTING).
• Even when each source screen is displayed, select (SET-
TING) to operate it in the same way.
• When the DVD playback screen is displayed, press the button
again to display the screen shown above.
3 Select (SET UP).
4 Select (DVD).
The DVD SET UP screen is displayed.
Audio and Visual 169
Setting the audio
5 When "After changing settings, system may not play
back" is displayed, select (Yes).
NOTE
The following can be conducted in this screen.
• Setting the screen (See Page 154.)
• Setting the dynamic range (See Page 170.)
• Setting the language (See Page 171.)
• Setting the parental level (See Page 173.)
Setting the screen
It is possible to make a setting to decide whether or not the angle mark
is displayed. And it is also possible to set the type of the image.
The angle mark is a mark displayed when the angle can be changed
while playing back a DVD compliant with multi-angle.
1 Select (SCREEN) in the DVD SET UP screen.
2 Make a setting to decide whether or not the angle mark
is displayed, and also set the type of the screen.
Select (ON) of the ANGLE MARK to display the angle mark.
And select (OFF) not to display the ANGLE MARK
.
Select either of the following to set the type of the image.
• : The width and height of the image is displayed in the
ratio of 16:9.
170 Audio and Visual
Setting the audio
• : With a black frame attached to the top and bottom
of the image in the ratio of 16:9, the width and
height is displayed in the ratio of 4:3.
• : The width and height is displayed in the ratio of 4:3.
Setting the dynamic range
The dynamic range is set. The setting of the dynamic range is effective
when playing back Dolby digital image.
1 Select (AUDIO) in the DVD SET UP screen.
2 Set the dynamic range.
Select either of the following to set the dynamic range.
• : Used to enhance the high-pitched sounds and the
low-pitched sounds so that the dynamic range is
played back in the sound modulated for effect.
• : Used to play back the dynamic range in the normal
mode.
• : Used to suppress the high-pitched sounds and the
low-pitched sounds to make speeches listener-
friendly.
Audio and Visual 171
Setting the audio
Setting the language
It is possible to initialize the voice language, the superimposed lan-
guage and the language to be displayed on the menu.
For detailed method for changing the language while in the looking
and listening of the DVD, refer to "Changing the voice language" on
Page 152 and "Changing the superimposed language" on Page 151.
1 Select (LANGUAGE) in the DVD SET UP
screen.
2 Select the language item you want to set.
: Used to set the voice language.
: Used to set the superimposed language.
: Used to set the language to be displayed
on the menu.
3 Select the voice you want to set. When there is no lan-
guage found you want to set, select (OTH-
ERS).
Selecting the language terminates this operation.
4 Enter the LANGUAGE CODE of the language you want to
set and then select (OK).
172 Audio and Visual
Setting the audio
Setting the password of the parental level
The parental level is used to restrict the looking and listening
of the DVD according to the level set. To set the parental level,
it is necessary to register a password in advance.
When setting the parental level, it sometimes occurs that a
password is asked for while in the looking and listening of the
DVD. In that case, enter the password you used when setting
the parental level.
1 Select (PARENTAL) in the DVD SET UP screen.
2 Select (REGISTER PASSWORD).
When the password has been set and you want to change it,
select (CHANGE PASSWORD).
3 Select the numeric key to enter a 4-digit password, and
then select (OK).
Selecting (CLEAR) deletes what has been entered.
4 As a password for confirmation, enter a 4-digit password
that is the same as the one used in step 3 and then select
(OK).
When setting the parental level, follow the procedure given at
step 4 and the succeeding steps on Page 173.
Audio and Visual 173
Setting the audio
Setting the parental level
Set the parental level to restrict the looking and listening of the DVD
according to the level set. In order to set the parental level, a password
is used. When a password is not yet set, it is necessary to register a pass-
word. (See Page 172.)
1 Select (PARENTAL) in the DVD SET UP screen.
2 Select (CHANGE LEVEL).
3 Select the numeric keys to enter a 4-digit password and
then select (OK).
Selecting (CLEAR) deletes what has been entered.
4 Select of the PARENTAL LEVEL.
The smaller the numeric value of the parental level, the more
severe the restriction. And the larger the numeric value, the more
gentle the restriction.
5 Select the numeric keys to enter a 4-digit password and
then select (OK).
If you want to change the password, select [CHANGE PASSWORD],
and then change it referring to"Setting the password of the paren-
tal level" on Page 172.
174 Audio and Visual
Setting the audio
Handsfree
176 Handsfree
Before using the Handsfree
What can be made with the handsfree
It is possible to connect the Bluetooth Phone of which the
operation has been confirmed to the in-vehicle equipment
through the Bluetooth format (wireless) to make a phone call
from the in-vehicle equipment or take an incoming phone
call.
Since the Bluetooth format is wireless, a connection between
the in-vehicle equipment and the Bluetooth Phone can be
made without placing them in the close vicinity of each other.
The Bluetooth Phone can be used with it left in the breast
pocket or bag.
The Bluetooth Phone that is compliant with the in-vehicle equipment
must meet the following requirements.
• Bluetooth Specification Ver. 1.1 or above (Ver. 1.2 or above is recom-
mended.)
• Corresponding Profiles are as shown below.
• HFP (Hands Free Profile) Ver. 1.0 (Ver. 2.0 or above is recommended.)
• OPP (Object Push Profile) Ver. 1.1
"Bluetooth" is a trademark of Bluetooth SIG, Inc.
What cannot be done with the handsfree
In the following cases, the functions of the handsfree cannot be used.
• While not in the phone call area.
• While in the phone call being restricted due to the lines congested.
• When the phone book data is being transmitted from the Bluetooth
Phone.
• When the Bluetooth Phone is being used, due to data communica-
tion.
• When the Bluetooth Phone is out of order.
• When the Bluetooth Phone is not connected to the in-vehicle equip-
ment.
• When the battery of the Bluetooth Phone has run down.
• When the power switch of the Bluetooth Phone is turned off.
• When the Bluetooth Phone is not set to the handsfree mode.
• When a changeover is made on the in-vehicle side from the phone
book transmission to the handsfree.
• When the Bluetooth Phone cannot be used for other reasons.
Handsfree 177
Before using the Handsfree
Precautions to be taken when using the Bluetooth equipment
Please take note of the following when using the Bluetooth
equipment.
WARNING
• For safety's sake, the driver should avoid the operation of the
Bluetooth Phone while driving.
• Do not make a phone call while driving. When you have an
incoming call, bring your car to a stop in a safe place in a
calm manner before taking the incoming phone call. When
you have to absolutely take a phone call, tell the caller "I'll
call you back" by handsfree. And then call him back after
stopping the car in a safe place.
• The buttons for the touch screen that cannot be used are
displayed in light color (tone down).
Operating the navigation system while in driving could cause
your attention to be distracted from the current traffic condi-
tions. And in consequence, this could result in a severe or fatal
accident. Follow the descriptions of all operations and the
instructions for safety given in this manual without fail.
• Please comply with the instructions specified in the laws and
regulations concerning the use of the telephone in the vehicle.
CAUTION
• Do not leave the Bluetooth Phone in the vehicle.
(The temperature in a sun-heated car may go up extremely high.)
• When using the Bluetooth Phone, be careful not to get it
close to the in-vehicle equipment. Getting it too close to the
in-vehicle equipment may result in deterioration in tone
quality or a poor connecting condition.
• The frequency band used by this equipment is the same
band on which other industrial, scientific and medical equip-
ment such as microwave ovens, radio stations (a license
required) to be used by the production line in the factory to
identify movable bodies, specific small power radio stations
(a license not required) and amateur radio stations (a license
required) is being operated. (These three type radio stations
mentioned above are hereinafter referred to as "other radio
stations.") Before using this equipment, be sure to check to
see if "other radio stations" are being operated in the vicin-
ity. Should there be a detrimental radio interference from
this equipment to "other radio stations," move the equip-
ment to another location as soon as possible to avoid radio
interference. The frequency band used by this equipment is
in the 2.4 GHz zone.
The FH-SS modulation is employed as a
modulation method. The expected inflicting interference dis-
tance is less than 10m. This equipment uses a full band and can
avoid a band used by a movable body identification device.
178 Handsfree
Before using the Handsfree
Name of each part
The name of each part used by the functions of the handsfree
is as shown below.
■ In-vehicle equipment
Operating the touch switches displayed on the screen allows you to use
the functions of the handsfree.
■ Steering switches
Pressing the switch short allows you to answer an incoming phone call.
Pressing the
switch long allows you to hang up the phone.
■ Microphone
Used while in the phone call. (dealer option)
For details, check with the dealer.
Handsfree 179
Before using the Handsfree
Phone voice
After making a phone call or having a phone call, you can talk
over the phone through mike and speaker.
• An incoming call notice and a voice output while in the phone call
are output from the speaker on the driver's seat side and passenger’s
seat.
• When a voice or an incoming call signal is issued by the handsfree,
the sound from the audio and the navigation system is muted.
180 Handsfree
Before using the Handsfree
Various types of displays
Selecting (Phone) with the button pressed dis-
plays the PHONE MENU screen, in which you can set and
operate the functions of the handsfree. The explanation here
is given of the various kinds of displays shown on the PHONE
MENU screen.
Reception level display
This shows a rough standard of the reception level of radio waves. How-
ever, this is not displayed while in the transmission of the phone book
data.
• When "Out of the range" is being displayed, you are now out of the
service area, or in the location to which no radio waves get through.
On occasions like this, you cannot use the Bluetooth Phone. Move to
a location where a clear reception can be obtained.
• The reception level does not always conform to the display of the
Bluetooth Phone. The reception level may not be displayed for some
model types.
Battery indicator
This shows a rough battery capacity of the Bluetooth Phone. However,
this is not displayed while in the transmission of the phone book data.
• The display of the battery capacity may not sometimes conform to
that of the Bluetooth Phone. And also, the battery capacity may not
be displayed for some model types.
• This system is not provided with a charging function for a cell phone.
Bluetooth connection
status display
Battery indicator
Reception level displayRoaming display
Out of
the range
IntenseFaintLevel:
Display:
Remaining
amount:
Display:
None Little Full
Handsfree 181
Before using the Handsfree
Bluetooth connection status display
This displays the Bluetooth connection status of the Bluetooth Phone.
Roaming display
Roaming is a service that provides a continuous use of the system by
using the facilities of a company with which the telephone company
ties up when you are out of the stipulated service area.
When the roaming function is being used, "Rm" is displayed.
The Bluetooth Phone is correctly connected to the in-vehicle equip-
ment.
The Bluetooth Phone is connected to the in-vehicle equipment, but
radio waves are weak.
The Bluetooth Phone is not connected to the in-vehicle equipment.
When using the handsfree, register the Bluetooth Phone and the in-
vehicle equipment, and then connect them each other. (See "Register-
ing the Bluetooth Phone" on Page 183)
182 Handsfree
Before using the Handsfree
When parting with your car
When using the handsfree, a lot of personal information is
registered.
When parting with your car, delete your personal information
and data referring to the following.
And data once deleted cannot be restored to their original
state. Be careful not delete date mistakenly.
Deleting all the outgoing and incoming call history. (See Page 200.)
Deleting all the phone book data. (See Page 212.)
Deleting the registered Bluetooth Phone from the in-vehicle equip-
ment. (See Page 214.)
Changing the Device Name of the in-vehicle equipment displayed in
the Bluetooth Phone. (See Page 216.)
Changing the Pass-Key to be used when certificating the Bluetooth
Phone. (See Page 222.)
Handsfree 183
Making preparations of the handsfree
Registering the Bluetooth Phone
To use the Bluetooth Phone in interlock with the in-vehicle
equipment, it is necessary to register the Bluetooth Phone
with the in-vehicle equipment in advance.
NOTE
It is possible to register up to five Bluetooth Phones with the in-vehicle equip-
ment. However, Bluetooth Phones that can be used with the in-vehicle equip-
ment are restricted only to those selected by the phone selection.
1 Press the button.
2 Select (Phone).
3 Select (Bluetooth Settings).
4 Select (Register).
5 Register the Bluetooth equipment from the Bluetooth
Phone and then enter the PASS-KEY displayed on the
screen for it to be transmitted.
184 Handsfree
Making preparations of the handsfree
The device name of the Bluetooth Phone is displayed on the
DEVICE LIST.
The Bluetooth Phone most recently registered is selected as a
Bluetooth Phone to be used with the in-vehicle equipment.
NOTE
• For detailed method for the transmission of the PASS-KEY from the Bluetooth Phone,
refer to the instruction manual of the Bluetooth Phone.
• With (Autoconnect) set to "ON" on the DEVICE LIST screen in advance,
the in-vehicle equipment automatically accept the connection of the Bluetooth Phone.
Selecting (Autoconnect) makes a changeover between ON and OFF.
• When registering two or more Bluetooth Phones, it is necessary to select a Bluetooth
Phone for connection.
Handsfree 185
Making preparations of the handsfree
Connecting the Bluetooth Phone
To use the Bluetooth Phone in interlock with the in-vehicle
equipment, the Bluetooth Phone registered with the in-vehi-
cle equipment is required to be connected to the in-vehicle
equipment. When is displayed on the PHONE MENU
screen, or when changing a Bluetooth Phone to be con-
nected, conduct this operation.
With "Autoconnect" set to "ON" in advance, a connection is made auto-
matically to the Bluetooth Phone most recently connected. It is recom-
mended that "Autoconnect" is set to "ON" in advance.
1 Press the button.
2 Select (Phone).
3 Select (Bluetooth Settings).
4 Select the Bluetooth Phone you want to connect.
186 Handsfree
Making preparations of the handsfree
5 Select (Connect).
NOTE
• With (Autoconnect) set to "ON" on the DEVICE LIST screen in
advance, the in-vehicle equipment automatically accept the connection of
the Bluetooth Phone. Selecting (Autoconnect) makes a
changeover between ON and OFF.
• When a connection has been made to another Bluetooth Phone, a confirma-
tion message is displayed.
6 Select (Yes).
The Bluetooth Phone selected is connected by the Bluetooth.
Handsfree 187
Speaking over the handsfree
Making a phone call
Entering a phone number to make a phone call
It is possible to select the in-vehicle equipment to enter a phone num-
ber and make a phone call.
1 Press the button.
2 Select (Phone).
3 Select (Bluetooth Phone).
4 Select numeric keys to enter a phone number and then
select .
188 Handsfree
Speaking over the handsfree
NOTE
• Selecting briefly allows you to enter "*." And then selecting for
more than two seconds allows you to enter "+."
• Selecting allows you to delete a digit entered.
5 Select (Yes).
You have a phone call. Speak over the phone.
When the phone call is over, hang up the phone. (See Page 198.)
Making a phone call from the outgoing or
incoming call history
It is possible to make a phone call to a phone number in the outgoing
or incoming call history.
1 Press the button.
2 Select (Phone).
3 Select (Redial List) or (Received Calls).
Handsfree 189
Speaking over the handsfree
4 Select the phone number and then select .
NOTE
The following can be conducted from this screen.
• It is possible to register a phone number with the phone book. (See Page
206.)
• It is possible to delete an outgoing or incoming call history. (See Page 200.)
5 Select (Yes).
You have a phone call. Speak over the phone.
When the phone call is over, hang up the phone. (See Page 198.)
190 Handsfree
Speaking over the handsfree
Making a phone call from the phone book
It is possible to select a phone number from the phone book registered
with the in-vehicle equipment to make a phone call.
NOTE
It is possible to copy the data in the phone book from the phone book of the
Bluetooth Phone into that of the in-vehicle equipment. (See Page 201.)
1 Press the button.
2 Select (Phone).
3 Select (Phone Book).
4 Select the name or phone number of a person to whom
you want to make a phone call.
• Selecting alphabets, numerical characters or [Others] displays a
phone book data to which the acronym has relevance.
• Selecting scrolls the display to display a phone book data 5
positions ahead.
• Selecting scrolls the display to display a phone book data 1
position ahead.
• Selecting scrolls the display to display a phone book data 1
position behind.
Handsfree 191
Speaking over the handsfree
• Selecting scrolls the display to display a phone book data 5
position behind.
NOTE
The following can be conducted from this screen.
• It is possible to register the phone book data. (See Page 203.)
• It is possible to register the phone book data from the Bluetooth Phone. (See
Page 201.)
• It is possible to delete all the phone book data. (See Page 212.)
5 Select the phone number and then select .
NOTE
The following can be conducted from this screen.
• It is possible to edit the phone book data. (See Page 208.)
• It is possible to delete the phone book data. (See Page 210 and 212.)
6 Select (Yes).
You have a phone call. Speak over the phone.
When the phone call is over, hang up the phone.
192 Handsfree
Speaking over the handsfree
Making a phone call from the Speed Dial
It is possible to select a phone number from the Speed Dial registered
with the in-vehicle equipment to make a phone call.
NOTE
To use the Speed Dial, the phone number needs to be registered onto Speed
Dial beforehand. (See page 218)
1 Press the button.
2 Select (Phone).
3 Select (Speed Dial).
4
Select the name or phone number of a person to whom you
want to make a phone call.
You have a phone call. Speak over the phone.
When the phone call is over, hang up the phone.
Handsfree 193
Speaking over the handsfree
Making a phone call to the phone number of the
Memory Point
It is possible to make a phone call to the phone number registered as a
memory point.
1 Press the button.
2 Select (Phone).
3 Select (Memory Points).
When the Memory Points is not stored in the in-vehicle equip-
ment, (Memory Points) cannot be selected.
4 Select the Memory Point.
• Selecting scrolls the display to display a memory point 5
position ahead.
• Selecting scrolls the display to display a memory point 1
position ahead.
• Selecting scrolls the display to display a memory point 1
position behind.
• Selecting scrolls the display to display a memory point 5
position behind.
• Selecting (Attribute) sorts the memory points in the
order of shorter distances.
• Selecting (Icon) sorts the memory points in icon
order.
• Selecting (Name) sorts the memory points in name
order.
• Selecting (Date) sorts the memory points in regis-
tered data order.
194 Handsfree
Speaking over the handsfree
5 Select .
6 Select (Yes).
You have a phone call. Speak over the phone.
When the phone call is over, hang up the phone. (See Page 198.)
Making a phone call from the Bluetooth Phone
It is possible to directly operate the Bluetooth Phone connected to the
in-vehicle equipment to make a phone call.
Even while speaking over the Bluetooth Phone, operating either of the
following, when connected to the in-vehicle equipment, displays the
handsfree screen in the in-vehicle equipment.
• Press the phone switch.
• Select (Phone) on the menu screen.
In this case, it is not possible to conduct any operations in relation to
the handsfree from the in-vehicle equipment.
WARNING
For safety's sake, the driver should refrain from the operation
of a cell phone while driving.
Handsfree 195
Speaking over the handsfree
Taking a phone call and declining a incoming call
When you have a phone call, the information of a caller is dis-
played together with an incoming call sign. When the name
of a caller is registered with the phone book, the name of the
caller is displayed. On an occasion other than the above, a
phone number is displayed. For a caller with no outgoing call
notice, no information is displayed.
Taking a phone call
It is possible to take an incoming phone call and talk over the phone.
1 Select (Call) or press the phone switch of the
steering switch.
You can take a phone call. Speak over the phone.
When the phone call is over, hang up the phone. (See Page 198.)
Putting an incoming phone call on hold
It is possible to put an incoming phone call on hold to take it later.
1 Select (Hold) or keep pressing the phone
switch of the steering switch for more than 2 seconds.
2 When taking it later, select or press the phone
switch.
When the phone call is over, hang up the phone. (See Page 198.)
196 Handsfree
Speaking over the handsfree
Hanging up an incoming call before answering
it (Denial of an incoming call)
It is possible to hang up an incoming call before answering it. And it is
also possible, while putting a phone call on hold, to conduct the follow-
ing operations to hang up the phone call.
1 Select (Disconnect) or keep pressing the
phone switch of the steering switch for more than 2 sec-
onds.
The phone call is hanged up.
Handsfree 197
Speaking over the handsfree
Speaking over the phone
Adjusting the tonal volume
It is possible to adjust the tonal volume.
1 While speaking over the phone, select either of the fig-
ures to shown on the lower section of the
screen or press the volume adjusting switch of the steer-
ing switch.
NOTE
• The larger the figure you select, the larger the tonal volume.
• Pressing the [+] button of the volume switch of the steering switch increases
the tonal volume, while pressing the [-] button decreases the tonal volume.
Muting the voice on this side
It is possible to make your voice unheard to the other party (Mute).
However, you can hear the voice of the other party.
1 Select (Mute) while speaking over the phone.
Select (Mute) again to cancel the mute.
198 Handsfree
Speaking over the handsfree
Transmitting the phone call
It is possible to transmit the phone call of the in-vehicle equipment to
the Bluetooth Phone. And also, the phone call of the Bluetooth Phone
can be transmitted to the in-vehicle equipment.
1 Select (Speaker) while speaking over the
phone or putting the answer on hold.
You can speak over the Bluetooth Phone.
NOTE
• While speaking over the Bluetooth Phone, the only operation that can be
made is to transmit the phone call again to the in-vehicle equipment.
• If you want to speak over the in-vehicle equipment, select
(Speaker).
Hanging up the phone
Hang up the phone while speaking over the phone or after the phone
call is over.
1 Select or keep pressing the phone switch of
the steering switch for more than 2 seconds.
NOTE
It is also possible to hang up the phone on the Bluetooth Phone.
Handsfree 199
Using the outgoing or incoming call history
Checking the outgoing or incoming call history
It is possible to check the outgoing or incoming call history.
1 Press the button.
2 Select (Phone).
3 Select (Redial List) or (Received Calls).
4 Check the outgoing or incoming call history.
• The maximum number of calls in the history items that can be
checked is five for each of the outgoing calls and the incoming
calls.
• The history of phone calls directly sent out from the Bluetooth
Phone and the history of phone calls received when not con-
nected to the in-vehicle equipment are not displayed.
NOTE
The following can be conducted from this screen.
• It is possible to make a phone call to the number displayed. (See Page 188.)
• It is possible to register a phone number with the phone book. (See Page
206.)
• It is possible to delete an outgoing or incoming call history displayed. (See
Page 200.)
200 Handsfree
Using the outgoing or incoming call history
Deleting all the outgoing and incoming call history
Delete all the outgoing and incoming call history. History
once deleted cannot be restored to its original state.
1 Press the button.
2 Select (Phone).
3 Select (Redial List) or (Received Calls).
4 Select .
NOTE
The following can be conducted from this screen.
• It is possible to make a phone call to the phone number displayed. (See Page
188
.)
• It is possible to register a phone number with the phone book. (See Page
206
.)
5 Select (Yes).
All of the outgoing or incoming call history are deleted.
NOTE
It is necessary to delete the outgoing call history and the incoming call history
separately.
Handsfree 201
Using the phone book
Registering the phone book data
Up to 1000 phone book data can be registered with the
phone book of the in-vehicle equipment.
Contents that can be registered as phone book data are as
shown below.
• Name: It is possible to register up to 24 characters. They can be
clipped.
• Phone number 1, phone number 2: Up to 25 digits can be regis-
tered. Any letter other than "0 to 9, *, #" cannot be used.
Transmitting the phone book of the Bluetooth
Phone
It is possible to transmit the phone book data from the phone book of
the Bluetooth Phone to that of the in-vehicle equipment. Phone book
data that can be transmitted are as shown below.
• Name
When the name of the phone book data of the Bluetooth Phone is in
excess of 24 character, up to 24 characters from the start are regis-
tered with the phone book of the in-vehicle equipment.
When a non-corresponding character is registered in the name of the
phone book data of the Bluetooth Phone, this is registered with the
phone book of the in-vehicle equipment as a blank.
• Phone number 1
• Phone number 2
When more than 3 phone numbers are registered with the phone
book data of the Bluetooth Phone, with two or more phone book
data of the same name created, they are divided to be registered
with the phone book of the in-vehicle equipment.
When any letters other than "0 to 9, *, #" are included in the phone
book data of the Bluetooth Phone, those relevant letters are deleted
to be registered with the phone book of the in-vehicle equipment.
When the phone book data of the Bluetooth Phone is a phone num-
ber in excess of 25 digits, it is not registered with the phone book of
the in-vehicle equipment.
202 Handsfree
Using the phone book
1 Press the button.
2 Select (Phone).
3 Select (Phone Book).
4 Select (Download).
5 Select (Add).
NOTE
When there is a phone book data already in the phone book, select
(Overwrite) or (Add). Selecting
(Overwrite) overwrites the existing phone book. And select-
ing (Add) adds a phone book data to the existing phone book data as
a new data.
Handsfree 203
Using the phone book
6
Transmit the phone number data from the Bluetooth Phone.
The phone book data is displayed in the phone book
NOTE
For detail method for transmitting the phone book data from the Bluetooth
Phone, refer to the instruction manual of the Bluetooth Phone.
Registering a new data with the phone book
Register a new phone book data with the phone book. It is possible to
register a name and up to 2 phone numbers as phone book data.
1 Press the button to edit the phone book data reg-
istered.
2 Select (Phone).
3 Select (Phone Book).
204 Handsfree
Using the phone book
4 Select (New).
5 Select (Name).
NOTE
The Name doesn't need to be entered. When not entered, the phone number is
displayed on the phone book. And when not entered, proceed to step 7.
6 Enter the name of the phone book data and select
(OK).
• Selecting deletes 1 character.
• Selecting (Others) displays other characters. Then
selecting or displays the preceding or succeeding
screen.
• Selecting (Sym.) displays figures and symbols. Then
selecting or displays the preceding or succeeding
screen.
• Selecting - displays alphabets and symbols.
• Selecting (Caps) allows you to make a changeover
between upper case and lower case.
7 Select (No.1) or (No.2).
Handsfree 205
Using the phone book
8 Enter the phone number and select (OK).
• Selecting briefly allows you to enter "*" and selecting
for more than 2 seconds allows you to enter "+."
• Selecting deletes 1 character.
9 Select (OK).
A phone book data is added.
206 Handsfree
Using the phone book
Registering data with the phone book from the
outgoing or incoming call history
It is possible to register a phone number of the outgoing or incoming
call history with the phone book.
1 Press the button.
2 Select (Phone).
3 Select (Redial List) or (Received Calls).
4 Select the phone number and then select .
NOTE
The following can be conducted from this screen.
• It is possible to make a phone call to a phone number displayed. (See Page
188.)
• It is possible to delete an incoming or outgoing call history displayed. (See
Page 200.)
5 Select (Name).
Handsfree 207
Using the phone book
6 Enter the name of a phone book data and select
(OK).
• Selecting deletes 1 character.
• Selecting (Others) displays other characters. Then
selecting or displays the preceding or succeeding
screen.
• Selecting (Sym.) displays figures and symbols. Then
selecting or displays the preceding or succeeding
screen.
• Selecting - displays alphabets.
• Selecting (Caps) allows you to make a changeover
between upper case and lower case.
7 Select (OK).
The phone number is registered with the phone book data.
208 Handsfree
Using the phone book
Editing or deleting a phone book data
Editing a phone book data
It is possible to edit the name of a phone book data and a phone num-
ber.
1 Press the button.
2 Select (Phone).
3 Select (Phone Book).
4 Select the phone book data you want to edit.
• Selecting alphabets, figures or (Others) given in the
upper section displays a phone book data to which the acro-
nym has relevance.
• Selecting scrolls the display to display a phone book data 5
positions ahead.
• Selecting scrolls the display to display a phone book data 1
position ahead.
Handsfree 209
Using the phone book
• Selecting scrolls the display to display a phone book data 1
position behind.
• Selecting scrolls the display to display a phone book data 5
positions behind.
NOTE
The following can be conducted from this screen.
• It is possible to register a phone book data. (See Page 203.)
• It is possible to register a phone book data from the Bluetooth Phone. (See
Page 201.)
• It is possible to delete all the phone book data. (See Page 212.)
5 Select (Edit).
NOTE
The following can also be conducted from this screen.
• It is possible to delete a phone book data. (See Page 210 and 212.)
• It is possible to make a phone call to the phone number selected. (See Page
190.)
6 Select an item you want to edit.
7 Enter a new data and select (OK).
NOTE
For details of the editing method, refer to "Registering a new data with the
phone book." (See Page 203.)
210 Handsfree
Using the phone book
8 Select (OK).
The result of the edit is reflected in the phone book data.
Selecting a phone book data to delete it
Select a phone book data registered and delete it.
NOTE
A phone book data once deleted cannot be restored to its original state.
1 Press the button.
2 Select (Phone).
3 Select (Phone Book).
Handsfree 211
Using the phone book
4 Select a phone book data you want to edit.
• Selecting alphabets, figures or (Others) given in the
upper section displays a phone book data to which the acro-
nym has relevance.
• Selecting scrolls the display to display a phone book data 5
positions ahead.
• Selecting scrolls the display to display a phone book data 1
position ahead.
• Selecting scrolls the display to display a phone book data 1
position behind.
• Selecting scrolls the display to display a phone book data 5
positions behind.
NOTE
The following can be conducted from this screen.
• It is possible to register a phone book data. (See Page 203.)
• It is possible to register a phone book data from the Bluetooth Phone. (See
Page 201.)
• It is possible to delete all the phone book data. (See Page 212.)
5 Select (Delete).
NOTE
The following can be conducted from this screen.
• It is possible to edit a phone book data. (See Page 208.)
• It is possible to make a phone call to the phone number selected. (See Page
190.)
6 Select (Yes).
212 Handsfree
Using the phone book
The phone book data selected is deleted.
Deleting all the phone book data
It is possible to delete all the phone book data.
NOTE
Phone book data once deleted cannot be restored to their original state.
1 Press the button.
2 Select (Phone).
3 Select (Phone Book).
Handsfree 213
Using the phone book
4 Select .
5 Select (Yes).
All the phone book data are deleted.
214 Handsfree
Other Bluetooth settings
Deleting the registered Bluetooth Phone from the in-vehicle equipment
Delete the Bluetooth Phone registered with the in-vehicle
equipment.
NOTE
When deleting the Bluetooth Phone with the Bluetooth Phone connected to the
in-vehicle equipment, no automatic connection is made.
1 Press the button.
2 Select (Phone).
3 Select (Bluetooth Settings).
4 Select a Bluetooth Phone name you want to delete.
Handsfree 215
Other Bluetooth settings
5 Select .
6 Select (Yes).
The Bluetooth Phone registered is deleted.
NOTE
• When you want to use again the deleted Bluetooth Phone in interlock with
the in-vehicle equipment, register and connect it again.
• Even when the Bluetooth Phone is deleted from the in-vehicle equipment,
the phone book data transmitted from the Bluetooth Phone and the outgo-
ing and incoming call history remain as they are.
216 Handsfree
Other Bluetooth settings
Changing the Device Name of the in-vehicle equipment displayed in the Bluetooth Phone
It is possible to change the Device Name of the in-vehicle
equipment displayed in the Bluetooth setting of the Blue-
tooth Phone.
1 Press the button.
2 Select (Phone).
3 Select (Bluetooth Settings).
4 Select (My Info).
5 Select (Device Name).
Handsfree 217
Other Bluetooth settings
6 Enter a new Device Name and select (OK).
• Selecting deletes 1 character.
• The number of characters that can be entered is up to 20 char-
acters.
• Selecting (Others) displays other characters. Then
selecting or displays the preceding or succeeding
screen.
• Selecting (Sym.) displays figures and symbols. Then
selecting or displays the preceding or succeeding
screen.
• Selecting - displays alphabets.
• Selecting (Caps) allows you to make a changeover
between upper case and lower case.
218 Handsfree
Other Bluetooth settings
Editing the Speed Dial setting
Adding the phone number to the Speed Dial
memory
It is possible to add the phone number from the Phone Book to Speed
Dial memory.
NOTE
To add the phone number to the Speed Dial memory, the phone num-
ber needs to be registered onto Phone Book beforehand. (See page
201
)
1 Press the button.
2 Select (Phone).
3 Select (Speed Dial Settings).
4 Select (Add).
Handsfree 219
Other Bluetooth settings
5 Select a name on a Phone Book whom you want to add
to the Speed Dial memory.
6 Select a phone number which you want to add to the
Speed Dial memory.
7 Select a registering position where you want to add to
the Speed Dial memory.
8 If you are going to overwrite the Speed Dial memory,
select (Yes) to finish the adding.
220 Handsfree
Other Bluetooth settings
Deleting the phone number from the Speed Dial
memory
It is possible to delete the phone number from the Speed Dial memory.
1 Press the button.
2 Select (Phone).
3 Select (Speed Dial Settings).
4 Select (Delete).
5 Select a Speed Dial memory which you want to delete.
Handsfree 221
Other Bluetooth settings
6 Select (Yes).
7 If you need to delete all memories from Speed Dial,
select (Delete all) on step 4.
8 Select (Yes).
222 Handsfree
Other Bluetooth settings
Changing the Pass-Key used when certificating the Bluetooth Phone
When connecting the Bluetooth Phone to the in-vehicle
equipment, the Pass-key is used for certification. It is possible
to change the Pass-Key used for certification.
1 Press the button.
2 Select (Phone).
3 Select (Bluetooth Settings).
4 Select (My Info).
5 Select (Pass-key).
Handsfree 223
Other Bluetooth settings
6 Enter a new Pass-key and then select (OK).
NOTE
• Selecting deletes 1 character.
• What can be entered as a Pass-key are limited only to numeric characters "0 to
9" in 4 to 8 digits.
224 Handsfree
Other Bluetooth settings
Vehicle
Information
226 Vehicle Information
Before Use
Precautions when using the system
WARNING
READ THIS MANUAL FIRST
Read this supplement carefully before using your vehicle informa-
tion system. We are not liable for accidents or other problems
resulting from failure to follow the instructions in this supplement.
AVOID OPERATING THE VEHICLE INFORMATION SYSTEM WHILE
DRIVING
You should stop the vehicle in a safe place before operating
the vehicle information system. For safety’s sake, some of the
vehicle information system’s functions cannot be used unless
the vehicle is stationary.
If you stare at the display with too much enthusiasm or oper-
ate the switches of the system while in driving, the navigation
system could cause your attention to be distracted from the
current traffic conditions. Please be sure to input in the system
as much information as possible before taking your departure.
And also please be sure to bring your car to a stop in a safe
place if you need to input information.
The buttons for the touch screen that cannot be used are dis-
played in light color (tone down).
Operating the navigation system while in driving could cause
your attention to be distracted from the current traffic condi-
tions. And in consequence, this could result in a severe or fatal
accident. Follow the descriptions of all operations and the
instructions for safety given in this manual without fail.
LOOK AT THE VEHICLE INFORMATION SCREEN ONLY WHEN
NECESSARY
When you need to look at the vehicle information screen, do
so for the shortest time possible. Looking away from the
road for too long could lead to an accident.
KEEP THE VOLUME LOW ENOUGH FOR YOU TO HEAR OUTSIDE
SOUNDS
Keep the system’s volume level low enough for you to be
able to hear outside sounds while driving. To do otherwise
may mean that you are unable to react appropriately to traf-
fic conditions thus resulting in an accident.
Vehicle Information 227
Before Use
CAUTION
NEVER DISASSEMBLE OR MODIFY THE VEHICLE INFORMATION
SYSTEM
Any attempt to disassemble or modify the vehicle information
system could lead to a fire, an electric shock, or some other
type of accident.
Do not continue using the vehicle information system if it mal-
functions
If the system shows any sign of malfunctioning (for example,
the monitor gives no picture), stop using it immediately and
contact the nearest SUBARU dealer. Continuing to use the
system could lead to a fire, an electric shock, or some other
type of accident.
If the vehicle information system gets contaminated, emits
smoke or an odd smell, stop using it
If a foreign object gets inside the system, liquid is spilled
onto the system, or the system emits smoke or an unusual
smell, stop using it immediately and contact the nearest
SUBARU dealer. Continuing to use the system could lead to a
fire, an electric shock, or some other type of accident.
228 Vehicle Information
Before Use
■ About the vehicle information screen
• Subjecting the control buttons or liquid crystal display to excessive
shock could result in vehicle information screen deformation or other
damage.
• Keep any heat source (including lighted cigarettes) away from the
vehicle information screen. If a heat source is brought into contact
with the vehicle information system cabinet and panel, they could
be deformed or otherwise degraded.
• In extreme cold, the vehicle information screen may operate slug-
gishly and the display may dim. Such conditions do not indicate a
problem. They will disappear when the cabin temperature rises to a
normal temperature.
• Tiny black and white dots may occasionally appear in the liquid crys-
tal display. These dots are a normal characteristic of the display. They
do not indicate a problem.
•
When the
vehicle information screen
requires cleaning, gently wipe it
with a silicone cloth or other soft cloth. If necessary, spray the cloth
with neutral cleaning fluid. Be sure to wipe away any cleaning fluid
left on the vehicle information screen. Do not spray the cleaning fluid
directly onto the
vehicle information screen
. Spraying cleaning fluid
directly onto the
vehicle information screen
could cause an adverse
effect on internal components. It is also not a good idea to wipe the
vehicle information screen
with a stiff cloth or attempt to clean it
using thinners, alcohol, or any other volatile solvent. Doing so could
leave scratches and/or erase the control button labels
.
• Do not allow the vehicle information screen to get wet. If it gets wet
(allowing, for example, to a spilled drink or wet umbrella), its internal
electronic circuitry may malfunction.
• In hot weather, cool the passenger compartment down before using
the vehicle information system. The liquid crystal display operates
correctly at temperatures between 0°C and 60°C (32°F and 140°F).
When the temperature exceeds 60°C (140°F), the vehicle information
system circuit protection function is activated, causing the display to
dim.
NOTE
• In the interest of safety, the use of some functions may be unavailable while in
driving. The button for a touch screen that cannot be used will be displayed in
tint color (toned down).
• Liquid-crystal displays may be difficult to read when wearing polarized
glasses.
Vehicle Information 229
Displaying Vehicle Information Screen
The vehicle information screen provides a variety of informa-
tion on your vehicle and driving. It also gives ways to program
certain functions available in your vehicle.
1 First, press the button, then select any of the keys
on the screen.
The screen displays the current fuel consumption rate, average
fuel consumption rate, and the range you can drive on the
remaining fuel. See Pages 230 through 231.
The screen displays the driving record data. The monitor system
can retain the record data. See Pages 232 through 237.
The screen displays the reading of the following three meters:
average fuel consumption rate, current fuel consumption rate and
throttle opening percentage. See Page 237.
You can program your maintenance schedule and other mainte-
nance-related items from this screen. See Pages 238 through 239.
You can use a calculator. You can also convert units, for example,
between miles and kilometers. See Page 242.
You can program certain monitor and other system functions. See
Pages 239 through 242.
NOTE
• You may not be able to use the vehicle information screen if data cannot be
properly retrieved from the relevant vehicle systems.
230 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
Displaying fuel consumption information and
programming for the automatic alarm display
■ Displaying fuel consumption information
Use the following procedure to display the current fuel consumption
rate, average fuel consumption rate, and range you can drive on the
remaining fuel.
1 Press the button.
2 Select .
The fuel consumption information screen will be displayed.
This completes the procedure.
NOTE
• Current and average fuel consumption rates will change all time due to driv-
ing and other conditions. The displayed data, including remaining fuel range
data, may be different from the actual values. It is advisable that you refuel
well in advance of reaching a displayed distance.
• Displayed current and average fuel consumption rates are based on estimates
during running, not on accurate measurements.
• The average fuel consumption rate is associated with the driving after the last
resetting of each trip meter. If the A or B trip meter is reset, the average fuel
consumption rate will also be reset. After resetting the trip meter, the average
fuel consumption rate will not be displayed until the vehicle has been driven
approximately 1 mile from the reset point.
■ Programming automatic alarm display for low remain-
ing fuel level
You can program the display to make it automatically alert you of the
correspondingly low fuel level remaining.
1 Press the button and then select .
2 Select .
Vehicle Information 231
Displaying Vehicle Information and Programming Vehicle System Functions
3 Select (off ) for the desired alarm display item
(“FUEL“).
The selected (off) should change to (on).
4 Select .
This completes the procedure.
NOTE
• If (on) is displayed for “FUEL” (remaining fuel level), the automatic alarm
display function has been activated for that item. To deactivate the function,
select (on). The indication should change from (on) to (off ).
• The current fuel consumption rate alarm will be displayed only when the nav-
igation screen is being used.
• The screen displaying an alarm looks like this:
232 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
Displaying, retaining, and erasing driving
record data
■ Displaying driving record data
Use the following procedure to display the current driving record data
(distance, time, and average fuel consumption rate).
1 Press the button.
2 Select .
The driving record screen will be displayed.
This completes the procedure.
NOTE
• If a vehicle's trip meter is reset, the corresponding drive distance and time dis-
play (“TRIP A” or “TRIP B”) will also be reset.
• The drive time display is associated with the amount of time the ignition
switch has stayed on since the trip meter was reset.
• When the vehicle battery is removed for repair or other purposes, the time is
reset, but the distance is not reset. To reset the distance, press the trip meter
knob. Please refer to the vehicle owner's manual for further details.
• The maximum time display possible is 240 hours (10 days).
■ Retaining driving record data
Use the following procedure to retain the current driving record data.
1 Press the button and then select .
2 Select (list) below the trip meter designation
(TRIP A or TRIP B) of the driving record data you wish to
keep.
Vehicle Information 233
Displaying Vehicle Information and Programming Vehicle System Functions
3 Select or to specify the number of the history
frame (data storage location) where the driving record
data are to be retained.
4 Select (store).
5 (yes) will appear, requesting you to confirm your
selection. Select it.
6 Select .
This completes the procedure.
NOTE
• A maximum of three different driving record data sets can be retained for
each of the trip meters (TRIP A and TRIP B).
• Driving record data can be retained while viewing the retained driving record
data list (See Page 235).
• If the data storage location (history frame) specified in Step 3 is already occu-
pied by data, this data will be replaced with new data once you have con-
firmed Step 5.
• When driving record data have been successfully retained in a history frame,
the history frame's heading will change from a number to the date of data
retention.
■ Erasing driving record data
Use the following procedure to erase retained driving record data.
1 Press the button and then select .
2 Select (list) below the trip meter designation
(TRIP A or TRIP B) about which you wish to erase the driv-
ing record data.
234 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
3 Select or to specify the number of the history
frame (data storage location) where the driving record
data to be erased are retained.
4 Select (reset).
5 (yes) will appear, requesting you to confirm your
selection. Select it.
6 Select .
This completes the procedure.
NOTE
There is no way to restore erased driving record data. Please use this procedure
with caution so as not to accidentally erase any important data.
■ Displaying retained driving record data list
Use the following procedure to display a retained driving record data
list.
1 Press the button and then select .
2 Select (table) for the trip meter (TRIP A or TRIP B)
about which you wish to display the list.
Vehicle Information 235
Displaying Vehicle Information and Programming Vehicle System Functions
This completes the procedure.
NOTE
Selecting on a driving record data list screen will cause the monitor sys-
tem to go back to the driving record screen.
■ Retaining driving record data while viewing a retained
driving record data list
Use the following procedure if you want to retain driving record data
while viewing a relevant data list.
1 Press the button and then select .
2 Select (table) for the trip meter (TRIP A or TRIP B)
about which you wish to retain the driving record data.
3 Select (store).
236 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
4 Select the history frame (data storage location) in which
the data are to be retained.
5 (yes) will appear, requesting you to confirm your
selection. Select it if the selection is correct.
6 Select .
This completes the procedure.
NOTE
• A maximum of three different driving record data sets can be retained for
each of the trip meters (TRIP A and TRIP B).
• When the data storage location (history frame) specified in Step 4 is already
occupied by data, this data will be replaced with new data once you have
confirmed Step 5.
• When the driving record data has been successfully retained in a history
frame, the history frame's heading will change from a number to the date of
the data retention.
• Data retention is cancelled if you select (no) in the “Select
data (no) “box.
■ Erasing driving record data while viewing a retained
driving record data list
Use the following procedure if you want to erase retained driving
record data while viewing a driving record data list.
1 Press the button and then select .
2 Select (table) for the trip meter (TRIP A or TRIP B)
about which you wish to erase the driving record data.
3 Select (reset).
Vehicle Information 237
Displaying Vehicle Information and Programming Vehicle System Functions
4 Select the history frame (data storage location) where
the data to be erased are retained.
5 (yes) will appear, requesting you to confirm your
selection. Select it.
6 Select .
This completes the procedure.
NOTE
• There is no way to restore erased driving record data. Please use this proce-
dure with caution so as not to accidentally erase any important data.
• Data erasure is cancelled if you select (no) in the “Select
data (no) “box.
Displaying three meters
Use the following procedure to display the three meters showing the
average fuel consumption rate, current fuel consumption rate and
throttle opening percentage.
1 Press the button.
2 Select .
The three meters will be displayed on the screen.
This completes the procedure.
NOTE
• The average fuel consumption rate, current fuel consumption rate and throttle
opening percentage indications are based on data retrieved from the relevant
vehicle systems. For this reason, the status represented by meter readings may
lag behind the current status.
• If data cannot be properly retrieved from the relevant vehicle systems, there
will be no readings displayed on the meters.
238 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
Maintenance schedule
■ Programming maintenance schedule
You can program your maintenance schedule into the monitor system
for any of the following items, in terms of period and distance intervals.
- Maintenance
- Fluids check
- Tire pressure
- Engine oil
Use the following procedure:
1 Press the button.
2 Select .
The maintenance information screen will be displayed.
3
Select the item (maintenance, fluids check, tire pressure,
or engine oil) for which you wish to program the schedule.
4 Select to enter the maintenance schedule date.
5 Select (set).
6 (yes) will appear on the screen. Select it if the
date is correct.
7 Select (next).
8 Select to enter the maintenance schedule dis-
tance.
Vehicle Information 239
Displaying Vehicle Information and Programming Vehicle System Functions
9 Select (set).
10 (yes) will appear on the screen. Select it if the
selection is correct.
11 Select .
This completes the procedure.
NOTE
• You may program in either the date first (Steps 4 through 6) or distance (Steps
7 through 10). You may also program in a date or a distance only.
• Do not fail to select (set) whenever a date or distance has been
entered, otherwise the entry will not be enabled.
• The date or distance entry can be cancelled by selecting (reset) in
Step 4 or 8.
• The programmed date and/or distance will be displayed in the maintenance
information screen.
• The icon(s) in the reminder messages for expired date and/or distance will be
displayed in red.
Programming vehicle system functions
■ Programming other vehicle system functions
You can program the vehicle system functions described below by
using the following procedure:
1 Press the button and then select (set).
2 Select .
Select or set the following items.
KEY ALERT
Select or deselect this key to enable or disable the key lock-in pre-
vention function. Please see the vehicle owner's manual for details
of the key lock-in prevention function.
ROOMLAMP (interior light)
You can choose the delay time before extinction of the interior
light when the doors are unlocked using the keyless entry system
transmitter, or when the doors are closed.
240 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
DEFOGGER
You can program the rear window defogger for two operation
modes: continuous and 15-minute. When the continuous opera-
tion mode is programmed, the rear window defogger will operate
for 15 minutes, stop for two minutes, and again operate for 15
minutes and so on. Even in under continuous operation mode,
the defogger shuts off if certain conditions are met.(Refer to the
vehicle owner's manual for these conditions.) In the 15-minute
mode, the defogger will automatically shut off after about 15 min-
utes. You can shut it off before that time if you push the rear win-
dow defogger switch.
DEICER
You can program the windshield wiper deicer for two operation
modes: continuous and 15-minute. When the continuous opera-
tion mode is programmed, pressing the windshield wiper deicer
switch means that the deicer will continue to function. It will,
however, stop operating automatically if certain conditions are
met. (Refer to the vehicle owner's manual for these conditions.) In
the 15-minute mode, the windshield wiper deicer will automati-
cally shut off after about 15 minutes. You can shut it off before that
time if you push the switch.
RESET
Select this key to revert all the three settings you performed on
this screen to the default settings.
This completes the procedure.
NOTE
• All selections and settings become effective as soon as they are made.
• The monitor system returns to the vehicle information screen when you
select .
• Setting the windshield wiper deicer is only enabled when your vehicle has the
windshield wiper deicer function.
• Interior light extinction delay time can be programmed as follows:
After unlocking doors with
keyless entry transmitter
After closing doors
0 SEC 0 second 0 second
SHORT 35 seconds 12 seconds
NORMAL 35 seconds 22 seconds
LONG 35 seconds 32 seconds
Vehicle Information 241
Displaying Vehicle Information and Programming Vehicle System Functions
■ Keyless entry system programming
You can program certain items related to the keyless entry system using
the following procedure:
1 Press the button and then select (set).
2 Select .
Select or set the following items.
LOCK SIGNAL
The keyless entry system has an answerback signaling function,
which notifies the driver by electronic chirp and the turn signal
lights when locking or unlocking operation performed. Please select
or deselect the activation or deactivation of the electronic chirp and
turn signal lights. The electronic chirp can be selected using the
“BEEP” icon, and the turn signal lights using the “LIGHT” icon.
RESET
Select this button to revert all settings performed on this screen
to the default settings.
This completes the procedure.
NOTE
• Each setting becomes effective as soon as you make it.
• The monitor system returns to the vehicle information screen when you
select .
• The answerback signaling setting is only enabled when your vehicle has that
function.
• For detailed information on how to operate the keyless entry system, refer to
your vehicle owner's manual.
■ Alarm system and shock sensor
You can activate or deactivate the alarm system and the dealer optional
shock sensor. Also, you can select the monitoring start delay time and
the sensitivity level for detection of impact to the vehicle.
1 Press the button and then select (set).
2 Select .
Select or set the following items.
242 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
ALARM
Set the alarm system ON or OFF.
DELAY
Set the monitoring start delay time (after closure of doors).
NOTE
• The settings for shock sensor can only be performed on a vehicle equipped
with the dealer optional shock sensor.
• It takes around 5 seconds for the sensitivity level to be adjusted. During this
time, the security indicator light will flash to indicate the adjustment is being
performed.
• If the sensitivity adjustment has not been performed correctly, the buzzer
(beeping sound) will sound four times. If the buzzer continues to sound fre-
quently, please have the system inspected by a SUBARU dealer.
The calculator functions
A calculator with an 8-digit display is available. The calculator also per-
forms unit conversions between miles and kilometers, pounds and kilo-
grams, etc.
1 Press the button and then select .
To perform a unit conversion, enter a number, then select the key
for the unit you wish to convert from, then the key for the unit you
wish to convert to.
Example: Convert 100 miles into kilometers: 100 ➔ [mile] ➔ [km]
= 160.9 km
Below is a description of each key and what it does.
Key Description Action
0-9 Numbers The numbers 0 to 9
. Decimal point Begin entering numbers below the deci-
mal point
= Equals sign Display the results of the calculation
Vehicle Information 243
Displaying Vehicle Information and Programming Vehicle System Functions
* Results of unit conversions may include rounding errors.
+ Addition operator Perform addition
– Subtraction operator Perform subtraction
÷ Division operator Perform division
× Multiplication opera-
tor
Perform multiplication
MR Memory recall Retrieve a number from memory, and
overwriting the current display
M+ Memory add Add the currently displayed number to the
memory
C Clear Clear the currently displayed number. If
you have entered a number after pressing
an operator, pressing this button returns
the calculator to the state of having
pressed the operator.
AC All clear Return to the initial state (clear the current
display, operator state, memory number,
etc.)
°F Fahrenheit Convert the entered number from Celsius
to Fahrenheit*
°C Celsius Convert the entered number from Fahren-
heit to Celsius*
gal Gallons Convert the entered number from liters to
gallons*
L Liters Convert the entered number from gallons
to liters*
lb Pounds Convert the entered number from kilo-
grams to pounds*
Key Description Action
kg Kilograms Convert the entered number from pounds
to kilograms*
mi Miles Convert the entered number from kilome-
ters to miles*
km Kilometers Convert the entered number from miles to
kilometers*
ft Feet Convert the entered number from meters
to feet*
m Meters Convert the entered number from feet to
meters*
in Inches Convert the entered number from centi-
meters to inches*
cm Centimeters Convert the entered number from inches
to centimeters*
acre Acres Convert the entered number from square
meters to acres*
m
2
Square meters Convert the entered number from acres to
square meters*
psi Pounds per square
inch
Convert the entered number from kilopas-
cals to pounds per square inch*
kPa Kilopascals Convert the entered number from pounds
per square inch to kilopascals*
Key Description Action
244 Vehicle Information
Displaying Vehicle Information and Programming Vehicle System Functions
The calendar functions
A calendar feature is available.
■ Displaying calendar
1 Press the button.
2 Select (calender).
The calendar will appear.
A mark will appear on today's date.
NOTE
Use the arrow buttons ( ) to display the previous and following
months.
Vehicle Information 245
Adjusting Brightness/Contrast
Adjusting brightness/contrast
Use the following procedure to adjust the brightness/contrast of the
image on each screen:
1 Press the button.
2 Adjust the image contrast/brightness as follows:
Select and then or to adjust the brightness.
Select and then or to adjust the contrast.
Select to restore the default settings.
Select to turn off the brightness/contrast on the
screen.
Press , , or button to turn on the
display.
3 Select .
The previous screen will be displayed.
This completes the procedure.
NOTE
• All adjustments take effect as soon as you make them and can be visually con-
firmed.
• The system saves the adjustments for individual screens (vehicle information
screen and navigation screen) as well as for a situation with and without illu-
mination from headlights or parking lights.
Notes
Notes
Notes
