en
2
Table of contents
Safety ...............................................3
General information ...........................3
Intended use......................................3
Restriction on user group...................4
Safe use ............................................4
Preventing material damage.............8
General..............................................8
Environmental protection and
saving energy ...................................8
Disposing of packaging .....................8
Saving energy....................................8
Familiarising yourself with your
appliance ........................................10
Appliance ........................................10
Controls...........................................11
Accessories....................................11
Basic operation ..............................11
Switching on the appliance ..............11
Selecting a fan setting .....................12
Switching off the appliance ..............12
Switching on the lighting ..................12
Switching off the lighting ..................12
Cleaning and servicing...................12
Cleaning products ...........................12
Cleaning the stainless steel sur-
faces ...............................................12
Cleaning painted surfaces ...............12
Cleaning aluminium .........................12
Cleaning plastic ...............................13
Cleaning glass.................................13
Cleaning controls.............................13
Removing the grease filter ...............13
Cleaning grease filters manually ......13
Cleaning grease filters in the dish-
washer.............................................14
Fitting grease filters..........................14
Odour filter for recirculating air
mode...............................................14
Odour filter for the CleanAir recir-
culation module ...............................15
Troubleshooting .............................16
Malfunctions ....................................16
Disposal..........................................17
Disposing of old appliance ..............17
Customer Service ...........................17
E number and FD number ...............17
en
3
Safety
Please read the safety information to ensure that you use the ap-
pliance safely.
General information
Here you can find general information about this information
product.
¡ Read this manual carefully. Only then can you operate the appli-
ance safely and efficiently.
¡ This manual is intended for the user of the appliance.
¡ Observe the safety instructions and warnings.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Check the appliance for damage after unpacking it. Do not con-
nect the appliance if it has been damaged in transit.
Intended use
Please read the information on intended use to ensure you use
the appliance correctly and safely.
This appliance is designed only to be built into kitchen units. Read
the special installation instructions.
Only a licensed professional may connect appliances without
plugs. Damage caused by incorrect connection is not covered un-
der the warranty.
Only use this appliance:
¡ As specified in this instruction manual.
¡ For extracting cooking vapour.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of max. 4000m above sea level.
en
4
Restriction on user group
Avoid risks to children and vulnerable persons.
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user maintenance unless
they are at least 15 years old and are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Safe use
Follow these safety instructions when using the appliance.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
WARNING‒Risk of poisoning!
Risk of poisoning from flue gases being drawn back in. Room
air-dependent heat-producing appliances (e.g. gas, oil, wood
or coal-operated heaters, continuous flow heaters or water
heaters) obtain combustion air from the room in which they
are installed and discharge the exhaust gases into the open
through an exhaust gas system (e.g. a chimney). With the ex-
tractor hood switched on, air is extracted from the kitchen and
the adjacent rooms. Without an adequate supply of air, the air
en
5
pressure falls below atmospheric pressure. Toxic gases from
the flue or the extraction shaft are sucked backed into the liv-
ing space.
▶
Always ensure adequate fresh air in the room if the appli-
ance is being operated in exhaust air mode at the same
time as room air-dependent heat-producing appliance is be-
ing operated.
▶
It is only possible to safely operate the appliance if the pres-
sure in the room in which the heating appliance is installed
does not drop more than 4Pa (0.04mbar) below atmo-
spheric pressure. This can be achieved whenever the air
needed for combustion is able to enter through openings
that cannot be sealed, for example in doors, windows, in-
coming/exhaust air wall boxes or by other technical means.
An incoming/exhaust air wall box alone will not ensure com-
pliance with the limit.
▶
In any case, consult your responsible chimney sweep. He is
able to assess the house's entire ventilation setup and will
suggest the suitable ventilation measures to you.
▶
Unrestricted operation is possible if the appliance is oper-
ated exclusively in air recirculation mode.
WARNING‒Risk of fire!
¡ Fatty deposits in the grease filters may catch fire.
▶
Clean the grease filters roughly every2 months.
▶
Never work with naked flames close to the appliance (e.g.
flambéing).
en
6
▶
Do not install the appliance near a solid fuel heating appli-
ance (e.g. wood- or coal-burning) unless the heating appli-
ance has a sealed, non-removable cover. There must be no
flying sparks.
¡ Hot oil or grease ignites very quickly.
▶
Always supervise hot oil and fat.
▶
Never extinguish burning oil or fat with water. Switch off the
cooking zone. Extinguish flames carefully using a lid, fire
blanket or something similar.
¡ When gas burners are in operation without any cookware
placed on them, they can build up a lot of heat. A ventilation
appliance installed above the cooker may become damaged
or catch fire.
▶
Only operate the gas burners with cookware on them.
¡ Gas burners can build up a lot of heat while operating. A vent-
ilation appliance installed above the cooker may become
damaged or catch fire.
▶
Only operate the gas burners with cookware on them.
▶
Never operate two gas hotplates simultaneously on the
highest flame for longer than 15minutes.
▶
Never operate large burners of more than 5kW with the
highest flame for longer than 15minutes, e.g. a wok.
WARNING‒Risk of burns!
The accessible parts of the appliance become hot during op-
eration.
▶
Never touch these hot parts.
▶
Keep children at a safe distance.
WARNING‒Risk of injury!
¡ Components inside the appliance may have sharp edges.
▶
Carefully clean the appliance interior.
¡ Items placed on the appliance may fall off.
▶
Do not place any objects on the appliance.
en
7
¡ The light emitted by LED lights is very dazzling, and can dam-
age the eyes (risk group 1).
▶
Do not look directly into the switched-on LED lights for
longer than 100seconds.
¡ Children may swallow batteries.
▶
Keep batteries out of the reach of children.
▶
Keep an eye on any children when you are replacing batter-
ies.
WARNING‒Risk of electric shock!
¡ A damaged appliance or a damaged power cord can be dan-
gerous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked or fractured sur-
face.
▶
Call our customer service.
▶
Repairs on the appliance must be carried out solely by
trained, specialist personnel.
¡ Improper repairs can be dangerous.
▶
Repairs on the appliance must be carried out solely by
trained, specialist personnel.
▶
If the power cord of this appliance is damaged, it must be
replaced by trained specialist staff.
¡ Penetrating moisture may cause electric shock.
▶
Do not use steam- or high-pressure cleaners to clean the
appliance.
en Preventing material damage
8
Preventing material dam-
age
Follow these instructions to prevent
material damage to your appliance, ac-
cessories or other objects in your kit-
chen.
General
Follow these instructions when using
the appliance.
ATTENTION!
¡ Condensate may cause corrosion
damage.
▶
To prevent condensation from
building up, switch on the appli-
ance during cooking.
¡ If moisture gets into the controls, this
may result in damage.
▶
Never clean controls with a wet
cloth.
¡ Incorrect cleaning damages the sur-
faces.
▶
Follow the cleaning instructions.
▶
Do not use harsh or abrasive de-
tergents.
▶
Clean stainless steel surfaces in
the direction of the finish only.
▶
Never clean controls with stain-
less steel cleaners.
¡ Condensation that flows back in may
damage the appliance.
▶
The air extraction duct must be in-
stalled with a gradient of at least
1° from the appliance.
¡ If you put incorrect stress on the
design elements, they may break off.
▶
Do not pull design elements.
▶
Do not place objects on the
design elements or hang objects
from them.
Environmental protection
and saving energy
Help protect the environment by using
your appliance in a way that conserves
resources and by disposing of re-
usable materials properly.
Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶
Sort the individual components by
type and dispose of them separately.
Information about current disposal
methods are available from your
specialist dealer or local authority.
Saving energy
If you follow these instructions, your ap-
pliance will use less power.
Ensure that there is sufficient ventila-
tion when cooking.
The appliance works more efficiently
and with fewer operating noises.
Adjust the fan speed to the amount of
steam produced during cooking.
The lower the fan speed, the less
energy is consumed.
If cooking produces large amounts of
steam, select a higher fan speed in
good time.
The odours are distributed around
the room less.
Switch the appliance off when you are
not using it.
The appliance does not consume
any energy.
Environmental protection and saving energy en
9
Switch off the lighting if you no longer
require it.
The lighting does not consume any
energy.
Clean or replace the filters at regular
intervals.
The effectiveness of the appliance is
increased.
Put the cooking lid on.
The cooking vapours and condensa-
tion are reduced.
en Familiarising yourself with your appliance
10
Familiarising yourself with your appliance
Familiarise yourself with the parts of your appliance.
Appliance
You can find an overview of the parts of your appliance here.
1 2 3 4 5
1
Controls
2
Grease filter
3
Filter cover
4
Lighting
5
Pivoting glass screen
Accessories en
11
Controls
The controls are used to configure all
functions of your appliance and to ob-
tain information about the operating
status.
Switches off the fan and lighting.
Switches fan setting 1 on.
Switches fan setting 2 on.
Switches fan setting 3 on.
Switches on the lighting.
Switches on fan setting 1 and the light-
ing.
Switches on fan setting 2 and the light-
ing.
Switches on fan setting 3 and the light-
ing.
Control knob
The control knob is retractable. You
can push the control knob to engage
and disengage it.
Accessories
You can buy accessories from the
after-sales service, from specialist re-
tailers or online. Only use original ac-
cessories, as these have been specific-
ally designed for your appliance.
Accessories vary from one appliance to
another. When purchasing accessories,
always quote the exact product number
(E no.) of your appliance. →Page17
You can find out which accessories are
available for your appliance in our cata-
logue, in the online shop or from our
after-sales service.
www.neff-international.com
Accessories Order number
Odour filter Z51IMA0X0
Starter set for air recir-
culation mode
Z51IBU0X0
Odour filter for the
CleanAir recirculation
module
Z54TR00X0
Odour filter for the
CleanAir recirculation
module, can be regen-
erated
Z51ITP0X0
CleanAir recirculation
module
Z54TR60X3
Short chimney exten-
sion
Z51IBG0N0
Long chimney exten-
sion
Z51IBN0N0
Basic operation
You can find out everything you need
to know about operating your appli-
ance here.
Switching on the appliance
▶
Set the control knob to .
a The appliance starts at fan setting 1.
en Cleaning and servicing
12
Selecting a fan setting
▶
Set the control knob to any fan set-
ting.
Switching off the appliance
▶
Set the control knob to .
Switching on the lighting
1.
Set the control knob to .
2. To use the lighting at the same time
as a fan setting, set the control knob
to , or .
Switching off the lighting
▶
Set the control knob to .
Cleaning and servicing
To keep your appliance looking its best
and working efficiently for a long time,
it is important to clean and maintain it
carefully.
Cleaning products
You can obtain suitable cleaning
products from after-sales service or the
online shop.
WARNING
Risk of electric shock!
Penetrating moisture may cause elec-
tric shock.
▶
Do not use steam- or high-pressure
cleaners to clean the appliance.
ATTENTION!
Unsuitable cleaning products may
damage the surfaces of the appliance.
▶
Do not use harsh or abrasive deter-
gents.
▶
Do not use cleaning products with a
high alcohol content.
▶
Do not use hard scouring pads or
cleaning sponges.
▶
Do not use any special cleaners for
cleaning the appliance while it is hot.
▶
Do not use limescale remover on the
door handle or control panel, as it
may leave permanent staining.
▶
Only use glass cleaners, glass
scrapers or stainless steel care
products if recommended in the
cleaning instructions for the relevant
part.
▶
Wash sponge cloths thoroughly be-
fore use.
Cleaning the stainless steel
surfaces
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Clean using a sponge cloth and hot
soapy water in the direction of the
finish.
3. Dry with a soft cloth.
4. Apply a thin layer of the stainless
steel cleaning product with a soft
cloth.
Tip:You can obtain stainless steel
cleaning products from after-sales ser-
vice or the online shop.
Cleaning painted surfaces
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Clean using a sponge cloth and hot
soapy water in the direction of the
finish.
3. Dry with a soft cloth.
Cleaning aluminium
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
Cleaning and servicing en
13
2. Clean with a soft cloth and glass
cleaner.
Cleaning plastic
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Clean with a soft cloth and glass
cleaner.
Cleaning glass
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Clean with a soft cloth and glass
cleaner.
Cleaning controls
WARNING
Risk of electric shock!
Penetrating moisture may cause an
electric shock.
▶
Do not use wet sponge cloths.
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Clean using a damp sponge cloth
and hot soapy water.
3. Dry with a soft cloth.
Removing the grease filter
ATTENTION!
Falling grease filters may damage the
hob below.
▶
Grip below the grease filter with one
hand.
1. Open the filter cover by pulling it
downwards.
2. Open the locks in the grease filters.
3. Remove the grease filters from the
holders.
To prevent grease from dripping,
hold the grease filter horizontally.
Cleaning grease filters manu-
ally
The grease filters filter the grease from
the cooking vapour. Regularly cleaned
grease filters guarantee a high level of
grease removal.
WARNING
Risk of fire!
Fatty deposits in the grease filters may
catch fire.
▶
Clean the grease filters roughly
every2 months.
Requirement:The grease filters have
been removed.
→"Removing the grease filter",
Page13
en Cleaning and servicing
14
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Soak the grease filter in hot soapy
water.
Use special grease solvent for stub-
born dirt. You can obtain grease
solvents from after-sales service or
the online shop.
3. Use a brush to clean the grease fil-
ters.
4. Rinse the grease filters thoroughly.
5. Allow the grease filters to drain.
Cleaning grease filters in the
dishwasher
The grease filters filter the grease from
the cooking vapour. Regularly cleaned
grease filters guarantee a high level of
grease removal.
WARNING
Risk of fire!
Fatty deposits in the grease filters may
catch fire.
▶
Clean the grease filters roughly
every2 months.
ATTENTION!
The grease filters may become dam-
aged if they are squeezed.
▶
Do not squeeze the grease filters.
Note:When cleaning the grease filter in
the dishwasher, light discolouration
may occur. This discolouration has no
effect on the performance of the metal
grease filters.
Requirement:The grease filters have
been removed.
→"Removing the grease filter",
Page13
1. Observe the information regarding
the cleaning agents.
→"Cleaning products", Page12
2. Place the grease filters loosely into
the dishwasher.
Do not clean heavily soiled grease
filters with utensils.
Use special grease solvent for stub-
born dirt. You can obtain grease
solvents from after-sales service or
the online shop.
3. Start the dishwasher.
Select a temperature of no more
than 70°C.
4. Allow the grease filters to drain.
Fitting grease filters
ATTENTION!
Falling grease filters may damage the
hob below.
▶
Grip below the grease filter with one
hand.
1. Fit the grease filter.
2. Fold the grease filter upwards and
engage the locks.
3. Make sure that the locks engage.
4. Fold the filter cover upwards to close
it.
Odour filter for recirculating
air mode
Odour filters bind odorous substances
in air recirculation mode. Regularly re-
placed odour filters guarantee a high
level of odour removal.
With normal use (approx.onehour a
day), the odour filter must be replaced
every 4 months. The odour filter can-
not be cleaned or regenerated.
You can obtain odour filters from the
after-sales service or the online shop.
Only use original odour filters.
Cleaning and servicing en
15
Removing odour filter
Requirement:The grease filters have
been removed.
→"Removing the grease filter",
Page13
▶
Rotate the old odour filters and re-
move them from the holder.
1
1
2
2
Fitting odour filters
1. Push the new odour filters onto the
holder and rotate.
1
2
2
1
2. Fit the grease filters.
→"Fitting grease filters", Page14
Odour filter for the CleanAir
recirculation module
You can use your appliance with a
CleanAir air recirculation module. The
installation instructions enclosed de-
scribe how to replace the correspond-
ing odour filter.
en Troubleshooting
16
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting in-
formation before contacting Customer Service. This will avoid unnecessary costs.
WARNING
Risk of injury!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained specialist staff.
▶
If the appliance is defective, call Customer Service.
WARNING
Risk of electric shock!
Improper repairs can be dangerous.
▶
Repairs on the appliance must be carried out solely by trained, specialist person-
nel.
▶
If the power cord of this appliance is damaged, it must be replaced by trained
specialist staff.
Malfunctions
Errors Cause Troubleshooting
The appliance is not working. The mains plug of the power
cord is not plugged in.
▶
Connect the appliance to the power
supply.
The circuit breaker is faulty.
▶
Check the circuit breaker in the fuse
box.
There has been a power cut.
▶
Check whether the lighting in your kit-
chen or other appliances are working.
The lighting does not work. Different causes are possible.
▶
Call the after-sales service.
→"Customer Service", Page17
Disposal en
17
Disposal
Find out here how to dispose of old ap-
pliances correctly.
Disposing of old appliance
Valuable raw materials can be re-
claimed by recycling.
▶
Dispose of the appliance in an envir-
onmentally friendly manner.
This appliance is labelled in ac-
cordance with European Directive
2012/19/EU concerning used
electrical and electronic appli-
ances (waste electrical and elec-
tronic equipment - WEEE).
The guideline determines the
framework for the return and re-
cycling of used appliances as ap-
plicable throughout the EU.
Customer Service
If you have any queries on use, are un-
able to rectify faults on the appliance
yourself or if your appliance needs to
be repaired, contact Customer Service.
You can solve many problems yourself
by consulting the information on
troubleshooting in these instructions or
on our website. If this is not the case,
contact our after-sales service.
We will always find an appropriate solu-
tion and try to avoid unnecessary visits
being made by a Customer Service
technician.
With any warranty claims, we will make
sure that your appliance is repaired by
after-sales customer service techni-
cians using original spare parts, includ-
ing after the manufacturer's warranty
has expired.
Note:Under the manufacturer's war-
ranty conditions, use of the after-sales
service is free.
When contacting after-sales service,
you will need the product number (E
no.) and the production number (FD
no.) of your appliance.
The contact details for Customer Ser-
vice can be found in the enclosed Cus-
tomer Service directory or on our web-
site.
E number and FD number
The E number and the FD number can
be found on the appliance's rating
plate.
Depending on the model, the rating
plate can be found:
¡ Inside the appliance (remove grease
filters for access).
¡ On top of the appliance.
Make a note of your appliance's details
and the Customer Service telephone
number to find them again quickly.
Constructa-Neff Vertriebs-GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.neff-international.com
*9001433734*
9001433734
en
990705
