MX Vertical Advanced Ergonomic Mouse
GETTING STARTED
We've put everything you need to get started with your MX Vertical Advanced
Ergonomic Mouse right here. If you still have questions browse the topics on the
left.
Time to make yourself comfortable!Time to make yourself comfortable!
Thank you for getting the new MX Vertical. We hope you will enjoy this ergonomic mouse. Please
download Logitech Options (https://support.logitech.com/software/options) to unlock the full
potential of your MX Vertical.
All Content
(http://buy.logitech.com/store/logib2c/DisplayShoppingCartPage/locale.en_us/)
(http://www.logitech.com/en-
us/home)
SUPPORT (/en_us/home)
CREATE AN ACCOUNT
(/EN_US/CREATE-
ACCOUNT)
Let's get startedLet's get started
MX Vertical can connect in three dierent ways. Please follow the instructions below to connect
the USB cable, or wirelessly using Bluetooth or the USB receiver.
Connect with the USB cableConnect with the USB cable
To connect through the USB cable please make sure your MX vertical is turned on. Then plug the USB cable into your MX Vertical to use it corded.
Connect Wirelessly using Bluetooth or USB receiverConnect Wirelessly using Bluetooth or USB receiver
You can connect your MX Vertical wirelessly using Bluetooth or the Unifying USB receiver. Below you can nd the instructions to get connected:
Connect via BluetoothConnect via Bluetooth
1. Make sure the cable is unplugged and then turn on your MX Vertical.
2. Press the Easy-Switch button to select the channel you want to pair to. (Make sure the
LED is blinking fast — if it's not, press and hold the button for 3 seconds.)
3. Open Bluetooth settings on your computer.
On MacOS: Open System PreferencesSystem Preferences > BluetoothBluetooth > Add “MX VerticalMX Vertical”
On Windows: Select StartStart > SettingsSettings > DevicesDevices > Add Bluetooth deviceAdd Bluetooth device > Add “MXMX
VerticalVertical”
4. MX Vertical isconnected.
Connect via Unifying USB ReceiverConnect via Unifying USB Receiver
1. Make sure the cable is unplugged and then turn on your MX Vertical.
2. Press the Easy-Switch button to select the channel you want to pair to.
3. Plug the Unifying USB receiver into a port on your computer.
4. MX Vertical is connected.
Product OverviewProduct Overview
MX Vertical at a glanceMX Vertical at a glance
1 – Natural angle 5 – High precision sensor
2 – Precision scroll-wheel 6 – Textured thumb rest
3 – Island keys 7 – Customizable shortcuts
4 – USB-C charging port 8 – Cursor speed switch
(http://buy.logitech.com/store/logib2c/DisplayShoppingCartPage/locale.en_us/)
(http://www.logitech.com/en-
us/home)
SUPPORT (/en_us/home)
CREATE AN ACCOUNT
(/EN_US/CREATE-
ACCOUNT)
Advanced FeaturesAdvanced Features
Ergonomic shapeErgonomic shape
MX VERTICAL is designed to promote a natural handshake position through a unique 57-degree
vertical angle. The textured rubber panel provides a soft comfortable feel while giving a good
grip.
Try to keep your hand in a natural, relaxed position while using, to avoid any unnecessary
extension in your wrist. Also, use the cursor speed switch to increase the speed to reduce the
overall movement needed.
Learn more about the ergonomic design (http://ergo.logi.com).
High precision sensor and cursor speed switchHigh precision sensor and cursor speed switch
MX Vertical has an advanced high-precision sensor with 4000 adjustable DPI and an instant
cursor speed switch.
Cursor speed switch
The cursor speed switch allows you to toggle between two cursor speeds with the press of a
button.
Cursor speed 1 1000 DPI
Cursor speed 2 1600DPI
(http://buy.logitech.com/store/logib2c/DisplayShoppingCartPage/locale.en_us/)
(http://www.logitech.com/en-
us/home)
SUPPORT (/en_us/home)
CREATE AN ACCOUNT
(/EN_US/CREATE-
ACCOUNT)
With Logitech Options, you will receive an on-screen notication when switching between cursor
speed 1 and cursor speed 2.
You can also fully customize the speed full to your needs. All you have to dois to press and hold
the cursor speed switch until the overlay appears (see example below) and then simply move the
mouse left or right to adjust the speed.
Power ManagementPower Management
MX Vertical has a rechargeable battery.
Battery life — fourmonths on a full charge
Fast charge — one minute of charge gives three hours of battery
The battery indicator LED will let you know when the power is low, and when torecharge. You can
install Logitech Options to get on-screen notications.
LEDLED DescriptionDescription
Green More than 10% battery life
Red Less than 10% battery life
Breathing eect Charging
NOTE: When charging MX vertical will be connected through the cable.
Easy-SwitchEasy-Switch
MX Vertical can connect up to three devices and seamlessly switch between them with a press of
a button.
The Easy-Switch button is located on the bottom of the MX Vertical.
DownloadsDownloads
(http://buy.logitech.com/store/logib2c/DisplayShoppingCartPage/locale.en_us/)
(http://www.logitech.com/en-
us/home)
SUPPORT (/en_us/home)
CREATE AN ACCOUNT
(/EN_US/CREATE-
ACCOUNT)
Use Logitech Options (https://support.logitech.com/en_us/software/options) software for
MacOS and Windows.
Additional InformationAdditional Information
1. Natural GripNatural Grip
MX VERTICAL is designed to promote a natural handshake position through a unique 57-
degree vertical angle. The textured rubber panel provides a soft comfortable, yet solid grip.
2. Precision WheelPrecision Wheel
The precision scroll wheel provides a precise line-by-line scrolling and has an integrated middle
click.
3. Island KeysIsland Keys
Island keys with quality switches that last up to 10 million clicks.
4. Rechargeable USB-CRechargeable USB-C
MX Vertical is rechargeable and lasts up to four months. One minute of charge will give three
hours of usage.
5. High Precision SensorHigh Precision Sensor
4000 adjustable DPI.
6. Textured Thumb RestTextured Thumb Rest
7. Customizable ShortcutsCustomizable Shortcuts
Easily accessible shortcuts. All extra buttons and shortcuts can be customized using Logitech
Options.
8. Cursor Speed SwitchCursor Speed Switch
The cursor speed switch allows you to switch cursor instantly with a press of a button.
