LH-T250SC
JA1ULZA
ⓒ
Copyright
2005,
Zenith
Electronics
Corporation
Installation
and
Operating
Guide
|
Warranty
Model
Number
|
ZHD-311
|
DVD
Receiver
Home
Theater
System
(Speakers:
LHS-25SCS/LHS-25SCW)
2
Safety
Precautions
This
lightning
flash
with
arrowhead
symbol
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
dangerous
voltage
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
important operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
the
appliance.
WARNING:
Do
not
install
this
equipment
in
a
confined
space
such
as a
book
case
or
similar
unit.
CAUTION:
This
Digital
Video
Disc
Receiver
employs
a
Laser
System.
To
ensure
proper
use
of
this
product,
please
read
this
owner's
manual
carefully
and
retain
for
future
reference.
Should
the
unit
require
maintenance,
contact
an
authorized
service
loca-
tion-see
service
procedure.
Use
of
controls,
adjustments
or
the
performance
of
procedures
other
than
those
specified
herein
may
result
in
hazardous
radiation
exposure.
To
prevent
direct
exposure
to
laser
beam,
do
not
try
to
open
the enclosure.
Visible
laser
radiation
when
open.
DO
NOT
STARE
INTO
BEAM.
CAUTION:
The
apparatus
shall
not
be
exposed
to
water,
dripping
or
splashing
and
that
no
objects
filled
with
liquids,
such
as
vases,
shall
be
placed
on
the
apparatus.
CAUTION
concerning
the
Power
Cord
Most
appliances
recommend
they
be
placed
upon
a
dedicated
circuit;
That
is,
a
single
outlet
circuit
which
powers
only
that
appliance
and
has
no
additional
outlets
or
branch
circuits.
Check
the
specification
page
of
this
owner's
manual
to
be
certain.
Do
not
overload
wall
outlets.
Overloaded
wall
outlets,
loose
or
damaged
wall
outlets,
extension
cords,
frayed
power
cords,
or
damaged
or
cracked
wire
insulation
are
dangerous.
Any
of
these
conditions
could
result
in
electric
shock
or
fire.
Periodically
examine
the
cord
of
your
appliance,
and
if
its
appearance
indicates
damage
or
deterioration,
unplug
it,
dis-
continue
use
of
the
appliance,
and
have
the
cord
replaced
with
an
exact
replacement
part
by
an
authorized
servicer.
Protect
the
power
cord
from
physical
or
mechanical
abuse,
such
as
being
twisted,
kinked,
pinched,
closed
in
a
door,
or
walked
upon.
Pay
particular
attention
to
plugs,
wall
outlets,
and
the
point
where
the
cord
exits
the
appliance.
REGULATORY
INFORMATION:
FCC
Part
15
This
product
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B
digital
device,
pursuant
to
Part
15
of
the
FCC
Rules.
These
limits
are
designed
to
provide
reasonable
protection
against
harmful
interference
when
the
product
is
operated
in
a
residential
installation.
This
product
generates,
uses
and
can
radiate radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instruction
manual,
may
cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular
installation.
If
this
product
does
cause
harmful
interference
to
radio
or
television
reception,
which
can
be
determined
by
turning
the
product
off
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
the
following
measures:
?
Reorient
or
relocate
the
receiving
antenna.
?
Increase
the
separation
between
the
product
and
receiv-
er.
?
Connect
the
product
into
an
outlet
on a
circuit
different
from
that
to
which
the
receiver
is
connected.
?
Consult
the
dealer
or
an
experienced
radio/TV
technician
for
help.
FCC
WARNING:
This
equipment
may
generate
or
use
radio
frequency
energy.
Changes
or
modifications
to
this
equipment
may
cause
harmful
interference
unless
the
modifications
are
expressly
approved
in
the
instruction
manual.
The
user
could
lose
the
authority
to
operate
this
equipment
if
an
unauthorized
change
or
modification
is
made.
FCC
COMPLIANCE:
The
responsible
party
for
this
product's
compliance
is:
Zenith
Electronics
Corporation,
2000
Millbrook
Drive,
Lincolnshire,
IL
60069,
USA
Phone: 1-847-391-7000.
otes
on
copyrights:
It
is
forbidden
by
law
to
copy,
broadcast,
show,
broadcast
via
cable,
play
in
public,
or
rent
copyright
material
without
permission.
This
product
is
equipped
with
copy
protection
measures
developed
by
Macrovision.
Copy
protection
signals
are
record-
ed
on
some
discs.
When
recording
these
discs
on a
VCR,
noise
will
appear
during
playback.
This
product
incorporates
copyright
protection
technology
that
is
protected
by
certain
U.S.
patent
claims
and
other
intellectual
property
rights
owned
by
Macrovision
Corporation
and
other
rights
owners.
Use
of
this
copyright
protection
technology
must
be
authorized
by
Macrovision
Corporation,
and
is
intended
for
home
and
other
limited
viewing
uses
only
unless
otherwise
authorized
by
Macrovision
Corporation.
Reverse
engineering
or
disassembly
is
prohibited.
SERIAL
NUMBER:
The
serial
number
is
found
on
the
back
of
this
unit.
This
number
is
unique
to
this
unit
and
not
available
to
others.
You
should
record
requested
information
here
and
retain
this
guide
as
a
permanent
record
of
your
purchase.
Model
No.
Serial
No.
___________________________________
WARNING:
TO
REDUCE
THE
RISK
OF
FIRE
OR
ELEC-
TRIC
SHOCK,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
CAUTION
RISK
OF
ELECTRIC
SHOCK
DO
NOT
OPEN
WARNING:
TO
REDUCE
THE
RISK
OF
ELECTRIC
SHOCK,
DO
NOT
REMOVE
COVER
(OR
BACK)
NO
USER-SERVICEABLE
PARTS
INSIDE
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
CLASS
1
LASER
PRODUCT
KLASSE
1
LASER
PRODUKT
LUOKAN
1
LASER
LAITE
KLASS
1
LASER
APPARAT
CLASSE
1
PRODUIT
LASER
Introduction
3
1.
Read
these
instructions.
-
All
these
safety
and
operating
instructions
should
be
read
before
the
product
is
operated.
2.
Keep
these
instructions.
-
The
safety,
operating
and
use
instructions
should
be
retained
for
future
reference.
3.
Heed
all
warnings.
-
All
warnings
on
the
product
and
in
the
operating
instructions
should
be
adhered
to.
4.
Follow
all
instructions.
-
All
operating
and
use
instructions
should
be
followed.
5.
Do
not
use
this
apparatus
near
water.
--
For
example:
near
a
bath
tub,
wash
bowl,
kitchen
sink,
laundry
tub,
in
a
wet
basement;
or
near
a
swimming
pool;
and
like.
6.
Clean
only
with
dry
cloth.
--
Unplug
this
product
from
the
wall
outlet
before
cleaning.
Do
not
use
liquid
cleaners.
7.
Do
not
block
any
ventilation
openings.
Install
in
accordance
with
the
manufacturer's
instructions.
-
Slots
and
openings
in
the
cabinet
are
provided
for
ventilation
and
to
ensure
reliable
operation
of
the
product
and
to
protect
it
from
over-
heating.
The
openings
should
never
be
blocked
by
placing
the
product
on
a
bed,
sofa,
rug
or
other
similar
surface.
This
product
should
not
be
placed
in
a
built-in
installation
such
as
a
bookcase
or
rack
unless
proper
ventilation
is
provided
or
the
manufacturer's
instructions
have
been
adhered
to.
8.
Do
not
install
near
any
heat
sources
such
as
radiators,
heat
registers,
stoves,
or
other
apparatus
(including
amplifiers)
that
produce
heat.
9.
Do
not
defeat
the
safety
purpose
of
the
polarized
or
grounding-type
plug.
A
polarized
plug
has
two
blades
with
one
wider
than
the
other.
A
ground-
ing
type
plug
has
two
blades
and
a
third
ground-
ing
prong.
The
wide
blade
or
the
third
prong
are
provided
for
your
safety.
If
the
provided
plug
does
not
fit
into
your
outlet,
consult
an
electri-
cian
for
replacement
of
the
obsolete
outlet.
10.
Protect
the
power
cord
from
being
walked
on
or
pinched
particularly
at
plugs,
convenience
receptacles,
and
the
point
where
they
exit
from
the
apparatus.
11.Only
use
attachments/accessories
specified
by
the
manufacturer.
12.
Use
only
with
the
cart,
stand,
tripod,
bracket,
or
table
specified
by
the
manufacturer,
or
sold
with
apparatus.
When
a
cart
is
used,
use
caution
when
moving
the
cart/apparatus
combination
to
avoid
injury
from
tip-over.
13.
Unplug
this
apparatus
during
lightning
storms
or
when
unused
for
long
periods
of
time.
14.
Refer
all
servicing
to
qualified
service
personnel.
Servicing
is
required
when
the
apparatus
has
been
damaged
in
any
way,
such
as
power-
supply
cord
or
plug
is
damaged,
liquid
has
been
spilled
or
objects
have
fallen
into
the
apparatus,
the
apparatus
has
been
exposed
to
rain
or
moisture,
does
not
operate
normally,
or
has
been
dropped.
CAUTION:
PLEASE
READ
AND
OBSERVE
ALL
WARNINGS
AND
INSTRUCTIONS
IN
THIS
OWNER'S
MANU-
AL
AND
THOSE
MARKED
ON
THE
UNIT.
RETAIN
THIS
BOOKLET
FOR
FUTURE
REFERENCE.
This
set
has
been
designed
and
manufactured
to
assure
personal
safety.
Improper
use can
result
in
electric
shock
or
fire
hazard.
The
safeguards
incorporated
in
this unit
will
protect
you
if
you
observe
the
following
procedures
for
installation,
use,
and
servicing.
This
unit
does
not
contain
any
parts
that
can
be
repaired
by
the
user.
DO
NOT
REMOVE
THE
CABINET
COVER,
OR YOU
MAY
BE
EXPOSED
TO
DANGEROUS
VOLTAGE.
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL
ONLY.
IMPORTANT
SAFETY
INSTRUCTIONS
4
Table
of
Contents
Introduction
SafetyPrecautions.........................2
IMPORTANTSAFETYINSTRUCTIONS.
. . . . . . . .
.3
TableofContents..........................4
BeforeUse..............................5-6
PlayableDiscs...........................5
Precautions.............................6
NotesonDiscs..........................6
AboutSymbols..........................6
FrontPanelandRearPanel..................7
RemoteControlOverview....................8
Preparation
Connections............................9-11
TVConnections.........................9
ExternalEquipmentConnections
. . . . . . . . . . .
.9
SpeakerSystemConnection...............10
AntennaConnections.....................10
SpeakerPositioning......................11
BeforeOperation.......................12-17
Mini
Glossary
for
Audio
Stream
&
Surround
Mode.................................12
SoundMode...........................12
On-ScreenDisplay.......................13
InitialSettings........................14-17
GeneralOperation....................14
Language..........................14
Display............................14
Audio..............................15
Lock(ParentalControl)................16
Others.............................17
Operation
DVDOperation.........................18-20
PlayingaDVD..........................18
GeneralFeatures.....................18-20
MovingtoanotherTITLE...............18
Moving
to
another
CHAPTER/TRACK
. . . . .
18
SlowMotion.........................18
Still
and
Frame-by-Frame
Playback
.
19
Search.............................19
Repeat............................19
RepeatA-B.........................19
TimeSearch........................19
MarkerSearch.......................20
Zoom..............................20
SpecialDVDFeatures....................20
TitleMenu..........................20
DiscMenu..........................20
ChangingtheAudioLanguage.
. . . . . . . . .
.20
ChangingtheAudioChannel.
. . . . . . . . . .
.20
Subtitles...........................20
AudioCDandMP3/WMADisc...............21
Playing
an
Audio
CD
and
MP3/WMA
Disc
. . . . .
21
Pause.............................21
MovingtoanotherTrack...............21
RepeatTrack/All/Off...................21
Search.............................21
JPEGDiscOperation......................22
ViewingaJPEGdisc.....................22
SlideShow.........................22
StillPicture.........................22
Movingtoanotherfile.................22
Torotatepicture......................22
ProgrammedPlayback.....................23
RepeatProgrammedTracks................23
ErasingatrackfromProgrammeList
. . . . . . .
.23
Erasing
the
Complete
Programme
List
. . . . . . .
23
DivXDiscOperation.......................24
AdditionalInformation.....................25
LastConditionMemory...................25
ScreenSaver...........................25
ControllingtheTV.......................25
OperationwithRadio......................26
Presettingtheradiostations................26
Listeningtotheradio.....................26
OtherFunctions...........................27
SleepTimerSetting......................27
Dimmer...............................27
Mute.................................27
XTS(ExcellentTrueSound)................27
XTSpro...............................27
Reference
LanguageCodeList.......................28
CountryCodeList.........................28
Troubleshooting........................29-30
Specification.............................31
5
Introduction
Before
Use
Playable
Discs
DVD
(8cm/12cmdisc)
Audio
CD
(8cm/12cmdisc)
In
addition,
this
unit
can
play
a
DVD-RW,
DVD+RW
and
CD-R
or
CD-RW
that
contains
audio
titles,
MP3,
WMA,
JPEG
or
DivX
files.
otes
Depending
on
the
conditions
of
the
recording
equip-
ment
or
the
CD-R/RW
(or
DVD-RW,
DVD+RW)
disc
itself,
some
CD-R/RW
(or
DVD-RW,
DVD+RW)
discs
cannot
be
played
on
the
unit.
Do
not
attach
any
seal
or
label
to
either
side
(the
labeled
side
or
the
recorded
side)
of
a
disc.
Do
not
use
irregularly
shaped
CDs
(e.g.,
heart-shaped
or
octagonal).
It
may
result
in
malfunctions.
otes
on
DVDs
Some
playback
operations
of
DVDs
may
be
intentional-
ly
fixed
by
software
manufacturers.
As
this unit
plays
DVDs
according
to
disc
content
designed by
the
soft-
ware
manufacturer,
some
playback
features
of
the
unit
may
not
be
available
or
other
functions
may
be
added.
Make
sure
to
also
refer
to
the
instructions
supplied
with
the
DVDs.
Some
DVDs
made
for
business
purposes
may
not
be
able
to
be
played
on
the
unit.
Regional
code
of
the
DVD/CD
receiver
and
DVDs
This
DVD/CD
Receiver
is
designed
and
manufactured
for
playback
of
region
"1"
encoded
DVD
software.
The
region
code
on
the
labels
of
some
DVDs
indicates
which
type
of
player
can
play
those
discs.
This
unit
can
only
play
DVDs
labeled
"1"
or
"ALL".
If
you
try
to
play
any
other
discs,
the
message
"Check
Regional
Code"
will
appear
on
the
TV
screen.
Some
DVDs
that
have
no
region
code
label
may
still
be
subject
to
area
restrictions
and
therefore
not
playable.
ote
on
DTS-encoded
CDs
When
playing
DTS-encoded
CDs,
excessive
audio
level
may
be
heard
from
the
analog
stereo
output.
To
avoid
possible
damage
to
the
audio
system,
turn
down
the
volume
before
playing
back
such
discs,
adjust
the
volume
gradually,
and
keep
the
volume
level
low.
To
enjoy
DTS
Digital
SurroundTM
playback,
an
external
5.1
channel
DTS
Digital
SurroundTM
decoder
system
must
be
connected
to
the
digital
output
of
the
unit.
Disc-related
terms
Title
(DVD
only)
The
main
film
content
or
accompanying
feature
content
or
additional
feature
content,
or
music
album.
Each
title
is
assigned
a
title
reference
number
enabling
you
to
locate
it
easily.
Chapter
(DVD
only)
Sections
of
a
or
a
musical
piece
that
are
smaller
than
titles.
A
title
is
composed
of
one
or
several
chap-
ters.
Each
chapter
is
assigned
a
chapter
number,
enabling
you
to
locate
the
chapter
you
want.
Depending
on
the
disc,
chapters
may
not
be
recorded.
1
R
6
Before
Use
(Continued)
Precautions
Handling
the
unit
When
shipping
the
unit
The
original
shipping
carton
and
packing
materials
may
come
in
handy.
For
maximum
protection,
re-pack
the
unit
as
it
was
originally
packed
at
the
factory.
When
setting
up
the
unit
The
and
sound
of
a
nearby
TV,
VCR,
or
radio
may
be
disturbed
during
playback.
In
this
case,
position
the
unit
away
from
the
TV,
VCR,
or
radio,
or
turn
off
the
unit
after
removing
the
disc.
To
keep
the
exterior
surfaces
clean
Do
not
use
volatile
liquids,
such
as
insecticide
spray,
near
the
unit.
Do
not
leave
rubber
or
plastic
products
in
contact
with
the
unit
for
a
long
period
of
time.
They
will
leave
marks
on
the
surface.
Cleaning
the
unit
To
clean
the
cabinet
Use
a
soft,
dry
cloth.
If
the
surfaces
are
extremely
dirty,
use
a
soft
cloth
lightly
moistened
with
a
mild
detergent
solution.
Do
not
use
strong
solvents
such
as
alcohol,
benzene,
or
thinner,
as
these
might
damage
the
surface
of
the
unit.
To
obtain
a
clear
The
DVD/CD
Receiver
is
a
high-tech,
precision
device.
If
the
optical
pick-up
lens
and
disc
drive
parts
are
dirty
or
worn,
the
quality
will
be
poor.
Regular
inspection
and
maintenance
are
recommended
after
every
1,000
hours
of
use.
(This
depends
on
the
operating
environment.)
For
details,
please
contact
your
nearest
dealer.
Notes
on
Discs
Disc
Handling
Do
not
touch
the
playback
side
of
the
disc.
Hold
the
disc
by
the
edges
so
that
fingerprints
will
not
get
on
the
surface.
Do
not
stick
paper
or
tape
on
the
disc.
Storing
discs
After
playing,
store
the
disc
in
its
case.
Do
not
expose
the
disc
to
direct
sunlight
or
sources
of
heat,
or
leave
it
in
a
parked
car
exposed
to
direct
sun-
light,
as
there
may
be
a
considerable
temperature
increase
inside
the
car.
Cleaning
discs
Fingerprints
and
dust
on
the
disc
can
distort
the
or
reduce
sound
quality.
Before
playing,
clean
the
disc
with
a
clean
cloth.
Wipe
the
disc
from
the
centre
out-
wards.
Do
not
use
strong
solvents
such
as
alcohol,
benzene,
thinner,
commercially
available
cleaners,
or
anti-static
spray
intended
for
vinyl
records.
About
Symbols
About
the
symbol
display
""
may
appear
on
the
TV
screen
during
operation.
This
icon
means
the
function
explained
in
this
owner's
manual
is
not
available
on
that
specific
DVD
video
disc.
About
the
disc
symbols
for
instructions
A
section
whose
title
has
one
of
the
following
symbol
is
applicable
only
to
the
disc
represented
by
the
symbol.
DVD
and
finalized
DVD±R/RW.
Audio
CDs.
MP3
disc.
WMA
disc.
JPEG
disc.
DivX
disc.
DivX
JPEG
WMA
MP3
CD
DVD
Introduction
7
Front
Panel
and
Rear
Panel
OPEN/CLOSE
button
TUNING(-/+)/
SKIP(-/+)
VOLUME
Control
STANDBY/ON
DISPLAY
Window
STANDBY
indicator
Lights
red
when
the
receiver
is
in
Standby
mode
(off).
DISC
Tray
Do
not
touch
the
inner
pins
of
the
jacks
on
the
rear
panel.
Electrostatic
discharge
may
cause
permanent
damage
to
the
unit.
AUX
IN
MONITOR
OUT
8
66
6
6
6
FM
Antenna
Connector
AM
Loop
Antenna
Connectors
SPEAKER
Connectors
POWER
CORD
MONITOR
OUT
Connector
PLAY
Begins
Playback.
Press
and
hold
down
this
button
for
about
3
seconds,
then
press
repeatedly
to
select
other
functions.
MONO/STEREO/
PAUSE/STEP
STOP
AUXILIARY
INPUT
Connectors
8
OPEN/CLOSE
(Z)
Opens
and
closes
the
disc
tray.
AUX
Selects
input
source.
TV
To
control
the
TV.
(LG
TV
only)
SLEEP
Set
the
System
to
turn
off
automatically.
at
a
specified
time.
MUTE
Mute
the
speakers.
SUBTITLE
Selects
a
subtitle
language
(DVD).
RETURN
Removes
the
setup
menu.
MARKER
Marks
a
point
during
playback.
SEARCH
Displays
MARKER
SEARCH
menu.
DISPLAY
Accesses
On-Screen
display.
INPUT
Selects
the
TV's
source.
b/B/v/V
(left/right/up/down)
Selects
an
option
in
the
menu.
ENTER
Acknowledges
menu
selection.
PRESET/CH(+/-)
(v/V):
Select
programme
of
TV
or
Radio.
TUN(-/+)
(b/B):
To
tune
in
the desired
radio
station.
TITLE
Displays
the
disc's
Title
menu,
if
available.
VOLUME
(+/-)
To
adjust
speaker
volume and
TV
volume.
PLAY
(B)
Starts
playback.
PAUSE/STEP
(X)
Pause
playback
STOP
(x)
Stops
playback.
ZOOM
Enlarges
DVD
video
image.
DIMMER
Press
to
change
brightness
of
the
display
window
on
the
front
panel
during
in
power-on
status.
Remote
Control
Overview
SLEEP
DVD
MUTE
SUBTITLE
SCAN
SKIP
MRAKER
-
SEARCH
SOUND
PRESET/ CH
AUDIO
..
+
-
POWER
DVD
Select
the
output
source
(CD/DVD)
or
accesses
BAND
Select
the
System's
tuner
(FM
and
AM
bands)
0-9
numerical
buttons
Select
a
service,
programme
number
directly
or
select
numbered
options
in
a
menu.
XTS
pro
To
enjoy
more
natural
and
realistic
sound.
XTS
To
enjoy
great
sound
effect.
AUDIO
Selects
an
audio
language
(DVD)
or
an
audio
channel
(CD).
SOUND
MODE
Selects
sound mode.
SETUP
Accesses
or
removes
setup
menu
.
MENU
Accesses
menu
on
a
DVD
disc.
SCAN-/+(bb/BB)
Search
backward
or
forward.
SLOW-/+(t/T)
Reverse/
Forward
slow
playback.
REVERSE
SKIP(.)
Search
backward*/go
to
beginning
of
current
chapter
or
track
or
go
to
previous
chapter
or
track.
FORWARD
SKIP(>)
Search
forward*/go
to
next
chapter
or
track.
PROG.
Accesses
or
removes
Program
menu.
MEMO.
Enter
a
radio
stations
frequency
into
the
tuner.
CLEAR
Removes
a
track
number
on
the
program
menu
or
a
mark
on
the
MARKER
SEARCH
menu.
REPEAT
Repeat
chapter,
track,
title,
all.
REPEAT
A-B
Repeats
sequence.
9
Preparation
Remote
Control
Operation
Range
Point
the
Remote
Control
at
the
remote
sensor
and
press
the
buttons.
Distance:
About
23
ft
(7
m)
from
the
front
of
the
remote
sen-
sor
Angle:
About
30°
in
each
direction
in
front
of
the
remote
sensor
Remote
control
battery
installation
Remove
the
battery
cover
on
the
rear
of
the
Remote
Control,
and
insert
two
R03
(size
AAA)
batteries
with
and
aligned
correctly.
Caution
Do
not
mix
old
and
new
batteries.
Never
mix
different
types
of
batteries
(standard,
alkaline,
etc.).
Connections
Make
one
of
the
following
connections,
depending
on
the
capabilities
of
your
existing
equipment.
ip
Please
refer
to
the
manuals
of
your
TV,
VCR,
Stereo
System
or
other
devices
as
necessary
to
make
the
best
connections.
Caution
Make
sure
the
DVD/CD
Receiver
is
connected
directly
to
the
TV.
Select
the
correct
AV
input
on
your
TV.
Do
not
connect
your
DVD/CD
Receiver
to
TV
via
your
VCR.
The
DVD
could
be
distorted
by
the
copy
protection
system.
Video
connection
Connect
the
MONITOR
OUT
jack
from
the
DVD/CD
Receiver
to
the
VIDEO
IN
jack
on
the
TV
using
the
video
cable
supplied
(V).
TV
Connections
L
R
AUDIO
INPUT
L
VIDEO
INPUT
Rear
of
TV
Rear
of
DVD/CD
receiver
V
AUX
IN
MO
OR
O
External
Equipment
Connections
Connection
Connect
the
AUX
IN
(L/R)
jacks
on
the
DVD/CD
receiver
to
the
AUDIO
OUT
(L/R)
jacks
on
the
VCR,
LD
player,
etc
using
the
audio
cables.
Tip:
Press
AUX
on
the
Remote
Control
to
select
input
to
these
jacks.
AV
1
appears
on
the
Display
Window.
Rear
of
VCR
(or
LD
player,
etc)
L
R
AUDIO
OUTPUT
VIDEO
OUTPUT
AUX
IN
MONITOR
OUT
86 6
6
6 6
10
Connections
(Continued)
AUX
IN
MONITOR
OUT
8
66
6
6
6
FM
Wire
antenna
(supplied)
AM
Loop
antenna
(supplied)
Antenna
Connections
Connect
the
supplied
FM/AM
antenna
for
listening
to
the
radio.
Connect
the
AM
Loop
antenna
to
the
AM
antenna
connector.
Connect
the
FM
Wire
antenna
to
the
FM
antenna
connector.
otes
To
prevent
noise
pickup,
keep
the
AM
Loop
antenna
away
from
the
DVD/CD
Receiver
and
other
components.
Be
sure
to
fully
extend
the
FM
wire
antenna.
After
connecting
the
FM
Wire
antenna,
keep
it
as
horizontal
as
possible.
AUX
IN
MONITOR
OUT
8
66
666
Front
speaker
(Right)
Front
speaker
(Left)
Center
speaker
Rear
speaker
(Right
surround)
Subwoofer
Rear
speaker
(Left
surround)
Speaker
System
Connection
Connect
the
speakers
using
the
supplied
speaker
cords.
To
obtain
the best
possible
surround
sound,
adjust
the
speaker
parameters
(volume,
distance,
etc.).
otes
Be
sure
to
match
the
speaker
cable
to
the
appropriate
terminal
on
the
components:
+
to
+
and
--
to
--.
If
the
cables
are
reversed,
the
sound
will
be
distorted
and
will
lack
bass.
If
you
use
front
speakers
with
low
maximum
input
rating,
adjust
the
volume
carefully
to
avoid
excessive
output
on
the
speakers.
Preparation
11
Connections
(Continued)
Center
Speaker
Front
Speaker
(Left)
Speaker
Positioning
Example
Rear
Speaker
(Left)
Rear
Speaker
(Right)
Front
Speaker
(Right)
Subwoofer
Speaker
Positioning
In
the
case
of
normal
position
use
the
6
speakers
(2
front
speakers,
center
speaker,
2
rear
speakers
and
sub-
woofer).
If
you
want
to
play
the
excellent
bass
sound,
DTS
digital
surround
or
Dolby
Digital
surround,
you
should
connect
a
subwoofer.
?
Front
speakers
According
to
your
listening
position
set
up
the
speakers
for
equal
distance.
And
by
hearing
position
set
up
the
interval
between
speakers
to
45
degree.
?
Centre
speaker
The
center
speakers
and
front
speakers
are
ideally
the
same
height.
But
normally
place
it
above
or
below
the
television.
?
Rear
speakers
Place
left
and
right
behind
the
listening
area.
These
speakers
recreate
sound
motion
and
atmosphere
required
for
surround
sound
playback.
For
best
results,
do
not
install
the
rear
speakers
too
far
behind
the
listening
position
and
install
them
at
or
above
the
level
of
the
listener's
ears.
It
is
also
effective
to
direct
the
rear
speakers
towards
a
wall
or
ceiling
to
further
disperse
the
sound.
In
the
case
of
a
smaller
room
size,
if
the
audience
is
near
to
the
rear
wall
set
the
rear
speakers
opposite
each
other,
and
set
the
rear
speakers
above
60
-
90
cm
than
the
listener
's
ears.
?
Subwoofer
This
can
be
placed
in
any
front
position.
12
Mini
Glossary
for
Audio
Stream
&
Surround
mode
Allows
you
to
enjoy
5.1(or
6)
discrete
channels
of
high
quality
digital
audio
from
DTS
program
sources
such
as
discs,
DVD
and
compact
discs,
etc.bearing
the
trademark.
DTS
Digital
Surround
delivers
up
to
6
channels
of
transparent
audio(which
means
identical
to
the
original
masters)
and
results
in
excep-
tional
clarity
throughout
a
true
360
degree
sound
field.
The
term
DTS
is
a
trademark
of
DTS
Technology,
LLC.
Manufactured
under
license
from
DTS
Technology,
LLC.
The
Dolby
Digital
surround
format
lets
you
enjoy
up
to
5.1
channels
of
digital
surround
sound
from
a
Dolby
Digital
pro-
gram
source.
If
you
play
DVDs
with
"
"
mark,
you
can
enjoy
even
better
sound
quality,
greater
spatial
accuracy,
and
improved
dynamic
range.
(II)
Dolby
Pro
Logic
II
creates
five
full-bandwidth
output
channels
from
two-channel
sources.
This
is
done
using
an
advanced,
high-purity
matrix
surround
decoder
that
extracts
the
spatial
properties
of
the
original
recording
without
adding
any
new
sounds
or
tonal
colorations.
MOVIE
mode:
The
Movie
mode
is
for
use
with
stereo
television
shows
and
all
programs
encoded
in
Dolby
Surround.
The
result
is
enhanced
soundfield
directionality
that
approaches
the
quality
of
discrete
5.1-channel
sound.
MUSIC
mode:
The
Music
mode
is
for
use
with
any
stereo
music
recordings.
MATRIX
mode:
The
Matrix
mode
is
the
same
as
the
Music
mode
except
that
the
directional
enhancement
logic
is
turned
off.
It
may
be
used
to
enhance
mono
signals
by
making
them
seem
"larger."
The
Matrix
mode
may
also
find
use
in
auto
systems,
where
the
fluc-
tuations
from
poor
FM
stereo
reception
can
otherwise
cause
dis-
turbing
surround
signals
from
a
logic
decoder.
The
ultimate
"cure"
for
poor
FM
stereo
reception
may
be
simply
to
force
the
audio
to
mono.
BYPASS
Software
with
multichannel
surround
audio
signals
is
played
according
to
the
way
it
was
recorded.
Sound
Mode
You
can
enjoy
surround
sound
simply
by
selecting
one
of
the
pre-programmed
sound
fields
according
to
the
program
you
want
to
listen
to.
When
DVD
is
inserted
You
can
change
the
Digital
Audio
Output
mode
by
pressing
the
AUDIO
button
on
the
Remote
Control dur-
ing
playback.
Although
the
DVD
contents
differ
from
disc
to
disc,
the
following
explains
the
basic
operation
when
this
feature
is
used.
a)
After
you
select
2
channel
(For
example
or
)
by
pressing
AUDIO
button,
press
SOUND
button
repeatedly.
b)
After
you
select
5.1
channel
(For
example
or
)
by
pressing
AUDIO
button,
press
SOUND
button.
-"
"
indicator
will
be
displayed
on
the
TV
screen.
-
"BYPASS"
indicator
will
be
only
displayed
on
the
display
window.
ote
After
you
select
the
"Bypass"
of
sound
mode
by
pressing
SOUND
button,
press
AUDIO
button.
The
Left,
Right
and
Stereo
of
audio
channel
will
be
displayed
on
the
TV
screen.
When
CD
is
inserted
Each
time
you
press
SOUND
button,
the
sound
mode
of
Audio
CD
is
changed
on
the
display
window
in
the
following
order.
BYPASS
→
STUDIO
→
CLUB
→
HALL
→
THEATER
1
→
CHURCH
→
PL
ll
MOVIE
→
PL
ll
MUSIC
→
PL
ll
MTRX
→
BYPASS...
For
your
reference
?
You
can
identify
the
encoding
format
of
program
software
by
looking
at
its
packaging.
-
Dolby
Digital
discs
are
labeled
with
the
logo.
-
Dolby
Surround
encoded
programs
are
labeled
with
the
logo.
-
DTS
Digital
Surround
discs
are
marked
with
DTS.
otes
When
you
play
sound
tracks
with
96kHz
sampling
frequen-
cy,
the
output
signals
will
be
converted
to
48kHz
(sampling
frequency).
4
ENG
DTS
5.1
CH
1
ENG
D
5.1
CH
Matrix
Music
Movie
Bypass
3
ENG
D
2CH
2
ENG
D
2CH
CD
DVD
Before
Operation
Preparation
13
Before
Operation
(Continued)
On-Screen
Display
You
can
display
the
general
playback
status
on
the
TV
screen.
Some
items
can
be
changed
using
the
menu.
To
use
the
on-screen
display:
1
Press
DISPLAY
during
playback.
2Pressv/Vtoselectanitem.
The
selected
item
is
highlighted.
3
Press
b
/
B
to
change
the
setting.
You
can
also
use
the
number
buttons
if
appropriate
(e.g.
inputting
the
title
number).
For
some
functions,
press
ENTER
to
execute
the
setting.
PLAYBACK
STATUS/RESTRICTIONS
Repeat
title
Repeat
sequence
Resume
play
from
this
point
Action
prohibited
or
not
available
otes
Some
discs
may
not
provide
all
of
the
features
shown.
If
no
button
is
pressed
for
10
seconds,
the
on-
screen
display
disappears.
A-B
Title
Items
Title
Number
Chapter
Number
Time
search
Audio
language
and
Digital
Audio
Output
mode
Subtitle
language
Angle
Sound
Selection
Method
b
/
B,
Numbers
ENTER
b
/
B,
Numbers
ENTER
Numbers,
ENTER
b/Bor
AUDIO
b/Bor
SUBTITLE
b/B
b/B
1/3
1/12
0:20:09
ABC
1
ENG
1/3
Bypass
Example:
On-Screen
Display
during
playing
DVD
Video
14
Before
Operation
(Continued)
Initial
Settings
By
using
the
Setup
menu,
you
can
make
various
adjust-
ments
to
items
such
as
and
sound.
You
can
also
set
a
language
for
the
subtitles
and
the
Setup
menu,
among
other
things.
For
details
on
each
Setup
menu
item,
see
pages
14
to
17.
To
display
and
exit
the
Menu:
Press
SET
UP
to
display
the
menu.
A
second
press
of
SET
UP
will
take
you
back
to
initial
screen.
To
go
to
the
next
level:
Press
B
on
the
Remote
Control.
To
go
back
to
the
previous
level:
Press
b
on
the
Remote
Control.
General
Operation
1
Press
SET
UP.
The
setup
menu
appears.
2
Use
v
/
V
to
select
the
desired
option
then
press
B
to
move
to
the
second
level.
The
screen
will
be
shown
the
current
setting
for
the
selected
item,
as
well
as
alternate
setting(s).
3
Use
v
/
V
to
select
the
second
desired
option
then
press
B
to
move
to
the
third
level.
4
Use
v
/
V
to
select
the
desired
setting
then
press
ENTER
to
confirm
your
selection.
Some
items
require
additional
steps.
5
Press
SET
UP
or
PLAY
to
exit
the
setup
menu.
LANGUAGE
OSD
Select
a
language
for
the
Setup
menu
and
on-screen
display.
Disc
Audio
/
Subtitle
/
Menu
Select
the
language
you
prefer
for
the
audio
track
(disc
audio),
subtitles,
and
the
disc
menu.
Original:
Refers
to
the
original
language
in
which
the
disc
was
recorded.
Other:
To
select
another
language,
press
number
buttons
to
enter
the
corresponding
4-digit
number
according
to
the
language
code
list
on
page
28.
If
you
enter
the
wrong
language
code,
press
CLEAR
on
the
Remote
Control.
DISPLAY
TV
Aspect
4:3:
Select
when
a
standard
4:3
TV
is
connected.
16:9:
Select
when
a
16:9
wide
TV
is
connected.
Display
Mode
Display
Mode
setting
works
only
when
the
TV
Aspect
mode
is
set
to
"4:3".
Letterbox:
Displays
a
wide
with
bands
on
the
upper
and
lower
portions
of
the
screen.
Panscan:
Automatically
displays
the
wide
on
the
entire
screen
and
cuts
off
the
portions
that
do
not
fit.
DVD
DVD
DVD
OSD
Original
English
Off
Original
Disc
Audio
Disc
Subtitle
Disc
Menu
Move
Select
LANGUAGE
DISPLAY
TV
Aspect
Widescreen
16:9
Display
Mode
Move
Select
Preparation
15
Before
Operation
(Continued)
AUDIO
Each
DVD
disc
has
a
variety
of
audio
output
options.
Set
the
DVD/CD
Receiver's
AUDIO
options
according
to
the
type
of
audio
system
you
use.
5.1
Speaker
Setup
Select
speaker
settings,
including
volume
balance
and
distance,
or
test
the
speaker
settings.
Speaker
settings
are
only
active
on
the
Analog
Multi-
Channel
Output.
Speaker
Select
a
speaker
that
you
want
to
adjust.
(Front
speak-
ers
(Left),
Front
speakers
(Right),
Center
Speaker,
SubWoofer,
Rear
speakers
(Left),
or
Rear
speakers
(Right))
ote
Certain
speaker
settings
are
prohibited
by
the
Dolby
Digital
licensing
agreement.
Size
Since
the
speaker
settings
are
fixed,
you
cannot
change
the
settings.
Volume
Press
b
/
B
to
adjust
the
output
level
of
the
selected
speaker.
(-5dB
~
+5dB)
Distance
If
you
connected
speakers
to
your
DVD/CD
Receiver,
setting
the
Distance
lets
the
speakers
know
how
far
the
sound
has
to
travel
to
reach
your
set
listening
point.
This
allows
the
sound
from
each
speaker
to
reach
the
listener
at
the
same
time.
Press
b
/
B
to
adjust
the
Distance
of
the
selected
speaker.
ote
Yo
u
c
a
n
adjust
the
Distance
of
Center
speaker
and
Rear
speakers
(Left
&
Right)
only.
Test
Press
b
/
B
to
test
the
signals
of
each
speaker.
Adjust
the
volume
to
match
the
volume
of
test
signals
memorized
in
the
system.
Front
Left
(L)
→
Center
→
Front
Right
(R)
→
Rear
Right
(R)
→
Rear
Left
(L)
→
SubWoofer
Dynamic
Range
Control
(DRC)
With
the
DVD
format,
you
can
hear
a
program's
sound-
track
in
the
most
accurate
and
realistic
presentation
possible,
thanks
to
digital
audio
technology.
However,
you
may
wish
to
compress
the
dynamic
range
of
the
audio
output
(the
difference
between
the
loudest
sounds
and
the
quietest
ones).
Then,
you
may
listen
to
a
movie
at
a
lower
volume
without
losing
dialog
intelligibility.
Set
DRC
to
On
for
this
effect.
otes
The
DRC
function
works
only
during
playback
of
Dolby
Digital
recorded
discs.
The
level
of
Dynamic
Range
Compression
may
differ
depending
on
the
DVD
disc.
Vocal
Set
Vocal
to
On
only
when
a
multi-channel
Karaoke
DVD
is
playing.
The
karaoke
channels
on
the
disc
will
mix
into
a
normal
stereo
sound.
DVD
DivX
DVD
DVD
AUDIO
Speaker
Volume
Distance
Test
Move
Return
Select
Size
Front L
Small
0
dB
m
2
Off
Enter
Select
On
5.1
Speaker
Setup
DRC
On
Vocal
Move
Select
AUDIO
16
Before
Operation
(Continued)
LOCK
(Parental
Control)
Rating
Some
movies
contain
scenes
that
may
not
be
suitable
for
children
to
view.
Many
of
these
discs
contain
parental
control
information
that
applies
to
the
complete
disc
or
to
certain
scenes
on
the
disc.
Movies
and
scenes
are
rated
from
1
to
8,
depending
on
the
country.
Some
discs
offer
more
suitable
scenes
as
an
alternative.
The
parental
control
feature
allows
you
to
block
access
to
scenes
below
the
rating
you
input,
thereby
preventing
your
children
from
being
able
to
view
material
you
believe
is
unsuitable.
1
Select
"Rating"
on
the
LOCK
menu
then
press
B.
2
To
access
the
Rating,
Password
and
Country
Code
features,
you
must
input
the
4-digit
security
code
you
created.
If
you
have
not
yet
entered
a
security
code
you
are
prompted
to
do
so.
Input
a
4-digit
code
and
press
ENTER.
Enter
it
again
and
press
ENTER
to
verify.
If
you
make
a
mistake
before
pressing
ENTER,
press
CLEAR.
3Selectaratingfrom1to8usingthev/V
buttons.
Rating
1-8:
Rating
one
(1)
has
the
most
restrictions
and
rating
eight
(8)
is
the
least
restrictive.
Unlock
If
you
select
unlock,
parental
control
is
not
active
and
the
disc
plays
in
full.
ote
If
you
set
a
rating
for
the
DVD/CD
Receiver,
all
disc
scenes
with
the
same
rating
or
lower
are
played.
Higher
rated
scenes
are
not
played
unless
an
alternate
scene
is
available
on
the
disc.
The
alternative
must
have
the
same
rating
or
a
lower
one.
If
no
suitable
alternative
is
found,
playback
stops.
You
must
enter
the
4-digit
pass-
word
or
change
the
rating
level
in
order
to
play
the
disc.
4
Press
ENTER
to
confirm
your
rating
selection,
then
press
SET
UP
to
exit
the
menu.
Password
(Security
Code)
You
can
enter
or
change
password.
1
Select
Password
on
the
LOCK
menu
then
press
B.
2
Follow
step
2
as
shown
left
(Rating).
"Change"
or
"New"
is
highlighted.
3
Enter
the
new
4-digit
code,
then
press
ENTER.
Input
it
again
to
verify.
4
Press
SET
UP
to
exit
the
menu.
If
you
forget
your
Security
Code
If
you
forget
your
security
code
you
can
clear
it
using
the
following
steps:
1
Input
the
6-digit
number
"210499"
on
the
setup
menu
and
the
security
code
is
cleared.
2
Enter
a
new
code
as
described
above.
ote
When
"
"
appears
on
the
TV
screen,
press
STOP
(x)
and
then
press
SET
UP
to
move
to
the
setup
menu.
Country
Code
Enter
the
code
of
the
country/area
whose
standards
were
used
to
rate
the
DVD
video
disc,
based
on
the
list
in
the
reference
chapter.
1
Select
"Country
Code"
on
the
LOCK
menu
then
press
B.
2
Follow
step
2
as
shown
left
(Rating).
3
Select
the
first
character
using
v
/
V
buttons.
4
Shift
the
cursor
using
B
button
and
select
the
second
character
using
v
/
V
buttons.
5
Press
ENTER
to
confirm
your
country
code
selection.
DVD
INPUT
PASSWD
DVD
LOCK
Rating
****
Unlock
Password
Country
Code
Move
Select
Preparation
17
Before
Operation
(Continued)
OTHERS
DivX(R)
Registration
You
can
show
the
DivX
DRM
(Digital
Right
Management)
Registration
code
for
your
unit
only.
The
Registration
code
is
used
for
VOD
(Video-On-
Demand)
service
agent.
You
can
purchase
or
rental
an
encrypt
movie
file.
ote
If
you
rent
the
DivX
VOD
file,
it
has
several
options
of
viewing
limits
as
show
below.
?
Display
the
number
which
you
can
watch
the
file.
?
The
rental
has
been
expired.
?
Display
the
authorization
error.
DivX
Move
OTHERS
Select
Select
DivX(R)
Registration
Your
registration
code
is
:
XXXXXXXX
Please
use
this
code
to
register
this
player
with
the
DivX(R)
Video
On
Demand
service.
This
will
allow
you
to
rent
and
purchase
videos
using
the
DivX(R)
Video
On
Demand
format.
To
learn
more
go
to
www.divx.com/vod
This
rental
video
has
7
views
left.
A
view
?
ends
when
you
stop
playback,
play
a
different
video,
or
turn
off
your
player.
Do
you
want
to
use one
of
your
7
views
now
Yes
No
This
rental
is
expired.
This video
player
is
not
authorized
to
play
this
video.
18
Playing
a
DVD
Playback
Setup
Turn
on
the
TV
and
select
the
video
input
source
con-
nected
to
the
DVD/CD
Receiver.
Audio
system:
Turn
on
the
audio
system
and
select
the
input
source
connected
to
the
DVD/CD
Receiver.
1
Press
OPEN/CLOSE
(Z)
to
open
the
disc
tray.
2
Load
your
chosen
disc
in
the
tray,
with
the
label
facing
up.
When
a
double-sided
DVD
is
inserted,
make
sure
the
side
you
want
to
play
is
facing
down.
3
Press
OPEN/CLOSE
(Z)
to
close
the
tray.
READING
appears
on
the
TV
screen,
and
playback
starts
automatically.
If
playback
does
not
start,
press
PLAY.
In
some
cases,
the
disc
menu
might
appear
instead.
If
a
menu
screen
is
displayed
The
menu
screen
may
be
displayed
first
after
loading
a
DVD
which
contains
a
menu.
Use
the
bBvVbuttons
to
select
the
title/chapter
you
want
to
view,
then
press
ENTER
to
start.
Press
TITLE
or
DVD
MENU
to
return
to
the
menu
screen.
otes
If
Parental
Control
is
set
and
the
disc
is
not
within
the
Rating
settings
(not
authorized),
the
4-digit
code
must
be
entered
and/or
the
disc
must
be
authorized
(see
"Parental
Control",
on
page
16).
DVDs
may
have
a
region
code.
Your
receiver
will
not
play
discs
that
have
a
region
code
different
from
your
receiver.
The
region
code
for
this
receiver
is
1
(one).
General
Features
ote
Unless
stated
otherwise,
all
operations
described
use
the
Remote
Control.
Some
features
may
also
be
available
on
the
Setup
menu.
Moving
to
another
TITLE
When
a
disc
has
more
than
one
title,
you
can
move
to
another
title
as
follows:
Press
DISP.,
then
press
the
appropriate
numbered
button
(0-9)
to
select
a
title
number.
Moving
to
another
CHAPTER/TRACK
When
a
title
on
a
disc
has
more
than
one
chapter
or
a
disc
has
more
than
one
track,
you
can
move
to
another
chapter/track
as
follows:
Press
.
or
>
briefly
during
playback
to
select
the
next
chapter/track
or
to
return
to
the
beginning
of
the
current
chapter/track.
Press
.
twice
briefly
to
step
back
to
the
previous
chapter/track.
To
go
directly
to
any
chapter
during
DVD
playback,
press
DISP.
Then,
press
3/4
to
select
the
chapter/track
icon.
Then,
enter
the
chapter/track
number
using
the
numbered
buttons
(0-9).
ote
For
two-digit
numbers,
press
the
numbered
buttons
(0-9)
in
rapid
succession.
Slow
Motion
1
Press
SLOW
-/+
during
pause.
The
player
will
enter
SLOW
mode.
2
Use
the
SLOW
-/+
to
select
the
required
speed:
t
1/16,
t
1/8,
t
1/4
or
t
1/2
(backward),
or
T
1/16,
T
1/8,
T
1/4
or
T
1/2
(forward).
3
To
exit
slow
motion
mode,
press
PLAY.
DVD
DVD
DVD
DVD
DVD
DVD
Operation
Operation
19
DVD
Operation
(Continued)
General
Features
(continued)
Still
and
Frame-by-frame
playback
1
Press
PAUSE/STEP
during
playback.
The
DVD/CD
Receiver
will
now
go
into
PAUSE
mode.
2
You
can
advance
the
frame-by-frame
by
press-
ing
PAUSE/STEP
repeatedly
on
the
Remote
Control.
Search
1
Press
m
or
M
during
playback.
The
DVD/CD
Receiver
will
now
go
into
SEARCH
mode.
2
Press
m
or
M
repeatedly
to
select
the
required
speed:
mX2,
mX4,
mX8,
mX16,
mX100
(backward)
or
MX2,
MX4,
MX8,
MX16,
MX100
(forward).
With
a
DivX,
the
Search
speed
changes:
mX2,
mX4,
mX8,
mX16
(backward)
or
MX2,
MX4,
MX8,
MX16
(forward).
3
To
exit
SEARCH
mode,
press
PLAY.
Repeat
DVD
Video
Discs
-
Repeat
Chapter/Title/Off
1
To
repeat
the
currently
playing
chapter,
press
REPEAT.
The
Repeat
Chapter
icon
appears
on
the
TV
screen.
2
To
repeat
the
title
currently
playing,
press
REPEAT
a
second
time.
The
Repeat
Title
icon
appears
on
the
TV
screen.
3
To
exit
Repeat
mode,
press
REPEAT
a
third
time.
The
Repeat
Off
icon
appears
on
the
TV
screen.
Repeat
A-B
To
repeat
a
sequence
in
a
title:
Press
A-B
at
your
chosen
starting
point.
A-
appears
briefly
on
the
TV
screen.
Press
A-B
again
at
your
chosen end
point.
A-B
appears
briefly
on
the
TV
screen,
and
the
repeat
sequence
begins.
To
cancel
the
sequence,
press
A-B
or
CLEAR.
Time
Search
The
Time
Search
function
allows
you
to
start
playing
at
any
chosen
time
on
the
disc.
Press
DISP.
during
playback.
The
on-screen
dis-
play
appears
on
the
screen.
The
Time
Search
box
shows
the
elapsed
playing
time
of
the
current
disc.
Within
10
seconds,
press
3/4
to
select
the
Time
Search
icon
in
the
on-screen
display.
The
"-:--:--"
appears
in
the
Time
Search
box.
Within
10
seconds,
use
the
number
buttons
to
enter
the
required
start
time.
Enter
hours,
min-
utes,
and
seconds
from
left
to
right
in
the
box.
If
you
enter
the
wrong
numbers,
press
CLEAR
to
remove
the
numbers
you
entered.
Then
enter
the
correct
num-
bers.
Within
10
seconds,
press
ENTER
to
confirm
the
start
time.
Playback
starts
from
the
selected
time
on
the
disc.
If
you
enter
an
invalid
time,
playback
will
continue
from
the
current
point.
DVD
DVD
DivX
DVD
DivX
DVD
DivX
DVD
20
DVD
Operation
(Continued)
General
Features
(continued)
Marker
Search
You
can
start
playback
from
a
memorized
point.
Up
to
nine
points
can
be memorized.
To
enter
a
mark,
follow
these
steps.
1
During
disc
playback,
press
MARKER
when
playback
reaches
the
spot
that
you
want
to
memorize.
The
Marker
icon
will
appear
on
the
TV
screen
briefly.
2
Repeat
step
1
to
enter
up
to
nine
Marker
points
on
a
disc.
To
Recall
a
Marked
Scene
1
During
disc
playback,
press
SEARCH.
The
MARKER
SEARCH
menu
will
appear
on
the
screen.
2
Within
10
seconds,
press
1/2
to
select
a
Marker
number
that
you
want
to
recall.
3
Press
ENTER.
Playback
will
start
from
the
Marked
scene.
4
To
remove
the
MARKER
SEARCH
menu,
press
SEARCH.
To
clear
a
Marked
Scene
1
During
disc
playback,
press
SEARCH.
The
MARKER
SEARCH
menu
will
appear
on
the
screen.
2
Press
1/2
to
select
the
Marker
number
that
you
want
to
erase.
3
Press
CLEAR.
The
Marker
number
will
be
erased
from
the
list.
4
Repeat
steps
2
and
3
to
erase
additional
Marker
numbers.
5
To
remove
the
MARKER
SEARCH
menu,
press
SEARCH.
Zoom
The
Zoom
function
allows
you
to
enlarge
the
video
and
to
move
through
the
enlarged
image.
1
Press
ZOOM
during
playback
or
still
playback
to
activate
the
Zoom
function.
If
you
press
ZOOM
repeatedly,
the
magnification
level
increases
up
to
four
steps.
400%
size
→
800%
→
1600%
size
2
Use
the
1 2
3
4
buttons
to
move
through
the
zoomed
picture.
ote
The
zoom
function
may
not
work
for
some
DVDs.
Special
DVD
Features
Checking
the
contents
of
DVD
discs:
Menus
DVDs
may
contain
menus
that
allow
you
to
access
special
features.
To
use
the
disc
menu,
press
MENU.
Then,
press
the
appropriate
number
button
to
select
an
option.
Or,
use
the
1/2/3/4
buttons
to
highlight
your
selection,
then
press
ENTER.
Title
Menu
1
Press
TITLE.
If
the
current
title
has
a
menu,
the
menu
will
appear
on
the
screen.
Otherwise,
the
disc
menu
may
appear.
2
The
menu
can
list
camera
angles,
spoken
lan-
guage
and
subtitle
options,
and
chapters
for
the
title.
Disc
Menu
Press
MENU.
The
disc
menu
is
displayed.
Changing
the
Audio
Language
Press
AUDIO
repeatedly
during
playback
to
hear
a
different
audio
language
or
audio
track.
Subtitles
Press
S-TITLE
repeatedly
during
playback
to
see
the
different
subtitle
languages.
otes
The
subtitle
file
of
the
DivX
file
is
displayed
only
smi,
srt
and
sub.
If
there
is
no
information
or
there
is
a
code
that
can
not
read
in
the
DivX
file,
"1/1"
etc
are
displayed.
DivX
DVD
DivX
DVD
DVD
DVD
DVD
DVD
DVD
Operation
21
Audio
CD
or
MP3/WMA
Disc
Operation
Playing
an
Audio
CD
and
MP3/WMA
Disc
The
DVD/CD
Receiver
can
play
MP3/WMA
formatted
recordings
on
CD-ROM,
CD-R,
or
CD-RW
discs.
Audio
CD
Once
you
insert
an
audio
CD
a
menu
appears
on
the
TV
screen.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER
and
playback
starts.
MP3
/
WMA
1.
Press
v
/
V
to
select
a
folder,
and
press
ENTER
to
see
the
folder
contents.
2.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER.
Playback
starts.
otes
If
you
are
in
a
file
list
on
the
MP3/WMA
menu
and
want
to
return
to
the
Folder
list,
use
the
v
/
V
to
highlight
and
press
ENTER.
Press
MENU
to
move
to
the
next
page.
On
a
CD
with
MP3/WMA
file
and
JPEG
file,
you
can
switch
MP3/WMA
and
JPEG
menu.
Press
TITLE
and
MP3/WMA
or
JPEG
word
on
top
of
the
menu
is
high-
lighted.
Then,
use
b
/
B
to
select
MP3/WMA
or
JPEG
then
press
ENTER.
Pause
1
Press
PAUSE/STEP
during
playback.
2
To
return
to
playback,
press
PLAY
or
press
PAUSE/STEP
again.
Moving
to
another
Track
Press
.
or
>
briefly
during
playback
to
go
to
the
next
track
or
to
return
to
the
beginning
of
the
current
track.
Press
.
twice
briefly
to
step
back
to
the
previous
track.
In
case
of
audio
CD,
to
go
directly
to
any
track,
enter
the
track
number
using
the
numbered
buttons
(0-9)
during
playback.
Repeat
Track/All/Off
You
can
play
a
title/chapter/all/track
on
a
disc.
1
Press
REPEAT
when
playing
a
disc.
The
repeat
icon
appears.
2
Press
REPEAT
to
select
a
desired
repeat
mode.
?
TRACK:
repeats
the
current
track
?
ALL:
repeats
all
the
tracks
on
a
disc.
?
Off(No
display):
does
not
play
repeatedly.
Search
1
Press
m
or
Mduring
playback.
The
receiver
will
now
go
into
SEARCH
mode.
2
Press
m
or
M
repeatedly
to
select
the
required
speed:
mX2, mX4,
mX8
(backward)
or
MX2,
MX4,
MX8
(forward).
3
To
exit
SEARCH
mode,
press
PLAY.
WMA
MP3
CD
WMA
MP3
CD
WMA
MP3
CD
WMA
MP3
CD
WMA
MP3
CD
MP3
/
WMA
disc
compatibility
with
this
player
is
limited
as
follows:
?
Sampling
frequency:
within
32
-
48
kHz
(MP3),
within
24
-
48kHz
(WMA)
?
Bit
rate:
within
8
-
320kbps
(MP3),
32-
192kbps
(WMA)
?
The
DVD/CD
Receiver
cannot
read
an
MP3/WMA
file
that
has
a
file
extension
other
than
".mp3"
/
".wma".
?
CD-R
physical
format
should
be
ISO
9660
?
If
you
record
MP3
/
WMA
files
using
software
that
cannot
create
a
file
system
(eg.
Direct-CD)
it
is
impossible
to
playback
MP3
/
WMA
files.
We
rec-
ommend
that
you
use
Easy-CD
Creator,
which
cre-
ates
an
ISO
9660
file
system.
?
File
names
should
have
a
maximum
of
8
letters
and
must
incorporate
an
.mp3
or
.wma
extension.
?
They
should
not
contain
special
letters
such
as
/
?
*:"<>letc.
?
The
total
number
of
files
on
the
disc
should
be
less
than
999.
This
DVD/CD
Receiver
requires
discs
and
recordings
to
meet
certain
technical
standards
in
order
to
achieve
optimal
playback
quality.
Pre-recorded
DVDs
are
automatically
set
to
these
standards.
There
are
many
different
types
of
recordable
disc
formats
(including
CD-R
containing
MP3
or
WMA
files)
and
these
require
certain
pre-existing
conditions
(see
above)
to
ensure
compatible
playback.
Customers
should
note
that
permission
is
required
in
order
to
download
MP3
/
WMA
files
and music
from
the
Internet.
Our
company
has
no
right
to
grant
such
permission.
Permission
should
always
be
sought
from
the
copyright
owner.
Program
List
Track1
Track2
Track3
Track4
Track5
Track6
Track7
Track8
Track8
Track3
Track12
Track7
Track6
Track9
Track1
Track10
0:00:00
1/12
Audio
CD
Program
List
0:00:00
1/104
MP3
2-Music2
1-Music1
3-Music3
4-Music4
5-Music5
6-Music6
7-Music7
22
JPEG
Disc
Operation
Viewing
a
JPEG
disc
This
unit
can
play
discs
with
JPEG
files.
Before
playing
JPEG
recordings,
read
the
notes
on
JPEG
Recordings
on
right.
Insert
a
disc
and
close
the
tray.
The
JPEG
menu
appears
on
the
TV
screen.
2
Press
v
/
V
to
select
a
folder,
and
press
ENTER.
A
list
of
files
in
the
folder
appears.
If
you
are
in
a
file
list
and
want
to
return
to
the
previous
Folder
list,
use
the
v
/
V
buttons
on
the
remote
to
highlight
and
press
ENTER.
3
If
you
want
to
view
a
particular
file,
press
v
/
V
to
highlight
a
file
and
press
ENTER
or
PLAY.
While
viewing
a
file,
you
can
press
STOP
to
move
to
the
previous
menu
(JPEG
menu).
ips
?
There
are
four
Slide
Speed
options
:
>
(Slow),
>>
(Normal),
>>>
(Fast)
and
II
(off).
Use
vVbBto
highlight
the
Speed.
Then,
use
b
/
B
to
select
the
option
you
want
to
use
then
press
ENTER.
?
If
you
set
Speed
option
to
Off,
Slide
is
not
active.
SLIDE
SHOW
Use
vVbBto
highlight
the
(Slide
Show)
then
press
ENTER.
STILL
1.
Press
PAUSE/STEP
during
slide
show.
The
DVD/CD
Receiver
will
now
go
into
PAUSE
mode.
2.
To
return
to
the
slide
show,
press
PLAY
or
press
PAUSE/STEP
again.
MOVING TO
ANOTHER
FILE
Press
SKIP
(.
or
>)
once
while
viewing
a
to
advance
to
the
next
or
previous
file.
TO
ROTATE
Press
b
/
B
during
showing
a
to
rotate
the
pic-
ture
clockwise
or
counter
clockwise.
JPEG
JPEG
JPEG
JPEG
JPEG
JPEG
disc
compatibility
with
this
player
is
limited
as
follows:
?
Depending
upon
the
size
and
number
of
JPEG
files,
it
could
take
a
long
time
for
the
DVD/CD
Receiver
to
read
the
disc's
contents.
If
you
don't
see
an
on-screen
display
after
several
minutes,
some
of
the
files
may
be
too
large
---
reduce
the
resolution
of
the
JPEG
files
to
less
than
2760
x
2048
pixels
and
burn
another
disc.
?
The
total
number
of
files
and
folders
on
the
disc
should
be
less
than
999.
?Some
discs
may
be
incompatible
due
to
a
different
recording
format
or
the
condition
of
disc.
?
Ensure
that
all
the selected
files
have
the
".jpg"
extensions
when
copying
into
the
CD
layout.
?
If
the
files
have
".jpe"
or
".jpeg"
extensions,
please
rename
them
as
".jpg"
file.
?
File
names
without
".jpg"
extension
will
not
be
able
to
be
read
by
this
DVD/CD
Receiver.
Even
though
the
files
are
shown
as
JPEG
files
in
Windows
Explorer.
Preview
List
JPEG
JPEG
Folder
1
JPEG
Folder
2
JPEG
Folder
3
JPEG
Folder
4
JPEG
Folder
5
JPEG
Folder
6
JPEG
Folder
7
JPEG
Folder
8
Operation
23
Programmed
Playback
WMA
MP3
CD
1
Insert
a
disc.
Audio
CD
and
MP3/WMA
Discs:
Audio
CD
or
MP3/WMA
menu
appears
as
below.
Audio
CD
Menu
MP3/WMA
Menu
2
Select
a
track
on
the
"List",
then
press
PROGRAM
or
select
"
(Add)"
icon
then
press
ENTER
to
place
the
selected
track
on
the
"Program"
list.
Repeat
to
place
additional
tracks
on
the
list.
ote
You
can
add
all
tracks
in
the
disc.
Select
"
(Add
All)"
icon
then
press
ENTER.
3
Select
the
track
you
want
to
start
playing
on
the
"Program"
list.
Press
MENU
to
move
to
the
next
page.
4
Press
PLAY
or
ENTER
to
start.
Playback
begins
in
the
order
in
which
you
programmed
the
tracks.
Playback
stops
after
all
of
the
tracks
on
the
"Program"
list
have
played
once.
5
To
resume
normal
playback
from
programmed
play-
back,
select
a
track
of
AUDIO
CD
(or
MP3/WMA)
list
and
then
press
PLAY.
REPEAT
PROGRAMMED
TRACKS
1.
Press
REPEAT
when
playing
a
disc.
The
repeat
icon
appears.
2.
Press
REPEAT
to
select
a
desired
repeat
mode.
?
TRACK:
repeats
the
current
track
?
ALL:
repeats
all
the
tracks
on
programmed
list.
?
Off(No
display):
does
not
play
repeatedly.
ERASING
A
TRACK
FROM
"PROGRAM"
LIST
1.
Use
vVto
select
the
track
that
you
wish
to
erase
from
the
Program
list.
2.
Press
CLEAR.
Or,
select
"
(Delete)"
icon
then
press
ENTER
to
place
the selected
track
on
the
Program
list.
Repeat
to
erase
additional
tracks
on
the
list.
ERASING
THE
COMPLETE
PROGRAM
LIST
Use
v
/
V
to
select
"
(Del
all)",
then
press
ENTER.
ote
The
programs
are
also
cleared
when
the
disc
is
removed.
The
program
function
enables
you
to
store
your
favorite
tracks
from
any
disc
in
the
receiver
memory.
A
program
can
contain
300
tracks.
Program
List
Tr
ack1
Tr
ack2
Tr
ack3
Tr
ack4
Tr
ack5
Tr
ack6
Tr
ack7
Tr
ack8
Tr
ack8
Tr
ack3
Tr
ack12
Tr
ack7
Tr
ack6
Tr
ack9
Tr
ack1
Tr
ack10
0:00:00
1/12
Audio
CD
Program
List
0:00:00
1/104
MP3
JPEG
Music
Folder
1
Music
Folder
2
Music
Folder
3
Music
Folder
4
Music
Folder
5
Music
Folder
6
Music
Folder
7
Music
Folder
8
24
DivX
Disc
Operation
Using
this
DVD/CD
Receiver
you
can
play
DivX
disc.
1
Insert
a
disc
and
close the
tray.
The
DivX
menu
appears
on
the
TV
screen.
2
Press
v
/
V
to
select
a
folder,
and
press
ENTER.
A
list
of
files
in
the
folder
appears.
If
you
are
in
a
file
list
and
want
to
return
to
the
Folder
list,
use
the
v
/
V
buttons
on
the
remote
to
highlight
and
press
ENTER.
3
If
you
want
to
view
a
particular
file,
press
v
/
V
to
highlight
a
file
and
press
ENTER
or
PLAY.
4
Press
STOP
to
exit.
otes
?
Be
sure
to
select
"SUBTITLE
ON"
mode
before
playback
a
DivX
file
by
pressing
ENTER
every
time.
?
When
the
Subtitle
has
more
than
two
languages
in
the
file,
original
Subtitle
is
only
available.
?
The
Pro
logic
II
Sound
mode
is
not
available
for
DivX
file.
List
0:00:00
DIVX
1/12
Movie
Folder
1
Movie
Folder
2
Movie
Folder
3
Movie
Folder
4
Movie
Folder
5
Movie
Folder
6
Movie
Folder
7
Movie
Folder
8
DivX
disc
compatibility
with
this
player
is
limited
as
follows:
?A
vailable
resolution
size
of
the
DivX
file
is
under
720x576
(W
x
H)
pixel.
?
The
file
name
of
the
DivX
subtitle
is
available
by
20~40
characters
(different
by
language).
?
If
there
is
impossible
code
to
express
in
the
DivX
file,
it
may
be
displayed
as
"
_
"
mark
on
the
dis-
play.
?
If
the
number
of
the
screen
frame
is
over
30
per
1
second,
this
unit
may
not
operate
normally.
?
If
the
video
and
audio
structure
of
recorded
file
is
not
interleaved,
either
video
or
audio
is
out-
putted.
?
If
the
file
is
recorded
with
GMC,
the
unit
sup-
ports
some
of
1-point
of
the record
level.
*
GMC?
GMC
is
the
acronym
for
Global
Motion
Compensation.
It
is
an
encoding
tool
specified
in
MPEG4
standard.
Some
MPEG4
encoders,
like
DivX
or
Xvid,
have
this
option.
There
are
different
levels
of
GMC
encoding,
usually
called
1-point,
2-point,
or
3-point
GMC.
Playable
DivX
file
z
".avi
",
".mpg
",
".mpeg
"
Playable
Codec
format
z
"DIVX3.xx
",
"DIVX4.xx
",
"DIVX5.xx
",
"XVID
",
"MP43
",
"3IVX
",
"MP42
".
Playable
Audio
format
z
"AC3
",
"DTS
",
"PCM
",
"MP3
",
"WMA
".
?
Sampling
frequency:
within
32
-
48
kHz
(MP3),
within
24
-
48kHz
(WMA)
?
Bit
rate:
within
32
-
320kbps
(MP3),
40
-
192kbps
(WMA)
Operation
25
Additional
Information
Last
Condition
Memory
This
DVD/CD
Receiver
memorizes
the
user
settings
for
the
last
disc
that
you
have
viewed.
Settings
remain
in
memory
even
if
you
remove
the
disc
from
the
player
or
switch
off
the
player.
If
you
load
a
disc
that
has
its
set-
tings
memorized,
the
latest
stop
position
is
automatical-
ly
recalled.
otes
Settings
are
stored
in
memory
for
use
any
time.
This
DVD/CD
Receiver
does
not
memorize
settings
of
a
disc
if
you
switch
off
the
DVD/CD
Receiver
before
commencing
to
play
it.
Screen
Saver
The
screen
saver
appears
when
you
leave
the
DVD
player
in
Stop
mode
for
about
five
minutes.
Controlling
the
TV
Your
Remote
Control
is
capable
of
operating
your
DVD/CD
Receiver
as
well
as
limited
functions
of
LG
TV.
Follow
the
instructions
below
to
operate
for
your
LG
TV.
1
Before
using
the
Remote
Control,
press
the
TV
to
select
the
device
to
be
operated.
To
switch the
Remote
Control
mode
(to
operate
a
different
device),
be
sure
to
press
the
TV
first.
2
The
POWER,
CH(E/D),
VOLUME
(+/-),
and
INPUT
buttons
on
Remote
Control
are
used
to
operate
the
LG
TV.
Setting
Remote
Control
Codes
for
LG
TV
Hold
POWER
and
press
PR/CH(+/-)
(E/D)
button
repeatedly
until
the
TV
on
or
off.
ote
If
the
Remote
Control
does
not
operate
your
particular
TV,
try
the
other
code
or
use
the
Remote
Control
originally
supplied
with
the
TV.
Due
to
the
variety
of
codes
used
by
manufacturers,
OUR
COMPANY
cannot
guarantee
that
the
Remote
Control
will
operate
every
model
of
TV.
DVD
26
Operation
with
Radio
Presetting
the
radio
stations
You
can
preset
50
stations
for
FM
and
AM
(MW).
Before
tuning,
make
sure
that
you
have
turned
down
the
vol-
ume.
1
Press
BAND
on
the
Remote
Control
until
FM
or
AM
(MW)
appears
in
the
display
window.
2
And
then
every
time
you
press
BAND,
FM
and
AM
(MW)
changes
alternately.
3
Press
and
hold
TUNING
or
on
the
front
panel
for
about
two
seconds
until
the
frequency
indication
starts
to
change,
then
release.
Scanning
stops
when
the
DVD/CD
Receiver
tunes
in
a
station.
"TUNED"
and
"STEREO"
(for
stereo
program)
appear
in
the
display
window.
4
Press
PROG./MEMO.
on
the
Remote
Control.
A
preset
number
will
flash
in
the
display
window.
5
Press
PR(D/E)
on
the
Remote
Control
to
select
the
preset
number
you
want.
6
Press
PROG./MEMO.
on
the
Remote
Control
again.
The
station
is
stored.
7
Repeat
steps
3
to
6
to
store
other
stations.
To
tune
in
a
station
with
a
weak
signal
Press
TUNING
or
repeatedly
in
step
3
to
tune
in
the
station
manually.
To
clear
all
the
stored
stations
Press
and
hold
PROG./MEMO.
for
about
two
seconds
and
"CLEAR
ALL"
is
appeared
in
the
display
window
and
then
press
PROG./MEMO.
again,
the
stations
are
cleared.
If
you
have
accidentally
entered
into
the
"CLEAR
ALL"
and
you
do
not
wish
to
clear
the
memory,
do
not
press
any
key.
After
a
few
seconds,
the
"CLEAR
ALL"
display
will
go
off
by
itself
and
change
to
mode.
ote
If
all
stations
have
already
been
entered,
the
FULL
message
will
appear
in
the
display
window
for
a
moment
and
then
a
preset
number
will
flash.
To
change
the
preset
number,
follow
the
steps
5-6
as
above.
Listening
to
the
radio
Preset
radio
stations
in
the
DVD/CD
Receiver's
memory
first
(see
"Presetting
radio
stations"
on
the
left).
1
Press
BAND
until
AM
(MW)
or
FM
appears
in
the
display
window.
The
last
received
station
is
tuned
in.
2
Press
PR(D/E)
repeatedly
on
the
Remote
Control
to
select
the
preset
station
you
want.
Each
time
you
press
the
button,
the
DVD/CD
Receiver
tunes
in
one
preset
station
at
a
time.
3
Adjust
the
volume
by
rotating
VOLUME
on
the
front
panel
or
by
pressing
VOLUME
+
or
-
on
the
Remote
Control
repeatedly.
To
turn
off
the
radio
Press
POWER
to
turn
the
DVD/CD
Receiver
off
or
select
another
function
mode
(DVD/CD,
AV
1,
etc.,).
To
listen
to
non-preset
radio
stations
Use
manual
or
automatic
tuning
in
step
2.
For
manual
tuning,
press
TUN-
b
or
TUN+
B
on
the
Remote
Control
repeatedly.
For automatic
tuning,
press
and
hold
TUN-
b
or
TUN+
B
for
about
two
seconds
on
the
Remote
Control.
To
select
a
preset
radio
station
directly
You
can use
the
number
buttons
on
the
Remote
Control
to
select
a
preset
radio
station
directly.
For
example,
to
listen
to
preset
station
4,
press
4
on
the
remote
control.
To
listen
to
preset
station
19,
press
1
then
9
(within
3
seconds).
For
your
reference
If
an
FM
program
is
noisy
Press
MONO/ST.
on
the
front
panel
so
that
"ST."
disappears
in
the
display
window.
There
will
be
no
stereo
effect,
but
the
reception
will
improve.
Press
the
button
again
to
restore
the
stereo
effect.
To
improve
reception
Reorient
the
supplied
antennas.
Operation
27
Other
Functions
Sleep
Timer
Setting
You
can
set
the
DVD/CD
Receiver
to
turn
off
automati-
cally
at
a
specified
time.
1
Press
SLEEP
to
set
the
desired
sleep
time.
The
SLEEP
indicator
and
sleep
time
appears
in
the
dis-
play
window.
2
Each
time
you
press
SLEEP
the
setting
changes
in
the
following
order.
SLEEP
180
→150
→120→90→80→70
→60→50→
40→30→20→10
→OFF
ote
You
can
check
the
time
remaining
before
the
DVD/CD
receiver
turns
off.
Press
SLEEP.
The
remaining
time
appears
in
the
display
window.
Dimmer
This
function
will
change
the
brightness
of
the
display
window
on
the
front
panel
during
in
power-on
status.
Press
the
DIMMER
repeatedly.
Mute
Press
MUTE
to
mute
your
unit.
You
can
mute
your
unit
in
order,
for
example,
to
answer
the
telephone,
"MUTE"
indicator
flashes
in
the
display
window.
XTS
(Excellent
True
Sound)
You
can
enjoy
the
vivid
stereophonic
sound
of
the
digital
original
source
without
any
signal
distortion.
Each
time
you
press
XTS
during
2
channel
mode,
the
setting
changes
in
the
following
order.
XTS-1→XTS-2→XTS-3→NORMAL...
Tips:
XTS-
1:
When
playing
the
movie
with
the
weak
bass
sound
relatively
to
the
general
music,
it
enforces
the
sense
of
sound
at
woofer
for
you
to
satisfy
with.
XTS-
2:
In
the
mode
of
2
CH
BYPASS,
It
creates
the
high
display
effect
by
playing
the
sound
source
via
the
rear
speakers
same
as
the
front
speakers.
XTS-
3:
You
can
operate
both
XTS-
1
and
XTS-
2
simultaneously
and
it
can
complement
the
relative
degrading
of
the
sound
pitch
of
the
woofer
at
the
XTS-
2
mode.
ote
The
XTS-
2
mode
is
temporarily
disabled
when
changing
from
2.1
CH
to
5.1
CH
and
it
is
enabled
when
changing
it
to
2.1
CH.
XTS
pro
The
unique
sound
quality
of
the
LG
Technology
creates
the
optimum
sound
for
you
to
play
the
perfect
playback
of
the
original
sound
and
to
feel
the
living
sound
source.
Each
time
you
press
XTS
pro
the
setting
changes
in
the
following
order.
XTS-P
ON
→
XTS-P
OFF
28
Language
Codes
Country
Code
Afghanistan
AF
Argentina
AR
Australia
AU
Austria
AT
Belgium
BE
Bhutan
BT
Bolivia
BO
Brazil
BR
Cambodia
KH
Canada
CA
Chile
CL
China
CN
Colombia
CO
Congo
CG
Costa
Rica
CR
Croatia
HR
Czech
Republic
CZ
Denmark
DK
Ecuador
EC
Egypt
EG
El
Salvador
SV
Country
Code
Ethiopia
ET
Fiji
FJ
Finland
FI
France
FR
Germany
DE
Great
Britain
GB
Greece
GR
Greenland
GL
Islands
HM
Hong
Kong
HK
Hungary
HU
India
IN
Indonesia
ID
Israel
IL
Italy
IT
Jamaica
JM
Japan
JP
Kenya
KE
Kuwait
KW
Libya
LY
Luxembourg
LU
Country
Code
Malaysia
MY
Maldives
MV
Mexico
MX
Monaco
MC
Mongolia
MN
Morocco
MA
Nepal
NP
Netherlands
NL
Netherlands
Antilles
AN
New
Zealand
NZ
Nigeria
NG
Norway
NO
Oman
OM
Pakistan
PK
Panama
PA
Paraguay
PY
Philippines
PH
Poland
PL
Portugal
PT
Romania
RO
Russian
Federation
RU
Country
Code
Saudi
Arabia
SA
Senegal
SN
Singapore
SG
Slovak
Republic
SK
Slovenia
SI
South
Africa
ZA
South
Korea
KR
Spain
ES
Sri
Lanka
LK
Sweden
SE
Switzerland
CH
Taiwan
TW
Thailand
TH
Turkey
TR
Uganda
UG
Ukraine
UA
United
States
US
Uruguay
UY
Uzbekistan
UZ
Vietnam
VN
Zimbabwe
ZW
Choose
a
country
code
from
this
list.
Language
Code
Abkhazian
6566
Afar
6565
Afrikaans
6570
Albanian
8381
Ameharic
6577
Arabic
6582
Armenian
7289
Assamese
6583
Azerbaijani
6590
Bashkir
6665
Basque
6985
Bengali;
Bangla
6678
Bhutani
6890
Bihari
6672
Breton
6682
Bulgarian
6671
Burmese
7789
Byelorussian
6669
Cambodian
7577
Catalan
6765
Chinese
9072
Corsican
6779
Croatian
7282
Czech
6783
Danish
6865
Dutch
7876
English
6978
Esperanto
6979
Estonian
6984
Faroese
7079
Fiji
7074
Language
Code
Finnish
7073
French
7082
Galician
7176
Georgian
7565
German
6869
Greek
6976
Greenlandic
7576
Guarani
7178
Gujarati
7185
Hausa
7265
Hebrew
7387
Hindi
7273
Hungarian
7285
Icelandic
7383
Indonesian
7378
Interlingua
7365
Irish
7165
Italian
7384
Japanese
7465
Javanese
7487
Kannada
7578
Kashmiri
7583
Kazakh
7575
Kirghiz
7589
Korean
7579
Kurdish
7585
Laothian
7679
Latin
7665
Latvian,
Lettish
7686
Lingala
7678
Lithuanian
7684
Language
Code
Macedonian
7775
Malagasy
7771
Malay
7783
Malayalam
7776
Maltese
7784
Maori
7773
Marathi
7782
Moldavian
7779
Mongolian
7778
Nauru
7865
Nepali
7869
Norwegian
7879
Oriya
7982
Panjabi
8065
Pashto,
Pushto
8083
Persian
7065
Polish
8076
Portuguese
8084
Quechua
8185
Rhaeto-Romance
8277
Rumanian
8279
Russian
8285
Samoan
8377
Sanskrit
8365
Scots
Gaelic
7168
Serbian
8382
Serbo-Croatian
8372
Shona
8378
Sindhi
8368
Singhalese
8373
Slovak
8375
Language
Code
Slovenian
8376
Somali
8379
Spanish
6983
Sudanese
8385
Swahili
8387
Swedish
8386
Tagalog
8476
Tajik
8471
Tamil
8465
Tatar
8484
Telugu
8469
Thai
8472
Tibetan
6679
Tigrinya
8473
Tonga
8479
Turkish
8482
Turkmen
8475
Twi
8487
Ukrainian
8575
Urdu
8582
Uzbek
8590
Vietnamese
8673
Volapuk
8679
Welsh
6789
Wolof
8779
Xhosa
8872
Yiddish
7473
Yoruba
8979
Zulu
9085
Use
this
list
to
input
your
desired
language
for
the
following
initial
settings:
Disc
Audio,
Disc
Subtitle,
Disc
Menu.
Country
Codes
Reference
29
Troubleshooting
Check
the
following
guide
for
the
possible
cause
of
a
problem
before
contacting
service.
Symptom
No
power.
The
power
is
on,
but
the
DVD/CD
Receiver
does
not
work.
No
picture.
There
is
no
sound
or
only
a
very
low-level
sound
is
heard.
The
playback
is
poor.
The
DVD/CD
Receiver
does
not
start
playback.
Loud
hum
or
noise
is
heard.
Cause
?
The
power
cord
is
disconnected.
?
No
disc
is
inserted.
?
The
TV
is
not set
to
receive
DVD
signal
output.
?
The
video
cable
is
not
connected
securely.
?
The
connected
TV
power
is
turned
off.
?
The
equipment
connected
with
the
audio
cable
is
not
set
to
receive
DVD
signal
output.
?
The
audio
cables
are
not
connected
securely.
?
The
power
of
the
equipment
connected
with
the
audio
cable
is
turned
off.
?
The
audio
connecting
cable
is
damaged.
?
The
disc
is
dirty.
?
No
disc
is
inserted.
?
An
unplayable
disc
is
inserted.
?
The
disc
is
placed
upside
down.
?T
he
disc
is
not
placed
within
the
guide.
?
The
disc
is
dirty.
?Amenu
is
on
the
TV
screen.
?
The
Rating
level
is
set.
?
The
plugs
and
jacks
are
dirty.
?
The
disc
is
dirty.
?
The
speakers
and
components
are
connected
poorly.
?
The
DVD/CD
Receiver
is
located
too
close
to
the
TV.
Correction
?
Plug
the
power
cord
securely
into
the
wall
outlet.
?
Insert
a
disc.
(Check
that
the
DVD
or,
audio
CD
indicator
in
the
DVD
display
is
lit.)
?
Select
the
appropriate
video
input
mode
on
the
TV
so
the
from
the
DVD/
CD
Receiver
appears
on
the
TV
screen.
?
Connect
the
video
cable
into
the
jacks
securely.
?T
urn
on
the
TV.
?
Select
the
correct
input
mode
of
the
audio
receiver
so
you
can
hear
the
sound
from
the
DVD/CD
Receiver.
?
Connect
the
audio
cable
into
the
jacks
securely.
?T
urn
on
the
equipment
connected
with
the
audio
cable.
?
Replace
it
with
new
one.
?
Clean
the
disc.
?
Insert
a
disc.
(Check
that
the
DVD,
or
audio
CD
indicator
in
the
DVD
display
is
lit.)
?
Insert
a
playable
disc.
(Check
the
disc
type,
colour
system
and
Regional
code.)
?
Place
the
disc
with
the
playback
side
down.
?
Place
the
disc
on
the
disc
tray
correctly
inside
the
guide.
?
Clean
the
disc.
?
Press
the
SET
UP
button
to
turn
off
the
menu
screen.
?
Cancel
the
Rating
function
or
change
the
rating
level.
?W
ipe
them
with
a
cloth
slightly
mois-
tened
with
alcohol.
?
Clean
the
disc.
?
Connect
the
speakers
and
components
securely.
?
Move
your
TV
away
from
the
audio
components.
30
Troubleshooting
(Cont'd)
Symptom
Radio
stations
cannot
be
tuned
in.
The
Remote
Control
does
not
work
properly.
The
front
panel
display
is
too
dim.
Cause
?
The
antenna
is
positioned
or
connected
poorly.
?
The
signal
strength
of
the
stations
is
too
weak
(when
tuning
in
with
automatic
tuning).
?N
o
stations
have been
preset
or
preset
stations
have
been
cleared
(when
tuning
by
scanning
preset
stations).
?
The
Remote
Control
is
not
pointed
at
the
remote
sensor
of
the
DVD/CD
Receiver.
?
The
Remote
Control
is
too
far
from
the
DVD/CD
Receiver.
?
There
is
an
obstacle
in
the
path
of
the
Remote
Control
and
the
DVD/CD
Receiver.
?
The
batteries
in
the
Remote
Control
are
flat.
?
Nothing
is
displayed
on
the
front
panel
display.
Correction
?
Connect
the
antenna
securely.
?
Adjust
the
antennas
and
connect
an
external
antenna
if
necessary.
?T
une
in
the
station
manually.
?
Preset
the
stations
(page
26).
?
Point
the
Remote
Control
at
the
remote
sensor
of
the
DVD/CD
Receiver.
?
Use
the
Remote
Control
within
about
23
ft
(7
m).
?
Remove
the
obstacle.
?
Replace
the
batteries
with
new
ones.
?
Press
DIMMER
on
the
Remote
Control.
Reference
31
Designs
and
specifications
are
subject
to
change
without
notice.
Tuner
Specification
General
CD/DVD
Amplifier
Speakers
Supplied
Accessories
Power
supply
Refer
to
main
label
Power
consumption
Refer
to
main
label
Weight
2.5
kg
External
dimensions
(W
x
H
x
D)
360
x
56
x
310
mm
Operating
conditions
Temperature:
5°C
to
35°C,
Operation
status:
Horizontal
Operating
humidity
5%
to
85%
Laser
Semiconductor
laser,
wavelength
650
nm
Signal
system
NTSC
525/60
Frequency
response
(audio)
140
Hz
to
20
kHz
Signal-to-noise
ratio
(audio)
More
than
75
dB
(1
kHz,
NOP-3dB,
20
kHz
LPF/A-Filter)
Dynamic
range
(audio)
More
than
80
dB
Harmonic
distortion
(audio)
0.5
%
(1
kHz,
at
12W
position)
(20
kHz
LPF/A-Filter)
Video
output
1.0
V
(p-p),
75
Ω,
negative
sync.,
RCA
jack
Tuning
Range
87.5
-
108.0
MHz
Intermediate
Frequency
10.7
MHz
Signal-to
Noise
Ratio
60
dB
(Mono)
Frequency
Response
140
-
10,000
Hz
Tuning
Range
520
-
1,720
kHz
Intermediate
Frequency
450
kHz
Stereo
mode
45W+45W(6Ωat1kHz,THD10%)
Surround
mode
Front:
45W
+
45W
(THD
10
%)
Center*:
45W
Surround*:
45W
+
45W
(6Ω
at
1
kHz,
THD
10
%)
Subwoofer*:
75W
(8Ω
at
30
Hz,
THD
10
%)
Outputs
MONITOR
Satellite
Speaker
(LHS-25SCS)
Passive
Subwoofer
(LHS-25SCW)
Type
1
Way
1
Speaker
1
Way
1
Speaker
Impedance
6Ω
8Ω
Frequency
Response
160
-
20,000
Hz
65
-
1,500
Hz
Sound
Pressure
Level
84
dB/W
(1m)
82
dB/W
(1m)
Rated
Input
Power
45W
75W
Max.
Input
Power
90W
150W
Net
Dimensions
(W
x
H
x
D)
92x115x80mm
160x350x280mm
Net
Weight
0.5
kg
3.18
kg
?Speakers..........................6?Videocable.........................1
?AMloopantenna.....................1?FMantenna.........................1
?Remotecontrol......................1?Batteries(AAA).......................2
(*
Depending
on
the
sound
mode
settings
and
the
source,
there
may
be
no
sound
output.)
FM
AM
[MW]
Marketed
and
Distributed
by
LG
Electronics
U.S.A.,
Inc.
Zenith
Part
No.
206-04009
1000
Sylvan
Avenue.
Englewood
Cliffs,
NJ.
GS#
3834RH0104A
Printed
in
China
Issue
O
Zenith
will
repair
or
replace
your
product,
at
Zenith's
option,
if
it
proves
to
be
defective
in
material
or
workman-
ship
under
normal
use,
during
the
warranty
period
("Warranty
Period")
listed
below,
effective
from
the
date
("Date
of
Purchase")
of
original
purchase
of
the
product.
This
limited
warranty
is
good
only
to
the
original
pur-
chaser
of
the
product
and
effective
only
when
used
in
the
United
States,
excluding
U.S.
Territories.
THIS
WARRANTY
IS
IN
LIEU
OF
ANY
OTHER
WARRANTY,
EXPRESS
OR
IMPLIED,
INCLUDING
WITHOUT
LIMITATION,
ANY
WARRANTY
OF
MERCHANTABILITY
OR
FITNESS
FOR
A
PARTICULAR
PURPOSE.
TO
THE
EXTENT
ANY
IMPLIED
WARRANTY
IS
REQUIRED
BY
LAW,
IT
IS
LIMITED
IN
DURATION
TO
THE
EXPRESS
WARRANTY
PERIOD
ABOVE.
ZENITH
WILL
NOT
BE
LIABLE
FOR
ANY
INCIDENTAL,
CONSE-
QUENTIAL,
INDIRECT,
SPECIAL,
OR
PUNITIVE
DAMAGES
OF
ANY
NATURE,
EVEN
IF
ADVISED
OF
THE
POSSIBILITY
OF
SUCH
DAMAGES,
INCLUDING
WITHOUT
LIMITATION,
LOST
REVENUES
OR
PROFITS,
LOST
OR
CORRUPTED
PROGRAMMING
OR
DATA,
OR
ANY
OTHER
DAMAGE
WHETHER
BASED
IN
CON-
TRACT,
TORT,
OR
OTHERWISE.
Some
states
do
not
allow
the
exclusion
or
limitation
of
incidental
or
consequential
damages
or
limitations
on
how
long
an
implied
warranty
lasts,
so
the
above
exclusion
or
limitation
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
rights
and
you
may
also
have
other
rights
that
vary
from
state
to
state.
WARRANTY
PERIOD:
LABOR:
90
days
from
the
Date
of
Purchase.
PARTS:
1
Year
from
the
Date
of
Purchase.
*Parts
replaced
are
warranted
for
the
remaining
portion
of
the
original
warranty
period.
HOW
SERVICE
IS
HANDLED:
Carry-In
Service:
Please
retain
dealer's
dated
bill
of
sale
or
delivery
ticket
as
evidence
of
the
Date
of
Purchase
for
proof
of
warranty,
and
submit
a
copy
of
the
bill
of
sale
to
the
service
person
at
the
time
warranty
service
is
provided.
Please
call
1-877-9
Zenith
(1-877-993-6484)
to
locate
your
nearest
Zenith
Authorized
Service
Center.
Or
visit
our
website
at
http://www.zenithservice.com
?
Damage
caused
in
shipping
or
transit
?
Service
required
as
a
result of
improper
installation,
including
incorrect
or
insufficient
AC
supply
(Please
consult
the
owner's
manual
for
power
supply
requirements)
?
Installation
or
repair
of
other
components
in
a
video
system
?
Set-up
or
adjustment
on
consumer
controls,
or
damage
caused
by
improper
adjustments
?
Damage
cause
by
other
system
components
?
Damage
(including
cosmetic
damage),
failure,
loss
or
personal
injury
due
to
misuse,
abuse,
negligence,
improper
maintenance
or
storage,
or
to
acts
of
nature
or
other
causes
beyond
Zenith's
control
(Causes
beyond
Zenith's
control
include
but
are
not
limited
to
lightning
strike,
power
surges,
power
outages,
and
water
damage)
?
Repair
or
replacement
of
warranted
parts
by
other
than
Zenith
Authorized
Service
Centers
?
Units
purchased
or
serviced
outside
the
coverage
area
?
Product
where
the
original
factory
serial
numbers
have
been
removed,
defaced,
or
changed
in
any
way
?
Product
sold
and
labeled
as
"as
is,
where
is"
or
similar
disclaimer
For
nearest
Authorized
Service
Center,
Where
to
buy,
Product
Assistance,
or
Customer
Assistance
Call
1-877-9Zenith
(1-877-993-6484)
(24
Hours
a
Day,
365
Days
a
Year)
and
select
appropriate
option
from
the
menu.
Or
visit
our
website
at
http://www.zenithservice.com
THIS
LIMITED
WARRANTY
DOES
NOT
APPLY
TO:
The
costs
of
repair
or
replacement
under
these
excluded
circumstances
shall
be
borne
by
the
con-
sumer.
CUSTOMER
INTER-ACTIVE
CENTER
NUMBERS:
