Gaggia Cadorna + Automatic Coffee Machine RI9601-01 User Manual

ENGLISH

POLSKI

NEDERLANDS

RI9600 (SUP049) / RI9601 (SUP049E)

GAGGIA CADORNA

STYLE / PLUS

Operating instructions

Gebruiksaanwijzing

Instrukcja obsługi

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 1 23/10/2020 11:32:12

POLSKI

NEDERLANDS

START/STOP

ON/OFF

my favourites

HOME

clean/setting

3 4 5 6 7

ESPRESSO COFFEE

STEAM HOT WATER

Control panel / Controlepaneel / Panel sterowania

Beverage menu / Menu dranken / Menu napojów

Ristretto

Coffee / Koe / Kawa 30 ml

Coffee / Koe / Kawa

Coffee / Koe / Kawa 120 ml

Espresso

Coffee / Koe / Kawa 40 ml

Americano

Coffee / Koe / Kawa 40 ml

Water / Water / Woda 110 ml

Espresso lungo

Coffee / Koe / Kawa 80 ml

Hot water / Heet water / Gorąca woda

Water / Water / Woda 150 ml

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 2 23/10/2020 11:32:14

24 23

1918

22 2021

15 14

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 3 23/10/2020 11:32:15

First installation / Eerste installatie / Pierwsza instalacja

START/STOP

ON/OFF

my favourites

HOME

clean/setting

FILLING WATER CIRUIT

to start press

START/STOP

ON/OFF

my favourites

HOME

clean/setting

Confermi di voler

cambiare la lingua

in Italiano?

START/STOP

ON/OFF

my favourites

HOME

clean/setting

WATER HARDNESS

START/STOP

ON/OFF

my favourites

HOME

clean/setting

In the next steps

we will set the correct

water hardness level

START/STOP

ON/OFF

my favourites

HOME

clean/setting

Are you sure you

want to select

2 zone red?

START/STOP

ON/OFF

my favourites

HOME

clean/setting

LANGUAGE

LIETUVOS

SLOVENIJA

ENGLISH

ITALIANO

DEUTSCH

FRANÇAIS

ESPAÑOL

PORTUGUÊS

START/STOP

ON/OFF

my favourites

HOME

clean/setting

WATER HARDNESS

START/STOP

ON/OFF

my favourites

HOME

clean/setting

Welcome

1 sec.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

LANGUAGE

SLOVENIJA

CECO

LIETUVOS

ENGLISH

ITALIANO

DEUTSCH

FRANÇAIS

ESPAÑOL

1 min.

19 20 21 22

14 1615 17

09 10 11 12

04 05 06 07

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 4 23/10/2020 11:32:18

Congratulations on purchasing the Gaggia Cadorna!

This easy-to-use machine guarantees excellent coffee drinks, every day. With its

intuitive interface, you can choose from among 6 beverages, customise them

and save them to the 4 available profiles, where they can be instantly brought up

whenever you want.

Before being packed, each of our high-quality machines undergoes rigorous testing

in our laboratories to ensure it works perfectly. Because real coffee is used during

testing, some residue may remain. This does not compromise the integrity of the

product: it is a brand new machine.

Please read the whole manual carefully before you instal, use or clean your

machine. Before using it for the first time, please read carefully the safety manual

provided separately and store it for future use.

ENGLISH

Van harte gelukgewenst met de aanschaf van een Gaggia Cadorna!

Met deze machine zal u op eenvoudige wijze steeds uitstekende resultaten

verkrijgen. Dankzij de intuïtieve interface kunt u kiezen uit 6 dranken, ze aanpassen

en opslaan in de 4 beschikbare profielen, om ze bij elk gebruik terug te vinden.

Alvorens verpakt te worden, ondergaat elke machine strenge tests in onze

laboratoria om de hoge kwaliteit en correcte werking ervan te garanderen. Er

wordt ook tijden het testen koffie gebruikt, dus het is mogelijk dat er wat residu

achterblijft. Dit doet geen afbreuk aan de integriteit van het product: het is een

volledig nieuwe machine.

In deze handleiding zult u alle nodige informatie vinden om uw machine te

installeren, te gebruiken, schoon te maken en te ontkalken. Lees de aparte

veiligheidsbrochure zorgvuldig door voordat u ze voor het eerst gebruikt en bewaar

deze voor toekomstig gebruik.

NEDERLANDS

Gratulujemy zakupu urządzenia Gaggia Cadorna!

Dzięki temu urządzeniu zawsze będziesz cieszyć się doskonałymi rezultatami,

o które w tym przypadku nie trudno. Za sprawą intuicyjnego interfejsu możesz

wybrać spośród 6 napojów, dostosować je do swoich potrzeb i zapisać je w

pamięci 4 dostępnych profili, aby odnaleźć je przy każdym użyciu urządzenia.

Przed zapakowaniem każde urządzenie przechodzi szereg rygorystycznych testów

w naszych laboratoriach, aby zapewnić ich wysoką jakość i prawidłowe działanie.

Podczas odbioru urządzenia testujemy je przy użyciu kawy, dlatego mogą

pozostać w nim jej pozostałości. Nie miało to jednak niekorzystnego wpływu na

integralność produktu: jest to urządzenie całkowicie nowe.

W niniejszej instrukcji zawarto wszelkie informacje niezbędne do zainstalowania,

użytkowania, czyszczenia i odwapniania urządzenia. Przed jego pierwszym

użyciem należy zapoznać się uważnie z dostarczoną osobno broszurą dotyczącą

bezpieczeństwa i zachować ją w razie potrzeby skorzystania z niej w przyszłości.

POLSKI

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 5 23/10/2020 11:32:19

English

Table of Contents

Machine Overview (Fig.2) ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................7

Control Panel and Display .................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................8

Control panel overview (Fig. 1) ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................8

Multifunction buttons ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................8

First Installation ...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................9

Manual rinse cycle .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................9

Measuring water hardness ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................10

INTENZA+ Water Filter ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................10

Installing the INTENZA+ water lter ........................................................................................................................................................................................................................................................................................................................................................................................................................................11

Replacing the INTENZA+ water lter .................................................................................................................................................................................................................................................................................................................................................................................................................................11

Types of Beverage .................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................12

Espresso tray (only for Cadorna Plus model) .....................................................................................................................................................................................................................................................................................................................................12

Brewing Co󰀨ee ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................13

Brewing co󰀨ee from whole co󰀨ee beans ........................................................................................................................................................................................................................................................................................................................................................................................................13

Brewing co󰀨ee using pre-ground co󰀨ee .............................................................................................................................................................................................................................................................................................................................................................................................................13

How to Froth Milk ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................14

Dispensing Hot Water ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................15

Beverage Customisation and Prole Creation ...............................................................................................................................................................................................................................................................................................................................15

Customisation .............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................15

Creating a prole ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................17

Co󰀨ee Grind Settings ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................18

Cleaning and Maintenance .................................................................................................................................................................................................................................................................................................................................................................................................................................................................................18

Cleaning table ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................18

Cleaning the Classic Pannarello ................................................................................................................................................................................................................................................................................................................................................................................................................................................20

Cleaning the brew group .....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................20

Lubricating the brew group .....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................23

Descaling ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................24

Descaling procedure ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................24

What to do if the descaling process is interrupted .................................................................................................................................................................................................................................................................................................................................................25

Various Settings .....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................25

Language ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................25

Water lter ...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................26

Timer stand-by ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................26

Water hardness ...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................26

Measurement units ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................26

Prepared beverages counter .................................................................................................................................................................................................................................................................................................................................................................................................................................................................................26

Restore factory settings .................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................26

Error Code Key ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................27

Troubleshooting ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................28

GAGGIA Accessories ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................30

Technical Specications ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................31

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 6 23/10/2020 11:32:20

English

Machine Overview (Fig.2)

1 Coffee bean container lid 13 Espresso tray (only for Cadorna Plus model)

2 Coffee bean container 14 Steame tube

3 Power cord socket 15 Steam wand protection

4 Water tank 16 Power cord

5 Pre-ground coffee compartment 17 Lubricant

6 Coffee grinder adjustment knob 18 Pre-ground coffee measuring scoop

7 Control panel 19 Water hardness tester

8 Adjustable coffee dispensing spout 20 Service door

9 Coffee pucks container 21 Coffee residues drawer

10 Drip tray 22 Brew group

11 Drip tray grid 23 Classic Pannarello

12 “Full drip tray” indicator 24 Classic Pannarello handle

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 7 23/10/2020 11:32:20

English

Control Panel and Display

This coffee machine features an easy-to-use, intuitive display. Please see below for

an in-depth explanation of each button.

Multifunction buttons

Use the multifunction buttons at the sides of the display to select the feature or

beverage indicated on the screen.

Control panel overview (g. 1)

1/2 MULTIFUNCTION buttons

Selects the function shown on the display.

ON/OFF

button

To switch the machine on or off.

MY FAVOURITES

my favourites

button

Opens the personal proles menu.

HOME

button

Opens the beverage menu.

CLEAN/SETTING

clean/setting

button

Opens the cleaning and settings menu.

START/STOP

button

Starts/stops the dispensing of the selected

beverage, or starts/stops the procedure

indicated on the display.

Note: the MY FAVOURITES

my favourites

, HOME

HOME

, CLEAN/SETTING

clean/setting

buttons are

also ESC buttons. You can exit any screen shown on the display at any time by

pressing one of these buttons, which will then bring you back to their initial menu.

Note: To make the reading of this manual easier, <<press the button " ">> means

<<press the button related to " ">>.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO

STEAM HOT WATER

COFFEE

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 8 23/10/2020 11:32:21

English

First Installation

Before using the machine, it is essential to follow a few simple steps, clearly

described in the explanatory drawings found in the quick guide at the beginning of

this instruction manual.

Note: To make the best-tasting coffee, you should brew 5 coffees initially to allow

the machine to complete its self-adjustment.

Warning: Do not use the steam wand protection as a handle, use the appropriate

classic pannarello handle.

Manual rinse cycle

When rst installing the machine or after a long period of its inactivity, it is

necessary to prime the water circuit through the manual rinse cycle.

1 Place a container under the coffee dispensing spout, browse through the

pages and select "ESPRESSO LUNGO".

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO

STEAM HOT WATER

COFFEE

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

OFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

2 Press the " "button without adding pre-ground coffee.

3 Press the START/STOP

START/STOP

button to start dispensing, the machine will

dispense hot water.

4 Empty the container and remove the classic pannarello from the steam wand.

5 Place the container under the steam wand and select the " HOT WATER "

beverage.

6 Press the START/STOP

START/STOP

button to commence dispensing.

7 Empty the container and repeat steps 6 to 7, until the water tank is empty.

8 At the end of this operation, ll the water tank again up to the MAX level. The

machine is now ready for use.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 9 23/10/2020 11:32:23

English

Measuring water hardness

You’ll need to set the water hardness when you instal your machine.

Take the water hardness measuring strip that you nd in the box and follow the

steps shown on the display during installation. To adjust the water hardness

setting later, press the CLEAN/SETTING

clean/setting

button, select " SETTINGS ", and then

" WATER HARDNESS " from the settings menu.

1 Immerse the water hardness measuring strip in a glass of water for 1 second.

Remove the strip from the water and wait 1 minute.

2 Note how many squares turn red.

3 Use the green " " and " " buttons to select the water hardness according

to the table below. Conrm the setting by pressing " ".

Small red

squares

Value to set Water hardness INTENZA+

1 very soft water A

2 soft water A

3 hard water B

4 very hard water C

INTENZA+ Water Filter

We recommend using the INTENZA+ water lter to limit the formation of limescale.

This ensures the machine will last longer and the aroma of your coffee will be

better.

Water is an essential element in brewing coffee: it is therefore extremely important

to ensure it is always ltered adequately.

The INTENZA+ water lter prevents the formation of mineral deposits, improving

the quality of the water.

1 sec.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 10 23/10/2020 11:32:24

English

Installing the INTENZA+ water lter

Remove the small white lter from the water tank and store it in a dry place.

Immerse the INTENZA+ water lter vertically (with the opening pointing up) in cold

water and gently press its sides to let any air bubbles out.

Place the INTENZA+ lter in the water tank, ensuring it is correctly in place. Rell

the water tank and place it in its compartment.

Press the CLEAN/SETTING

clean/setting

button, select " SETTINGS ", and then " WATER

FILTER " from the settings menu.

Follow the instructions shown on the display to activate the lter.

Note: you can pause the lter activation procedure by pressing the START/STOP

START/STOP

button. To resume the procedure, press the START/STOP

START/STOP

button again.

Remove the INTENZA+ water lter from the water. Set the machine according to

the detected water hardness (see the "Measuring water hardness" chapter) and the

letters found on the lter base:

A = soft water – 1 or 2 small squares

B = hard water (standard) – 3 small squares

C = very hard water – 4 small squares

Replacing the INTENZA+ water lter

When the INTENZA+ water lter runs out, the display will show an alarm message.

1 Replace or deactivate by pressing the CLEAN/SETTING

clean/setting

button, and then

the " SETTINGS " button.

2 Select the " WATER FILTER " button.

3 Select " REPLACE " to change the lter or " DISABLE " if you do not intend to

use the lter. Conrm with the " " button.

Follow the instructions shown on the display to activate the lter correctly.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

WATER FILTER

REPLACE

ACTIVATE

DISABLE

START/STOP

ON/OFF

my favourites

HOME

clean/setting

Filter expired, replace

or disable it

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 11 23/10/2020 11:32:25

English

Types of Beverage

Beverage name Description

Ristretto A ristretto, served in a small cup, is an espresso whose brewing time is shorter

than a regular espresso. As such, a ristretto is a shorter shot and lower in

caffeine.

Espresso The espresso is known around the globe as true "Italian coffee". Served in

a small cup, its unmistakeable characteristics are a full and intense aroma

and a top layer of compact, natural crema. It is the result of the hot-water

pressurised extraction process invented by Achille Gaggia in 1938.

Espresso lungo An espresso lungo is an espresso shot with a longer extraction time. It is more

diluted, with a different aromatic intensity and a higher caffeine content. It is

served in a medium-sized cup.

Coffee Coffee is a beverage prepared with a greater quantity of water than an

espresso shot. It has a lighter aroma and is served in a medium-large cup.

Americano An Americano is a long, less intense coffee drink prepared by combining hot

water and espresso.

Hot water Hot water can be used to prepare hot teas, infusions and instant beverages.

Espresso tray (only for Cadorna Plus

model)

This machine was designed to guarantee awless results, from a traditional

espresso to a number of different beverages. If you wish to try a traditional Italian

espresso, with a delicious layer of natural crema on the surface, we recommend

using the "Espresso Tray", which has been specically designed for and integrated

into the machine. This tray makes it possible to use traditional espresso cups,

ensuring the perfect height from the spout for compact, homogeneous crema and

dispensation without messy splashes.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 12 23/10/2020 11:32:26

English

Brewing co󰀨ee using pre-ground co󰀨ee

Use the measuring scoop provided to insert the correct dose in the pre-ground

coffee compartment.

1 Lift the lid of the pre-ground coffee compartment and add one level measuring

scoop of pre-ground coffee.

Warning: do not insert anything other than pre-ground coffee in the pre-ground

coffee compartment, as it may damage the machine.

2 Place a cup under the coffee dispensing spout and select the desired beverage.

3 Once the beverage is selected, it is possible to prepare two cups at the same

time using the " " button, except the AMERICANO.

2 Browse the various pages to nd and select the desired beverage.

4 Finally, press the START/STOP

START/STOP

button to begin dispensing the coffee.

Note: you can interrupt the brewing at any time by pressing the START/STOP

START/STOP

button.

If you wish to customise the settings of a specic beverage, please refer to the

"Beverage customisation" chapter.

Brewing co󰀨ee

Brewing co󰀨ee from whole co󰀨ee beans

Warning: always use whole coffee beans when making espresso. Do not put any

pre-ground, unroasted, freeze-dried or instant coffee in the coffee bean container,

as they may damage the machine.

Tip: Preheat the cups with hot water to enjoy a hotter coffee.

1 Remove the espresso tray, place an espresso cup beneath the coffee

dispensing spout, raising or lowering it according to the size of the cup being

used.

Press the HOME

HOME

button to bring up the beverage menu.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO

STEAM HOT WATER

COFFEE

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 13 23/10/2020 11:32:27

English

3 Press the " " button.

Note: the "pre-ground coffee" function cannot dispense two cups of coffee at

the same time, and it disables the aroma setting, both of which are possible with

coffee beans only.

4 Press the START/STOP

START/STOP

button to start dispensing the coffee.

If you wish to customise the settings of a specic beverage, please refer to the

"Beverage customisation" chapter.

Note: you can interrupt the brewing at any time by pressing the START/STOP

START/STOP

button.

How to Froth Milk

Tip: use cold milk (at a temperature of around 5 °C) with a protein content of at

least 3% to ensure optimum results for the froth. You can use either whole milk or

semi-skimmed milk. You can also use skimmed milk, soy milk or lactose-free milk.

Fill 1/3 of a carafe with milk.

2 Press the HOME

HOME

button to open the beverage menu.

3 Insert the Classic Pannarello into the milk. From the beverage selection menu,

select " STEAM ".

4 Froth the milk by gently swirling the carafe and moving it up and down.

5 When the milk froth comes to the desired consistency. Press the START/STOP

START/STOP

button to stop steam dispensing.

Note: After frothing milk, clean the circuit by dispensing a small quantity of hot

water.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

OFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO

STEAM HOT WATER

COFFEE

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 14 23/10/2020 11:32:29

English

Dispensing Hot Water

Warning: when the machine starts preparing hot water, the Pannarello spout may

spray steam and hot water.

1 Place a container under the Classic Pannarello.

2 Press the HOME

HOME

button.

3 Press the "HOT WATER" button. Finally, press the START/STOP

START/STOP

button to

commence dispensing.

Note: you can interrupt the brewing at any time by pressing the START/STOP

START/STOP

button.

If you wish to customise the settings, please refer to the "Customisation" chapter.

Beverage Customisation and Prole

Creation

This machine makes it possible to modify the settings of a beverage according to

your preferences and save it to one of four available proles.

Customisation

1 Press the HOME

HOME

button.

2 Select your beverage.

3 All the settings that can be adjusted and/or selected are displayed on the

screen. Based on the type of beverage, you can adjust and/or select:

- the amount of coffee;

- the temperature of the coffee;

- the dispensing of two cups at the same time;

- the use of pre-ground coffee;

- the intensity of the aroma (only when using coffee beans);

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO

STEAM HOT WATER

COFFEE

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 15 23/10/2020 11:32:30

English

4 Once the " COFFEE " button has been pressed, use the green " " and

" " buttons to select the desired amount.

Press " " to conrm and return to the previous screen, where the new

quantity will be displayed.

5 Press the " TEMP " button several times to adjust the temperature of the

beverage from among the following options:

- low;

- medium;

- high;

6 Press " " to prepare two cups, or " " to prepare a single cup. The picture

of the beverage in the centre of the display will indicate the number of cups

selected.

Note: this function is not available for the AMERICANO and the HOT WATER.

7 Press the " " button to activate the use of pre-ground coffee.

Note: this function only allows the dispensing of one coffee at a time.

8 To adjust the aroma intensity, press " ". Each time you press the

button, the aroma intensity changes by one degree. The display shows the

chosen intensity.

1 Very light

2 Light

3 Normal

4 Strong

5 Very strong

Note: this function is not available for pre-ground coffee.

9 Once the drink has been customised, you can save it in a specic prole by

pressing the " " button.

10 Choose the prole where you wish to save the beverage from the 4 available.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO

COFFEE

30 ml

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 16 23/10/2020 11:32:32

English

3 Press the " ADD DRINK " button.

4 The beverage screens will be displayed. Select the beverage that you want to

save to your prole and customise it by following steps 3 to 8 in the "Beverage

customisation" chapter.

Creating a prole

There are two ways to create a prole:

- Using the HOME

HOME

button, as described in the "Beverage customisation"

chapter, points 9 and 10;

- Using the MY FAVOURITES

my favourites

button, as follows:

1 Press the MY FAVOURITES

my favourites

button.

2 Select your preferred prole colour.

6 The beverage saved in the prole can be modied using the " EDIT " button,

or deleted using the " DELETE " button.

Note: It is not possible to save the beverage from the HOME menu via the MY

FAVOURITES

my favourites

button. Instead, use the " " button, otherwise you will lose the

settings you have just applied.

5 Press " " to save the customised beverage to your prole. At this point,

you can dispense the beverage or exit the menu by pressing one of the ESC

buttons (HOME

HOME

, MY FAVOURITES

my favourites

, CLEAN/SETTING

clean/setting

The saved beverage is now present in the list of your preferences and

marked with a small heart in the same colour as the selected prole.

Note: Once used, the " " prole icon will change colour.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ADD DRINK

START/STOP

ON/OFF

my favourites

HOME

clean/setting

CHOOSE YOUR

PROFILE

START/STOP

ON/OFF

my favourites

HOME

clean/setting

DELETEDIT

START/STOP

ON/OFF

my favourites

HOME

clean/setting

30 ml

medium

ESPRESSO

COFFEE

TEMP

START/STOP

ON/OFF

my favourites

HOME

clean/setting

ESPRESSO ADD DRINK

START/STOP

ON/OFF

my favourites

HOME

clean/setting

CHOOSE YOUR

PROFILE

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 17 23/10/2020 11:32:34

English

Co󰀨ee Grind Settings

You can adjust the grind setting using the grinder adjustment knob on the coffee

bean container. The ceramic coffee grinder guarantees perfect, even grinding for

the preparation of every cup of coffee. The aroma is thus preserved, ensuring the

perfect avour every time.

Note: you can only adjust the grind setting while the machine is grinding the coffee

beans. The difference in avour will be noticeable after 2-3 cups of coffee have

been brewed.

Warning: to avoid damaging the coffee grinder, do not rotate the grinder

adjustment knob more than one notch at a time.

1 Place a cup under the coffee dispensing spout.

2 Remove the lid of the coffee bean container.

3 Prepare an espresso as described in the "Brewing coffee from coffee beans"

chapter.

4 While the machine is grinding the coffee, place the end of the handle of the

pre-ground coffee measuring scoop on the coffee grinder adjustment knob,

located in the coffee bean container. Use the handle of the measuring scoop to

press and rotate the knob to the left or right, one notch at a time.

5 You can select from 10 grinding settings, from ne to course. The smaller the

notch, the stronger and richer the coffee.

Note:

- Coarse grind: lighter taste, for dark roasted coffee blends (5-10);

- Fine grind: stronger taste, for light roasted coffee blends (1-5);

Cleaning and Maintenance

Regular cleaning and maintenance keep the machine in perfect condition and

ensure perfect coffee avour, a constant coffee ow and excellent milk froth.

Please refer to the following table to know when and how to clean the removable

parts of the machine. For more detailed information, please read the relevant

chapters.

Cleaning table

Part description When to clean How to clean

Classic Pannarello After use Remove the Classic Pannarello and rinse it under

running water.

Weekly Disassemble the Classic Pannarello and the

rubber handle. Clean them under running water.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 18 23/10/2020 11:32:35

English

Part description When to clean How to clean

Brew group Weekly Remove the brew group and clean it under

running water.

Depending on usage See the "Cleaning and lubricating the brew group"

chapter.

Monthly Clean the brew group with the Gaggia coffee oil

remover to remove any oily coffee residue

Drip tray full When the red indicator emerges

from the grid of the drip tray

Empty the drip tray and clean it under running

water.

Coffee pucks

container

Whenever the machine requires it Empty the coffee pucks container and clean it

under running water. Ensure that the machine is

switched on during this procedure, or the coffee

pucks container will not reset.

Water tank Weekly Clean it under running water.

Pre-ground coffee

compartment/coffee

outlet duct

Weekly Clean the upper part using the handle of a spoon,

as shown below.

Espresso tray Depending on usage Remove the espresso tray and clean it with

running water. It can also be washed in the upper

tray of a dishwasher.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 19 23/10/2020 11:32:35

English

Cleaning the Classic Pannarello

1 Remove the Classic Pannarello and the rubber handle from the steam spout

and rinse them under running water.

2 Clean the steam wand with a damp cloth.

3 Reassemble the parts.

Cleaning the brew group

Warning: do not wash the brew group in the dishwasher and do not use dish-

washing detergents, since they may cause the malfunctioning of the brew group

and alter the coffee avour.

Removing the brew group

1 Turn off the machine and disconnect the power cord.

2 Remove the coffee pucks container and open the service door.

3 Remove the coffee residues drawer.

4 Press the PUSH lever (1) and pull the handle of the brew group (2) to remove it

from the machine.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 20 23/10/2020 11:32:36

English

Cleaning the brew group under running water

1 Clean the coffee outlet duct thoroughly with a spoon handle or with another

round-tipped kitchen utensil.

2 Thoroughly rinse the brew group using lukewarm water. Carefully wash the

upper lter.

3 Let the brew group air dry.

Note: to avoid the build-up of bres in its interior, do not dry the brew group with

cloth.

Cleaning the brew group with co󰀨ee cleaning tablets

Warning: use only Gaggia tablets for removing oily coffee residue.

1 Place a container under the coffee dispensing spout.

2 Press the CLEAN/SETTING

clean/setting

button and select the " CLEAN " button shown

on the display.

3 Select " BREW GROUP CLEANING " and press the START/STOP

START/STOP

button to

launch the cleaning procedure.

4 Follow the instructions shown on the display to correctly clean the brew group.

5 The procedure will take approximately 5 minutes. The START/STOP

START/STOP

button can be used to suspend and then resume the procedure.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

BREW GROUP CLEAN

DESCLING

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 21 23/10/2020 11:32:37

English

Reinserting the brew group

1 Before reinserting the brew group into the machine, ensure that the two yellow

reference indicators on the side coincide. If this is not the case, perform the

following step:

Make sure that the lever is in contact with the base of the brew group.

2 Make sure that the yellow locking hook of the brew group is in the right

position.

To correctly position the hook, push it upwards to the highest possible position.

If the hook is still in the lower position, this means it has not been correctly

positioned.

3 Reinsert the brew group in the machine along the side guides until it locks in

the right position with a click.

Warning: do not press the PUSH lever.

4 Close the service door.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 22 23/10/2020 11:32:38

English

Lubricating the brew group

In order to ensure the perfect performance of the machine, it is necessary

to lubricate the brew group. Refer to the following table for the frequency of

lubrication.

Frequency of use

Number of beverages prepared

daily

Frequency of

lubrication

Low 1-5 Every 4 months

Regular 6-10 Every 2 months

High >10 Every month

1 Turn off the appliance and disconnect the power cord.

2 Remove the brew group and rinse it using lukewarm water (see the "Cleaning

the brew group under running water" chapter).

3 Apply a thin layer of the lubricant provided around the inserting pin on the

lower part of the brew group.

4 Apply a thin layer of lubricant to the guides, on both sides (see gure).

5 Reinsert the brew group (see the "Reinserting the brew group" chapter).

Note: you can use the lubricant tube multiple times.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 23 23/10/2020 11:32:39

English

Descaling

Descaling procedure

Descaling needs to be carried out when the machine signals it.

Use only the Gaggia descaling solution designed to guarantee the machine’s

excellent performance. The use of other products could damage the machine and

leave residue in the water. Failure to descale the machine will void the warranty.

1 Remove the Classic Pannarello.

2 Press the CLEAN/SETTING

clean/setting

button and select the " CLEAN " button shown

on the display.

- Press the " DESCALING " button, then press the START/STOP

START/STOP

button.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

BREW GROUP CLEAN

DESCLING

3 Remove the drip tray and the coffee pucks container, empty them, and insert

them in the machine again.

4 Remove the water tank and empty it. Remove the INTENZA+ lter, if present.

5 Empty the entire bottle of Gaggia descaling solution into the water tank and ll

the tank with water up to the CALC CLEAN notch. Reinsert it in the machine.

6 Place a large container (1.5l) under the steam tube and coffee dispenser.

7 Follow the instructions shown on the display to launch the descaling

procedure. This procedure lasts approximately 25 minutes and consists of

a descaling cycle and a rinse cycle, carried out with dispensing at regular

intervals.

8 Once the descaling cycle is complete, rinse the water tank, and water circuit,

following the instructions shown on the display.

9 Replace the INTENZA+ lter into the water tank.

Note: it is possible to pause and resume the procedure at any time by pressing the

START/STOP

button.

Warning: when the descaling procedure is active, the brew group cannot be

removed. Wait for the descaling process to end, then remove the brew group.

CALC

CLEAN

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 24 23/10/2020 11:32:39

English

What to do if the descaling process is interrupted

You can exit the descaling procedure by pressing the ON/OFF

ON/OFF

button on the

control panel. If the descaling procedure is interrupted before its completion,

proceed as follows:

1 Empty the water tank and wash it thoroughly.

2 Fill the water tank with fresh water up to the CALC CLEAN notch and switch

the machine on again. The machine will warm up and perform an automatic

rinse cycle.

3 Before preparing any beverage, perform a rinsing cycle as described in the

specic chapter.

Note: if the procedure has not been completed, it will be necessary to carry out

another descaling procedure as soon as possible.

Language

When the language setting icon is selected, the list of available languages will be

displayed.

Languages available

ITALIAN DUTCH HUNGARIAN

ENGLISH DANISH BULGARIAN

GERMAN GREEK CZECH

FRENCH POLISH SLOVAK

SPANISH RUSSIAN LITHUANIAN

PORTUGUESE ROMANIAN

Various Settings

By pressing the CLEAN/SETTING

clean/setting

button and selecting " SETTINGS " on the

display, it is possible to reset or modify several machine parameters including:

- Language

- Water lter

- Timer stand-by

- Water hardness

- Measurement units

- Beverage counter

- Restore factory settings

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 25 23/10/2020 11:32:40

English

Timer stand-by

When " TIMER STAND-BY " is selected, the timer can be set to:

- 15 min

- 30 min

- 60 min

- 180 min

START/STOP

ON/OFF

my favourites

HOME

clean/setting

LANGUAGE

TIMER STAND-BY

WATER FILTER

UNITS

START/STOP

ON/OFF

my favourites

HOME

clean/setting

LANGUAGE

TIMER STAND-BY

WATER FILTER

UNITS

START/STOP

ON/OFF

my favourites

HOME

clean/setting

LANGUAGE

TIMER STAND-BY

WATER FILTER

UNITS

Water hardness

With " WATER HARDNESS " selected, follow the instructions on the display and

those described under the "Measuring water hardness" chapter.

Water lter

When " WATER FILTER " is selected, follow the instructions on the display and

those described under the "Installing the INTENZA+ water lter" and "Replacing the

INTENZA+ water lter" chapters.

Beverage counter

It is possible to display the number of cups of each beverage that have been

dispensed since the rst operation of the machine. These numbers cannot be

reset.

Restore factory settings

It is possible to restore the machine to the default factory settings. The machine

will require a secondary conrmation before proceeding. All the parameters will be

reset except those relating to the proles (MY FAVOURITES

my favourites

) and the beverage

counter.

Measurement units

By selecting " MEASUREMENT UNITS ":

it is possible to set the measurement units to "ml" or "oz".

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 26 23/10/2020 11:32:41

English

Error Code Key

The list below reports the error codes that the display can show, their meanings

and how to solve the problem. If the indicated solutions are ineffective because

the display keeps showing the error code icon and the machine does not function

correctly, or if further error codes are displayed, please contact an authorised

service centre or your local vendor..

The contact info is listed on www.gaggia.com and www.gaggia.it.

Error code Problem Cause Possible solution

01 The coffee grinder is

clogged.

The coffee outlet duct

is clogged.

Remove the power cord and remove the

brew group. Clean the coffee outlet duct

thoroughly using a spoon handle. Switch

the appliance on again.

03 - 04 A problem occurred in the

brew group.

The brew group is dirty

or not well lubricated.

Switch off the machine using the power

button. Remove the brew group and clean

it thoroughly. (Refer to the "Cleaning the

Brew Group" chapter)

The brew group is not

positioned correctly.

Switch off the machine using the power

button. Remove the brew group and

reinsert it. Ensure that the brew group is

in the correct position before inserting it.

Refer to the "Reinserting the brew group"

chapter.

05 A problem occurred in the

water circuit.

There is air in the water

circuit.

Remove and reinsert the tank in the

machine a couple of times. Make sure you

insert the tank correctly in the machine.

Check that the water tank seat is clean.

If you use an "INTENZA+" lter: pull out the

lter from the water tank and shake it to

remove all air from the lter. Then reinsert

the "INTENZA+" lter into the water tank.

14 The machine is

overheated.

There may be multiple

causes.

Switch off the machine and switch it

on again after 30 minutes. Perform this

operation 2 or 3 times.

START/STOP

ON/OFF

my favourites

HOME

clean/setting

x x

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 27 23/10/2020 11:32:41

English

Troubleshooting

This chapter summarises the most common problems you may encounter while

using the machine. If you are unable to resolve the problem using the information

given below, visit the FAQ sections on www.gaggia.com or www.gaggia.it or

contact the Customer Service Centre in your country.

Problem Cause Solution

The machine does not

switch on.

The machine is not connected. Check that the power cord has been inserted

correctly.

The drip tray lls quickly. This is normal. The machine uses

water to rinse the internal circuit

and the brew group. Part of the

water ows through the internal

system directly into the drip tray.

Empty the drip tray when the red indicator

emerges from the grid of the drip tray.

Tip: Place a cup under the dispensing spout to

gather the rinse water.

The display

continuously shows the

"coffee pucks container

full" icon.

The coffee pucks container has

been emptied when the machine

was off.

Always empty the coffee pucks container when

the machine is on. If you empty the coffee

pucks container when the machine is off, the

coffee cycle counter does not reset. In this

case, the display shows the icon even if the

container is not full.

The coffee pucks container has

been put back too quickly.

Always wait about 5 seconds when you replace

the coffee pucks container. This way, the

counter will reset to zero.

The machine says to

empty the coffee pucks

container even if the

container is not full.

The machine has not reset the

counter last time the coffee pucks

container has been emptied.

Always wait about 5 seconds when you replace

the coffee pucks container. This way, the

coffee grounds counter will reset to zero.

Always empty the coffee pucks container when

the machine is on. If you empty the coffee

pucks container when the machine is off, the

coffee cycle counter does not reset.

Impossible to remove

the brew group.

The brew group is not in the correct

position.

Close the service door. Switch the machine off

and then back on. Wait for the display to show

the ready message, then remove the brew

group.

The coffee pucks container has not

been removed.

Remove the coffee pucks container before

removing the brew group.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 28 23/10/2020 11:32:41

English

Problem Cause Solution

The brew group cannot

be inserted.

The brew group is not in the correct

position.

The brew group has not been positioned

correctly before being placed back. Ensure that

the lever is in contact with the base of the brew

group and that the hook of the brew group is

in its correct position. See the "Reinserting the

brew group" chapter.

To reset the machine: put the coffee pucks

container back in place. Do not insert the brew

group. Close the service door with the coffee

pucks container inserted, then unplug and plug

in the power cord. Then try to reinsert the brew

group and switch on the machine.

The espresso does not

have enough crema or it

is watery.

The coffee grinder is set to a

coarse grinding.

Adjust the coffee grinder to a ner setting.

The machine is performing the self-

adjustment.

Dispense several cups of coffee so that the

machine regulates itself automatically.

The coffee outlet duct is clogged. Clean the coffee outlet duct with a spoon as

described in the "Cleaning the brew group

under running water" chapter.

The coffee dispensed is

not hot enough.

The set temperature is too low.

Check the menu settings.

Set the menu temperature to "MAX".

The machine grinds the

coffee beans, but the

coffee is not dispensed.

The coffee grinder is set to a too

ne grinding.

Adjust the coffee grinder to a coarser setting.

The coffee dispensing spout is

blocked.

Dispense a long coffee from pre-ground coffee

but without actually adding pre-ground coffee.

The nozzles of the coffee

dispensing spout are blocked.

Clean the nozzles of the coffee dispensing

spout with a small bottlebrush.

Coffee is dispensed

slowly or by drips.

The coffee grinder is set to a too

ne grinding.

Adjust the coffee grinder to a coarser setting.

The nozzles of the coffee

dispensing spout are blocked.

Clean the nozzles of the coffee dispensing

spout with a small bottlebrush.

The machine circuit is clogged by

limescale.

Descale the machine.

The milk does not froth. The Classic Pannarello may be

dirty.

Clean the Classic Pannarello as described in

the chapter "Cleaning the Classic Pannarello".

Make sure that all the Classic Pannarello

components have been correctly assembled.

The type of milk used is not

suitable for foaming.

The amount and the quality of froth vary

depending on the type of milk.

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 29 23/10/2020 11:32:42

English

Problem Cause Solution

The "INTENZA+" lter

cannot be inserted.

Remove the air from the lter. Let the air bubbles ow out of the lter.

The tank still contains some water. Empty the water tank before installing the lter.

The rubber seal is not inserted on

the "INTENZA+" lter.

Check the packaging and insert the seal on the

"INTENZA+" lter.

There is some water

under the machine.

The drip tray is too full and has

spilled over.

Empty the drip tray when the red indicator

emerges from the grid of the drip tray. Always

empty the drip tray before starting the

descaling procedure.

GAGGIA Accessories

Coffee and accessories are available through authorised centres (Italy),

or distributors in your country.

Descaling product INTENZA+ water lter Coffee oil remover

Range of coffee available in beans and pre-ground: 100% Arabica / Intense / Decaffeinated

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 30 23/10/2020 11:32:44

English

Technical Specications

Nominal voltage - Power rating -

Power supply

See data plate on the inside of the

service door

Housing material Thermoplastic type

Dimensions (Style) 260 x 345 x 440 mm

Dimensions (Plus) 260 x 380 x 440 mm

Weight (Style) 8.2 kg

Weight (Plus) 9 kg

Power cord length 1200 mm

Control panel Front panel

Cup size (Style) Up to 110 mm

Cup size (Plus) Up to 150 mm

Water tank 1.8 litres - Removable type

Coffee bean container capacity 250 g

Coffee pucks container capacity 10

Pump pressure 15 bar

Boiler Stainless steel boiler

Safety devices Thermal Fuse

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 31 23/10/2020 11:32:44

Nederlands

Inhoudsopgave

Overzicht van de machine (afb. 2) .........................................................................................................................................................................................................................................................................................................................................................................................................................33

Bedieningspaneel en display ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................34

Overzicht van het controlepaneel (afb. 1) ....................................................................................................................................................................................................................................................................................................................................................................................................34

Multifunctietoetsen ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................34

Eerste installatie ...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................35

Handmatige spoelcyclus ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................35

Meting van de waterhardheid ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................36

Waterlter INTENZA+ .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................36

Installatie van het waterlter INTENZA+ ............................................................................................................................................................................................................................................................................................................................................................................................................37

Vervanging van het waterlter INTENZA+ ................................................................................................................................................................................................................................................................................................................................................................................................37

Type drank ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................38

Espresso tray (enkel voor het model Cadorna Plus) ...............................................................................................................................................................................................................................................................................38

Ko󰀩eafgifte ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................39

Afgifte van ko󰀩e met ko󰀩ebonen ....................................................................................................................................................................................................................................................................................................................................................................................................................................................39

Afgifte van de ko󰀩e met voorgemalen ko󰀩e .................................................................................................................................................................................................................................................................................................................................................................................39

Melk opschuimen ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................40

Afgifte van heet water .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................41

Aanpassing van de dranken en creatie van een proel ........................................................................................................................................................................................................................................................41

Aanpassing van de dranken .....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................41

Een nieuw proel aanmaken ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................43

Instelling van de maaljnheid ................................................................................................................................................................................................................................................................................................................................................................................................................................................................44

Reiniging en onderhoud ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................44

Reinigingstabel ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................44

Reiniging van de klassieke pannarello .....................................................................................................................................................................................................................................................................................................................................................................................................46

Reiniging van de zetgroep .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................46

Invetten van de zetgroep ...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................49

Ontkalking .........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................50

Frequentie van de ontkalking ...............................................................................................................................................................................................................................................................................................................................................................................................................................................................................50

Wat te doen in geval van onderbreking van de ontkalkingsprocedure ......................................................................................................................................................................................................................51

Verschillende instellingen .............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................51

Taal ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................51

Waterlter .......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................52

Waterhardheid ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................52

Meeteenheid .....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................52

Drankenteller ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................52

Fabrieksinstellingen herstellen ......................................................................................................................................................................................................................................................................................................................................................................................................................................................................52

Betekenis van de foutcodes ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................53

Oplossing van problemen ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................54

Accessoires GAGGIA ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................56

Technische gegevens ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................57

4219-450-06381 MAN. GAG. CADORNA Style_Plus EN-NL-PL Rev 01.indd 32 23/10/2020 11:32:45
