Flying the aircraft with touch control or the Remote Controller.
Up
Left Stick Right Stick
Down
Forward
Backward
Left Right
Turn RightTurn Left
Controls
V1.2
SPARK
Designed by DJI. Printed in China.
SPARK is a trademark of DJI.
Copyright © 2017 DJI All Rights Reserved.
※This content is subject to change without prior notice.
●
Aircraft
Weight 300 g
Dimensions 143×143×55 mm
Max Speed 31 mph (50 kph) in Sport Mode without wind
Operating Temperature 32° to 104° F (0° to 40° C)
●
Camera
Sensor 1/2.3” CMOS Effective pixels: 12 Megapixels
Video Recording Modes FHD: 1920×1080 30p
Lens 25 mm (35 mm format equivalent), f/2.6
●
Remote Control Device
Operating Frequency 2.4 GHz / 5.8 GHz
Max Transmission Distance Wi-Fi: 100 m (Distance), 50 m (Height)
(Unobstructed, free of interference) Remote Controller:
2.4 GHz: 2000 m (FCC), 500 m (CE), 500 m (SRRC)
5.8 GHz: 2000 m (FCC), 300 m (CE), 1200 m (SRRC)
●
Charger
Input 100-240 V, 50/60 Hz, 0.5 A
Output 5 V 3 A / 9 V 2A / 12 V 1.5 A
●
Intelligent Flight Battery
Capacity 1480 mAh
Battery Type LiPo 3S
Charging Temperature 41° to 104° F (5° to 40° C)
Specifications
For more information, read the User Manual:
http://www.dji.com/spark
Quick Start Guide
1. Gimbal and Camera
2. Vision System
3. 3D Sensing System
4. Intelligent Flight Battery
5. External Charging Contact
6. Motors
7. Propellers
8. Front LEDs
9. Aircraft Status
Indicators
SPARK
The DJI™ SPARK™ is DJI's smallest flying camera featuring a stabilized
camera, Intelligent Flight Modes, and Obstacle Avoidance inside a light,
portable body. Equipped with a Vision System and 3D Sensing System*.
Spark can film 1080P videos, capture 12-megapixel photos, and is capable
of QuickShot and Gesture Control. With a maximum flight speed of 31 mph
(50 kph), and a maximum flight time of 16 minutes**, Spark is quick and fun,
making drone photography exciting, simple and professional.
* The Vision System and 3D Sensing System are affected by surrounding conditions.
For more information, please read the Disclaimer and Safety Guidelines or watch the
tutorial in the DJI GO
TM
4 app or on the Official DJI website: http://www.dji.com/spark
** Maximum flight time was tested in windless conditions flying at a consistent 12.4 mph
(20 kph). This value should be taken for reference only.
10. Micro USB Port
11. Micro SD Card Slot
12. Battery Level Indicators
13. Power Button
8
9
1
2
3
5
6
7
4
10
11
12
13
Download the DJI GO 4 App
You can find your Wi-Fi network name (SSID) and password on the storage box.
Please refer to the User Manual to change or reset your Wi-Fi password.
Search for ‘DJI GO 4’ on the App Store or Google
Play, or scan the QR code to download the app on
your mobile device.
DJI GO 4 is supported in iOS 9.0 (or later) or Android 4.4 (or later).
Press once to check the battery level.
Press once, then again and hold to
turn on/off.
The battery is fully charged when
the battery level indicators turn off.
Charge time: ~ 1 hr 20 min
Power Outlet
100~240 V
USB Charger Micro USB Port
HighLow
Prepare the Battery
Charge the battery for the first time to
activate it.
Activation
Launch DJI GO 4, tap the icon in the upper right corner, scan the
QR Code on the storage box, and follow the prompt for activation.
Use your DJI account to activate the aircraft. Activation requires an internet connection.
Internet
Power on the aircraft Connect to Wi-Fi with
your mobile device
Launch DJI GO 4
Spark-XXX
DJI GO 4
App
Connection
1. Gimbal and Camera
2. Vision System
3. 3D Sensing System
4. Intelligent Flight Battery
5. External Charging Contact
6. Motors
7. Propellers
8. Front LEDs
9. Aircraft Status
Indicators
SPARK
The DJI™ SPARK™ is DJI's smallest flying camera featuring a stabilized
camera, Intelligent Flight Modes, and Obstacle Avoidance inside a light,
portable body. Equipped with a Vision System and 3D Sensing System*.
Spark can film 1080P videos, capture 12-megapixel photos, and is capable
of QuickShot and Gesture Control. With a maximum flight speed of 31 mph
(50 kph), and a maximum flight time of 16 minutes**, Spark is quick and fun,
making drone photography exciting, simple and professional.
* The Vision System and 3D Sensing System are affected by surrounding conditions.
For more information, please read the Disclaimer and Safety Guidelines or watch the
tutorial in the DJI GO
TM
4 app or on the Official DJI website: http://www.dji.com/spark
** Maximum flight time was tested in windless conditions flying at a consistent 12.4 mph
(20 kph). This value should be taken for reference only.
10. Micro USB Port
11. Micro SD Card Slot
12. Battery Level Indicators
13. Power Button
8
9
1
2
3
5
6
7
4
10
11
12
13
Download the DJI GO 4 App
You can find your Wi-Fi network name (SSID) and password on the storage box.
Please refer to the User Manual to change or reset your Wi-Fi password.
Search for ‘DJI GO 4’ on the App Store or Google
Play, or scan the QR code to download the app on
your mobile device.
DJI GO 4 is supported in iOS 9.0 (or later) or Android 4.4 (or later).
Press once to check the battery level.
Press once, then again and hold to
turn on/off.
The battery is fully charged when
the battery level indicators turn off.
Charge time: ~ 1 hr 20 min
Power Outlet
100~240 V
USB Charger Micro USB Port
HighLow
Prepare the Battery
Charge the battery for the first time to
activate it.
Activation
Launch DJI GO 4, tap the icon in the upper right corner, scan the
QR Code on the storage box, and follow the prompt for activation.
Use your DJI account to activate the aircraft. Activation requires an internet connection.
Internet
Power on the aircraft Connect to Wi-Fi with
your mobile device
Launch DJI GO 4
Spark-XXX
DJI GO 4
App
Connection
Flying the aircraft with touch control or the Remote Controller.
Up
Left Stick Right Stick
Down
Forward
Backward
Left Right
Turn RightTurn Left
Controls
V1.2
SPARK
Designed by DJI. Printed in China.
SPARK is a trademark of DJI.
Copyright © 2017 DJI All Rights Reserved.
※This content is subject to change without prior notice.
●
Aircraft
Weight 300 g
Dimensions 143×143×55 mm
Max Speed 31 mph (50 kph) in Sport Mode without wind
Operating Temperature 32° to 104° F (0° to 40° C)
●
Camera
Sensor 1/2.3” CMOS Effective pixels: 12 Megapixels
Video Recording Modes FHD: 1920×1080 30p
Lens 25 mm (35 mm format equivalent), f/2.6
●
Remote Control Device
Operating Frequency 2.4 GHz / 5.8 GHz
Max Transmission Distance Wi-Fi: 100 m (Distance), 50 m (Height)
(Unobstructed, free of interference) Remote Controller:
2.4 GHz: 2000 m (FCC), 500 m (CE), 500 m (SRRC)
5.8 GHz: 2000 m (FCC), 300 m (CE), 1200 m (SRRC)
●
Charger
Input 100-240 V, 50/60 Hz, 0.5 A
Output 5 V 3 A / 9 V 2A / 12 V 1.5 A
●
Intelligent Flight Battery
Capacity 1480 mAh
Battery Type LiPo 3S
Charging Temperature 41° to 104° F (5° to 40° C)
Specifications
For more information, read the User Manual:
http://www.dji.com/spark
Quick Start Guide
