ITEM NO:901484
ASSEMBLY INSTRUCTIONS
Assembly Instructions
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present
prior to start of assembly.
3.please follow attached attached instructions in the same sequence
as numbered to assure fast & easy assembly.
Warning!
1.Don't attempt to repair or modify parts that are broken
or defective.Please contact the store immediately.
2.This product is for home use only and not intended for
commercial establishment.
PARTS IDENTIFICATION: HARDWARE PACKAGE
DECRIPTION FIGURE Q'TY NO DECRIPTION FIGURE Q'TY
A BASE 1PC 1 LARGE WASHER 1PC
B MAIN POLE 1PC 2 SMALL WASHER 1PC
C OUTER SHADE 3PCS 3 NUT 1PC
D ARMS
1SET
4 WRENCH 1PC
5 SCREW 1PC
E RING 1PC
6 HOLLOW SCREW 1PC
F LIGHT BULB 3PCS
PAGE 2 OF 3
