User’s Guide
Model: Sky® Lite
Sky® Lite Laser Projector
Please ONLY use
manufacturer-provided
USB cord and adapter.
LASER RADIATION
DO NOT STARE INTO THE BEAM
CLASS 2 LASER PRODUCT
Diode Laser - Max. Output < 1 mW
Wavelength 400-700 nm
EC 62472 Risk Group 1
Classied per IEC 60825-1 Ed. 3.0.2014
TABLE OF CONTENTS
Notice ..............................................................................................................................1
Introduction ..................................................................................................................2
Before You Begin ..........................................................................................................2
Parts List ..........................................................................................................................2
Setting up the Laser Projector ................................................................................3
Default Settings ...........................................................................................................3
Installation Tips ............................................................................................................4
Product Specications ............................................................................................... 4
Limited Warranty .........................................................................................................5
Caution ............................................................................................................................ 5
Cleaning Instructions .................................................................................................5
Disposal...........................................................................................................................5
1
NOTICE
CAUTION—Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This product is classied as a Class 2 laser product and complies with the applicable parts
of IEC/EN 60825-1 Ed. 2.0:2007 and Ed. 3.0:2014. The manufacturer additionally certies it
complies with the US FDA Federal Laser Product Performance Standard (FLPPS) provided in
21 CFR Subchapter J, 1040.10 and 1040.11 except for allowable deviations specied in FDA
Guidance documents.
Do not stare into the beams emitted from the product. Intentional long term viewing of
CLASS 2 levels of laser light can be hazardous. This product uses diractive optics to scatter
the beam energy. This scattering eect causes the energy concentration to drop below
the exposure limits for momentary or accidental viewing at a relatively short distance
from the laser aperture. As with all bright light-sources, when you operate this device in
unsupervised general public areas, it is recommended that up-close access to the light
be restricted or prevented and the beams be directed into locations were persons are not
expected.
This laser display device incorporates a CLASS 3B laser system which, by itself, may be
hazardous. However, this laser display product incorporates a protective housing and
diractive optics in its design so that there is no exposure or human access to laser
radiation during operation or maintenance above the CLASS 2 limits. Each individual laser
beamlet’s power is below the Class 2 limit of 1 mW.
UNDER NO CIRCUMSTANCES shall attempts be made to open the protective housing or
operate the device if the aperture window is damaged.
All service to this laser display device requiring the protective housing to be opened and/
or removed shall be performed by service personnel or their authorized agents. Opening
the protective housing voids the warranty.
NO LASERS SHOULD BE POINTED INTO THE Sky WITHIN 10 NAUTICAL MILES
(18.5 km) OF AN AIRPORT. IF YOU ARE LOCATED WITHIN THIS SPECIFIC PERIMETER, WE
RECOMMEND THE LASERS BE POINTED DOWN AT THE GROUND SO NO STRAY BEAMS
ARE PROJECTED INTO THE AIR. CHECK WITH YOUR LOCAL AIRPORT OR PROVINCIAL
GUIDELINES FOR FURTHER INFORMATION.
2
INTRODUCTION
Thank you for purchasing the BlissLights Sky® Lite Laser Galaxy Projector. This product is a
unique indoor light xture that uses patented laser and holographic technology to project
thousands of moving pin-points of light against a transforming nebula cloud. Sleep under
the stars, create a romantic starlit dinner, or take your home entertainment center to the
next level. We hope you enjoy this incredibly unique lighting experience.
Each unit provides up to 30 x 30 ft of coverage. It has maximum electrical usage of less than
5 Watts and operates in temperatures between 14°F to 95°F (-10°C to 40°C).
BEFORE YOU BEGIN
Immediately upon receiving the xture, carefully unpack and check the carton contents to
ensure that all parts are present and in good condition. Notify the retailer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the
carton itself shows signs of mishandling. Save the carton and all packing materials. In the
event that the xture must be returned, it is important that the xture be returned in the
original factory box. Please see parts list below for box contents.
PARTS LIST:
1) Laser Projector
2) USB-C Power Cord
3) Power adapter
Please note: Included adapter may vary
from picture shown.
1
2
3
3
Before operating your laser projector, please read the “Before you Begin” section and
“Notice” section of this user’s guide.
SETTING UP THE LASER PROJECTOR
1. Remove protective lm sticker from laser aperture.
2. Insert the USB power cord into a powered USB port or use the included wall adapter
to connect to an available electrical outlet. It is best practice for users to connect the
power adapter to the wall before connecting the device to the power adapter.
3. Place the Sky® Lite on a at solid surface and aim toward desired ceiling/wall.
4. Press the power button. The nebula and laser stars will gradually illuminate
and begin moving by default.
5. To adjust the illumination angle for walls, tilt the light forward onto the secondary
support panel.
6. To turn o the light, cycle through the power button modes until the unit turns o
completely. Remove the power plug from electrical outlet.
7. Use the following buttons to control lighting eects:
Top button (eects):
• Power on
• Pulse mode
• Stars only
• Cloud only
• Power o
Middle button (rotation):
• Rotation o
• Rotation on
Bottom button (brightness):
• Normal
• Low
• High
DEFAULT SETTINGS
Once the laser projector is plugged in, it will enter the default mode where all eects are
on. Use the buttons to change the eect settings and brightness. This light has a built-in
timer that is designed to automatically shut o after 6 hours of operation.
4
PRODUCT SPECIFICATIONS
Designed in the USA
By BlissLights LLC
100 E San Marcos Blvd
San Marcos, CA 92069
Made in China
INSTALLATION TIPS
• Do not connect the light to a dimmer pack, as a dimmer accessory may damage
the laser component.
• The darker the display area, the brighter your projection will appear.
Laser Classication Class 2
Laser Color Blue - 445nm
Nebula Cloud Color Blue - 450nm
Housing ABS plastic
Power consumption Less than 5 W
USB Power Adapter Input 100-240 V ~ 50/60 Hz , 0.2 A
USB Power Adapter Output 5V --- 1A
Operation Indoor
Operating Temperature 14°F to 95°F (-10°C to 40°C)
Projection Coverage Laser - 30 x 30 ft Nebula cloud - 15 x 15ft
Maintenance Maintenance Free
Dimensions 6.5”L x 2.5”W x 6.5”H
Cord Length 5 ft (1.5 m)
5
BLISSLIGHTS LIMITED WARRANTY
This product carries a limited warranty against defects in workmanship and materials. BlissLights
LLC agrees to replace the defective product free of charge within the stated warranty period, when
returned by the original purchaser with proof of purchase. This product is not guaranteed against
wear or breakage due to misuse and/or abuse. For detailed warranty information for your country,
please visit www.blisslights.com/warranty
CAUTION
This is not a toy. Young children must be supervised while using this device at all times.
This unit is not waterproof. Use and store indoors or in a dry place.
CLEANING INSTRUCTIONS
Surface clean only with a soft, dry cloth. Unplug unit before cleaning.
DISPOSAL
At the end of its serviceable life, this product should not be treated as household or general waste. It
should be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.
www.blisslights.com
