Dimplex DFI2310 Deluxe 23" Electric Fireplace Inser

User Manual - Transcript

• Page 1 - English - : Owners Manual Model DFI2309 DFI2310 7205650300R03 IMPORTANT SAFETY INFORMATION Always read this manual rst before attempting to install or use this replace For your safety always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage To view the full line of Dimplex products please visit wwwdimplexcom
• Page 2 - English - : 2 wwwdimplexcom Table of Contents Always use a qualied technician or service agency to repair this replace NOTE Procedures and techniques that are considered important enough to emphasize CAUTION Procedures and techniques which if not carefully followed will result in damage to the equipment WARNING Procedures and techniques which if not carefully followed will expose the user to the risk of re serious injury or death Welcome amp Congratulations 3 IMPORTANT INSTRUCTIONS 4 Fireplace Installation 7 Operation 9 Maintenance 11 Warranty 13 Replacement Parts 16
• Page 3 - English - : Welcome amp Congratulations Thank you and congratulations for choosing to purchase an electric replace from Dimplex the world leader in electric replaces Please carefully read and save these instructions CAUTION Read all instructions and warnings carefully before starting installation Failure to follow these instructions may result in a possible electric shock re hazard and will void the warranty Please record your model and serial numbers below for future reference model and serial numbers can be found on the Model and Serial Number Label of your replace NO NEED TO RETURN TO THE STORE Questions with operation or assembly Require Parts Information Product Under Manufacturers Warranty Contact us at wwwdimplexcomcustomersupport For Troubleshooting and Technical Support OR TollFree 1888DIMPLEX 18883467539 Monday to Friday 800 am to 430 pm EST Please have your model number and product serial number ready See above Model Number Serial Number
• Page 4 - English - : 4 wwwdimplexcom IMPORTANT INSTRUCTIONS When using electrical appliances basic precautions should always be followed to reduce the risk of fire electric shock and injury to persons including the following ① Read all instructions before using this heater ② This heater is hot when in use To avoid burns do not let bare skin touch hot surfaces The trim around the heater outlet becomes hot during heater operation Keep combustible materials such as furniture pillows bedding papers clothes and curtains at least 3 feet 09 m from the front of the heater and keep them away from the sides and rear ③ Extreme caution is neces sary when any heater is used by or near children or invalids and whenever the unit is left operating and unattended ④ Always unplug the heater when not in use ⑤ Do not operate any heater after it malfunctions Disconnect power at the service panel and have the heater inspected by a reputable electrician before reus ing ⑥ Do not operate any unit with a damaged cord or plug or if the heater has malfunctioned or if the electric replace has been dropped or damaged in any man ner contact Dimplex Technical Service at 18883467539 ⑦ Do not use outdoors ⑧ This heater is not intended for use in bathrooms laundry ar eas and similar indoor locations Never locate this heater where it may fall into a bathtub or other water container ⑨ Do not run cord under carpet ing Do not cover cord with throw rugs runners or the like Arrange cord away from trafc area and where it will not be tripped over ⑩ To disconnect heater turn controls to off then remove plug from outlet ⑪ Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or re or damage the heater ⑫ To prevent a possible re do not block air intakes or exhaust in any manner ⑬ All electrical heaters have hot and arcing or sparking parts
• Page 5 - English - : SAVE THESE INSTRUCTIONS IMPORTANT INSTRUCTIONS inside Do not use in areas where gasoline paint or ammable liquids are used or stored ⑭ Do not modify the heater Use it only as described in this man ual Any other use not recom mended by the manufacturer may cause re electric shock or injury to persons ⑮ This unit may have a polarized plug one blade is wider than the other The plug will t in a polar ized outlet only one way If the plug does not t fully in the outlet reverse the plug If it still does not t contact a qualied electrician to install the proper outlet ⑯ Always plug heaters directly into a wall outletreceptacle Never use with an extension cord or relocatable power tap outlet power strip ⑰ Do not burn wood or other materials in the Fireplace ⑱ Do not strike the front glass ⑲ Always use a certied electri cian should new circuits or outlets be required ⑳ Always use properly grounded fused and polarized outlets ㉑ Do not install the replace directly on carpet or a similar surface which may restrict air circulation beneath the unit ㉒ Disconnect all power supply before performing any cleaning maintenance or relocation of the heater ㉓ When transporting or storing the heater and cord keep in a dry place free from excessive vibration and store so as to avoid damage CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN NO USERSERVICEABLE PARTS INSIDE
• Page 6 - English - : 6 wwwdimplexcom IMPORTANT INSTRUCTIONS This equipment has been tested and found to comply with the limits for Class B digital device pursuant to part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio or television reception which can be determined by turning the equipment off and on the user is encouraged to try to correct the interference by one or more of the following measures Reorient or relocate the receiving antenna Increase the separation between the equipment and the receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radioTV technician for help Operation is subject to the following two conditions 1 this device may not cause interference and 2 this device must accept any interference including interference that may cause undesired operation of the device WARNING Remote control contains small batteries keep away from children If swallowed seek medical attention immediately WARNING Do not install battery backwards charge put in re or mix with used or other battery types may explode or lead causing injury NOTE Changes or modications not expressly approved by the party responsible for compliance could void users authority to operate the equipment
• Page 7 - English - : Fireplace Installation WARNING Ensure the power cord is not installed so that it is pinched or against a sharp edge and ensure that the power cord is stored or secured to avoid tripping or snagging to reduce the risk of re electric shock or injury to persons WARNING Construction and electrical outlet wiring must comply with local building codes and other applicable regulations to reduce the risk of re electric shock and injury to persons WARNING Do not attempt to wire your own new outlets or circuits To reduce the risk of re electric shock or injury to persons always use a licensed electrician WARNING To reduce the risk of re do not store or use gaso line or other ammable vapors or liquids in the vicinity of the heater CAUTION High temperature risk of re keep electrical cords drapery furnishings and other combustibles at least 3 ft 09 m from the front of the heater NOTE A 15amp 120volt cir cuit is required A dedicated cir cuit is preferred but not essential in all cases A dedicated circuit will be required if after installa tion the circuit breaker trips or the fuse blows on a regular basis when the heater is operating Ad ditional appliances on the same circuit may exceed the current rating of the circuit breaker CAUTION Clearance for air circulation beneath the replace insert is provided by two rubber feet Do not install the replace insert directly on carpet or similar surfaces which may restrict air circulation CAUTION If installing the replace in a carpeted area place a onepiece solid at surface under the replace Ensure that both of the feet rest securely on this surface NOTE The electric insert must be installed in an opening with the minimum dimensions 24 in 61 cm wide 215 in 546 cm high and 12 in 305 cm deep The replace does not require any additional venting Figure 1 Existing Fireplace 1 Seal all drafts and vents with a nonbrous insulation material to prevent any chimney debris from falling onto the replace Do not install into an existing
• Page 8 - English - : 8 wwwdimplexcom Fireplace Installation replace that is prone to damp ness 2 Cap the top of the chimney ue to prevent rain from entering 3 Plan your electric power sup ply 4 Install an outlet into the exist ing replace If an outlet is not installed into the existing re place the power cord can also run along the front of the hearth to an outlet near the replace 5 Ensure the insert power is off see Operation Plug the insert into the outlet and slide the unit into the existing replace 6 Push the insert into the rebox and center within the open ing Adjust the four feet on the bottom of the insert by turning counter clockwise to raise and clockwise to lower so that is level with the existing replace hearth 7 Install the trim kit onto the re place insert if applicable and push the trim and or insert back until the trim is at against the nished wall WARNING The replace insert can be used with existing replace and screens Due to the heat produced from the heater existing replace screens must provide adequate air ow in front of the unit Do not use existing replace doors that close sealing off the replace insert from the room If installed behind bifold doors doors must be open to allow heat to be exhausted WIRING CONTROL RECEIVER REMOTE FLICKER MOTOR SWITCH 3POSITION SWITCH LOW HEAT SWITCH HIGH HEAT MOTOR THERMAL CUTOUT ELEMENT L N M CAPACITOR LED LOGS LED DRIVER BOARD DFI2310 ONLY LOWER LIGHTS
• Page 9 - English - : WARNING This electric rebox must be properly installed before it is used Manual Controls A 3Position Switch The switch has two On positions marked with I and II The I position is for manual operation In this position the builtin remote control is bypassed The II position is for operating the unit with the provided remote control When in II position the unit is operated with the ON and OFF buttons of the remote con trol When the switch is in the center O position the unit is off B Low Heat OnOff Switch The Low Heat OnOff Switch supplies power to the heater fan Figure 1 Operation and the heater element When the switch is in the ON position the heater operates on LOW C High Heat Switch The High Heat OnOff Switch supplies power to the heater fan and the heater element when the switch is in the ON position the heater operates on HIGH The Low Heat Switch must also be in the ON position for the high heat setting to operate NOTE The heater on your replace may emit a slight harmless odor when rst used This odor is a normal condition caused by the initial heating of internal heater parts and will not occur again Resetting the Temperature Cut off Switch The heater is protected with a ABC
• Page 10 - English - : 10 wwwdimplexcom Operation safety device to prevent overheat ing Should the heater overheat an automatic cut out will turn the heater off and it will not come back on without being reset It can be reset by switching the 3Position Switch Figure 1A to Off O position and waiting ve minutes before switching the unit back on CAUTION If you need to continuously reset the heater unplug the unit and call your local dealer Remote Control Figure 2 The replace is supplied with an integrated OnOff remote control NOTE Ensure that the re places 3Position Switch is set to the remote control setting II position To operate push the ON button to turn replace on push the OFF button to turn the replace off NOTE Before attempting any operation with the remote pull the plastic insulator strip out from between the remote cas ing and battery cover Remote Control Initialization Reprogramming In the event that your remote control ceases to operate your replace follow these steps to reinitialize the remote controland the remote control receiver in the replace 1 Place the 3Position Switch Figure 1A in the Off O position 2 Wait a minimum of ve sec onds and then place the 3Position Switch in the Re mote Control II position 3 Within 10 seconds of chang ing the switch position press the ON button located on the remote control Figure 2 This will synchronize the remote control and the replace receiver NOTE You will have only 10 seconds to perform this last step Failure to do so will result Figure 2 Off Button On Button Battery cover Plastic strip
• Page 11 - English - : Maintenance WARNING Disconnect power before attempting any main tenance or cleaning to reduce the risk of re electric shock or damage to persons NOTE The replace should not be operated with an accumu lation of dust or dirt on or in the unit as this can cause a build up of heat and eventual damage For this reason the heater must be inspected regularly depending upon conditions and at least at yearly intervals Light Bulb Replacement Light bulbs need to be replaced when you notice a dark section of the ame There are two bulbs under the log set which generate the ames and embers Light Bulb Requirements Quantity 2 clear chandelier or candelabra bulbs with an E12 small socket base 60 Watt rat ing Example GE 60BC or Philips 60CTCDo not exceed 60 Watts per bulb Replacement CAUTION Allow at least 10 minutes for the light bulbs and heater to cool before attempt ing any maintenance or clean ing 1 With a Phillips screwdriver remove the screws from the Log Grate Figure 3 2 Remove the Log Set by lifting straight up NOTE Log Set ts tightly in these steps needing to be followed again Battery Replacement To replace the battery 1 Slide battery cover open on the hand held transmitter 2 Correctly install one 12 Volt A23 battery in the battery holder 3 Close the battery cover Battery must be recycled or disposed of properly Check with your Local Authority or Retailer for recycling advice in your area Operation
• Page 12 - English - : 12 wwwdimplexcom Figure 3 Log Set Light Bulbs 2 LED Wire Harness DFI2310 only x4 Log Grate into rebox some force may be necessary to remove 3 Disconnect the Log Set LED Wire Harness from the unit DFI2310 only 4 Unscrew the bulbs counter clockwise 5 Insert and install new bulbs 6 Reconnect the Log Set LED Wire Harness to unit DFI2310 only 7 Replace the Log Set into the insert 8 Replace Log Grate and install screws from step 2 Maintenance Glass Cleaning The glass is cleaned in the factory during the assembly operation During shipment installation handling etc the glass surface may collect dust particles these can be removed by bufng lightly with a clean dry cloth To remove ngerprints or other marks the glass can be cleaned with a damp cloth using a good quality household glass cleaner The glass should be completely dried with a lint free cloth or paper towel Do notuse abrasive clean ers on glass surface or spray
• Page 13 - English - : One Year Limited Warranty Products to which this limited warranty applies This limited warranty applies to the fol lowing models of your newly purchased Dimplex electric replace 6901470100 DFI2309 6901470200 DFI2310 and to newly purchased Dimplex replace sur rounds mantels and trims This limited warranty applies only to purchases made in any province of Canada except for Yukon Territory Nunavut or Northwest Territories or in any of the 50 States of the USA and the District of Columbia except for Hawaii and Alaska This limited war ranty applies to the original purchaser of the product only and is not transferable Products excluded from this limited warranty Light bulbs are not covered by this limited warranty and are the sole responsibil ity of the ownerpurchaser Products purchased in Yukon Territory Nunavut Northwest Territories Hawaii or Alaska are not covered by this limited warranty Products purchased in these States provinces or territories are sold AS IS without warranty or condition of any kind including without limitation any implied warranties or conditions of merchant ability or tness for a particular purpose and the entire risk of as to the quality and performance of the products is with the purchaser and in the event of a defect the purchaser assumes the entire cost of all necessary servicing or repair What this limited warranty covers and for how long Products covered by this limited warranty have been tested and inspected prior to shipment and subject to the provisions of this warranty Dimplex warrants such products to be free from defects in mate rial and workmanship for a period of 12 months from the date of the rst purchase of such product Warranty Maintenance liquids directly onto any surface Fireplace Surface Cleaning Use warm water only to clean painted surfaces of the Compact Fireplace Do not use abrasive cleaners Servicing Except for light bulb replacement and cleaning described above an authorized service representative should perform any other servicing
• Page 14 - English - : 14 wwwdimplexcom The limited 12 month warranty period also applies to any implied warranties that may exist under applicable law Some jurisdic tions do not allow limitations on how long an implied warranty lasts so the above limitation may not apply to the purchaser What this limited warranty does not cover This limited warranty does not apply to products that have been repaired except by Dimplex or its authorized service representatives or otherwise altered This limited warranty does further not apply to defects resulting from misuse abuse accident neglect incorrect installation improper maintenance or handling or operation with an incorrect power source What you must do to get service under this limited warranty Defects must be brought to the attention of Dimplex Technical Service by contacting Dimplex at 1888DIMPLEX 1888346 7539 or 1367 Industrial Road Cam bridge Ontario Canada N1R 7G8 Please have proof of purchase cataloguemodel and serial numbers available when calling Limited warranty service requires a proof of purchase of the product What Dimplex will do in the event of a defect In the event a product or part covered by this limited warranty is proven to be defec tive in material or workmanship during the 12 month limited warranty period you have the following rights Dimplex will in its sole discretion either repair or replace such defective prod uct or part without charge If Dimplex is unable to repair or replace such product or part or if repair or replace ment is not commercially practicable or cannot be timely made Dimplex may in lieu of repair or replacement choose to refund the purchase price for such product or part Limited warranty service will be performed solely by dealers or service agents of Dimplex authorized to pro vide limited warranty services The purchaser is responsible for removal and transportation of such product or part and any repaired or replacement product or part to and from the authorized dealers or service agents place of business This limited warranty does not entitle the purchaser to onsite or inhome services Onsite or inhome services may be performed at the purchasers specic request and expense at Dimplexs thencurrent rates for such services Dimplex will not be responsible for and the limited warranty services shall not include any expense incurred for installation or removal of the product or part or any replacement product or part or any labour or transporta tion costs Such costs shall be the purchasers responsibility What Dimplex and its dealers and service agents are also not responsible for IN NO EVENT WILL DIMPLEX OR ITS DIRECTORS OFFICERS OR AGENTS BE LIABLE TO THE PURCHASER OR ANY THIRD PARTY WHETHER IN CON TRACT IN TORT OR ON ANY OTHER BASIS FOR ANY INDIRECT SPECIAL PUNITIVE EXEMPLARY CONSEQUEN TIAL OR INCIDENTAL LOSS COST OR DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE SALE MAINTENANCE USE OR INABILITY TO USE THE PRODUCT EVEN IF DIMPLEX OR ITS DIRECTORS OFFICERS OR AGENTS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSSES COSTS OR DAMAGES OR IF SUCH LOSSES COSTS OR DAMAGES ARE Warranty
• Page 15 - English - : Warranty FORESEEABLE IN NO EVENT WILL DIMPLEX OR ITS OFFICERS DIREC TORS OR AGENTS BE LIABLE FOR ANY DIRECT LOSSES COSTS OR DAMAGES THAT EXCEED THE PUR CHASE PRICE OF THE PRODUCT SOME JURISDICTIONS DO NOT AL LOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO THE PURCHASER How State and Provincial law apply This limited warranty gives you specic legal rights and you may also have other rights which vary from jurisdiction to jurisdiction The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty
• Page 16 - English - : 16 wwwdimplexcom 2013 Dimplex North America Limited Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 Replacement Parts 3Position Switch 2800071100RP Low Heat OnOff Switch 2800070900RP High Heat OnOff Switch 2800071000RP Cordset 4100090101RP Heater Assembly 2200490800RP Cutout 2300270200RP Partially Reective Glass 5900350100RP Flicker Motor 2000220100RP Reector Assembly 5900340100RP Lamp Holder 4200121000RP Log Set DFI2309 0438200800RP DFI2310 LED 0439230200RP LED Log Set Driver 3000390100RP Remote Control Reciever 3000380200RP Remote Control 3000370500RP
