1. Overview
Inline Fan Instructions
The iPower Inline Fan utilizes the newest and advanced technology to offer an affordable air
movement solution with its features of low noise, large air volume, high static pressure. The
motor and the impellers are easy to install and clean.
2. Product Structure
•
The iPower Inline Fan is composed of the chassis, impeller, external rotor motor.
•
Chassis: Is made of high-quality, cold-rolled steel. The surface is treated with a kind
of plastic sealant to provide a strong resistance to corrosion. CAD optimizations on
the flow channel design to allow the impeller perform at its greatest efficiency. Inlet
and outlet diameter flanges are easy to install, repair and clean.
•
Impeller: The curved-end blade impeller works with the fan casing in harmony; the
fan can produce maximum air flow and efficiency while minimizing noise.
•
External Rotor Motor: A single-phase asynchronous external rotor motor is located
on the chassis. The impeller is attached directly to the rotor motor by die-casting.
The impeller is driven directly by rotor to minimize noise while providing high airflow
and extending service life.
3. Dimensions:
A---Air outlet and intake diameter B---Cylindrical chasse diameter
C---Length of a draft / Length of air inlet D---Total length of chasse
