Installation
Install the Hood:
If present, remove all protective polyfilm from the hood and/or parts.
This product can be installed in two different ways (Wall-mounted
and
Top-mounted
)
. Below
picture shows the 1:1 hole drawing of different installation
1)
step 1
Step 2 assemble the 7'' adapter to the top of the whole machine
27.8"
15"
8.86''
4.72''
6.93''
9.07''
1.67''
9.45"
30''
24.44''
5.58''
3.88''
18''
step 1 Install front baffle
step 2 assemble the 7'' adapter to the
top of the whole machine
use screws fixed
Use six
screws (0.16"*0.31")
Knock open (wire outlet)
for fixed
1
methods.
Wall-mounted
