AAAANND FACE (PLATE) LOCK IT UP
6 7
Cut out
this template
for STEP 2
Cutting
Template
Remember
the last time
you “winged it”?
2—1/8”
3—7/16”
Your Desired Location
1 2 3
THE SWEET SPOT TRACE CUT IT OUT
“I’d like
to play
a game”
“stay
in the
lines”
RUN A/V CABLES
BRACE YOURSELF
5
4
“are you
an inny or
an outy?”
#YourGearUpgraded
IN-WALL CABLE PASS THROUGH - SINGLE GANG
Model EGAV-CMIWPTSW
Installation Instructions
Doc. #1507328 11/19 Rev A
Confuzzled?
Contact the ECHOGEAR Pros:
helpmehelpyou@ECHOGEAR.com
1-855-428-2490
Grab Your Tools
Stud
Finder
Pencil
Drywall
Saw
Level Scissors
Slotted
Screwdriver
Tape
Measure
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ENTIRE MANUAL PRIOR TO USE
SAVE THESE INSTRUCTIONS
CAUTION: Avoid potential personal injuries and property damage!
● FOR LOW VOLTAGE CABLES ONLY.
● RISK OF FIRE - DO NOT install power supply cord within the wall cavity.
● Do not use this product for any purpose not explicitly specified by manufacturer.
● Manufacturer is not responsible for damage or injury caused by incorrect
assembly or use.
● If you do not understand these instructions or have doubts about the safety of
the installation, assembly or use of this product, contact The Echogear Pros at
www.echogear.com.
“apologies, to
all the Jacks
in the world”
Yea, the boring stuff ... but read it, so you don’t jack things up!
©2019 Legrand AV Inc.
All Rights Reserved.
ECHOGEAR is a Legrand AV Inc.
brand and a registered trademark
owned by Legrand.
Made in China.
Legrand AV Inc. • 6436 City West Parkway • Eden Prairie, MN 55344 USA
