A Division of Snow Joe
®
, LLC Model 24V-SS10-CT-RM Form No. SJ-24V-SS10-CT-RM-880E-V1
OPERATOR’S MANUAL
R
CORDLESS SNOW SHOVEL – CORE TOOL
10-INCH | 24V MAX*
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Read all instructions before using this cordless snow shovel.
Basic safety precautions should always be followed to reduce
the risk of re, electric shock and personal injury.
General Safety WARNINGS!
You and any other operator of this snow shovel must read,
understand and follow these instructions in their entirety, and
should reread them at the start of each snow season. Failure
to follow these instructions may result in ELECTRIC SHOCK,
FIRE and/or serious PERSONAL INJURY.
Notice the personal safety alert symbol
m used in this
manual to draw your attention to a WARNING given along
with the particular operating instruction. This means that
the operation requires special ATTENTION, CAUTION and
AWARENESS.
1. Keep work area clean and well lit – Cluttered, dark areas
invite accidents.
2. Use the right product – Do not use this machine for any
job except that for which it is intended.
3. Replacement parts – When servicing this unit, use only
identical replacement parts. Replace or repair damaged
cord immediately on the charger.
Do not use on gravel surfaces unless the snow shovel
is adjusted for such surfaces in accordance with the
operator’s manual.
4. Keep children, bystanders and pets away –
All spectators, including pets, should be kept a safe
distance away from the work area.
5. Dress properly – Do not wear loose articles of clothing or
jewelry. They can become caught in moving parts.
Wear rubber boots.
The cordless snow shovel should not be operated in the
hand-held position except when the instructions provided
in this manual deem such use permissible.
6. Avoid accidental starting – Make sure the safety
switch and the trigger switch are in the o position
before inserting the battery in the unit. Do not carry the
cordless snow shovel with the safety switch and the
trigger switch engaged.
7. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
8.
mCAUTION! Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
9. Use safety glasses – Also use safety footwear,
snug-tting clothing, protective gloves, hearing and head
protection.
10. Stay alert – Watch what you are doing. Use common
sense. Do not operate the cordless snow shovel when you
are tired or under the inuence of alcohol or drugs.
11. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it was designed.
12. Do not overreach – Keep proper footing and balance at
all times.
13. If the cordless snow shovel strikes a foreign object,
follow these steps:
• Stop the cordless snow shovel. Remove the battery.
• Inspect for damage.
• Repair any damage before restarting and operating
the snow shovel.
14. Disconnect the tool – Turn o the cordless snow shovel
and remove the battery when it is not in use, before
servicing it, when changing accessories and when
performing any other maintenance task.
15. Store idle tool indoors – When not in use, the cordless
snow shovel should be stored indoors in a dry, locked
place out of the reach of children.
16. Maintain the cordless snow shovel with care – Follow
the applicable maintenance instructions for replacing parts
and changing accessories. Lubrication is not required.
mThis is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
Improperly using or maintaining this cordless snow
shovel could result in injury or death. To reduce
this potential, comply with the following safety
instructions.
2
3
This cordless snow shovel can amputate hands and
feet if used incorrectly. It can also pick up foreign
objects, which can become dangerous projectiles
when thrown into the air. Failure to observe the
following safety instructions could result in serious
personal injury.
Training
• Read, understand and follow all instructions on the machine
and in the manual before operating this unit. Thoroughly
familiarize yourself with the controls and the proper use of
the equipment. Know how to stop the unit and disengage
the controls quickly.
• Children should never be allowed access to the equipment.
Adults should never operate the equipment without
carefully reading and understanding these instructions.
• Keep the area of operation clear of all persons, particularly
small children and pets.
• Exercise caution to avoid slipping or falling.
Preparation
• Thoroughly inspect the area where the equipment is to be
used and remove all doormats, sleds, boards, wires and
other foreign objects.
• Do not operate the equipment without wearing adequate
winter garments. Avoid loose tting articles of clothing that
can become caught in moving parts. Wear footwear that will
improve footing on slippery surfaces.
• Do not attempt to clear snow from a gravel or crushed
rock surface. This product is intended for use only on
paved surfaces.
• Never attempt to make any adjustments while the motor
is running (except when specically recommended by the
manufacturer).
• Always wear safety glasses or eye shields during operation
or while performing an adjustment or repair to protect your
eyes from foreign objects that may be thrown from the
machine.
Operation
• Do not put hands or feet near or under rotating parts.
Keep clear of the discharge opening at all times.
• Exercise extreme caution when operating on or crossing
gravel drives, walks or roads. Stay alert for hidden hazards
or trac.
• After striking a foreign object, stop the motor. Thoroughly
inspect the cordless snow shovel for any damage, and
repair the damage before restarting and operating the
cordless snow shovel.
• If the unit should start to vibrate abnormally, stop the motor
and check the unit immediately to ascertain the cause.
Vibration is generally a sign of trouble.
• Stop the motor and remove the battery whenever you leave
the operating position, when transporting the unit,
before unclogging the rotor blade housing and when
making any repairs, adjustments or inspections to the unit.
• When cleaning, repairing or inspecting the cordless snow
shovel, make sure that all moving parts have come to a
complete stop before beginning work.
• Exercise extreme caution when operating on slopes.
• Never operate the cordless snow shovel without proper
guards and other safety devices in place and in proper
working order.
• Never direct the discharge toward people or areas where
property damage can occur. Keep children, pets and other
bystanders away from the work area.
• Do not overload the machine capacity by attempting to
clear snow at too fast a rate.
• Look behind and use care when backing up with the
cordless snow shovel.
• Never operate the cordless snow shovel without good
visibility or light. Always be sure of your footing, and keep
a rm hold on the handles. Walk, never run, with the unit.
Clearing a Clogged Rotor Housing
Hand contact with the rotating rotor blades inside the rotor
housing is the most common cause of injury associated
with cordless snow shovels. Never use your hands to clear a
clogged rotor housing.
To clear the rotor housing:
• Shut the motor o and remove the battery.
• Wait 10 seconds to be sure the rotor blades have come to a
complete stop.
• Always use a clean-out tool, not your hands, to free the
rotating blades.
Maintenance and Storage
• Check all fasteners at frequent intervals for proper tightness
to ensure that the equipment is in safe working condition.
• Always refer to the operator's manual for important details,
such as how to properly store your cordless snow shovel
for an extended period of time.
• Maintain or replace safety and instruction labels as needed.
• Run the machine a few minutes after throwing snow to
prevent the rotor blades from freezing.
4
Battery + Charger
Safety Instructions
NOTE: This unit is a core tool. The battery and the charger are
not included. They must be purchased separately.
Model 24V-SS10-CT-RM is compatible with the iON+ 24V
System batteries and chargers. See page 14 for more
information.
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the cordless snow shovel and
cause it to malfunction, which can lead to serious personal
injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the
iON+ 24V lithium-ion battery pack only in its designated
iON+ 24V lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire a battery
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is
41°F – 105ºF (5°C – 40.5°C). Do not charge the battery
outside in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger,
pull the plug, not the cord, from the receptacle to reduce
the risk of damage to the electrical plug and cord.
Never carry the charger by its cord or yank it by the cord
to disconnect it from the receptacle. Keep the cord away
from heat, oil and sharp edges. Make sure the cord will not
be stepped on, tripped over or subjected to damage or
stress when the charger is in use. Do not use the charger
with a damaged cord or plug. Replace a damaged charger
immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger 24VCHRG-QC is rated for 120 volt AC only –
The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage.
Toxic fumes and materials are created when battery packs
are burned.
• Do not crush, drop or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe
®
+ Sun Joe
®
dealer or
5
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If a
damaged battery pack leaks battery chemicals, use rubber
or neoprene gloves to safely dispose of it. If skin is exposed
to battery uids, wash the aected area with soap and
water and rinse with vinegar. If eyes are exposed to battery
chemicals, immediately ush with water for
20 minutes and seek medical attention. Remove and
dispose of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. The battery pack supplied with your cordless snow shovel
is only partially charged. The battery pack has to be
charged completely before you use the tool for the
rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at
77°F (25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your snow shovel,
and therefore pose a safety risk.
5. Do not throw battery packs into an open re as this poses
a risk of explosion.
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not
apparent externally.
9. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
10. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
11. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C).
In particular, do not leave the battery charger in a car that
is parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than
60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. Avoid electrostatic
charging and never touch the battery poles.
6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on the machine before attempting to assemble and operate.
The rotating part will continuously
run for several seconds after you
turn o the machine.
READ THE OPERATOR'S
MANUAL(S) – Read, understand
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning or a danger.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Keep bystanders and children a
safe distance (at least 11 yd/10 m)
away from the work area.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
CAUTION! Beware of stones and
other foreign objects that could
be thrown from the appliance.
DANGER! Cutting/dismemberment
hazard - Keep hands away from the
rotating auger. Do not use hands to
unclog rotor housing. Stop motor
before removing debris.
DANGER! Cutting/dismemberment
hazard - Keep feet away from the
rotating auger.
Symbols SymbolsDescriptions Descriptions
Indoor use only. Only use
battery charger indoors.
Do not use hands to unclog chute.
Keep hands, feet and clothing
away from the rotating auger to
avoid injury.
Wear safety gloves during use to
protect hands.
Wear safety footwear at all times to
provide protection against objects
that may accidentally fall on feet.
7
8
Know Your Cordless Snow Shovel
Read the owner’s manual and safety rules carefully before operating your cordless snow shovel. Compare the illustration
below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
1. Upper handle
2. ON/OFF trigger switch
3. Battery compartment
4. Handle knob
5. Joint-xing knob, washer and bolt (2)
6. Middle pole
7. Lower pole
8. Motor housing
9. Scraper blade
10. Auger blade
11. Upper pole
12. Auxiliary handle
13. Safety switch
1
2
3
4
5
6
10
THE OTHER SIDE
THE OTHER SIDE
8
9
11
13
7
12
SOLD SEPARATELY
Battery + Charger options available at snowjoe.com
24VBAT
24VBAT-LTE
24VBAT-LT
24VBAT-XR
24VCHRG-QC
24VCHRG-DPC
9
Technical Data
Battery Voltage* ................................ 24 V D.C.
Battery Capacity ..............................See page 14 for battery
options and specications
Battery Charge Time Max ................See page 14 for battery
options and specications
Battery Run Time Max .....................See page 14 for battery
options and specications
No Load Speed ................................2500 rpm
Rotor .................................................2-blade plastic
paddle auger
Motor ................................................ 210 W brush
Clearing Width ................................. 10 in. (25.4 cm)
Depth of Snow Cut .......................... 6 in. (15 cm)
Throw Distance Max ........................20 ft (6 m)
Plowing Capacity Max .....................See page 14 for battery
options and specications
Weight (without battery) ...................8.2 lbs (3.7 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless snow shovel upper pole assembly
• Cordless snow shovel lower pole assembly
• Middle pole
• Joint-xing knob, washer and bolt (2 sets)
• Manual with registration card
NOTE: In order to operate this cordless snow shovel you will
need iON+ 24V System batteries and chargers. See page 14 for
battery options and specications, or visit snowjoe.com.
1. Carefully remove the cordless snow shovel and check to
see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless snow
shovel. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with
local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags,
foils or small parts. These items can be swallowed and pose a
suocation risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, insert the battery into the charger and charge as
needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
In order to operate this cordless snow shovel you will need
a iON+ 24V System battery and charger. See page 14 for
battery and charger options and specications, or for more
information visit snowjoe.com.
CORE TOOL
BATTERY + CHARGER SOLD SEPARATELY
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights
10
Charger Operation
m
WARNING! Charge only iON+ 24V lithium-ion battery
packs with its compatible iON+ 24V lithium-ion quick charger.
Other types of batteries may cause personal injury and
damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24V
Lithium-Ion Battery
NOTE: The iON+ 24V lithium-ion battery packs do not develop
a "memory" when charged after only a partial discharge.
Therefore, it is not necessary to run down the battery pack
before placing it into the charger.
• Use the battery charge indicator lights to determine when to
charge your iON+ 24V lithium-ion battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Press the push lock buttons on the battery to pull the
battery pack out of the equipment (Fig. 1).
2. Depending on your Snow Joe
®
+ Sun Joe
®
charger
model, how to recharge your lithium-ion battery will vary.
You may either insert your 24-volt battery into the
24VCHRG-QC Quick Charger (sold separately) or the
24VCHRG-DPC Dual Port Charger (sold separately)
(Figs. 2 – 3).
3. The battery indicator LEDs will illuminate one by one
during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
4. The 24VCHRG-QC Quick Charger (sold separately) and
the 24VCHRG-DPC Dual Port Charger (sold separately)
are also equipped with additional charging indicating
lights which will indicate the charging status (Figs. 2 – 3).
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery.
mWARNING! The chargers do not automatically turn
owhenthebatteryisfullycharged.Please take care not
toleavethebatterypluggedintothecharger.Switchoor
unplug the charger at the mains when charging is complete.
4. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
In order to operate this cordless snow shovel you will need
a iON+ 24V System battery and charger. See page 14 for
battery and charger options and specications, or for more
information visit snowjoe.com.
CORE TOOL
BATTERY + CHARGER SOLD SEPARATELY
Fig. 1
Push lock button
Fig. 2
Battery pack
24VCHRG-QC
quick charger
(Sold separately)
red
Charging
green
Fully
Charged
Fig. 3
Battery pack
24VCHRG-DPC
dual port charger
(Sold separately)
red
Charging
green
Fully
Charged
11
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the
battery.
5. When charging is complete, remove the battery from the
charger by pulling the push lock button and sliding the
battery backward to unlock it from the charger.
Assembly
Connecting the Poles
1. Slide the middle pole into the lower pole assembly and the
upper pole assembly. Align the screw holes (Fig. 4).
2. Insert the joint-xing bolts through the aligned holes in the
poles and secure the other end with the washers and the
joint-xing knobs (Fig. 5). Twist until tight.
NOTE: You may have to carefully move the wiring inside
the tube to one side if it blocks the path of the bolt.
Operation
mWARNING! Keep the area to be cleared free of stones,
toys or other foreign objects that the rotor blades might pick
up and throw. Such items could be covered by snow and are
easy to overlook, so be sure to conduct a thorough inspection
of the area before beginning work.
Starting the Machine
1. Slide the battery down in the battery compartment until it
clicks to lock it into position (Fig. 6).
2. To start the cordless snow shovel, push and hold the
safety lock switch on the side of the handle grip with your
thumb and then squeeze the trigger switch with your
ngers. Once the machine powers on, you can release the
safety lock switch and proceed with operation (Fig. 7).
3. To stop the cordless snow shovel, release the trigger
switch.
Handle Adjustment
To adjust the angle of the auxiliary handle, follow the
instructions below:
1. Stop the machine and remove the battery. Wait until the
blade comes to a completely stop.
Fig. 4
Upper pole
assembly
Middle pole
Lower pole
assembly
Fig. 5
Upper pole
assembly
Middle pole
Lower pole
assembly
Joint-xing
knob
Washer
Bolt
Fig. 6
Battery
Battery
compartment
Fig. 7
Trigger switch
Safety lock switch
12
2. Loosen the auxiliary handle by turning the handle knob
counterclockwise. Rotate the auxiliary handle to a
comfortable position (Fig. 8).
3. Fix the handle by tightening the handle knob. Insert the
battery and resume working.
To adjust the position of the auxiliary handle, follow the
instructions below:
1. Stop the machine and remove the battery. Wait until the
blade comes to a complete stop.
2. Loosen handle knob slightly and adjust auxiliary handle
as needed to desired position. Retighten handle knob
securely (Fig. 9).
3. Insert the battery and resume working.
NOTE: In order to prevent the auxiliary handle from moving
around or sliding on the pole, be sure to tighten securely.
Operating Tips
• Start the cordless snow shovel. Push the shovel forward
at a comfortable rate, yet slow enough to clear the path
completely. The clearing width of the snow shovel and the
depth of snowfall should dictate your forward speed.
• Direct the snow discharge to the right or to the left by
holding the cordless snow shovel at a slight angle.
• To remove snow most eciently, throw the snow
downwind and slightly overlap each swath.
• If you need to clear snow from a crushed rock or gravel
surface, push down on the handle to keep the scraper
blade clear of any loose material that the rotor blades
could throw.
• This cordless snow shovel cuts a path 10 in. (25.4 cm)
wide and up to 6 in. (15 cm) deep in one pass.
• When clearing deeper drifts, hold the cordless snow
shovel by the upper and lower handles and use a swinging
or sweeping motion. Remove up to 6 in.
(15 cm) of snow with each pass and repeat as many
times as needed.
• Remove the battery after using the cordless snow shovel.
Hang the shovel so it will not be misplaced or damaged.
Maintenance
To order genuine replacement parts or accessories for the
Snow Joe
®
24V-SS10-CT-RM cordless snow shovel, please
visit snowjoe.com or contact the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE (1-866-766-9563).
Proper Care for Battery + Charger
mWARNING! To reduce the risk of injury, always unplug
the charger and remove the battery pack from the charger
before performing any maintenance task. Never disassemble
the battery pack or charger. Contact your Snow Joe
®
+
Sun Joe
®
dealer or the Snow Joe
®
+ Sun Joe
®
customer
service center for ALL repairs.
1. To reduce the risk of injury and damage, never immerse
your battery pack or charger in liquid or allow any liquid to
ow inside these components.
2. Clean out dust and debris from charger vents and
electrical contacts by blowing with compressed air.
3. Use only mild soap on a damp cloth to clean the battery
pack and charger, keeping away from all electrical
contacts. Certain cleaning agents and solvents are harmful
to plastics and other insulated parts. Some of these
include gasoline, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia and household
detergents containing ammonia. Never use ammable
or combustible solvents around battery packs, battery
chargers or tools.
4. The iON+ 24V lithium-ion battery chargers have no
serviceable parts.
Fig. 8
Handle knob
Auxiliary
handle
Fig. 9
Loosen the
handle knob
Auxiliary
handle
13
Lubricating the Cordless Snow Shovel
This cordless snow shovel does not need lubrication.
All bearings are lubricated at the factory for the life of the
product.
Storage
1. Examine the cordless snow shovel thoroughly for worn,
loose or damaged parts. Should you need to repair or
replace a part, contact an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563) for assistance.
2. Remove the battery from the cordless snow shovel
before storing.
3. Store the cordless snow shovel indoors in a locked,
dry place out of the reach of children to prevent
unauthorized use or damage.
Battery+ChargerO-SeasonStorage
1. Do not expose your battery pack or charger to water,
rain or allow them to get wet. This could permanently
damage the charger and the battery pack. Do not use oil
or solvents to clean or lubricate your battery pack as the
plastic casing can become brittle and crack, causing a
serious risk of injury.
2. Store the battery pack and charger at room temperature
away from moisture. Do not store in damp locations where
corrosion of terminals may occur. As with other battery
pack types, permanent capacity loss can result if the pack
is stored for long periods of time at high temperatures
(over 120ºF/49ºC).
3. iON+ 24V lithium-ion battery packs maintain their charge
during storage longer than other battery pack types.
As a general practice, it is best to unplug the battery
charger and remove the battery pack when they are not
in use. Recharge the battery pack every 6 months to 50%
capacity (2 lights on) during o-season storage to maintain
optimal battery performance.
Battery Caution + Disposal
Always dispose of your battery pack according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes and
materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride,
or Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Service and Support
If your Snow Joe
®
24V-SS10-CT-RM cordless snow shovel
requires service or maintenance, please call the Snow Joe
®
+
Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model and Serial Numbers
When contacting the company, reordering parts or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
2 4 V - S S 1 0 - C T - R M
14
Optional Accessories
m
WARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless snow shovel. Contact Snow Joe
®
+ Sun Joe
®
if you are unsure whether it is safe to use a particular replacement part or accessory with your cordless snow shovel. The use of
any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
®
+ Sun Joe
®
. Accessories
can be ordered online at snowjoe.com or via phone by contacting the Snow Joe
®
+ Sun Joe
®
customer service center
at 1-866-SNOWJOE (1-866-766-9563).
24V iON+ 2.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 1 hr 20 min | 24VCHRG-QC: 55 min | 24VCHRG-DPC: 55 min
Battery Runtime Max: 12 min
Plowing Capacity Max: 816 lbs/charge (370 kg/charge)
24V iON+ 2.5 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 1 hr 40 min | 24VCHRG-QC: 1 hr 10 min | 24VCHRG-DPC: 1 hr 10 min
Battery Runtime Max: 15 min
Plowing Capacity Max: 1,020 lbs/charge (463 kg/charge)
24V iON+ 4.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 2 hrs 40 min | 24VCHRG-QC: 1 hr 50 min | 24VCHRG-DPC: 1 hr 50 min
Battery Runtime Max: 24 min
Plowing Capacity Max: 1,632 lbs/charge (740 kg/charge)
24V iON+ 5.0 Ah Lithium-Ion Battery
Battery Charge Time Max:
24VCHRG-AC: 3 hrs 20 min | 24VCHRG-QC: 2 hr 20 min | 24VCHRG-DPC: 2 hr 20 min
Battery Runtime Max: 30 min
Plowing Capacity Max: 2,040 lbs/charge (925 kg/charge)
24V iON+ Lithium-Ion Battery Quick Charger
24V iON+ Lithium-Ion Battery Dual Port Charger
24VBAT-LTE
24VCHRG-QC
24VCHRG-DPC
24VBAT-LT
24VBAT
24VBAT-XR
ModelAccessories Item
1
2
3
4
5
6
15
19
19
19
SNOW JOE
®
+ SUN JOE
®
REFURBISHED GOODS WARRANTY
GENERAL CONDITIONS:
Snow Joe
®
+ Sun Joe
®
operating under Snow Joe
®
33*^HYYHU[Z
this refurbished product to the original purchaser for 90 days
against defects in material or workmanship when used for normal
residential purposes. If a replacement part or product is needed,
it will be sent free of charge to the original purchaser except as
noted below.
;OLK\YH[PVUVM[OPZ^HYYHU[`HWWSPLZVUS`PM[OLWYVK\J[PZW\[[V
personal use around the household. It is the owner’s responsibility
to correctly perform all maintenance and minor adjustments
explained in the owner’s manual.
HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:
;V VI[HPU H YLWSHJLTLU[ WHY[ VY WYVK\J[ WSLHZL ]PZP[
snowjoe.com/help or email us at [email protected] for
instructions. Please be sure to register your unit beforehand to
speed up this process. Certain products may require a serial
U\TILY [`WPJHSS` MV\UK VU [OL KLJHS Hɉ_LK [V [OL OV\ZPUN
or guard of your product. All products require a valid proof
of purchase.
EXCLUSIONS:
>LHYPUN WHY[Z SPRL ILS[Z H\NLYZ JOHPUZ HUK [PULZ HYL
not covered under this warranty. Wearing parts can be
purchased at snowjoe.com or by calling 1-866-SNOWJOE
(1-866-766-9563).
)H[[LYPLZ HYL JV]LYLK PU M\SS MVY KH`Z MYVT [OL KH[L VM
purchase.
Snow Joe
®
+ Sun Joe
®
may from time to time change the design
of its products. Nothing contained in this warranty shall be
construed as obligating Snow Joe
®
+ Sun Joe
®
to incorporate
such design changes into previously manufactured products, nor
shall such changes be construed as an admission that previous
designs were defective.
;OPZ ^HYYHU[` PZ PU[LUKLK [V JV]LY WYVK\J[ KLMLJ[Z VUS`
Snow Joe
®
33* PZ UV[ SPHISL MVY PUKPYLJ[ PUJPKLU[HS VY
consequential damages in connection with the use or misuse of
the Snow Joe
®
+ Sun Joe
®
products covered by this warranty.
;OPZ ^HYYHU[` KVLZ UV[ JV]LY HU` JVZ[ VY L_WLUZL PUJ\YYLK
by the purchaser in providing substitute equipment or service
during reasonable periods of malfunction or non-use of this
product while waiting for a replacement part or unit under this
warranty. Some states do not allow exclusions of incidental or
consequential damages so the above exclusions may not apply
PU HSS Z[H[LZ ;OPZ ^HYYHU[` TH` NP]L `V\ ZWLJPÄJ SLNHS YPNO[Z PU
your state.
HOW TO REACH US:
>L»YLOLYL[VOLSW4VUKH`[OYV\NO-YPKH`MYVT (4[V74,:;
and Sunday 9AM to 4PM. You can reach us at 1-866-SNOWJOE
(1-866-766-9563), online at snowjoe.com, via email at
[email protected] or tweet us @snowjoe.
EXPORTS:
Customers who have purchased Snow Joe
®
+ Sun Joe
®
products exported from the United States and Canada should
contact their Snow Joe
®
+ Sun Joe
®
distributor (dealer) to obtain
information applicable to your country, province or state. If for
HU` YLHZVU `V\ HYL UV[ ZH[PZÄLK ^P[O [OL KPZ[YPI\[VY»Z ZLY]PJL
VY PM `V\ OH]L KPɉJ\S[` VI[HPUPUN ^HYYHU[` PUMVYTH[PVU JVU[HJ[
your Snow Joe
®
+ Sun Joe
®
ZLSSLY0MPU[OLL]LU[`V\YLɈVY[ZHYL
unsatisfactory, please reach out to us directly.
snowjoe.com
