User Manual
KODAK
DIGITAL CAMERA
PIXPRO FZ152
ii 1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
Company website: kodakpixpro.com
For Customers in the U.S.A.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference and (2) this device
must accept any interference received, including interference that may cause undesired
camera operation.
For Customers in Europe
"CE" mark indicates that this product complies with the European requirements for
safety, health, environment and customer protection. "CE" marked cameras are
intended for sales in Europe.
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection
of electrical waste and electronic equipment in the European countries. Please do
not throw the equipment into domestic refuse. Please use the return and collection
systems available in your country for proper, safe disposal of this product.
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
Before You Start
2 32 3
About this Manual
Thank you for purchasing this KODAK PIXPRO Digital Camera. Please read this manual
carefully and keep it in a safe place for future reference.
JK Imaging reserves all rights of this document. No part of this published manual may be
reproduced, transmitted, transcribed, stored in a retrieval system or translated into any
language or computer language, in any form, by any means, without the prior written
permission of JK Imaging.
All trademarks mentioned in this manual are used for identiication purposes only and
are properties of their respective owners.
This manual will instruct you on how to operate the KODAK PIXPRO Digital Camera. JK
Imaging has tried its utmost to ensure the correctness of the user manual contents,
but reserves the right to modify as necessary. All of these contents are subject to
change without prior notice.
Throughout this manual, the following symbols are used to help you locate
information quickly and easily:
Indicates useful information.
The following symbols are used throughout this manual to facilitate better
understanding of how to operate the camera:
[Item properties]：
The optional properties in the camera interface are indicated by
the [ ] symbol.
2 32 3
Safety Notes
Safety Notes for this Camera
Do not drop the camera or allow it to hit solid objects.
Do not attempt to disassemble or repair the camera.
Do not use or store the camera in dusty places or on a beach to help prevent dust or
sand from entering the camera, causing possible damage.
Do not use or store the camera in a hot environment or under or in direct sunlight.
Do not use or store the camera near powerful magnetic ields, for example near a
magnet or transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for a long period of time.
To prevent the camera from being damaged by moisture, do not use or store the camera in
very humid environments, such as in rain or near bodies of water.
If water accidentally comes in contact with the camera, turn the camera o immediately.
Remove the battery and the memory card and dry it completely within 24 hours.
When you take the camera from a cold environment to a warmer environment,
condensation may occur. Please wait for a reasonable period of time before you turn
the camera on.
Before you remove the battery and memory card, the camera should be turned o.
When you clean the body of the camera, do not use abrasive, alcohol-based or
organic cleansers or solvents.
Use a professional lens cleaning cloth and appropriate cleaner to wipe and clean the lens.
Download your photos and remove the memory card when you are going to store the
camera for long periods of time.
If this camera is not in use for a long period of time, please keep it in a dry and clean
storage location.
Our company will not pay compensation for any failure of playback including: pictures
or videos damaged or unrecoverable by improper operation.
4 5
Safety Notes for Battery
Please use a battery that is the same type as the one included.
Please use the attached charger to charge the battery.
If battery luid leaks inside the camera, contact our customer service department
immediately. If battery luid leaks onto your skin, rinse your skin immediately with clean
water and seek immediate medical attention.
Disposal of used batteries should be carried out in accordance with your local
(national or regional) regulations.
To prevent the battery from being damaged, do not drop the battery or allow it to hit
solid objects or to be scratched by foreign objects.
Do not let the battery come in contact with metal objects (including coins) to avoid
short circuiting, discharging, excessive heat or possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep the battery contacts dry.
Do not heat the battery or throw it into a ire to avoid a possible explosion.
Do not store the battery in a hot environment or in direct sunlight.
If the battery overheats during charging or use, stop charging or use immediately.
Turn o the product, remove the battery carefully, and wait until it cools down.
When the camera is stored for a long period of time, remove the battery and keep it in
a safe, dry place that is not accessible to infants and children.
In colder environments, the performance of the battery could be noticeably reduced.
When you install the battery, align the battery markings according to the positive and
negative markings inside on the camera battery compartment. Never force the battery
into the battery compartment.
4 5
Safety Notes for Memory Cards
We highly suggest buying only well-known, name brand memory cards to ensure peak
performance and reliability.
Format the memory card using the camera before you use it or insert a new one.
Do not drop the memory card or allow it to hit solid objects to avoid damaging it.
Do not attempt to disassemble or repair the memory card.
Do not expose the memory card to water. Always keep it dry.
Do not remove the memory card when the camera is turned on. Otherwise, the
memory card and photo/video iles could be permanently damaged.
Do not directly edit the data on the memory card. Copy the data to your computer
before you edit the iles.
When the camera is stored for long periods of time, be sure to download your photos
and remove the memory card. Store the memory card in a dry environment.
Do not modify the name of the iles or folders of the memory card using your PC.
Modifying the ile names may cause the iles to not be recognized on the camera or a
possible permanent error may occur.
A photo taken with the camera will be stored in the folder that is automatically
generated on the memory card. Do not store photos that are not taken using this
camera in these folders as the pictures cannot be recognized during playback.
When you insert the memory card, make sure the notch of the card matches the
markings on the top of the camera card slot.
6 76 7
Other Safety Notes
Do not disconnect the power or turn the camera o during the update process. Doing
so may cause incorrect data to be written and the camera may not power on later.
When using your camera on an airplane, observe the relevant rules speciied by the
airline and FAA regulations.
Due to the limitations of manufacturing technology, the LCD may have a few dead
or bright pixels. These pixels do no eect the quality or performance of the camera,
photos or video.
Do not expose the camera’s LCD to water. In a humid environment, only wipe it with a
soft, dry, cleaning cloth.
If the LCD screen is damaged, pay particular attention to the liquid crystal in the
screen. If any of the following situations arise, immediately take the steps listed below:
1. If liquid crystal comes in contact with your skin, please wipe with a dry cloth, wash
thoroughly with soap, and rinse with plenty of clean water.
2. If liquid crystal gets into your eye, lush the eye immediately with plenty of clean
water for at least 15 minutes and then seek medical assistance.
3. If liquid crystal is swallowed, immediately rinse your mouth thoroughly with clean
water and induce vomiting. Seek medical assistance.
6 76 7
Before You Start ............................................................................... 1
Safety Notes
................................................................................... 3
Contents
..........................................................................................7
Getting Started
...............................................................................11
Accessories Included .......................................................................................................11
Part Names
...................................................................................................................... 12
Installing Battery and Memory Card
............................................................................... 14
Charging Battery
............................................................................................................. 16
Turning Camera On and O
.............................................................................................17
How to Take Pictures
........................................................................................................17
Set your Language, Date/Time
....................................................................................... 18
Mode Overview .............................................................................21
LCD Screen Display ......................................................................................................... 21
Overview of the Screen Icons in Photo Shooting Mode
......................................... 21
Contents
8 9
Overview of the Screen Icons in Movie Mode ......................................................... 22
Using the Mode Button
...................................................................................................23
Panorama Mode
........................................................................................................24
Scene Mode
..............................................................................................................25
Basic Operation ............................................................................ 29
Using the Zoom Function................................................................................................29
Display Setting
............................................................................................................... 30
Macro Mode
..................................................................................................................... 31
Self-Timer Setting
............................................................................................................ 32
Flash Mode
......................................................................................................................33
EV Setting
........................................................................................................................34
Using Quick Recording
.................................................................................................. 36
Playback Mode ............................................................................. 37
Overview of the Screen Icons in Playback Mode .......................................................... 37
Viewing Photos and Videos
............................................................................................38
Thumbnail View
.............................................................................................................. 39
Using Zoom Playback (for still pictures only)
................................................................ 40
8 9
Slideshow ........................................................................................................................ 41
Deleting Photos and Videos
............................................................................................ 42
Using the Menus ........................................................................... 43
Shooting Menu ............................................................................................................... 43
Shooting Setting Menu
.................................................................................................. 49
Movie Menu
.....................................................................................................................53
Movie Setting Menu
........................................................................................................56
Playback Menu
................................................................................................................ 57
Playback Setting Menu
.................................................................................................. 60
Setup Menu
.................................................................................................................... 63
Sound Settings
......................................................................................................... 64
Power Saver
.............................................................................................................. 64
Language
...................................................................................................................65
World Time
................................................................................................................65
Date & Time
...............................................................................................................65
LCD Brightness
..........................................................................................................65
10 1110 11
File Setting ...................................................................................................................... 66
Format
...................................................................................................................... 66
Copy to Card
............................................................................................................. 67
File Numbering
..........................................................................................................67
Reset
......................................................................................................................... 68
Firmware (FW) Version
............................................................................................. 68
Connection Settings .................................................................... 69
Connecting to a Computer ............................................................................................ 69
Connecting to a PICTBRIDGE
™ Compatible Printer .......................................................71
Using the PICTBRIDGE
™ Menu .......................................................................................73
Video System
.................................................................................................................. 77
Set Eye-Fi Card Connection Mode
.................................................................................78
Appendices ................................................................................... 79
Product Speciications .................................................................................................... 79
Prompts and Warning Messages
....................................................................................83
Troubleshooting
..............................................................................................................87
10 1110 11
Getting Ready
Your camera box should contain the camera model you purchased along with the
following accessories. If anything is missing or appears to be damaged, please contact
your retailer irst or our customer service center. (Based on sales in dierent countries or
regions, the shape of the AC adapter will vary).
Accessories Included
Micro USB Cable
Warranty Card
AC Adapter Wrist StrapRechargeable
Li-ion Battery
Quick Start Guide Service Card
Quick Start Guide
STOP
12 1312 13
Part Names
1. Micro USB Port
2. Zoom Lever
3. Shutter Button
4. Power Button
5. AF Assist Beam/Self-Timer Lamp
6. Flash Lamp
7. Lens
8. Microphone
2
7
54
8
6
1
3
12 1312 13
9. Indicator Lamp
10. Fast Video Recording Button
11. Mode Button
12.
AC
Display Button/Arrow Button
(Up)
13.
C
A
Flash Button/Arrow Button (Right)
14. SET Button
15. Playback Button
16. Battery Cover
17.
CA
Delete Button/Arrow Button
(Down)
18. Menu Button
19.
A
C
Macro Button/Self-Timer
Button/Arrow Button (Left)
20. Tripod Socket
21. Speaker
22. LCD
9
10
12
11
16
13
14
15
18
17
20
19
21
22
14 1514 15
2. Insert the battery into the battery
compartment according to the
negative and positive marks as
illustrated in the picture below. Push
the battery down until it locks in place.
1. Open the battery door cover.
2
1
Installing Battery and Memory Card
14 1514 15
4. Close the battery door cover.
1
2
To remove your memory card, open
the battery cover door, gently press
the memory card to eject it and
remove it carefully.
3. Insert the memory card into the
memory card slot as shown in the
diagram below:
A standard SD memory card is not
included in the camera packaging
and needs to be purchased
separately. This camera takes a
standard (SD/SDHC) memory card.
We recommend using a name brand
memory card that is Class 4 or
higher and has a capacity of 4GB to
32GB. The camera is not compatible
with Micro SD, Ultra, Ultra Plus,
Extreme, XC, or adapters for any of
these other memory cards.
Write
Protection
Toggle
Switch
16 1716 17
1. Connect the camera and the power charger
using the supplied Micro USB cable.
2. Insert the plug of the power charger into
the power outlet to charge the battery.
3. When the camera is turned o, you can
also connect the camera to your PC using
a Micro USB cable to charge the battery.
After the battery is stored for long periods
of time, use the supplied power charger to
fully charge the battery prior to use.
Charging Indicator Lamp:
Steady orange indicates charging.
The indicator will go out once charging
is inished.
To maximize battery life, charge the
battery for at least 4 hours before irst
use.
Please charge the battery indoors
between 0°C and 40°C (32°F and 104°F).
The camera will only charge while
powered o. If the camera is turned
on while connected to power, normal
camera functions will be available for
use, but the camera will not charge until
it is turned o.
Charging the Battery
Indicator lamp
Please insert the battery and charge it in “OFF“ mode.
16 1716 17
Turning Camera On and O
Press the Power button to turn the camera
on. To turn the camera o, press the
Power button again.
Power Button
When the power is o, press and
hold the play button to power on
and enter Playback mode.
How to Take Pictures
1. Hold the camera securely with both
hands, being careful not to block the
lash and lens with ingers.
2. Point the lens toward the object you
want to take a picture of.
3. Use the zoom lever to select Tele or
Wide position to zoom in or out on your
subject.
4. Press the shutter button down half-way
to allow the camera to focus on your
subject.
5. When the frame around your subject
turns green and the LCD is focused to
your liking, push the shutter button
down completely to take the picture.
18 1918 19
Set your Language, Date/Time
1. When you turn the camera on for
the irst time, the language selection
screen appears.
2. Press the direction buttons to select
your desired language.
3. After you press the button to
conirm your language selection, the
Date/Time settings screen will appear.
4. Press the left/right button to select
the Date/Time to be adjusted: Time is
displayed in YYYY.MM.DD/HH:MM.
5. Press the up/down button to adjust the
value for the desired Date/Time.
6. Press the button to conirm the time
settings and the snapshot screen will
appear.
Set your Language, Date/Time After the First Power-On
18 1918 19
Resetting your Language
After you set your language for the irst
time, follow the instructions below to
reset your desired language.
1. Press the button and press the up/
down button to select . Press the
button to enter the menu.
2. Press the up/down button to select
and press the button or right button
to enter the menu.
3. Press the up/down button to select
[Language] and press the button or
right button to enter the menu.
4. Press the direction buttons to select
your desired language and press the
button to conirm.
5. Press the button and the snapshot
screen will appear.
20 2120 21
Resetting Date/Time
After you set your Date/Time for the irst
time, follow the instructions below to
reset date and time.
1. Press the button and press the up/
down button to select . Press the
button to enter the menu.
2. Press the up/down button to select
and press the button or right button
to enter the menu.
3. Press the up/down button to select
[Date & Time] and press the button
or right button to enter the menu.
4. Press the left/right button to select
the Date/Time to be adjusted: Time is
displayed in YYYY.MM.DD/HH:MM.
5. Press the up/down button to press the
value for your selected entry. After
you inish your settings, press the
button to conirm.
6. Press the button and the following
snapshot screen will appear.
20 2120 21
LCD Screen Display
Overview of the Screen Icons in Photo Shooting Mode
Mode Overview
5M 3M 2M
-0.3
EV
400
ISO
1234
00:56:00
SD
12 34
5
6
7
8
9
10
11
12
13
141516
17
18
20
21
22
23
19
x3.
2
15 sec
1 Shooting Mode 9 Image Size 17
OIS (Optical Image
Stabilization)
2 Macro Mode 10 Video Quality 18 Eye-Fi ON (with signal)
3
Zoom Display (By
turning the Zoom Lever)
11 ISO Value 19 Continuous Shot
4
Memory Card/Built-in
Memory
12
Remaining
Recording Time
20 Expo Metering
5 Battery Status 13
Exposure
Compensation
21 Self-Timer
6 White Balance 14 Focus Frame 22 AF Mode
7 Color Eect 15 Shutter Speed 23 Flash Mode
8
Number of Remaining
Shots
16 Histogram
22 2322 23
Overview of the Screen Icons in Movie Mode
-0.3 EV
00:56:00
00:56:00
SD
1 2 43 5 6
91011
12
14
15
13
7
8
x3.
2
1 Movie Mode 6 Battery Status 11 Focus Frame
2 Macro Mode 7 Color Eect 12 Image Stabilization
3 Self-Timer 8 Video Quality 13
Eye-Fi ON (with
signal)
4
Zoom Display (By
turning the Zoom
Lever)
9
Remaining Recording
Time
14 Expo Metering
5
Memory Card/Built-in
Memory
10
Exposure
Compensation
15 AF Mode
22 2322 23
Using the Mode Button
This camera provides a convenient Mode button that allows you to switch easily between
dierent modes. After pressing the button to enter the Mode Selection Menu, press
the left/right button to choose the selected mode. Press the button to conirm your
selection. All the available modes are listed below:
Mode Name Icon Description
Auto Mode
In this mode, the optimal conditions for taking pictures will
be set based on the subject and environment. It is the most
commonly used mode for taking pictures.
Manual Mode
This mode is for manually setting EV, shutter speed and ISO
value.
Portrait Mode
The best setting for portrait shooting, enables AE/AF for faces.
The camera is set to automatically adjust exposure for realistic
capture of skin tones.
Movie Mode
Record videos.
Panorama
Mode
In this mode, up to 4 frames (or 180
o
) can be stitched together
to create a single panoramic photo.
Scene Mode
Choose from 20 dierent pre-set scene types and eects for
your photos.
24 25
4. After the irst shot is taken, the
semi-transparent image of the irst
shot will appear at the edge of the
screen. You can use this image to
compose and align your picture
before you press the Shutter button to
capture and inish manual stitching.
5. If continuous pictures are less than 4
shots, when you press the button,
the camera will automatically stitch the
pictures together. Press the Playback
button to enter Playback mode to see
the inished eect.
6. If you take 4 pictures, the camera
will stitch the pictures together
automatically. Press the Playback
button to enter Playback mode to see
the inished eect.
Panorama Mode
Panorama Mode allows you to create a
panoramic picture up to 180
o
. The camera
will automatically compose a panoramic
picture by stitching together individual
shots that you take.
Follow these easy steps to create a
panoramic picture:
1. Press the button to select Panorama
Mode ( ).
2. Press the direction buttons to select
a desired shooting direction. Should
you not select a direction, the default
shooting direction is “right.” 2 seconds
later, the camera will be ready to take
pictures. You can also press the
button or press the shutter button
down halfway to be ready to take
pictures.
3. Compose the irst view of the
panoramic picture on the LCD and
press the Shutter button to capture the
image.
24 25
When shooting in Panorama Mode,
the Flash, Self-Timer, Macro Modes
and Exposure Compensation are not
available. Focus Adjustment is also
not available at this time.
In Panorama Mode, up to 4 photos
can be captured when the image
size is set at 2M.
During Panorama Mode shooting,
press the
button to interrupt
shooting and save the current
pictures taken. Press the down
button ( ) to cancel shooting and
delete the previously taken pictures.
Scene Mode
You can select your desired scene from
the 20 preset modes according to the
type of environment you are shooting.
The camera then automatically conigures
the most appropriate settings for the best
possible photos.
1. Press the button to select scene
mode ( ). The LCD will display a
menu like the example below:
Auto Scene
2. Press the direction buttons to select a
scene, and press the button to
conirm.
3. If any need of changing the scene,
please press the button and then
the button and inally the direction
buttons to reselect the scene.
26 27
Scene Description
Auto Scene
Identiies the scene automatically; Person, Backlighting,
Landscape, Macro, Night Scene, Night Scene Person and Auto.
Landscape
For landscapes and outdoor shots. Vivid reproduction of
greens and blues.
Sport
For fast-moving subjects. Captures sharp, action shots with
minimal blur. This mode is not recommended for shooting
indoors.
Beach
For taking pictures in areas with strong sunlight.
Sunset
For sunsets. Captures subjects in strong sunlight.
Fireworks
For ireworks at night. Adjusts slower shutter speed for brilliant
images. The use of a tripod is recommended with this setting.
Night Landscape
For night scenes. The use of a tripod is recommended.
Snow
For snowy conditions. Reproduces natural, clear, white scenes.
Children
Turns lash o automatically. Avoids disturbing the subject,
and is suitable for taking photos of children and pets.
ID
For shooting ID size photos. (It is recommended to print using
6-inch 4R (6X4) photographic paper).
Glass
For objects behind transparent glass.
Photo Frame
For adding interesting frame eects to the photo.
26 27
Scene Description
Panning Shot
Captures fast moving objects clearly with a blurred
background.
Fish Eye
For an interesting ish eye eect.
Party
Suitable for taking indoor party pictures, even under
complicated lighting conditions.
Indoor
For indoor settings. Reduces blur and improves color
accuracy.
Leaf
For plants. Captures brilliant shots of greenery and blossoms.
Museum
For museums or lash-free areas. Retains color and reduce
blur.
Night Portrait
For portraits against night scenery.
Sketch
For taking photos with a pencil sketch eect.
28 2928 29
Auto Scene Mode (ASCN)
In “ASCN” Scene Mode, the camera can intelligently detect dierent environments and
automatically select the best scene and photo settings for you.
“ASCN” can intelligently detect the following scenes:
Mode Name Description
Landscape Mode
For landscapes, automatically adjusts the exposure and
reproduces vivid greens and blues.
Portrait Mode
Most suitable for capturing people with focus on their
faces.
Night Portrait
When you take portraits at night or in low light conditions,
automatically adjusts the exposure for people and night
scenes.
Backlit Portrait
When the sun or any other light source is behind you,
automatically adjusts the foreground exposure to produce
the best pictures possible.
Night Landscape Mode
For night scenes, automatically increases the ISO value to
compensate for low light.
Macro Mode
The Macro setting is ideal for shooting small objects or
close-up photos.
Auto Mode
The camera automatically adjusts the exposure and focus
to ensure the best possible pictures.
28 2928 29
Your camera is equipped with two types of
zoom functions: Optical Zoom and Digital
Zoom. Toggle the Zoom Lever of the
camera to zoom in or out of the subject
while taking pictures.
Using the Zoom Function
Basic Operation
Zoom
Indicator
When Optical Zoom reaches the
maximum threshold as Digital Zoom,
release and turn the Zoom Lever to T to
switch between Optical Zoom and Digital
Zoom.
Zoom
Lever
Zoom Out Zoom In
30 31
Classic: Displays the camera parameters
on screen
-0.3
EV
400
ISO
1234
SD
16M
00:56:00
Full: Camera parameters with Grid and
Histogram
-0.3
EV
400
ISO
1234
SD
16M
00:56:00
O: Does not display any additional icons
on screen
Display Setting
Press the button to display the settings: Classic, Full, O.
30 31
Macro Mode
The Macro setting is ideal for shooting
small objects or close-up photos. This
mode allows you to focus on subjects very
close to the camera.
1. Press the left button ( ) to enter
the Macro Menu.
2. Press the left/right button to select the
following 2 modes:
•
Macro O
Select this option to disable
macro.
•
Macro On
Select this option to make
focusing on the object closer
to the lens (At the W side, the
shooting distance should be
more than 3 cm).
3. Press the button to conirm the
settings and enter the shooting screen.
32 33
Self-Timer Setting
Use this function to take pictures at pre-
set intervals. First choose 2 seconds, 10
seconds or Smile Detection.
1. Press the left button ( ) , and then
press the down button ( ) to enter
the Self-Timer Menu.
2. Press the left/right button to select the
following 4 modes:
•
Self-Timer O
Disables the Self-timer.
•
Self-Timer 2 sec
A single picture is shot 2
seconds after the shutter
button is pressed.
•
Self-Timer 10 sec
A single picture is shot 10
seconds after the shutter
button is pressed.
•
Self-Timer Smile
Press the shutter button
and a picture will be taken
immediately after a smile is
detected.
3. Press the button to conirm the
settings and enter the shooting screen.
When enabling the Self-Timer,
pressing the shutter or the (
)
button can disable the Self-Timer
and return to the shooting screen
while keeping the Self-Timer setting.
When enabling the Smile Detection,
pressing the shutter or the
button
can disable the Self-Timer and return
to the shooting screen without
keeping the Self-Timer Smile setting.
32 33
Flash Mode
The lash provides supplemental light for
a scene. The lash is usually used when
shooting against the light to highlight the
object. It is also suitable for metering and
shooting in darker scenes to improve the
exposure.
1. Pop the lash up manually as shown
below (as shown in the igure).
2. Press the right button ( ) to enter the
lash settings menu.
3. Press the left/right button to select the
following 6 modes:
•
Force O
Flash is turned o.
•
Flash Auto
Camera lash goes o automatically
based on existing light conditions.
•
Fill Flash
The lash will engage with each
shot even if there is enough
available light to take the photo
without lash.
•
Slow Sync.
This allows you to take pictures
of people at night that clearly
show both your subjects and the
night time backdrop. The use of
a tripod is recommended when
shooting with this setting.
•
Slow Sync. + Red-Eye
Use this mode for slow synchrony
shots with red-eye reduction.
•
Red-Eye Reduction
The camera emits a brief pre-lash
before the picture is taken to
reduce red-eye eects.
4. Press the button to conirm the
settings and enter the shooting screen.
34 3534 35
EV Setting
The EV Function Menu of the camera
includes functions, such as EV, Shutter
Adjustment, ISO. Using the appropriate
function settings can improve your
pictures.
To select the best settings for optimum
photos, follow these steps:
1. Press the button to display the
settings screen.
2. Press the left/right button to select the
setting options.
3. Press the up/down button to adjust the
option values.
4. Press the button to conirm the
settings and enter the shooting screen.
Exposure Compensation
Set up Exposure Compensation to adjust
the picture brightness. If there is very
high contrast between the photographed
object and the background, the
brightness of the picture can be adjusted
as necessary. (This can be adjusted in
Mode)
The adjustable range of exposure value is
from EV -2.0 to EV+2.0.
34 3534 35
ISO
The ISO function allows you to set the
sensitivity of the camera's light sensor
based on the brightness of the scene. To
improve the camera's sensor performance
in darker environments, a higher ISO value
is required. A lower ISO value is needed
when shooting in brighter conditions.
Pictures taken at higher ISO settings will
generally have more noise than those
taken at lower ISO settings. (Adjustable in
Mode)
The camera's ISO settings include: Auto,
80, 100, 200, 400, 800, 1600.
Shutter Adjustment
For shutter speed, the camera may
automatically set the aperture value
corresponding to the manually set shutter
speed so as to obtain a most suitable
exposure value. The movement of object
may be shown by adjusting the shutter
speed. High shutter value can help you
more clearly capture fast moving objects
while low shutter value can better show
the movement of objects. (Adjustable in
Mode)
36 3736 37
Using Quick Recording
In Photo Shooting Mode, press the button to begin recording video.
After recording, press the button or the shutter button to stop recording. The camera
will store the video and return to the shooting screen.
36 3736 37
Playback Mode
Overview of the Screen Icons in Playback Mode
1/45
x2
SD
9
321
4
5
11
10
12
6
8
7
2015 06-25 00:002015 06-25 00:00
1 DPOF File 7 Image Zoom Ratios
2 File Protection 8 Image Zone
3
Memory Space (indicating the current
number of photos and total number of
photos)
9 Shooting Date
4 Memory Card/Built-in Memory 10 Eye-Fi ON (with signal)
5 Battery Status 11 Red-Eye Reduction
6 Zoom Magniication Area 12 HDR
38 39
Viewing Photos and Videos
To view the captured photos and video clips on the LCD:
1. After pressing the button, the last photo or video clip taken will be displayed on the LCD.
2. Use the left/right navigation buttons to scroll through the photos or video clips stored
on the camera’s internal memory or on the Memory Card.
3. To play a selected video clip, press the button to enter the movie playback mode.
An operation guide appears on the screen when playing back a video. Press the
appropriate buttons to enable the corresponding functions.
00:00:47 00:01:23
00:00:47 00:01:23
1 Increase volume
2 Pause
3 Fast forward
4 Decrease volume
5 Rewind
6 Return to the beginning of the
video
7 Play
8 Play video forward
9 Cancel playback
10 Play video backward
Mute
Under Playback Paused
38 39
Thumbnail View
When in Playback Mode, rotate the Zoom
lever counter to the position to
display thumbnail images of the photos
and videos on the screen.
1. Slide the zoom lever to switch between
3 x 3 and 4 x 4 thumbnails.
2. Press the direction buttons to select
a picture or video clip to view and
press the button to restore it to the
original size.
When the icon
appears, it means
this is a video ile.
W
40 41
Using Zoom Playback (for still pictures only)
When playing back photos, you can also use the
Zoom Lever to zoom in on the photos 2x to 8x
their original magniication.
1. Press the button to switch to playback
mode.
2. Press the left/right button to select a picture
on which to use the zoom feature.
3. Rotate the zoom lever to to zoom in.
4. The screen will display the number of times
the image is magniied and area of the photo
shown.
5. Press the direction buttons to navigate and
select a portion of the photo to be zoomed in
on.
6. Press the button to return the image to its
original scale.
Movie images cannot be magniied.
x2
T Zoom In
40 41
This setting allows you to view all the stored images as a slideshow.
1. Press the button to enter playback screen.
2. Press the button to enter slide option.
3. Press the left/right button to select slideshow playing or [Cancel] to return to the
playback screen.
4. Press the button to conirm the setting.
Slide playing function supports movie playing.
Images don’t rotate in the slideshow playback.
Slideshow
42 4342 43
Deleting Photos and Videos
In Playback Mode, press the down button
( ) to delete your photos and videos.
To delete photos or videos:
1. Press the button to switch to
Playback Mode.
2. Press the left/right button to select the
photos and videos to be deleted.
3. Press the down button ( ) and the
deletion screen is displayed.
4. Press the up/down button to select
[Delete One] or [Exit] and press the
button to conirm.
Erased photos/video clips cannot be
recovered.
Please refer to page 61 for
instructions on deleting more than
one image at a time.
42 4342 43
Shooting Menu
Using the Menus
Functions that can be enabled are
dierent under each mode.
Mode:
1. In Photo Shooting Mode, press the
button to enter the Shooting Menu.
2. Press the up/down button to select the
Shooting Menu and settings.
3. Press the left/right button to select the
shooting menu to be set and press the
button to conirm.
Refer to the following pages for more
details about each setting.
Expo Metering (Exposure Metering)
Use this setting to select the “target”
size of the camera’s ield of view to be
metered.
• AIAE (Artiicial Intelligence AE)
Automatically selects the central
and peripheral metering, to
calculate the reasonable value of
metering by weighting.
•
Spot
For metering targets a small area
in the center of the camera's
ield of view.
•
Center
For metering targets a slightly
larger area in the center of the
cameras ield of view.
44 45
Image Size
The size setting refers to the image
resolution in pixels. A higher image
resolution allows you to print that image
in larger sizes without degrading the
photo image quality.
The larger the number of recorded
pixels, the larger the ile size and
note that fewer iles can be saved on
your memory card.
OIS (Optical Image Stabilization)
This mode can help reduce photo blur
caused by unintentional hand shake, low
light.
• OIS: O
• OIS: On
Use this Image Stabilization Mode in
dark environments.
Shooting in a windy or unstable
environment (such as a moving
vehicle) may cause blurry images.
44 45
Continuous AF (Auto-Focus)
Enable the Continuous AF Setting to be
able to continuously focus automatically
when taking pictures.
• Cont. AF: O
•
Cont. AF: On
White Balance Setting
The White Balance Setting allows you to
adjust the color temperature for dierent
lighting scenes to ensure the most
accurate color reproduction.
• AWB
• Daylight
• Cloudy
• Fluorescent
•
Fluorescent CWF
•
Incandescent
•
Manual WB (Fully press the
shutter button to detect the
white balance value)
46 47
Focus Setting
In dierent Photo Shooting Modes, you
can select dierent focus methods.
• Single-AF
The focus frame appears on
the center of the LCD to help
you focus on the subject.
•
Multi-AF
The camera automatically
focuses the subject in a wider
area to ind the focal point.
Continuous Shot
Use this setting to perform continuous
shooting. After entering this mode,
you can shoot multiple images by
continuously holding the shutter button
down.
• Single
• Continuous Shot
• 3 Shots
• Time-Lapse 30sec
• Time-Lapse 1min
• Time-Lapse 5min
• Time-Lapse 10min
46 47
Color Eect
The Image Color Setting allows you to
select dierent eects.
1. In Photo Shooting Mode, press the
button to enter the Shooting Menu.
2. Press the up/down button to select the
Image Color Setting Menu, press the
button to enter the menu.
3. Press the left/right button to select the
image color setting options.
• Normal
• Vivid
• Sepia
• Black and White
The lash is disabled in the
Continuous Shooting Mode in order
to achieve quick succession of
shots.
48 4948 49
• Options in the Shooting Modes (
○
: Available
×
: Unavailable)
Options
Shooting Modes
○ ○ ○ ○
○ ○ ○ ○
○ ○
× ×
○ ○ ○
×
○ ○ ○
×
○ ○
× ×
×
○
× ×
×
○
× ×
× × ×
○
48 4948 49
Mode:
1. Press the button in Photo Shooting
Mode and press the up/down button to
select .
2. Press the button to enter the menu.
3. Press the up/down button to select
and press the button or right button
to enter the menu.
4. Press the up/down button to select the
item to be selected and press the
button or right button to enter the menu.
5. Press the up/down buttons to select
an option and press the button to
conirm.
Shooting Setting Menu
Quality
The quality setting can be used to adjust
the image compression ratio.
• Best (16M Average File Size: 4.0MB)
• Fine (16M Average File Size: 2.5MB)
• Normal (16M Average File Size:
2.0MB)
50 51
AF Assist Beam (Auto-Focus Assist
Beam)
In a darker environment, the AF Assist
Beam setting can be turned on for better
focus.
• O
•
On
Digital Zoom
This setting is for adjusting Digital Zoom.
If this function is disabled, only Ooptical
Zoom can be used.
• O
•
On
50 51
Quick Review
This option allows quick review of the
photos immediately after they are taken.
Each photo is displayed on the LCD
screen for the selected time.
• O
• 1 sec
• 2 sec
• 3 sec
A shorter Quick Review time will
improve battery life.
Date Imprint
Include a Date/Time stamp on the photo
image.
• O
• Date
• Date / Time
52 5352 53
Face Detection
Detects and focuses on faces to make all
faces as clear as possible in Photo Mode.
1. Hold the camera steadily and then
focus on your subject to detect their
face. A focus frame will appear around
the face when a face is detected.
1/50F2.9
2. Press the shutter button half-way down
to focus. The LCD will show a green
focus frame when the subject is in
focus.
1/50F2.9
3. Press the shutter button all the way
down to take pictures.
The Blink Detection Setting is usually
on. If the camera detects in the
course of quick review there is a
face with eyes closed, a prompt of
closed eyes will appear
.
52 5352 53
Movie Menu
Mode:
1. Press the button, select the
Mode and press the button to enter
the movie menu.
2. Press the up/down button to select the
movie menu to be set.
3. Press the left/right button to select the
movie menu to be set and press the
button to conirm.
Expo Metering (Exposure Metering)
Use this setting to select the “target”
size of the camera’s ield of view to be
metered.
• AIAE (Artiicial Intelligence AE)
Automatically selects the central
and peripheral metering, to
calculate the reasonable value
of metering by weighting.
•
Spot
For metering targets a small
area in the center of the
camera's ield of view.
•
Center
For metering targets a slightly
larger area in the center of the
cameras ield of view.
54 55
Video Quality
Set the image resolution used during
video recording.
The speed requirements for reading and
writing high resolution image pixel images
to a memory card are as follows:
No.
Image Pixel
Frame
Recommendation
Approximate
Recording time
(4GB)
1
1280 x 720
*
30 Class 4 19 Minutes
2
1280 x 720
15 Class 4
37 Minutes
3
640 x 480
30 Class 4
33 Minutes
* The longest recording time is 29
minutes at one time.
When recording in higher pixel
resolutions for extended periods of
time, this can cause the camera to
generate heat. This is not a camera
malfunction.
54 55
Color Eect
The Image Color Setting allows you to
select dierent eects.
1. Press the button to select the Image
Color Setting menu.
2. Press the left/right button to select the
Image Color Setting options.
• Normal
• Vivid
• Sepia
• Black and White
OIS (Optical Image Stabilization)
This mode can help reduce images blur
caused by unintentional shaking or low
light.
• OIS: O
• OIS: On
Use this Image Stabilization Mode in
dark environments.
Shooting in a windy or unstable
environment (such as a moving
vehicle) may cause blurry images.
56 57
Movie Setting Menu
Mode:
1. Press the button, and select to
enter the video recording screen.
2. Press the button, press the up/
down button to select and press
the button to enter the menu.
3. Press the up/down button to select
and press the button or right button
to enter the menu.
4. Select the items to be set and press
the button or the right button to
enter the menu.
5. Press the up/down buttons to select
an option and press the button to
conirm.
Digital Zoom
This setting is for adjusting Digital Zoom.
If this function is disabled, only Optical
Zoom can be used.
• O
• On
56 57
Playback Menu
Mode:
1. Press the button to display the
playback screen and press the
button to enter the menu.
2. Press the up/down button to select
the playback desired and press the
button to enter.
3. Press the left/right buttons to select
an option and press the button to
conirm.
Refer to the following pages for more
details about each setting.
HDR (High Dynamic Range)
With the HDR function, pictures that
are overexposed may be corrected to
optimize the highlights and lowlights
captured to more accurately represent
the actual scene.
: HDR
: Cancel
After using the HDR function, the
image will be saved as a new ile and
the original ile is still stored in the
memory.
58 59
Red-Eye Reduction
You can use this setting to reduce the
chance of red-eyes in a picture.
: Red-Eye Reduction
: Cancel
Rotate
You can use this setting to change the
orientation of the picture.
: Turn Right
: Turn Left
: Cancel
Videos and panoramic pictures
cannot be rotated.
The rotated picture ile will replace
the original photo.
58 59
Resize
This setting allows you to resize a picture
to a particular resolution and saves it as a
new picture.
: Resize to 1024 x 768
: Resize to 640 x 480
： Cancel
Only for adjusting pictures with high
resolution to a low resolution.
Color Eect
This setting allows you to change the
picture color eect. The ile is saved
as a new photo and stored in memory
together with the original photo.
: Cancel
: Vivid
: Sepia
: Black and White
60 6160 61
Mode:
1. Press the button to show the
playback screen, press the button,
and press the up/down button to select
.
2. Press the button to enter the menu.
3. Press the up/down button to select
and press the button or right button
to enter the menu.
4. Press the up/down button to select the
item to be set and press the button
or right button to enter the menu.
5. Press the up/down buttons to select
an option and press the button to
conirm.
Refer to the following pages for more
details about each setting.
Playback Setting Menu
60 6160 61
Protect
To prevent any pictures or videos from
accidentally being erased, use this setting
to lock one or all of the iles.
• One: Lock the selected photo or
video if they are unprotected;
unlock the selected photo or
video if they are protected.
• All: Lock all photos or videos.
• Reset: Cancel all locked photos or
videos.
Delete
You can delete one or all photo/video
iles.
• One: Delete one photo or video.
• All: Delete all photos or videos.
The “ ” indicator means a ile is
protected. File protection must be
removed irst before a ile can be
deleted.
Deleting iles will cause DPOF
(Digital Print Order Format) settings
to be reset.
Deleted iles will be permanently
deleted and will not be able to be
recovered or restored.
62 6362 63
Trim
The Trim Setting allows you to crop photos
and save them as new pictures.
1. Select [Yes] to conirm trim. Select a
section of the photo to be trimmed using
the zoom lever and direction buttons to
trim a photo.
2. Press the button and the [Save
Change?] prompt appears. Select [
] to
change and save the picture. Select [ ]
to cancel changes and return to the trim
prompt screen.
The image cannot be clipped/trimmed
again once it has been clipped to
640 x 480.
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile
and select a group of pictures that you
would like to print and will save your
selection on the memory card so that you
can use the memory card to print without
having to individually specify the photos
you want to print.
A printer that supports DPOF is
needed for photo printing.
62 6362 63
Setup Menu
Mode :
1. Press the button in any mode and
press the up/down button to select
.
2. Press the button to enter the menu.
3. Press the up/down button to select
and press the button or right button
to enter the menu.
4. Press the up/down button to select the
item to be set and press the button
or right button to enter the menu.
5. Press the up/down buttons to select
an option and press the button to
conirm.
Refer to the following pages for more
details about each setting.
64 65
Power Saver
This setting allows you to save power and
get the maximum possible running time
for your camera’s batteries. This setting
will also turn the LCD and camera o
automatically after a consecutive period
of inactivity.
• Auto
• Normal
• Best
Sound Settings
With this setting you may adjust the sound
and volume.
Press the left/right button to adjust
the volume and Press the
button to
conirm.
Power
Saver
LCD
Power O
Time
Turn O
Time
Auto 3 min 5 min
Normal 1 min 3 min
Best 30 s 1 min
64 65
Language
Refer to the “Reset your language” section
on page 19.
World Time
The world time setting is a useful function
for your overseas trips. This feature
enables you to display the local time on
the LCD while you are abroad.
1. Press the up/down to select the
departure place (
) and destination
(
) ields.
2. Press the left/right button to select a
city located in the same time zone as
that of the ield. Press the
button to
conirm settings.
Date & Time
Refer to the “Reset Date/Time” section on
page 20.
LCD Brightness
Use this setting to adjust the brightness of
your LCD.
LCD Brightness Normal
Normal
66 6766 67
Mode :
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press the up/down button to select
and press the button or right button
to enter the menu.
Format
Copy to Card
Reset
FW Version
File Numbering
<>>>
4. Press the up/down button to select the
item to be set and press the button
or right button to enter the menu.
5. Press the up/down buttons to select
an option and press the button to
conirm.
File Setting
Format
Please note: formatting enables you to
delete all contents on the memory card
and built-in memory, including protected
photo and movie iles.
If you select [Yes] the camera will
format its memory.
If there is no memory card in the
camera, the built-in memory will
be formatted; if there is a memory
card, only the memory card will be
formatted.
66 6766 67
File Numbering
After you take a picture or video clip, the
camera will automatically save it with a
sequential number. You can use this to
reset the ile numbering to 0001.
Copy to Card
Use this setting to copy the iles stored in
the camera’s built-in memory to a memory
card.
If there is no card available in the
camera, this function will not be
displayed.
68 6968 69
Firmware (FW) Version
Use this setting to view the current
camera irmware version.
FW Version
Current Ver: X.XX
Back
When there is a new irmware version in
the memory card, select [Yes] to update.
FW Version
Current Ver: X.XX
New Ver: X.XX
Cancel
Yes
Update Firmware?
Reset
Use this setting to restore the camera to
its original factory default settings.
68 6968 69
4. Press the up/down buttons to select
[PC] and press the button to
conirm.
Connecting to a Computer
You can use a Micro USB cable to connect
the camera and copy (transmit) photos to
a computer, printer or other device.
Setting the USB Mode
The camera’s USB port can be used
to connect to either a computer or a
printer. The following steps will allow you
to ensure that the camera is correctly
conigured to connect with a PC.
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press the up/down button to select
and press the button or right button
to enter the menu.
3. Press the up/down button to select
[USB] and press the button or right
button to enter the menu.
Connection Settings
70 7170 71
Transferring Files to your Computer
The computer will automatically detect
the camera as a removable drive. Double-
click the “My Computer” icon on the
desktop to locate the removable drive and
to copy folders and iles in the drive to a
directory on your PC as you would copy
any typical folder or ile.
Follow the steps below to connect the
camera to a computer:
1. Make sure the computer is turned on.
2. Connect one end of the supplied Micro
USB cable to the USB port on your
camera.
3. Connect the other end of the Micro
USB cable to an available USB port on
your computer.
4. After the transmission is complete,
disconnect the Micro USB cable
according to your computer
manufacturer's instructions specifying
how to safely remove USB devices.
70 7170 71
Connecting to a PICTBRIDGE
™
Compatible Printer
PICTBRIDGE™ technology allows printing
of the photos saved on a memory card by a
printer.
To ind out if a printer is PICTBRIDGE
™
compatible, simply look for the PICTBRIDGE
™
logo on the packaging or check the owner's
manual for speciications. With the
PICTBRIDGE
™ function on your camera, you
can print the captured photos directly to a
PICTBRIDGE
™ compatible printer using the
supplied Micro USB cable, without the need
for a PC.
Setting the USB Mode
The camera’s USB port can be set to connect
with either a PC or a printer. The following
steps will ensure that the camera is correctly
conigured to connect with a printer.
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press up/down button to select and
press the button or right button to
enter the menu.
3. Press the up/down button to select
[USB] and press the button or right
button to enter the menu.
4. Press the up/down button to select
[Printer] and press the button to
conirm.
After the camera is reset, it will
switch to PC mode automatically
from USB mode.
See “Using the PICTBRIDGE
™ Menu“
section on page 73.
72 7372 73
Connecting to your Printer
1. Make sure the printer is turned on.
2. Connect one end of the supplied Micro
USB cable to the USB port on your
camera.
3. Connect the other end of the Micro
USB cable to the USB port on the
printer.
If the camera is not connected to a
PICTBRIDGE™ compatible printer, the
following error message will appear on
the LCD.
The error message above will
also appear if the USB mode is
set incorrectly, in which case you
should disconnect the Micro USB
cable, check the USB mode settings,
ensure that the printer is turned on,
and then try connecting the Micro
USB cable again.
72 7372 73
Using the PICTBRIDGE
™
Menu
After setting the USB mode to Printer, the
PICTBRIDGE
™ menu will appear.
Press the up/down button to select a
menu item and press the button or
right button to enter the item.
Refer to the following sections for more
detailed information on each setting.
Print (with Date)
If you have set the date and time on
your camera, the date and time will be
recorded and saved with each photo you
take.
1. In the PICTBRIDGE™ menu, select
[Print (with Date)] and the screen as
shown below appears.
2. Press the left/right button to select the
photo to be printed.
74 75
3. Press the up/down button to select
the number of copies for the currently
displayed photo.
4. Press the button and the following
screen will appear.
5. Select [Yes] and press the button
to conirm printing; select [Cancel]
and press the
button to cancel
printing.
Print (without Date)
Use this setting to print the photos
without dates on them.
1.
In the
PICTBRIDGE
™
menu, select
[Print (without Date)] and the screen as
shown below appears.
2.
Press the left/right button to select a
photo to be printed.
3.
Press the up/down button to select
the number of copies for the currently
displayed photo.
4.
Press the
button and the following
screen will appear.
74 75
5. Select [Yes] and press the button
to conirm printing; select [Cancel]
and press the
button to cancel
printing.
Print Index
You can print all photos in the camera via
this function.
1. In the PICTBRIDGE™ menu, select [Print
Index] and the screen as shown below
appears.
2. Select [Yes] and press the button to
conirm printing; select [Cancel] and
press the
button to cancel printing.
76 7776 77
Print DPOF Images
To use DPOF printing, you must select
your photos for printing using the DPOF
settings beforehand. See “DPOF” section
on page 62.
1. In the PICTBRIDGE™ menu, select
[Print DPOF Images] and the screen as
shown below appears.
2. Select [Yes] and press the button to
conirm printing; select [Cancel] and
press the button to cancel printing.
Exit
Select [Exit] to exit the PICTBRIDGE™
menu. At this time, the message [Remove
USB Cable!] will appear on the screen.
Disconnect the Micro USB cable from the
camera and printer.
76 7776 77
Video System
You can use the AV cable (which should
be purchased separately) to connect the
camera and the television for setting up
the video output. Connect one end of the
AV cable to AV port of the camera, and
connect the other end to AVOUT port of
the television. To adjust the format of the
video output system according to your
requirements:
1. Press the button, press the up/down
button to select and press the
button to enter the menu.
2. Press the up/down button to select
and press the button or right button
to enter the menu.
3. Press the up/down button to select
[TVSystem] and press the button
or right button to enter the menu.
4. Press the up/down button to select
[NTSC] or [PAL] and press the
button to conirm.
NTSC: English, Chinese (Traditional),
Japanese, French, Korean,
Russian, Vietnamese, Greek,
Hungarian
PAL: German, Spanish, Italian,
Chinese (Simpliied),
Portuguese, Swedish, Danish,
Finnish, Indonesia, Norwegian,
Dutch, Turkish, Polish, Thai,
Croatian, Czech, Arabic, Hindi
The video output system changes
based on the selected language.
78 7978 79
This camera supports wireless connection for Eye-Fi cards. Enable the Eye-Fi connection
by following the steps below:
1. Press the button, press the up/down button to select and press the button
to enter the menu.
2. Press the up/down button to select and press the button or right button to
enter the menu.
3. Press the up/down button to select [Eye-Fi] and press the button or right button to
enter the menu.
4. Press the up/down buttons to select [On] or [O] and press the button to conirm.
If the Eye-Fi card is not available in the camera, this feature is not displayed.
Set Eye-Fi Card Connection Mode
78 7978 79
Product Speciications
Appendices
Design and speciications are subject to change without notice.
Sensor
Type 1/2.3"CCD
Eective Pixels 16.15 Megapixels
Total Pixels 16.44 Megapixels
Lens
Focal Length 4.3mm (Wide) — 64.5mm (Tele)
35mm ilm Equivalent 24mm (Wide) — 360mm (Tele)]
F Number F3.3 (Wide) — F5.9 (Tele)
Lens Construction 9 Groups 10 Elements
Optical Zoom 15x
Focusing Range
Normal: (Wide) 60cm ~ ∞
(Tele) 250cm ~ ∞
Macro: 3cm ~ ∞ (Wide Only)
Autofocus System TTL Autofocus
Anti-Handshake Optical Image Stabilization (OIS)
Digital Zoom 4x Digital Zoom (Combined Zoom: 60x)
80 81
Number of
Recording
Pixels
Still
(4:3)
16MP: 4608×3456
10MP: 3648×2736
5MP: 2592×1944
3MP: 2048×1536
0.3MP: 640×480
(3:2)
14MP: 4608×3072
(16:9)
12MP: 4608×2592
2MP: 1920×1080
Movie 1280×720 (15/30fps), 640×480 (30fps)
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1)
Support
Yes
File Format
Still
Exif 2.3 (JPEG)
Movie MOV [Image: Motion JPEG; Audio: G.711 (Monaural)]
Shooting Modes
Auto Mode, Manual Mode, Portrait Mode, Movie Mode,
Panorama Mode, Scene Mode
Scene Mode
Auto Scene, Landscape, Sport, Beach, Sunset, Fireworks,
Night Landscape, Snow, Children, ID, Glass, Photo Frame,
Panning Shot, Fish Eye, Party, Indoor, Leaf, Museum, Night
Portrait, Sketch
Detection Features Face, Smile, Blink
Red-Eye Removal Yes
HDR Yes (Post-Processing)
80 81
Panorama Up to 180° (Horizontal)
LCD Display 3.0inch (230k Pixels)
ISO Sensitivity Auto, ISO80/100/200/400/800/1600
AF Method Single AF, Multi-AF (TTL 9-point), Face-Detection
Exposure Metering Method
Artiicial Intelligence AE (AiAE), Center-Weighted
Average, Spot (Fixed to Center of Frame), Face AE
Exposure Control Method Program AE (AELock Available)
Exposure Compensation ±2EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 4 Seconds (Manual: 30 Seconds)
Continuous Shooting Yes
Playback Modes
Single Photo, Index (9/16 Thumbnails), Slide Show
Zoom (Approx. x2~x8)
White Balance Control
AWB, Daylight, Cloudy, Fluorescent, Fluorescent CWF,
Incandescent, Manual WB
82 8382 83
Flash
Flash Method Pop-up (Manual)
Flash Modes
Force O, Flash Auto, Fill Flash, Slow Sync., Slow
Sync. + Red-Eye, Red-Eye Reduction
Recording Media
Internal Memory: Approx. 8MB
SD/SDHC Card (Up to 32GB Support) (MMC Card Not
support )
Multi-Language Support 27 Languages
Jacks AVOUT/USB 2.0 (Micro 5 pin USB)
Eye-Fi Support Yes
Power
Rechargeable Li-ion Battery LB052, 3.7V 890mAh,
In-Camera Charging
Shooting Capability (Battery
Performance)
Approx. 210 Shots (Based on CIPA Standards)
Operation Environment Temperature: 0 ~ 40
o
C, Humidity: 0 ~ 90%
Dimensions (W×H×D)
Approx. 108.4×69.9×32.8mm (Based on CIPA
Standards)
Weight Approx. 185g (Body Only)
82 8382 83
Prompts and Warning Messages
Message Description Action
Warning! Battery
exhausted.
The camera battery is depleted.
It is a warning indicating that the
camera is going to shut o.
Charge the battery.
Lens obstruction,
Re-start Camera.
The lens is jammed or some
foreign object is preventing the
lens from functioning properly.
Turn the camera o and
restart it to reset the lens.
Suggest using
tripod.
The message will appear when
shooting in low light/illuminated
scenes.
Use of a tripod or other
support is suggested.
Battery
temperature is
too high.
The battery temperature reaches
58°C (136°F).
Let the battery cool before
attempting to use the camera
again. This message will
disappear after 2 seconds.
Built-in memory
error!
An error has occurred in the
internal memory.
Format the internal memory.
Slow shutter
is on: may
easily cause
overexposure.
When the B shutter is on, the
prompt appears on the screen
after you go back to the photo
shooting screen.
This message will disappear
after 2 seconds.
84 85
Message Description Action
Improper
alignment.
Please try again.
The oset is too big for panorama
shooting.
This message will
disappear after 2
seconds.
Connection
Failed!
In the case of failing to connect to a PC
or a printer.
Remove transmission
line to stop connection,
and the message is
removed.
Warning! Do not
turn o your
camera during
update!
This message appears during the
irmware update process.
This message
disappears after the
camera update and
restart.
Remove USB
Cable!
Indicates that you can disconnect the
Micro USB cable.
This message
disappears after you
disconnect the Micro
USB cable.
Write Protect! The memory card is locked.
Unlock the write-
protect switch of the
memory card.
Card Full ! Indicates that the memory card is full.
Insert a new memory
card or delete
unwanted images.
84 85
Message Description Action
Memory Full !
Indicates that the internal
memory is full.
Insert a new memory card or
delete unwanted images.
Card Error !
The memory card cannot
be recognized after being
formatted.
Insert a new memory card or
format the card with this camera.
Card is not
formatted.
The inserted memory card
is unformatted or has been
formatted on a computer
or other device and is not
compatible with this camera.
This message disappears after 2
seconds and the camera enters
the formatting process.
Slow access
When a memory card lower
than Class 4 is used to record
a HD movie, the writing speed
will be slower and recording
will not continue.
Use an memory card with Class 4
or higher.
No Red-Eye
Detected!
Red eyes have not been
detected in the image.
This message will disappear after
2 seconds.
86 8786 87
Message Description Action
This image cannot
be edited.
The ile format does not support
editing or the edited ile cannot be
edited again.
This message will
disappear after 2 seconds.
Exceeded
maximum folder
number.
Prompt message when the
archives or ile folders in the
memory card have reached the
maximum (9999 for archives, 999
for ile folder).
Copy the images to your
PC and format the memory
card with this camera.
Too many
pictures for quick
processing.
During the playback by date, the
images exceed speciications so
that it is not possible to play by
date.
This may be solved by
deleting unnecessary
images.
Unable to
recognize iles.
The format of the ile to be viewed
is not supported or the ile is
corrupted so it cannot be properly
read.
You may be able to play
it back on another brand
of camera or on your
computer.
No Picture!
When you press the playbutton, no
image iles exist in the camera or
memory card.
This message disappears
after 2 seconds and returns
to the photo shooting
screen.
Protected!
Undeletable!
The ile is protected. The message
appears when you go into delete
mode.
Unprotect the ile before
deleting.
86 8786 87
Troubleshooting
Problem Possible causes Solution
Camera does not turn
on
The battery has been
depleted.
The battery is not inserted
correctly.
Recharge the battery.
Correctly reinstall the
battery.
Camera turns o
suddenly during
operation
The battery has been
depleted.
Recharge the battery.
The picture is blurry
Camera shakes while taking
a picture.
Turn on OIS Feature.
Images and video iles
cannot be saved
The memory card is full.
The memory card is
locked.
Use another memory card
or delete unnecessary iles.
Unlock the memory card.
Images will not print
from the connected
printer
The camera is not
connected to the printer
correctly.
The printer is not
PICTBRIDGE™ compatible.
The printer is out of paper
or ink.
The printer paper is
jammed.
Check the connection
between the camera and
printer.
Use a PICTBRIDGE™
compatible printer.
Load paper into the printer
or replace the ink cartridge
in the printer.
Remove the jammed paper.
88 89
Problem Possible Causes Solution
Saving data to memory card
is slow
Using a memory card
below Class 4 may result in
slower recording times.
Use a memory
card with write
Class 4 or higher
to improve
performance.
Cannot write to the memory
card
The memory card has been
locked.
Release the write
lock of the memory
card or replace
with another card.
Too many movies to process
The number of pictures or
folders in the memory card
exceed the speciications,
so the playback of
data folder can not be
displayed.
Delete unwanted
iles.
The lash
lashes on the
LCD screen.
Current shooting
environment requires lash.
Turn on lash.
© 2019
JK Imaging Ltd. All Rights Reserved.
The Kodak trademark, logo and trade dress are used under license from Eastman Kodak Company.
All other logos, products or company names that are referred to in this document are trade names, trademarks or registered
trademarks of their respective owners and holders. The owners and holders are not ailiated with JK Imaging Ltd., our
products or our website.
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
kodakpixpro.com
Made in Myanmar
Ver. 7
