i
User Manual
DIGITAL CAMERA
KODAK
PIXPRO AZ425
1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
Company website: kodakpixpro.com
For Customers in the USA
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired camera operation.
For Customers in Europe
"CE" mark indicates that this product complies with the European requirements for safety, health,
environment and customer protection. "CE" marked cameras are intended for sales in Europe.
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of electrical waste
and electronic equipment in the European countries. Please do not throw the equipment into domestic
refuse. Please use the return and collection systems available in your country for proper, safe disposal
of this product.
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
BEFORE YOU START
2
About this Manual
Thank you for purchasing this KODAK PIXPRO Digital Camera. Please read this manual carefully and keep it in
a safe place for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be reproduced,
transmitted, transcribed, stored in a retrieval system or translated into any language or computer
language, in any form, by any means, without the prior written permission of JK Imaging Ltd.
All trademarks mentioned in this manual are used for identification purposes only and are properties of
their respective owners.
This manual provides you with instructions on how to use your new KODAK PIXPRO Digital Camera. Every
effort has been made to ensure that the contents of this manual are accurate: however JK Imaging Ltd.
reserves the right to make changes without notice.
Throughout this manual, the following symbols are used to help you locate information quickly and easily:
Indicates useful information.
The following symbols may be used throughout this manual to facilitate your understanding of how to
operate the camera:
[Item properties]: The optional properties in the camera interface are indicated by the [ ] symbol.
3
SAFETY NOTES
Safety Notes for this Camera
Do not drop the camera or allow it to hit solid objects.
Do not attempt to disassemble or repair the camera.
Do not use or store the camera in dusty places or on a beach without taking precautions to help prevent
dust or sand from entering the camera, causing possible damage.
Do not use or store the camera in a hot environment or in direct sunlight.
Do not use or store the camera near powerful magnetic fields, for example near a magnet or transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for a long period of time.
To prevent the camera from being damaged by moisture, do not use or store the camera in very humid
environments, such as in rain or near bodies of water.
If water accidentally comes in contact with the camera, turn the camera off immediately, remove the
battery and the memory card and dry it completely within 24 hours.
When you take the camera from a cold environment to a warmer environment, condensation may occur.
Please wait for a reasonable period of time before you turn the camera on and use it.
Before you remove the battery and memory card, the camera should be turned off.
When you clean the body of the camera, do not use abrasive, alcohol-based or organic cleansers or solvents.
Use a professional lens cleaning cloth and appropriate cleaner to wipe and clean the lens.
Download your photos and remove the memory card when you are going to store the camera for long
periods of time.
If this camera is not in use for a long period of time, please keep it in a dry and clean storage location.
Our company will not pay compensation for any failure of playback including: pictures or videos damaged
or unrecoverable by improper operation.
4
Safety Notes for Battery
Please use a battery that is the same type as the one included.
Please use the attached charger to charge the battery.
If battery fluid leaks inside the camera, contact our customer service department immediately. If battery
fluid leaks onto your skin, rinse your skin with clean water and seek immediate medical attention.
Disposal of used batteries should be carried out in accordance with your local (national or regional)
regulations.
To prevent the battery from being damaged, do not drop the battery or allow it to hit solid objects or to be
scratched by foreign objects.
Do not let the battery come in contact with metal objects (including coins) to avoid short circuiting,
discharging, excessive heat or possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep the battery contacts dry.
Do not heat the battery or throw it into a fire to avoid a possible explosion.
Do not store the battery in a hot environment or in direct sunlight.
If the battery overheats during charging or use, stop charging or use immediately. Turn off the product,
remove the battery carefully and wait until it cools down.
When the camera is stored for a long period of time, remove the battery and keep it in a safe, dry place
that is not accessible to infants and children.
In colder environments, the performance of the battery could be noticeably reduced.
When you install the battery, align the battery markings according to the positive and negative markings
inside the camera battery compartment. Never force the battery into the battery compartment.
5
Safety Notes for Memory Cards
We highly suggest buying only well-known, name brand memory cards to ensure peak performance and
reliability.
This KODAK PIXPRO digital camera takes standard SD, SDHC or SDXC memory cards. Please purchase a
Class 10 or higher speed SD card with memory of 4GB-528GB max. (SD cards are not included with this
camera unless otherwise sold as part of a bundle.)
Format the memory card using the camera before you use it or insert a new one.
Do not drop the memory card or allow it to hit solid objects to avoid damaging it.
Do not attempt to disassemble or repair the memory card.
Do not expose the memory card to water. Always keep it dry.
Do not remove the memory card when the camera is turned on. Otherwise, the memory card and photo /
video files could be permanently damaged.
Do not directly edit the data on the memory card. Copy the data to your computer before you edit files.
When the camera is stored for long periods of time, be sure to download your photos and remove the
memory card. Store the memory card in a dry environment.
Do not modify the name of the files or folders of the memory card using your computer. Modifying the file
names may cause the files to not be recognized on the camera or a possible permanent error may occur.
A photo taken with the camera will be stored in the folder that is automatically generated on the memory
card. Do not store photos that are not taken using this camera in these folders as the pictures cannot be
recognized during playback.
When you insert the memory card, make sure the notch of the card matches the markings on the top of
the camera card slot.
6
Other Safety Notes
Do not disconnect the power or turn the camera off during the update process. Doing so may cause
incorrect data to be written and the camera may not power on later.
Do not hang the neck or wrist strap of the camera around the neck of a child.
When using your camera on an airplane, observe the relevant rules specified by the airline and FAA
regulations.
Due to the limitations of manufacturing technology, the LCD may have a few dead or bright pixels. These
pixels do no effect the quality or performance of the camera, photos or video.
Do not expose the camera’s LCD to water. In a humid environment, only wipe it with a soft, dry and
cleaning cloth.
If the LCD screen is damaged, pay particular attention to the liquid crystal in the screen. If any of the
following situations arise, immediately take the steps listed below:
1. If liquid crystal comes in contact with your skin, please wipe with a dry cloth, wash thoroughly with
soap, and rinse with plenty of clean water.
2. If liquid crystal gets into your eye, flush the eye immediately with plenty of clean water for at least 15
minutes and then seek medical assistance.
3. If liquid crystal is swallowed, immediately rinse your mouth thoroughly with clean water and induce
vomiting. Seek medical assistance.
7
WARNING
Altering, tampering or modifying the any parts of AZ425 camera is unauthorized and will void the
manufacturer’s warranty and “could” void Federal and/or State Compliance.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this camera equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the camera equipment and receiver
- Connect the camera equipment into an outlet on a circuit different from that to which the receiver is
connected
- Consult the dealer or an experienced radio / TV technician for help
8
BEFORE YOU START .................................................................................................1
SAFETY NOTES ....................................................................................................... 3
CONTENTS .............................................................................................................. 8
GETTING STARTED ................................................................................................. 12
Accessories Included ....................................................................................................................................... 12
Installing Lens Cap and Neck Strap ................................................................................................................13
Part Names .......................................................................................................................................................14
Installing Battery and Memory Card ...............................................................................................................16
Charging Battery ..............................................................................................................................................18
Turning Camera On and Off ............................................................................................................................19
How to Take Pictures ........................................................................................................................................ 20
Set your Language, Date / Time ......................................................................................................................21
Set your Language, Date / Time after the First Power-On .......................................................................21
Resetting your Language ...........................................................................................................................22
Resetting Date / Time ................................................................................................................................23
MODE OVERVIEW ..................................................................................................24
Display Setting .................................................................................................................................................24
LCD Screen Display ..........................................................................................................................................25
Using the Mode Dial .........................................................................................................................................28
Auto Mode
...........................................................................................................................................28
Program AE
.........................................................................................................................................28
CONTENTS
9
Shutter Priority ...................................................................................................................................28
Aperture Priority
................................................................................................................................29
Manual Mode .....................................................................................................................................29
Face Beautifier
.................................................................................................................................29
Panorama Mode
................................................................................................................................30
Scene Mode
....................................................................................................................................31
Movie Mode
.......................................................................................................................................34
Custom Settings
................................................................................................................................34
BASIC OPERATION ................................................................................................ 36
Using the Zoom Function................................................................................................................................36
Focus Setting...................................................................................................................................................37
Macro Mode.....................................................................................................................................................38
Self-Timer Setting ............................................................................................................................................39
Flash Mode ......................................................................................................................................................40
White Balance Setting .....................................................................................................................................42
Continuous Shot .............................................................................................................................................43
EV Setting ........................................................................................................................................................ 44
Using Quick Recording ...................................................................................................................................45
Color Setting ...................................................................................................................................................46
PLAYBACK ..............................................................................................................48
Viewing Photos and Videos ............................................................................................................................48
10
Thumbnail View ............................................................................................................................................... 49
Using Zoom Playback (for still pictures only) .................................................................................................51
Slideshow ........................................................................................................................................................52
Animation Panorama Playback .......................................................................................................................53
Photos and Video Deletion .............................................................................................................................54
USING THE MENUS ................................................................................................55
Photo Menu .....................................................................................................................................................55
Photo Shoot Settings Menu
.....................................................................................................................59
Quality ....................................................................................................................................................... 59
AF Assist Beam .......................................................................................................................................... 60
Digital Zoom .............................................................................................................................................. 60
Date Imprint .............................................................................................................................................. 61
Quick Review............................................................................................................................................. 61
Custom Settings ....................................................................................................................................... 62
Face Detection .......................................................................................................................................... 62
Movie Menu .....................................................................................................................................................63
Movie Shooting Settings Menu
...............................................................................................................65
AF Assist Beam .......................................................................................................................................... 66
Digital Zoom .............................................................................................................................................. 66
Custom Settings ....................................................................................................................................... 66
Playback Menu ................................................................................................................................................68
Playback Settings Menu
.........................................................................................................................72
Protect ....................................................................................................................................................... 72
11
Delete ........................................................................................................................................................ 73
DPOF (Digital Print Order Format) ............................................................................................................ 74
Trim ............................................................................................................................................................ 74
General Settings .....................................................................................................................................75
Sound Settings.......................................................................................................................................... 76
Power Saver............................................................................................................................................... 76
Language ................................................................................................................................................... 77
World Time ................................................................................................................................................ 77
Date & Time ............................................................................................................................................... 77
LCD Brightness .......................................................................................................................................... 77
Connection Settings
...............................................................................................................................78
File Settings ............................................................................................................................................80
Format ....................................................................................................................................................... 81
Copy to Card ............................................................................................................................................. 81
File Numbering .......................................................................................................................................... 82
Reset .......................................................................................................................................................... 82
Firmware (FW) Version .............................................................................................................................. 82
APPENDICES ......................................................................................................... 83
Specifications ..................................................................................................................................................83
Prompts and Warning Messages ....................................................................................................................87
Troubleshooting ..............................................................................................................................................91
Memory Card Compatibility ...........................................................................................................................92
12
GETTING STARTED
Accessories Included
Your camera box should contain the camera model you purchased along with the following accessories.
If anything is missing or appears to be damaged, please contact your retailer first or our customer service
center. (The battery chargers may be a little different in shape due to the difference of countries or regions
this type of cameras are sold to, and are subject to matching the physical product).
Rechargeable Li-ion
Battery
AC Adapter (Optional) Micro USB Cable Neck Strap
Quick Start Guide Warranty Card Service Card
Quick Start Guide
STOP
Lens Cap with Cord
13
Installing Lens Cap and Neck Strap
14
Part Names
1 Zoom Lever
2 Shutter Button
3 Strap Eyelet
4
Exposure Compensation Button
5
Continuous Shot Button
6 Power Switch
7 AF Assist Beam / Self-Timer Lamp
8 Mode Dial
9 Flash Lamp
10 Flash Button
11 Microphone
12 Speaker
13 Lens
15
14
“I” Button
15 Indicator Lamp
16
Fast Video Recording Button
17
Menu Button
18 Micro USB Port
19
[
] AF Button / Arrow Button (Up)
20
[
] Flash Button / Arrow Button (Right)
21
[
] Delete Button / Self-Timer Button /
Arrow Button (Down)
22
Display Button
23 Battery Door Cover
24
Playback Button
25 Tripod Socket
26
[
] Macro Button / Arrow Button (Left)
27
SET Button
28 LCD
16
Installing Battery and Memory Card
1. Open the battery cover door.
2. Insert the battery into the battery slot in the
correct direction as shown in the following
diagram.
1
2
Battery Lock Knob
17
Write Protection
Toggle Switch
1
2
3. Insert the memory card into the memory card slot as
shown in the diagram below:
A memory card (SD / SDHC / SDXC) is necessary
to store photos and videos and is not included in
all camera packaging. It needs to be purchased
separately. Please use a memory card which is
Class 10 or higher and has a capacity of 4GB to
512GB.
To remove your memory card, open the battery
cover door, gently press the memory card to eject
it and remove it carefully.
4. Close the battery cover door.
18
Charging Battery
Before you charge your battery, you should
turn the camera off and insert the battery.
1. Connect the camera to the power charger
using the supplied USB cable
2. Insert the plug of the power charger into
the wall outlet to charge the battery.
The charger is for indoor use only.
After the battery is stored for long
periods of time, use the supplied power
charger to fully charge the battery prior
to use.
19
Turning Camera On and Off
Slide the Power Switch to turn the camera on/off.
When the power is off, press and hold the Playback
Button
to power on and enter Playback Mode.
Power Switch
Indicator Lamp
3. When the camera is turned off, you can also connect
the camera to your computer using a Micro USB
cable to charge the battery.
Charging indicator:
Orange: Charging
The indicator lamp will go out once charging is
finished.
To maximize battery life, charge the battery for at
least 4 hours the first time.
Please charge the battery indoors between 0°C
and 40°C (32°F and 104°F).
20
1. Hold the camera with both hands, being careful
to not block the flash and lens with fingers.
2. Point the Lens toward the object you want to
take a picture of, then frame it with the LCD.
3. Use the Zoom Lever to select Tele or Wide
positions to zoom in or out on your subject.
4. Press the Shutter Button halfway down to focus
on the subject. When the focus frame turns
green, press the Shutter Button all the way down
completely to take the picture.
How to Take Pictures
21
Set your Language, Date / Time
Set your Language, Date / Time after the First Power-On
1. When you turn the camera on for the first time, the language selection screen appears.
2. Press the [
] / [ ] / [ ] / [ ] buttons to select your desired language.
3. After you press the
button to confirm your language selection, the Date / Time settings screen will
appear.
4. Press the [
] / [ ] buttons to select the Date / Time to be adjusted: This information is displayed in
YYYY.MM.DD / HH:MM.
5. Press the [
] / [ ] buttons to adjust the value for the desired Date / Time.
6. Press the
button to confirm the time settings and the snapshot screen will appear.
22
Resetting your Language
After you set your language for the first time, follow the instructions below to reset your desired language.
1. Press the
button and press the [ ] / [ ] buttons to select . Press the button to enter
the menu.
2. Press the [ ] / [ ] buttons to select , and press the / [ ] button to enter the menu.
3. Press the [
] / [ ] buttons to select [Language] and press the / [ ] button to enter the
menu.
4. Press the [ ] / [ ] / [ ] / [ ] buttons to select your desired language and press the
button to confirm.
5. Press the
button and the snapshot screen will appear.
Sound Settings
Power Saver Auto
Language English
World Time Home
Date & Time 2022.10.10 00:00
Español
English
Français
Português
Italiano
Deutsch
Svenska
Language
23
Resetting Date / Time
After you set your Date / Time for the first time, follow the instructions below to reset date and time.
1. Press the
button and press the [ ] / [ ] buttons to select . Press the button to enter
the menu.
2. Press the [ ] / [ ] buttons to select , and press the / [ ] button to enter the menu.
3. Press the [
] / [ ] buttons to select [Date & Time] and press the / [ ] button to enter
the menu.
Sound Settings
Power Saver Auto
Language English
World Time Home
Date & Time 2022.10.10 00:00
Date & Time
: . .
10 10 00 00
Back
H-M
2022
4. Press the [ ] / [ ] buttons to select the Date / Time to be adjusted: This information is displayed in
YYYY.MM.DD/HH:MM.
5. Press the [
] / [ ] buttons to press the value for your selected entry. After you finish your
settings, press the
button to confirm.
6. Press the button and the following snapshot screen will appear.
24
Display Setting
Press the
button to display the settings: Classic, Full, Off.
Classic: Displays the camera parameters on screen Full: Camera parameters with Grid and Histogram
-0.3
EV
15
F5.0
400
ISO
1234
00:56:00
SD
x3.6
SD
-0.3
EV
15
F5.0
400
ISO
1234
00:56:00
x3.6
Off: Does not display any additional icons on screen
MODE OVERVIEW
25
LCD Screen Display
Overview of the Screen Icons in Photo Shooting Mode
SD
-0.3
EV
15
F2.9 400
ISO
1234
00:56:00
SD
IN
x3.6
1 Self-Timer 9 Histogram 17 Color Effect
2 Flash Mode 10 Optical Image Stabilization (OIS) 18 Focus Frame
3 Macro Mode 11 Aperture 19 Image Size
4 Shooting Mode 12 Shutter Speed 20 Number of Remaining Shots
5 AF Mode 13 Zoom Display 21 Video Quality
6 Continuous Shot 14 Memory Card / Built-In Memory 22 Remaining Recording Time
7 Expo Metering 15 Battery Status 23 ISO Value
8 HDR 16 White Balance 24 Exposure Compensation (EV Value)
26
Overview of the Screen Icons in Movie Mode
SD
-0.3 EV
00:56:00
2
3
4
5
6
7
1
9
10
11
12
13
14
8
IN
SD
x3.6
1 Zoom Display 6 Self-Timer 11 Focus Frame
2 Movie Mode 7 Optical Image Stabilization (OIS) 12 Remaining Recording Time
3 Single-AF 8 Memory Card / Built-In Memory 13 Video Quality
4 Expo Metering 9 Battery Status 14 Exposure Compensation (EV Value)
5 Macro Mode 10 Color Effect
For optimal video recording and more than a couple of test photos, it is recommended that an SD, SDHC
or SDXC memory card be used.
Optical Zoom and Digital Zoom can be adjusted (168X in total). Digital Zoom can be adjusted to 4X.
27
Overview of the Screen Icons in Playback Mode
1/45
15:3700:01:23
x2
SD
SD
1
3
2
4
5
6
7
8
11
13
12
14
15
16
17
10
9
IN
SD
25
1/45
x2
SD
15:37
SD
18
19
21
20
22
23
2022 10-10
2022 10-10
1 File Protection 9 Memory Space (indicating the current number
of photos and total number of photos)
17 Shooting Date
2 DPOF File 10 Memory Card / Built-In Memory 18 Continuous Shot
3 Movies / Animated
panoramas
11 Battery Status 19 Number of Photos in Burst
4 HDR 12 Image Zone 20 Frame Backward
5 Touch-up 13 Playback Type 21 Switch to Single Playback
6 Display Mode 14 Deletion 22 Frame Forward
7 Video Quality 15 Image Zoom Ratios 23 Play
8 Recording Time 16 Zoom Magnification Area
28
Using the Mode Dial
This camera provides a convenient Mode dial that allows you to manually switch between different modes
with ease.
Auto Mode
Auto Mode is the most common and easiest mode to take photos. While operating in this mode, the camera
automatically optimizes numerous camera settings to optimally adjust settings for your photos and videos for
the best possible results.
Program AE
The user can switch the ISO and EV value according to personal preference, the camera can automatically set
the shutter speed and aperture value.
Shutter Priority
This setting allows you to adjust the shutter speed, EV value and ISO value. The camera automatically sets the
aperture value based on the shutter speed and ISO value to get the most appropriate exposure value.
29
Aperture Priority
In this mode, you can adjusting the aperture size, EV and ISO values. The large aperture is to highlight the
object focused through blurring the background, while the small aperture is for clear focusing on both the
background and the object.
Manual Mode
The user can adjust the aperture, shutter speed and ISO values manually. This setting is generally used to
shoot static photos.
Face Beautifier
This mode automatically enhances facial features with skin softening touches and eye brightening
capabilities.
1. Press the
button and press the [ ] / [ ] button to select .
2. Press the [
] / [ ] button to select an option and press the button to confirm and enter the
shooting screen.
Effect 1
Skin Soften
Effect 2
Skin Soften + Eye Brightening
Effect 3
Skin Soften + Eye Brightening + Eye Enlargement
Skin Soften
Effect 1
30
Panorama Mode
This feature allows you to capture a panoramic
view that will have significantly more content
than a single photograph. Follow the instruction
arrow with a smooth and steady movement of
the camera to seamlessly shoot an ultra-wide
scene of up to 360 degrees.
1. Press the [
] / [ ] / [ ]/
[ ] button to select a shooting direction.
(The right direction is used as default if you
do not make any choice), 2 seconds later,
the camera is ready to take pictures. You can
also press the
button or half press the
Shutter Button to be ready to take pictures.
2. Compose your shot on the LCD and press the
Shutter Button half way down to focus on the
subject. After focusing, continue to press the
Shutter Button all the way down to take the
first picture. At this time, the process dialog
of panorama mode stitching appears on the
screen.
3. Rotate the camera according to the set
direction. When the range of rotation does
not exceed the range that the camera
can detect, the progress dialog along the
indication arrow partially turns orange. When
it completely turns orange, panorama mode
shooting is finished.
Save
Cancel
In Panorama Mode, the Flash, Self-Timer, Macro
Modes and Exposure Compensation are not
available. Focus Adjustment is also not available
at this time.
During Panorama Mode shooting, when the
moving direction of the camera is wrong or
the angle deviates from the internal settings,
the LCD shows a warning message [Improper
alignment. Please try again.] and the current
pictures taken are saved.
During Panorama Mode shooting, press the
button to interrupt shooting and save the current
pictures. Press the [ ] button to cancel
shooting and delete previously taken pictures.
Panoramic images can be played back by the
method of flash playing. Refer to the “Animation
Panorama Playback” section on page 53.
31
Scene Mode
You can press the [ ] / [ ] button to select your desired scene from the 13 preset modes according to
the type of environment you are shooting in and press the
button to confirm your selection. The camera
then automatically configures the most appropriate settings for the best possible photos.
Auto Scene
Sunset
If in need of changing the scene, please press the button and then the button and finally the
[ ] / [ ] button to select the new scene.
Auto Scene
The camera can intelligently detect different environments and automatically select the best scene and photo
settings for you.
ASCN can intelligently detect the following scenes:
Auto Mode The camera automatically adjusts the exposure and focus to ensure the best
possible pictures.
Landscape Mode For landscapes, automatically adjusts the exposure and reproduces vivid green
and blue colors.
32
Backlit Portrait When the sun or any other light source is behind the target you want to shoot, this
mode automatically adjusts the foreground exposure to produce the best pictures
possible.
Macro Mode The macro setting is ideal for shooting small objects or extreme close-up photos.
Night Landscape
Mode
For night scenes, this mode automatically increases the ISO value to compensate
for low light.
Portrait Mode Most suitable for capturing people with focus on their faces.
Night Portrait When you take portraits at night, or in low light conditions, this mode
automatically adjusts the exposure for people and night scenes.
Night Landscape
For night scenes. Use of a tripod or a flat surface to rest the camera on is recommended with this setting.
Pet Mode
The camera automatically takes a picture when a dog or cat face is detected.
Snow
For snowy conditions. Reproduces natural, clear, white scenes.
Party
Suitable for taking indoor party pictures, even under complicated lighting conditions.
33
Sport
For fast-moving subjects. Captures sharp, action shots with minimal blur. This mode is not recommended for
shooting indoors.
Night Portrait
For portraits against night scenery. Use of a tripod or a flat surface to rest the camera on is recommended
with this setting.
Portrait
The camera is set to automatically adjust exposure for realistic capture of skin tones.
Children
Turns flash off automatically. Avoids disturbing the subject and is suitable for taking photos of children.
Landscape
For landscapes and outdoor shots. Vivid reproduction of greens and blues.
Sunset
For sunsets. Captures subjects in strong sunlight. Use of a tripod or a flat surface to rest the camera on is
recommended with this setting.
Fireworks
For fireworks at night. Use of a tripod or a flat surface to rest the camera on is recommended with this setting.
Beach
For taking pictures in areas with strong sunlight.
34
Movie Mode
Switch to this mode to record videos.
1. Press down the Shutter Button to start recording.
2. Once you are finished, press the Fast Video Recording Button
or the Shutter Button to stop recording
and return to the shooting screen.
Custom Settings
The user can store the frequently used shooting modes and parameters and switch to this mode for quick
adjustment.
•Settings under
mode (unset state or state after reset):
1. Turn the mode dial to select the mode
, and enter the setup screen.
2. Press the [
] / [ ] button to select a capture mode that you want to define as , and press the
button to enter the shooting screen.
Go to setting CS mode.
Or
Rotate the mode dial to skip.
Yes
Select one capture mode to define CS.
Auto Mode
Save
Exit
35
•For setting under other modes (use this method to select a different custom setting):
1. Select any mode to be stored and set your desired parameters in the current mode.
2. Press the
button, press the [ ] / [ ] buttons to select and press the button to
enter the menu. Press the [
] button to select [Custom Settings] and press the / [ ]
button to enter the menu afterwards.
Custom Settings
Face Detection Off
Custom Settings
Reset camera settings to
custom settings mode.
Yes
No
3. Select [Yes] to save or [No] to cancel.
4. Turn the mode dial to switch to the custom settings (
).
5. The photo settings you stored the last time are invoked.
When the mode is used for the first time, there is no preset parameter stored in the mode.
If you want to remove the parameter setting of [Custom Settings], please see the reset function on page
62 to operate.
36
Using the Zoom Function
Your camera is equipped with two types of zoom functions: Optical Zoom and Digital Zoom. Toggle the Zoom
Lever of the camera to zoom in or out of the subject while taking pictures.
When the Optical Zoom reaches the threshold as Digital Zoom, release and turn the Zoom Lever to T to switch
between the Optical Zoom and Digital Zoom.
BASIC OPERATION
SD
-0.3
EV
15
F5.0
400
ISO
1234
00:56:00
x3.6
Zoom Indicator
Zoom Lever
Zoom Out Zoom In
37
Focus Setting
This setting allows you to select different modes for optimum focus.
1. Press the [
] button to enter the Focus Menu.
Single-AF
2. Press the [ ] / [ ] buttons to select the following 3 modes:
Single-AF
The focus frame appears on the center of the LCD to help you focus on the subject.
Multi-AF
The camera automatically focuses the subject in a wider area to find the focal point.
Object Tracking
Smart tracking of the object in motion under the focusing shooting.
3. Press the
button to confirm the settings and exit the menu.
When
is enabled, Object Tracking function is not available.
38
Macro Mode
The Macro Setting is ideal for shooting small objects or close-up photos. This mode allows you to focus on
subjects very close to the camera and will provide very detailed photos.
1. Press the [
] button to enter the Macro Menu.
Macro Off
2. Press the [ ] / [ ] buttons to select the following 2 modes:
Macro Off
Select this option to disable Macro.
Macro On
Select this option to focus on subjects 1.6cm from the lens.
3. Press the
button to confirm the settings and exit the menu.
39
Self-Timer Setting
Use this function to take pictures at pre-set intervals. The camera shutter speed can be set to 2 seconds, 10
seconds or Smile Detection.
1. Press the [
] button to enter the Self-Timer Menu.
Self-timer Off
2. Press the [ ] / [ ] buttons to select one of the following 4 modes:
Self-Timer Off
Disables the Self-Timer.
Self-Timer 2sec
A single picture is shot 2 seconds after the Shutter Button is pressed.
Self-Timer 10sec
A single picture is shot 10 seconds after the Shutter Button is pressed.
Self-Timer Smile
Press the Shutter Button and a picture will be taken immediately after a smile is detected.
3. Press the button to confirm the settings and exit the menu.
40
When enabling the Self-Timer feature, pressing the Shutter Button or the [ ] button can disable
the Self-Timer and return to the shooting screen without keeping the Self-Timer setting.
When enabling Smile Detection, pressing the Shutter Button or the
button can disable the Self-Timer
and return to the shooting screen without keeping the Self-Timer Smile Setting.
Flash Mode
The flash provides supplemental light for scenes. The flash is usually used when shooting against the light to
highlight the object; it is also suitable for metering and shooting in darker scenes to improve the exposure.
1. Press the Flash
Button to pop up the flash.
2. Press the [ ] button to enter the Flash Settings Menu.
Flash Auto
1
2
41
3. Press the [ ] / [ ] buttons to select one of the following 6 modes:
Force Off
Flash is turned off.
Flash Auto
Camera flash goes off automatically based on lighting conditions.
Force Flash
The flash will engage with each shot even if there is enough available light to take the photo
without flash.
Slow Sync.
This allows you to take pictures of people at night that clearly show both your subjects
and the night time backdrop. The use of a tripod is recommended when shooting with this
setting.
Slow Sync. + Red-Eye
Use this mode for slow synchrony shots with red-eye reduction.
Red-Eye Reduction
The camera emits a brief pre-flash before the picture is taken to reduce red-eye effects.
4. Press the
button to confirm the settings and exit this option.
42
White Balance Setting
The White Balance setting allows you to adjust the color temperature for different lighting scenes to ensure
the most accurate color reproduction.
1. Press the
button to enter the White Balance Settings Menu.
AWB
2. Press the [ ] / [ ] buttons to select one of the following 8 modes:
AWB Incandescent
Daylight
Manual WB
(Fully press the Shutter Button to detect the White
Balance value)
Cloudy
Fluorescent
Color Temp. (1900K~10000K)
Press the [
] / [ ] buttons to “Adjust the
K value”; Press the [ ] button to exit the K value.
Fluorescent CWF
3. Press the button to confirm the settings and exit this option.
43
Continuous Shot
Use this setting to perform Continuous Shooting. After entering this mode, you can shoot multiple images by
continuously holding the Shutter Button down.
1. Press the
button to enter the Continuous Shot Settings Menu.
Single
2. Press the [ ] / [ ] buttons to select one of the following 5 modes:
Single Cont. Shot - Fast (2M)
Continuous Shot Time - Lapse (30sec / 1min / 5min / 10min)
Cont. Shot - High Speed (VGA)
3. Press the button to confirm the settings and exit this option.
4. Press the Shutter Button to start shooting.
The flash is disabled in Continuous Shot Mode in order to achieve quick succession of shots.
44
EV Setting
The EV Function Menu of the camera includes
functions, such as EV, ISO, Shutter and Aperture
Adjustment. Using the appropriate Function
Settings can improve your pictures.
1. Press the
button to display the Settings
screen.
2. Press the [
] / [ ] buttons to select the
Setting options.
1/50
+0.3 EV 800 ISO
F3.7
3. Press the [ ] / [ ] buttons to adjust
the option values.
4. Press the
button to complete the setting and
enter Shooting Mode.
Exposure Compensation
Set up Exposure Compensation to adjust the
picture brightness. If there is very high contrast
between the photographed object and the
background, the brightness of the picture can be
adjusted as necessary.
The adjustable range of exposure value is from EV
-3.0 to EV + 3.0.
ISO
The ISO Function allows you to set the sensitivity of
the camera’s light sensor based on the brightness
of the scene. To improve the camera’s sensor
performance in darker environments, a higher
ISO value is required. A lower ISO value is needed
when shooting in brighter conditions.
Pictures taken at higher ISO settings will generally
have more noise than those taken at lower ISO
settings. The camera’s ISO settings include: Auto,
100, 200, 400, 800, 1600 and 3200.
45
Shutter Adjustment
For shutter speed, the camera may automatically
set the aperture value corresponding to the
manually set shutter speed to obtain the most
suitable exposure value. The movement of objects
may be shown by adjusting the shutter speed. High
shutter value can help you more clearly capture
fast moving objects, while low shutter value can
better show the movement of objects.
Aperture Adjustment
You can adjust the aperture size value. Selecting
a large aperture opening will emphasize the
point of focus and show a blurry background and
foreground. A small aperture opening will keep
both the background and main object in clear
focus.
Using Quick Recording
In the Photo Shooting Mode, press the Fast Video
Recording Button
to begin recording video.
00:00:0600:00:06
x3.6
Once you are finished, press the Fast Video
Recording Button or the Shutter Button to stop
and store the video. The camera will return to the
Shooting Mode automatically.
46
Color Setting
The image color setting allows you to select
different color effects.
1. Press the
button to enter the Color Effect
Settings Menu.
2. Press the [
] / [ ] buttons to select the
color effect setting options.
NormalNormal
There are 7 options in Mode:
Normal Dreamy
Vivid Vignetting
Black and White Salon
Sepia
There are 4 options in Movie Mode (
):
Normal
Vivid
Black and White
Sepia
When the mode other than
is set to mode, the color effect
cannot be adjusted.
When HDR or Continuous Shot function
is enabled, Dreamy, Vignetting and Salon
cannot be displayed.
47
Options in the shooting mode (O: Available X: Unavailable)
If each option is available in the mode set to
, the option is available in mode; otherwise, it is not
available.
Options
Shooting Modes
O O O O O X X X X
O O O O O O X
O (
)
O
O O O O O O X
O (Except
)
O
O O O O O O X
O (
)
X
X O O O O X X X X
O O O O O X X
O (
)
X
EV X O O O X O X X O
ISO X O O O O O X X X
Shutter X X O X O X X X X
Aperture X X X O O X X X X
X O O O O X X X O
48
PLAYBACK
Viewing Photos and Videos
To view captured photos and video clips on the LCD:
1. After pressing the
button, the last photo or video clip taken will be displayed on the LCD.
2. Use the [
] / [ ] buttons to scroll through the photos or video clips stored on the built-in memory
or on the Memory Card in the camera.
3. To play a selected video clip, press the button to enter the Movie Playback Mode.
An operation guide appears on the screen when playing back a video. Press the appropriate buttons to
enable the corresponding functions.
00:00:47 00:01:23
1
2
3
4
5
00:00:47 00:01:23
6
7
8
9
10
1 Increase Volume
6
Return Back to the Beginning of the Video
2 Pause
7
Play
3 Fast Forward
8
Frame Forward
4 Rewind
9
Frame Backward
5 Decrease Volume
10
Cancel Playback
Mute
49
Thumbnail View
When in Playback Mode, rotate the Zoom Lever counter clockwise to the position
to display thumbnail
images of the photos and videos on the LCD screen.
W Zoom Out T Zoom In
•For Normal Mode
1. Slide the Zoom Lever to switch between 3 x 3 and 4 x 4 thumbnails.
2. When a 3 x 3 or 4 x 4 thumbnail is displayed, press the [ ] / [ ] / [ ] / [ ]
buttons to select the picture or video clip to view. Press the button to restore it to the original size.
50
•For Date Mode or Cont. Photo Mode
1. Press the
button to display the playback screen and press the button to enter the menu.
2. Select
and press the button to confirm.
3. Press the [
] / [ ] buttons to select / .
4. Slide the Zoom Lever to switch between 2 x 2 and 4 x 4 thumbnails.
5. When a 2 x 2 or 4 x 4 thumbnail is displayed, press the [
] / [ ] / [ ] / [ ]
buttons to select the picture or video clip to view. Press the
button to restore it to the original size.
Date Mode: Arranged by date.
[40]
[3]
[10]
[10]
‘22-10-25
‘22-11-07 ‘22-11-21
‘22-10-10
25
1/45
SD
1/45
SD
10-10 15:372022
10-10 15:372022
If the indicator appears on the LCD, then a movie file is currently being displayed.
Press the
button to restore a preview icon to its original image size.
51
Using Zoom Playback (for still pictures only)
When playing back photos, you can also use the Zoom Lever to zoom in on the photos, 2 to 8 times their
original magnification.
W Zoom Out T Zoom In
1. Press the [
] / [ ] buttons to select the picture on which to use the zoom feature.
2. Rotate the Zoom Lever to
to zoom in.
3. The bottom right corner of the screen will display the amount zoomed in as well as the area of the photo
shown.
4. Press the arrow buttons to navigate and select the desired portion of
the photo to be zoomed in on.
5. Press the
button to return the image to its original scale.
Movie images cannot be magnified.
Please note: This camera’s LCD is only capable of displaying a
fraction of the detail and resolution of the actual photo or video file.
Once photos / videos are downloaded to your computer, you will
see the full resolution of the photo / video file captured.
x4
52
Slideshow
This setting allows you to view all the stored pictures as a slideshow.
1. Press the
button to enter playback screen.
2. Press the
button to enter slide option.
3. Press the [
] / [ ] buttons to select slideshow playing or [Cancel] to return to the playback screen.
Play Slide Show
Effect 2
Play Slide Show
Effect 1
Fade in and out
Play Slide Show
Effect 2
Left and right interlaced
Play Slide Show
Effect 3
Animated photo tile effect
4. Press the button to confirm the setting.
53
Animation Panorama Playback
The panoramic animation will be played back as a full-size image in accordance with the shooting direction.
1. Press the
button to enter playback screen.
2. Press the [
] / [ ] button to select the animated panoramic photos.
3. Press the
buttons to playback in selected shooting direction.
Animation panorama Playing Pause
1/45
SD
10-10 15:37
2022
SD
4. During playback, press the button to pause playback, and then press the button to resume playback.
Press the [ ] button to select , it will stop playback and return to the static image of the
panoramic image.
5. After playback, it will automatically return to the static image of the panoramic image.
Rotation is not performed during animation panorama playback or pause.
54
Photos and Video Deletion
In Playback Mode, press the [
] button to select your desired photos and videos.
To delete photos or videos:
1. Press the
button to switch to Playback Mode.
2. Press the [
] / [ ] buttons to select the photos and videos to be deleted.
3. Press the [
] button and the deletion screen is displayed.
Exit
Delete One
4. Press the [ ] / [ ] buttons to select [Delete One] or [Exit] and press the button to confirm.
Erased photos / video clips cannot be recovered.
Please refer to Page 73 for instructions on deleting more than one image at a time.
55
USING THE MENUS
Photo Menu
Mode:
1. In Photo Shooting Mode, press the button to
enter the Photo Shooting Menu.
2. Press the [
] / [ ] buttons to select
the Photo Shooting Menu and settings.
3. Press the [
] / [ ] buttons to select the
Photo Shooting Menu to be set and press the
button to confirm.
Expo Metering: AiAE
Expo Metering (Exposure Metering)
Use this setting to select the “target” size of the
camera’s field of view to be metered.
Expo Metering: AiAE
AiAE (Artificial
Intelligence AE)
Automatically selects the
central and peripheral
metering, to calculate the
reasonable value of metering
by weighting.
Spot Metering targets a small area
in the center of the camera’s
field of view.
Center Metering targets a slightly
larger area in the center of
the camera’s field of view.
56
Image Size
The Size Setting refers to the image resolution in
pixels. A higher image resolution allows you to
print that image in larger sizes without degrading
the photo image quality.
20M: 5184 x 3888
18M: 5184 x 3456 (3:2)
15M: 5120 x 2880 (16:9)
10M: 3648 x 2736
5M: 2592 x 1944
3M: 2048 x 1536
2M: 1920 x 1080 (16:9)
VGA: 640 x 480
The bigger the number of recorded pixels is,
the better the image quality becomes. As the
number of recorded pixels lessens, you will
be able to record more images on a memory
card.
Continuous AF
Use the Continuous AF setting to be able to
continuously focus automatically when taking
pictures.
Cont. AF:Off
Cont.AF: Off
Cont.AF: Off
Cont.AF: On
57
OIS (Optical Image Stabilization)
This mode can help reduce photo blur caused by
unintentional hand shake, or low light.
OIS:Off
OIS: Off
OIS: On
Use this Image Stabilization Mode in dark
environments.
Shooting in a windy or unstable environment
(such as a moving vehicle) may cause blurred
images.
When using a tripod, we suggest that the
image stabilization setting be turned “Off”.
HDR (High Dynamic Range)
Use this setting to control wide dynamic image
range when taking static pictures. Photos with
extreme contrast of bright and dark areas will still
maintain distinguishable detail and depth. (Suggest
using tripod)
HDR: Off
HDR: Off
HDR: On
When shooting in a high light contrast
situation, we suggest using the HDR setting
to compensate and provide the best photos
possible.
58
Face Beautifier
Skin Soften
Effect 1
Effect 1
Skin Soften
Effect 2
Skin Soften + Eye Brightening
Effect 3
Skin Soften + Eye Brightening +
Eye Enlargement
Scene
Select a scene under Scene Mode ( ). Refer to
the “Scene Mode” section on page 31.
Pet Mode
Press SET To Select Scene
In mode, you can press the [ ] button
on the shooting screen to set up Auto shooting.
Auto Shooting: On
59
Photo Shoot Settings Menu
Menu
Press SET To Enter
Press the button to enter the menu.
Quality Normal
AF Assist Beam On
Digital Zoom On
Date Imprint Off
Quick Review Off
Quality
The Quality Setting can be used to adjust the
image compression ratio.
Quality Normal
Best
Fine
Normal
Best 20M Average File Size: 5.5MB
Fine 20M Average File Size: 2.5MB
Normal 20M Average File Size: 2.0MB
60
AF Assist Beam
In a darker environment, the AF assist beam setting
can be turned on for better focus.
AF Assist Beam
Off
On
Digital Zoom
This setting is for adjusting digital zoom. If this
function is disabled, only optical zoom can be
used.
On
Digital Zoom
Off
On
61
Quick Review
This option allows quick review of the photos
immediately after they are taken. Each photo is
displayed on the LCD screen based on the selected
time.
Quick Review
Off
1 sec
2 sec
3 sec
Date Imprint
Include a Date/Time stamp on the photo image.
Date Imprint
Off
Date
Date/Time
2022/10/10
08:00
62
Custom Settings
Custom Settings stores the current Photo Shooting
Mode and its parameters. The stored mode and
parameters are directly invoked in Custom Settings
Mode.
•Select [Custom Settings] under other modes
Custom Settings
Reset camera settings to
custom settings mode.
Yes
No
•Select [Custom Settings] under mode
Select one capture mode to define CS.
Auto Mode
Save
Exit
Face Detection
Detects and focuses on faces to make all faces as
clear as possible in Photo Mode.
Face Detection
Off
On
63
Movie Menu
Mode:
1. Turn the Mode Dial to select the mode and
press the button to enter the Movie Menu.
Expo Metering: AiAE
2. Press the [ ] / [ ] buttons to select
the Movie Menu to be set.
3. Press the [
] / [ ] buttons to select the
Movie Menu to be set and press the
button
to confirm.
Expo Metering (Exposure Metering)
Use this setting to select the “target” size of the
camera’s field of view to be metered.
Expo Metering: AiAE
AiAE (Artificial
Intelligence AE)
Automatically selects the
central and peripheral
metering, to calculate the
reasonable value of metering
by weighting.
Spot Metering targets a small area
in the center of the camera’s
field of view.
Center Metering targets a slightly
larger area in the center of
the camera’s field of view.
64
Video Quality
Set the image resolution used during video recording.
Size: 1080p 30fps
The speed requirements for reading and writing high
resolution image pixel images to an SD card are as
follows:
No.
Image Pixels
Frames
Recording Time
(32GB) About
1
1920 x 1080 * 30 60 Minutes
2
1280 x 720 * 60 64 Minutes
3
1280 x 720 * 30 128 Minutes
4
640 x 480 30 259 Minutes
5
640 x 480 120 65 Minutes
* The longest recording time is 29 minutes
at one time.
If the recorded video segment/file
exceeds 4GB:
① The camera will automatically generate
a new separate file(s) sequentially and
will continue recording until the SD
memory card is full.
② Each sequential recorded file of 4GB
(max) will be a separate file and cannot
be played back continuously.
To playback files, please manually
select each one to view.
When recording in higher pixel resolutions
for extended periods of time, this can
cause the camera to generate heat. This is
not a camera malfunction.
Sound recording is disabled when 640 x
480 (120fps) is chosen.
When the video format is set as 640 x 480
(120fps), the shooting time is 30 seconds
and the playback time is 2 minutes.
65
Movie Shooting Settings Menu
Menu
Press SET To Enter
Press the button to enter the menu.
AF Assist Beam On
Digital Zoom
Custom Settings
On
OIS (Optical Image Stabilization)
This mode can help reduce video images blur
caused by unintentional hand shake, or low light.
OIS:Off
OIS: Off
OIS: On
Use Optical Image Stabilization Mode in dark
environments.
Shooting in a windy or unstable environment
(such as a moving vehicle) may cause blurred
images.
When using a tripod, we suggest that the
image stabilization setting be turned “Off”.
66
AF Assist Beam
In a darker environment, the AF assist beam setting
can be turned on for better focus.
AF Assist Beam Normal
Off
On
Digital Zoom
This setting is for adjusting Digital Zoom. If this
function is disabled, only Optical Zoom can be
used.
Digital Zoom
Off
On
Custom Settings
Custom Settings stores the current Photo Shooting
Mode and its parameters. The stored mode and
parameters are directly invoked in Custom Settings
Mode.
Custom Settings
Reset camera settings to
custom settings mode.
Yes
No
67
Options in the Shooting Mode (O: Available X: Unavailable)
If each option is available in the mode set to
, the option is available in mode; otherwise, it is not
available.
Options
Shooting Modes
Others
O O O O O O X O O O O
O O O O O O X O O O X
X X X X X X X X X X O
O O O O O O X X O X X
O O O O O O X X X X O
X X X X X O X X X X X
O O O O O X X O O X X
O O O O O O O O O O O
68
Playback Menu
Mode:
1. Press the button to display the playback
screen and press the button to enter the
menu.
Normal Mode
Press SET To Confirm
2. Press the [ ] / [ ] buttons to select
the playback desired and press the
button to
enter.
3. Press the [
] / [ ] or [ ] /
[
] buttons to select an option and press the
button to confirm.
Display Mode
Normal Mode: Display all images.
Normal Mode: Display all images.
Date Mode: Arranged by date.
Cont.Photo Mode: Arranged by
Cont.Photo Group.
The Date Folder is displayed in date order
based on photo shooting date/time.
If there is no continuous shot image file
in memory, Cont. Photo Mode cannot be
enabled.
69
HDR (High Dynamic Range)
With the HDR function, pictures that are
overexposed may be corrected to optimize
the highlights and lowlights captured to more
accurately represent the actual scene.
HDR
HDR
Cancel
After using the HDR function, the image will
be saved as a new file and the original file is
still stored on the memory card.
Touch-up
The playback beauty feature allows for
beautification using three individual effects.
Red-Eye Reduction
Red-Eye Reduction
Skin Soften
Eye Brightening
Eye Enlargement
Cancel
70
Rotate
You can use this setting to change the orientation of
the picture.
Turn Right
Turn Right
Turn Left
Cancel
Videos and panoramic pictures cannot be
rotated.
The rotated picture file will replace the
original photo.
Resize
This setting allows you to resize a picture to a
particular resolution and saves it as a new picture.
Resize to 1024x768
Resize To 1024 x 768
Resize To 640 x 480
Cancel
Only for adjusting pictures with high
resolution to those with a lower resolution.
Sizes of photos taken in panorama mode or
rotated cannot be adjusted.
71
Color
This setting allows you to change the picture color effect. The file is saved as a new photo and stored in
memory together with the original photo.
1. Press the
button to enter the Color Effect Settings Menu.
2. Press the [
] / [ ] buttons to select the color effect setting options.
Cancel
Cancel Grainy
Vivid Dreamy
Sepia Vignetting
Black and White Salon
72
Playback Settings Menu
Menu
Press SET To Enter
Press the button to enter the menu.
Protect
Delete
DPOF
Trim
Protect
To prevent any pictures or videos from being
accidentally erased, use this setting to lock one or
all of the files stored on the memory card.
Protect
One
Date folder
Cont. Group
All
Reset
One
Lock the selected photo or video
if they are unprotected; unlock the
selected photo or video if they are
protected.
Date
Folder
Protect all photos in the Date Folder.
Cont.
Group
Protect all photos in the Cont.
Group.
All
Lock all photos or videos.
Reset
Cancel all locked photos or videos.
73
Delete
You can delete one or all photo/video files.
Delete
One
Date folder
Cont. Group
All
One Delete one photo or video.
Date Folder Delete all photos in the Date Folder.
Cont. Group Delete all photos in the Cont. Group.
All Delete all photos or videos.
The “ ” indicator means a file is protected. File protection must be removed before a file can be
deleted.
Deleting files will cause DPOF settings to be reset.
Deleted files will be permanently deleted and will not be able to be recovered or restored.
74
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile and select
a group of pictures that you would like to print and
will save your selection on the memory card so
that you can use the memory card to print without
having to individually specify the photos you want
to print.
DPOF
One
All
Reset
A printer that supports DPOF is needed for
photo printing.
Trim
The Trim setting allows you to crop photos and
save them as new pictures.
1. Select [Yes] to confirm trim. Select a section of
the photo to be trimmed using the Zoom Lever
and the [ ] / [ ] / [ ] / [ ]
buttons to trim a photo.
2X
2. Press the button and the [Save change?]
prompt appears. Select [
] to change
and save the picture. Select [ ] to cancel
changes and return to the trim prompt screen.
The image cannot be clipped / trimmed again
once it has been clipped to 640 x 480.
Videos cannot be trimmed in camera.
The picture after trimming cannot be trimmed
again.
75
General Settings
Mode:
1. Press the button and press the [ ] / [ ] buttons to select . Press the button to enter
the menu.
2. Press the [
] / [ ] buttons to select and press the / [ ] button to enter the menu.
Sound Settings
Power Saver Auto
Language English
World Time Home
Date & Time 2022.10.10 00:00
3. Press the [ ] / [ ] buttons to select the item to be set and press the / [ ] button to
enter the menu.
4. Press the [ ] / [ ] or [ ] / [ ] buttons to select an option, and press the button to
confirm.
76
Sound Settings
With this setting you may adjust the sound volume.
Sound Settings
Volume
Back
Power Saver
This setting allows you to save power and get the
maximum possible running time for your camera’s
batteries.
Power Saver
Auto
Normal
Best
Power
Saver
LCD
power off time
Turn off
time
Auto 3 min 5 min
Normal 1 min 3 min
Best 30 s 1 min
77
Language
Refer to the “Resetting your Language” section on
page 22.
World Time
The Zone setting is a useful function for your
overseas trips. This feature enables you to display
the local time on the LCD while you are abroad.
1. Press the [
] / [ ] buttons to select
the departure place (
) and destination( )
fields.
2. Press the [
] / [ ] buttons to select a
city located in the same time zone as that of the
field. Press the
button to confirm settings.
World Time
Trindade. Martim Vaz
London, Iceland
Date & Time
Refer to the “Resetting Date/Time” section on page
23.
LCD Brightness
Use this setting to adjust the brightness of your
LCD.
LCD Brightness Normal
+2
+1
Normal
-1
-2
Setting and adjusting your camera’s LCD
brightness to the lowest setting will help
conserve your camera’s battery life and
longevity. Using the LCD screen on the
brightnest setting will drain your batteries
more quickly.
78
Connection Settings
Mode:
1. Press the button and press the [ ] / [ ] buttons to select . Press the button to enter
the menu.
2. Press the [
] / [ ] buttons to select and press the / [ ] button to enter the menu.
3. Select [USB] and press the / [ ] button to enter the menu.
USB PC USB PC
PC
79
Connecting to a Computer
You can use a USB cable to connect the camera and copy (transmit) photos to a computer (PC or Mac),
printer or other device.
Transferring Files to Your Computer
The computer will automatically detect the camera as a removable drive. Double-click the “My Computer”
icon on the desktop to locate the removable drive and to copy folders and files in the drive to a directory on
your computer as you would copy any typical folder or file.
Follow the steps below to connect the camera to a computer:
1. Make sure both the camera and computer are turned on.
2. Connect one end of the supplied USB cable to the USB port on your camera.
3. Connect the other end of the cable to an available USB port on your computer.
4. After the transmission is complete, disconnect the USB cable according to your computer manufacturer's
instructions specifying how to safely remove USB devices.
80
File Settings
Mode:
1. Press the button and press the [ ] / [ ] buttons to select . Press the button to enter
the menu.
2. Press the [
] / [ ] buttons to select and press the / [ ] button to enter the menu.
Format
Copy to Card
File Numbering
Reset
FW Version V1.00
3. Press the [ ] / [ ] buttons to select the item to be set and press the / [ ] button to
enter the menu.
4. Press the [
] / [ ] button to select an option and press the button to confirm.
81
Format
Please Note: formatting enables you to delete all
contents on the memory card and camera’s built-in
memory, including protected photo and movie files.
Format
Doing so will clear all data.
Yes
No
If there is no memory card in the camera, the
built-in memory will be formatted; if there is
a memory card, only the memory card will be
formatted.
Copy to Card
Use this setting to copy the files stored in the
camera’s built-in memory to a memory card.
Copy to Card
Copy files from built-in memory to
the memory card.
Yes
No
If there is no card available in the camera, this
function will not be displayed.
82
Firmware (FW) Version
Use this setting to view the current camera
firmware version.
FW Version
Back
Current Ver: V1.00
When there is a new firmware version in the SD
card, select [Yes] to update.
FW Version
Current Ver: V1.00
New Ver: VX.XX
Update Firmware?
Cancel
Yes
File Numbering
After you take a picture or video clip, the camera
will automatically save it with a sequential number.
You can use this to reset the file numbering to 1.
File Numbering
Create a new directory and
reset the file number.
Yes
No
Reset
Use this setting to restore the camera to its original
factory default settings.
Reset
Reset camera settings to factory defaults.
Yes
No
83
APPENDICES
Specifications
Design and specifications are subject to change without notice.
Sensor
Type
1 / 2.3" BSI CMOS
Effective Pixels
20.68 Megapixels
Total Pixels
21.14 Megapixels
Lens
Focal Length
4.3mm (Wide) — 180.6mm (Tele)
35mm Film Equivalent
24mm (Wide) — 1008mm (Tele)
F Number
F3.0 (Wide) — F6.8 (Tele)
Lens Construction
11 groups 15 elements
Optical Zoom
42x
Focusing Range
Normal: (Wide) 50cm ~ ∞
(Tele) 200cm ~ ∞
Macro: 1.6cm ~ ∞ (Wide Only)
Autofocus System
TTL Autofocus
Anti-Handshake
Optical Image Stabilization
Digital Zoom
4x Digital Zoom (Combined Zoom: 168x)
84
Number of
Recording
Pixels
Still Image
(4:3)
20MP: 5184 × 3888
10MP: 3648 × 2736
5MP: 2592 × 1944
3MP: 2048 × 1536
0.3MP: 640 × 480
(3:2)
18MP: 5184 × 3456
(16:9)
15MP: 5120 × 2880
2MP: 1920 × 1080
Movie
1920 × 1080 (30fps), 1280 × 720 (60fps), 1280 × 720 (30fps), 640 × 480 (30fps),
High-Speed Movie: 640 × 480 (120fps)
Image Compression
Best, Fine, Normal
DCF, DPOF (Ver1.1) Support
Yes
File Format
Still Image Exif 2.3 (JPEG)
Movie Movie Format: MOV (Motion JPEG), Audio: Linear PCM [Monaural]
Shooting Modes
Auto Mode, Program AE, Shutter Priority, Aperture Priority, Manual Mode,
Face Beautifier, Panorama Mode, Scene Mode, Movie Mode, Custom Settings
Scene Mode
ASCN, Night Landscape, Pet Mode, Snow, Party, Sport, Night Portrait, Portrait,
Children, Landscape, Sunset, Fireworks, Beach
Detection Features
Face, Smile, Blink, Cat, Dog
Photo Touch-up Red-Eye Reduction, Skin Soften, Eye Brightening, Eye Enlargement
HDR
Yes
85
Scan Panorama Up to 360°
LCD Display 3.0 inch (460k Pixels)
ISO Sensitivity Auto, ISO 100 / 200 / 400 / 800 / 1600 / 3200
AF Method Single AF, Multi-AF (TTL 9-point), Object Tracking, Face-Detection
Exposure Metering Method
Artificial Intelligence AE (AiAE), Center-Weighted Average,
Spot (Fixed to Center of Frame), Face AE
Exposure Control Method Program AE (AE-Lock Available), Shutter Prior AE, Aperture Prior AE
Exposure Compensation ±3EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 30 Seconds
Continuous Shooting Yes
Playback Modes
Single Photo, Index (9/16 Thumbnails), Slide Show, Date Mode,
Burst Shooting, Zoom (Approx. x2 ~ x8)
White Balance Control
AWB, Daylight, Cloudy, Fluorescent, Fluorescent CWF,
Incandescent, Manual WB, Color Temp. (1900K~10000K)
86
Flash
Flash Method Pop-up (Manual)
Flash Modes
Force Off, Flash Auto, Force Flash, Slow Sync.,
Slow Sync. + Red-Eye Reduction, Red-Eye Reduction
Recording Media
Internal Memory: Approx. 67MB
SD / SDHC / SDXC Card (Up to 512GB Support)
[MMC Card not supported]
Multi-Language Support 27 Languages
Jacks USB 2.0 (Micro 5 pin USB)
Power Rechargeable Li-ion Battery LB-060, 3.7V 1100mAh, In-Camera Charging
Shooting Capability
(Battery Performance)
Approx. 240 Shots (Based on CIPA Standards)
Operation Environment Temperature: 0 ~ 40°C, Humidity: 0 ~ 90%
Dimensions (W×H×D)
Approx. 112.7 × 81.6 × 84.4mm
(Based on CIPA Standards)
Weight Approx. 444g (Body Only)
87
Prompts and Warning Messages
Message Description Action
Warning! Battery
exhausted.
The camera battery is depleted.
It is a warning indicating that the
camera is going to shut off.
Recharge the Li-ion Battery. The
camera will shut down in 2 seconds.
Lens obstruction, Re-start
Camera.
The lens is jammed or some foreign
object is preventing the lens from
functioning properly.
Turn the camera off and restart it to
reset the lens.
Suggest using tripod.
When continuous exposure is
enabled, this prompt message is
displayed when the photo shooting
screen is displayed for the first time.
This message will disappear after 2
seconds.
Battery temperature is too
high.
The battery temperature reaches
53.5°C or 128.3°F.
Let the battery cool before
attempting to use the camera again.
This message will disappear after 2
seconds
Built-in memory error!
An error has occurred in the internal
memory.
Try shutting down the camera and
turning it on again. This message will
disappear after 2 seconds
88
Message Description Action
Improper alignment.
Please try again.
The offset is too big for panorama
shooting.
This message will disappear after 2
seconds.
Warning! Do not turn
off your camera during
update!
This message appears during the
firmware update process.
This message disappears after the
camera update and restart.
Remove USB cable!!
Indicates that you can disconnect
the USB cable.
The message disappears after you
disconnect the USB cable.
Connection Failed!
Failure to connect to your
computer.
Remove USB cable and retry connection.
Write Protect ! The memory card is locked.
Remove memory card and switch the
lever on the side of card to UNLOCK. This
message will disappear after 2 seconds.
Card Full !
Indicates that the memory card
is full.
Replace memory card with another that
has available memory. This message will
disappear after 2 seconds.
Memory Full !
Indicates that the camera memory
is full.
It will disappear after 2 seconds.
89
Message Description Action
Card Error !
During power-on, the memory
card cannot be recognized.
Format the memory card. WARNING: Formatting the
memory card will erase all data on the card. Copy
the data from the memory card to another storage,
such as a computer. Otherwise, all data will be
erased after the format. This message will disappear
after 2 seconds.
Card is not
formatted.
When an error occurs in the
memory card, the message "Not
Formatted" will appear.
Format the memory card. WARNING: Formatting the
memory card will erase all data on the card. Copy
the data from the memory card to another storage,
such as a computer. Otherwise, all data will be
erased after the format.
Slow access!
When a memory card lower than
Class 10 is used to record a HD
movie, the writing speed will be
slower and recording will not
continue.
Replace the memory card with a higher Class over
10. This message will disappear after 2 seconds.
Cannot write to
SD card.
The photo shooting or video
recording has been interrupted,
so recording cannot continue.
Turn the camera off. Then unload and reload the
memory card and turn on the camera to restart. Also
check if memory card is full or in the locked position.
No Red-Eye
Detected!
Red eyes have not been detected
in the image.
This message will disappear after 2 seconds.
90
Message Description Action
This image
cannot be edited.
The file format does not support editing or the
edited file cannot be edited again.
This message will disappear after 2
seconds.
Exceeded
maximum folder
number.
This indicates that the memory card exceeded
the maximum number of folders (999). This
could cause a long read time during the
camera's power up.
Copy the data to your PC and
format the memory card using the
camera.
Too many
pictures for fast
processing.
During the playback by date, the images exceed
specifications so that it is not possible to play
by date.
The message disappears after 2
seconds and the camera returns to
normal playback mode.
Unable to
recognize files.
The format of the file to be viewed is not
supported or the file is corrupted so it cannot
be properly read.
This message disappears only after
the file is deleted.
No Picture!
When you press the play button, no image files
exist in the camera or on memory card.
This message disappears after 2
seconds and returns to the photo
shooting screen.
No contiunous
group file.
When it switches from playback mode to Cont.
playback mode, if there is no continuous group
file in the files, this prompt message will display.
The message disappears after 2
seconds and the camera returns to
normal playback mode.
Protected!
Undeletable!
The file is protected. The message appears
when you go into delete mode.
Remove memory card and switch
the lever on the side of card to
UNLOCK. Place card back into the
camera and try again. This message
will disappear after 2 seconds.
91
Troubleshooting
Problem Possible causes Solution
Camera does not turn on The camera battery is depleted.
The batteries are not inserted correctly.
Replace with newly charged
battery.
Correctly reinstall the battery.
Camera turns off suddenly
during operation
The camera battery is depleted. Replace with recharged battery.
The picture is blurred
Camera movement while taking a
picture.
Turn on Anti-shake mode.
Images and video files
cannot be saved
The memory card is full.
The memory card is locked.
Use another memory card or
delete unnecessary files.
Unlock the memory card.
Saving data to memory
card is slow
Using a memory card below Class 10
may result in slower recording times.
Use a memory card with
Class 10 or higher standard to
improve performance.
Cannot write to the
memory card
The memory card has been locked. Release the write lock of the
memory card or replace with
another card.
Too many movies to
process
The number of pictures or folders in the
memory card exceed the specifications,
so the playback can not be displayed.
Delete unwanted files.
The flash
flashes on the
LCD screen.
Current shooting environment requires
flash.
Turn on flash.
92
Memory Card Compatibility
•Cardscompatiblewiththiscamera(√ : Compatible X: Not Compatible)
micro
SD
micro
SDHC
micro
SDXC
Conversion adapter
to SD card
SD SDHC SDXC
Format FAT12, 16 FAT32
exFAT -
FAT12, 16 FAT32
exFAT
Capacity Up to 2GB 4~32GB 64GB~2TB
-
Up to 2GB 4~32GB 64GB~2TB
Compatibility
X X X √ √ √ √
It indicates that the writing speed class will be displayed on the memory card.
Use a memory card with the appropriate writing speed for the video recording mode to be recorded.
(O: Recommended X: Not recommended)
Speed
Class
UHS
Speed Class
Video
Speed Class
Video Recording
4K FHD HD VGA
90MB/sec
V90
O O O O
60MB/sec
UHS-III V60
O O O O
30MB/sec
UHS-I V30
O O O O
10MB/sec
Class 10 V10
O O O O
6MB/sec
Class 6
X X X O
4MB/sec
Class 4
X X X O
2MB/sec
Class 2
X X X O
93
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
kodakpixpro.com
Made in Myanmar (Burma)
© 2022 JK Imaging Ltd. All Rights Reserved.
The Kodak trademark, logo and trade dress are used under license from Eastman Kodak Company.
All other logos, products or company names that are referred to in this document are trade names, trademarks or registered
trademarks of their holders. The holders are not affiliated with JK Imaging Ltd., our products or our website.
Document No/Sequence: U.DIS.0074.1122.en.02
Ver. 2.0
