EN
1
DAILY REFERENCE
GUIDE
Before using the appliance carefully read Health and Safety guide.
APPLIANCE
PRODUCT DESCRIPTION
CONTROL PANEL
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.hotpoint.eu/register
You can download the Safety Instructions and the
Use and Care Guide, by visiting our website docs.
hotpoint.eu and following the Instructions on the
back of this booklet.
1. On-O/Reset button with indicator light
2. Program selection button
3. Salt rell indicator light
4. Rinse Aid rell indicator light
5. Program number and delay time indicator
6. Delay indicator light
7. Display
8. Zone Wash 3D indicator light
9. Delay button
10. Zone Wash 3D button
11. Tablet (Tab) button with indicator light
1 2 3
4
5 6 7
8 9 10 11
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Space Zone
7. Cutlery basket
8. Lower spray arm
9. Filter Assembly
10. Salt reservoir
11. Detergent and Rinse Aid dispensers
12. Rating plate
13. Control panel
2
1
3
11
4
13
5
0000 000 00000
Service:
12
10
6
8
9
7
