7 FIN
OIL FILLED RADIATOR
MODEL WL43003Y
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.warmlite.co
2 SERVICE DEPARTMENT: +44 (0) 333 220 6056
TECHNICAL DATA
Description: Oil Filled Radiator
Model: WL43003Y
Rated Voltage: 220 - 240V
Frequency: ~ 50/60Hz
Power consumption: 1500W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2004/108/EC Electromagnetic Compatibility Directive.
2006/95/EC Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RKW Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RKW has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
3www.warmlite.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must
be connected to the terminal marked [N] or
coloured black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked
.
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal
.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - and then cut it o the mains
lead and immediately dispose of its safely. Never
attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
WARNING:
This Appliance MUST be Earthed
FUSE
4 SERVICE DEPARTMENT: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• Do not immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• Do not leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• Do not let the cord hang over
the edge of a table or counter
or let it come into contact with
any hot surfaces.
• The use of accessory attachments
is not recommended by the
appliance manufacturer, apart from
those supplied with this product.
• Do not pull the plug out by the
cord as this may damage the
plug and/or the cable.
• Do not use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• Do not carry the appliance by
the power cord.
• Do not use the appliance
outdoors.
5www.warmlite.co
• Always ensure that the heater is
placed on a rm level surface.
Ensure that the heater is not
positioned close to curtains,
furniture
or any combustible materials as
this could create a re hazard.
• The heater must not be located
immediately below a mains
socket outlet.
• Do NOT cover the heater as
this may lead to a re risk.
• Do NOT obstruct any of
the openings of the heater
especially the heat outlet at the
bottom of the heater.
• Do NOT insert any object
through any openings on the
heater.
• Do NOT use the heater in areas
where ammable liquids are
stored or where ammable
fumes may be present.
• Do NOT operate the heater on
a timer or leave on overnight.
• When not being used, please
unplug the heater from the
mains socket.
• Keep the mains lead away from
the hot body of the heater and
ensure that it is not pulled tight
between the socket and the
heater.
• Do not use the heater in the
immediate surroundings of a
bath, a shower, a swimming
pool or similar indoor locations.
• Always unplug the heater and
allow it to cool before moving it
from one location to another.
• Do not attempt to dismantle or
repair any part of the heater.
This should only be done by a
qualied service agent.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the service
department.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
6 SERVICE DEPARTMENT: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Oil Filled Radiator
2 x Castor units
4 x Wing Nuts
2 x U bolt
1. Handle
2. Power Switches
3. Thermostat
4. Cord Storage
5. Castors
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Assemble your appliance.
3. Locate your appliance in accordance with the safety instructions.
4. Plug the appliance into the mains supply.
5. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
2
3
4
5
1
7www.warmlite.co
ASSEMBLY
A
Fit the Castor units to the cross bars.
B
Turn the radiator upside-down on a
scratch-free and stable surface to
prevent damage to the paint nish or
your oor surfacing.
C
Fit the two Castor units to the radiator by
placing the U bolts between the
outermost ns on each side of the
radiator.
D
Securely fasten the two Castor units onto
the radiator by screwing two Wing Nuts
onto each Foot.
Once turned to the upright position, allow the oil
to settle and wait for at least half an hour before
using.
USING YOUR APPLIANCE
NOTE: It is normal when the heaters are turned
on for the rst time or when they are turned on
after having not been used for a long period
of time the heaters may emit some smell and
fumes. This will disappear when the heater has
been on a short while.
1. Set the radiator thermostat to the minimal
position and with wall socket power switch
in the ‘OFF’ position, insert the plug to the
power supply.
2. The thermostat will automatically maintain
your desired room temperature.
3. Set the power switch to the ‘ON’ position.
4. Turn the thermostat control clockwise
all the way round until you hear a click,
this sound indicates that the oil heater is
activated, the indicator is ON. Continue
turning the thermostat control clockwise to
its highest setting.
5. When the indicator light is ON, the heater is
activated. The indicator light turns ON and
OFF repeatedly during use this is normal
and shows that the thermostat is keeping
the radiator at your desired temperature.
6. There are three heat settings:
• Switch 1 = Low Heat
• Switch 2 = Medium Heat
• Both Switches = High Heat
A
C
B
D
8 SERVICE DEPARTMENT: +44 (0) 333 220 6056
• CLEANING AND CARE
• Before cleaning always switch o the
radiator and remove the plug from the
electrical socket.
• Ensure that the unit is cool enough to
work on.
• To remove the dust, wipe the appliance
with a dry cloth.
• Never use abrasive powders or solvents.
• If the heater shows any signs of wear or
damage disconnect immediately from
the mains supply, do NOT use it – have it
checked by a suitably qualied person.
WARNING:
DO NOT IMMERSE THE APPLIANCE IN WATER
9www.warmlite.co
NOTES
10 SERVICE DEPARTMENT: +44 (0) 333 220 6056
NOTES
11www.warmlite.co
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish. You are
required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk
for access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of electrical items
purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled,
rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling, once it has
reached the end of its life.
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are giving you an extra year peace of mind.
To receive your extra year guarantee, register your appliance online by visiting
www.warmlite.co
Should you have a problem
with your appliance or need any spare parts please call our
Service Department on:
+44 (0) 333 220 6056
Distributed throughout the UK by RKW LTD
1015.V3
