A Division of Snow Joe
®
, LLC
© 2018 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
Model SJ-SHLV02
SHOVELUTION
TM
18" CLEAR SNOW SHOVEL
ASSEMBLY INSTRUCTIONS
R
FOR STORAGE:
Make a loop with the retaining strap around the spring-loaded
handle, and with the other end, secure to knob on the upper pole.
NOTE: If you have further questions, please contact the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
mCAUTION!
HANDLE IS SPRING LOADED UNDER HEAVY TENSION.
To avoid injury, securely grasp handle before cutting zip ties.
Then, remove retaining strap and save for later storage.
TO DISASSEMBLE:
Follow instructions above in reverse order.
TO ASSEMBLE:
1. Depress the small button at the end of
the lower pole, push and insert the lower
pole into the poly blade unit until it snaps
securely into place.
2. Remove the knob and the bolt from the
upper pole.
3. Insert the top of the lower pole into the
upper pole.
4. Align bolt holes, insert the bolt into the
square hole, through pole.
5. Tighten with the knob.
lower
pole
upper
pole
knob bolt
poly blade
unit
