DCD7010
Register your product and get support at
www.philips.com/welcome
DCD7010
Register your product and get support at
www.philips.com/welcome
EN User manual
Norge
Typeskilt nnes på apparatens
underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller
elektrisk støt, skal apparatet ikke
utsettes for regn eller fuktighet.
Press &
HOLD
button
for
2 seconds
“AUTO INSTALL" scrolls
(in standby mode) (in standby mode)
RADIO
PLUG&PLAY
DEMO MODE
C
M
Y
CM
MY
CY
CMY
K
DCD7010plug and play_new.pdf 3/30/2011 2:10:17 PM
Contents
3EN
7 Listen to FM radio 19
Program radio stations automatically 19
Program radio stations manually 19
Tune to a programmed radio station 19
Show RDS information 19
8 Setup 20
General setup 20
Audio Setup 20
Video Setup 20
Preference setup 21
Update software 21
9 Other features 22
Play audio from an external device 22
Listen through headphone 22
Timer and sleep 22
Add your le to play list 22
Use the sleep timer 22
10 Product information 23
Region Code 23
Specications 23
Supported disc formats 24
Supported audio 24
USB playability information 24
11 Troubleshooting 25
Picture 25
Sound 25
Play 25
Others 26
12 Notice 27
Compliance and Environment 27
Contents
1 Important 4
Know these safety symbols 4
Hearing safety 4
Copyright notice 5
Trademark notice 5
2 Congratulations 6
Feature introduction 6
What’s in the box 6
Overview of the main unit 7
3 Before use 11
Place the unit 11
Connect 11
Install/replace the battery of remote
control 12
4 Get started 13
Turn on 13
Adjust brightness of display panel 13
Turn on or off LED light 13
Store radio stations automatically 13
Find the correct video input channel 13
Select the correct TV system 14
Select a language for on-screen display 14
5 Play disc/USB 15
Basic operation 15
Play a disc 15
Play recored les 15
Control the play 16
Search by time or title/chapter/track
number 17
Adjust sound 17
6 Play iPod/iPhone/iPad 18
Compatible iPod/iPhone/iPad 18
Load the iPod/iPhone/iPad 18
Listen to the iPod/iPhone/iPad 18
Charge the iPod/iPhone/iPad 18
Remove the iPod/iPhone/iPad 18
Contents
4
Hearing safety
Listen at a moderate volume.
• Using headphones at a high volume can
impair your hearing. This product can
produce sounds in decibel ranges that
may cause hearing loss for a normal
person, even for exposure less than a
minute. The higher decibel ranges are
offered for those that may have already
experienced some hearing loss.
• Sound can be deceiving. Over time your
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can
actually be loud and harmful to your
hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even
at normally ‘safe’ levels, can also cause
hearing loss.
• Be sure to use your equipment
reasonably and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume as
your hearing adapts.
• Do not turn up the volume so high that
you can’t hear what’s around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a trafc
hazard and is illegal in many areas.
1 Important
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an
electrical shock. For the safety of everyone
in your household, please do not remove
product covering.
The ‘exclamation point’ calls attention to
features for which you should read the
enclosed literature closely to prevent
operating and maintenance problems.
WARNING: To reduce the risk of re or
electric shock, this apparatus should not be
exposed to rain or moisture and objects lled
with liquids, such as vases, should not be
placed on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Caution
•
Use of controls or adjustments or
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
EN
5
HDMI, the HDMI logo, and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC
in the United States and other countries.
“Made for iPod,” “Made for iPhone,” and
“Made for iPad” mean that an electronic
accessory has been designed to connect
specically to iPod, iPhone, or iPad,
respectively, and has been certied by the
developer to meet Apple performance
standards. Apple is not responsible for the
operation of this device or its compliance
with safety and regulatory standards. Please
note that the use of this accessory with
iPod, iPhone, or iPad may affect wireless
performance.
iPod and iPhone are trademarks of Apple Inc.,
registered in the U.S. and other countries. iPad
is a trademark of Apple Inc.
Note
•
The type plate is located on the bottom of
the unit.
Copyright notice
This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
Trademark notice
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.
ABOUT DIVX VIDEO: DivX
®
is a digital video
format created by DivX, Inc. This is an ofcial
DivX Certied device that plays DivX video.
Visit www.divx.com for more information and
software tools to convert your les into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certied
®
device must be registered in
order to play DivX Video-on-Demand (VOD)
content. To generate the registration code,
locate the DivX VOD section in the device
setup menu. Go to vod.divx.com with this
code to complete the registration process and
learn more about DivX VOD.
DivX
®
, DivX Certied
®
and associated logos
are registered trademarks of DivX, Inc. and
are used under license.
EN
6
What’s in the box
Check and identify the contents of your
package:
• Main unit
• 2 speakers
• Remote control
• 2 AAA batteries
• AC power cord
• Video cable
• 2 speaker wires
• FM antenna wire
• MP3-LINK cord
• User manual
XXXXXX
2 Congratulations
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
If you contact Philips, you will be asked for the
model and serial number of this product. The
model number and serial number are on the
back of the main unit. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Feature introduction
This unit can
• play videos, audios, and display pictures
from discs and USB storage devices
• play audios from iPod/iPhone/iPad
For the details of supported media, refer to
“Specications”.
EN
7
j /
• Search fast backward or forward.
k
• Stop the play.
• Erase a programed radio station.
• Activate/deactivate demonstration
mode.
l
• Eject or close the disc compartment.
m VOLUME
• Increase or decrease the volume
level.
n Disc compartment
Overview of the main unit
a Dock for iPod/iPhone/iPad
b
/
• Skip to the previous or next title,
chapter, track, or le.
c SOURCE
• Select a media source (disc, USB
storage device, iPod/iPhone/iPad, FM
tuner, or external device connected
through MP3 link cable).
d
• Turn on or off the unit.
• Switch to ECO mode.
e
• Start, pause or resume the play.
f
• Connect a USB storage device.
g MP3 LINK
• Connect an MP3 link cable.
h
• Socket for headphones.
i Pull open
• Pull to open the dock.
a
b
d
e
g
h
f
c
l
m
n
k
j
i
EN
8
Back view
a COAXIAL/DIGITAL OUT
• Coaxial / digital out jack
b AC MAIN~
• Power supply socket.
c SPEAKER OUT
• Connect the speakers.
d AUX-IN
• Connect an external audio device.
e FM ANTENNA
• Improve FM reception.
f LINE OUT
• Connect audio cables.
g DIGITAL AV OUT
• Connect an HDMI cable.
h VIDEO OUT
• Video output jack.
b
a
e
f
g
h
c
d
EN
9
e
• Navigate through the menus;
• Press
to rotate a picture
clockwise or counter-clockwise
during slideshow.
• Press
/ to fast backward or
forward; Press repeatedly to change
the search speed.
• Press
to slow forward.
• Press
to slow backward.
• Long press
(ZOOM) to zoom in/
out.
• Press OK to conrm a selection or
entry.
f
BACK
• Return to a previous display menu.
g
/
• Skip to the previous or next title,
chapter, track, or le.
h
• Start, pause or resume play.
i CLOCK
• Show time.
j AUDIO
• Select an audio language or channel.
k VOL +/-
• Adjust the volume.
l SUBTITLE
• Select a subtitle language.
m PROGRAM
• Program radio stations.
n DIM
• Select different level of brightness.
• Turn on/off the VOL knob light and
the LED light.
o MODE
• Select repeat play or random play.
p
• Open or close the disc
compartment.
Overview of remote control
a
• Switch the device on/off.
b DISC / RADIO / DOCK / USB / AUX/
MP3 LINK
• Select the source.
c A-B
• Marks the section for repeat play, or
turns off repeat mode.
d DISC MENU
• Access the main menu of the disk.
a
b
d
e
f
k
i
h
m
j
l
u
c
n
o
q
p
r
s
g
v
t
w
x
EN
10
q SYSTEM MENU
• Go to the system menu.
r RDS/INFO
• Show the disk information such as
title, chapter, subtitle, time elapsed,
total time etc.
s
• Stop play.
• Erase a programed radio station.
• Activate/deactivate the
demonstration mode.
t TIMER/SLEEP
• To time or enter SLEEP mode in
120/90/60/45/30/15 min.
u
• Mute.
v TREBLE/BASS
• Increase/decrease the treble/bass
level.
w Numeric buttons
• Select a title/chapter/track to play.
x LOUDNESS
• Turn on/off loudness control.
EN
11
Connect
Connect speakers
Note
•
For the best sound quality, use the supplied
speakers only.
• Connect speakers with the same or
higher impedance only. Refer to “Product
information” > “Specications” for details.
Connect TV
Connect the audio and video cables to
the output sockets on the unit and the
corresponding input sockets on your TV.
Select the best video connection that your TV
supports.
Connect through a composite video
cable
1
2
3
d
e
f
VIDEO R
L
3 Before use
Place the unit
Note
•
Risk of overheating! Never install this
apparatus in a conned space. Always leave a
space of at least 4 inches around this apparatus
for ventilation. Ensure curtains or other
objects never cover the ventilation slots on
this apparatus.
• Place this unit on a at, hard, and stable surface.
• Never place this unit in an enclosed cabinet,
nor on any other electrical equipment.
• Keep this unit away from direct sunlight, naked
ames, or heat.
• Do not insert any object other than indicated
into ventilation openings nor other openings.
• Apparatus shall not be exposed to dripping or
splashing.
• Do not place any sources of danger on the
unit (for example, liquid lled objects, lighted
candles).
• Install this unit near the AC outlet where the
AC power plug can be easily reached.
• To avoid magnetic interference or unwanted
noise, never place the main unit and speakers
too close to any radiation devices.
1 Place the unit near to the TV.
2 Place the speakers at a suitable
distance from the TV and at an angle
of approximately 45 degrees from the
listening position.
EN
12
Caution
•
Risk of explosion! Keep batteries away from heat,
sunshine or re. Never discard batteries in re.
• Do not mix batteries (old and new or carbon
and alkaline, etc).
• Remove the battery if the remote control is
not to be used for an extended period of time.
Connect power
Note
•
Where the MAINS plug or an appliance coupler
is used as the disconnect device, the disconnect
device shall remain readily operable.
• Risk of product damage! Make sure that the
power supply voltage corresponds to the
voltage printed on the back of the MAIN plug.
• Before you connect the AC power cord, make
sure that you have complete all other connections.
• Protect the power cord from being walked on
or pinched, particularly at plugs, convenience
receptacles, and the points where they exit
from the apparatus.
• Unplug this apparatus during lightning storms
or when unused for long periods of time.
Install/replace the battery of
remote control
a Push to open the battery compartment cover.
b Insert 2 AAA batteries with correct
polarity (+/-) as indicated.
c Close the cover.
EN
13
Note
•
The number key on the RC is deactivated in
this mode.
Adjust brightness of display
panel
1 Press DIM repeatedly to select different
brightness levels.
Turn on or off LED light
1 In power-on mode, press and hold DIM
to turn on or off the LED light at the
bottom of the unit or at the volume
knob.
Store radio stations
automatically
If no radio stations are stored, the unit can store
radio stations automatically.
1 Turn on the unit.
2 Press RADIO.
» [AUTO INSTALL ---- PRESS PLAY
STOP CANCEL] (press
to start
automatic installation, or press
to
cancel) is displayed.
3 Press .
» The unit automatically stores radio
stations with sufcient signal strength.
» After all available radio stations are
stored, the rst stored radio station is
broadcast automatically.
Find the correct video input
channel
1 Turn on your unit.
2 Press DISC to select the disc source.
• Turn on the TV and switch to the
correct video-in channel.
4 Get started
Turn on
1 Press .
» The unit switches to the last selected
source.
Note
•
If no source is played within 15 minutes, the
unit switches to standby mode.
• If no operation is performed within 15 minutes
in standby mode, the unit switches to Eco-
power standby mode.
• Press to switch the unit to the last source
when it was turned off.
Demonstrate the unit’s features
1. In the standby mode, press until “DEMO
ON” is displayed.
» This system’s features are displayed
one by one.
• To turn off the demonstration, press
again.
Set the clock
The unit uses the 24-hour or 12-hour time
format.
1 In standby mode, press and hold CLOCK
for 2 seconds.
» “CLOCK SET” scrolls on the display.
Then the time format [24H] or [12H]
appears.
2 Press VOL +/- to select a time format.
Press CLOCK to conrm.
» The hour digits blink.
3 Press VOL +/- to set the hour. Press
CLOCK to conrm.
» The minute digits blink.
4 Press CLOCK to conrm the setup.
EN
14
Note
•
See the user manual of your TV for how to
switch between video-in channels.
Select the correct TV system
This unit is compatible with both NTSC and
PAL. If the picture is abnormally displayed with
the default setting, select a TV system that
matches your TV. (Refer to “Setup” > “Video
Setup” > [TV Type] for details)
Select a language for on-
screen display
English is the default language options for this
setting. (See “Setup” > “General Setup” > [OSD
LANGUAGE] for details)
EN
15
Play recored les
You can play DivX/MP3/WMA/JPEG les that
are copied onto a CD-R/RW, recordable DVD,
or USB storage device.
Note
•
You can only play DivX videos that are rented
or purchased with DivX
®
registration code of
this unit. (See “Setup” > “General setup” >
[DivX(R) VOD Code])
• Subtitle les with the following le extensions
(.srt, .smi, .sub, .ssa, .ass) are supported but not
displayed in the le list.
• The subtitle lename has to be the same
as the lename of the DivX video (the le
extension excluded).
• The DivX video le and the subtitle les must
be saved under the same directory.
Connect a USB storage device
1 Press USB to select the source for USB
storage device.
2 Insert the USB storage device.
» The unit starts playing automatically.
» The user interface is displayed.
5 Play disc/USB
Caution
•
Risk of damage to the unit! During play, never
move the unit.
• Never put any object other than a disc into the
disc compartment.
• Never look at the laser beam inside the unit.
• Never play discs with accessories such as disc
stabilizer rings or disc treatment sheets.
When is displayed, it means that this
operation is unavailable for the current media
or at the current time.
Basic operation
The listed operations are applicable for all
supported media.
Function Action
Stop play Press
.
Pause or resume play Press
.
Skip to the previous/next
title, chapter, track, or le
Press
/ .
Play a disc
1 Press DISC to select the disc source.
2 Press to eject the disc tray.
3 Place a disc onto the disc tray with the
printed side upward, and then press
.
4 The unit starts playing automatically.
• To start the play manually, press
.
• To play a DVD that has a rating level
higher than your setting, enter the
6-digit password (000000) rst.
EN
16
Note
•
This unit can only display digital camera
pictures with JPEG-EXIF format, which is
widely used in digital cameras. It cannot display
Motion JPEG, nor pictures in formats other
than JPEG. Sound clips associated with pictures
cannot be displayed either.
• If the JPEG photo is not recorded with an
“exif” type le, it is displayed as a “blue
mountain” thumbnail picture.
Control the play
Follow the instructions to control the play.
Function Media Action
Return to
the disc
menu
Press DISC
MENU.
Enable/
disable
the PBC
(playback
control)
feature
Press SYSTEM
MENU
repeatedly.
• Enable PBC to
display the PBC
menu, and then
use Navigation
buttons and OK
to enter your
choice.
Select
an audio
language
or audio
channel
Press AUDIO
repeatedly.
Select a
subtitle
language
Press SUBTITLE
repeatedly.
Select a
play mode
(repeat
chapter,
title, all or
repeat off)
Press MODE
repeatedly.
• On the top: time elapsed, total time for
the audio/video, the numeric place in the
USB storage les and the name of current
folder.
• On the left: the information source.
• In the middle: the folder and le list.
• On the right: the detailed le information.
Access a folder
1 Press / to highlight the selected
folder name.
2 Highlight [Previous] and press OK back to
the last-level menu.
Play a le
1 Access the selected folder.
2 Press / to highlight the selected le
name.
3 Press OK to conrm.
» The selected le starts playing.
» The unit stops playing automatically
at the end of the last le of same
category.
Play slideshow and music
simultaneously
Note
•
Make sure that the USB storage device or the
disc contains both WMA/MP3 les and JPEG
photos.
1 Play a WMA/MP3 le.
2 Access a photo folder.
3 Select a photo le.
4 Press OK to start the slideshow.
• The slideshow stops after all photos
are displayed for one time.
• To stop the slideshow, press
.
EN
17
Search
backward
or forward
fast
Press /
to search in a fast
speed.
• Press OK back
to normal speed
play.
Preview
photos
Press to highlight
a le name in the
le list.
Reverse a
Press .
Rotate a
Press / .
Search by time or title/
chapter/track number
1 During play, press INFO.
2 Press / to highlight the title
number, chapter number, track number,
or time eld.
3 Use the numeric buttons to enter the
number or time digits.
4 Press OK to conrm.
» the selected segment is displayed.
» Play starts automatically.
Adjust sound
You can adjust the volume level and select
sound effects.
Function Action
Increase/
decrease the
volume level
Press + VOL -; turn VOLUME
clockwise or anti-clockwise.
Adjust treble
or bass
To activate treble level, press
TREBLE and then adjust with
VOL +/-.
To activate bass level, press
BASS and then adjust
withVOL +/-.
Mute/unmute
the speakers
Press
Repeat a
specic
section
within a
chapter or
track
1) Press A-B to
select the start
point.
2) Press A-B
again to select
the end point.
»The selected
section starts
play repeatedly.
• To resume
normal play,
press A-B until
[Repeat off] is
displayed.
Zoom in or
out
• Long press
ZOOM
repeatedly to
change the zoom
degree.
• Press
buttons to move
the zoomed
picture up,
down, left, or
right.
Display
the play
information
Press INFO.
Play or
rewind in
slow speed.
• During DVD/
VCD playback,
press to play
in slow speed.
• During DVD/
VCD playback,
press to
rewind in slow
speed.
• Press
repeatedly to
change the slow
forward speed.
• Press
repeatedly to
change the back
forward speed.
• Press OK back
to normal speed
play.
EN
18
Load the iPod/iPhone/iPad
1 Lift the lid of the dock.
2 Load the iPod/iPhone/iPad onto the dock.
Listen to the iPod/iPhone/iPad
1 Load your iPod/iPhone/iPad.
2 Press the button DOCK on your RC.
3 Play the selected track on your iPod/
iPhone/iPad.
• To pause/resume the play, press
.
• To stop the play, press
.
• To skip to the previous/next audio
track, press
/ .
Charge the iPod/iPhone/iPad
When the unit is connected to power, the
docked iPod/iPhone/iPad starts charging.
Tip
•
For certain iPod models, it may take up to a
minute before the charging indication appears.
Remove the iPod/iPhone/iPad
1 Unload the iPod/iPhone/iPad from the dock.
2 Flip down the lid to hide the dock.
1
2
6 Play iPod/
iPhone/iPad
You can enjoy audio from iPod/iPhone/iPad
through this unit.
Note
•
The audio is only output through the supplied
speakers.
Compatible iPod/iPhone/iPad
The unit supports the following iPod/iPhone/
iPad models:
• iPod 4G
• iPod 5G
• iPod nano (6th generation)
• iPod nano (5th generation)
• iPod nano (4th generation)
• iPod nano (3rd generation)
• iPod nano (2nd generation)
• iPod nano (1st generation)
• iPod Classic
• iPod Touch (4th generation)
• iPod Touch (3rd generation)
• iPod Touch (2nd generation)
• iPod Touch (1st generation)
• iPod Mini
• iPhone
• iPhone 3G
• iPhone 3GS
• iPhone 4
• iPad
Note
•
IPod with color display, iPod classic, and iPod
with video are not compatible with dock
charging.
EN
19
Tip
•
To overwrite a programmed station, store
another station with its sequence number.
• [STEREO] is default setting for tuner mode.
• Under tuner mode, you can press OK repeatedly
to toggle between [STEREO] and [MONO], and
the unit memorizes your setting even if you turn
off the unit or turn to other sources.
Tune to a programmed radio
station
1 Press RADIO.
2 Press / repeatedly to select a
programmed radio station.
Show RDS information
RDS (Radio Data System) is a service
that allows FM stations to show additional
information. If you tune to an RDS station, an
RDS icon and the station name are displayed.
1 Tune to an RDS station.
2 Press RDS/INFO repeatedly to scroll
through the following information (if
available):
» Station name
» Program type such as [NEWS] (news),
[SPORT] (sport), [POP M] (pop music)...
» Frequency
Synchronize clock with RDS station
You can synchronize the clock time on the
unit with an RDS station.
1 Tune to an RDS radio station that
transmits time signals.
2 Press RDS/INFO for over 2 seconds.
» [CT SYNC] is displayed and the unit
reads RDS time automatically.
» If no time signal is received, [NO CT]
is displayed.
Note
•
The accuracy of the transmitted time depends
on the RDS station that transmits the time signal.
7 Listen to FM
radio
Note
•
A maximum of 20 radio stations can be stored.
• Fully extend the FM antenna for better
reception.
Program radio stations
automatically
1 Press RADIO.
2 Press and hold PROGRAM for 2 seconds.
»
AUTO
appears.
» Available stations are stored
automatically.
» The rst programmed radio station is
broadcast automatically.
Program radio stations
manually
1 Press RADIO.
2 Long press / to search to a radio
station, or press
/ to manually
tune to a radio station.
3 Press PROGRAM to program the current
station .
» The sequence number blinks with the
current frequency displayed.
4 Press / to allocate a sequence
number from 01 to 20 to this radio
station.
5 Press PROGRAM to conrm.
» The sequence number and the current
frequency are displayed.
6 Repeat steps 2-5 to program more
stations.
EN
20
Note
•
If you select a language which is not available
on a disc, this unit uses the default language of
the disc.
Audio Setup
1 Press SYSTEM MENU button.
2 Select to access the [Audio Setup]
options.
• [HDMI Audio]: Selects HDMI audio
format when this unit is connected
through HDMI or disables HDMI audio
output for the TV.
• [Audio Sync]: Set the delay time for audio
output when you play a video disc.
• [Night Mode]: Select quiet or full dynamic
sound. Night mode decreases the volume
of loud sound and increases the volume
of soft sound (such as speech).
Note
•
For settings related to HDMI, the TV must be
connected through HDMI.
• Night mode is only available for Dolby
encoded DVD.
Video Setup
1 Press SYSTEM MENU button.
2 Select to access the [Video Setup]
options.
• [T V Type]: Select video output
format(PAL, Multi or NTSC).
• [TV Display]: Set screen display
format(Pan Scan, Letter Box or Wide
Screen).
• [Picture Settings]: Select a predened
color setting or set the color manually.
• [HDMI Setup]: When you connect this
unit and TV with HDMI cable, select
the best HDMI setup that your TV can
support.
8 Setup
1 After you press the button SYSTEM
MENU.
» The system menu appears. Click the
symbol to access each setup.
Note
•
You cannot change a menu option that is
grayed out.
• To return to the previous menu, press . To
exit the menu, press SYSTEM MENU again.
General setup
1 Press SYSTEM MENU button.
2 Select to access the [General Setup]
options.
• [Disc Lock]: Turn Disc lock.
• [Display Dim]: Change the brightness of
the display panel of the unit.
• [OSD Language]: Select an on-screen
display menu language.
• [Screen Saver]: Enable or disable screen
saver mode. If enabled, the screen enters
idle mode after 5 minutes of inactivity (for
example, in pause or stop mode).
• [Sleep Timer]: Enable a countdown timer
to switch this unit to standby mode after
a specic period of time.
• [DivX(R) VOD Code]: Get registration
code of DivX Video On Demand
Registration.
EN
21
Update software
Before you update the software of this unit,
check the current software version:
• Press SYSTEM MENU , and then select
([Preference Setup]).
• Use navigation button to nd [Version
Info.], and nd out current version.
Update software via USB
1 Check the latest software version on
www.philips.com/support.
• Search for your model and click on
“Software and drivers”.
2 Download the software into a USB
storage device.
3 Unzip the download in the root directory.
4 Connect the USB storage device to the
(USB) connector on this unit.
» The unit will read the le automatically.
A box comes out on the TV screen.
5 Follow the instructions on the TV screen
to update the software.
» When the update is complete, this unit
automatically turns off and on again.
Caution
•
Do not turn off the power or remove the USB
storage device when the software update is in
progress because you might damage this unit.
• You may also burn a disc to update your
software.
Note
•
For settings related to HDMI, the TV must be
connected through HDMI.
• Night mode is only available for Dolby
encoded DVD.
Preference setup
1 Press SYSTEM MENU button .
2 Select to access the [Preference Setup]
options.
• [Audio]: Select an audio language for
video.
• [Subtitle]: Select a subtitle language for
video.
• [Disc Menu]: Select a menu language for
a video disc.
• [Parental]: Set the rating level to a
disc. Restrict access to discs that are
encoded with ratings These discs must be
recorded with rating levels.
• [PBC]:Display or skip the content menu
for VCD and SVCD.
• [MP3/JPEG Display]: Set Mp3 or jpeg
view mode.
• [Password]: Set or change a password to
play a restricted disc.
• [DivX Subtitle]:Select the language of the
DivX.
• [Version Info.]:Display the software
version for the .
• [Default]:Reset the home theater to
the default settings programmed at the
factory.
Note
•
Ensure that the subtitle le has the exact same
le name as the movie le. If for example the
le name of the movie is ‘Movie.avi’, then
you need to name the text le ‘Movie.sub’ or
‘Movie.srt’.
EN
22
7 Press VOL +/- to select a volume for
the timer, and press SLEEP/TIMER to
conrm.
8 Press SLEEP/TIMER to activate the timer.
»
is displayed.
» The system turns on to the set source
at the set time.
• To deactivate the timer, press SLEEP/
TIMER again.
Note
•
Alarm timer is not available in MP3 LINK
mode.
• If DISC/USB source is selected and the
track cannot be played, tuner is activated
automatically.
• If iPod/iPhone/iPad playlist is selected as
alarm source, you need create a playlist called
“PHILIPS” in your iPod/iPhone/iPad.
• If no playlist called “PHILIPS” created in the
iPod/iPhone/iPad or no track is stored in the
playlist, the unit switches to iPod/iPhone/iPad
alarm source.
Add your le to play list
1 Select one le.
2 Press PROGRAM to add this le into
playlist.
3 Repeat step 1 and 2 to add other les.
4 Press DISC MENU to view the detailed
information about playlist.
Use the sleep timer
The system can also turn off automatically after
a preset period (120, 90, 60, 45, 30, 15 minutes).
1 During play, press SLEEP/TIMER
repeatedly to select a period.
»
SLEEP
is displayed.
»
is displayed.
2 To deactivate the sleep timer, press
SLEEP/TIMER repeatedly until
SLEEP OFF
is displayed.
9 Other features
Play audio from an external
device
You can use this unit to play audio from an
external device.
1 Connect the MP3 link cable to
• the MP3 LINK jack of this unit
• the audio output jack (usually
headphone jack) of the external
device.
2 Press MP3-LINK.
3 Play the external device (see the user
manual of this device for details).
Listen through headphone
Plug a headphone into the socket.
Timer and sleep
You can set a time for automatic back to one
source.
Note
•
Make sure that you have set the clock before
this setup.
1 In standby mode, press and hold SLEEP/
TIMER.
»
appears.
2 Press VOL +/- to select
SOURCE
(DISC,
USB , DOCK, TUNER and PLAY LIST).
Then press SLEEP/TIMER to conrm.
» The hour digits blink.
3 Press VOL +/- to set the hour.
4 Press SLEEP/TIMER again.
» The minute digits blink.
5 Press VOL +/- to set the minute.
6 Press SLEEP/TIMER to conrm the time
for auto power on.
EN
23
Total Harmonic
Distortion
< 0.1% (1 kHz)
Frequency
Response
4 Hz - 20 kHz (44.1 kHz)
4 Hz - 22 kHz (48 kHz)
4 Hz - 24 kHz (96 kHz)
S/N Ratio > 82 dBA
Tuner (FM)
Tuning Range 87.5 - 108MHz
Tuning grid 50KHz
Sensitivity - Mono, 26dB
S/N Ratio
<22 dBf
Sensitivity - Stereo, 46dB
S/N Ratio
<43 dBf
Search Selectivity <28dBf
Total Harmonic
Distortion
<2%
Signal to Noise Ratio >55dB
Speakers
Speaker
Impedance
6 ohm
Speaker
Driver
13cm woofer+2.5cm”Dome
tweeter
Sensitivity > 86 dB/m/W±4dB/m/W
General information
AC power 220–240 V, 50/60
Hz
Operation Power
Consumption
38 W
Eco Standby Power
Consumption
<0.5 W
Headphone output 2 X 15 mW, 32
ohm
USB Direct Version 2.0
Composite Video Output 1.0 Vp-p, 75 ohm
Coaxial Output 0.5 Vpp±0.1Vpp,
75 ohm
10 Product
information
Note
•
Product information is subject to change
without prior notice.
Region Code
You can play DVD discs marked with the
following region code.
DVD region code Countries
Europe
Specications
Amplier
Rated Output
Power
2 X 50 W RMS
Frequency
Response
20-20000 Hz, ±3 dB
Signal to Noise
Ratio
> 82 dB
Aux Input 1000 mV RMS 22kohm
Disc
Laser Type Semiconductor
Disc Diameter 12 cm/8 cm
Video Decoding MPEG-1 / MPEG-2 / DivX
Video DAC 12 Bits
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N > 57 dB
Audio DAC 24 Bits / 96 kHz
EN
24
• The following formats are not supported:
• Files like *.VMA,, *.DLF, *.M3U
• *.PLS, *.WAV
• Discs recorded in Joliet format
• MP3 Pro
USB playability information
Compatible USB devices:
• USB ash memory (USB 2.0 or USB1.1)
• USB ash players (USB 2.0 or USB1.1)
• memory cards is not compatible with this
set.
Supported formats:
• USB host shall support FAT16 and FAT 32
File System
• Audio playback: MP3, WMA
• Video playback: MPEG4, AVI, DivX 5.0,
DivX Ultra+addendium 1.0
• Photo playback: JPEG
Unsupported formats:
• Empty albums: An empty album is an
album that does not contain MP3/WMA
les.
• Unsupported le formats are skipped. For
example, Word documents (.doc) or MP3
les with extension .dlf are ignored and
not played.
• AAC, WAV, DTS, PCM audio les
• Dolby True HD les
• DRM protected WMA les (.wav, .m4a,
.m4p, .aac)
• WMA les in Lossless format
Dimensions
- Main Unit (W x H x D)
- Speaker Box (W x H
x D)
250 X 92 X
285 mm
174 X 260 X
240 mm
Weight
- With Packaging
- Main Unit
- Speaker Box
10 kg
2.5 kg
6.1 kg
Supported disc formats
• Supported video media:
• DivX Ultra
• Digital Video Discs (DVDs)
• Picture CD
• Video CDs (VCDs)
• Super Video CDs (SVCDs)
• DVD-R/-RW
• MP3-CD
• CD-R/CD-RW
• DVD+R/+RW
• Compact Discs (CDs)
Supported compression formats:
• MPEG1, MPEG2, DivX(DivX
Ultra+addendum 1.0), XivD, AVI(MPG),
MPEG4, ASF
• JPEG le
Supported audio
• Supported audio media
• CD
• CD-R/RW
• MP3-CD
• WMA-CD
Supported following audio formats:
• Dolby Digital Plus/5.1
• PCM Audio
• MP3, MP3 ID3 Tag
• WMA, WMA Tags
EN
25
The aspect ratio of the TV screen cannot be
changed even though you have set the TV
display format.
• The aspect ratio is xed on the loaded
DVD disc.
• The aspect ratio may not be changed for
some TV systems.
The disc does not play high-denition video.
• Make sure that the disc contains high-
denition video.
• Make sure that the TV supports high-
denition video.
Sound
No audio output from the TV.
• Ensure that the audio cables are
connected to the audio input of the TV.
• Assign the audio input of the TV to the
corresponding video input. See the TV
user manual for details.
No sound or poor sound
• Adjust the volume.
• Disconnect the headphones.
• Check that the speakers are connected
correctly.
No audio output from the loudspeakers of
the audio device (stereo system/amplier/
receiver).
• Ensure that the audio cables are
connected to the audio input of the audio
device.
• Turn on the audio device to its correct
audio input source.
Play
No disc detected
• Insert a disc.
• Check if the disc is inserted upside down.
• Wait until the moisture condensation at
the lens has cleared.
• Replace or clean the disc.
• Use a nalized CD or correct format disc.
11 Troubleshooting
Caution
•
Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the philips web site (www.
philips.com/support). When you contact philips,
ensure that your apparatus is nearby and the
model number and serial number are available.
No power
• Ensure that the AC cord of the apparatus
is connected properly.
• Ensure that there is power at the AC
outlet.
• As a power-saving feature, the system
switches off automatically 15 minutes
after track play reaches the end and no
control is operated.
No picture
• Check the video connection.
• Turn on the TV to the correct Video-In
channel.
• Progressive scan is activated but the TV
does not support progressive scan.
Black and white or distorted picture
• The disc does not match the TV color
system standard (PAL/NTSC).
• Sometimes a slight picture distortion may
appear. This is not a malfunction.
• Clean the disc.
• A distorted picture may appear during
progressive scan setup.
EN
26
Others
Poor radio reception
• Increase the distance between the
apparatus and your TV or VCR.
• Fully extend the FM antenna.
• Connect an outdoor FM antenna instead.
Cannot display some les in USB device
• The number of folders or les in the USB
device has exceeded a certain limit. This
phenomenon is not a malfunction.
• The formats of these les are not
supported.
USB device not supported
• The USB storage device is incompatible
with the unitr. Try another one.
Timer does not work
• Set the clock correctly.
• Switch on the timer.
Clock/timer setting erased
• Power has been interrupted or the power
cord has been disconnected.
• Reset the clock/timer.
Disc does not play
• Insert a readable disc with the label side
facing you.
• Check the disc type, color system and
regional code. Check for any scratches or
smudges on the disc.
• Press SYSTEM MENU to exit the system
setup menu.
• Disable the password for parental control
or change the rating level.
• Moisture has condensed inside the
system. Remove the disc and leave the
system turned on for about an hour.
Disconnect and reconnect the AC power
plug, and then turn on the system again.
• As a power-saving feature, the system
turns off automatically 15 minutes after
disc play reaches the end and no control
is operated.
Remote control does not work
• Before you press any function button,
rst select the correct source with the
remote control instead of the main unit.
• Reduce the distance between the remote
control and the unit.
• Insert the battery with its polarities (+/–
signs) aligned as indicated.
• Replace the battery.
• Aim the remote control directly at the
sensor on the front of the unit.
Audio or subtitle languages cannot be set
• The disc is not recorded with sound or
subtitles in multiple languages.
• The audio or subtitle language setting is
prohibited on the disc.
DivX video les cannot be played.
• Make sure that the DivX video le is
complete.
• Make sure that the le extension is correct.
• Due to Digital Rights issue, the DRM-
protected video les stored on a
USB storage device cannot be played
through an analog video connection
(e.g. composite, component, and scart).
Transfer the video content onto a
supported disc to play these les.
EN
27
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
This apparatus includes this label:
12 Notice
Compliance and Environment
Any changes or modications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
This product complies with the radio
interference requirements of the European
Community.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol
is attached to a product it means that the
product is covered by the European Directive
2002/96/EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment
and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved.
DCD7010_12_UM_V4.0
