Router
WAN LAN
1
2
3
6
More: To add additional Powerline
adapters and extenders with the default
settings, simply plug them into the wall
sockets on the same electrical circuit.
4
Adapter
TL-PA7017P
Adapter
TL-PA7017P
* Applicable to TL-PA7017P and its multiple-pack kits.
* TL-PA7017P KIT (European version) is used for demonstration in this guide.
Images may dier from your actual product.
Quick Installation Guide
Same Electrical Circuit
Same Electrical Circuit
Attention
Wall Outlet Power Strip
Plug powerline devices into wall outlets instead of power strips.
Wait until the Powerline LED turns on.
Note: If the LED is o, please refer to FAQ-Q2.
