1620
Protector
Sensative equipment needs protection, and since 1976 the answer has been
the Pelican™ Protector Case. These cases are designed rugged, and travel
the harshest environments on earth. Against the extreme cold of the artic or
the heat of battle, Pelican cases have survived.
Made in the USA, these tough cases are designed with an automatic purge
valve, that equalizes air pressure, a watertight silicone O-ring lid, over-molded
rubber handles and stainless steel hardware.
- Retractable extension handle
- Strong polyurethane wheels with stainless steel bearings
- Easy open Double Throw latches
- Open cell core with solid wall design - strong, light weight
- O-ring seal
- Automatic Pressure Equalization Valve - balances interior pressure, keeps
water out
- Fold down handles
- Stainless steel hardware and padlock protectors
- 4 level Pick N Pluck™ with convoluted lid foam
- Personalized nameplate service available
- Watertight, crushproof, and dustproof
CONFIGURATIONS
1620
Standard
1624
With Padded Dividers
1620NF
No Foam
DIMENSIONS
Interior (L x W x D)
21.48 x 16.42" x 12.54 (54.6 x 41.7 x 31.9 cm)
Exterior (L x W x D)
24.76 x 19.57" x 13.90 (62.9 x 49.7 x 35.3 cm)
Lid Depth
2.01" (5.1 cm)
Bottom Depth
10.53" (26.7 cm)
Total Depth
12.54" (31.9 cm)
Int Volume
2.56 ft³ (0.072 m³)
MATERIALS
Body
Polypropylene
Latch
ABS
O-Ring
Polymer
Pins
Stainless Steel
Foam
1.3 lb Polyurethane
Purge Body
ABS
Purge Vent
3 Micron Hydrophobic Non-Woven
COLORS
Black OD Green Desert Tan
WEIGHT
Weight With Foam
24.62 lbs (11.2 kg)
Weight Empty
21.20 lbs (9.6 kg)
Buoyancy
149.91 lbs (68 kg)
Master Pack Weight
26.90 lbs (12.2 kg)
TEMPERATURE
Minimum Temperature
-40°
Maximum Temperature
210°
CERTIFICATIONS
IP67
MIL C-4150J
Def Stan 81-41
STANAG 4280
FOAM PROPERTIES
Layer 1 (Lid)
1.00" Convolute
Layer 2 (Base)
1.00" Pad
Layer 3 (Base)
2.38" Pick N Pluck
Layer 4 (Base)
2.38" Pick N Pluck
Layer 5 (Base)
2.38" Pick N Pluck
Layer 6 (Base)
2.38" Pick N Pluck
OTHER
Wheels
2
Extendable Handle
yes
Master Pack
1
Nameplate
yes
Military
yes
ACCESSORIES
1609
Lid Organizer
1621
6 pc. Replacement Foam Set
1622
Pick N Pluck™ Sections Only
(set of 4)
1623
Replacement O-ring
1625
Padded Divider Set
Pelican
23215 Early Ave • Torrance, CA 90505 USA • Phone: (310) 326-4700 • (800) 473-5422 • Fax: (310) 326-3311
[email protected] • www.pelican.com
Document created on 05-02-18
