Model 24V-X2-PW1200-RM
Form No. SJ-24V-X2-PW1200-RM-880E-MR1-V2
CORDLESS PORTABLE
PRESSURE WASHER
48V MAX* | 4.0 Ah | PRESSURE-SELECT TECHNOLOGY
1196 PSI MAX PRESSURE AT INITIAL DISCHARGE PER CSA INTERNAL PRESSURE TESTING
1 GPM MAX FLOW WITH NOZZLE OPEN AT MINIMUM PRESSURE
© 2021 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
A Division of Snow Joe
®
, LLC
R
OPERATOR’S MANUAL
Model 24V-X2-PW1200-RM
Form No. SJ-24V-X2-PW1200-RM-880E-MR1-V2
CORDLESS PORTABLE
PRESSURE WASHER
48V MAX* | 4.0 Ah | PRESSURE-SELECT TECHNOLOGY
1196 PSI MAX PRESSURE AT INITIAL DISCHARGE PER CSA INTERNAL PRESSURE TESTING
1 GPM MAX FLOW WITH NOZZLE OPEN AT MINIMUM PRESSURE
© 2021 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
1
A Division of Snow Joe
®
, LLC
R
OPERATOR’S MANUAL
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in death or serious injury.
General Safety
m
WARNING! This appliance is not intended for use by
persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play
with the appliance.
Before starting up your machine, please check it carefully for
any defects. If you nd any, do not start up your machine.
Contact your authorized Snow Joe
®
+ Sun Joe
®
dealer or
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! When using the pressure washer, basic
safety precautions should always be followed to reduce the
risk of re, electric shock, and personal injury. These include:
• Know your product – Know how to stop the machine and
bleed pressure quickly. Thoroughly familiarize yourself with
the controls.
• Keep bystanders away – All visitors and pets should be
kept a safe distance away from the work area.
• Use the right product – Do not use this machine for any
job except that for which it is intended.
• Dress properly – Do not wear loose clothing or jewelry.
They can get caught in moving parts. Protective rubber
gloves and non-slip footwear are recommended when
working outdoors.
•
mCAUTION! – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
• Stay alert – Watch what you are doing. Use common
sense. Do not operate the pressure washer when you are
tired, or under the inuence of alcohol or drugs.
• Do not overreach –
Keep proper footing and balance at
all times.
• Avoid unintentional starting – Do not carry a machine with
power with your nger on the trigger. Make sure the switch
is o before insert the batteries.
• Remove the batteries – Remove the batteries from the
pressure washer when it is not in use, before servicing it,
when changing accessories, and when performing any
other maintenance task.
• Use safety glasses – Also use safety footwear, snug-tting
clothing, protective gloves, hearing and head protection.
• Check the water temperature – This pressure washer is
not meant to pump hot water. NEVER connect it to a hot
water supply or pour hot water into the bucket as it will
signicantly reduce the life of the pump.
• Store indoors – NEVER store the pressure washer
outdoors or where it could freeze. The pump could be
seriously damaged.
mWARNING! Do not use this appliance without reading
this instruction manual.
mWARNING! This appliance has been designed for
use with cleaning agents that are recommended by the
manufacturer. The use of other cleaning agents or chemicals
may adversely aect the safety of the appliance.
mWARNING! Do not use the appliance within range of
persons unless they are wearing protective clothing.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
• Do not direct the jet at yourself or others in order to clean
clothes or footwear.
• Risk of explosion – Do not spray ammable liquids.
• Keep children away – This cordless pressure washer must
not be used by children or untrained personnel. Close
supervision is necessary when a product is used near
children.
2
• To ensure appliance safety, use only original replacement
parts from the manufacturer or those approved by the
manufacturer.
mWARNING! During cleaning, maintenance or when
replacing parts, the machine must be disconnected from its
power source by removing the batteries.
mWARNING! High-pressure hoses, ttings, and
couplings are important for the safe operation of the appliance.
Use only hoses, ttings, and couplings recommended by
the manufacturer.
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects.
If you nd any, do not start up your machine and contact
your distributor.
IMPORTANT: Only use water without any impurities.
If there is a risk of running sand into the inlet water (i.e. from
your own well), an additional lter should be installed.
• Check for damaged parts – Do not use the appliance if
any important parts of the appliance are damaged (e.g.
safety devices, high-pressure hoses, trigger gun).
• This cordless pressure power washer must not be used at
temperatures below 32ºF (0°C).
• Keep the machine on a stable, at surface during operation,
handling, transportation, and storage. Sudden overturn of
the machine can cause bodily injury.
• In the event of an accident or breakdown, switch o the
machine immediately. (If contact with detergent occurs,
rinse with an abundance of clean water.)
Battery + Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling the batteries. The following points
must be obeyed at all times to ensure safe use. Safe use can
only be guaranteed if undamaged cells are used. Incorrect
handling of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the cordless pressure washer and
cause it to malfunction, which can lead to serious personal
injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied battery may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
packs except as indicated in the instructions for use and care.
Have your battery packs serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery packs is maintained.
mCAUTION! To reduce the risk of injury, charge the 24V
iON+ lithium-ion battery packs only in the designated 24V
iON+ lithium-ion charger. Other types of chargers present risk
of re, personal injury and damage. Do not wire the battery
packs to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery packs.
• Avoid dangerous environments – Do not charge the
battery packs in rain, snow or in damp or wet locations.
Do not use the battery packs or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when
connecting or disconnecting the battery pack, which could
lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is 41°F –
105ºF (5°C – 40.5°C). Do not charge the batteries outside in
freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger 24VCHRG-DPC is rated for 120 volt AC
only – The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to
disconnect battery packs from unplugged charger.
3
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage. Toxic
fumes and materials are created when the battery pack is
burned.
• Do not crush, drop or damage battery packs – Do not
use the battery packs or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the batteries or charger are damaged,
contact an authorized Snow Joe
®
+ Sun Joe
®
dealer or
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery packs and charger in a cool, dry
place – Do not store the battery packs or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the batteries
1. The battery packs supplied with your cordless pressure
washer are only partially charged. The battery packs have
to be charged completely before you use the tool for the
rst time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery packs frequently.
3. Store the battery packs in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging
process. The battery packs must be replaced at the latest
when their capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your cordless pressure
washer, and therefore pose a safety risk.
5. Do not throw the battery packs into an open re as this
poses a risk of explosion.
6. Do not ignite the battery packs or expose them to re.
7. Do not exhaustively discharge the batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged battery. Stop working as
soon as the performance of the battery fall noticeably or
the electronic protection system triggers. Place the battery
packs in storage only after they have been fully charged.
8. Protect the batteries and the tool from overloads.
Overloads will quickly result in overheating and cell
damage inside the battery housing even if this overheating
is not apparent externally.
9. Avoid damage and shocks. Immediately replace the
batteries that has been dropped from a height of more
than one meter or has been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
10. If the battery packs suer overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the On/O button any more
if the protective cut-o has been activated. This may
damage the battery packs.
11. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe
®
+
Sun Joe
®
dealer or call the Snow Joe
®
+ Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery packs and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
4
6. During periods of heavy use, the battery packs will
become warm. Allow the battery packs to cool to room
temperature before recharging.
7. Do not overcharge the batteries. Do not exceed the
maximum charging times. These charging times only
apply to discharged batteries. Frequent connection of
a charged or partially charged battery pack will result in
overcharging and cell damage. Do not leave the batteries
connected with the charger for days on end.
8. Never use or charge battery if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging the batteries at a temperature below 41°F (5°C)
will cause chemical damage to the cells and may cause a
re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use the battery if it suered curvature or
deformation during the charging process or exhibit other
atypical symptoms (gassing, hissing, cracking, etc.).
12. Never fully discharge the battery packs (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protectionfromenvironmentalinuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger
from moisture and rain – Moisture and rain can cause
dangerous cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery packs in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery packs, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery packs from freezing.
Battery packs that were stored below 32°F (0°C) for more
than 60 minutes must be discarded.
9. When handling the batteries, be wary of electrostatic
charge. Electrostatic discharges can damage the
electronic protection system and the battery cells. Avoid
electrostatic charging and never touch the battery poles.
Risk of Explosion
• Do not spray ammable liquids.
• Do not use acids, bases, solvents, or any ammable
material in this product. These substances can cause
physical injuries to the operator and irreversible damage to
the machine.
Additional Safety Instructions
• High-pressure: keep clear of nozzle.
• Injection hazard: equipment can cause serious injury if the
spray penetrates the skin.
• Do not point the gun at anyone or at any part of the body.
• In case of skin penetration, seek medical aid immediately.
• Before servicing, cleaning, or removing any parts, shut o
the power and relieve pressure.
• This machine is not suitable for connection to the potable
water mains.
• Do not spray electrical apparatus and wiring.
• ARCING PARTS – Keep the motor at least 20 ft (6 m) away
from explosive vapors.
•
mCAUTION! Gun kicks back. Hold trigger with
both hands.
Product Description
Purpose
• This cordless pressure power washer is intended for
residential use to clean vehicles, machines, buildings,
facades, etc.
Areas of Application
• Never use the machine in potentially explosive areas under
any circumstances!
• The operating temperature must be between 32ºF (0ºC) and
104ºF (40ºC).
• The machine consists of an assembly with a pump, which
is encased in a shock-absorbing housing. To provide the
operator with an optimal working position, the machine is
equipped with a spray wand.
• Do not cover or modify the spray wand or the spray nozzles
in any way.
• The cordless pressure washer is designed to be used with
cold or lukewarm water; higher temperatures can damage
the pump.
• Do not use water that is dirty, gritty, or contains any
chemical products, as these could impair operation and
shorten the life of the machine.
5
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
To reduce the risk of injury, user
must keep all bystanders at least
49 ft (15 m) away.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
WARNING! Do not expose the unit
to rain or wet conditions. Keep dry.
Machine not suitable for connection
to the potable water mains.
Symbols SymbolsDescriptions Descriptions
Wear non-slip footwear that will
protect your feet and improve your
footing on slippery surfaces.
Wear safety gloves during
use to protect hands.
Store indoors. Never store the
pressure washer outdoors.
If the pump freezes, permanent
damage may result.
Indoor use only. Only use battery
charger indoors.
6
Know Your Cordless Pressure Washer
Read the owner’s manual and safety instructions carefully before operating the cordless pressure washer. Compare the
illustration below to the cordless pressure washer in order to familiarize yourself with the location of the various controls and
adjustments. Save this manual for future reference.
R
1
2
3
456
7
8
9
10 11
12
13
14
1516
17
18
20
21
22
23
24
2526
272829
30
31
32
33
19
1. High-pressure hose connection
2. Lock latch
3. Safety lock
4. Trigger
5. Trigger gun
6. Bucket handles (2)
7. Bucket lid
8. Lid buckles (2)
9. Water bucket
10. Base unit
11. Water outlet/high-pressure hose
connection
12. Base handle
13. Bucket buckles (2)
14. All-direction wheel (2)
15. Front wheel
16. Control panel
17. Battery compartment cover
18. Water inlet connector
19. Garden hose adapter/connection
20. Water inlet/Bucket adapter
21. 5-in-1 Quick-Connect nozzle
22. Quick-Connect collar
23. Spray wand
24. Trigger gun holder
25. 24V iON+ lithium-ion battery
(2) (24VBAT) featuring exclusive
EcoSharp
®
technology
26. Push lock button
27. Push button for battery indicator
28. Battery indicator
29. Charger plug
30. 24V iON+ lithium-ion dual-port
charger (24VCHRG-DPC)
31. High-pressure hose
32. Foam Cannon
33. Needle clean-out tool
7
Technical Data
Motor .............................................................. 600 W Brushless
Battery Voltage Max* .................................. 48V D.C. (2 x 24 V)
Battery Capacity ............................................................. 4.0 Ah
Charger Input ....................................... 120 V AC, 60Hz, 160 W
Charger Output ............................................ 26 V DC, 2 x 2.2 A
Charge Time Max .................................................... 1 hr 50 min
Max Water Inlet Temperature ................................. 104ºF/40ºC
Max Water Inlet Pressure ............................................ 0.7 MPa
Max Pressure at initial discharge ................................ 1196 PSI
per CSA internal pressure testing
Rated Pressure under typical load ...................... LOW 650 PSI
HIGH 800 PSI
Max Flow with nozzle open ........................................... 1 GPM
at minimum pressure
Rated Flow under typical load ......................... LOW 0.65 GPM
HIGH 0.77 GPM
Removable Bucket Capacity ................................ 6.6 gal (25 L)
Foam Cannon Capacity ................................... 8.5 oz (0.25 L)
High Pressure Hose Length ....................................... 20 ft (6 m)
Net Weight ........................................................ 26 lbs (11.8 kg)
* Generates 48 V max with two 24 V lithium-ion batteries. Initial no-load voltage,
..per fully charged battery, peaks at 24 V. Nominal voltage under typical load is
..21.6 V.
Unpacking
Carton Contents
• Water bucket assembly
• Bucket lid
• Base unit
• Trigger gun
• Spray wand
• 5-in-1 Quick-Connect nozzle
• Needle clean-out tool
• Foam cannon
• Trigger gun holder
• High-pressure hose
• Garden hose adapter (female coupler)
• Water inlet connector
• 24V iON+ lithium-ion batteries (2)
• 24V iON+ lithium-ion dual port charger
• Manual and registration card
1. Carefully remove the pressure washer and check to see that
all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
pressure washer. The packaging is made of recyclable
materials. Properly dispose of these materials in accordance
with local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation risk!
mWARNING! Do not insert the batteries until assembly is
complete. Failure to comply could result in accidental starting and
possible serious personal injury.
Battery Pack Operation
The equipment is powered by 2 lithium-ion batteries. The
battery packs are completely sealed and maintenance free.
mWARNING! The pressure washer can only be powered
by both of the batteries together. Using one battery cannot
provide sucient power to start the tool. Make sure to use
two batteries of the same voltage and the same capacity.
Using the tool with batteries of dierent capacities will cause
damage to the batteries.
mWARNING! Before rst use, the batteries require 1 hr
50 min charge time to be fully charged. When the batteries
are at low capacity, recharge for 1 hr 50 min again before
resuming operation.
Battery Charge Level Indicator
The battery packs are equipped with a push button for
checking the charge level. Simply press the push button to
read o the battery charge level from the LEDs of the battery
indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
* Generates 48 V max with two 24 V lithium-ion batteries. Initial no-load voltage,
..per fully charged battery, peaks at 24 V. Nominal voltage under typical load is
..21.6 V.
8
NOTE: If the charge level button does not appear to be
working, connect to the charger and charge as needed.
NOTE: Immediately after using the battery packs, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
Charger Operation
m
WARNING! Charge only 24V iON+ lithium-ion battery
packs with its compatible 24V iON+ lithium-ion charger. Other
types of batteries may cause personal injury and damage.
To reduce the risk of electric shock, do not allow water to ow
into the charger's AC/DC plug.
When to Charge the iON+ 24VBAT
Lithium-iON Batteries
NOTE: The iON+ 24VBAT lithium-iON battery packs do
not develop a "memory" when charged after only a partial
discharge. Therefore, it is not necessary to run down the
battery packs before charging them again.
• Use the battery indicator lights to determine when to charge
your iON+ 24VBAT lithium-iON battery packs.
• You can "top-o" your battery packs' charge before starting
a big job or after a long day of use.
Charging the Battery
1. Open the battery compartment cover, and push the push
lock buttons on the batteries to pull the battery packs out
from the battery compartment (Fig. 1).
2. Check that the mains voltage is the same as that marked
on the rating plate of the battery charger. Then, insert the
charger's plug into the electrical wall outlet. When you
plug in the charger, two green lights will illuminate and
stay green (Fig. 2).
3. Place the battery packs into the charger by sliding the
packs to lock them into position. When you insert the
batteries into the charger, the two green lights will go
o, and the red lights will illuminate to indicate that the
batteries are charging (Fig. 3).
4. When the charger lights turn green, the batteries are fully
charged (Fig. 3).
NOTE: A fully discharged pack with an internal
temperature in the normal range will fully charge in
1 hr 50 min (between 32ºF/0ºC and 113ºF/45ºC).
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights
Fig. 1
Battery packs
Battery
compartment cover
Fig. 2
Charger
green
Power on
Fig. 3
Battery packs
red
Charging
green
Fully
Charged
9
5. If the light indicators do not come on at all, check that
the battery packs are fully seated into the bay. Remove
the battery packs and reinsert. If the problem persists,
contact an authorized Snow Joe
®
+ Sun Joe
®
dealer or
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
6. When charging is complete, remove the batteries from the
charger by pressing the push lock buttons and sliding the
batteries backward to unlock them from the charger
(Fig. 4).
mCAUTION! FIRE HAZARD. When removing the batteries
from the charger, be sure to unplug the charger from the outlet
rst, then remove the batteries from the charger.
mWARNING! This charger does not automatically turn
o when the batteries are fully charged. Please take care not
to leave the batteries in the charger. Switch o or unplug the
charger at the mains when charging is complete.
7. Timely recharging of the batteries will help prolong the
batteries' life. You must recharge the battery packs when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery packs to become
fully discharged as this will cause irreversible damage to the
batteries.
Charging a Hot or Cold Battery Pack
The green indicator lights on the charger base indicates that
the battery packs' temperatures are outside the charging
range. Once the packs are within the acceptable range,
normal charging will take place and the red light will be
continuous. Hot or cold battery packs may take longer to
charge.
Assembly
1. The washer must be used on a secure and stable surface in
a standing, upright position (Fig. 5).
2.
Open the box, take out the bucket lid, bucket and the
base unit (Fig. 6).
3. Insert the trigger gun holder onto the bucket (Fig. 7).
Fig. 4
Push lock
button
Lithium-Ion Charging Status
Battery
Pack
Temperature
Charger
Base
Indicator
Light
Battery
Pack
Indicator
Light
Charging
Status
Too hot
Green
Flashing
together
Not charging
Normal range
Red
Flashing
one by one
Normal
charging
Too cold
Green
Flashing
together
Not charging
Fig. 5
Fig. 6
Bucket lid
Base unit
Bucket
10
4. Align the water inlet on the base unit with the outlet on
the bottom of the bucket, and seat the bucket on the
base unit. Check alignment to ensure a proper seal and
connection (Fig. 8).
5. Flip up the buckles on the base unit and latch to bucket.
Press down on the buckle ends to lock the bucket to the
base unit (Fig. 9).
mWARNING! When the water bucket is xed on the base
unit, do not lift the pressure washer by the handles. Instead,
use the one handle to pull the pressure washer unit along on
its wheels (Fig. 10).
6. Take the spray wand and align the two tabs with your
trigger gun. Once aligned, push the spray wand rmly into
the trigger gun, twist counter-clockwise to lock into place
(Fig. 11).
R
Fig. 7
Trigger gun holder
R
Fig. 8
Base unit
Bucket
Water inlet
Fig. 9
Bucket
buckle
Press the
end
Flip up
R
Fig. 10
Fig. 11
Spray wand
Trigger gun
11
7. The 5-in-1 nozzle is equipped with a Quick-Connect tip
which can be easily attached to the Quick-Connect collar
of the spray wand. To connect the nozzle, pulling the
quick-connect collar backwards, at the same time, snap
the nozzle onto the quick-connect collar until it clicks into
place, then release the quick-connect collar (Fig. 12).
mWARNING! Do not attach or remove the nozzle while
the trigger is engaged. Doing so could result in damage to the
pressure washer or injury to the user.
8. Unlock the lock latch by sliding it down, and insert the
high pressure hose into the high pressure hose connection
on the end of the trigger gun. Slide the latch back to lock
the hose in place (Figs. 13 – 14).
mWARNING! Keep hose away from sharp objects.
Bursting hoses may cause injury. Examine hoses regularly and
replace if damaged. Do not attempt to mend a damaged hose.
9. Connect the high-pressure hose to the base unit by
inserting the other end into the water outlet. While pushing
rmly in on the hose, twist the outer collar clockwise until
tight to ensure a water-tight connection (Fig. 15).
10. Put the trigger gun with spray wand assembly on the gun
holder. Your pressure washer is ready for use (Fig. 16).
Fig. 12
5-in-1 nozzle
“Click”
Quick-Connect collar
Spray wand
Lock latch
High-pressure hose
Fig. 13
Lock latch
High-pressure hose
Fig. 14
Fig. 15
High-pressure hose
Water outlet
R
Fig. 16
12
Operation
m
IMPORTANT! This pressure washer is equipped with
a micro-switch sensitive to water ow. This Total Stop System
(TSS) senses water ow in the pump. When the trigger is
released, water stops owing through the pump. The TSS then
automatically turns the motor o to protect the pump from
overheating, thus saving energy and prolonging pump life.
The TSS system will work only when there's water in the
bucket or the base unit is connected with a water supply.
When there's no water connected with the unit, the On/O
button has to be pressed to stop the unit.
mIMPORTANT! This system is capable of producing
8 Mpa. To avoid rupture and injury, do not operate this pump
with components rated less than 8 Mpa working pressure
(including but not limited to spray guns, hose, and hose
connections).
Connecting to Water Source and Start
the Unit
1. Open the battery compartment cover and slide the battery
packs in until they click to lock into position, then close
the battery compartment cover (Fig. 17).
2. Remove the water bucket from the base unit and ll with
clean (fresh) water.
mWARNING! The intake water temperature must not
exceed 104ºF/40ºC.
mCAUTION! The washer must only be used with clean
(fresh) water; use of unltered water containing corrosive
chemicals will damage the washer.
mWARNING! Do not ll the bucket with the bucket still
xed on the base unit.
3. Put the bucket back on the base unit. Make sure the
bucket is properly aligned on the base. Latch and lock
the buckles to ensure the bucket is securely connected
before using (Figs. 8 – 9).
NOTE: If you do not want to use the bucket, you can use
the base unit directly as a pressure washer. See following
instructions (step 4 – 6) to learn how to connect the base unit
with a water supply.
4. Disengage the bucket buckles and remove the bucket
from the base unit. Disconnect the bucket adapter from
the water inlet by turning it counterclockwise with a
wrench (Fig. 18).
5. Connect the included brass water inlet connector to the
water inlet and turn it clockwise to lock securely. Connect
the included garden hose adapter with the brass water
inlet connector and push it until it clicks and locks in place
(Fig. 19).
6. Thread your garden hose (male end) into the garden
hose adapter (Fig. 20). The garden hose must have an
internal diameter of at least 13 mm (1/2 in.) and must be
reinforced. The water supply must be at least equal to the
washer delivery capacity.
Fig. 17
Battery
compartment cover
Fig. 18
Bucket adapter
Water inlet
Fig. 19
Water inlet
Water inlet connector
Garden hose adapter
13
7. Attach garden hose to water supply (Fig. 21).
mWARNING! Water that has owed through back ow
preventers is considered to be non-potable.
mWARNING! The water supply must not exceed 0.7Mpa.
8. If only using the base unit, turn the water supply tap
on completely.
9. Push the safety lock on the spray gun handle, then press
the trigger for a few seconds until the water ow is steady.
Operating the pressure washer in this manner will allow
air to escape and discharge residual pressure in the hose
(Fig. 22).
10. Keeping the trigger pressed, turn on the unit by pressing
the On/O button on the control panel. Using the "Pressure
Select" feature, you can also use the pressure washer in a
lower setting by pressing the
button below the ON/O
button (Fig. 23).
NOTE: This machine is equipped with 2 power/pressure levels.
When starting, the machine is set in default high power/high
pressure level. See table below for detailed specs.
11. When re-starting the motor, always keep the trigger
pressed.
NOTE: The motor only runs when the trigger is operated
and shuts o when the trigger is released.
Control Panel (Fig. 24)
Fig. 20
Garden hose
Fig. 21
Connect to water supply
Garden hose
Fig. 22
Trigger
Safety lock
Fig. 23
Control panel
Power
Light
indication
Ratedow
Rated
pressure
– O
– On
High 0.65 GPM 800 PSI
– On
– On
Low 0.77 GPM 650 PSI
Fig. 24
On/Obutton
Power indicator
Low power
mode indicator
Low power
setting button
Error indicator
14
1. On/Obutton–Press to turn on and shut o the
machine. The power indicator will light when the machine
is turned on.
2. Low setting button – After turning on the machine, press
to enter the low power/pressure level. The low setting
indicator will light when the machine enters low power/
pressure level. The low power/pressure level reduces the
motor speed for a maximum battery life. It is also ideal for
cleaning everyday dirt + grime.
NOTE: The machine is set to be operated in default high
power/ high pressure level when it is started every time.
You need to press the low setting button if low power/
pressure level is desired. To enter HIGH power/high
pressure level from low power/pressure level, press the
low setting button again. The low setting indicator will turn
o and the machine will increase power and pressure.
3. Error indicator – The error indicator is o when the
machine is working normally. A ashing error indicator
means something is wrong with the machine. Check the
table below for possible causes and solutions for the
ashing error indicator. If the indicator keeps ashing
after all the measures have been taken, please call
the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563)
Using the 5-in-1 Quick-connect Nozzle
Before beginning any cleaning task, determine the best spray
setting for the job. The included 5-in-1 Quick-Connect nozzle
features 5 dierent spray options to match your desired
cleaning application. The nozzle patterns are 40˚ (for gentle
cleaning), 15˚ (for tough jobs), 0˚ (for spot cleaning or hard-to-
reach areas), 0+ (for long range spray), 40+ (for short range
spray).
mCAUTION! NEVER change spray pattern without
locking the safety lock on the trigger handle.
mWARNING! High-pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
pets, live electrical equipment, or the appliance itself.
To change the spray pattern for the nozzle, rst make sure the
pressure washer is shut o and not connected with any water
source, and the trigger gun is locked, then twist the nozzle
collar to align the symbol of the desired spray pattern with the
mark on the nozzle (Fig. 25).
Working with Detergents
When cleaning with the pressure washer, some cleaning tasks
can be solved with water alone, but for most tasks cleaning
with detergent allows for more eective dirt removal.
mWARNING! Use only detergents specically designed
for use with pressure washers, such as Sun Joe
®
HOUSE +
DECK WASH (SPX-HDC1G), Sun Joe
®
SNOW FOAM AUTO
WASH (SPX-FCS1G), or Sun Joe
®
HEAVY DUTY CLEANER
(SPX-APC1G). DO NOT USE household detergents, acids,
alkaline solutions, bleaches, solvents, ammable material, or
industrial grade solutions. These could damage the pressure
washer. Many detergents may require mixing prior to use.
Prepare the cleaning solution as instructed on the solution
bottle.
1. Turn o the pressure washer, remove the bucket or shut
o the water supply. Pull the trigger to release water
pressure.
2. Remove the spray wand attachment from the trigger gun.
3. Remove the soap dispenser sprayer from the bottle and
ll with mixed detergent. Put the sprayer back on when
nished.
4. Take the foam cannon and align the two tabs with your
trigger gun. Once aligned, push it into the trigger gun, and
twist counter-clockwise to lock securely into place
(Fig. 26).
Error Indicator
Possible Reasons
Solutions
Flashes for 6
seconds and
shuts down
Short circuit Please call the
Snow Joe
®
+ Sun
Joe
®
customer
service center at
1-866-SNOWJOE
(1-866-766-9563)
for assistance.
Flashes for 3 min
and shuts down
•Nozzle is blocked.
•Batteries are at.
•Clean the nozzle
with the included
needle clean-out
tool.
•Recharge the
batteries.
Fig. 25
Multi-spray nozzle
Align with the mark
15
5. Reconnect the pressure washer with the water bucket or
the garden hose. Turn on the pressure washer. Pull the
trigger to operate the unit.
mCAUTION! Always test the detergent in an
inconspicuous area before use.
6. Apply detergent from the bottom to the top of the dry
surface to be cleaned.
NOTE: Wetting the surface rst is not recommended as it
dilutes the detergent and reduces its cleaning ability.
7. Allow the detergent to remain on the surface for a short
time before rinsing. Do not allow the detergent to dry on
the surface.
mCAUTION! Damage may occur to painted surfaces if
the detergent is allowed to dry on the surface. Wash and rinse
a small section at a time. Avoid working on hot surfaces or in
direct sunlight.
mCAUTION! Failure to follow these cleaning instructions
will cause the injection system to become clogged and
inoperable.
Rinsing with the Pressure Washer
1. Turn o the pressure washer, remove the bucket or shut
o the water supply.
2. Pull the trigger to release water pressure.
3. Push the safety lock on the trigger handle to lock it.
4. Remove the foam cannon by pushing rmly in while
twisting it clockwise to unlock the tabs and remove from
the slots. Pull the attachment out of the trigger gun.
5. Attach the spray wand and the 5-in-1 nozzle onto the
trigger gun.
6. Select the right spray pattern for the job (Fig. 27).
I) The 0º intense-jet spray pattern is an extremely
powerful , high-pressure, pencil-point jet stream.
It is used to cut heavy dirt deposits in a small,
concentrated area. It is ideal for dissolving stubborn
substances, like tar and grease spots on concrete,
or for removing caked mud from equipment. Use this
pattern to clean hard-to-reach areas including the
facades of 2-story buildings or the undersides of lawn
mowers and tractors.
NOTE: Care should be used when choosing the right
spray pattern to avoid permanently gouging wood or
damaging fragile surfaces.
II) Use the 0+ straight line pattern for home siding, brick
patios, wood decks, driveways, or sidewalks. When
using this nozzle, test a small area rst to avoid surface
damage.
III) Use the 15º spray pattern for intense cleaning jobs on
hard surfaces. Applications include stripping paint,
removing oil stains, grease, heavy mildew stains, and
rust from steel. This spray should only be used in areas
that can withstand the high-pressure from this spray.
IV) Use the 40º wide-spray pattern to clean items such as
cars, trucks, boats, patio furniture, or lawn equipment.
V) Use the 40+ pattern for light cleaning applications.
7. Lock the bucket with water on the base unit or connect
the base unit with a water supply. Start at the top of the
area to be rinsed and work your way down, making sure
to overlap your strokes.
mIMPORTANT! NEVER USE:
• Bleach, chlorine products, and other corrosive chemicals
• Liquids containing solvents (e.g. paint thinners,
gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
Fig. 26
Trigger gun
Foam cannon
Fig. 27
0º
15º
40º 0+
40+
16
These chemicals will harm the unit and will damage the
cleaning surface.
Shutting Down
1. Press the On/O button on the control panel.
2. Pour the remaining water out from the bucket or turn o
the water source.
3. Hold the trigger to release water pressure.
4. If using the base unit directly, disconnect the garden hose
from the water inlet on the base unit.
5. Disconnect the high-pressure hose connection on the
trigger gun handle.
6. Release the trigger and lock the gun safety lock.
mWARNING! Turn o the water supply and squeeze the
trigger to depressurize the unit. Failure to do so could result in
personal injury due to discharge of high-pressure water.
Taking a Break
If you are taking a break between cleaning tasks:
1. Lock the gun safety lock.
2. Push the On/O button to stop the machine.
NOTE: If being kept in stand-by mode for 3 minutes, the
machine will shut o automatically.
Storage
mCAUTION! Always store your pressure washer in a
location where the temperature will not fall below 32ºF (0ºC).
The pump in this machine is susceptible to permanent damage
if it freezes. FREEZE DAMAGE IS NOT COVERED BY THE
WARRANTY.
• Store the pressure washer indoors in a dry, covered area
where it is not subject to adverse weather conditions.
• It is important to store this product in a frost-free area.
• Always empty water from all hoses, the pump, the soap
dispense attachment and the bucket before storing.
mCAUTION! The use of a pump protector is
recommended to prevent cold weather damage during storage
over the winter months.
Winterizing + Long-Term Storage
If you must store your pressure washer in a location where
the temperature falls below 32ºF (0ºC), you can minimize the
chance of damage to your machine by utilizing the following
procedure:
• Disconnect all water connections.
• Turn on the machine for a few seconds until the remaining
water in the pump exits. Turn o immediately.
• Do not allow the high-pressure hose to become kinked.
• Store the machine and accessories in a room that does
not reach freezing temperatures.
• Do not store near a furnace or other sources of heat that
may dry out the pump seals.
• Operate the pressure washer with non-corrosive/non-toxic
anti-freeze, a pump saver, or a pump protector before
storing for the winter.
mWARNING! Before reusing, completely ush the
unit out with clear water. Anti-freeze products can damage
paintwork, so you must ensure there is no anti-freeze left in the
system before using it again.
Maintenance
m
CAUTION! Before working on the pressure washer,
remove the batteries from the compartment.
1. To ensure good performance, check and clean the lters.
Remove the lters and rinse with warm water to prevent
any foreign matter from clogging the pump.
2. Remove the water bucket lid and make sure the bucket is
empty.
3. Turn the bucket lter counterclockwise to align the tabs
with the slots, and disassemble it from the water bucket
(Fig. 28).
4. Remove the bucket from the base unit. Disconnect
the bucket adapter from the water inlet by turning it
counterclockwise (Fig. 18)
5. Using pliers, remove the water inlet lter from the water
inlet (Fig. 29)
Fig. 28
Water bucket
Bucketlter
Tab
Slots
17
6. Rinse both lters and all other components with warm
water to prevent any foreign matter from clogging the
pump.
7. Remove the nozzle by placing your hand over the nozzle
while pulling back on the Quick-Connect collar. Clean the
nozzle with the needle clean-out tool provided (Fig. 30).
Remove the spray wand from the gun; remove any dirt
from the nozzle orices and rinse.
8. Remove additional debris by back ushing water through
the nozzle and spray wand. To do this, place the end of
your garden hose (with water running) to the tip of the
nozzle, pushing water and debris out of the back opening
of the nozzle and spray wand.
Disposal
Recycling the Washer
• Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities.
• Contact your local government agency for information
regarding the collection systems available.
• If electrical appliances are disposed of in landlls
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
• When replacing old appliances with new ones, the retailer
is legally obligated to take back your old appliance for
disposal at least free of charge.
Recycling + Disposal
The product comes in a package that protects it against
damage during shipping. Keep the package until you are
sure that all parts have been delivered and the product is
functioning properly. Recycle the package afterwards or keep
it for long-term storage.
WEEE symbol. Waste electrical products should not
be disposed of with household waste. Please
recycle where facilities exist. Check with your local
authority or local store for recycling regulations.
Battery Caution + Disposal
Always dispose of your battery packs according to federal,
state, and local regulations. Contact a recycling agency in your
area for recycling locations.
mCAUTION! Even discharged battery packs contain
some energy. Before disposing, use electrical tape to cover
the terminals to prevent the battery pack from shorting, which
could cause a re or explosion.
mWARNING! To reduce the risk of injury or explosion,
never burn or incinerate a battery pack even if it is damaged,
dead or completely discharged. When burned, toxic fumes
and materials are emitted into the surrounding atmosphere.
1. Batteries vary according to device. Consult your manual
for specic information.
2. Install only new batteries of the same type in your product
(where applicable).
3. Failure to insert batteries in the correct polarity, as
indicated in the battery compartment or manual, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc) or
Rechargeable (Nickel Cadmium, Nickel Metal Hydride, or
Lithium-Ion) batteries.
6. Do not dispose of batteries in re.
7. Batteries should be recycled or disposed of as per state
and local guidelines.
Fig. 29
Waterinletlter
Fig. 30
Needle clean-out tool
18
Service + Support
If your Sun Joe
®
24V-X2-PW1200-RM cordless pressure washer
requires service or maintenance, please call the Snow Joe
®
+
Sun Joe
®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
24VCHRG-DPC
Federal Communications Commission
(FCC)
mWARNING! Any changes or modications to this
unit not expressly approved by the party responsible for
compliance could void the user's authority to operate
the equipment.
Class B device:
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Record the following numbers from the housing or handle of your
new product:
2 4 V - X 2 - P W 1 2 0 0 - R M
Model #:
Serial #:
19
Troubleshooting
• Remove the batteries from the compartment before carrying out maintenance on the machine or when checking that its parts
are in proper working order.
• To avoid unnecessary hassles, consult the following table before contacting customer service with any mechanical issues.
Problems Possible Cause Possible Solution
Machine refuses
to start
• Power failure/Batteries are not
inserted well
• Check to make sure the batteries have
sucient power and are inserted well
• Check the hoses and connections are airtight
• Clean or replace valves/seals
• Please call the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563)
for assistance
• Clean the nozzle
• Charge the batteries.
• Allow machine to run by holding the trigger until
regular working pressure resumes
• Check that the water supply corresponds to the
specications required
• WARNING! Avoid using long, thin hoses
(minimum 1/2 in. diameter)
• Clean the nozzle
• Clean the lters
• Straighten out the hose to remove any kinks/blockages
• Please call Snow Joe
®
+ Sun Joe
®
customer service
center at 1-866-SNOWJOE (1-866-766-9563) for
assistance
• Wait for pump/hoses or accessories to thaw
• Connect inlet water
• Clean the lters
• Clean the nozzle
• Pump sucking air
• Valves dirty, worn out, or stuck
• Pump seals worn out
• Nozzle partially blocked
• Batteries are at
• Air in inlet hose
• Inadequate supply of mains water
• Nozzle partially blocked
• Water lter blocked
• Hose kinked
• Pump/spray gun is leaking
• Trigger mechanism is broken
• Pump/hoses or accessories frozen
• No water supply
• Water lter blocked
• Nozzle blocked
Fluctuating pressure
The error indicator
ashes and then
machine stops
Machine pulsating
Machine often starts
and stops by itself
Machine starts, but
no water comes out
20
Optional Accessories
m
WARNING! ALWAYS use only authorized Snow Joe
®
+ Sun Joe
®
replacement parts and accessories. NEVER use
replacement parts or accessories that are not intended for use with this cordless pressure washer. Contact Snow Joe
®
+
Sun Joe
®
if you are unsure whether it is safe to use a particular replacement part or accessory with your pressure washer. The
use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage.
24V iON+ Lithium-Ion Battery Quick Charger 24VCHRG-QC
ModelAccessories Item
1
2
3
4
5
24V iON+ 2.0 Ah Lithium-Ion Battery 24VBAT-LTE
24V iON+ 2.5 Ah Lithium-Ion Battery 24VBAT-LT
24V iON+ 4.0 Ah Lithium-Ion Battery 24VBAT
24V iON+ 5.0 Ah Lithium-Ion Battery
24VBAT-XR
6
24V iON+ Lithium-Ion Dual-Port Battery Charger
24VCHRG-DPC
Sun Joe’s complete line of premium pressure washer accessories and attachments
make it easy to get your dirty work done, and also help you get the most out of your model!
SHOP ONLINE now at sunjoe.com
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
®
+ Sun Joe
®
to provide notice of such
changes. Accessories can be ordered online at sunjoe.com or via phone by contacting the Snow Joe
®
+ Sun Joe
®
customer
service center at 1-866-SNOWJOE (1-866-766-9563).
SNOW JOE
®
+ SUN JOE
®
REFURBISHED GOODS WARRANTY
GENERAL CONDITIONS:
Snow Joe
®
+ Sun Joe
®
operating under Snow Joe
®
, LLC warrants
this refurbished product to the original purchaser for 90 days
against defects in material or workmanship when used for normal
residential purposes. If a replacement part or product is needed,
it will be sent free of charge to the original purchaser except as
noted below.
The duration of this warranty applies only if the product is put to
personal use around the household. It is the owner’s responsibility
to correctly perform all maintenance and minor adjustments
explained in the owner’s manual.
HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:
To obtain a replacement part or product, please visit
snowjoe.com/help or email us at [email protected] for
instructions. Please be sure to register your unit beforehand
to speed up this process. Certain products may require a serial
number, typically found on the decal afxed to the housing
or guard of your product. All products require a valid proof
of purchase.
EXCLUSIONS:
• Wearing parts like belts, augers, chains and tines are
not covered under this warranty. Wearing parts can be
purchased at snowjoe.com or by calling 1-866-SNOWJOE
(1-866-766-9563).
• Batteries are covered in full for 90-days from the date of
purchase.
Snow Joe
®
+ Sun Joe
®
may from time to time change the design of
its products. Nothing contained in this warranty shall be construed
as obligating Snow Joe
®
+ Sun Joe
®
to incorporate such design
changes into previously manufactured products, nor shall such
changes be construed as an admission that previous designs
were defective.
This warranty is intended to cover product defects only.
Snow Joe
®
, LLC is not liable for indirect, incidental or
consequential damages in connection with the use or misuse of
the Snow Joe
®
+ Sun Joe
®
products covered by this warranty.
This warranty does not cover any cost or expense incurred
by the purchaser in providing substitute equipment or service
during reasonable periods of malfunction or non-use of this product
while waiting for a replacement part or unit under this warranty.
Some states do not allow exclusions of incidental or consequential
damages so the above exclusions may not apply in all states. This
warranty may give you specic legal rights in your state.
HOW TO REACH US:
We’re here to help Monday through Friday from 9AM to 7PM EST
and Saturday and Sunday 9AM to 4PM. You can reach us at
1-866-SNOWJOE (1 866-766-9563), online at snowjoe/com, via
email at [email protected] or tweet us @snowjoe.
EXPORTS:
Customers who have purchased Snow Joe
®
+ Sun Joe
®
products exported from the United States and Canada should
contact their Snow Joe
®
+ Sun Joe
®
distributor (dealer) to obtain
information applicable to your country, province or state. If for
any reason, you are not satised with the distributor’s service,
or if you have difculty obtaining warranty information, contact
your Snow Joe
®
+ Sun Joe
®
seller. If in the event your efforts are
unsatisfactory, please reach out to us directly.
22
sunjoe.com
