User Manual Netgear ‎XS728T-100NES Switch

Installation

NETGEAR ProSAFE® Smart Switch

XS728T

Package Contents

• NETGEARProSafeSmartSwitchXS728T

• Rubberfootpadsfortabletopinstallation

• ACpowercord

• 19-inchrack-mountkitforrackinstallation

• SmartSwitchresourceCD

Conﬁgure the Switch

InstalltheSmartControlCenterUtilityanduseittoconguretheswitch.

¾ To install the Smart Control Center Utility on a computer:

1. InserttheresourceCDintoyourCDdrive.

2. RuntheSetupprogramtoinstalltheSmartControlCenterUtility.

TheInstallationWizardguidesyouthoughtheinstallation.

Connect Your Switch

IfyouhaveaDHCPserverinyournetworkseeConnect the Switch to Your

Network.

IfyouareusingstaticIPaddressesinyounetwork,rstseeConﬁgure the

Switch with a Static IP Address,andthenseeConnect the Switch to Your

Network.

Conﬁgure the Switch with a Static IP Address

IfyouareusingastaticIPaddressinyounetwork,conguretheswitch

IPaddressbeforeconnectingtheswitchtoyournetwork.ThedefaultIP

addressoftheswitchis192.168.0.239.

Note: IfyouareusingaDHCPserverinyournetwork,thisprocedure

doesnotapplytoyou;instead,godirectlytoConnect the Switch to Your

Network.

¾ To conﬁgure the switch with a static IP address:

1. SetupthecomputerwithastaticIPaddressinthe192.168.0.xsubnet.

2. ConnectthecomputertotheswitchusinganEthernetcable.

3. Inabrowser,enterthedefaultIPaddressofyourswitch.ThedefaultIP

addressis192.168.0.239.

Aloginscreendisplays.

4. Enterpasswordforthepassword.

5. SelectSystem > Management > IP Conﬁguration.

6. EnterthestaticIPaddressyouwanttoassigntheswitch.

7. ClicktheApplybutton.

Connect the Switch to Your Network

¾ To connect the switch to your network:

1. ConnecteachcomputertoanRJ-45networkportontheswitchfront

panel.

UseCategory5e(Cat5e)orbetterEthernetcable(Cat6,Cat6a,orCat7)

terminatedwithanRJ-45connectortomake10Gconnections.

Note: Cat6aorCat7cablesarerecommendedifcabledistanceisgreater

than45m(148).

2. Connecttheswitchtoyournetwork.

3. Powerontheswitch.

4. VerifythatthecomputerwiththeSmartControlCenterUtilityisonthe

samesubnetastheswitch.

Conﬁgure the Switch with the Smart Control Center

Utility

¾ To conﬁgure the switch with the Smart Control Center Utility:

1. Double-clicktheSmartControlCenterUtilityicononyourdesktoporinthe

WindowsStartmenutoruntheutility.

TheSmartControlCenterdisplays.

2. ClicktheDiscoverbutton.

Servers

INTERNET

Computers

Smart Switch

Printers
