24" Microwave Drawer
F2412MVD8SS
INSTALLATION MANUAL
SPECIAL WARNING
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE this installation manual FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CLEARANCES AND DIMENSIONS
For SAFETY CONSIDERATIONS do not install drawer in any combustible cabinetry, which is not in accord
with the stated clearances and dimensions on pages 2 and 3. See Figure 1.
UNPACKING YOUR MICROWAVE DRAWER
·Remove all packing materials from inside the
Microwave Drawer.DO NOT REMOVE THE
WAVEGUIDE COVER，which is located on the top
of the Microwave Drawer.
·Remove the feature sticker, if there is one .Check
the drawer for any damage, such as misaligned or
bent drawer, damaged drawer seals and sealing
surfaces, broken or loose Microwave Drawer
guides and dents inside the cavity or on the front
side of the drawer. If there is any damage, do not
operate the Microwave Drawer and contact your
dealer or a MIDEA AUTHORIZED SERVICER.
IMPORTANT NOTES TO THE INSTALLER
·Read all of the Installation Manual before
installing the Microwave Drawer.
·Remove all packing material before connecting
the electrical supply.
·Observe all governing codes and ordinances.
·Be sure to leave these instructions with the
consumer.
IMPORTANT NOTES TO THE CONSUMER
Keep this manual with your Operation Manual for
future
reference.
·As when using any microwave oven generating
heat, there are certain safety precautions you
should follow. These are listed in the Operation
Manual. Read all and follow carefully.
·Be sure your Microwave Drawer is installed and
grounded properly by a qualified installer or
service technician.
IMPORTANT SAFETY INSTRUCTIONS
WARNING if the information in this manual is not
followed exactly, a fire or electrical shock may result
that could cause property damage, personal injury or
death.
WARNING To reduce the risk of tipping ,the
Microwave Drawer must be secured by a properly
installed Anti-Tip block.
·This Microwave Drawer must be electrically
grounded in accordance with local codes.
·Make sure the wall coverings and the cabinets
around the Microwave Drawer can withstand the heat
generated by the Microwave Drawer.
WARNING Never leave children alone or
unattended in the area where a Microwave Drawer
is in use. Never leave the drawer open when the
microwave is unattended.
WARNING Stepping ,leaning or sitting on the drawer
may result in serious injuries and can also cause
damage to the Microwave Drawer.
·Do not use the Microwave Drawer as a storage
space .This creates a potentially hazardous
situation.
·Check that the time-of-day is in the display. IF not,
touch Stop/Clear to prevent unintended use.
1
