1xKL52, 3xLED module, 1xBattery charger, 2x18650
battery, 1xRemote switch, 1xUniversal rapid mount,
1xPicatinny rail mount, 1xLanyard, 4xSpare O-ring,
1xWarranty card, 1xUser manual
PACKAGE INCLUDED
ZOOMABLE LONG RANGE LED GUN LIGHT
USER MANUAL
KL52 PLUS
Thank you for purchasing the KL52 PLUS flashlight!
Please read this manual carefully before using this
product.
High intensity LEDs with 50,000 hours lifespan
Rapid LED module change without tools
Two tubes design with covered threads to avoid
dirt and debris to get into
Fully adjustable from a flood to spot light beam
for the desired distance of each hunting
landscape
IPX-8 standard weatherproof design allows it to
be used during heavy rain
Made from precision machined high grade 6061
aircraft aluminum
Matte black finish and non-reflective with military
grade type III hard anodization
Versatile usage as a handheld, scope mounted
or rail mounted
KL52 plus is an innovative, watherproof hunting
light featuring innovative zoom/focus mechanism
design for adjustable focus and interchangeable
color LED modules. It is one of your must-have
hunting kits in your gun light arsenal.
Product Instruction
Product Features
With remote switch, press the remote switch to turn
on the light, release the switch to turn off the light.
TURN ON / TURN OFF
Hold the head of KL52 PLUS, and rotate the tail
cap to adjust the beam, the beam can be
adjusted from flood to spot.
FLOOD LIGHT / SPOT LIGHT
1.With the light off, half press the tailcap switch and
then release it, quickly half press the switch again,
the output will change to the next level.
2.With the light on, press the tailcap switch to turn
off the light. Press the tailcap switch again, the
output will change to the next level.Brightness level
will be followed by low-med-high-strobe-SOS.
MEMORIZED FUNCTION(
White- tailcap switch
)
If the light has been lit up over 3 seconds before
shutting off, press the tailcap switch to turn the light
on to the last output mode (including strobe and
SOS) that was in use.
CHANGE BGIHTNESS LEVEL (
White - tailcap switch
)
HOW TO OPERATE
click
memorized function
OFF
press & hold
release
tailcap switch
tailcap switch
tailcap switch
tailcap switch
click
OFF
ON
constant-on
over 3 sec.
click twice
red
green
white
IR850
output mode cycling
click
low med high strobe sos
SOS
ON
Remote switch
Remote switch
The KL52 PLUS comes with an unlock remote
switch.
Take down the original tailcap and fit on the
remoteswitchtotheflashlightforhunting.The
remoteswitchforKL52PLUScanbeusedwith
anylonggunorshotgun(notforpumpaction
weapons).Itdoesn'tmakeanoisy"click"
sound once you press and hold it with gloves.
HOW TO USE REMOTE-SWITCH
*The specifications in the chart above claim to ANSI/NEMA FL1-2009
Standards. Tests are performed with 1X 18650 battery (3.7V. 3000mAh).
All specification are subject to change without prior notice
SPECIFICATIONS
LED colors
HIGH
Run time Beam Distance
White 1.63HOURS 400 YARDS
Red 3.3HOURS 375 YARDS
Green 4.1HOURS 452 YARDS
IR850
Infrared is not visible to the human eye.
Use of IR viewing device is required
(WHITE)
lumens
IMPACT 1M/(3.28ft)
LENGTH (flood / spot ) 148mm(5.82in)/171mm(6.73in)
BEZEL DIAM 54mm / 2.12in
WEIGHT (w/o battery) 240g / 8.46oz
MED
(WHITE)
LOW
(WHITE)
SOS
(WHITE)
STROBE
(WHITE)
800
lumens
240
lumens
36
lumens
800
lumens
800
When the battery is low, the light will start to shine
weakly. We suggest you charge the batteries after
every use to keep them ready to use. Place the
battery properly into the charger.
1.Remove the head of KL52 PLUS
2.Rotate the tail cap toward to LED side
3.Unscrew and replace with different clolor LED
module
4.Screw up the head of KL52 PLUS as far as it can
go.
HOW TO CHARGE BATTERY
MODULE REPLACEMENT
Red LED : charging in progress.
Green LED : charging fully completed.
Please ensure the positive end (+) pointing to the
head of light and insert the battery properly. If the
battery is not installed correctly, the light can not
turn on properly.
+
-
*
1.Please keep the battery positive pole (+)
towards the flashlight head (The LED direction).
2.Odepro recommends using excellent quality
battery. If the light will not be used for an
extended period, remove the battery to avoid
damage from electrolyte leakage or battery
explosion.
FLASHLIGHT MAINTENANCE
Replace the LED module
Twist to remove the LED module
BODY
HEAD
3.Long-term use can result in O-ring abrasion.
Check the condition of O-rings every time you
open the body of the light. Replace the ring with
an approved spare to keep the light properly
sealed against water.
4.Please clean the contacts of your light periodi-
cally to keep the light performance good,
especially when the light flickers or does not light
up. There are probably several reasons for a
flickering or not working light as following:
Reason A: The battery need to be replaced.
Solution: Replace battery (please confirm the
correct installation of anode and cathode).
Reason B: The threads, PCB board contact or
other contacts are dirty.
Solution: Clean the contact points with a cotton
swab soaked in rubbing alcohol. If the above
methods don’t work, please refer to the warranty
policy and contact us for customer service.
Danger:
Never point the flashlight into your eyes or the
eyes of other people otherwise it will cause your
eyes blind or get hurt.
(1)30 days free replacement: Return to Odepro
for free replacement.
(2) 24 months free repair: Reture to Odepro for
repair.
(3) Limited lifetime warranty: If problems develop
after 24 months of the purchase, we will charge
for parts. The total repair fee is assessed
according to the cost of the replaced materials.
This warranty does not cover normal wear and
modifications, misuse, disintegrations,
negligence, accidents, improper maintenance,
or repair by anyone other than Odepro itself.
CUSTOMER SERVICE: service@odepro.com
www.odepro.com
Odepro Technology Co., Ltd.
Add 7F,Building 6,Yusheng Industrial
Park,Gushu,Xixiang,
Baoan,Shenzhen,China 518102
Tel +86-755-36538983
Fax +86-755-29454989
WARRANTY
